Giga-tronics 7011 User manual

Manual 07507011 Model 7011
Page 1
Operation Manual
Model 7011
(2x16) 2-wire Matrix
91000140

Manual 07507011 Model 7011
Page 2
Operation Manual
All technical data and specifications in this publication are subject to change without prior notice and do
not represent a commitment on the part of Giga-tronics, Incorporated.
© 2011 Giga-tronics Incorporated. All rights reserved. Printed in the U.S.A.
CONTACT INFORMATION
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]
On the Internet: www.gigatronics.com
Warranty
Giga-tronics Series 7000 Switching Modules are warranted against
defective materials and workmanship for three yearsfrom date of shipment,
or as detailed in the warranty section of this manual. Giga-tronics will, at its
option, repair or replace products that are proven defective during the
warranty period. This warranty DOES NOT cover damage resulting from
improper use, nor workmanship other than Giga-tronics service. There is no
implied warranty of fitness for a particular purpose, nor is Giga-tronics liable
for any consequential damages. Specification and price change privileges are
reserved by Giga-tronics.

Manual 07507011 Model 7011
Page 3
Operation Manual
Regulatory compliance information
This product complies with the essential requirements of the following applicable European
Directives, and carries the CE mark accordingly.
89/336/EEC and 73/23/EEC
EMC Directive and Low Voltage Directive
EN61010-1 (1993)
Electrical Safety
EN61326-1 (1997)
EMC –Emissions and Immunity
Manufacturer’s Name:
Manufacturer’s Address
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
U.S.A.
Type of Equipment:
Model Series Number
Switching Module
7011
Declaration of Conformity on file. Contact Giga-tronics at the following;
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]

Manual 07507011 Model 7011
Page 4
Operation Manual
Record of Changes to This Manual
Use the table below to maintain a permanent record of changes to this document. Corrected
replacement pages are issued as Technical Publication Change Instructions (TPCI). When you
are issued a TPCI, do the following:
1. Insert the TPCI at the front of the manual binder.
2. Remove the pages from the manual binder that are noted in the TPCI.
3. Replace the page(s) removed in the previous step with the corrected page(s).
4. Record the changes in the table below.
TPCI
Number
TPCI Issue
Date
Date Entered
Comments

Manual 07507011 Model 7011
Page 5
Operation Manual
Revision History
Revision
Description of Change
Chg Order #
Approved By
A
Initial Release 2/02
JL
B
Updated
C
Reformatted 5/12
RCW

Manual 07507011 Model 7011
Page 6
Operation Manual
Contents
Contents........................................................................................................................................................6
Chapter 1 Introduction .................................................................................................................................7
1.1 Safety and Manual Conventions.........................................................................................................7
1.1.1 Product Reference.......................................................................................................................7
1.1.2 Personal Safety Alert...................................................................................................................7
1.1.3 Equipment Safety Alert ...............................................................................................................7
1.1.4 Notes ...........................................................................................................................................7
1.1.5 Electrical Safety Precautions ....................................................................................................... 7
Chapter 2 Configuration Table....................................................................... Error! Bookmark not defined.
Chapter 3 Functional Description .................................................................................................................9
3.1 Introduction........................................................................................................................................9
3.2 General Description............................................................................. Error! Bookmark not defined.
Chapter 4 Block Diagram ............................................................................................................................10
Chapter 6 Specifications .............................................................................................................................11
Chapter 7 Register Map ................................................................................. Error! Bookmark not defined.
Chapter 8 Front Panel Connector Pins........................................................... Error! Bookmark not defined.

Manual 07507011 Model 7011
Page 7
Operation Manual
Chapter 1 Introduction
1.1 Safety and Manual Conventions
This manual contains conventions regarding safety and equipment usage as described below.
1.1.1 Product Reference
Throughout this manual, the term “Common Core Switching Platform, Series 8800” refers to all models
of within the series, unless otherwise specified.
1.1.2 Personal Safety Alert
WARNING: Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
1.1.3 Equipment Safety Alert
CAUTION: Indicates a situation which can damage or adversely affect the product or
associated equipment.
1.1.4 Notes
Notes are denoted and used as follows:
NOTE: Highlights or amplifies an essential operating or maintenance procedure, practice, condition or
statement.
1.1.5 Electrical Safety Precautions
Any servicing instructions are for use by service-trained personnel only. To avoid personal injury, do not
perform any service unless you are qualified to do so.
For continued protections against fire hazard, replace the AC line fuse only with a fuse of the same
current rating and type. Do not use repaired fuses or short circuited fuse holders.
WARNING
!
CAUTION

Manual 07507011 Model 7011
Page 8
Operation Manual
Chapter 2 Configuration Table
Module
PL91000140
Assy91000140
Schematics
PL85003630
Assy85003630
SCH85003630

Manual 07507011 Model 7011
Page 9
Operation Manual
Chapter 3 Functional Description
3.1 Introduction
This card assembly contains an unshielded 2 x 16 dual wire matrix. The unit is completely compatible
with the National Instrument PXI series chassis. The Model 7011 also meets the requirements found in
the PXI specifications. Such compatibility allows the unit to be used in complex PXI systems with a
minimum of concerns.

Manual 07507011 Model 7011
Page 10
Operation Manual
Chapter 4 Block Diagram
CH B (H)
CH B (L)
16
Port 1 (L)
Port 1 (H)
Port 16 (L)
Port 16 (H)
Analog Groundplane
CH A (H)
CH A (L)

Manual 07507011 Model 7011
Page 11
Operation Manual
Chapter 6 Specifications
Electrical:
Bandwidth: 50 MHz
Max. switching power: 60 W or 62.5 VA
Max. switching current : 2 Amp
Max. switching voltage: 220 VDC or 250 VAC
Min. mech. life expectancy: 500K cycles
Initial Contact Resistance: < 60mΩ
Mechanical:
Size: 3U PXI
Width: 0.8 inches
Height: 5.2 inches
Length: 6.5 inches
Weight: 0.5 lbs.
J1 & J2 connectors: AMP (TYCO) #104129-9
Mating Connectors: ASCOR Installation Kit P/N 89800700
Environmental Specifications
Temperature:
Operating: 0º to 55ºC
Storage: - 40º to 75ºC
Relative Humidity:
Operating: 0 to 90% non-condensing
Storage: 0 to 95% non-condensing

Manual 07507011 Model 7011
Page 12
Operation Manual
Chapter 7 Programming
The Model 7011 is a PXI register based card assembly design to be used with PXI standard chassis. The
Model 7011 can be programmed in 8, 16 or 32 bit wide data format. Through your PXI controller, write
the data to the appropriate register as shown on the register map for the relay or relays in the register
that is being closed. When the data bit is true, the relay chosen will be closed. The state of the relays in
a register can be determined by reading the desired register. Data read back represents the value of the
desired register. In addition, you can read back the coil state to verify that the coil is driven correctly by
the program register. This scenario verifies that the program register has correctly controlled the relay
coil.
The register map is organized to show the relay designation in each register. It is followed by the
register’s functionality and the path connections to the front panel. PXI will automatically assign the
starting address of the card, called Bar0. This will be the starting address of the first register. Each
address location controls 8 bits. Shown are the control functions using 16 format.
Programming of the Model 7011 is very straight forward. The module is organized as a 2 x 16 dual wire
matrix. The location of the first register is assigned by the PCI enumerator. This is designated as “Bar0”
or the starting address of the card. The program registers using 16 bit format are located as follows:
Register #1: read/write function: Bar0 + 0000h
coil read back: Bar0 + 0008h
Register #2: read/write function: Bar0 + 0002h
coil read back: Bar0 + 000Ah

Manual 07507011 Model 7011
Page 13
Operation Manual
Chapter 8 Connector Pin Assignments
J1 –FRONT PANEL CONNECTOR
Description
Pin #
Pin #
Description
Not Used
50
49
Not Used
Not Used
48
47
Not Used
Not Used
46
45
Not Used
Not Used
44
43
Not Used
Not Used
42
41
Not Used
Analog Ground
40
39
Analog Ground
PIN 1A
38
37
PIN 1B
PIN 2A
36
35
PIN 2B
PIN 3A
34
33
PIN 3B
PIN 4A
32
31
PIN 4B
PIN 5A
30
29
PIN 5B
PIN 6A
28
27
PIN 6B
PIN 7A
26
25
PIN 7B
PIN 8A
24
23
PIN 8B
PIN 9A
22
21
PIN 9B
PIN 10A
20
19
PIN 10B
PIN 11A
18
17
PIN 11B
PIN 12A
16
15
PIN 12B
PIN 13A
14
13
PIN 13B
PIN 14A
12
11
PIN 14B
PIN 15A
10
9
PIN 15B
PIN 16A
8
7
PIN 16B
Channel 1A
6
5
Channel 1B
Channel 2A
4
3
Channel 2B
Analog Ground
2
1
Analog Ground
