Chapter 2 Functional Description
2.1 Introduction
This manual provides the necessary information for the Model 4504 card assembly.
2.2 General Description
This card assembly contains twenty form A 20 amp relays. This card assembly fits in an ASCOR’s series
4000 VXI host modules which can be a 3 wide to 8 wide VXI module with the capacity for six to 17 card
assemblies. This card occupies two 0.5 inch slots or 1 inch width. This allows of ease in design of
complex switch systems. The Series 4000 host VXI module contains sixteen 2-wire analog back plane to
allow connections between card assemblies without the need of external cabling. This architecture
produces a high performance switch system without the usual custom designs or external wiring and
integration efforts. The interface and mechanical construction of the Series 4000 VXI module and card
assemblies meets the specification of the VXIbus System Specification, rev. 1.2 and 1.3.
This card assembly requires a ASCOR Series 4000 host VXI module. It is not a stand alone VXI module.

Manual 07504504 Model 4504
Page 9
Operation Manual
Chapter 3 Block Diagram
20 Channels
Analog Groundplane

Manual 07504504 Model 4504
Page 10
Operation Manual
Chapter 4 Specifications
Electrical:
Switching Voltage (DC/Peak, AC, Resistive): 200VDC, 250VACpk
Switching Current (DC/Peak, AC, Resistive): 20 Amps
Max Switching Power: 280W, 5000VA
Contact resistance <1 Ω
Mechanical:
Thickness: 1 inches
Width: 7.825 inches
Length: 10.75 inches
Weight: 2 lbs.
Connectors:
Connector: Positronic # PLC30M10830
Environmental Specifications
Temperature:
Operating: 0º to 55ºC
Storage: - 40º to 75ºC
Relative Humidity:
Operating: 0 to 90% non-condensing
Storage: 0 to 95% non-condensing

Manual 07504504 Model 4504
Page 11
Operation Manual
Chapter 5 Register Map
5.1 Introduction
The Model 4504 is a VXI register based card assembly design to be used with the ASCOR Series 4000
host VXI module. The switch paths are controlled by a high speed interface called VXImax™ is a 16/32
bit data controller. The Model 4504 can be programmed in 16 bit or 32 bit wide data format. Through
your VXI controller, write the data to the appropriate register as shown on the register map for the relay
or relays in the register that is being closed. When the data bit is true, the relay chosen will be closed.
The state of the relays in a register can be determined by reading the desired register. The data read
back represents the value at the coil of the relay. This allows verification that the program register has
correctly controlled the relay coil.
The following register maps are shown in two configurations: 16 bit mode and 32 bit mode. In each
section, 16 bit and 32 bit, the register map is organized to show the relay designation in each register. It
is followed by the register’s functionality and the path connections to the front panel.

Manual 07504504 Model 4504
Page 12
Operation Manual
Programming of the Model 4504 is very simple. The base offset address for the Model 4504 is 8000h.
The total offset of the card is dependent on the location of the card in the host VXI module, Series 4000.
The offset is x8000h where x is the card location number in hexadecimal.
Register Map
A16 Register
Offset Value
00h 7Fb5h
7= Register Based, A16/A24 Module
FB5=VXI Manufacturer ID, ASCOR
02h 7xxxh
7=A24 space requirement
xxx= Model Number for this module (see host module)
04h FFFCh
06h (assigned by Resource Manager)
Control Bit
3Eh 0 Low true output to enable coil driver IC’s
1 When low enables readback of coil state
2 High true EEPROM write enable (factory only)
3-15 Don’t care

Manual 07504504 Model 4504
Page 13
Operation Manual
16-bit Mode
REGISTER: 8000h
MODE: 16 bit
FUNCTION: Control Matrix K1 through K15, 1x4 #'s 1-5
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x4 #1
K1
nc to K2, no to K3
1
1x4 #1
K2
com to K1 nc
2
1x4 #1
K3
com to K1 no
3
1x4 #2
K4
nc to K5, no to K6
4
1x4 #2
K5
com to K4 nc
5
1x4 #2
K6
com to K4 no
6
1x4 #3
K7
nc to K8, no to K9
7
1x4 #3
K8
com to K7 nc
8
1x4 #3
K9
com to K7 no
9
1x4 #4
K10
nc to K11, no to K12
10
1x4 #4
K11
com to K10 nc
11
1x4 #4
K12
com to K10 no
12
1x4 #5
K13
nc to K14, no to K15
13
1x4 #5
K14
com to K13 nc
14
1x4 #5
K15
com to K13 no
15
-
-
-
-
REGISTER: 8002h
MODE: 16 bit
FUNCTION: Control Matrix K16 through K20, 1x2 #'s 1-5
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x2 #1
K16
1
1x2 #2
K17
2
1x2 #3
K18
3
1x2 #4
K19
4
1x2 #5
K20
5
-
-
-
6
-
-
-
7
-
-
-
8
-
-
-
9
-
-
-
10
-
-
-
11
-
-
-
12
-
-
-
13
-
-
-
14
-
-
-
15
-
-
-

Manual 07504504 Model 4504
Page 14
Operation Manual
32-Bit Mode
REGISTER: 8000h
MODE: 32 bit
FUNCTION: Control Matrix K1 through K20, 1x4 #'s 1-5 1x2 #'s 1-5
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
1x4 #1
K1
nc to K2, no to K3
1
1x4 #1
K2
com to K1 nc
2
1x4 #1
K3
com to K1 no
3
1x4 #2
K4
nc to K5, no to K6
4
1x4 #2
K5
com to K4 nc
5
1x4 #2
K6
com to K4 no
6
1x4 #3
K7
nc to K8, no to K9
7
1x4 #3
K8
com to K7 nc
8
1x4 #3
K9
com to K7 no
9
1x4 #4
K10
nc to K11, no to K12
10
1x4 #4
K11
com to K10 nc
11
1x4 #4
K12
com to K10 no
12
1x4 #5
K13
nc to K14, no to K15
13
1x4 #5
K14
com to K13 nc
14
1x4 #5
K15
com to K13 no
15
-
-
-
16
1x2 #1
K16
17
1x2 #2
K17
18
1x2 #3
K18
19
1x2 #4
K19
20
1x2 #5
K20
21
-
-
-
22
-
-
-
23
-
-
-
24
-
-
-
25
-
-
-
26
-
-
-
27
-
-
-
28
-
-
-
29
-
-
-
30
-
-
-
31
-
-
-

Manual 07504504 Model 4504
Page 15
Operation Manual
Chapter 6 CONNECTOR PIN LIST
J1 J2
CONN
RELAY
CONN
RELAY
J1-01
---
J2-01
---
J1-02
---
J2-02
---
J1-03
---
J2-03
---
J1-04
---
J2-04
---
J1-05
---
J2-05
---
J1-06
---
J2-06
---
J1-07
---
J2-07
---
J1-08
---
J2-08
---
J1-09
---
J2-09
---
J1-10
---
J2-10
---
J1-11
K01-COM
J2-11
K11-COM
J1-12
K02-COM
J2-12
K12-COM
J1-13
K03-COM
J2-13
K13-COM
J1-14
K04-COM
J2-14
K14-COM
J1-15
K05-COM
J2-15
K15-COM
J1-16
K06-COM
J2-16
K16-COM
J1-17
K07-COM
J2-17
K17-COM
J1-18
K08-COM
J2-18
K18-COM
J1-19
K09-COM
J2-19
K19-COM
J1-20
K10-COM
J2-20
K20-COM
J1-21
K01-NO
J2-21
K11-NO
J1-22
K02-NO
J2-22
K12-NO
J1-23
K03-NO
J2-23
K13-NO
J1-24
K04-NO
J2-24
K14-NO
J1-25
K05-NO
J2-25
K15-NO
J1-26
K06-NO
J2-26
K16-NO
J1-27
K07-NO
J2-27
K17-NO
J1-28
K08-NO
J2-28
K18-NO
J1-29
K09-NO
J2-29
K19-NO
J1-30
K10-NO
J2-30
K20-NO
NO = NORMALLY OPEN; COM = COMMON; NC = NORMALLY CLOSED

Manual 07504504 Model 4504
Page 16
Operation Manual
ASCOR 4504 VXI Card Assembly Module Programming Guide
The base offset address for the Model 4504 is 8000h. The total offset of the card is dependent
on the location of the card in the host VXI module, Series 4000. The offset is x8000h where x is
the card location number in hexidecimal.
refer to the program guide in the Series 4000 host VXI module manual for programing this card
