English
EN
004
2. GIGABYTE Notebook Tour
14
15
1
2
3
4
5
6
7
12 13
9
810
11
1Microphone 9MicroSD Card Reader (UHS-II)
2Webcam 10 Audio Combo Jack
3Display Panel 11 Thunderbolt 4 Port (USB type-C)
4Light Sensor Area* 12 HDMI 2.1
5Power Button 13 USB 3.2 Port (USB type-A)
6Keyboard 14 Battery Reset Hole**
7Touchpad 15 Speaker
8DC-in charge (Type-C)
* The system will adjust the brightness of the screen automatically according to the ambient light, beware not to cover this area.
** Whenever the system hangs, please:
(1) power off the notebook ; (2) remove the AC power; (3) use a straightened paperclip and insert it to this hole for 4 secs ; (4)
waiting for 15 secs then connect the AC power; (5) power on the notebook.
IMPORTANT:
● Do not remove the built-in lithium battery.
For any service needs, please contact your local GIGABYTE Authorized Service Center.
● Do not install the Notebook PC on a slant or a place prone to vibrations, or avoid using the Notebook PC in that location for
a long time.This increases the risk that a malfunction or damage to the product will occur.
● Do not store and use Notebook PC in direct sunlight or the location where temperatures exceed 112°F (45°C) such
as inside a vehicle.There is a danger of Lithium-ion battery expansion and aging.
● Do not use the Notebook PC in a badly ventilated location such as on bedding, on a pillow or cushion, etc, and do not use it
in a location such as room with floor heating as it may cause the computer to overheat.Take care that the Notebook PC vents
(on the side or the bottom) are not blocked especially in these environments. If the vents are blocked, it may be dangerous and
cause the Notebook PC to overheat.
