AV64S-TGraphics Accelerator
Copyright
CopyrightbyGIGA-BYTETECHNOLOGYCO., LTD.(“GBT”)Nopartofthismanual
maybe reproducedortransmittedinanyfromwithoutthe expressed,written permissionof
GBT.
Trademarks
Third-partybrandsand namesarethe propertyoftheirrespectiveowners.
Notice
Due torapidchange intechnology,someofthe specificationsmightbe outofdatebefore
publicationofthisbooklet.
The authorassumesnoresponsibilityforanyerrorsoromissionswhichmayappearinthis
documentnordoesitmakeacommitmenttoupdatethe informationcontainedherein.
Pleasedo notremoveanylabelson VGAcard,thismayvoidthe warrantyofthisVGA
card.
March17,2003Taipei,Taiwan
Chapter1User’sManual
Thisproductincorporatescopyrightprotection technologythatisprotected by
method claimsofcertainU.S.patentsand otherintellectualpropertyrights
owned byMacrovision Corporation and otherrightsowners.Useofthis
copyrightprotection technologymustbe authorized byMacrovision
Corporation,and isintended forhomeand otherlimited viewing usesonly
unless otherwiseauthorized byMacrovision Corporation.Reverseengineer-
ing ordisassemblyisprohibited.

3
TableofContent
TableofContents
1.INTRODUCTION
1.1.PREFACE...................................................................................4
1.2.Overview....................................................................................4
2.HARDWAREINSTALLATION
2.1.UNPACKING...............................................................................5
2.2.BOARD LAYOUT.........................................................................6
2.3.HARDWAREINSTALLATION.......................................................7
3.SOFTWAREINSTALLATION
3.1Win98 /98SEorWinME/WinXPDriverAnd UtilitiesInstallation ..........9
3.1.1Operatingsystemrequirement ..................................................9
3.1.2DirectXinstallation .................................................................. 10
3.1.3Driverinstallation ................................................................... 12
3.1.4Utilitieson driverCD .............................................................. 15
3.1.5TaskbarIcon ......................................................................... 15
3.1.6Propertypages..................................................................... 18
3.2.WINDOWSNT4.0DRIVERINSTALLATION.............................. 23
3.3.WINDOWS2000 DRIVERINSTALLATION................................... 24
3.4BIOSFLASHUTILITY................................................................ 24
4.TroubleshootingTips................................................................................. 25
5.Appendix
5.1.Howtorefashthe BIOS............................................................... 26
5.2.ResolutionsandColorDepthTable.............................................. 28

4
AV64S-TGraphics Accelerator
1.INTRODUCTION
1.1.PREFACE
AV Seriesdeliversenhanced3Dand 2Dgraphicsperformancefortoday’sdemandingapplications.
Powered bythe ATiRADEON™7000Egraphics processorand 32 /64 MBSDR memory;MayaAV
SeriesfeaturesHYPERZ™technologytoincreaseeffectivememorybandwidthand PIXELTAPES-
TRY™forfastimage rendering.AV Serieshasindustryleading,built-inDVDplayback capability..
1.2.KEY FEATURES
nPoweredbytheRADEON™7000Egraphics processor
nATIHYPERZ™ technologyreducesmemorybandwidthconsumption
resulting inimproved3Dperformance
nIncredible3Dgraphics performance withATIPIXELTAPESTRY™3D
renderingengine
nSupportsDirectX®7.0,DirectX®8.xandOpenGL®
nDVDplayback withintegratedmotion compensationand iDCT
nSupports3Dresolutions(32-bitcolor)up to2048x1536
nAGPuniversalbus(forAGP2X/4Xsystems)
nSupportTV-OUT
Chapter 1 User's Manual

5
HardwareInstallation
2.HARDWAREINSTALLATION
WARNING!
ExpansioncardscontainverydelicateIntegratedCircuit(IC)chips.Toprotectthemagainst
damage fromstaticelectricity,youshouldfollowsomeprecautionswheneveryou workonyour
computer.
1.Turnoffyourcomputerand unplug powersupply.
2.Useagrounded wriststrap beforehandling computercomponents.Ifyoudo nothaveone,touch
bothofyourhandstoasafelygrounded objectortoametalobject, suchasthe powersupply
case.
3.Placecomponentsonagrounded antistaticpadoronthebag thatcamewiththe components
wheneverthe componentsareseparated fromthe system.
Thecardcontainssensitiveelectriccomponents,whichcan be easilydamaged bystaticelectricity
,sothe cardshouldbe leftinitsoriginalpacking untilitisinstalled.
Unpackingandinstallationshouldbedoneonagroundedanti-staticmat.Theoperatorshouldbe
wearingananti-staticwristband,grounded atthe samepointasthe anti-staticmat.
Inspectthe cardcarton forobviousdamage.Shipping and handlingmaycausedamage toyour
card.Besuretherearenoshippingand handlingdamagesonthecardbeforeproceeding.
MDONOTAPPLYPOWERTOYOUR SYSTEMIFITHASBEENDAMAGEDONTHE
CARD.
MInordertoensureyourgraphics cardworkingcorrectly,please useofficialGigabyte
BIOSonlyUse noneofficialgigabyteBIOSmightcause problemonthegraphics card.
2.1.UNPACKING
TheAV64S-Tpackagecontainsthefollowing:
lTheAV64S-Tgraphicsaccelerator
lThisUSER'SMANUAL
l DVDPlayersoftwareincluded
lFull version Gamex1(CD x1)
lLiteversion Gamex2(CD x1)
lCD fordriver&Utilities

6
AV64S-TGraphics Accelerator
2.2.BOARD LAYOUT
AV64S-T(8Mx16 64MBSDRAM)
8Mx16 FrameBufferSDRAM
BIOSATi
RADEON7000E
S-Video
(TV-Out)
VGAMonitor
Connector
(15pin)
CompositeRC AOutput
S-Video Output
VGAOutput
CompositeRCA
Connector
(TV-OUT)
S-Video
(TV-Out)
VGAMonitor
Connector
(15pin)
CompositeRCA
Connector
(TV-OUT)

7
HardwareInstallation
2.3.HARDWAREINSTALLATION
Installing YourGraphicscard..
Nowthatyou haveprepared yourcomputer,you arereadytoinstall yourgraphics
acceleratorcard.
Toinstall yourgraphics acceleratorcard
1.Poweroff thecomputerandmonitor,thendisconnectthe displaycablefromthe
backofyourcomputer.
2.Removethe computercover.Ifnecessary,consultyourcomputer'smanualforhelp
inremoving the cover.
3.Removeanyexisting graphicscardfromyourcomputer.
Or,ifyourcomputerhasanyon-boardgraphics capability,you mayneed todisableit ...
onthe motherboard.Formoreinformation,seeyourcomputerdocumentation.

8
AV64S-TGraphics Accelerator
4.Locatethe AGPslot. Ifnecessary,removethe metalcoverfromthisslot;then align
yourGraphicscardwiththeAGPslot, andpress itinfirmlyuntil the cardisfully
eated.
5.Replacethescrewtofasten thecardinplace,andreplacethecomputercover.
6.Plug thedisplaycableintoyourcard;then turnonthe computerand monitor.
You arenowreadytoproceed withthe installation oftheGraphics carddriver.Fordetailed
instructions,selectyouroperatingsystemfromthelistbelow:
AV64S-TGraphics card
AGPSlot
AV64S-TGraphics card
ToVGAMONITOR
S-Video
(TV-Out)
CompositeRCA
Connector
(TV-OUT)

9
SoftwareInstallation
3.SOFTWAREINSTALLATION
Inthismanual, weassumethatyourCD-ROMDrive lettertobeDrive D:
3.1.WINDOWS®98 /98SE orWINDOWSME/WINDOWSXP DRIVER
AND UTILITIES INSTALLATION
The installation ofWin98/98SE /WinME/WinXP driversisverysimple.
When you insertthe driverCD intoyourCD-ROMdrive,you can see the AUTORUN
window(ifitdoesnotshowup,run "D:\setup.exe").Thenyou can followguidestosetup
yourAV64S-Tdriver(Pleasefollowthe subsection3.1.3"StepByStepInstallation"to
install the driverforyourgraphics accelerator.
3.1.1.Operatingsystemrequirement
lIf yourOSisMicrosoftWindows,when loading the AV64S-Tdriversforthe
system,pleasemakesureyoursystem(Windows98/98SEorWindowsME)has
installed DirectX8.1orlater.
lIf youinstall the AV64S-Tdriversforthe mainboard,which
consistofSIS,ALIorVIAchipsets,pleaseinstall theappropriateDriverprogramfor
thatmainboard.OrpleasecontactyourmotherboardnearestdealerforM/BDiver.

10
AV64S-TGraphics Accelerator
3.1.2.DirectXInstallation
InstallMicrosoft DirectX8.1toenable3Dhardwareacceleration supportforWin98/98SE or
WinMEtoachievebetter3Dperformence.
Note:ForsoftwareMPEGsupportinWin98/98SE orWinME,youmustDirectXfirstinstall.
2.Click "Yes"icon.
3.Click "Yes“icon.
1.Installation DirectXDriver
Click "DisplayDriverSetup Utility”Item.

11
SoftwareInstallation
4.Click "OK"item.

12
AV64S-TGraphics Accelerator
3.1.3.DriverInstallation
Thefollowing isthe step-by-stepinstallation guide.
Step1:NewHardwareFound
AfterAV64S-Tisinsertedintoyourcomputeratthefirsttime,thewindowswillautomatically
detectanewhardwareinthe systemand pop outa"NewHardwareFound"message.
Pleaseselect"Donotinstall adriver"and press OK.
Step2:UpdateDevice DriverWizard:StandardPCIGraphics Adapter(VGA)
Step3:UpdateDevice DriverWizard:Finish
Atthistime,systemwill ask foryourWindowsCD inordertocompletethe VGAdriver
installation.
If you don'thavetheCD,you can pressC:\Windows\Systemdirectory.
Step4:SystemSetting Change
1.Click "Next“icon.
2..Click "Finish“icon.
MDon’tclick “Cancel”,because
the systemwill hang ifyou press it.

13
SoftwareInstallation
Afterthe systemhasfinished loading,inserttheAV64S-TdriverCD disk intoyourCD-
ROM,and then you can see the AUTORUNwindow.If itdoesnotshowup,pleaserun
"D:\setup.exe".
3..Click "NO“icon.
Step5:DriverSetup
1.Click "Install DisplayDriver(Radeon
VE Series)

14
AV64S-TGraphics Accelerator
2..Click “Next“icon.
3.Click “Yes”icon.
4.Click “Finish”icon torestart
computer.

15
SoftwareInstallation
3.1.5TaskbarIcon
3.1.4.Utilities on driverCD
The utilitiesinclude DisplayDriverand V-Tunerutilities.Pleasebrowsethe driverCD for
detail.
Afterinstallation ofthe displaydrivers,youwill findan GBTicon onthe taskbar’sstatus
area.Right-clicking thisicon opensthe GBTcontrolpanel,showing amenu composedof
shortcuteofthegraphicsboard’senhancedandotherfunctions.
Youmayclickthe “DisplayProperties”item,andthenclick Settings.Click “Advanced”after
clickngSettings.Click theappropriatetabtochange yourdisplaysettings.
You canlinktoGBTweb site
forupdatedinformationabout
thegraphicsborad,latest
drivers,andotherinformation.

16
AV64S-TGraphics Accelerator
V-Tuner(Overclock Utility)
V-Tunerletsyou adjustthe working frequency ofthe graphicengine and
video memory(CoreClock and MemoryClock)

17
SoftwareInstallation
VGAInfo
VGAInfoliststhe relevantinformation aboutyourcard.
ColorAdjust
ColorAdjustallowsyou tomakecoloradjustments,suchasbrightness,
contrast, and gammavaluesforeachorall ofRGBcolors.

18
AV64S-TGraphics Accelerator
3.1.6.DisplayPropertypages
The screenshowstheinformation ofdisplayadapter,color,therange ofdisplayarea ..
andtherefreshrate.
Setting (Resolutionsand Colordepthforwindows)
TheSetting propertiespage allowsyou toadjusttheDirect3Dsettings
OptionsProperties
Click”Advanced..”icon foradapter
andsetting.
You can click the itemtochange the
colordepth.
You can movethe slidertothe
changeresolution.
nEnableATItaskbariconapplication enablesor
disablesthe ATItaskbaricon.However,thisfeature
mustbe enabled forATIhotkeysupport.
nShowATIicon on taskbaraddsorremovestheATI
icon fromthe taskbar.

19
SoftwareInstallation
OpenGLProperties:
The OpenGLpropertiespage givesyou completecontrolofthe OpenGLsettings.
nOptimizationPreference
lQualityallowsyou tooptimizeyourOpenGLsettingsforquality.
lPerformance allowsyou tooptimizeyourOpenGLsettingsforperformance
nOpenGLSettings
lConvert32bittexturesto16 bitallowsyoutoincreasevideo performanceforgames
thatmakeheavyuseoftextures.Howeverthiscouldalsoreduceimage quality.
lEnableKTXbufferregionextension enablesrapidupdatesofthoseportionsofyour
screenthathavebeenmoved.
lEnablepageflipping allowsyoutoenablehardwareaccelerationofpageflippingto
swap fullscreen buffers.
lForce 16-bitZ-buffering allowsyou todisableallotherformatsofZ-bufferand utilizes
16-bitZ-buffering.
lDisabledithering whenalphablending mayremoveartifactslefton the screen
whenbothdithering andalphablendingareenabled.
lWaitforverticalsynclowersthe framespersecondrateinfullscreen games
Howeverthiscan reducethe image tearing thatcanoccurwithhigherframerates.
lEnabletexturecompressionenablesand disablestexturecompression.
lFull Screenanti-aliasing allowsyou tosetthe leveloffull-screen anti-aliasing.This
will resultinan overall higherqualityimage withaslightreduction inperformance.

20
AV64S-TGraphics Accelerator
Direct3DDisplayProperties
TheDirect3Dpropertiespageallowsyou toadjusttheDirect3Dsettings.
D3DSettings
nWaitforverticalsyncallowsyou tolowerthe framerateoffull screen games.Thiswill
reduceimagetearingthatcan occurwithhigherframerates.
nW-buffersupportallowsyoutoenableordisableW-buffersupport. ItisrecommendthatW-
buffersupportshouldbedisabled forgamesthatdonotsupportthisfeature.
nCompressedtextureformatallowsyoutoenablesupportforDirectXcompressed texture
formats.Someapplicationscannothandletoo manytextureformats.Disablingcompressed
textureformatthe video driverceasestosupportthisfeature.
nAlternatepixelcentermayeliminateproblemswithsome3Dgamesthatdisplaysvertical.
andhorizontallinesaround texturesortextthatappearsincorrect. However,thissetting
shouldonlybe usedifyou areexperiencing thesesymptoms,asitmaycauseproblems
withothergames.
nZ-bufferbitdepthsallowsyou tosetthe Z-bufferbitrate.Bydefault16:24(16 and 24)is
selectedtoachieveoptimumperformance.
8-bitStencil allowsyou toadd 32-bitZ-bufferwith8bitsforstencil and 24 bitsfortheZ-buffer.
lAnisotropictexturefiltering allowsyoutosetalevelofanisotropictexturefiltering.
Thiswill resultinmuchhigherqualitytextureswithanegligiblereduction inperformance.
lLevelofDetail allowsyou tosetthe levelofmipmapped detail.
The Sharpsetting isrecommendedforlarger,moredetailed,mipmappingscenes.The
Fuzzysetting isrecommendedforsmaller,lessdetailed,mipmapping scenes.
