GV-R7500L
RADEONTM7500 Graphics Accelerator
REV.103
12MD-R7500L-103
USER'SMANUAL
中文使用手冊
Upgrade your Life

GV-R7500L GraphicsAccelerator-2-
English
Copyright
CopyrightbyGIGA-BYTETECHNOLOGYCO., LTD.(“GBT”)Nopartofthismanual
maybe reproduced ortransmitted inanyfromwithoutthe expressed,written permission
ofGBT.
Trademarks
Third-partybrandsand namesarethe propertyoftheirrespectiveowners.
Notice
Due torapidchange intechnology,someofthe specificationsmightbe outofdatebefore
publication ofthisbooklet.
The authorassumesno responsibilityforanyerrorsoromissionswhichmayappearin
thisdocumentnordoesitmakeacommitmenttoupdatethe information contained
herein.
Pleasedo notremoveanylabelson VGAcard,thismayvoidthe warrantyofthisVGA
card.
March17,2003 Taipei,Taiwan
Chapter1User’sManual
Thisproductincorporatescopyrightprotection technologythatisprotected by
method claimsofcertainU.S.patentsand otherintellectualpropertyrights
owned byMacrovision Corporation and otherrightsowners.Useofthiscopy-
rightprotection technologymustbe authorized byMacrovision Corporation,and
isintended forhomeand otherlimited viewing usesonlyunless otherwise
authorized byMacrovision Corporation.Reverseengineering ordisassemblyis
prohibited.

TableofContent-3-
English
TableofContents
1.INTRODUCTION
1.1.PREFACE...................................................................................4
1.2.Overview.....................................................................................4
2.HARDWAREINSTALLATION
2.1.UNPACKING...............................................................................5
2.2.BOARD LAYOUT.........................................................................6
2.3.HARDWAREINSTALLATION.......................................................7
3.SOFTWAREINSTALLATION
3.1Win98/98SE ,WinME,WinXP DriverAnd UtilitiesInstallation ..........9
3.1.1Operating systemrequirement ................................................9
3.1.2DirectXinstallation ................................................................ 10
3.1.3Driverinstallation .................................................................. 12
3.1.4Utilitieson driverCD ............................................................. 15
3.1.5TaskbarIcon ......................................................................... 16
3.1.6Propertypages..................................................................... 23
3.2.WINDOWSNT4.0DRIVERINSTALLATION.............................. 31
3.3.WINDOWS2000 DRIVERINSTALLATION.................................. 32
3.4BIOSFLASHUTILITY................................................................ 32
4.TroubleshootingTips................................................................................. 33
5.Appendix
5.1.Howtorefashthe BIOS.............................................................. 34
5.2.Resolutionsand ColorDepthTable............................................. 36

GV-R7500L GraphicsAccelerator-4-
English
1.INTRODUCTION
1.1.PREFACE
Gigabyte7500 Seriesisapowerfulandversatilegraphicsolution.64MBofpowerfulDDRmemory
along withthe RADEON™7500 GPUprovideshigh performanceacceleration oftoday’sdemand-
ing 3Dgraphicapplications.Industryleading DVDplayback,
1.2.KEY FEATURES
nPowered bythe RADEON™7500 GPUand 64MBDDR memoryfor
advanced 3Dgraphics
nUnique HyperZTMtechnology,enhencedisplaymemorybandwidthwith32
bittrue color,and resolution up to2048x1536.bestforall 3Dgames
nSupportofDirectX8®and OpenGL®applications
nCHARISMAENGINE™supportsfull Transformation,Clipping and Lighting
(T&L)at45 million triangles/second peakprocessing capability
nPIXELTAPESTRY™,the RADEON™7500 rendering engine,powersan
incredible1.74 gigatexels/second forthe highestfill ratesin32-bitathigh
resolutions
nSupported V-Tunerforperformancetweaker.
nSupported CRT,TV-outand SVideo-out
nDVDplayback withintegrated motion compensation and iDCT
nLeading-edge HYDRAVISIONtechnologysupportstraditionalCRTmonitors,
flatpaneldisplays and TVs.
nVIDEOIMMERSIONtechnologyenablesintegration ofindustry-leading
digitalvideo features,including advanced de-interlacing algorithmsfor
unprecedentedvideo quality.
Chapter 1 User's Manual

HardwareInstallation-5-
English
2.HARDWAREINSTALLATION
2.1.UNPACKING
The GV-R7500L package containsthe following:
lThe GV-R7500L graphicsaccelerator
lThisUSER'SMANUAL
l DVDPlayersoftwareincluded
lGameCD x1
lDriverCD withV-Tunerutilities
lS-Videocable
lAV cable,StoAV adapter
WARNING!
Expansion cardscontainverydelicateIntegrated Circuit(IC)chips.Toprotectthemagainst
damage fromstaticelectricity,you shouldfollowsomeprecautionswheneveryou workon your
computer.
1.Turnoffyourcomputerand unplug powersupply.
2.Useagrounded wriststrap beforehandling computercomponents.If you do nothaveone,
touchbothofyourhandstoasafelygroundedobjectortoametalobject, suchasthe power
supplycase.
3.Placecomponentson agrounded antistaticpad oron the bag thatcamewiththe
componentswheneverthe componentsareseparated fromthe system.
The cardcontainssensitiveelectriccomponents,whichcan be easilydamaged bystatic
electricity,sothe cardshouldbe left initsoriginalpacking until itisinstalled.
Unpacking and installation shouldbe done on agrounded anti-staticmat. The operatorshould
be wearing an anti-staticwristband,grounded atthe samepointasthe anti-staticmat.
Inspectthe cardcarton forobviousdamage.Shipping and handling maycausedamage toyour
card.Besurethereareno shippingand handling damagesonthe cardbeforeproceeding.
MDONOTAPPLYPOWERTOYOUR SYSTEMIFITHASBEENDAMAGEDONTHE
CARD.
MInordertoensureyourgraphicscardworkingcorrectly,pleaseuse officialGigabyte
BIOSonlyUsenoneofficialgigabyteBIOSmightcauseproblemon thegraphicscard.

GV-R7500L GraphicsAccelerator-6-
English
2.2.BOARD LAYOUT
GV-R7500L (8Mx16 64MBDDRAM)
TV-out
VGAMonitor
Connector
(15pin)
AV Output
NTSC/PALTV
Projector
S-VideoOutput
Analog LC D MonitorAnalog Monitor
ORVGAOutput
TV-Out
VGAMonitor
Connector
(15pin)
OR
NTSC/PALTV
Projector
7Pin
7Pin
4Pin
4Pin

HardwareInstallation-7-
English
2.3.HARDWAREINSTALLATION
Installing YourGraphics card..
Nowthatyouhaveprepared yourcomputer,you arereadytoinstall yourgraphics accelerator
card.
Toinstall yourgraphics acceleratorcard:
1.Poweroff the computerand monitor,then
disconnectthe displaycablefromthe back of
yourcomputer.
2.Removethe computercover.If necessary,
consultyourcomputer'smanualforhelpin
removing the cover.
3.Removeanyexisting graphics cardfromyour
computer.
Or,ifyourcomputerhasanyon-board
graphics capability,you mayneed todisableit
on the motherboard.Formoreinformation,
see you computerdocumentation.

GV-R7500L GraphicsAccelerator-8-
English
4.Locatethe AGPslot. If necessary,
removethe metalcoverfromthisslot;
then align yourGraphics cardwiththe
AGPslot, and press itinfirmlyuntil the
cardisfullyeated.
GV-R7500L Graphics card
AGPSlot
GV-R7500L Graphics card
ToTVorVCR
ToVGAMONITOR
You arenowreadytoproceed withthe installation ofthe Graphics carddriver.Fordetailed
instructions,selectyouroperating systemfromthe listbelow:
6.Plug thedisplaycableintoyourcard;then turn
on the computerand monitor.
5.Replacethe screwtofasten the cardinplace,
and replacethecomputercover.

SoftwareInstallation-9-
English
3.SOFTWAREINSTALLATION
Inthismanual, weassumethatyourCD-ROMDrive lettertobeDrive D:
3.1.WINDOWS®98 /98SE ,WINDOWSMEand WindowsXP DRIVER
AND UTILITIES INSTALLATION
The installation ofWindows98/98SE orWindowsMEorWindowsXP driversisverysimple.
When you insertthe driverCD intoyourCD-ROMdrive,you can see the AUTORUN window(ifit
doesnotshowup,run "D:\setup.exe").Then you can followguidestosetup yourGV-R7500L
driver(Pleasefollowthe subsection 3.1.3"Step ByStep Installation"toinstall the driverforyour
graphicsaccelerator.
3.1.1.Operating systemrequirement
lIf yourOSisMicrosoft Windows,when loading the GV-R7500Ldriversforthe
system,pleasemakesureyoursystem(Windows98/98SE orWindowsME)has
installed DirectX8.1orlater.
lIf you install the GV-R7500Ldriversforthe mainboard,which
consistofSIS,ALIorVIAchipsets,pleaseinstall the appropriateDriverprogramfor
thatmainboard.OrpleasecontactyourmotherboardnearestdealerforM/BDiver.

GV-R7500L GraphicsAccelerator-10 -
English
3.1.2.DirectXInstallation
Install Microsoft DirectX8.1toenable3Dhardwareacceleration supportforWin98/98SE/MEto
achievebetter3Dperformence.
Note:ForsoftwareMPEGsupportinWin98/98SE orWinME,you mustDirectXfirstinstall.
MMustbe install DirectX8.1(orlater)
1.Installation DirectXDriver
Click "Install DirectX8.1”Item.
2.Click "Yes"icon.
3.Click "Yes“icon.

SoftwareInstallation-11 -
English
Then the DirectX8.1installation iscompleted.
4.Click "OK"item.

GV-R7500L GraphicsAccelerator-12 -
English
3.1.3.DriverInstallation
The following isthe step-by-step installation guide.
Step3:UpdateDevice DriverWizard:Finish
Atthistime,systemwill ask foryourWindowsCD inordertocompletethe VGAdriver
installation.
If you don'thavethe CD,you can press C:\Windows\Systemdirectory.
Step4:SystemSetting Change
1.Click "Next“icon.
2.Click "Finish“icon.
MDon’tclick “Cancel”,because
the systemwill hang ifyou press it.
Step2:UpdateDevice DriverWizard:StandardPCIGraphicsAdapter(VGA)
Step1:NewHardwareFound
AfterGV-R7500Lisinserted intoyourcomputeratthe firsttime,the windowswill automatically
detectanewhardwareinthe systemand pop outa"NewHardwareFound"message.Please
select"Donotinstall adriver"and press OK.

SoftwareInstallation-13 -
English
Afterthe systemhasfinished loading,insertthe GV-R7500L driverCD disk intoyourCD-ROM,
and then you can see the AUTORUN window.Ifitdoesnotshowup,pleaserun "D:\setup.exe".
Step5:DriverSetup
1.Click "Install DisplayDriver(Radeon
7500 Series).
2.Click "Next".
3.Click "NO“icon.

GV-R7500L GraphicsAccelerator-14 -
English
3.Click "Yes".
4.Click "Finish"torestartcomputer.

SoftwareInstallation-15 -
English
3.1.4.Utilities on driverCD
The utilitiesinclude DisplayDriverand V-Tunerutilities.Pleasebrowsethe driverCD fordetail.
OtherUtility(V-Tunerand Hydravision)
Followthesetup thatshowing onthescreentoinstall theUtility.
A.Installing V-TunerUtility
Click "Hydravision Install”Item.
B.Installing HydravisionUtility
Click "V-Tuner”Item.

GV-R7500L GraphicsAccelerator-16 -
English
3.1.5TaskbarIcon
Afterinstallation ofthe displaydrivers,you will find an GBTicon on the taskbar'sstatusarea.
Right-clicking thisicon opensthe GBTcontrolpanel,showing amenu composed ofshortcuteofthe
graphics card'senhanced and otherfunctions.
You mayclick the "DisplayProperties"item,and then click Settings.Click "Advanced"afterclickng
Settings.Click the appropriatetab tochange yourdisplaysettings.
Youcan linktoGBTwebsitefor
updated information aboutthe
graphics card,latestdrivers,
andotherinformation.
Rightclick the icon.

SoftwareInstallation-17 -
English
V-Tuner(Overclock Utility)
V-Tunerletsyou adjustthe working frequency ofthe graphicengine and video memory(CoreClock
and MemoryClock)
DisplayMemoryClock
CloseV-Tuner
MinV-Tuner
DisplayCoreClock
Display&Adjust
CoreClock
Linktothe WebsitofGigabyteHelpdescription CloseV-TunerTo
systemTray
Display&Adjust
MemoryClock

GV-R7500L GraphicsAccelerator-18 -
English
VGAInfo
VGAInfoliststhe relevantinformation aboutyourcard.
ColorAdjust
ColorAdjustallowsyou tomakecoloradjustments,suchasbrightness,contrast, and gamma
valuesforeachorall ofRGBcolors.

SoftwareInstallation-19 -
English
Afterinstallation ofthe displaydrivers,you will find an ATIicon on the taskbar'sstatusarea.
Clicking thisiconopen the ATicontrolpanel.
HYDRAVISION™isprimarilysoftwaredesigned formultiplemonitorsettings.RADEON7500 graphic
cardsthathavemorethan one displayoutputcan benefitfullyfromthissoftware.ARADEON7500
withonlyone displayoutputcan still takeadvantage ofthe manyfeaturesofHYDRAVISION™.
HYDRAVISION™installation enablesthe Desktop Managerand createsaWindows®
programgroup forHYDRAVISION™displaymanagementsoftware.
HYDRAVISION™
HYDRAVISION™and the Desktop Managerareactivated wheneverWindows®starts.Installing
HYDRAVISION™addsmenu optionstothe ATIIcon.
Click on the ATIicontoaccess theapplication'sfeaturesand help,ortounload the HYDRAVISION™
DesktopManager.
1.RotateScreen
2.Using SingleDisplay
3.Hydravision

GV-R7500L GraphicsAccelerator-20 -
English
Desktop ManagementControls:
The Desktop Managementdialog letsyou configurethe behaviorofwindowsand dialogboxesin
amultiplemonitorenvironment.
Dialog Control
Enabledialog repositioning -Togglesdialog controlon and
off. Whenthisboxischecked,you can choosetohave
dialog boxesappearon the parentapplication'smonitor.If
the parentapplication orassociated monitorcannotbe
located,the dialog boxdefaultstomonitor1.
Showonapp'smonitor-Thisforcesall open dialog boxes
tothe monitorthatoriginated the applications.
Showatcursor-You can choosetohavedialog boxes
appearon the monitorinwhichthe cursorislocated.
Showon monitor-You can choosetohavedialog boxes
always appearon aspecificmonitorinthe array
WindowControl
Singlemonitorwindows-Whenhisboxischecked,windowsaresized no largerthan asingle
monitor.Windowsthatareplaced on monitorsplitsareautomaticallyrelocated tothe monitoron
whichmostofthe windowappears.
HydraVision Maxbutton management-Allowsyou tocontrolthe behaviorofthe Windows
Maximizebutton.When HydraVision isrunning,aHydraVisionMax/Restorebutton appearsinthe
upper-rightcornerofan application titlebar.Clicking thisbutton makesthe activewindow
maximizeinone oftwoways:
Maxtowindowcornerscauseswindowstomaximizetothe monitor(s)thatcontainthe window's
upper-leftand lower-rightcorners.
Maxtofull desktop causeswindowstomaximizetothe entiremonitorarray.
Maxchildwindows-Keepswindowsgenerated byparentapplicationsfromsplitting across
monitors.The abilitytokeep childwindowson asinglemonitorwhenmaximized isextremely
usefulforediting multipledocumentsside-by-side inaparentapplication.
The HydraVision application titlebarbutton changesfromasinglesquaretotwosmallersquares
when awindowisinaHydraVision maximized state.Clicking the button againrestoresthe active
windowtoitsdefaultstateasasinglesquare.
General
Application position memory-Check thisboxto"remember"the sizeand location ofapplication
windowswhen theyareclosed and re-applythosesettingswhen the application isre-opened.
Automaticallyalign monitors-You can manuallydefine monitorplacementfromthe Settings
dialog inthe DisplayPropertiesdialog box.When thisboxischecked,HydraVision will override
user-defined monitorplacementifthe monitorsarenotevenlyaligned.
Thiscontrolwill workonlyifall monitorsarerunning atthe sameresolution and yourdesktop is
configured asarectangle.
RemoveHydraVision titlebarbuttons-Thisboxremovesorrestoresthe ATItitlebarbuttonsfrom
all applications.
RemoveMultiDesk systemtrayicon -Thisboxremovesorrestoresthe MultiDesk systemtray
icon.
ATILogo -Click heretoaccess theAboutdialog whichprovidessoftwareversion information and
alinktothe ATITechnologieswebsite.
