Declaration ofConformity
We,Manufacturer/Importer
(full address)
G.B.T.TechnologyTräding GMbH
AusschlagerWeg41,1F,20537 Hamburg,Germany
declarethatthe product
(description ofthe apparatus,sy stem,installation towhichitrefers)
VGACard
GV-R9000 PRO
isinconformitywith
(referencetothe specification underwhichconformityisdeclared)
inaccordancewith89/336 EEC-EMCDirective
oEN55011 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
industrial,scientificand medical(ISM
high frequency equipment
oEN61000-3-2*
TEN60555-2
Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Harmonics”
oEN55013 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
broadcastreceiversand associated
equipment
oEN61000-3-3*Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Voltage fluctuations”
oEN55014 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
householdelectricalappliances,
portabletoolsand similarelectrical
apparatus
TEN50081-1Genericemission standardPart1:
Residualcommercialand lightindustry
TEN50082-1GenericimmunitystandardPart1:
Residualcommercialand lightindustry
oEN55015 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
fluorescentlampsand luminaries
Genericemission standardPart2:
Industrialenvironment
oEN55081-2
Immunityfromradiointerferenceof
broadcastreceiversand associated
equipment
Genericemission standardPart2:
Industrialenvironment
oEN55082-2
TEN55022 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
information technologyequipment
lmmunityrequirementsforhousehold
appliancestoolsand similarapparatus
oENV55104
Cabled distribution systems;Equipment
forreceiving and/ordistribution from
sound and television signals
EMCrequirementsforuninterruptible
powersystems(UPS)
oEN50091-2
oEN55020
oDINVDE0855
opart10
opart12
(ECconformitymarking)
TCEmarking
Themanufactureralsodeclares theconformityofabove mentionedproduct
withtheactualrequiredsafetystandardsinaccordance withLVD73/23 EEC
Safetyrequirementsformainsoperated
electronicand related apparatusfor
householdand similargeneraluse
oEN60950
oEN60065
Safetyofhouseholdand similar
electricalappliances
oEN60335
Manufacturer/Importer
Signature:
Name:
(Stamp)
Date:July26,2002
TEN60555-3
TimmyHuang
Timmy Huang
oEN50091-1
Safetyforinformation technologyequipment
including electricalbussiness equipment
Generaland Safetyrequirementsfor
uninterruptiblepowersystems(UPS)

FCC Part15,SubpartB,Section 15.107(a)and Section 15.109
(a),Class BDigitalDevice
DECLARATIONOFCONFORMITY
PerFCC Part2Section 2.1077(a)
ResponsiblePartyName:
Address:
Phone/FaxNo:
hereby declaresthattheproduct
ProductName:
Conformstothefollowing specifications:
Thisdevice complieswithpart15 oftheFCC Rules.Operation is
subjecttothefollowing twoconditions:(1)Thisdevice maynot
causeharmfuland (2)thisdevicemustacceptanyinference received,
including thatmaycauseundesiredoperation.
RepresentativePerson’sName:
Signature:EricLu
SupplementaryInformation:
ModelNumber:
17358RailroadStreet
CityofIndustry,CA 91748
G.B.T.INC.(U.S.A.)
[phone]/[phone]
VGACard
GV-R9000PRO
Date:
ERICLU
July26,2002

GV-R9000 PRO
Radeon 9000 PROGraphics Accelerator
REV.102
12MD-R90P64-102
USER'SMANUAL
中文使用手冊
Upgrade your Life

GV-R9000 PROGraphics Accelerator-2-
English
Copyright
CopyrightbyGIGA-BYTETECHNOLOGYCO., LTD.("GBT")Nopartofthismanual
maybe reproducedortransmitted inanyfromwithoutthe expressed,written permission
ofGBT.
Trademarks
Third-partybrandsand namesarethe propertyoftheirrespectiveowners.
Notice
Due torapidchange intechnology,someofthe specificationsmightbe outofdatebefore
publication ofthisbooklet.
The authorassumesno responsibilityforanyerrorsoromissionswhichmayappearin
thisdocumentnordoesitmakeacommitmenttoupdatethe informationcontained herein.
Pleasedo notremoveanylabelson VGAcard,thismayvoidthe warrantyofthisVGA
card.
Sep.3,2002 Taipei,Taiwan
Chapter1User'sManual

TableofContent-3-
English
TableofContent
1.INTRODUCTION.............................................................................4
1.1.PREFACE...............................................................................................4
1.2.KEY FEATURES .....................................................................................4
2.HARDWAREINSTALLATION...........................................................5
2.1.UNPACKING...........................................................................................5
2.2.BOARD LAYOUT....................................................................................6
2.3.HARDWAREINSTALLATION...................................................................7
3.SOFTWAREINSTALLATION...........................................................9
3.1.WINDOWS®98 /98SE /WINDOWS®ME/WINDOWS®XP DRIVER
AND UTILITIES INSTALLATION..............................................................9
3.1.1.OPERATINGSYSTEMREQUIREMENT.......................................................... 9
3.1.2.DIRECTXINSTALLATION................................................................................. 10
3.1.3.DRIVERINSTALLATION................................................................................... 12
3.1.4.UTILITIES ONDRIVERCD .............................................................................. 15
3.1.5.TASKBARICON................................................................................................. 17
3.1.6.DISPLAY PROPERTIES PAGES ...................................................................... 21
3.2.WINDOWS2000 DRIVERINSTALLATION............................................. 27
3.3.BIOSFLASHUTILITY........................................................................... 27
4.Troubleshooting Tips...................................................................... 28
5.Appendix....................................................................................... 29
5.1.Howtoreflashthe BIOS........................................................................ 29
5.2.Resolutionsand ColorDepthTable........................................................ 31

GV-R9000 PROGraphicsAccelerator-4-
English
1.INTRODUCTION
1.1.PREFACE
GV-R9000 PRO provides high-end performance to the mainstream graphics market at
a competitive price point. GV-R9000 PRO features four parallel, highly optimized rendering
pipelines usually available only for the high-end gaming cards that significantly enhance
performanceand game-playresponsiveness bydoublingthepixelfill rate co mpared to
the standard2-pipeline architecturesfoundinmostmid-range products.
1.2.KEY FEATURES
nPowered byATiRadeon 9000 PROGPUwith64MBDDR SDRAM
n275MHzengine and memoryclock speeds
nSMARTSHADER™technologyfullysupportsDirectX®8.1
nSharper-looking 3Dgraphics withATISMOOTHVISION™technology
nDualdisplaysupportwithHYDRAVISION™
nFeaturing ATICATLYST™-Industry-leading softwaresuite
nDVI-Iand TV-Outsupported
nSupportsGigabyteV-TunerforTweakerUtility

HardwareInstallation-5-
English
WARNING!
Expansion cardscontainverydelicateIntegrated Circuit(IC)chips.Toprotectthemagainst
damage fromstaticelectricity,you shouldfollowsomeprecautionswheneveryou workon
yourcomputer.
1.Turnoffyourcomputerand unplug powersupply.
2.Useagrounded wriststrap beforehandling computercomponents.If you do nothaveone,
touchbothofyourhandstoasafelygrounded objectortoametalobject, suchasthe
powersupplycase.
3.Placecomponentson agrounded antistaticpad oron the bag thatcamewiththe
componentswheneverthe componentsareseparated fromthe system.
The cardcontainssensitiveelectriccomponents,whichcan be easilydamaged bystatic
electricity,sothe cardshouldbe left initsoriginalpacking until itisinstalled.
Unpacking and installation shouldbe done on agrounded anti-staticmat. The operatorshould
be wearing an anti-staticwristband,grounded atthe samepointasthe anti-staticmat.
Inspectthe cardcarton forobviousdamage.Shipping and handling maycausedamage to
yourcard.Besuretherearenoshipping and handlingdamageson the cardbeforeproceeding.
MDONOTAPPLYPOWERTOYOUR SYSTEMIFITHASBEENDAMAGEDONTHECARD.
MInordertoensureyourgraphics cardworking correctly,please use officialGigabyte
BIOSonly.UsenoneofficialgigabyteBIOSmightcauseproblemonthegraphics card.
2.HARDWAREINSTALLATION
2.1.UNPACKING
The GV-R9000 PROpackage containsthe following:
lThe GV-R9000 PROGraphics Accelerator
lThisUSER'SMANUAL
lThe GV-R9000 PRODriverCD x1
lPowerDVDXP CD x1
lGameCD x2
lOne cablesupportS-video and AV-Output;DVI-ItoD-Sub connector

GV-R9000 PROGraphics Accelerator-6-
English
2.2.BOARD LAYOUT
GV-R9000 PRO(64MBDDR)
TV-out
VGAMonitor
Connector
(15pin)
DVIConnector
TV-Out
VGAMonitor
Connector
(15pin)
DVIConnector
AV Output
NTSC/PALTV
Projector
S-VideoOutput
DVIOutput
DigitalLC D Monitor
DVI-ItoD-sub
Connector
VGAOutput
Analog LCD Monitor
OR
Analog LCD MonitorAnalog Monitor
OR
VGAOutput

HardwareInstallation-7-
English
2.3.HARDWAREINSTALLATION
Installing YourGraphics card.
Nowthatyou haveprepared yourcomputer,you arereadytoinstall yourgraphics
acceleratorcard.
To install yourgraphics acceleratorcard:
1.Poweroff thecomputerand monitor,then
disconnectthe displaycablefromtheback
ofyourcomputer.
2.Removethe computercover.Ifnecessary,
consultyourcomputer'smanualforhelp
inremovingthe cover.
3.Removeanyexisting graphics cardfrom
yourcomputer.
Or,ifyourcomputerhasanyon-board
graphics capability,you mayneed to
disableiton the motherboard.Formore
information,se e you compu ter
documentation.

GV-R9000 PROGraphics Accelerator-8-
English
4.LocatetheAGPslot. If necessary,remove
the metalcoverfromthisslot; then align
yourgraphics cardwiththe AGPslot, and
press itinfirmlyuntil thecardisfullyeated.
ToFlatPanelDisplay
ToTVorVCR
ToVGAMonitor
AGPSlot
GV-R9000 PROGraphics card
5.Replacethe screwtofasten the cardin
place,and replacethe computercover.
6.Plug the displaycableintoyourcard;then
turnon the computerand monitor.If your
Graphics cardcamewithaDVIconnector,
you can connectaflatpaneldisplaytothe
appropriateconnector,asshownbelow...
You arenowreadytoproceed withthe installation oftheGraphics carddriver.Fordetailed
instructions,selectyouroperatingsystemfromthe listbelow.

SoftwareInstallation-9-
English
3.SOFTWAREINSTALLATION
Inthismanual, weassumethatyourCD-ROMDrive lettertobeDrive D:
3.1.WINDOWS®98 /98SE /WINDOWS®ME/WINDOWS®XP DRIVER
AND UTILITIES INSTALLATION
The installation ofWin®98/98SE /WINDOWS®2000 /Win®ME/Win®XP driversisvery
simple.When you insertthe driverCDintoyourCD-ROMdrive,you cansee theAUTORUN
window(ifitdoesnotshowup,run "D:\setup.exe").Then you can followguidestosetup
yourGV-R9000PROdriver(Pleasefollowthe subsection3.1.3"Step ByStep Installation"
toinstall the driverforyourGV-R9000 PROgraphics accelerator.
3.1.1.OPERATINGSYSTEMREQUIREMENT
lIf yourOSisMicrosoft Windows,when loading the GV-R9000 PROdriversforthe
system,pleasemakesureyoursystem(Windows98/98SE,Windows2000 or
WindowsME)hasinstalled DirectX8.1orlater.
lIf you install the GV-R9000 PROdriversforthe motherboard,whichconsistofSIS,
ALIorVIAchipsets,pleaseinstall the appropriateDriverprogramforthat
motherboard.OrpleasecontactyourmotherboardnearestdealerforM/BDriver.

GV-R9000 PROGraphics Accelerator-10 -
English
3.1.2.DIRECTXINSTALLATION
Install Microsoft DirectX8.1toenable3Dhardwareacceleration supportforWindows®
98/98SE/Windows®2000/MEtoachievebetter3Dperformence.
MNote:ForsoftwareMPEGsupportinWindows®98/98SE/Windows®2000 or
Windows®ME,you mustinstall DirectX8.1(orlater) first. (If yourOSisWindows®XP,
pleaseskipthissection.)
1.Install DirectXDriver:
Click "Install DirectX8.1"Item.
3.Click "Yes"icon.
2.Click "Yes"icon.

SoftwareInstallation-11 -
English
Then the DirectX8.1installation iscompleted.
4.Click "OK"item.

GV-R9000 PROGraphics Accelerator-12 -
English
3.1.3.DRIVERINSTALLATION
The following isthe step-by-step installation guide.
Step1:NewHardwareFound
AfterGV-R9000 PROisinserted intoyourcomputeratthe firsttime,the windows
will automaticallydetectanewhardwareinthe systemand pop outa"New
HardwareFound"message.Pleaseselect"Donotinstall adriver"and press OK.
Step2:UpdateDevice DriverWizard:StandardPCIGraphics Adapter(VGA)
Step3:UpdateDevice DriverWizard:Finish
Atthistime,systemwill ask foryourWindowsCD inordertocompletethe VGA
driverinstallation.
If you don'thavethe CD,you can press C:\Windows\Systemdirectory.
Step4:SystemSetting Change
1.Click "Next"icon.
MDon'tclick "Cancel",because the
systemwill hang ifyou press it.
2.Click "Finish"icon.

SoftwareInstallation-13 -
English
Afterthe systemhasfinished loading,insertthe GV-R9000 PROdriverCD disk
intoyourCD-ROM,and then you can see the AUTORUN window.If itdoesnot
showup,pleaserun "D:\setup.exe".
3..Click "No"icon.
Step5:DriverSetup
(Pictures belowareshowninWindowsXP)
1.Click "WindowsXP Drivers(Radeon
9000 Series)"item.
2.Click "Next".

GV-R9000 PROGraphics Accelerator-14 -
English
3.Click "Yes".
4.Click "Express"or"Custom"icon.
5.Click "Finish"torestartcomputer.

SoftwareInstallation-15 -
English
lInstall ATIWDMDriver:
1.Click "WDMDriver(VIVO)"item.
3.Click "Finish"torestartcomputer.
2.Click "Next".
3.1.4.UTILITIES ONDRIVERCD
The utilitiesinclude DisplayDriverand V-Tunerutilities.Pleasefollowthe steps.

GV-R9000 PROGraphics Accelerator-16 -
English
lInstall V-Tuner:
1.Click "V-Tuner"item.
4.Click "Finish"torestartcomputer.
3.Enteryournameand company.
2.Click "Next".

SoftwareInstallation-17 -
English
3.1.5.TASKBAR ICON
Afterinstallation ofthe displaydrivers,you will find an GBTicon on the taskbar's
statusarea.Right-clicking thisicon opensthe GBTcontrolpanel,showing amenu
composed ofshortcuteofthe graphics card'senhanced and otherfunctions.
You mayclick the "DisplayProperties"item,and then click Settings.Click "Advanced"
afterclickng Settings.Click the appropriatetab tochange yourdisplaysettings.
Youcan linktoGBTwebsitefor
updated information aboutthe
graphics card,latestdrivers,
andotherinformation.
Rightclick the icon.

GV-R9000 PROGraphics Accelerator-18 -
English
DisplayMemory
Clock
CloseV-Tuner
MinV-Tuner
DisplayCoreClock
Display&Adjust
CoreClock
Linktothe WebsitofGigabyteThisPage CloseV-TunerTo
systemTray
Display&Adjust
MemoryClock
V-Tuner(Overclock Utility)
V-Tunerletsyou adjustthe working frequency ofthe graphicengine and video memory
(CoreClock and MemoryClock)
