Gigaset S910 User manual

Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / Cover_front.fm /
Congratulations
By purchasing a Gigaset, you have chosen a brand that is fully committed
to sustainability. This product’s packaging is eco-friendly!
To learn more, visit www.gigaset.com.

Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / Cover_front.fm

1
Gigaset S910/S910A – more than just a telephone
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / introduction.fm / 10.09.2012
Version 4.1, 21.11.2007
Gigaset S910/S910A – more than just a telephone
Your telephone sets new standards for the way you communicate at home.
The configuration and user interface of the cordless phone are excellent, providing
you with first-class voice quality in handsfree mode, while Bluetooth™ offers you
enormous flexibility.
The large TFT display, user-friendly keypad and clearly laid out menu are very sim-
ple to use.
Your phone can do a whole lot more:
uYou can use Bluetooth™ for wireless communication with other devices
(e.g. headsets) that also use this technology.
uYou can synchronise your directories on your telephone, mobile phone and PC
via Bluetooth™ using the Gigaset QuickSync software (¢page 69).
uYou can save appointments (¢page 46) and anniversaries, e.g., birthdays
(¢page 35), in your phone and it will remind you of them in advance.
uYou can designate important people as VIPs to identify important calls from the
ringtone (¢page 32).
uYou can assign a picture to entries in the directory – in future the picture will
appear every time you receive a call from this number (¢page 32).
uIf you do not want to take calls where the caller has withheld their number, just
set your handset to only ring if Calling Line Identification has not been withheld
(¢page 60).
uIf you do not wish to be disturbed, you can simply set up a time control so that
your phone will only ring when it is convenient (¢page 60). VIP calls are still
connected.
uYou can assign important numbers to the number keys on your phone. The
number is then dialled by simply pressing a key (¢page 56).
uAdapt your Gigaset to suit your handsfree requirements (¢page 59) and adjust
the brightness of your keypad to suit you (¢page 58).
uView your personal pictures as a screensaver slide show (¢page 57).
uYou can set the display to large font to increase readability in the directory
(¢page 57).
uYou can adapt the menu display to suit your individual requirements so that only
the most important functions Simplified (simplified mode) or all functions
Complete (expert mode •) are displayed (¢page 26). Menu options that are
only available in Complete (expert mode are marked with the •icon.
uGigaset Green Home — Be environmentally aware when using your phone.
Details about our ECO WDCT products can be found at
www.gigaset.com/service.
You can find additional information about your phone at
www.gigaset.com/gigasets910.
Have fun using your new phone!

2
The handset at a glance
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / overview.fm / 10.09.2012
Version 4.1, 21.11.2007
The handset at a glance 1Display in idle status
2Battery charge status (¢page 18)
3Side keys
Set call (¢page 58) or ringtone volume
(¢page 59)
4Display keys (¢page 21)
5Message key (¢page 36)
Access to call and message lists;
Flashes: new message or new call
6End call key, On/Off key
End call, cancel function, go back one menu
level (press briefly), back to idle status (press
and hold), activate/deactivate handset (press
and hold in idle status)
7IP Key (¢page 55)
Insert IP number
8Hash key
Keypad lock on/off (press and hold in idle sta-
tus);
toggles between upper/lower case and digits
9Mute key (¢page 31)
Mute the microphone
10 Microphone
11 Recall key
- Consultation call (flash)
- Insert a dialling pause (press and hold)
12 Star key
Ringtone on/off (press and hold);
with an open connection: switch between
pulse dialling/tone dialling (press briefly);
text input: open table of special characters
13 Headset socket (¢page 18)
14 Key 1
Dial answer machine (S910A only)/network
mailbox (press and hold)
15 Talk key
Flashes: incoming call;
Accept a call; open redial list (press briefly);
start dialling (press and hold)
16 Handsfree key
Switch between earpiece and handsfree mode
17 Control key (¢page 20)
18 Signal strength (¢page 18)
Green: Eco Mode (¢page 46) activated
19 Answer machine symbol (S910A only)
Answer machine switched on;
Flashes: answer machine is recording a mes-
sage or is being operated by another internal
party
ià V
07:15
INT 1 Oct 14
Redial Time
2
4
6
5
7
9
17
15
1
16
18
12
14
3
11
13
8
10
19

3
The handset at a glance
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / overview.fm / 10.09.2012
Version 4.1, 21.11.2007
The following symbols are displayed dependent on the settings and the operating status of
your telephone:
Ø«Ú
Signalling
External call (¢page 29)
ØåÚ ØþÚ
Internal call (¢page 50)
Answer machine is record-
ing (¢page 40)
i à »ó˝
Û08:00 07:15
INT 1 Oct 14
Ù
02 10 08
Redial Time
ØðÚ
Anniversary (¢page 47)
ØìÚ
Alarm (¢page 48)
Signal strength i(¢page 46)
Answer machine switched on (S910A only, ¢page 4)
Bluetooth activated (¢page 53)
or ô/ õ(Bluetooth headset/data device) connected
Ringtone switched off (¢page 60)
or ñalert tone activated (¢page 60)
Keypad lock switched on (¢page 23)
ØáÚ
Appointment (¢page 47)
Batteries are charged (¢page 18)
Charge status of the batteries (¢page 18)
Alarm switched on and wake-up time set (¢page 48)
Current time (¢page 16)
Current day and month (¢page 16)
Name of the handset (¢page 51)
Number of new messages:
uÃon the answering machine (Gigaset S910A only)/
network mailbox (¢page 36)
u™in the list of missed calls (¢page 36)
uin the list of missed appointments (¢page 38)
V

4
The base at a glance
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / overview.fm / 10.09.2012
Version 4.1, 21.11.2007
The base at a glance
You can use the keys on the base to register
handsets to the base, search for handsets
(paging), (¢page 50) and operate the inte-
grated answer machine (Gigaset S910A
only).
Gigaset S910A base
1Registration/Paging key
Press briefly: search for handsets (paging)
(¢page 50).
Press and hold: register handsets and WDCT
devices (¢page 49).
2On/Off key
Activating/deactivating the answer machine.
3Display
Lights up: answer machine is activated (0 is
shown in the display).
00 flashes: the answer machine is recording a
new message.
Flashes slowly: there are new messages. The
number of new messages is displayed.
99 flashes quickly: the answer machine is full.
During message playback:
4Play/Stop key
Play backnew messages from answer machine
or cancel playback (press briefly).
Play back new and old messages (press and
hold).
5 Skip to next message (press once) or skip
ahead two messages (press twice).
6 Skip back to the beginning of the message
(press once) or skip back to the previous mes-
sage (press twice).
7 Delete current message.
8 Adjust volume during message playback: ÷
= quieter; ø= louder.
While an external call is being signalled: adjust
ringtone volume.
Please note:
If the answer machine is being operated
from a handset or if it is recording a message
(00 flashes), it cannot be operated from the
base at the same time.
Gigaset S910 base
Registration/Paging key
– Press briefly: search for handsets (paging)
¢page 50.
– Press and hold: register handsets and
WDCT devices (¢page 49).
6
8
2
7
4
1
5
3

5
Contents
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / S910AIVZ.fm / 10.09.2012
Version 4.1, 21.11.2007
Contents
Gigaset S910/S910A – more than just a telephone . . . . . . . . . . . . . . . . . . . 1
The handset at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
The base at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
First steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Checking the package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting up the base and charger (if included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting the charger (if included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Setting up the handset for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing the display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
What would you like to do next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Control key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Display keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Keys on the keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Side keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Correcting incorrect entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Activating/deactivating the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Activating/deactivating the keypad lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Using this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Making an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
One Touch Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Accepting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Calling Line Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Notes on calling line display (CLIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Handsfree mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Switching to mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using the directory and lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Redial list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Message key function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Answer machine list (Gigaset S910A only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Calls list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
List of missed alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6
Contents
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / S910AIVZ.fm / 10.09.2012
Version 4.1, 21.11.2007
Making cost-effective calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Automatic network provider code (preselection) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Operating the Gigaset S910A base answer machine . . . . . . . . . . . . . . . . 40
Operating via the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Playing back messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Activating/deactivating call screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Setting the recording parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Resetting fast access for the answer machine using key 1 . . . . . . . . . . . . . . . . . . . . . . 43
Operating when on the move (remote operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using the network mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Accepting a new message from the network mailbox . . . . . . . . . . . . . . . . . . . . . . . . . 45
Playing back messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
ECO WDCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Setting an appointment (calendar) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Displaying missed appointments, anniversaries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Setting the alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Using multiple handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Registering handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
De-registering handsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Locating a handset ("Paging") . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Changing the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Making internal calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Listening in to an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Changing the name of a handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Using a handset as a room monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Using Bluetooth devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Handset settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Quickly accessing IP number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Quick access to numbers and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Changing the display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setting the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setting keypad illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Activating/deactivating auto answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Changing the speaker/earpiece volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Setting a handsfree profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Changing ringtones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Resource Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Activating/deactivating advisory tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Setting your own area code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Restoring the handset default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

7
Contents
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / S910AIVZ.fm / 10.09.2012
Version 4.1, 21.11.2007
Setting the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Changing the Gigaset S910A base ringtones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Activating/deactivating music on hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Protecting against unauthorised access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Resetting the base to the factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Connecting the base to the PABX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Dialling mode and Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Setting pauses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Switching temporarily to tone dialling (DTMF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Customer Care and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Questions and answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Caring for your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Contact with liquid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Writing and editing text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Additional functions via the PC interface . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Mounting the base on the wall (Gigaset S910 only) . . . . . . . . . . . . . . . . . 72
Mounting the charger on the wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

8
Safety precautions
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / security.fm / 10.09.2012
Version 4.1, 21.11.2007
Safety precautions
Warning
Be sure to read this user guide and the safety precautions before using your telephone
Explain their content and the potential hazards associated with using the telephone to your
children.
Use only the power adapter supplied, as indicated on the underside of the base.
Use only rechargeable batteries that correspond to the specification provided on
page 67, as this could otherwise result in significant health risks and personal injury.
Using your telephone may affect nearby medical equipment. Be aware of the tech-
nical conditions in your particular environment e.g., doctor's surgery.
If you use a medical device (e.g. a pacemaker), please contact the device manufac-
turer. They will be able to advise you regarding the susceptibility of the device to
external sources of high-frequency energy. Please refer to the “Appendix” chapter
for the specifications of this Gigaset product.
Do not hold the rear of the handset to your ear when it is ringing or when handsfree
mode is activated. Otherwise you risk serious and permanent damage to your hear-
ing.
Your Gigaset is compatible with the majority of digital hearing aids on the market.
However, perfect function with all hearing aids cannot be guaranteed.
The handset may cause an unpleasant humming or whistling noise in hearing aids
or cause them to overload. If you require assistance, please contact the hearing aid
supplier.
Do not install the base or charger in bathrooms or shower rooms. The base and
charger are not splashproof (¢page 67).
Do not use your phone in environments with a potential explosion hazard
(e.g., paint shops).
If you give your Gigaset to a third party, make sure you also give them the user guide.
Remove faulty bases from use or have them repaired by our Service department, as
they could interfere with other wireless services.
Please note
uNot all of the functions described in this user guide are available in all countries.
uThe device cannot be used in the event of a power failure. It is also not possible to trans-
mit emergency calls.
$
ƒ

9
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
First steps
Checking the package contents
1One Gigaset S910/S910A base
2One power adapter
3One Gigaset S910H handset
4One phone cord
5Two batteries
6One battery cover
7One belt clip
8One plastic headset socket cover
9One user guide
If you have purchased a
model with multiple hand-
sets the package should
contain two batteries, a bat-
tery cover, a belt clip and a
charger 9with power
adapter Jfor each addi-
tional handset.
21
345
7
6
9
8
or
9J

10
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
Setting up the base and charger (if included)
The base and charger are designed for use in dry rooms in a temperature range of
+5°C to +45°C.
¤Set up the base at a central point in the building on a level, non-slip surface or
mount the base (Gigaset S910 only) or charger on the wall (¢page 72).
The phone's feet do not usually leave any marks on surfaces. However, due to the
multitude of different varnishes and polishes used on today's furnishings, the
occurrence of marks on the surfaces cannot be completely ruled out.
Please note:
uNever expose the telephone to the influence of heat sources, direct sunlight or
other electrical devices.
uProtect your Gigaset from moisture, dust, corrosive liquids and fumes.
Connecting the base
¤First connect the tel-
ephone jack 2and
insert the cables into
the cable ducts.
¤Then connect the
power adapter 1.
Please note:
uThe power adapter must always be connected, as the phone will not operate
without a mains connection.
uUse only the power adapter and phone cord supplied. Pin connections on tele-
phone cables can vary (pin connections ¢page 68).
Please note
Pay attention to the range of the base.
This is up to 300 m in unobstructed outdoor areas and up to 50 m inside build-
ings. The range is reduced when Eco Mode (¢page 46) is activated.
1
1
1
2

11
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
Connecting the charger (if included)
¤Plug the power adapter into the plug
socket 2.
¤Connect the flat plug from the power
adapter 1.
To disconnect the plug from the charger, press the
release button 3and disconnect the plug 4.
1
2
3
4

12
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
Setting up the handset for use
The display and keypad are protected by plastic films.
Remove the protective films!
Inserting the batteries and closing the battery cover
Warning
Use only rechargeable batteries recommended by Gigaset Communications
GmbH (¢page 67), i.e., Never use conventional (non-rechargeable) batteries,
as this could result in significant health risks and personal injury. For example,
the outer casing of the batteries could be damaged or the batteries could
explode. The phone could also malfunction or be damaged as a result of using
batteries that are not of the recommended type.
¤Insert the batteries with
the polarity in the cor-
rect direction.
The polarity is indicated
in/on the battery com-
partment.
¤First insert the battery
cover at the top.
¤Then press the cover until
it clicks into place.
To open the battery cover, for
instance to replace the batter-
ies, insert a coin into the cavity
on the left-hand side of the cas-
ing, then pull the battery cover
in an upward direction.

13
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
¤Insert the plastic cover provided for the
headset socket to ensure optimum sound in
handsfree mode.
Attaching the belt clip
The handset has notches on each side to attach the belt clip.
¤To attach — press the belt clip
onto the back of the handset so
that the protrusions on the belt
clip engage with the notches.
¤To remove — press the centre of
the belt clip firmly with your right
thumb, push the fingernail of
your left index finger up between
the clip and the housing and pull
the clip in an upward direction.

14
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
Initial charging and discharging of the batteries
The correct charge status can only be displayed if the batteries are first fully
charged and discharged.
¤Charge the handset in the base for 8.5 hours.
¤After charging, remove the handset from the base and only replace it when the
batteries are fully discharged.
Please note
The handset must only be placed in the designated Gigaset S910/S910A base or
charging cradle.
8.5 h
Please note
uEach handset is registered with the base at the factory. You do not need to
register the handset again. If you wish to use your handset with a different
base or use further handsets with your base, you will need to register the
handset manually (¢page 49).
uAfter the initial battery charge and discharge, you may place your handset in
the base after every call.
uAlways repeat the charging and discharging procedure if you remove the
batteries from the handset and reinsert them.
uThe batteries may warm up during charging. This is not dangerous.
uAfter a while, the charge capacity of the batteries will decrease for technical
reasons.

15
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
Changing the display language
Change the display language if you do not understand the language currently set.
¤Press and hold the end call key ato return to idle status.
O5
¤Press right on the control key.
¤Slowly press keys Oand5one
after the other.
The display for setting languages appears.
The current language (e.g. English) is
selected.
¤Press down on the control key s...
... until the language you wish to use is
marked, e.g., Espanol.
¤Press the right key directly below the
display to select this language.
The selection is marked with Ø.
English Ø
Espanol ±
Portugues ±
ÖÐÎÄ ±
English Ø
Espanol ±
Portugues ±
±
Back Select
English ±
Espanol Ø
Portugues ±
ÖÐÎÄ ±

16
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
Setting the date and time
Set the date and time so that the correct date and time can be assigned to incoming
calls, and so that the alarm can be used.
Date/Time
Date:
2012.10.14
Time:
00:00
Back Save
¤Press the key below §Time§ on the dis-
play screen to open the input field.
(If you have already set the time and
date, open the input field via the menu
¢page 27.)
The Date/Time submenu is shown on the
display.
¤The active input position flashes.
Enter day, month and year as an
8-digit number via the keypad, e.g.,
2Q2Q4
for 2012/10/14.
Date/Time
Date:
2012.01.31
Time:
00:00
Back Save
Redial Time
Press the right or left control key
to change the input position and
correct an entry.
¤Enter the hours and minutes in 4-digit
format via the keypad, e.g.,
QM5for 07:15 am.
Change the input position with the
control key if necessary.
¤Press down on the control key to switch
to the time input field.

17
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
¤Press the key below §Save§ on the dis-
play screen to confirm your entry.
The display shows Saved. You will hear a
confirmation tone and the handset will
automatically return to idle status.
Back Save
Date/Time
‰
Saved

18
First steps
Gigaset S910-S910A / China WDCT EN / A31008-M2306-Y101-1-7619 / starting.fm / 10.09.2012
Version 4.1, 21.11.2007
Display in idle status
Once the phone is registered and the time is set, the idle display is shown as in this
example. If the answer machine is activated, the answer machine icon Ãis dis-
played in the header.
Displays
uReception between the base and the handset:
– Poor to good: ÐiÑÒ
–Noreception:|
Green: Eco Mode activated (¢page 46)
uBattery charge status:
–{white: charged over 66%
–{white: charged between 34% and 66%
–ywhite: charged between 11% and 33%
–yred: charged below 11%
–yflashes red: battery almost empty
(less than 10 minutes talktime)
–xyxyx{x{ white: battery charging
uINT 1
Internal name of the handset (¢page 51)
Your answer machine is set with a pre-recorded announcement.
Your phone is now ready for use!
Connecting the headset
After removing the plastic cover, you can connect a head-
set to the left-hand side of your telephone with the 2.5 mm
jack connector.
See the relevant product page at www.gigaset.com for
information on recommended headsets.
The headset volume corresponds to the settings for the
handset volume (¢page 58).
After using the headset, replace the plastic cover to enable
optimum sound in handsfree mode.
Please note
If you have chosen a colour scheme with a white background, the white sym-
bols are displayed in black.
i à V
07:15
INT 1 Oct 14
Redial Time
