Gin Bolero 4 User manual

Bolero 4 Owner’s Manual
Please read this manual prior to your first flight with the Bolero 4

2
Thank You…
Thankyoufor choosingtheBolero4. We are confident that thisparaglider will provide you with
countlesshappyexperiencesasyouprogressin yourflyingcareer.Thismanual containsallthe
informationyou need to flyandmaintainyourparaglider.Athoroughknowledge of your
equipmentwillkeepyou safe andenableyoutomaximizeyourfullpotential.
Pleasepassonthismanual to the new ownerifyoudoresell yourglider.
HappyFlights and SafeLandings,
TheGINTeam
Safety Notice
By the purchase of our equipment, you are responsible for being a certified
paraglider pilot and you accept all risks inherent with paragliding activities
including injury and death. Improper use or misuse of GIN equipment greatly
increases these risks. Neither Gin Gliders Inc nor the seller of GIN equipment
shall be held liable for personalor third party injuries or damages under any
circumstances. If any aspect of the use of our equipment remains unclear,
please contact your local paragliding instructor, GIN reseller or the importer in
your country.

3
Contents
ThankYou…..........................................................................................................................................2
SafetyNotice........................................................................................................................................2
1. Gin Gliders ........................................................................................................................4
2. Introducing the Bolero 4...................................................................................................5
ForPilotsWho…...................................................................................................................................5
Cutting-edgeDesign.............................................................................................................................5
Manufacturing......................................................................................................................................6
3. Before you Fly...................................................................................................................7
Pre-delivery Inspection........................................................................................................................7
SpeedSystem.......................................................................................................................................7
Brakelineadjustment...........................................................................................................................8
Rucksack ..............................................................................................................................................8
Yourharness........................................................................................................................................9
Certified Weight Range.........................................................................................................................9
Pre-flightsafety...................................................................................................................................9
4. Flying the Bolero 4..........................................................................................................10
Preparationforlaunch........................................................................................................................10
Takeoff..............................................................................................................................................10
Lineknotsortangles..........................................................................................................................11
MinSink/bestglide...........................................................................................................................11
Acceleratedflight...............................................................................................................................11
ActiveFlying......................................................................................................................................11
Inturbulence......................................................................................................................................11
Losingaltitude...................................................................................................................................12
Steeringwithoutbrakes.....................................................................................................................15
Aerobatics..........................................................................................................................................15
LandingwiththeBolero4...................................................................................................................15
Towlaunch.........................................................................................................................................15
Motorizedflight..................................................................................................................................15
5. Care, Maintenance and Repairs........................................................................................16
Groundhandling.................................................................................................................................16
UVdamage.........................................................................................................................................16
Packinginstructions...........................................................................................................................16
TransportandStorage........................................................................................................................17
Cleaning.............................................................................................................................................17
Inspections ........................................................................................................................................17
Repairs...............................................................................................................................................17
6. Reference........................................................................................................................18
TestingandCertification....................................................................................................................18
Technical Specifications .....................................................................................................................18
LinePlan ............................................................................................................................................18

4
1. Gin Gliders
Gin Gliders wasformed in 1998 by paragliderdesignerandcompetitionpilotGinSeok Song and
his team of engineersandtestpilots.
Gin’sphilosophyissimple:todesignglidersthathe,andanyotherpilot,lovestofly.This
philosophyappliesequallyfor anentry-levelwingsuchastheBolero4,asfortheworld-
beatingcompetitionglider,the Boomerang. Noglider is released tothe market without Gin’s
completesatisfaction.
Ginhasover20years’experienceof designing andmanufacturingparagliders,andisbackedby
anequallyexperiencedteam,bothwithinthe companyin Koreaandthroughout a worldwide
networkofdistributorsanddealers.GINTeampilotshavewontheParaglidingWorldCup
numeroustimesandhavehadcountlessothercompetitionsuccessesin WorldCups,Worldand
NationalChampionships.Thishighlevelof expertiseprovidedbydedicatedprofessionals
ensuresthatyougetthe bestpossibleproductsupportandaftersalesservice.

5
2. Introducing the Bolero 4
TheBolero 4 is anew conceptinan entry-levelwing.Designer Gin Seok Song hasdrawn on all
hisyearsofexperiencetoproduceawing that is uniquelyintunewith the needs of today’s
pilots.TheBolero4offersoutstanding security, with precisebutforgivinghandling. Thisallows
the pilotto accurately feelthe sensations of flight,andthusdevelop an active flying style.
Rapidprogression up the learningcurveisenabled,asthe pilot becomeswellacquainted with
the myriad of different movements and moodsof theair.TheBolero 4willallow you to
experience thefullpleasureof freeflight,withoutevercompromising yoursafety.
For Pilots Who…
TheBolero4 isanideal firstglider,and is also suitablefor the more experienced clubpilot who
fliesinfrequently and wantsagoodperforming gliderwith thehighestsafetymargin.The
Bolero4 isdesignedforallkindsof flying, from the first stepsat theparaglidingschool
training slope viaridge soaringto thermallingandcrosscountry.
Cutting-edge Design
Gin has made extensiveimprovementsin the Bolero 4compared to its predecessor, the Bolero 3.
Performance, take-off and handling characteristics have beenimprovedwithout sacrificing
security.
Rigifoilreinforcements at theleadingedgehavebeenintroduced.Thisimprovestake-off
characteristics,performance and increasesthelifetime of the canopy.
Thebrakeline layout features an extra upper linethat givesthe wing an evenmore precise feel.

6
Weightanddraghavebeenreducedbyusingthinneryetverystronglinematerialsandbythe
introductionof anew,hi-tech,lightfabric.
Theseand otherinnovationsensurethat bypurchasingthe Bolero 4, you are getting the best
possiblegliderin itsclass.
Manufacturing
AllGIN gliders are producedin thecompany’s ownfacilitiesusingthemostmoderntechniques.
Highlyskilledstafftakeextremecareduringthe entiremanufacturing process.Stringent
qualitycontrol ismade after each step,and all materialsthatgointo each wing can be traced.
Thesemeasures guaranteethatpilotsflywith theassurance thattheir wingmeetsthemost
exactingsafetystandards.

7
3. Before you Fly
Pre-delivery Inspection
The Bolero 4 is deliveredwith speed system, rucksack, inner bag, riser cover,compression strap,
repairtapeandthis manual. Yourinstructorordealershouldhavemade atestinflation
followedbyatestflight before delivery. Each Bolero4 ischeckedfor conformity withtheEN
andLTFtestedspecimenbeforeitleavesthe factory.
Speed System
Thespeed system increases themaximumspeedbyloweringtheangleofattackwith apulley-
guided,foot-operated system.Approx. 10km/hgain in speed canberealized withthe
accelerator at full travel.
Itisimportanttohaveyour acceleratorsystemcorrectly routedthroughyourharnessand
attached to the risers with the supplied Brummelhooks.Thelengthofthespeedbarshouldbe
initially adjustedwhile on the ground, sitting in the harness sothat the legs are fully extended
atthepointof full acceleratortravel.Itishelpfulto have an assistantholdthe riserstaut
whilemaking thisadjustment.Subsequentfinetuning can be doneontheground followingthe
firstflightwiththespeed system. If in doubt about thisprocedure,consultyourinstructoror
dealer.
Riser A B C D
lengthattrimspeed 48cm 48cm 48cm 48cm
lengthat fullspeed 37cm 39cm 43.5cm 48cm

8
Brake line adjustment
Themainbrakeline lengthsof theBolero 4 correspondtotheones usedin theEN and LTF test
flights. These linelengthshave been finetunedby GINtestpilots,anditshouldnotbe
necessarytoadjust them.
In soaring flight,it is common tofly with half awrapon the brakes.However, careshould be
takentoreleasethewraps in anyextremesituation.
Ifyoudo needto make adjustmentsto suityourharness,bodyandflying style,westrongly
recommendthatyoutestflytheglider
withevery2cm ofadjustment.There
should be a minimum of 10cmof free
braketravelwhen theglider isflown
hands-off.Thispreventsthebrakesbeing
appliedunintentionallywhen thespeed
systemisfullyengaged. Werecommend a
doublesheepshankor a bowlineknotfor
thebrake handleattachment as shown in
thediagram.
Rucksack
AllGinglidersaredeliveredwith adurableripstopKODURA®rucksack,designed forergonomic
carryingcomfort andeaseof use.
Therucksack shouldbepackedcarefullytoachieve maximum comfort.First,placetheglider
insidethe harnessandthen put the top of harness in thebottomoftherucksackwith the glider
side nextto the backof the rucksack.Finally, tighten theinternaland externalcompression
strapsandadjusttheshoulder andwaiststrapsto ensure theequipment stays firmlyinplace
whenwalking.Therearealsotwostorage pockets for accessories.
AnXXLrucksack(200L capacity) is availableasanoptional extraforpilotsthat requireit.

9
Your harness
TheBolero 4 hasbeen testedwithaharness withavariable cheststrapandwithout fixed
cross-bracing. Olderharnesseswithfixedcross-bracingarenotsuitablefor flying with the
Bolero4andshouldnotbeused.Checkwith themanufacturer of the harnessor your
paraglidinginstructorifindoubt.
Theadjustment oftheharnesschest strap controls the distance between carabiners and affects
thehandlingandstabilityoftheglider. Tighteningthe cheststrapincreases stability,
lengthening it gives morefeedback from the gliderdecreasesstability.
Gin calculates and draws the planof the glider withadistancebetweenthe carabiners of 44cm.
Werecommendasettinga distanceof 42cmto50cmbetweenthecarabiners,dependingonthe
sizeanddesignoftheharness.There isno needto flywith atightcheststrapsettingwiththe
Bolero 4, asthere is no tendency for it tofeel unstable, unlike older gliders.
Certified Weight Range
The Bolero 4 must be flownwithin thecertified weight rangegivenin thereferencesectionat
the back ofthis manual.The weight rangeis quoted asthetotal weightinflight,i.e.theweight
of the pilot,glider, harness and accessories. Theeasiestwayto check yourtotalweightisto
standonweighing scales with allyourequipmentpacked intoyourrucksack.Inmost cases the
differencebetweenyourbody weightandyourtotalflyingweight willbe around 20kg.
Pre-flight safety
Toflythis equipment you should:
Haveappropriate practical and theoretical training and experience forthisclassof glider.
Havethenecessary insuranceandlicences.
Beinyour rightmind,unaffectedby extremestress,recreationalor prescribeddrugs.
Onlyflyin conditionssuitable foryourlevelofparagliding.
Wearsuitable head protection, usea certifiedharnessandemergencyparachute.
Makea thoroughpre-flightcheck.

10
4. Flying the Bolero 4
Werecommendthatyoufirstpracticeinflating yourglider on a smalltraininghill,orflat
ground.Make your firstflightswith yournewparaglideringentleconditionson a familiar
flyingsite.
Preparation for launch
Following a consistent method of preparationandpre-flight checks isvitalforsafeflying.We
recommendthefollowing:
Onarrivalattheflyingsite,assessthesuitabilityofthe conditions:windspeed and
direction, airspace,turbulenceandthermalcycles.
Inspect yourglider, harness,reservehandleandpin,helmetand anyother equipment.
Chooseasufficiently largetake-offareawithevenground and no obstacles.
Laytheglideroutaccordingtotheplanform, andgetthe lines andrisers sorted out.
Secureyourselfinyourharnessand don’t forgetthelegloops!Putyourhelmeton.
Connectthe risers to yourharnesscarabiners, ensuringthere are no twistsorloops
aroundthe lines.
Connectthe speed system tothe riserswiththe Brummelhooks.
Doafinalline check by pullinggentlyontherisersorlines to ensure therearenonew
knots,tangles orinterferingbranchesorrocks.Take extra careinnilorlightwinds.
Pre-flightchecklist
Reserveparachute:pin in andhandle secure.
Helmet and harness bucklesclosed.
Linesfree.
Canopyopen and into wind.
Airspaceclear.
Take off
The keyto a successful launch techniqueis to practicegroundhandlingon flat ground whenever
youcan.
Light or Nil Wind Launch
TheBolero 4 inflatessteadilyinnil-windconditions. Simplyguidethegliderwith the A-risers,
keepingyourarmsbentandhands at theleveloftheshoulders. Allowyour armstoriseinan
arcandwaitfortheglider toinflate and come above yourhead–do not push therisers. There
is no need to pull the risers hard. Run positivelyasthe glidercomesaboveyour head. Be sure
tolookupandcheck that the canopy is fully inflated before you take-off, and thatthereare
notanglesinthelines.If any irregularityshouldoccurandyou’renot yet airborne, abort the
launchimmediatelyby stalling theglider. On steep launches,stallone sideofthegliderand run
parallelto the hill.
Iftheglidershould come upsideways,and the situationisrecoverable,runtowards the lower
sideratherthantryingtostruggleagainsttheforce.
An impulse launch where you startrunningwithslacklinesclose to the glider isnot needed.
