Girard Products GC105A Installation guide

5 CHANNEL REMOTE HANDSET
GC105A
INSTALLATION AND PROGRAMMING GUIDE
REV.12302015
RV AWNING PRODUCTS
1361 CALLE AVANZADO, SAN CLEMENTE, CA 92673 [phone] FAX [phone]
www.girardrv.com

Page 2of 11
Girard Systems awnings may be operated in light wind and rain
conditions. When periods of heavy rain and or high wind are expected
the awning must be closed. Never leave the awning open and
unattended.
Damage caused by wind and rain is not covered by warranty.
All awnings must be closed prior to moving the vehicle for any reason.
As an extra safety precaution a visual check that every awning is fully
closed is required.
Damage caused by failure to comply with these instructions is
not covered by warranty.
Before using your awning, ensure that the area into which the awning
will be deployed is free of obstructions (Trees, walls, pillars, posts,
other vehicles etc.)
Damage caused by collisions with any of the above or similar is
not covered by warranty.
Before using your awning make sure that all of your electrical circuits
are operating correctly. Recreational Vehicles can generate AC power
from three separate sources. The electrical system transfer switch in
your vehicle will select power for the awning as follows:
Shore Power – if connected;
Generator Power – if the generator is running;
Inverter Power – batteries must be charged for inverter operation.
Girard Systems awnings are supplied with an electric motor appropriate to the
product.

Page 3of 11
CONTENTS
The G-Link System ………………………………………………………………………….. 3
Product Description …………………………………………………………………………. 4
Programming ……………………………………………………………….…………………. 6
GC136 AC Motor Controller ………………………………………………………………. 6
GC274A / GC274B AC motor Controllers ………………………………………….... 7
98GC74 AC Motor Controller ………………………………….…………………………. 8
GC732G DC Motor Controller ……………………………………………………………. 9
GC1146C DC Motor Controller …………………………………………………………. 10
THE G–LINK SYSTEM
The G-Link motors and control modules provided by Girard Systems communicate by
use of RF signals on a frequency of 433.92 MHZ. This eliminates the need for wiring
and the drilling of holes in the vehicle. These components must be electronically
matched, programmed or paired before use. This is usually done at the Girard Systems
factory. Should the need arise for the user to pair a device with the motor controller
they must refer to the appropriate manual for the devices applicable to their particular
installation.

Page 4of 11
PRODUCT DESCRIPTION
The GC105A is a 5 channel RF transmitter, powered by a single 3v Lithium battery
(CR2430) designed to control up to 5 awnings by means of a multi-functional circular
control pad. As shown in Fig.1 below.
Fig.1
Channel Display Screen
Awning retract
Stop
Channel select
UP
Channel select
DOWN
Awning extend

Page 5of 11
Turn the remote handset over to find;
•The Battery compartment, (into which a single CR2430 3v Lithium battery should
be inserted as shown)
•The P2 button (used when pairing the device to some other G-Link Modules)
•Time button (Not used)
•Mode button (Not used)
Fig.2
Please ensure that when the handset is being paired to another device that the correct
channel is selected and that only one device is paired to each channel.
P2 Button

Page 6of 11
PROGRAMMING
The following pages give instructions of how to Program or electronically Pair the
GC105A with various motor controllers. Ensure that you select the correct set of
instructions for the motor controller on your vehicle.
GC136 AC Motor Controller
Fig.1 Fig.2
To pair the GC105A Remote handset with a GC136 Motor controller, follow the steps
below.
Note; When carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Ensure that there is power supplied to the Motor controller.
2) Using an appropriate tool press the Program button on the Motor controller. See
Fig.1 (The Green LED will start blinking)
3) Press the STOP button on the Motor Controller. See Fig.2 ( The Green LED will
remain ON)
4) Select the desired channel on the remote handset
5) Press the IN button on the remote handset. (The Green LED will extinguish)
6) Press the OUT, STOP and IN buttons on the handset to ensure that the Modules
have been successfully paired.
Program Button
Stop Button

Page 7of 11
GC274A / GC274B AC motor Controllers
Fig.3
To pair the GC105A Remote handset with a GC274A or GC274B, first remove the lid of
the motor control module by pressing on the Lid release catches as shown in Fig.3
Note; When carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Ensure that there is power supplied to the Motor controller.
2) Press the Program button on the Motor controller. (The Green LED will start
blinking)
3) Press the STOP button on the Motor Controller. ( The Green LED will remain ON)
4) Select the desired channel on the remote handset.
5) Press the IN button on the remote handset. (The Green LED will extinguish)
6) Press the OUT, STOP and IN buttons alternately on the handset to ensure that
the Modules have been successfully paired.
Lid Release
Lid Release
Program Button

Page 8of 11
98GC74 AC Motor Controller
When pairing with the 98GC74 it is advised that the awning to be controlled is manually
extended couple of feet to enable the programmer to see if the awning is responding in
the correct direction when the buttons on the remote handset are pressed.
The programming window for this module is only 6 seconds so please ensure
that the programming instructions are read and understood before
attempting to execute them.
1) Supply power to the motor control module. (It will beep ONCE )
2) Select the desired channel on the Remote Handset.
3) Press the P2 button on the Remote Handset TWICE. (The motor controller will
beep with each press)
4) Press the IN button on the Remote handset. (The awning should retract)
If the awning extends at this point instead of retracting, press the STOP button
immediately, then remove the power supply to the motor controller for at least 10
seconds.
Next repeat steps 1 to 3 above then press the OUT button on the Remote handset to
complete the programming procedure.
Ensure that the awning responds correctly to the handset by pressing the OUT, STOP
and IN buttons alternately.

Page 9of 11
GC732G DC Motor Controller
Fig.4
To pair the GC105A Remote handset with a GC732G Motor controller, follow the steps
below.
Note; When carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Ensure that there is power supplied to the Motor controller.
2) Press the Program button on the Motor controller (Fig.4). The Red LED will start
blinking)
3) Press the STOP button on the Motor Controller. ( The Red LED will remain ON)
4) Select the desired channel on the remote handset.
5) Press the IN button on the handset. (The Red LED will extinguish)
6) Press the OUT, STOP and IN buttons alternately on the handset to ensure that
the Modules have been successfully paired.
Program Button

Page 10 of 11
GC1146C DC Motor Controller
To pair the GC105A Remote handset with a GC1146C Motor controller, follow the steps
below.
•Fully extend the awning to ensure smooth operation, and then retract the
awning leaving it partially open (about 3 feet).
•Locate the P2 Button on the back of the handset.
P2 Button

Page 11 of 11
Note; When carrying out this part of the procedure each step must be
executed within 10 seconds of the previous one or the module will revert to
factory settings. It is highly recommended that you read and understand the
following sequence before attempting to execute it.
1) Supply power to the Motor controller. (The GC1146C will emit a soft beep)
2) Select the desired channel on the remote handset.
3) Using an appropriate tool press the P2 button on the back of the Handset
TWICE. ( The GC1146C will Beep with each press)
4) Press the IN button on the wall switch and verify that the awning moves in the
desired direction.
If the awning extends at this point instead of retracting, press the STOP button
immediately, then remove the power supply to the motor controller for at least 10
seconds.
Next repeat steps 1, 2 and 3 above then press the OUT button on the wall switch to
complete the programming procedure.
Ensure that the awning responds correctly to the wall switch by pressing the OUT,
STOP and IN buttons alternately.
For queries or assistance with programming any of your G-Link devices
please call Girard Systems TOLL FREE on 800–382–8442 between 7:30am
and 3:30pm P.S.T.
