GIRET GMM-10 User manual

GMM-Series Milling Machine Welding & Cutting accessories
GMM-10 type
Operation Manual
Read the manual carefully before use!
Shanghai GIRET Machinery and Equipment Co., Ltd.
1

GMM-Series Milling Machine Welding & Cutting accessories
2
Catalog
Preface 3
1. Note 3
2. Parameters 4
2.1 Application Scope
2.2 Parameters
2.3 Cutting Parameters
2.4 Each Cutter Cutting Parameters
3. Operation Instruction 5
3.1 Electric Voltage Detection
3.2 Detection Cutter
3.3 Bevel Height Adjustment
3.4 Instruction
4. Replace Cutter Head 7
4.1 General Protection Measures
4.2 Dismantle Milling Tool Head
4.3 Replace Milling Cutter Head
5. Replace Cutter Blade 8
5.1 Diagram
5.2 Step
6. Speed Governing Instruction
9
6.1 Speed Setting Table
6.2 Speed Adjustment Notes
7. Maintenance and Repair 9
8. Packing List 10
9. After-sales service 10

GMM-Series Milling Machine Welding & Cutting accessories
Preface
Dear customer, we are appreciating that your support for our products (GIRET)! Read the manual
carefully to avoid unnecessary losses.
1. Note
Read the manual and notes carefully, follow the technical specification.
Carry out related technical specification provided by country and DIN, VDE, CEE, AFNOR.
Danger!!!
Turn off the power before maintenance!
Check the socket, electric wire and machine before using.
Keep the machine dry, not in the humid environment.
Please use the thermocutout, 30mA ultimate trip current, to protect the
machine in outdoor.
Warning!!!
Do not use the machine beyond the performance
Unusual use will cause damage!
Put on the protective goggles, ear protector, gloves and protective
footwear!
Plug in the socket in switch-off state, and pull out the power wire after use
Notice!!!
Incorrect method will cause machine damage!
Do not lift the machine by the power cord!
Do not put the power wire behind the machine all the time or on sharp
objects!
Testing and maintenance personnel must be professional!
Please use the original accessories!
3

GMM-Series Milling Machine Welding & Cutting accessories
4
2. Technical Parameters
2.1 Application Scope
Can be use to process iron, chromium iron, fine-grained steel, aluminum product,
aluminum alloy, copper and plastics.
Can be used on industrial equipment by proficient personnel.
Can be processed into K, V, X or Y –shaped groove.
Can process on the mechanical engineering.
2.2 Parameters
Type:GMM-10 Bevel Width：0～15mm
Bore Dia.＞50mm Bevel Angle（Can customize the other angle）
Power：2450W Rotation speed （Adjustable）
Power Supply：AC 220V 50Hz Cutter：1 Set
Net Weight：7.0kg Original Place: Shanghai China
2.3 Cutting Parameters
Material Scope：5～20 cm³/min Plastics：20 cm³/min
Aluminum/Cooper/Mg/Lead：20 cm³/min S235：15 cm³/min
S355:：12 cm³/min S690：12 cm³/min
S960：10 cm³/min X 5 CrNi 18 10：12 cm³/min
X 6 CrNiMoTi 17 12 2：10 cm³/min
2.4 Each Cutter Cutting Parameters
Material Scope：6～4000 cm³/hd Plastics：4000 cm³/hd
Aluminum/Cooper/Mg/Lead：1500 cm³/hd S235：1000 cm³/hd
S355:：1000 cm³/hd S690：1000 cm³/hd
S960：750 cm³/hd X 5 CrNi 18 10：1000 cm³/hd
X 6 CrNiMoTi 17 12 2：750 cm³/hd
Note: GIRET keep the right of changing the technical parameters.
Asbestos-containedmaterialscannotbeusedonthe machine.
The data above the diagram based on the testing results of GMM-10 Beveling machine. All of
above parameters are only for reference; we do not take any responsibility.
We are appreciate that more parameters can be provided by you!

GMM-Series Milling Machine Welding & Cutting accessories
3. Operation Instruction
3.1 Electric Voltage Detection
Danger
Check the Voltage whether the same with the nameplate!
3.2 Cutter Detection
Blunt cutter will damage and overload the machine!
Check the cutter regularly to avoid excessive wearing!
Make sure the cutter sharp!
Notice Change the direction of cutter or replace indexable tool before blunt!
3.3 Bevel Height Adjustment
1) Rotate the check ring (2) Until the slide caliper(4) And the main scale (3)To the bevel height
you wanted.
2) Use the check ring locking at the position.
3) Use the crescent wrench tightening the guide board device (1), not too tight.
1. Guide Board Device
2. Check Ring
3. Main Scale
4. Slide Caliper
Note: For not all milling cutter heads are the same length, so the data on the main scale not
exactly accurate, and usually adjust the bevel height accurate to the millimeter!!!
3.4 Instruction
Fix the machine and use it in a flat ground before using.
Do not touch the milling cutter head while it is working.
Keep a certain distance form the machine.
Not allowed to use the machine lifting over the head.
Notice
Do not touch the work pieces while the milling cutter head rotating.
5

GMM-Series Milling Machine Welding & Cutting accessories
1.Flywheel
2.Insurance
3.Power Switch
a．Adjust “Flywheel 1” to a suitable rotation
speed;
b．Press “Insurance 2”;
c．Press “Power Switch 3”
d．Push the machine form left to right while it
is working;
e．Only clockwise operation when beveling
the circular arc;
f．Press “Power Switch 3”when stop the
work;
g．The motor stop rotating and the milling
working end.
6
Note: Control the machine by both hands when operates the machine!
Please keep a distance form the cutting head!
Unrelated person away form the working area!
2 3
Machine operation direction
Cutter rotation direction
1
Please turn off the machine, interfered a long time by the
electromagnetism.
Electromagnetic
interference(230 V)
Can reuse the machine after the electromagnetic interference
disappeared.
The electric generator shut down automatically when the temperature is
too high.
When the above happens, let the machine cool down and use it.
Engine overload
protection(230 V)
Under the normal temperature, the machine will operate.
Notice: Advice bevel height better not beyond 2mm at the beginning, and operates the machine
slowly in order to know the performance clearly!
4. Cutter Head Replacement

GMM-Series Milling Machine Welding & Cutting accessories
4.1 Conventional protective measures.
Make sure the power turn off.
Pull out the plugs form the socket.
Can not operate the machine in those cases: Turn on the machine accidentally and unknown
the machine’s performance.
4.2 Dismantle Milling Cutter Head
1) Keep a certain distance when rotates the
guide board components (guide board +
guide board rack)
2) Twist the drive shaft by the 44-52mm
wrench.
3) Then detach the guided shift head by the
hexagonal wrench.
4) Detach the milling cutter head from the
guided shift and the guided shift head by
the hook-type wrench (include the bolts,
directional bearing, guide bush, spacer
and spacer ring).
5) Put the cutting head and guided shift head
together.
Notice
Avoid damaging the screw hole, so just tight the screw by the
hand, not too tight!
4.3 Milling Cutter Head Replacement
Keep far away from the machine when rotates the guide board components (2) (guide board
+ guide board rack)
As picture shows, assembly including bolts, directional bearing, guide bush, spacer, spacer
ring and milling cutter head.
Put the lock shaft(3015R / 3018R) or the 44-52 mm wrench on the drive shaft, and then
tighten the cutting head on the drive shaft by the hook-type wrench.
As the picture shows, fix the guided shift head on the drive shaft by the hexagonal wrench.
If the guide shift head position is not yet fully aligned with the bevel cutter, adjust the spacer
numbers or the adjustment guide bush to keep them in the best position.
7

GMM-Series Milling Machine Welding & Cutting accessories
5. Replace Cutter Blade
5.1 Diagram
1 Hexagonal wrench
2 Fix the screw
3 Indexable tool
4 The milling cutting head
5 The guide board rack surface
6 The back of guide board
1 Directional bearing
2 Tight the screw
3 Cutter
4 Interface/Groove
5 Milling cutter head
5.2 Steps:
Turn off the power supply;
Press the safe button;
Loosen the screw and detach the cutter;
Clean the cutter head (guide board rack and the back) and check whether exists damage;
Rotate all the cutter head and replace them at the same time;
Make sure all the replacement cutter heads are the same model;
Put the replacement cutter heads on the dent of the guide board rack surface(5);
Put the milling cutter heads on the homologous position and tight them by the hexagonal
wrench;
Check the cutter heads and make sure they are all tight.
Check the cutter heads are the same model and fix them on the surface of guide board rack,
and all the screws are very tight.
Operate the machine slowly at the beginning, once it backward suddenly, please turn off the
machine, check the model of the cutter heads and follows what we said above. If the
phenomenon still exists, please change all the cutter heads.
Note: 1) Please turn off the power supply when replace the cutter blades!
2) Replace the cutter heads not timely will damage the machine!
3) The installed blades should be close to the directional bearing tightly, that is, the cutter
head should be installed in the top slot of the directional bearing and the long blade should
be in the middle of the slot.
8

GMM-Series Milling Machine Welding & Cutting accessories
6. Speed Governing Instruction
6.1 Speed Setting Table
Processing object Speed setting Arcing time factor
Aluminum，Copper，
Plastics approximately 5500–7500 rpm 60 %
Material intensity≤400
N/mm² Speed 3–5 approximately 4500–6500 rpm 40 %
Material intensity > 400
N/mm² Speed 2–3 approximately 2500–4500 rpm 30 %
Chrome steel，Stainless
steel，Fine-grained steel Speed 2–3 approximately 2500–4500 rpm 20 %
Notice
Arcing time factor means the working time of the machine under
full load, this percentage was calculated on 100 minutes, such
as: 60% represents the machine can only work 60 minutes every
100 minutes.
Please pay attention to the arcing time factor!
6.2 Speed Adjustment Notes:
First adjust the speed to the mid-range(‘4’);
The bevel height should not too high at the beginning;
Reduce the rotation speed if much sparkle appears.
If there is no obvious sparkle appears, you can increase appropriate speed;
The faster the rotation, the faster processing;
More sparkle, the cutter damage more quickly;
Professional indexable cutter blade can take higher temperature and more sparkle, can adapt
to higher speeds as well;
For fixed operation object, the speed can be set in the “1”in order to avoid overload operating;
do not keep the machine at the same speed all the time.
7. Maintenance and Repair
Maintenance position Maintenance method Maintenance material Maintenance time
Altitude controller Clean and add the lubrication Lubrication Weekly
Vent Clean Air Necessary
Gear Replace gear lubrication
After 100 hours work
Carbon brush
Replace carbon brush （Carbon
brush overload will cause the
machine stop automatically)
Necessary
9

GMM-Series Milling Machine Welding & Cutting accessories
8. Packing List
No. Project Model Qty Unit Remarks
1 Portable beveling machine GMM-10 1 Pcs
2 Cutting head 45° 1 Pcs
Has been installed on the
machine
3 Cutting blade 45°used 1 Set
Has been installed on the cutting
head
4 Professional wrench 1 Set
5 Operation manual 1 Pcs
9. After-sales Service
ADD: No. 16, Lane 89, Shuangye Road, Pudong Area, P.R.2012 China
Shanghai GIRET Machinery Equipment Co., Ltd.
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
10
