Gizzmo DSII Shift Light User manual

Instruction Manual
gizzmo
ELECTRONICS
www.gizzmoelectronics.com
Real Performance Product By GIZZMO
Thank you for purchasing the Gizzmo DSII Shift Light. This manual
contains operating instructions and installation procedures that are
needed for the fitting and operation of this product.

Installation Instructions
RED WIRE - 12v ignition Positive ECU terminal wire
BLUE WIRE - Negative ECU terminal wire
GREEN WIRE - Connect onto the ECU tacho signal Wire or the ECU igniter trigger wire
Once installed, when the ignition is switched on, the unit will do an opening ceremony
indicating that it is receiving power and Earth.
Warnings:
1: Incorrect installation can damage this product
2: Gizzmo Electronics will not warranty any item that has been damaged due to incorrect
installation or misuse of product.
3: When installing the product, remove the negative terminal of the battery beforehand
4: Never disassemble, modify, or tamper with this unit. Failure may cause injury or fire
and void warranty.
5: If any adjustment must be made during actual driving, take special care not to interfere
with other traffic, observing the traffic laws and
regulations
6: Do not operate this product under direct sunlight or in high-temperature
vehicle interiors that are not air-conditioned in the summer season
7: Do not install the product in a high-temperature
place or in a place exposed to direct water
Caution: under no circumstances is the DS II’s Signal wire (Green Wire) to
be connected to a high voltage ignition source e.g. the coil negative.

To Change Display intensity
The DSII has 3 Display Intensity settings. To change the present display setting simply
touch the DSII just long enough for the centre white LED to go out and then remove
your finger. Every time you do this the DSII will rotate to the next setting in the
rotation of Dim – Normal – Bright – Dim – Normal .
To Change the shift points
1. Hold your finger on the DSII until the center LED illuminates for a second time.
2. If you wish to change the Second Stage, briefly touch the DSII once and it will
3. Rev or drive your vehicle to exactly ½ of the RPM that you wish to set the
4. The DSII will display a confirmation flash of the respective stage that has been
At this point remove your finger and the DSII will start flashing the central
LED to signify that you are in the First Stage setting mode
toggle from the First Stage to the Second Stage and start flashing the outside
ring to signify this. If you briefly touch the DSII once more, it will again
toggle back to the First Stage setting mode and cause the central LED to
flash.
chosen shiftlight stage to, and hold your finger on the DSII for at least 4
seconds at this RPM.
set to indicate the new setting has been saved and then return to the normal
running mode.
For help and more details please refer to our website:
www.gizzmoelectronics.com

Gizzmo Electronics Limited
Limited Warranties Statement
Effective 1 January 2003
All Products manufactured or distributed by Gizzmo
Electronics are subject to the following Limited Express Warranties, and
no others:
For a period of one year from and after the date of purchase of a new
Gizzmo Electronics product, Gizzmo Electronics warranties and
guarantees only to the original purchase/user that such a product will be
free from defects of material and workmanship in the manufacturing
process. Gizzmo Electronics, at its sole option, shall replace the defective
product. This express warranty shall be inapplicable to any product not
properly installed and properly used by the purchaser/user or to any
product damaged or impaired be external forces. This is the extent of
Warranties available on this product. Gizzmo Electronics shall have no
liability
whatsoever for consequential damages following from the use of any
defective product or by reason the failure of any product. Gizzmo
Electronics specifically disclaims and disavows all other warranties,
express or implied including, without limitation, all Warranties of fitness
for a particular propose, Warranties of Description, Warranties of
Merchantability, Trade Usage or Warranties of Trade Usage, The above
warranty is valid in New Zealand, Australia, UK and the America’s only as
Gizzmo Electronics does not offer an international warranty outside of
these regions.
