Glacier bay SP-2026PS1 User manual

THANK YOU
We appreciate the trust and confidence you have placed in Glacier Bay through the purchase of this SINGLE DOOR MEDICINE CABINET. We
strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for
your home improvement needs. Thank you for choosing Glacier Bay!
USE AND CARE GUIDE
SINGLE DOOR MEDICINE CABINET
Questions, problems, missing parts? Before returning to the store,
call Glacier Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-HD-GLACIER
HOMEDEPOT.COM/GLACIERBAY
Item #1001 332 932
Model #SP-2026PS1

2
Table of Contents
Table of Contents ...................................2
Safety Information ..................................2
Warranty ......................................... . 2
Pre-Installation.................................... . 3
Planning Installation ...............................3
Tools Required ................................... . 3
Hardware Included................................ . 3
Package Contents .................................4
Safety Information
Save these installation instructions for future reference. WARNING: Safety discard all packing material. Keep
plastic bags and small parts away from children.
CAUTION: Accessories are installed in both top & bottom
poly-foam. Please ensure all the accessories are removed
from the packing before discard.
CAUTION: Safety glasses should be worn at all times.
Warranty
This product is guaranteed to operate a minimum of 1 year from the original date of purchase. If, under
normal use and for the full time period, your product fails to operate, please return it to: Service Dept .,
Prokonian Inc.. USA (with your original proof of purchase receipt) and we will refund it.
This warranty is considered void if the product fails from misuse. Contact the Customer
Service Team at 1-855-HD-GLACIER or visit www.homedepot.com/glacierbay.
Installation ................................... . . 5-10
Surface Mounting Only .......................... .
Recess Mounting Only ............................. . 7
Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Care and Cleaning .................................11
Hinge Adjustment ............................. . 8-10
5-6

3 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Pre-Installation
PLANNING INSTALLATION
□Unpack your medicine cabinet carefully, and close the sink drain to prevent any dropped parts from falling into the drain.
□Before installing your medicine cabinet, decide whether you want to install your cabinet using a surface or a recess mount and
determine which direction you want the door to open.
□For a recessed mount installation, you do not install the side mirrors. Additional framing may be required to secure the cabinet.
TOOLS REQUIRED
Measuring
tape Level Phillips screwdriver
Electric drill
for surface
mounting
Stud
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
GG II JJ KK
BB CC
AA DD EE
FF HH
MMLL NN
FF
KK
Part Description Original Part QTY Spare Part QTY
Philips head screws (#8x0.375 in.) 4 2
Shelf clip 12 2
Shelf hole plug 24 2
Snap cap 4 2
Washer 4 2
AA
BB
CC
DD
EE
Side mirror bracket
2
0
Philips head screws (#8x1.5 in.) 4 2
Wall anchor 4 2
Top clip 2 0
Side mirror bracket tape 2 0
GG
HH
II
JJ
Bumper
4
2
CAUTION: The included plastic wall anchors (HH) are intended for use
with solid wall applications only (tile and concrete). DO NOT USE WITH
DRYWALL OR OTHER HOLLOW WALL APPLICATIONS. Refer to additional
warning information on Page 5 of this instruction manual.

4
Pre-Installation (continued)
PACKAGE CONTENTS
A
D
E
F
C
B
Part Description Quantity
A Hinge 2
B Side mirror 2
C Cabinet 1
D Door 1
E Shelf glass 3
F Bottom bracket 1

5 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
Installation - Surface Mounting Only
1a
Installing the bottom bracket
NOTE: The height of the bottom bracket (F)
should be a minimum of 2 in. above the faucet.
□Using a level and measuring tape, ensure the bottom
bracket (F) is level and positioned accordingly.
□Mount the bottom bracket (F) to the wall using the 1.5 in.
Phillips head screws (GG). See the Warning regarding the
fastening of the bracket (F).
□Carefully position the cabinet (C)
onto the bottom bracket (F).
F
GG
2a
Installing the top clips
□Install the top clips (II) by inserting the rounded ends
into the rear top slot of the cabinet (C). See the Warning
regarding the fastening of top clips (II).
□Slide one top clip (II) to the left and one to the right.
□Mount the top clips (II) to the wall by installing two 1.5 in.
screws (GG) through the top clips to secure the cabinet.
GG II
C
II
C
WARNING: If installing the cabinet on drywall or other
hollow wall applications, the bottom mounting bracket (F)
and top clips (II) must be fastened to studs, headers, or
other structural wall members. The included plastic wall
anchors are intended for use with solid wall applications
only (tile or concrete). DO NOT USE WITH DRYWALL OR
OTHER HOLLOW WALL APPLICATIONS.

6
Installation - Surface Mounting Only
3a
Preparing the side mirror brackets
□Adhere the side mirror bracket tape (JJ) to the side mirror
brackets (KK) as shown. Make sure the bracket (KK) surface
is clean.
4a
Attaching the side mirrors
JJ
KK
Unable to assembling it as the
mounting bracket is turned upside
down not correctly.
KK
Side view
The hole is off center, the side
mirror mounting brackets only
one side can be assembled
KKKK
Side view
□Attach four side mirror brackets (KK) to the cabinet (C)
sides with screws (AA) and washers (EE). Cover the screw
heads with snap caps (DD).
□Remove the paper on the side mirror bracket tape (JJ), and
stick the side mirrors (B) to the side mirror brackets (KK).
NOTE: Please make sure the side mirrors are
aligning with the cabinet (C) before attaching the
side mirrors (B).
DD AA EE
CKK B
KK
Rotary the side mirror
mounting bracket of
clockwise 180 degree.
.

7
Installation - Recess Mounting Only
1b
Cut away the drywall
NOTE: For recess mount, do not install side mirrors and
brackets.
□Cut away the drywall. The rough opening dimension is
19-1/5 in. x 25-2/5 in. x 3-7/8 in..
19-1/5 in
25-2/5 in
2b
Frame out the wall cavity
□Mark the opening size of the framing.
□Construct rough opening as illustrated.
3b
Mounting the cabinet into a recess
□Insert the cabinet (C) into the rough opening and make
sure the cabinet is level and plumb. (Use wood shims as
required)
□Secure both sides of the cabinet (C) at the designated
mounting hole locations using screws (GG) and washers
(EE). Cover the screws (GG) with snap caps (DD).
EE GG DD
C
HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.

8
Installation - Hinge Adjustment
1c
Hinge installation
Depth adjustment is made without loosening any screw. The
door can be moved in or out by rotating the cam adjuster on
the hinge arm.
□
NOTE: Two people may be needed to perform this
installation.
Side view of the Cabinet
Top view of the hinge

9
HOMEDEPOT.COM/GLACIERBAY
Vista frontal del gabinete
Installation - Hinge Adjustment
2c
Hinge installation
Side adjustment of the door is made by using the indicated
screw.
□
NOTE: Two people may be needed to perform this
installation.
Front view of the cabinet
Top view of the hinge
Please contact 1-855-HD GLACIER for further assistance.

10
Installation - Hinge Adjustment
3c
Hinge installation
up or down, the door can be adjusted vertically. After retightening the
screws, the depth adjustment is done
□
NOTE: Two people may be needed to perform this
installation.
Front view of the Cabinet
Top view of the hinge

11 HOMEDEPOT.COM/GLACIERBAY
Please contact 1-855-HD-GLACIER for further assistance.
1 Installing the shelves
□Install the glass shelves (E) to your desired positions with
shelf clips (BB) as illustrated below.
E
BB
C
2 Plugging the empty holes
□Use the shelf hole plugs (CC) to seal the empty holes.
C
CC
3 Adding the bumpers
□Stick the bumpers (FF) at the two corners of the door (D).
FF
FF
D
A
Care and Cleaning
□Use a household liquid glass cleaner to keep the mirror and glass surfaces clean.
□Do not use abrasive cleaners containing ammonia.
Assembly

Questions, problems, missing parts? Before returning to the store,
call Glacier Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-HD-GLACIER
HOMEDEPOT.COM/GLACIERBAY
Retain this manual for future use.

1001 332 932
SP-2026PS1

Instalación ..................................... 5-10
................... 5-6
Montaje empotrable solamente....................... 7
Ensamblaje ......................................11
Cuidado y limpieza .................................11
............................ . 8-10Ajuste de la bisagra

3 HOMEDEPOT.COM/GLACIERBAY
Para obtener asistencia, por favor, póngase en contacto llamando al 1-855-HD-GLACIER.
Pre-instalación
PLANIFICACIÓN DE LA INSTALACIÓN
□Desempaque su botiquín con cuidado y cierre el desagüe del lavabo para evitar que las piezas caigan en el desagüe.
□
quiere que abra la puerta.
□Usted no instalará los espejos laterales (B), se puede requerir enmarcado adicional para asegurar el gabinete.
HERRAMIENTAS REQUERIDAS
Cinta
métrica Nivel Destornillador Phillips
Taladro
eléctrico
para montaje
Localizador
de montantes
HERRAJE INCLUIDO
NOTA: No se muestra el herraje en el tamaño real.
GG II JJ KK
BB CC
AA DD EE
FF HH
Tornillos Phillips (#8 X 0.375 pulg.)
Gancho de repisa
Tapón de agujero de repisa
Tapa a presión
Arandela
Paragolpes
Tornillos Phillips (#8 X 1.5 pulg.)
Ancla de pared
Gancho superior
Cinta de soporte de espejo lateral
Soporte de espejo lateral
FF
KK
Cantidad
Pieza Original
Cantidad de
Pieza Repuesto
4 2
12 2
24 2
4 2
4 2
AA
BB
CC
DD
EE
2
0
4 2
4 2
2 0
2 0
GG
HH
II
JJ
4
2
Pieza Descripción
PRECAUCIÓN: Las anclas plásticas incluidas (BB) están previstas
para ser usadas con aplicaciones de pared sólida solamente (azulejo
y concreto). NO LO USE CON APLICACIONES DE PARED SECA U
OTRAS APLICACIONES DE PARED HUECA. Consulte la información de
advertencia adicional en la página 5 de este manual de instrucción.

4
Pre-instalación (continuación)
CONTENIDO DEL PAQUETE
A
D
E
F
C
B
Pieza Descripción Cantidad
A Bisagra 2
B Espejo lateral 2
C Gabinete 1
D Puerta 1
E Repisa de vidrio 3
F Soporte del fondo 1

5 HOMEDEPOT.COM/GLACIERBAY
Installation - Surface Mounting Only
1a
Installing the bottom bracket
NOTE: The height of the bottom bracket (F)
should be a minimum of 2 in. above the faucet.
□Using a level and measuring tape, ensure the bottom
bracket (F) is level and positioned accordingly.
□Mount the bottom bracket (F) to the wall using the 1.5 in.
Phillips head screws (GG). See the Warning regarding the
fastening of the bracket (F).
□Carefully position the cabinet (C)
onto the bottom bracket (F).
F
GG
2a
Installing the top clips
□Install the top clips (II) by inserting the rounded ends
into the rear top slot of the cabinet (C). See the Warning
regarding the fastening of top clips (II).
□Slide one top clip (II) to the left and one to the right.
□Mount the top clips (II) to the wall by installing two 1.5 in.
screws (GG) through the top clips to secure the cabinet.
GG II
C
II
C
WARNING: If installing the cabinet on drywall or other
hollow wall applications, the bottom mounting bracket (F)
and top clips (II) must be fastened to studs, headers, or
other structural wall members. The included plastic wall
anchors are intended for use with solid wall applications
only (tile or concrete). DO NOT USE WITH DRYWALL OR
OTHER HOLLOW WALL APPLICATIONS.
Para obtener asistencia, por favor, póngase en contacto llamando al 1-855-HD-GLACIER.

6
4a
JJ
KK
DD AA EE
CKK B
I
3a
Preparación de los soportes
del espejo lateral
□Adhiera las cintas (JJ) en los soportes del espejo lateral
de los soportes (KK) esté limpia.
Instalación de los espejos laterales
□Instale cuatro soportes deespejo lateral (KK) en los ladosdel
gabinete (C) con tornillos (AA) y arandelas (EE),y tapas apresión
(DD) para cubrir lascabezas delos tornillos como seilustra.
□Retire el papel en las cintas (JJ), y adhiera los espejos
laterales (B) en los soportes de espejo lateral (KK).
NOTA: Asegúrese de que los espejos laterales
están alineando con el gabinete (C) antes de
adjuntando los espejos laterales (B).
No se puede ensamblar ya que el
soporte de montaje está invertido
de manera no correcta.
Gire el soporte de montaje del
espejo lateral hacia la derecha
180 grados.
El agujero está descentrado, los soportes
de montaje del espejo lateral solo
un lado se puede ensamblar.
KK
Vista lateral
KKKK
Vista lateral
KK

7
Instalación – Montaje empotrable solamente
1bCorte la pared seca
NOTA: Para montaje empotrable, no instale los espejos
laterales y los soportes.
□Corte la pared seca Las dimensiones de la abertura áspera
son 19-1/5 pulg. x 25-2/5 pulg. x 3-7/8 pulg
19-1/5 pulg.
25-2/5 pulg.
2b
Enmarque la cavidad de la pared
□Marque el tamaño de la abertura del enmarcado.
□Construya la abertura áspera como se ilustra.
3b
Montaje del gabinete en un hueco
□Inserte el gabinete (C) en la abertura áspera y asegúrese
de que el gabinete esté a nivel y vertical. (Use cuñas de
madera como se requiera)
□Asegure ambos lados del gabinete (C) en las ubicaciones
del agujero de montaje designado usando tornillos (GG)
y arandelas (EE). Cubra las cabezas de los tornillos (GG)
con tapas a presión (DD).
EE GG DD
C
HOMEDEPOT.COM/GLACIERBAY
Para obtener asistencia, por favor, póngase en contacto llamando al 1-855-HD-GLACIER.

8
I - Ajuste de la bisagra
1c La instalaci
Vista superrior de bisagra
□
NOTA: Se necesitan dos personas para realizar esta
instalación.
La se puede mover hacia adentro y hacia afuera girando el
regulador de la leva en el brazo de la bisagra.
nstalación
ón de bisagra
Vista laterral del gabinete
