SERIES II
MANUAL & INSTRUCTIONS
For Rocker Switch Accu-Finish II Machines
Serial Numbers begin with (115 V) AB08033 or
(230 V) EB08015. Revised 08/2008.
GLENDO CORPORATION
Accu-Finish SERIES II

PAGE 1 of 7 001-193
Dear Customer,
We appreciate your business. Your
new machine is quality engineered and
manufactured. Although it is designed
for minimal maintenance, it does require
some attention. Please consult this
manual for information on operation and
maintenance.
Glendo Corporation warrants this
product for two (2) full years against
defects in material and workmanship.
Any such defect will be repaired or
replaced by sending it freight prepaid to:
Glendo Corporation
900 Overlander Road
Emporia, KS 66801
After servicing under the warranty,
Glendo will pay normal surface freight
back to the customer’s location. Shipping
damage, normal wear and tear, and
abuse not covered. Consumables not
included. If damage occurs in transit, le
a claim with the carrier.
To put this warranty into effect, ll out the
warranty card and return it within ve (5)
days of receipt. Please keep a copy for
your records. All inquiries about servicing
your machine should be addressed to
Glendo Corporation.
Please Note: Accessories for this product are
constantly being developed. The only way we can
inform you of these new items is if you return your
warranty card. Your name will remain a condential
part of our company records.
Accu-Finish SERIES II
SERIES II
Accu-Finish Series II
Accu-Finish is designed to provide accurate angles and superior nishes
on virtually all tool materials. As the name implies, Accu-Finish is not for
rough shaping where large amounts of tool material must be removed.
This is best done on a high speed bench grinder or similar machine. Tool
nishing or resharpening dull tools is the strength of Accu-Finish. Since
proper tool nishing is by far the most critical job, the Accu-Finish works
where the machinist needs the most help.
Safety
Wear proper Safety Items such as safety glasses, gloves, respirator, and
other personal safety equipment as necessary or required.
DISCONNECT machine’s electrical power cord from power outlet before
performing any service on your machine which does not require power.
EYE PROTECTION IS REQUIRED
WHEN OPERATING THIS MACHINE
RESPIRATOR IS REQUIRED
Avoid breathing dust to prevent lung disease.

001-193 PAGE 2 of 7
Accu-Finish SERIES II
A
TABLE LEVER HANDLE
BALL BEARING (4)
METAL RETAINER STRIP
SERIES II
TABLE LOCK
This knob locks the table in position. Loosen
it when you want to oscillate the table.
Tighten it to hold the table in place.
B
C
8. Replace the retainer bar with
the two Phillips head screws.
Make sure the rubber bumper
is oriented properly. It should be
directly across from the rubber
bumper on the other side and the
rubber pointy nub on the outside.
9. See Cfor how to lock table.
*A denite resistance will be
encountered with engaging the
second set of bearings. This is due
to the preloaded design in which the
bearings actually squeeze the mating
track. Align bearings with machined
track before using any force. When
properly aligned, only a slight nudge
is required to urge the table over the
second set.
4. Note there are four (4) ball
bearings mounted on the table
support structure. These bearings
allow the table to roll.
5. Place the table face down on
your work bench. Find the metal
retainer strip located at each
end. From only one strip, remove
the two screws with a Phillips
screwdriver (B). Note the small
rubber bumper.
6. Turn the table face up and start
the table onto the rst set of
bearings, making sure they locate
properly in the machined tracks.
7. Slide table across until the
second set of bearing*contacts
to the end of the track (B).
Conrm proper alignment, then
slide table the rest of the way.
Installation
1. Unpack the machine and parts on
a suitable work surface.
2. Rotate the motor housing up and
back until the wheel spindle is
oriented in the vertical position (A).
3. For easier table installation, loosen
table support by pulling the handle
left. Rotate the support up until it is
at approximately 0°. Lock handle.
Attaching A Wheel
Select the wheel you wish to use
(see application chart below). Attach
wheel to machine with the at head
machine screw using the 3/16" hex
T-wrench. To ensure proper wheel
trueness, make sure that the back of
the wheel and the spindle face are
clean when mounting wheels.
Wheel Use For
260 Grit Roughing & Shaping
360 Grit Carbide Roughing
600 Grit General Purpose
1200 Grit Fine Finish
Ceramic Lap Mirror Finish
See back page for wheels available
to use with Accu-Finish.
READ ALL DIRECTIONS before attempting setup or installation of this machine.

PAGE 3 of 7 001-193
Accu-Finish Protractor Extension Arm
Order #001-822
G
SERIES II
TABLE
ANGLE
LEVER
HANDLE
TABLE
LOCK
DIAMOND
WHEEL
TOOL
GUIDE
TABLE ANGLE
PROTRACTOR
TO SET
TOOL CLEARANCE
(RELIEF)
WHEEL
ANGLE
PROTRACTOR
SERIES II
LOCATOR
BLOCK
D
E
Table Position
The vertical wheel position allows
use of the calibrated table and
tool guide. Two tool angles can be
simultaneously controlled.
Tool clearance (relief) can be
adjusted by setting the table
elevation. To set table elevation:
1. Slide table to the right.
2. Pull the table lever handle left
to free the table, allowing you to
change the angle.
3. Set the elevation scale to desired
degree (0° is square to wheel).
Tighten locking knob (D).
NOTE: To ensure proper elevation
accuracy, the hinged surface between
the main motor housing and the side
support arms must be kept clean.
Make sure that no metal particles or
obstructions are stuck to the holding
magnet or their mating surfaces.
The table is factory calibrated, but
you may want to calibrate it yourself
sometime in the future. With the
table angle unlocked, place a square
against the table and wheel, then lock
the table. This is a perfect 90° -OR-
0° on the angle protractor. Loosen the
locator block and align mark with the
0° mark on the protractor and tighten
the locator block (E).
The tool guide is adjustable to 75º
either side of 0º. Loosen the knurled
locking screw in the tool guide. Set
angle to desired degree on scale and
tighten locking screw.
Tool Guide
For angles greater than 75º, obtain
a piece of at material about 2" – 3"
square by 1/8" – 1/2" thick. Place this
square block against the tool guide
(F). Working from the 90º offset lets
you set all angles.
Accu-Finish offers a Protractor
Extension Arm (#001-822) that
clamps to the tool guide. This makes
it easier to hold the tools while
sharpening (G).
F
COUNTER CLOCKWISE
“OFF” POSITION
CLOCKWISE
READ ALL DIRECTIONS before attempting
setup or installation of this machine.

001-193 PAGE 4 of 7
Power Controls
To operate this machine, use the
Rocker Switch (shown above). The
center position designates that the
machine is “OFF”. Press the left side
of the switch to operate in Counter
Clockwise (CCW) mode. Use CCW
mode when you are working on
the left side of the wheel. Press the
right side of the switch to operate
in Clockwise (CW) mode. Use CW
mode when you are working on the
right side of the wheel.
There is an optional Power Foot
Switch (#002-205) available that will
allow you to start the machine with
the touch of your toe. The foot switch
is handy especially when you want
both hands free. The foot switch is
ideal for horizontal lapping.
Changing The Fuse
FIRST: UNPLUG THE MACHINE.
The fuse is located near where the
power cord connects to the machine
(H). Using a screw driver, gently turn
the spring-loaded fuse retainer until
it is loose and pops out. Replace the
fuse in the retainer with the correct
fuse. Press it back into the fuse
housing. Gently turn the retainer with
the screw driver until it locks.
SERIES II
Horizontal Wheel Use
As you learned when you installed
the table, the motor housing pivots so
the wheel is in a horizontal position.
This feature has many diverse uses.
Two of the more common uses
include renishing the tops (or faces)
of inserts and honing at surfaces
on tool blanks. It is also useful in
removing build-up from the top edges
of cutting tools.
Grinding on
Diamond Wheels
Follow this recommended procedure.
Approach the surface carefully with the
tool. Apply cutting pressure smoothly.
Be especially attentive when rst
cutting sharp points. Wet the diamond
surface with the water soluble cutting
uid supplied with your Accu-Finish.
Only occasional spraying to keep the
surface wet is required. Oscillate the
table whenever practical during cutting.
This promotes faster cutting, helps
keep the wheel clean, and increases
wheel life. Clean the diamond wheels
when required (see below).
Clean or Dress a Wheel?
Terminology is often confusing on
the difference between cleaning and
dressing a diamond wheel. Cleaning
means removing dirt. Dressing is
done with an abrasive stick. Dressing
is performed on a rotating wheel and
actually removes a small amount of
wheel material, mostly the bonding
agent. Proper dressing will extend
wheel life, not shorten it. Cleaning
should be done much more regularly
than dressing.
Clean a Diamond Wheel
Remove wheel from machine and
take wheel to a sink. Wet the wheel
with water and liberally sprinkle with
scouring powder (e.g. Bon Ami, Ajax,
Comet). IMPORTANT: DO NOT USE
SOLVENTS. With a scrub brush or rag,
work the powder into the diamond area
thoroughly, then rinse with clean water
and wipe dry.
Dress a Diamond Wheel
Place the Accu-Finish machine in
the horizontal position. Place a cloth
or large rag over the table assembly
to protect from dust. Wet wheel with
water soluble wetting agent and turn
machine ON. Apply Wheel Cleaning
Stick (#001-783) to the wheel and
slowly transverse the stick across
the face of the wheel, maintaining a
moderate, uniform pressure. Remove
stick and turn machine OFF. Clean
abrasive debris off wheel and machine.
Remove cloth from table assembly and
return machine to vertical position.
600
Accu-Finish diamond wheels
are designed for this slow RPM
application. Most materials are
compatible with Accu-Finish wheels,
including ceramic, carbide, borazon,
HSS, and polycrystaline diamond.
We recommend wetting the wheels
with wheel wetting agent. The
concentrate supplied with you
machine is ideal (#001-659, 3 Pack
/ #001-660, 12 Pack). Occasionally
mist the wheel with the agent from a
hand spray bottle. A dry nishing will
give fair results, but wet nishing will
perform better than dry.
Diamond wheels provide long
term economy and performance in
abrasive service if used correctly.
Diamond is the hardest material
known, although the bond which
holds the diamond particles in place
can be damaged. Grooving the wheel
by gouging the bonding material is
the biggest error. The ner the grit,
the easier it is to damage the wheel.
The user should not be afraid of using
moderate pressure while cutting as
the wheels are designed for this.
H
COUNTER CLOCKWISE
(CCW)
“OFF” POSITION
CLOCKWISE
(CW)

PAGE 5 of 7 001-193
Drive Belt Replacement
Disconnect machine from electrical
power. Remove rear panel from
machine by removing four (4) Phillips
screws. Roll the old belt(s) off, rst
from the small pulley and then from
the large pulley. Place new belt(s)
over the large pulley rst, align
with small pulley and roll them on.
Replace rear panel.
Lift Kit
Included with your Accu-Finish
Series II is a lift kit. This is for those
who wish to raise the wheel center
higher above the table. Because
some xtures on the market are taller
than Accu-Finish xtures, the lift kit
will allow the use of those xtures.
TO INSTALL LIFT KIT
Remove the side bolts (one located
each side) that hold the motor
housing. Separate the motor housing
from the base. On each side, switch
the bolt bushings and the plastic
plugs. (I).
From the center base, remove the
bolts that hold the latch magnet. Turn
the magnet brackets 90º. Move the
magnet to the top and replace the
bolts (I). Remove the two rubber
stops located at the back. Push the
bolt out of the center of each and
replace with the long bolt that comes
with the lift kit. Insert the long bolt
through the plastic extensions and
replace on base. Reattach the motor
housing unit to the side arms.
SERIES II
Heavy-Duty Lamp Kit
Order #001-756 - 115 Volt
Order #001-951 - 230 Volt
Extra heavy-duty, UL listed lamp
has 24" exible neck that is sealed
against oil and grit. This lamp stays
where you put it. Quick-mount
bracket for easy installation.
Rated to a bright 100 watts to
give plenty of work light. Insulated
shade stays cool.
Power Foot Switch
Order #002-205
Turn the machine ON
and OFF with both
hands free. Especially
useful for horizontal
lapping. Comes prewired for
standard 3-wire, 115 Volt grounded
outlet. UL listed to 1/2 HP.
SERIES II
Inspection
The better you can see, the better
the results!
This Accu-Finish microscope system
is unique because you can inspect
and work under it. This difference is
critical. The large focal length gives
you plenty of distance under the
microscope for hand tools, power
tools, measuring and gauging tools.
Work is done with absolute
clarity and precision without
eye fatigue.
ACCESSORIES
For more information about
Accu-Finish products visit
www.accu-finish.com
or call 1-800-835-3519
I
Table removed to
show detail
LIFT KIT
EXTENSION POSTS
& LONG BOLTS
MAGNET
BRACKET

001-193 PAGE 6 of 7
Power Cord
Capacitor
002-275
Motor
002-273
230 V, 50 Hz
Machine Frame
Fuse
022-136
Yellow Wire
Red Wire 011-401
Blue Wire 011-402
001-588 (Black)
Yellow Jumper 011-400
Red Motor Wire
Blue Motor Wire
Light Blue Wire
Brown Wire
Yellow / Green Wire
001-589 (Yellow / Green Wire)
Fuse Holder
Switch
022-568
Power Cord
Motor
Machine Frame
Yellow Wire
Red Wire 011-401
Blue Wire 011-402
001-588 (Black)
Yellow Jumper 011-400
Red Motor Wire
Blue Motor Wire
001-589 (Yellow / Green Wire)
Black Wire
White Wire
002-274
115 V, 60 Hz
Fuse Holder
Yellow / Green Wire
Switch
022-568
Fuse
022-137
Capacitor
002-276
WIRING DIAGRAM
WARNING: ALWAYS DISCONNECT MACHINE FROM POWER BEFORE SERVICING.
SHOCK HAZARD: ANY CAPACITOR CAN HOLD A CHARGE.
DISCHARGE CAPACITOR BEFORE HANDLING.
115 V, 60 Hz MODEL
022-137 Fuse - VDE / GDC 3.15A
002-274 Motor - 115 V, 60 Hz
002-276 Capacitor - 115 V, 60 Hz
230 V, 50 Hz MODEL
022-136 Fuse - VDE / GDC 2A
002-273 Motor - 230 V, 50 Hz
002-275 Capacitor - 230 V, 50 Hz

PAGE 7 of 7 001-193
SERIES II
1
2
3
5
611
INSIDE
10
9
78
4
Order # Description
1 022-568 Rocker Switch
2 002-293 5/16" -18 UNC X 1/2" FHSMS
3 001-592 Tool Guide Assembly
4 001-644 Tool Guide Lock Stud
5 001-539 Knob Assembly
6 002-252 Table Lock Handle
Order # Description
7 022-135 Fuse Holder
8 022-137 Fuse - VDE / GDC 3.15A - 115 V, 60 Hz
022-136 Fuse - VDE / GDC 2A - 230 V, 50 Hz
9 002-274 Motor - 115 V, 60 Hz
002-273 Motor - 230 V, 50 Hz
10 002-263 Belt (1)
11 002-276 Capacitor - 115 V, 60 Hz
002-275 Capacitor - 230 V, 50 Hz
Diamond Wheels Available for Accu-Finish Series II
Call for pricing or visit our website
Description & Application (6" Dia.) Order #
100 Grit Fast Rouging 011-198
180 Grit “Gator” Fast Rouging 001-387
260 Grit Rouging and Shaping 001-233
360 Grit “Gator” Rouging 001-234
360 Grit Rouging 001-661
500 Grit General Purpose / Medium 011-080
600 Grit General Purpose / Medium Fine 001-235
600 Grit BORAZON - Medium Fine 001-809
800 Grit Fine 011-212
1200 Grit Extra Fine 001-236
1200 Grit BORAZON - Extra Fine 011-254
Automotive and Special Tool Wheels
360 Grit Face / Edge Rouging 001-920
600 Grit Face / Edge General 001-921
1200 Grit Face / Edge Extra Fine 001-922
320 Grit Reverse Angle Rouging 011-113
600 Grit Reverse Angle General 011-087
1200 Grit Reverse Angle Extra fine 011-088
Ceramic Lap
Ultra-polishing “Mirror” Finish 001-671
Requires charging with diamond spray.
900 Overlander Road
Emporia, KS 66801
Toll Free: 1-800-835-3519
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
www.accu-finish.com
600
PARTS LIST
