Global American Inc. 3308520 User manual

3308520 User’s Manual
5.25" Embedded Controller with Socket 479
for Intel Pentium M/ Celeron M
Version 1.0

Copyrights
This document is copyrighted and all rights are reserved. It does not allow any non
authorization in copied, photocopied, translated or reproduced to any electronic or
machine readable form in whole or in part without prior written consent from the
manufacturer.
In general, the manufacturer will not be liable for any direct, indirect, special, incidental
or consequential damages arising from the use of inability to use the product or
documentation, even if advised of the possibility of such damages. The manufacturer
keeps the rights in the subject to change the contents of this document without prior
notices in order to improve the function design, performance, quality and reliability. The
author assumes no responsibility for any errors or omissions, which may appear in this
document, nor does it make a commitment to update the information contained herein.
Trademarks
Intel is a registered trademark of Intel Corporation.
Award is a registered trademark of Award Software, Inc.
All other trademarks, products and or product's name mentioned herein are mentioned
for identification purposes only, and may be trademarks and/or registered trademarks of
their respective companies or owners.

Table of Contents
Chapter 1 General Description ..................................1
1.1 Major Features....................................................................... 2
1.2 Specifications ........................................................................ 3
1.3 Board Dimensions................................................................. 5
Chapter 2 Unpacking ..................................................7
2.1 Opening the Delivery Package............................................. 7
2.2 Inspection............................................................................... 7
Chapter 3 Hardware Installation ..............................9
3.1 Before Installation ................................................................. 9
3.2 Board Layout ....................................................................... 10
3.3 Jumper List .......................................................................... 11
3.4 Connector List ..................................................................... 11
3.5 Configuring the CPU ........................................................... 12
3.6 System Memory ................................................................... 12
3.7 VGA Controller .................................................................... 13
3.8 PCI E-IDE Drive Connector................................................. 15
3.9 Floppy disk Drive Connector ............................................. 16
3.10 Parallel Connector............................................................... 17
3.11 Serial Port Connectors ....................................................... 18
3.12 Ethernet Connector............................................................. 19
3.13 USB Port............................................................................... 20
3.14 CMOS Data Clear................................................................. 20
3.15 Power and Fan Connectors................................................ 20
3.16 Keyboard/Mouse Connectors ............................................ 22
3.17 System Front Panel Control ............................................... 22
3.18 Watchdog Timer .................................................................. 23
3.19 Audio Connectors ............................................................... 24
3.20 CompactFlashConnector................................................ 24
3.21 PCI Expansion Slot ............................................................. 25
3.22 GPIO Function ..................................................................... 26
3.23 Capture Function................................................................. 26
3.24 TV-Out and S-Video Function ............................................ 27
3.25 PC/104 Connectors ............................................................. 28

Safety Instructions
Integrated circuits on computer boards are sensitive to static electricity. To
avoid damaging chips from electrostatic discharge, observe the following
precautions:
 Do not remove boards or integrated circuits from their anti-static packaging
until you are ready to install them.
 Before handling a board or integrated circuit, touch an unpainted portion of
the system unit chassis for a few seconds. This helps to discharge any static
electricity from your body.
 Wear a wrist-grounding strap, available from most electronic component
stores, when handling boards and components. Fasten the ALLIGATOR clip
of the strap to the end of the shielded wire lead from a grounded object.
Please wear and connect the strap before handle the product to ensure
harmlessly discharge any static electricity through the strap.
 Please use a conductive from pad when putting down any components or
parts or tools outside the computer. You may also use an anti-static bag
instead of the pad. If such a situation is not available, you can provide some
ESD protection by wearing an antistatic wrist strap and attaching if to a metal
part of the computer chassis. Please inquire from your local supplier for
additional assistance in finding the necessary anti-static gadgets.
NOTE: DO NOT TOUCH THE BOARD OR ANY OTHER SENSITIVE
COMPONENTS WITHOUT ALL NECESSARY ANTI-STATIC
PROTECTIONS.

1
Chapter 1
General Description
The 3308520 is an Intel® 852GME GMCH and is an Intel®
852GM GMCH chipset-based board designed. The 3308520/
is ideal all-in-one embedded engine board. Additional
features include an enhanced I/O with CF, mini PCI slot, PCI slot,
GPIO, CRT/LVDS, LAN, audio, 4 COM, PC/104, and USB2.0
interfaces.
Its onboard ATA/33/66/100 to IDE drive interface architecture allows
the 3308520/ to support data transfers of 33, 66 or
100MB/sec. to one IDE drive connection. The 3308520 supports Intel®
Pentium® M/Celeron® M processor 1.3~2.0GHz, and
supports ULV Intel® Celeron® M processor 600MHz/512K.
The Intel® 852GM(E) with 8MB shared main memory supports CRT
display up to 1600 x 1200. It also supports LVDS interface, 3308520
provides 24-bit single channel/48-bit dual channel, provides
18-bit single channel/36-bit dual channel.
System memory is also sufficient with the one DDR socket that can
support up to 1GB.
Additional onboard connectors include 6 x USB2.0 ports providing
faster data transmission. And one 10-pin connector for 10/100 Based
Ethernet uses.

2
To ensure the reliability in an unmanned or standalone system, the
watchdog timer (WDT) onboard 3308520/ is designed with
software that does not need the arithmetical functions of a real-time
clock chip. If any program causes unexpected halts to the system, the
onboard WDT will automatically reset the CPU or generate an interrupt
to resolve such condition.
1.1 Major Features
The 3308520/ provides with the following features:
 Intel® Pentium® M/Celeron® M processor 1.3~2.0GHz (3308520)
ULV Intel® Celeron® M processor 600MHz/512K ()
 Supports 533MHz FSB (only 3308520)
 One 200-pin SO-DIMM socket up to 1GB DDR SDRAM
 Intel® 852GME GMCH/ICH4 system chipset (3308520)
Intel® 852GM GMCH/ICH4 system chipset ()
 Winbond W83627HG-AW super I/O chipset
 Intel® 82852GME graphics controller (3308520)
Intel® 82852GM graphics controller ()
 24-bit/48-bit LVDS Panel display interface (3308520)
18-bit/36-bit LVDS Panel display interface ()
 Intel® 82562ET fast Ethernet controller
 ALC203 3D audio controller
 Fast PCI ATA/33/66/100 IDE controller
 CF, GPIO, 4 COM, 6 USB2.0, PC/104
 TV-Out (3308520 only), Capture (3308520 only), H/W Monitor function

3
1.2 Specifications
 System
 CPU
3308520 provides Intel® Pentium® M processor 760 2.0GHz, Intel®
Pentium® M processor 745 1.8GHz, Intel® Celeron® M processor 370
1.5GHz, Intel® Celeron® M processor 320 1.3GHz
provides ULV Intel® Celeron® M processor 600MHz/512K
 Front Side Bus
3308520 supports 400/533MHz FSB
supports 400MHz FSB
 BIOS
Award PnP Flash BIOS
 Chipset System
Intel® 852GME GMCH/ICH4
 I/O Chipset
Winbond W83627HG-AW
 System Memory
One 200-pin SO-DIMM socket up to 1GB DDR SDRAM
 Storage
One Type I/II CF socket
 Watchdog Timer
Software programmable time-out intervals from 1~255 sec.
 Hardware Monitor
Monitoring temperatures, voltages, and cooling fan status
 Expansion
One Type III mini PCI slot, one standard PCI slot, PC/104 Bus
 I/O Interface
 MIO
1 x IDE
1 x FDD
1 x Parallel
1 x RS-232/422/485
3 x RS-232
6 x USB2.0
1 x 6-pin header for KB/MS
 DIO
8-bit digital input/output port

4
 Display
 Chipset
Intel® 82852GME
 LVDS
24-bit single channel/48-bit dual channel
 TV-Out
Provides PAL or NTSC TV systems
 Capture
SAA7134HL video broadcast decoder
 Audio
 Chipset
ALC203
 Audio Interface (w/header)
MIC In, Line In, Line Out
 Ethernet
 Chipset
Intel® 82562ET 10/100 Mbps LAN
 Ethernet Interface
Internal 5x2 header
 Mechanical & Environmental
 Operating Temperature
0~60 degrees
 Operating Humidity
0~95%, non-condensing
 Board Size (LxW)
170 x 170 mm

5
1.3 Board Dimensions

7
Chapter 2
Unpacking
2.1 Opening the Delivery Package
The 3308520 is packed with an anti-static bag. The board
contains sensitive electrical components that are easily damaged by
static (electricity). Do not remove the anti-static wrapping until proper
grounding have been taken. Safety instruction has been described the
anti-static precautions and procedures in the previous.
2.2 Inspection
After unpacking the Panel PC, places it on a raised surface and
carefully inspect the board for any damage that might have occurred
during shipment. Grounding the board and exercise extremely careful
to prevent any damages to the board from static.
Integrated circuits will sometimes come out from socket during
shipment. Examine all integrated circuits, particularly the BIOS,
processor, memory modules, ROM-Disk, and keyboard controller chip
to ensure that they are firmly seated. The 3308520 delivery
package contains the following items:
 3308520 or Board x 1
 System board driver CD x 1
 Cables Package x 1
 Jumper Bag x 1
 User’s Manual

8
Cables Package
NO. Description Qty.
1 LAN 10-pin to RJ-45 cable 1
2 ATX power cable 20-pin to 4-pin(12V+5V) and 5-pin(5V only) 1
3 COM 40-pin to DB9*4 1
4 1-to-2 USB Y-cable w/bracket 1
5 Floppy controller cable 34-pin 1
6 UDMA5 40-pin IDE cable 1
7 Printer cable DB26-25pin 1
8 VGA cable DB10-15pin 1
9 Speaker/MIC port w/8-pin header 1
10 PS/2 Keyboard/Mouse 1-to-2 6-pin Mini DIN cable 1
It is recommended that you keep all the parts of the delivery package
intact and store them in a safe/dry place for any unforeseen event
requiring the return shipment of the product. In case you discover any
missing and/or damaged items from the list of items, please contact
your dealer immediately.

9
Chapter 3
Hardware Installation
This chapter illustrates how to install the hardware using the
3308520/. This chapter also contains information related to
jumper settings of switch, and watchdog timer selection.
3.1 Before Installation
After checking your package contents, you are now ready to install your
hardware. The following are important reminders and steps to take
before you begin with your installation process.
1. Make sure that all jumper settings match their default settings
and CMOS setup correctly. Refer to the sections on this chapter
for the default settings of each jumper. (sets JP1 short 1-2)
2. Go through the connections of all external devices and make
sure that they are installed properly and configured correctly
within the CMOS setup. Refer to the sections on this chapter
for the detailed information on the connectors.
3. Keep the manual and diskette in good condition for future
reference use.

10
3.2 Board Layout
Top Side
Solder Side

11
3.3 Jumper List
Jumper Default Setting Setting Page
JP1 Clear CMOS: Normal Operation Short 1-2 20
JP2 Panel Voltage Select: +3.3V Short 1-2 13
JP4 COM4 Use RS-232 or RS-422/485 Select:
RS-232 Open 18
CN4 Short
CN21 Short
CN22 Open
CN23
System & Memory Frequency Select: 400MHz
FSB
Short
12
NOTE: CN4/CN21/CN22/CN23 are for 3308520 only.
3.4 Connector List
Connector Definition Page
CN1 S-Video Out Connector 30
CN2 TV-Out Connector 30
CN3 Inverter Power In Connector 13
CN6 Capture In Connector 29
CN8(1-2) HDD LED 22
CN8(2-4-6-8) Speaker Connector 22
CN8(5-7) ATX Power Button 22
CN8(9-11) Reset Button 22
CN8(10-12) Power LED 22
CN9/CN10 PC/104 64-pin/40-pin Connector 30
CN11 6-pin AT Power In Connector (P8) 20
CN12 2-pin ATX Power Switch 20
CN13 5-pin ATX Power In Connector 20
CN14 Internal CRT Connector (2x5 header) 13
CN15 RS-422/485 Connector (2x3 header) 18
CN16 Internal LAN Connector (2x5 header) 19
CN17 Internal KB/MS Connector 22
CN18 GPIO Connector 26
CN19 COM 1~COM 4 Connector (2x20 header) 18
CN20 CompactFlash Connector 24
DDR1 DDR Socket 12
FDC1 FDD Connector 16
FN1/FN2 Fan Power Connector 30

12
Connector Definition Page
IDE1 IDE Connector 15
J1 Line In Connector 24
JP3 MIC In/Line Out Connector 24
LPT1 Parallel Port 17
PANEL1/PANEL2 LVDS Panel Connector 13
PCI1 Standard PCI Slot 25
PCI2 Type III Mini PCI Connector 25
US1/US2/US3 Internal USB2.0 Port 20
PW1 4-pin Power In Connector 20
3.5 Configuring the CPU
The 3308520 provides Intel® Pentium® M processor 760 2.0GHz,
Pentium® M processor 745 1.8GHz, Celeron® M processor 370
1.5GHz, and Celeron® M processor 1.3GHz socket. The
embedded with ULV Intel® Celeron® M processor 600MHz/512K. If
you want to use 533MHz FSB processor, please set CN4, CN21,
CN22, CN23 as below table.
 CN4/CN21/CN22/CN23: System & Memory Frequency Select
Options Settings
System Memory CN4 CN21 CN22 CN23
400MHz FSB (default) Short Short Open Short
533MHz FSB Open Open Open Short
2
1
3.6 System Memory
The 3308520/ provides one DDR socket at locations DDR1.
It supports:
 266/333MHz un-buffered, non-registered DDR1 DIMMs.
 Serial Presence Detect (SPD) memory only.
 Non-ECC memory
 Up to 1GB of memory.

13
3.7 VGA Controller
The 3308520/ provides two connection methods of a VGA
device. CN14 offers an internal 10-pin CRT connector and
PANEL1/PANEL2 are the LVDS interface connectors onboard
reserved for flat panel installation. Please see the following chart for
more detail:
3308520
VGA Chipset 852GME
TV-Out Function Yes
Capture Function Yes
LVDS Interface 24-bit/48-bit
 CN14: Internal CRT Connector
PIN Description PIN Description
1 Red 6 GND
2 GND 7 HSYNC
3 Green 8 SDA
4 GND 9 VSYNC
5 Blue 10 SDC
1
910
2
 PANEL1/PANEL2: LVDS Interface Connector
PIN Description PIN Description
1 VLCD 2 VLCD
3 GND 4 GND
5 A0-/A4- 6 A0+/A4+
7 A1-/A5- 8 A1+/A5+
9 A2-/A6- 10 A2+/A6+
11 CLK1-/CLK2- 12 CLK1+/CLK2+
13 A3-/A7- 14 A3+/A7+
1 2
13 14
CAUTION: Please check LVDS panel pin assign specification from your
LVDS panel manufacturer. Failure to do so could damage
the board and any attached devices.
NOTE: LVDS cable should be produced very carefully. A0- & A0+ have to
be fabricated in twister pair (A1- & A1+, A2- & A2+ and so on)
otherwise the signal won’t be stable.
NOTE: If use PANEL1 only, it just supports 24-bit single channel LVDS
panel; If you want to use 48-bit dual channel LVDS panel, please
use PANEL1 and PANEL2 combined.

14
The 3308520/ has an onboard jumper voltage select for flat
panel. Jumper JP2 offers two voltage settings for the user.
 JP2: Panel Voltage Select
Options Settings
+3.3V (default) Short 1-2
+5V Short 2-3
1
3
 CN3: Inverter Power In Connector
PIN Description
1 +12V
2 +12V
3 VCC5
4 BK_EN
5 LCD_EN
6 GND
1
6
