Global American Inc. 3308040A User manual

User’s Manual
5_1/4" Embedded Controller
3308040
Version 1.0,
August 2006

Copyrights
This manual is copyrighted and all rights are reserved. It does not allow any non authorization in
copied, photocopied, translated or reproduced to any electronic or machine readable form in
whole or in part without prior written consent from the manufacturer.
In general, the manufacturer will not be liable for any direct, indirect, special, incidental or
consequential damages arising from the use of inability to use the product or documentation, even
if advised of the possibility of such damages. The manufacturer keeps the rights in the subject to
change the contents of this manual without prior notices in order to improve the function design,
performance, quality and reliability. The author assumes no responsibility for any errors or
omissions, which may appear in this manual, nor does it make a commitment to update the
information contained herein.
Trademarks
Intel is a registered trademark of Intel Corporation.
Award is a registered trademark of Award Software, Inc.
All other trademarks, products and or product's name mentioned herein are mentioned for
identification purposes only, and may be trademarks and/or registered trademarks of their
respective companies or owners.

3308040 Motherboard
Table of Contents
1INTRODUCTION................................................................................................... 13
1.1 3308040 OVERVIEW................................................................................................ 14
1.1.1 3308040 Models .............................................................................................. 14
1.1.2 3308040 Applications...................................................................................... 14
1.1.3 3308040 Benefits ............................................................................................. 15
1.1.4 3308040 Features............................................................................................ 15
1.2 3308040 OVERVIEW................................................................................................ 16
1.2.1 3308040 Connectors........................................................................................ 17
1.2.2 Technical Specifications................................................................................... 18
2DETAILED SPECIFICATIONS ........................................................................... 21
2.1 OVERVIEW ............................................................................................................... 22
2.2 BOARD DIMENSIONS................................................................................................ 22
2.2.1 CPU Support.................................................................................................... 23
2.2.2 Supported Pentium® M CPUs......................................................................... 23
2.2.3 Supported Celeron® M CPUs ......................................................................... 24
2.3 ONBOARD CHIPSETS ................................................................................................ 25
2.3.1 Northbridge and Southbridge Chipsets ........................................................... 25
2.3.2 Intel®852GM Northbridge Chipset................................................................. 25
2.3.3 Intel®ICH4 Southbridge Chipset .................................................................... 26
2.4 DATA FLOW.............................................................................................................. 26
2.5 GRAPHICS SUPPORT ................................................................................................. 28
2.6 MEMORY SUPPORT................................................................................................... 29
2.7 PCI BUS INTERFACE SUPPORT ................................................................................. 29
2.8 GBE ETHERNET ....................................................................................................... 29
2.9 DRIVE INTERFACES .................................................................................................. 30
2.9.1 SATA Drives ..................................................................................................... 30
2.9.2 IDE HDD Interfaces........................................................................................ 30
2.9.3 Floppy Disk Drive (FDD)................................................................................ 30
2.9.4 CompactFlash Support .................................................................................... 31
2.11 REAL TIME CLOCK................................................................................................. 31
3

2.12 SYSTEM MONITORING............................................................................................ 31
2.13 INFRARED DATA ASSOCIATION (IRDA) INTERFACE................................................ 31
2.14 USB INTERFACES................................................................................................... 32
2.15 BIOS ..................................................................................................................... 32
2.16 OPERATING TEMPERATURE AND TEMPERATURE CONTROL..................................... 32
2.17 AUDIO CODEC........................................................................................................ 32
2.18 POWER CONSUMPTION........................................................................................... 34
2.19 PACKAGED CONTENTS AND OPTIONALACCESSORY ITEMS..................................... 34
2.19.1 Package Contents........................................................................................... 34
2.19.2 Optional Accessory Items............................................................................... 35
3CONNECTORS AND JUMPERS......................................................................... 37
3.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 38
3.1.1 3308040 Layout............................................................................................... 38
3.1.2 Peripheral Interface Connectors ..................................................................... 39
3.1.3 Rear Panel Connectors.................................................................................... 41
3.1.4 Onboard Jumpers............................................................................................. 41
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 41
3.2.1 Power Connector............................................................................................. 42
3.2.2 ATX PS_ON Connector.................................................................................... 43
3.2.3 Audio Connector .............................................................................................. 44
3.2.4 CompactFlash Connector................................................................................ 45
3.2.5 Digital Input/Output (DIO) Connector............................................................ 46
3.2.6 Digital Visual Interface (DVI) Connector........................................................ 48
3.2.7 Fan Connector................................................................................................. 49
3.2.8 Floppy Disk Connector.................................................................................... 50
3.2.9 Front Panel Connector .................................................................................... 52
3.2.10 IDE Connector (Primary).............................................................................. 53
3.2.11 IDE Connector (Secondary)........................................................................... 55
3.2.12 Inverter Power Connector ............................................................................. 56
3.2.13 IR Interface Connector .................................................................................. 57
3.2.14 Keyboard/Mouse Connector.......................................................................... 59
3.2.15 LCD LVDS Connector ................................................................................... 60
3.2.16 Parallel Port Connector ................................................................................ 62
3.2.17 RS-232 Serial Port Connectors...................................................................... 63
3.2.18 RS-232/422/485 Serial Port Connector......................................................... 64
4Global American Inc.

3308040 Motherboard
3.2.19 SATA Drive Connectors ................................................................................. 66
3.2.20 Internal USB Connectors............................................................................... 67
3.2.21 VGA Connector (Internal) ............................................................................. 68
3.3 EXTERNAL (REAR PANEL) CONNECTORS ................................................................. 69
3.3.1 LAN Connectors............................................................................................... 69
3.4 ONBOARD JUMPERS ................................................................................................. 71
3.4.1 Clear CMOS Jumper........................................................................................ 72
3.4.2 CF Card Setup ................................................................................................. 73
3.4.3 LCD Voltage Setup Jumper.............................................................................. 75
3.4.4 COM4 Setup Jumper (RS-232/422/485).......................................................... 76
4INSTALLATION AND CONFIGURATION ....................................................... 79
4.1 ANTI-STATIC PRECAUTIONS...................................................................................... 80
4.2 INSTALLATION CONSIDERATIONS ............................................................................. 80
4.2.1 Installation Notices.......................................................................................... 80
4.3 UNPACKING.............................................................................................................. 81
4.3.1 Unpacking Precautions.................................................................................... 81
4.3.2 Checklist........................................................................................................... 82
4.4 3308040 MOTHERBOARD INSTALLATION................................................................. 82
4.4.1 CPU Installation.............................................................................................. 84
4.4.2 Cooling Kit (CF-479B-RS ) Installation.......................................................... 86
4.4.3 DIMM Module Installation.............................................................................. 88
4.4.3.1 Purchasing the Memory Module............................................................... 88
4.4.3.2 DIMM Module Installation....................................................................... 88
4.4.4 Peripheral Device Connection......................................................................... 89
4.4.4.1 IDE Disk Drive Connector (IDE1) ........................................................... 90
4.5 CHASSIS INSTALLATION ........................................................................................... 90
4.6 REAR PANEL CONNECTORS ...................................................................................... 91
4.6.1 Ethernet Connection ........................................................................................ 91
A WATCHDOG TIMER.............................................................................................93
B ADDRESS MAPPING..............................................................................................97
C EXTERNAL AC’97 AUDIO CODEC....................................................................101
D RAID SETUP............................................................................................................107
5
5 Global American Inc.

3308040
THIS PAGE IS INTENTIONALLY LEFT BLANK
6
Global American Inc.

List of Figures
Figure 1-1: 3308040 Overview ...................................................................................16
Figure 1-2: 3308040 Solder Side Overview ..............................................................16
Figure 2-1: 3308040 Dimension (mm).......................................................................22
Figure 2-2: Data Flow Block Diagram........................................................................27
Figure 3-1: Connector and Jumper Locations.........................................................38
Figure 3-2: Connector and Jumper Locations (Solder Side)..................................39
Figure 3-3: Power Connector Location.....................................................................42
Figure 3-4: ATX PS_ON Connector Location ...........................................................43
Figure 3-5: Audio Connector Location......................................................................44
Figure 3-6: CompactFlash Connector Location.......................................................45
Figure 3-7: DIO Connector Connector Locations....................................................47
Figure 3-8: DVI Connector Location..........................................................................48
Figure 3-9: Fan Connector Location .........................................................................50
Figure 3-10: FDD Connector Location ......................................................................51
Figure 3-11: Front Panel Connector Locations........................................................52
Figure 3-12: Primary IDE Device Connector Locations...........................................54
Figure 3-13: Secondary IDE Device Connector Locations......................................55
Figure 3-14: Inverter Connector Locations ..............................................................57
Figure 3-15: IR Connector Pinout Locations............................................................58
Figure 3-16: Keyboard/Mouse Connector Location.................................................59
Figure 3-17: LVDS Connector Locations..................................................................61
Figure 3-18: Parallel Port Connector Location.........................................................62
Figure 3-19: RS-232 Serial Port Connector Locations ............................................63
Figure 3-20: RS-232/422/485 Serial Port Connector Location ................................65
Figure 3-21: SATA Drive Connector Locations........................................................66
Figure 3-22: USB Connector Pinout Locations........................................................67
Figure 3-23: VGA Connector Location......................................................................68
Figure 3-24: 3308040 Rear Panel...............................................................................69
Figure 3-25: RJ-45 Ethernet Connector ....................................................................70
7 Global American Inc.

8
3308040 Motherboard
Figure 3-26: CLR_CMOS Pinout Locations ..............................................................73
Figure 3-27: JP5 Pinout Locations............................................................................74
Figure 3-28: JP3 Pinout Locations............................................................................76
Figure 3-29: COM4 Setup Jumper Pinout Locations...............................................77
Figure 4-1: Make sure the CPU socket retention screw is unlocked.....................84
Figure 4-2: Lock the CPU Socket Retention Screw .................................................85
Figure 4-3: GAI 2107703 Cooling Kit .........................................................................86
Figure 4-4: Cooling Kit Support Bracket...................................................................87
Figure 4-5: Connect the cooling fan cable ...............................................................87
Figure 4-6: DIMM Module Installation........................................................................89

List of Tables
Table 1-1: 3308040 Model Specifications.................................................................14
Table 1-2: Technical Specifications ..........................................................................18
Table 2-1: Supported Pentium® M CPUs..................................................................23
Table 2-2: Supported Celeron® M CPUs...................................................................24
Table 2-3: Power Consumption .................................................................................34
Table 3-1: Peripheral Interface Connectors..............................................................39
Table 3-2: Rear Panel Connectors.............................................................................41
Table 3-3: Onboard Jumpers .....................................................................................41
Table 3-4: Power Connector Pinouts ........................................................................43
Table 3-5: ATX PS_ON Connector Pinouts...............................................................44
Table 3-6: Audio Connector Pinouts.........................................................................45
Table 3-7: CompactFlash Connector Pinouts ..........................................................46
Table 3-8: DIO Connector Connector Pinouts..........................................................47
Table 3-9: DVI Connector Connector Pinouts..........................................................48
Table 3-10: Fan Connector Pinouts...........................................................................50
Table 3-11: FDD Connector Pinouts..........................................................................51
Table 3-12: Front Panel Connector Pinouts .............................................................53
Table 3-13: Primary IDE Connector Pinouts.............................................................54
Table 3-14: Secondary IDE Connector Pinouts........................................................55
Table 3-15: Inverter Power Connector Pinouts........................................................57
Table 3-16: IR Connector Pinouts..............................................................................58
Table 3-17: Keyboard/Mouse Connector Pinouts....................................................60
Table 3-18: LCD LVDS Connector Pinouts...............................................................61
Table 3-19: Parallel Port Connector Pinouts............................................................63
Table 3-20: RS-232 Serial Port Connector Pinouts..................................................64
Table 3-21: RS-232/RS-422/RS-485 Serial Port Connector Pinouts.......................65
Table 3-22: SATA Drive Connector Pinouts .............................................................66
Table 3-23: USB Port Connector Pinouts .................................................................68
Table 3-24: VGA Connector Pinouts .........................................................................69
9 Global American Inc.

3308040 Motherboard
Table 3-25: LAN Pinouts.............................................................................................70
Table 3-26: RJ-45 Ethernet Connector LEDs............................................................70
Table 3-27: Jumpers....................................................................................................71
Table 3-28: Clear CMOS Jumper Settings ................................................................72
Table 3-29: CF Card Setup Jumper Settings............................................................74
Table 3-30: JP3 Jumper Settings...............................................................................75
Table 3-31: COM4 Setup Jumper Settings................................................................76
Table 4-1: GAI Provided Cables.................................................................................89
10

3308040 Motherboard
Glossary
AC ’97 Audio Codec 97
ACPI Advanced Configuration and
Power Interface
APM Advanced Power Management
ARMD ATAPI Removable Media Device
ASKIR Shift Keyed Infrared
ATA Advanced Technology
Attachments
BIOS Basic Input/Output System
CFII CompactFlash Type 2
CMOS Complementary Metal Oxide
Semiconductor
CPU Central Processing Unit
Codec Compressor/Decompressor
COM Serial Port
DAC Digital to Analog Converter
DDR Double Data Rate
DIMM Dual Inline Memory Module
DIO Digital Input/Output
DMA Direct Memory Access
EIDE Enhanced IDE
EIST Enhanced Intel SpeedStep
Technology
FDD Floppy Disk Drive
FDC Floppy Disk Connector
FFIO Flexible File Input/Output
FIFO First In/First Out
FSB Front Side Bus
IrDA Infrared Data Association
HDD Hard Disk Drive
IDE Integrated Data Electronics
I/O Input/Output
ICH4 I/O Controller Hub 4
L1 Cache Level 1 Cache
L2 Cache Level 2 Cache
LCD Liquid Crystal Display
LPT Parallel Port Connector
LVDS Low Voltage Differential Signaling
MAC Media Access Controller
OS Operating System
PCI Peripheral Connect Interface
PIO Programmed Input Output
PnP Plug and Play
POST Power On Self Test
RAM Random Access Memory
SATA Serial ATA
S.M.A.R.T Self Monitoring Analysis and
Reporting Technology
SPD Serial Presence Detect
S/PDI Sony/Philips Digital Interface
SDRAM Synchronous Dynamic Random
Access Memory
SIR Serial Infrared
UART Universal Asynchronous
Receiver-transmitter
USB Universal Serial Bus
VGA Video Graphics Adapter
11

12 Global American Inc.
THIS PAGE IS INTENTIONALLY LEFT BLANK

3308040 Motherboard
Chapter
1
1 Introduction
13

1.1 3308040 Overview
The 5.25” 3308040 socket 479 Pentium M and Celeron M single board computer
(SBC) is fully equipped with advanced multi-mode I/Os. The 3308040 is designed
for system manufacturers, integrators, and VARs that want performance, reliability, and
quality at a reasonable price.
1.1.1 3308040 Models
The 3308040 series has eight models:
 3308040A
 3308040B
 3308040C
 3308040D
 3308040E
 3308040F
The specifications for the four models are show in Table 1-1.
3308040 ABCD EF
Onboard CPU NO CM600Z CM1GZ NO CM600Z CM1GZ
CRT/LCD YES YES YES YES YES YES
Dual GbE YES YES YES YES YES YES
SATA YES YES YES YES YES YES
Audio YES YES YES YES YES YES
DVI Function NO NO NO YES YES YES
Table 1-1: 3308040 Model Specifications
CM600Z : Intel Celeron M 600MHz / zero cache CPU
CM1GZ : Intel Celeron M 1GMHz / zero cache CPU
1.1.2 3308040 Applications
The 3308040 is designed for applications in the following areas:
14 Global American Inc.
 3308040G
 3308040H

3308040 Motherboard
 Industrial PC applications
 Human Machine Interface (HMI) applications
 Marine, GPS and transportation applications
 Financial, retail and kiosk applications
1.1.3 3308040 Benefits
Some of the 3308040 benefits include:
 Low power, high performance
 Flexible dual display options
 Multiple storage option integration including
o 40 Pin IFM or 3.5”HDD (hard disk drive)
o 44 Pin IFM or 2.5”HDD (hard disk drive)
o Dual SATA ports with RAID 0 and RAID 1 support
o CFII (CompactFlash) support
o Floppy disk drive (FDD) support
 Mini PCI
 SATA RAID support
1.1.4 3308040 Features
Some of the 3308040 features are listed below:
 5.25” form factor
 RoHS compliant
 Socket 479 Intel® Pentium M/Celeron M processors supported
 Dual-independent display functionality
 Maximum front side bus (FSB) speed up to 400MHz supported
 Up to 2GB of 266MHz of DDR memory supported
 Two high performance gigabit Ethernet (GbE) controllers onboard
 Two SATA channels with transfer rates up to 150MB/s onboard
 Six USB 2.0 devices onboard
 Integrated audio
15

1.2 3308040 Overview
Figure 1-1: 3308040 Overview
Figure 1-2: 3308040 Solder Side Overview
16 Global American Inc.

3308040 Motherboard
1.2.1 3308040 Connectors
The 3308040 has the following connectors onboard:
 1 x Power connector
 1 x PS_ON power connector
 1 x Audio connector
 1 x CompactFlash (CF) connector (solder side)
 1 x Digital input/output connector
 1 x DVI connector
 1 x Fan connector
 1 x Floppy disk connector
 1 x Front panel connector
 2 x IDE Interface connectors (40-pin and 44-pin)
 1 x Inverter power connector
 1 x IR interface connector
 1 x Keyboard/mouse connector
 1 x LCD LVDS interface connector
 1 x PCI slot
 1 x Parallel port connector
 1 x RS-232/422/485 serial port connector
 3 x RS-232 serial port connectors
 2 x SATA connectors
 3 x USB connectors
 1 x VGA connector
 2 x 184-pin DIMM sockets
The 3308040 has the following connectors on the board rear panel:
 2 x Ethernet connectors
The 3308040 has the following onboard jumpers:
 Clear CMOS
 CF card setup
17

1.2.2 Technical Specifications
3308040 technical specifications are listed in Table 1-2. Detailed descriptions of
each specification can be found in Chapter 2 Detailed Specifications.
Specification 3308040
Form Factor 5.25” form factor
CPU Intel socket 479 Pentium M (up to 2.1 GHz)
Intel socket 479 Celeron M (up to 1.7 GHz)
Northbridge Chipset Intel 852GM
Southbridge Chipset ICH4
Display Intel Extreme Graphics 2 (integrated into Northbridge)
Memory Supports two 1GB DDR266 184-pin DIMM modules
BIOS AMI BIOS Label
SSD CompactFlash (CF)
Super I/O W83627HG
Audio Realtek ALC655 AC'97 Codec
LAN Dual RTL8110SC
COM 3 x RS-232C
1 x RS-232/422/485
USB2.0 3 x USB 1.1 or 2.0 onboard connectors support two devices
each
IDE 1 x 40-pin IDE connects to two Ultra ATA33/66/100 devices
1 x 44-pin IDE connects to two Ultra ATA33/66/100 devices
Parallel Port 1 x LPT port connector
SATA 2 x SATA connectors with transfer rates up to 150MB/sec
18 Global American Inc.

3308040 Motherboard
KB/MS PS/2 connector
WDT Software programmable 1-255 sec. by super I/O
IrDA SIR / ASKIR
Digital I/O 4 input / 4 output by super I/O
Fan connector 1x3 pin for CPU Fan
Expansion 1x mini PCI slot
1 x PCI slot
Power +5V/+12V, AT/ATX support
Temperature 0ºC - 60ºC
Humidity 5%~95% non-condensing
Dimensions 146.05mm x 203.2mm
Weight (GW/NW) 1000g/400g
Table 1-2: Technical Specifications
19

THIS PAGE IS INTENTIONALLY LEFT BLANK
20 Global American Inc.
