Global American Inc. 3308490 User manual

3308490 User’s Manual
Version 1.0
Half-Size PCISA SBC with Intel Atom N270 Processor

Copyrights
This document is copyrighted and all rights are reserved. It does not allow any non
authorization in copied, photocopied, translated or reproduced to any electronic or
machine readable form in whole or in part without prior written consent from the
manufacturer.
In general, the manufacturer will not be liable for any direct, indirect, special, incidental
or consequential damages arising from the use of inability to use the product or
documentation, even if advised of the possibility of such damages. The manufacturer
keeps the rights in the subject to change the contents of this document without prior
notices in order to improve the function design, performance, quality and reliability. The
author assumes no responsibility for any errors or omissions, which may appear in this
document, nor does it make a commitment to update the information contained herein.
Trademarks
Intel is a registered trademark of Intel Corporation.
Award is a registered trademark of Award Software, Inc.
All other trademarks, products and or product's name mentioned herein are mentioned
for identification purposes only, and may be trademarks and/or registered trademarks of
their respective companies or owners.

Packing List
The items listed below should all be included in the 3308490 package.
 1 x 3308490 PCISA Motherboard
 1 x LPT and RS-232 cable
 2 x SATA cable
 1 x USB cable
 1 x Mini jumper pack
 1 x Utility CD
 1 x Manual
Images of the above items are shown in Chapter 3.

Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION .......................................................................................................... 2
1.2 OVERVIEW PHOTO...................................................................................................... 3
1.3 PERIPHERAL CONNECTORS AND JUMPERS .................................................................. 4
1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 5
2 DETAILED SPECIFICATIONS.................................................................................. 8
2.1 DIMENSIONS .............................................................................................................. 9
2.1.1 Board Dimensions.............................................................................................. 9
2.1.2 External Interface Panel Dimensions.............................................................. 10
2.2 DATA FLOW...............................................................................................................11
2.3 INTEL® ATOM™ PROCESSOR .................................................................................. 12
2.3.1 Overview.......................................................................................................... 12
2.3.2 Features ........................................................................................................... 12
2.3.3 Front Side Bus (FSB)....................................................................................... 13
2.4 INTEL® 945GSE NORTHBRIDGE CHIP..................................................................... 13
2.4.1 DDR2 Controller.............................................................................................. 13
2.4.2 Graphics........................................................................................................... 14
2.4.2.1 Analog CRT (VGA) .................................................................................. 14
2.4.2.2 LVDS ........................................................................................................ 14
2.4.2.3 TV Out ...................................................................................................... 14
2.4.2.4 SDVO and DVI......................................................................................... 15
2.5 INTEL® ICH7M SOUTHBRIDGE CHIPSET................................................................. 15
2.5.1 HD Audio Controller........................................................................................ 17
2.5.2 IDE Interface ................................................................................................... 17
2.5.2.1 IDE Connector.......................................................................................... 18
2.5.2.2 CompactFlash® Slot................................................................................. 18
2.5.3 Real Time Clock............................................................................................... 18
2.5.4 SATA Controller............................................................................................... 19
2.5.5 USB Controller ................................................................................................ 19
2.5.6 iTE IT8718F Super I/O chipset........................................................................ 19

2.5.6.1 LPC Interface............................................................................................ 20
2.5.6.2 16C550 UARTs......................................................................................... 20
2.5.6.3 Digital Input/Output.................................................................................. 21
2.5.6.4 Enhanced Hardware Monitor.................................................................... 21
2.5.6.5 Fan Speed Controller ................................................................................ 21
2.5.6.6 Keyboard/Mouse Controller ..................................................................... 21
2.5.6.7 Parallel Port............................................................................................... 21
2.5.7 PCI Bus............................................................................................................ 21
2.5.7.1 PCI Edge Connector ................................................................................. 22
2.5.7.2 ISA Edge Connector ................................................................................. 22
2.5.8 PCIe Bus .......................................................................................................... 22
2.5.8.1 Gigabit Ethernet Connector ...................................................................... 22
2.5.9 SPI Bus Components........................................................................................ 23
2.5.9.1 SPI BIOS................................................................................................... 23
2.6 ENVIRONMENTALAND POWER SPECIFICATIONS ....................................................... 24
2.6.1 System Monitoring ........................................................................................... 24
2.6.2 Operating Temperature and Temperature Control........................................... 24
2.6.3 Power Consumption......................................................................................... 25
3 UNPACKING............................................................................................................... 26
3.1 ANTI-STATIC PRECAUTIONS...................................................................................... 27
3.2 UNPACKING.............................................................................................................. 27
3.2.1 Unpacking Precautions.................................................................................... 27
3.3 UNPACKING CHECKLIST........................................................................................... 28
3.3.1 Package Contents............................................................................................. 28
3.3.2 Optional Items.................................................................................................. 29
4 CONNECTORS ........................................................................................................... 31
4.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 32
4.1.1 Layout .............................................................................................................. 32
4.1.2 Internal Peripheral Interface Connectors ....................................................... 33
4.1.3 External Interface Panel Connectors............................................................... 34
4.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 35
4.2.1 ATX Power Control Connector........................................................................ 35
4.2.2 Audio Connector .............................................................................................. 36

4.2.3 Backlight Inverter Connector .......................................................................... 37
4.2.4 Battery Connector............................................................................................ 38
4.2.5 BIOS Programming Connector........................................................................ 38
4.2.6 CompactFlash® Socket.................................................................................... 39
4.2.7 Digital I/O Connector...................................................................................... 41
4.2.8 Fan Connector................................................................................................. 42
4.2.9 Floppy Disk Connector.................................................................................... 43
4.2.10 Front Panel Connector .................................................................................. 44
4.2.11 IDE Connector ............................................................................................... 45
4.2.12 Infrared Interface Connector......................................................................... 47
4.2.13 Keyboard/Mouse Connector .......................................................................... 48
4.2.14 LVDS LCD Connector ................................................................................... 48
4.2.15 SATA Drive Connectors ................................................................................. 50
4.2.16 Parallel Port Connector ................................................................................ 51
4.2.17 Serial Port Connector (RS-232)..................................................................... 52
4.2.18 Serial Port Connector (RS-232/422/485) ...................................................... 53
4.2.19 SDVO Connector............................................................................................ 54
4.2.20 TV Out Connector.......................................................................................... 55
4.2.21 USB Connectors............................................................................................. 56
4.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 57
4.3.1 LAN Connectors............................................................................................... 58
4.3.2 USB Connectors............................................................................................... 59
4.3.3 VGA Connector................................................................................................ 59
5 INSTALLATION ......................................................................................................... 61
5.1 ANTI-STATIC PRECAUTIONS...................................................................................... 62
5.2 INSTALLATION CONSIDERATIONS ............................................................................. 63
5.2.1 Installation Notices.......................................................................................... 63
5.2.2 Installation Checklist....................................................................................... 64
5.3 UNPACKING.............................................................................................................. 64
5.4 CF CARD INSTALLATION.......................................................................................... 65
5.5 ATX POWER CONTROL CONNECTOR........................................................................ 66
5.6 JUMPER SETTINGS.................................................................................................... 68
5.6.1 AT/ATX Power Selection.................................................................................. 69
5.6.2 Clear CMOS Jumper........................................................................................ 70

5.6.3 CF Card Setup ................................................................................................. 71
5.6.4 COM2 RS-232/422/485 Selection Jumper....................................................... 71
5.6.5 LCD Panel Type Selection ............................................................................... 72
5.6.6 LVDS Voltage Selection.................................................................................... 72
5.7 CHASSIS INSTALLATION ........................................................................................... 73
5.7.1 Airflow.............................................................................................................. 73
5.7.2 Motherboard Installation................................................................................. 74
5.8 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 74
5.8.1 5.1 Channel Audio Kit Installation.................................................................. 74
5.8.2 7.1 Channel Audio Kit Installation.................................................................. 76
5.8.3 ATA Flat Cable Connection ............................................................................. 77
5.8.4 Dual RS-232 Cable with Slot Bracket.............................................................. 78
5.8.5 Floppy Drive Cable Connection...................................................................... 79
5.8.6 Parallel Port Cable without Bracket ............................................................... 80
5.8.7 SATA Drive Connection ................................................................................... 81
5.8.8 USB Cable (Dual Port) with Slot Bracket ....................................................... 83
5.9 EXTERNAL PERIPHERAL INTERFACE CONNECTION................................................... 85
5.9.1 LAN Connection............................................................................................... 85
5.9.2 USB Device Connection (Single Connector)................................................... 86
5.9.3 VGA Monitor Connection ................................................................................ 87

List of Figures
Figure 1-1: 3308490 ...............................................................................................................2
Figure 1-2: 3308490 Overview (Front)..................................................................................3
Figure 1-3: 3308490 Overview (Rear)...................................................................................4
Figure 2-1: 3308490 Dimensions (mm)................................................................................9
Figure 2-2: External Interface Panel Dimensions (mm)............................................................10
Figure 2-3: Data Flow Block Diagram.........................................................................................11
Figure 2-4: CPU and Northbridge Connections.........................................................................12
Figure 2-5: Intel® ICH7M Southbridge Connections.................................................................16
Figure 2-6: Super I/O Connections .............................................................................................20
Figure 4-1: Connector and Jumper Locations [Front Side] .....................................................32
Figure 4-2: Connector and Jumper Locations [Solder Side] ...................................................33
Figure 4-3: ATX Power Supply Enable Connector Location....................................................35
Figure 4-4: Audio Connector Location (9-pin)...........................................................................36
Figure 4-5: LCD Backlight Connector Pinout Locations..........................................................37
Figure 4-6: Battery Connector Location.....................................................................................38
Figure 4-7: BIOS Programming Connector Pinouts..................................................................39
Figure 4-8: CF Card Socket Location .........................................................................................40
Figure 4-9: Digital I/O Connector Locations ..............................................................................41
Figure 4-10: CPU Fan Connector Location................................................................................42
Figure 4-11: Floppy Disk Connector Location...........................................................................43
Figure 4-12: Front Panel Connector Pinout Locations.............................................................45
Figure 4-13: IDE Device Connector Locations ..........................................................................46
Figure 4-14: Infrared Connector Pinout Locations ...................................................................47
Figure 4-15: Keyboard/Mouse Connector Location..................................................................48
Figure 4-16: LVDS LCD Connector Pinout Locations...............................................................49
Figure 4-17: SATA Drive Connector Locations.........................................................................50
Figure 4-18: Parallel Port Connector Location..........................................................................51
Figure 4-19: RS-232 Connector Pinout Locations.....................................................................52
Figure 4-20: RS-232/422/485 Connector Pinout Locations.......................................................53
Figure 4-21: SDVO Connector Pinout Locations.......................................................................54

Figure 4-22: TV Connector Pinout Locations ............................................................................56
Figure 4-23: USB Connector Pinout Locations.........................................................................57
Figure 4-24: 3308490 External Peripheral Interface Connector......................................58
Figure 4-25: LAN Connector........................................................................................................58
Figure 4-26: VGA Connector .......................................................................................................60
Figure 5-1: CF Card Installation..................................................................................................66
Figure 5-2: ATX Power Control Connector ................................................................................67
Figure 5-3: Jumper Location.......................................................................................................69
Figure 5-4: 5.1 Channel Audio Kit...............................................................................................75
Figure 5-5: 7.1 Channel Audio Kit...............................................................................................77
Figure 5-6: IDE Cable Connection...............................................................................................78
Figure 5-7: Dual RS-232 Cable Installation................................................................................79
Figure 5-8: FDD Cable Connection.............................................................................................80
Figure 5-9: LPT Cable Connection..............................................................................................81
Figure 5-10: SATA Drive Cable Connection...............................................................................82
Figure 5-11: SATA Power Drive Connection..............................................................................83
Figure 5-12: Dual USB Cable Connection..................................................................................84
Figure 5-13: Connect the LPT Device.........................................................................................85
Figure 5-14: LAN Connection......................................................................................................86
Figure 5-15: USB Device Connection.........................................................................................87
Figure 5-16: VGA Connector .......................................................................................................88
Figure 7-1: Start Up Screen ...................................................................................................... 143
Figure 7-2: Select Operating System....................................................................................... 143
Figure 7-3: Drivers..................................................................................................................... 144
Figure 7-4: Chipset Driver Welcome Screen........................................................................... 145
Figure 7-5: Chipset Driver License Agreement...................................................................... 145
Figure 7-6: Chipset Driver Read Me File ................................................................................. 146
Figure 7-7: Chipset Driver Setup Operations ......................................................................... 147
Figure 7-8: Chipset Driver Installation Finish Screen............................................................ 147
Figure 7-9: VGA Driver Read Me File....................................................................................... 148
Figure 7-10: VGA Driver Setup Files Extracted...................................................................... 149
Figure 7-11: VGA Driver Welcome Screen.............................................................................. 149
Figure 7-12: VGA Driver License Agreement.......................................................................... 150
Figure 7-13: VGA Driver Read Me File..................................................................................... 150
Figure 7-14: VGA Driver Setup Operations............................................................................. 151

Figure 7-15: VGA Driver Installation Finish Screen............................................................... 152
Figure 7-16: LAN Driver Welcome Screen .............................................................................. 153
Figure 7-17: LAN Driver Welcome Screen .............................................................................. 153
Figure 7-18: LAN Driver Installation ........................................................................................ 154
Figure 7-19: LAN Driver Installation Complete....................................................................... 154
Figure 7-20: AC'97 Audio.......................................................................................................... 155
Figure 7-21: AC’97 Audio Driver Options................................................................................ 156
Figure 7-22: AC’97 Driver Installation Welcome Screen........................................................ 156
Figure 7-23: AC’97 Driver Installation Verification................................................................. 157
Figure 7-24: AC’97 Driver Installation Complete.................................................................... 157
Figure 7-25: HD Audio............................................................................................................... 158
Figure 7-26: HD Audio Driver Options..................................................................................... 158
Figure 7-27: HD Audio Driver Installation Welcome Screen................................................. 159
Figure 7-28: HD Audio Driver Installation Complete.............................................................. 159
Figure 7-29: iSMM Directory..................................................................................................... 160
Figure 7-30: iSMM Installation File........................................................................................... 161
Figure 7-31: iSMM InstallShield Welcome Screen.................................................................. 161
Figure 7-32: iSMM License Agreement.................................................................................... 162
Figure 7-33: iSMM Customer Information............................................................................... 163
Figure 7-34: iSMM Setup Type ................................................................................................. 164
Figure 7-35: iSMM Installation Confirmation .......................................................................... 165
Figure 7-36: iSMM InstallShield Wizard Complete................................................................. 166
Figure 7-37: iSMM Restart Confirmation................................................................................. 166

List of Tables
Table 1-1: Technical Specifications..............................................................................................7
Table 2-1: Supported HDD Specifications..................................................................................18
Table 2-2: Power Consumption...................................................................................................25
Table 3-1: Packing List.................................................................................................................29
Table 3-2: Power Consumption...................................................................................................30
Table 4-1: Peripheral Interface Connectors...............................................................................34
Table 4-2: Rear Panel Connectors..............................................................................................34
Table 4-3: ATX Power Supply Enable Connector Pinouts .......................................................36
Table 4-4: Audio Connector Pinouts (9-pin) ..............................................................................37
Table 4-5: LCD Backlight Connector Pinouts............................................................................37
Table 4-6: Battery Connector Pinouts........................................................................................38
Table 4-7: BIOS Programming Connector .................................................................................39
Table 4-8: CF Card Socket Pinouts.............................................................................................41
Table 4-9: DIO Connector Pinouts..............................................................................................42
Table 4-10: CPU Fan Connector Pinouts ...................................................................................42
Table 4-11: Floppy Disk Connector Pinouts..............................................................................44
Table 4-12: Front Panel Connector Pinouts...............................................................................45
Table 4-13: IDE Connector Pinouts.............................................................................................47
Table 4-14: Infrared Connector Pinouts.....................................................................................47
Table 4-15: Keyboard/Mouse Connector Pinouts .....................................................................48
Table 4-16: LVDS LCD Port Connector Pinouts........................................................................50
Table 4-17: SATA Drive Connector Pinouts...............................................................................51
Table 4-18: Parallel Port Connector Pinouts .............................................................................52
Table 4-19: RS-232 Connector Pinouts ......................................................................................53
Table 4-20: RS-232/422/485 Connector Pinouts........................................................................53
Table 4-21: SDVO Connector Pinouts ........................................................................................55
Table 4-22: TV Port Connector Pinouts......................................................................................56
Table 4-23: USB Port Connector Pinouts...................................................................................57
Table 4-24: LAN Connector Pinouts...........................................................................................58
Table 4-25: LAN Connector LEDs...............................................................................................59

Table 4-26: USB Port Pinouts......................................................................................................59
Table 4-27: VGA Connector Pinouts...........................................................................................60
Table 5-1: Jumpers.......................................................................................................................68
Table 5-2: AT/ATX Power Selection Jumper Settings...............................................................70
Table 5-3: Clear CMOS Jumper Settings....................................................................................70
Table 5-4: CF Card Setup Jumper Settings ...............................................................................71
Table 5-5: COM2 RS-232/422/485 Selection Jumper Pinouts...................................................71
Table 5-6: LCD Panel Type Selection Jumper Settings............................................................72
Table 5-7: LVDS Voltage Selection Jumper Settings................................................................73
Table 5-8: GAI Provided Cables ....................................................................................................74

Page 1
Chapter
1
1 Introduction

Page 2
1.1 Introduction
Figure 1-1: 3308490
The 3308490 is a PCISA CPU card with an embedded 45 nm Intel® Atom™
processor. The embedded Intel® Atom™ N270 processor has a 1.60 GHz clock speed,
533 MHz FSB and 512 KB of L2 cache.
The 3308490 includes four graphics outputs. VGA on the rear panel provides basic
output capabilities for use with most monitors. Internally, an LVDS header provides a
connection to LCD displays for integrating the 3308490 into a system with built-in
monitor. The TV header provides output to a standard TV or HDTV through the optional
adapter cables, which provide a single cable connection on a card slot and a cable
splitting the signal into the component parts. Finally, an SDVO connector provides a direct
connection from the Northbridge SDVO port to an GAI SDVO graphics card.
512 MB of DDR2 memory is included with the 3308490 (a custom option with a
DDR2 SO-DIMM slot is available). Permanent storage is provided through dual SATA
ports, offering 300 MB/s transfer speeds, RAID 0 and RAID 1 support. Legacy IDE
connectivity is available through an IDE port, and through a CompactFlash® card located
on the solder side of the 3308490.
Other connectors on the 3308490 include six USB ports (two external, four internal),
an RS-232 port, an RS-232/422/485 port, LPT and digital I/O. An HD Audio connector
connects to an external audio kit, providing HD audio or AC’97 audio capabilities with the
appropriate audio kit.

Page 3
1.2 Overview Photo
The 3308490 has a wide variety of peripheral interface connectors. 7Figure 1-2 is a
labeled photo of the peripheral interface connectors on the 3308490.
Figure 1-2: 3308490 Overview (Front)

Page 4
Figure 1-3: 3308490 Overview (Rear)
1.3 Peripheral Connectors and Jumpers
The 3308490 has the following connectors on-board:
 1 x ATX power control connector
 1 x Audio kit connector
 1 x Backlight inverter connector
 1 x Battery connector
 1 x BIOS programming header
 1 x CompactFlash® slot
 1 x Digital I/O connector
 1 x Edge connector
 1 x Fan connector
 1 x Floppy disk connector
 1 x Front panel connector
 1 x IDE connector
 1 x Infrared connector
 1 x Keyboard / mouse connector
 1 x LVDS connector

Page 5
 1 x Parallel port connector
 1 x RS-232 connector
 1 x RS-232/422/485 connector
 2 x SATA connectors
 1 x SDVO connector
 1 x TV connector
 2 x USB connectors
The 3308490 has the following external peripheral interface connectors on the board
rear panel.
 2 x Network ports
 2 x USB ports
 1 x VGA port
The 3308490 has the following on-board jumpers:
 ATX power control
 Clear CMOS
 COM2 port mode
 CompactFlash® card setup
 LCD panel type selector
 LCD voltage selector
1.4 Technical Specifications
3308490 technical specifications are listed in 7Table 1-1. See Chapter 2 for details.
Specification 3308490
Form Factor PCISA
System CPU 45 nm 1.60 GHz Intel® Atom™ N270
Front Side Bus (FSB) 533 MHz
System Chipset Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7M

Page 6
Specification 3308490
Memory 512 MB of DDR2 RAM integrated (a DDR2 SO-DIMM slot is a
custom option)
CompactFlash® One CompactFlash® socket
Super I/O iTE IT8718F
Display
VGA
LVDS
HDTV
SDVO
BIOS AMI BIOS label
Audio Through HD Audio or AC’97 audio kit
LAN Two Realtek RTL8111CP PCIe GbE controllers
COM One RS-232 serial port
One RS-232/422/485 serial port
USB2.0 Six USB 2.0 devices supported (four internal, two external)
Hard Drives One 40-pin IDE connector
SATA Two 3.0 Gb/s SATA drives supported
Keyboard/mouse Internal PS/2 keyboard/mouse connector
Digital I/O One 8-bit digital I/O connector
Watchdog Timer Software programmable 1-255 sec.
Infrared
One infrared connector supports
Serial Infrared (SIR)
Amplitude Shift Keyed IR (ASKIR)
Power Supply ATX and AT power supported
Power Consumption
5 V @ 2.89 A
12 V @ 0.22 A
(with 512 MB DDR2 memory)
Temperature 0ºC – 60ºC (32ºF - 140ºF)
Humidity (operating) 5%~95% non-condensing

Page 7
Specification 3308490
Dimensions (LxH) 185 mm x 127.6 mm
Weight (GW/NW) 1000 g / 252 g
Table 1-1: Technical Specifications
