Global Fire Equipment GFE-TCP-WEB Instruction sheet

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
REMOTE ACCESS TCP/IP INTERFACE
Version 11/2017
GFE-TCP-WEB
CONFIGURATION MANUAL

General Description
Technical Specifications
GFE--TCP-WEB is a new interface forTCP/IP communication, which will bring new functionalities to JUNIOR V4, JUNO NET
panels. It uses our data-loop protocol and an external web-server to send and receive information from panel. In
this way, supervision over individual systems via web browser can be achievable easily.
Network and web-server configurations are defined through available USB connector. The following URL,
contains the webpage where remote access to panels can be configured and activated, USB
drivers and configuration software are also available for download.
and
ORION PLUS
http://www.createc.pt/v2/gfe
Characteristics
SUPPLY VOLTAGE
SUPPLY CURRENT
CONFIGURATION
COMMUNICATION CONNECTOR
INPUT
CONFIGURATION OPERATING SYSTEM
OPERATING TEMPERATURE
DIMENSIONS
WEIGHT
Description
20 to 30 V DC
28 mA
USB mini
RJ45
Restart switch
Windows XP/7/8/10, MacOS, Linux, Android, IOS
-10ºC to 50ºC
90 (L) x 40 (W) mm
24 g
Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
Ethernet
Configuration
Restart
Switch
WI-FI
(future uses)
CONFIGURATION: PANELS
Introduction
Connection Diagram
Interface power and communication is achieved via a 5way flat cable that's connected to a 5 pin molex connector available at
panels and interface.
Panel communication uses our data-loop protocol which is available differently according to the panel.
JUNIOR V4ORION PLUSJUNO NET

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
JUNIORV4 settings
JUNO NET settings
ORION-PLUS settings
Dataloop is available as default in JUNIOR V4 panel range. If necessary it can be changed in Installation Menu of panel
Diagnostic mode as per below image.
Dataloop is permantly available atCON5 connector in J-NET-CON board.
Dataloop is permanently available at Data-Loop connector.
Additional Notes:
Both JUNIOR V4 & JUNO NET panels should have COMMS parameter set as 'Normal' as per below image.
Panel must be completely OFF when connecting/disconnecting 5way flat cable otherwise panel and/or interface could
be damaged.
NOTE: Panel should havefirmware 3.09build001P or higher for enhanced webpage usability.
NOTE:
JUNO NET panels with 4, 7, 10 & 13 Loops require a specific 5-way flat cable lead. Please contact your supplier
requesting it.
JUNO NET panels prior to 2009 with J-NET-CON board version 4.X also require the same specific 5-way flat cable lead.
Please contact your supplier requesting it.
Panels should have firmware 3.09 build001P or higher for enhanced webpage usability.
en54secfse:N ac_flt_latch:Y (pg 1/2)
prot: ADVANCED comms:NRMAL en54:Y
output:DT LOOP
com_flt_ltch:Y
en54secfse:N ac_flt_latch:Y (pg 1/2)
prot: ADVANCED comms:NRMAL en54:Y
output:DT LOOP
com_flt_ltch:Y

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
CONFIGURATION: INTERFACE
The interface is supplied with a default configuration, and it's only necessary to take the steps below:
This automatic process requires that DHCP is enabled in local network, which is normally activated on the
router that connects to internet.
1) Take note of‘Client ID’ and‘Channel’values described in interface label.
2) Turn panel power OFF (including batteries).
3) Connect 5 way flat cable between interface and panel as per indicated in‘Connection Diagram’section of this manual.
4) Connect interface to local network using RJ45 connector.
5) Turn panel power ON
6) Check if red and yellow Led’s are blinking.This behaviour is a visual indication of active communication with server.
7) Go to chapter‘Configuration:Webpage’and insert interface‘Client ID’ and‘Channel’in the corresponding fields.
8) Optional: Assign a name to installation and press‘Save’.
9) Press‘Connect’to start communication with panel.
Refer to manual section‘Manual Configuration: Software’in case it’s necessary to configure interface manually.
Automatic Configuration
ATTENTION:

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
Manual Configuration: Software
Connect interface to computer using only USB connector (no other cable should be connected). Regarding USB driver
installation, computers with Windows 10 do not require additional steps, while remainder Windows operating systems drivers
must be loaded in order to create a virtual COM (VCOM). Necessary drivers are available for download in our web page
. Interface communication is put in place via a 'serial port emulator'. We will use 'PuTTY' during next
steps and it's also available in installation package.
After connecting GFE-TCP-WEB to computer, check device manager to find number of COM port attributed to interface.
At this stage please execute 'PuTTY' directly available from GFE-TCP-WEB homepage indicated above, and select options
highlighted in bellow screenshot followed by 'open':
Next steps will be performed in console window created after clicking 'open' at PuTTY.
http://www.createc.pt/v2/gfe
Serie USB
(COM4)

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
Manual Configuration: Procedure
Execute below commands to configure network and web-server parameters:
NOTE:
Disable the DHCP Client: wdhc=0 and press ENTER
Set Network IP: wip4=xxx.xxx.xxx.xxx and press ENTER
NOTE:
> If you want to configure DHCP again enter the following command: wdhc = 1 and press ENTER
IP address, Subnet Mask and gateway must be introduced in its complete form, including zeros on the
left (ex: 192.168.001.020)
'Client ID' and 'CHANNEL 1' parameters are necessary during webpage configuration steps.
>
>
> Set SubNetMask: wsu4=xxx.xxx.xxx.xxx and press ENTER
> Set Gateway: wga4=xxx.xxx.xxx.xxx and press ENTER
> Set Channel 1: wch1=xxxxx and press ENTER (Note: channel name must have 5 characteres).
With command 'rdat=' it's possible to check all sent parameters which can be redefined individually. Please find below
screenshots of above steps and 'rdat=' commands.
After sucessufully completion of above steps, disconnect USB cable, connect GFE-TCP-WEB interface to desired panel and
network cable.

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
CONFIGURATION:WEBPAGE
To access the website enter the link of our server http://www.createc.pt/v2/gfe
http://www.createc.pt/v1/gfe

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
Last step to complete configuration is to load interface and web-server parameters into webpage, press 'settings' button (left
side) to hide/unhide below settings fields.
SETTINGS:
In order to read saved settings, write 'Installation Name' previously set and press 'Read button.
Additional buttons available have the following function:
Connecting - Connect webpage to web-server
Settings
Read
Save
Clear Item
Clear All
Restart
Exit
?Installation - Installation ID name
?Channel - Channel name previously recorded in the interface
?Customer ID - Interface serial number
'
- Hide/unhide communication parameters
- Read parameters of previously saved installation. Place 'Instalation' name and click on 'Read’
- Save parameters after defining ‘installation name’
- Delete loaded installation parameters
- Delete all saved installation parameters
- Reload webpage
- Exit webpage

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
DIAGNOSTICS
Interface
Browser compatibility table
LED 2
OFF
ON
1s
I/O
ON
OFF
LED 1
OFF
ON
OFF
I/O
OFF
ON
DESCRIPTION
No Power. Connecting JUNIOR V4
In error, restart
Normal state without communication
Normal state, to communicate
In error, locked, restart
In error, locked restart
Operation
YES
YES
YES
YES
YES
YES
Read / Save
YES
YES
NO
YES
YES
NO
Remarks
-
Restart - CTRL+F5
-
-
-
-
Browser software
Chrome
Firefox
Internet Explorer
Safari
Opera
Microsoft Edge

Manufacturers of Fire Detection Equipment
globalfire.pt
GFE-TCP-WEB - CONFIGURATION MANUAL - 11/2017
