Global Industrial 293119 User manual

Please read and save these instructions. Read carefully before attempting to assemble, install, oper-
ate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and / or property damage! Retain instructions for future reference.
A er unpacking the unit, carefully inspect unit for any damage that may have occurred during
transit. Check for any loose, missing, or damaged parts.
Unpacking
293119
Figure 1
Owner’s Manual
Speci ca ons
293119
Model No. Power Supply Ph-V-Hz Cooling Capacity Btu/h Power Con-
sump on Wa s
Rated Current
Amps
293119 3Phases - 460V - 60Hz 144,400 21.5kW 27A
Model No. Weight (Net / Gross)
Lbs(kg)
Ambient temperature
range °F( °C)
Dimensions
W x D x H - in. (mm)
293119 1168/1245lbs.
(530/565kg) 64~113(18~45) 34.3 x 75 x 71 (870 x 1904 x 1801 )
Model No. Indoor Air Flow CFM Refrigerant Type / oz(g)
293119 4000 R-410A / 278.7(7900)
Global industrial Portable Air Condi oners are specialized for
“SPOT COOLING” where central cooling is imprac cal.
Global industrial air condi oners can also be used in enclosed
areas just like conven onal air condi oners. Simple digital
controller and self-diagnos c func ons allow users to easily
operate the unit. Built-in Caster wheels enable users to move
the unit without any hassle. The unit can be installed in
5minutes and does not require any extra materials or cer  ed
technician for installa on.
Global industrial Portable Air Condi oner, anywhere,
everywhere. Plug-and-Go!
Descrip on
High Capacity
Air Conditioner
(For Indoor & Outdoor)
TM

2 3
Owner’s Manual 293119
TM
Specicaons (Connued)
Safety Devices
Compressor overload protector, An-freezing
thermister, Automac restart (Power interrupon),
Compressor me delay program, High pressure
switch
Features
Temperature control, Self-diagnosc funcon,
Oponal drain pump kit, Washable lters, °C display,
O-mer
PUMP-DOWN
The unit is integrated with “PUMP-DOWN” funcon.
PUMP-DOWN funcon keeps compressor running for
certain me to protect compressor and other crucial
parts before the unit or compressor is turned o.
PUMP-DOWN funcon acvates,
- When the unit reaches target temperature
- In between cooling mode to heang mode
- In between cooling mode to Fan only operaon
The unit operates in this parcular way to protect the
internal parts.
During PUMP-DOWN cycle, the compressor and fans
will be keep operang even though user turns o the
unit or turns o the compressor.
Please do not forcefully switch o the unit or
compressor during PUMP-DOWN cycle. The unit or
compressor will turn o itself when it is safe for the
unit to do so.
General Safety Informaon
Please read this manual carefully for correct installaon and usage. Please read all safeguards.
1. Transport and store the unit in an upright posion only. Leave unit in an upright posion for
at least 3 hours before rst use.
2. Always place the unit on an even, level surface.
3. Ensure the unit is connected to a grounded power supply of the correct rang / capacity.
4. The unit will operate between 18°C (64°F) ~ 45°C(113°F) depending on the temperature
seng.
5. DO NOT use this unit for other purposes that is not described in this instrucon manual.
6. DO NOT lt the unit.
7. NEVER unplug the unit under operaon.

3
Owner’s Manual 293119
TM
DO NOT use the unit in wet environments, such as a laundry room, to avoid
the risk of electrical shock.
10. DO NOT place any foreign objects on the unit.
11. DO NOT operate the unit with wet or damp hands.
12. DO NOT allow chemical substances to come into contact with the unit.
13. DO NOT operate the unit near ammable substances or vapors such as alcohols,
pescides, gasoline, etc.
14. DO NOT unplug to turn o the unit. Always use the power switch to start and to stop the unit.
15. Always turn o the unit and unplug it before cleaning, moving or performing maintenance.
16. AVOID using adapter plugs or extension cords. If extension cord or an adapter plug is
needed , ensure they are correctly rated for the applicaon. Consult a local qualied
electrician for proper setup. Any extension cord used with this device must be rated for
a minimum of 72A.(460V)
17. DO NOT unplug the unit by pulling on the electrical cord. Keep electrical cord away from
heat sources and always completely unroll the cord to avoid overheang. If the power cord
is damaged, contact a qualied service agent, qualied electrician, or similarly qualied
person for replacement.
DO NOT operate the unit in explosive or ammable environments.
DO NOT operate a unit with a damaged power cord.
18. The lters must be used with the product at all mes. When the lters are removed for
cleaning, always ensure that the unit has been turned o and unplugged from the
electrical outlet.
19. Regularly clean the lters to maintain eciency. If the lters are not cleaned regularly,
the units output performance and eciency will decrease.
20. DO NOT operate the unit with a damaged power cord or plug,
21. Only use in the upright posion on an even, at surface. There must not be any objects
or walls within 24 inches (60 cm) from the unit.
22. Halt the unit immediately if abnormal noise or odor is detected. Contact your local
service center or manufacturer.
23. Appliance is not to be operated by children or persons with reduced physical, sensory
or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon.
24. Children must be supervised not to play with appliance.
25. The unit must be installed in accordance with naonal wiring regulaons.
26. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualied persons in order to avoid a hazard. .

4 5
Owner’s Manual 293119
TM
Assembly (WPC-36003)
COMPONENT PARTS
RSTE
RSTE
Front and Right Side View
Controls
Hot Air Exhaust
Electrical Panel
Caster
Condensate
outlet
I BOLT
Cold Air Inlet
Cold Air Inlet Filter
Emergency Stop
Controls
Figure 2
Figure 3
Figure 4
Figure 5
Casters can be locked by
locking the break down
Handle

5
Owner’s Manual 293119
TM
Figure 6
Figure 7
DUCT CONNECTIONS
Cool Air Out Duct(EVA)
Cool Air in Duct(EVA)
Hot Air Out Duct(COND)
Hot Air in Duct (COND)
Forkli
The Cool air duct connecons are labeled “AIR OUT”. The connecon size is
350Ø in diameter. Connect the exible air ducng as follows:
1. Aach the exible air ducng to the unit’s duct collars making sure
that air will not leak past the connecon collar by using appropriate
round exible ducng clamps.
2. Route the ducng as straight as possible to the space being
condioned avoiding excessive turns and pinches in the ducng.
3. Verify the terminaon points are not restricted meaning no
objects are directly in front of the terminaon.
The Return Air In duct connecon is labeled “AIR IN”.
The connecon size is 350Ø in diameter.
Follow the same procedures as the Cool Air Duct Connecons.
If you need outdoor air, please note that machine will read the
temperature of the outdoor air.
The Hot Air Out duct connecon is labeled “AIR OUT”
The connecon size is 450Ø in diameter.
Follow the procedures as the cool air duct connecons
The Hot Air Out duct connecon is labeled “AIR IN”
The connecon size is 450Ø in diameter.
Follow the procedures as the cool air duct connecons
If a forkli is needed to move the unit, put the foot of the forkli
to the forkli hole (shown in the picture: gure 8).

6 7
Owner’s Manual 293119
TM
Installaon
MOVING THE UNIT
PLUGGING IN THE UNIT
Unlock the casters and push the unit using the side handles to a at, level surface and set the
caster brakes to the locked posion.
Check the prongs and surface of the power cord plug for dust/dirt. If dust and/or dirt are pres-
ent, wipe o with a clean, dry cloth.
Check the power cord, plug and prongs for damage or excess play.
If any damage or excess play is found, contact a qualied repair technician or a qualied electri-
cian to perform replacement or repair of the power cord, plug or prongs.
NOTE: Make sure the AC outlet is free of dirt, dust, oil, water, or any other foreign material. The
unit is equipped with an approved NEMA plug conguraon. The appropriate outlet must
be used for each plug type.
WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION
Do not use the unit in explosive environments or in areas where ammable
gas leakage may occur.
Do not use the unit in areas where it will be exposed to rain or water.
Do not use the unit in a corrosive atmosphere.
Do not use the unit above 18°C(64°F) ~ 45°C(113°F).
Do not install the unit on uneven or sloping surface. The unit may roll or
topple over even if the casters are set to the locked posion.
If the power cord or plug is damaged, repair should only be performed by
qualied electrical personnel.
Do not connect / disconnect the power cord or aempt to operate buons
with wet hands. This could result in electrical shock.

7
Owner’s Manual 293119
TM
Operaon
CONTROL PANEL
10
Figure 8
108&3 #-08&3 $00- 5*.&3
4105$00-
"-"3.
$633&/5 5&.1)6.*% 5" 3(&5 5&.1)6.*%
1
2
7
34
6
5
98
1. POWER BUTTON: Acvates unit when POWER BUTTON is pressed. If POWER BUTTON is
pressed during operaon, unit stops.
2. BLOWER BUTTON: Indicates fan speed. (Not available for 3 phase model)
3. COOL BUTTON: Acvates compressor and begins producing cool air in 5 seconds aer
buon is pressed.
4. TIMER BUTTON: Enters to Timer Seng Mode by pressing TIMER BUTTON for 1 seconds.
Two digits on CURRENT TEMP indicate hour(s) and two digits on TARGET TEMP indicate
minutes. Set desired o-me by pressing SET TEMP BUTTONS.
5. ALARM: Alarm indicator lights (blinks) and indicates abnormal system operaon.
If Alarm occurs, compressor stops. System operaon stops when Alarm light is acvated
(blinks) longer than 3 minutes.
6. SPOT/COOL: Lights (blinks) when unit is operated on SPOT/COOL mode.
7. SET TEMP BUTTONS: Change target temperature/data value by +/-1. Press the SET TEMP
BUTTONS to set temperature. Upper buon is to heighten temperature and Lower buon
is to lower temperture.
8. TARGET TEMP: Displays unit set temperature for ROOM/COOL mode only.
Set TARGET TEMP 0 ℃ or 32℉ on SPOT/COOL mode.

8 9
Owner’s Manual 293119
TM
Operaon
CONTROL PANEL
9. CURRENT TEMP: Displays ambient temperature (In ROOM/COOL mode only) / Displays outlet
(cool air) temperature during normal operaons (In SPOT/COOL mode only)
In order to change ℃ to ℉, press BLOWER and COOL buons together for 2 seconds.
F will blink 2 mes and Figure will change to °F. ALARM codes blink and are displayed
when abnormal operaon occurs.
10. EMERGENCY STOP :
Emergency stop buon immediately halts the operaon
1. Press the red buon – Unit stops
2. Inspect the unit.
3. Rotate the red buon clockwise to restart the unit
SPOT/COOL mode → ROOM/COOL mode : Enter to ROOM/COOL mode if COOL BUTTON and
TIMER BUTTON are pressed together for 1 seconds.
ROOM/COOL mode → SPOT/COOL mode : Enter to SPOT/COOL mode if COOL BUTTON is
pressed for 1 seconds.
AUTO RESTART: If the unit goes o due to an electrical interrupon, the unit will automacally
restart when the power resumes.

9
Owner’s Manual 293119
TM
Maintenance
FILTER CLEANING (See Figures 11 and 12)
1. loosen up 6 bolts on the front lter guard.
2. Slide lter up and use a vacuum cleaner to remove the dust from the lter.
3. If the lter is heavily covered with dust and dirt, warm water and mild soap or neutral deter-
gent may be used to wash the lter. Do not use any other chemicals to clean lter, as they will
likely damage the lter.
4. Dry the lter in a shaded area before replacing it. Do not operate the unit without the lter
installed and the lter guard in the closed posion.
5. Replace the clean lter and close the lter guard.
– For your convenience, record the complete model number and product name (located on the
Product Idencaon Plate), the purchase date, purchase locaon, serial number, and war-
ranty period in the table below.
– Also, aach your purchase receipt as proof of purchase to this instrucon manual for future
reference.
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
Do not operate without the lter ed.
Do not operate the unit with a damaged cord or plug, aer the unit malfunc-
ons, or if the unit has been dropped or damaged.
– Loosen up 12 bolts on
the front filter guard.
– Slide filter up and use
a vacuum cleaner to remove
the dust from the filter.
– Remove dust from the filter
using a vacuum cleaner
hose aachment.
– If required wash the filter in
lukewarm water with a mild
detergent. Leave to dry in
a shaded area before
reinstalling.
Figure 11 – Removing Filters Figure 12 – Removal of Dust
NOTE: For eecve cooling clean the lter at least every 2 weeks.

10 11
Owner’s Manual 293119
TM
Maintenance (Connued)
– To ensure your product is covered by warranty, the complete faulty product along with your
original purchase receipt must be provided at the place of purchase.
Product Portable Air Condioner
Model No.
Date of Purchase
Place of Purchase
Serial No.
Period of Warranty
Customer: Please read and keep this
manual for future reference and keep
sales receipt as proof of purchase.
SELF-DIAGNOSTIC CODES (See Table 1)
The alarm light is acvated if abnormal operaon occurs, and a code is displayed on the control
panel. The compressor and condenser fan motor will stop operang. The evaporator fan will con-
nue to run for 3 minutes. If the fault is reced within 3 minutes, the unit will resume opera-
on. If the fault persists for more than 3 minutes, the evaporator fan also stops. The fault must
be reced before the unit can resume normal operaon.
Table 1- Alarm Codes
SELF-DIAGNOSTIC ALARM CODES
Alarm Display Problem Cause Correcve Acon
Frost prevenon
sensor and Abnormal
temperature sensor
value
• Indoor heat
exchanger tempera-
ture too low
• TH3 temperature
sensor has a loose
or broken connec-
on
• Do not use the air
condioner if ambient
temperature is lower
than 18°C (64°F)
• Contact a qualied
service agent

11
Owner’s Manual 293119
TM
Table 1- Alarm Codes
SELF-DIAGNOSTIC ALARM CODES
Alarm Display Problem Cause Correcve Acon
Refrigerant high
pressure switch
Overheat
• Blocked air lter
• Blocked / kinked
exhaust duct
• Ambient tempera-
ture is too high
• Internal Unit
temperature is over
85°C (185°F)
• Clean air lter
• Ensure exhaust duct is
not blocked / kinked
• Do not use the air
condioner if ambient
temperature is higher
than 45°C (113°F)
• Turn o the unit, wait
for it to cool down, Turn
on again.
• If HO alarm code is sll
on, it means that the
unit has reached over
95°C(203°F). Reseable
overheat sensor is on
• Manually switch o the
reseable overheat
sensor to re-operate.
Abnormal tempera-
ture sensor value
TH1(Outlet) tem-
perature sensor has
a loose or broken
connecon
Contact a qualied service
agent
Abnormal tempera-
ture sensor value
TH2(Inlet) tem-
perature sensor has a
loose or
broken connecon
Contact a qualied service
agent
Compressor over-
loaded
• Ambient tempera-
ture is too high
• Unstable voltage
supply
• Defecve compres-
sor
• Do not use the air
condioner if ambient
temperature is higher
than 45°C (113°F)
• Contact a qualied
service agent
• Replace compressor
(Opon)

12 13
Owner’s Manual 293119
TM
Wiring Diagram
Figure 14 - Circuit Wiring Diagram (WPC-36003)
WPC-36003 CL/EL
MCCB
TH1 TH1
OUT_TEMP
Sensor
TH2 TH2 TH3 TH3
IN_TEMP
Sensor
ICE_TEMP
Sensor
MC 1 OCR 1
R
T
COMP'
R-1A
COM
L
H
COM
CP
N-1
L-1
COM
CO
EXT
COM
Phase Protector
C (CM)
B (NC)
A (NO)
R (L1)
S (L2)
T (L3)
TR
220V
E
PBS
R
T
380-460V
R
S
T
R
S
T
R-1
S-1
T-1
S
S-1A
T-1A
MC 2 OCR 2
R-2
S-2
T-2
R
T
COND'
MOTOR
S
R-2A
S-2A
T-2A
MC 3 OCR 3
R-3
S-3
T-3
R-3A
S-3A
T-3A
R
T
S
No.1
E VA '
MOTOR
R
T
CP CP
COM
H
COM
CO
COM
R
S
T
R
T
S
No.2
E VA '
MOTOR
Low
Pressure
Switch (Option)
LP LP
PU
HG
COM
Solenoid
Valve
(Hot Gas
Bypass)
Power
3P AC 380V-50Hz 3P AC 460V-60Hz
E
R
S
T
TB
CP
PU
HT
EXT
COM
EMC
L
H
SEN1 SEN2 SEN3
FND
PS (HP)
COM
COM
EXT
FU
FT
CO
COM
(FUSE)
(FUSE)
IR/FT
T (AC) S R
Power Remote
Control (Option)
High Pressure Switch
COM
HP
COM
FU
Drain
Pump
(Option)
Emergency Switch

13
Owner’s Manual 293119
TM
Troubleshoong chart
Symptom Possible Cause(s) Correcve Acon
The unit doesn’t work
1. Check the power supply
to verify that power is
available to the unit
1. Reset the circuit breaker and
restart the unit
2. Verify that the power
cord is connected
2. Connect power cord
No cold air ows from the
cold air outlet
1. Ambient air cannot be
properly cooled if the
lter is dirty and not
regularly cleaned
1. Clean the lter
2. Compressor will not
work if the unit is
turned o and on
quickly.
2. Wait 2 minutes aer unit is
turned o before turning the
unit back on.
3. The ambient air tem-
perature may be too
high
3. The temperature of the com-
pressor can be higher when
the ambient temperature is
too high. The compressor will
not work unless the ambient
air temperature is within the
acceptable operang range of
the unit
Water ow can be heard
aer compressor shuts o
No cause Common to hear coolant owing
aer unit shuts o

14 15
Owner’s Manual 293119
TM

15
Owner’s Manual 293119
TM

16 PB
Owner’s Manual 293119
TM
LIMITED WARRANTY
Global industrial ONE-YEAR LIMITED WARRANTY. Global industrial PORTABLE AIR CONDITIONERS, MODELS
COVERED IN THIS MANUAL, ARE WARRANTED BY Global industrial TO THE ORIGINAL USER AGAINST DEFECTS
IN WORK MANSHIP OR MATERIALS UNDER NORMAL USE FOR ONE YEAR AFTER DATE OF PURCHASE. ANY PART
WHICH IS DETERMINED TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP AND RETURNED TO AN AUTHO-
RIZED SERVICE LOCATION, Global industrial DESIGNATES, SHIPPING COSTS PREPAID, WILL BE, AS THE EXCLU-
SIVE REMEDY, REPAIRED OR REPLACED BY Global industrial OPTION. FOR LIMITED WARRANTY CLAIM PROCE-
DURES, SEE “PROMPT DISPOSITION” BELOW. THIS LIMITED WARRANTY GIVE PURCHASERS SPECIFIC LEGAL
RIGHTS WHICH VARY FROM JURISDICTION TO JURISDICTION.
LIMITATION OF LIABILITY. TO THE EXTENT ALLOWABLE UNDER APPLICABLE LAW, Global industrial LIABILITY
FOR CONSEQUENTIAL AND INCIDENTAL DAMAGES IS EXPRESSLY DISCLAIMED. Global industrial LIABILITY
IN ALL EVENTS IS LIMITED TO AND SHALL NOT EXCEED THE PURCHASE PRICE PAID.
WARRANTY DISCLAIMER. A DILIGENT EFFORT HAS BEEN MADE TO PROVIDE PRODUCT INFORMATION AND
ILLUSTRATE THE PRODUCTS IN THIS LITERATURE ACCURATELY; HOWEVER, SUCH INFORMATION AND ILLUSTRA-
TIONS ARE FOR THE SOLE PURPOSE OF IDENTIFICATION, AND DO NOT EXPRESS OR IMPLY A WARRANTY THAT
THE PRODUCTS ARE MERCHANTABLE, OR FIT FOR PARTICULAR PURPOSE, OR THAT THE PRODUCTS WILL NEC-
ESSARILY CONFORM TO THE ILLUSTRATIONS OR DESCRIPTIONS. EXCEPT AS PROVIDED BELOW, NO WARRANTY
OF AFFIRMATION OF FACT, EXPRESSED OR IMPLIED, OTHER THAT AS STATED IN THE “LIMITED WARRANTY”
ABOVE IS MADE OR AUTHORIZED BY Global industrial.
Technical Advice and Recommendaons, Disclaimer. Notwithstanding any past pracce or dealings or trade
custom, sales shall not include the furnishing of technical advice or assistance or system design. Global indus-
trial assumes no obligaons or liability on account of any unauthorized recommendaons, opinions or advice
as to the choice, installaon or use of products.
Product Suitability. Many jurisdicons have codes and regulaons governing sales, construcon, installaon,
and/or use of products for certain purposes, which may vary from those in neighboring areas. While aempts
are made to assure that Global industrial products comply with such codes, Global industrial cannot guarantee
compliance, and cannot be responsible for how the product is installed or used. Before purchase and use of a
product, review the product applicaons, and all applicable naonal and local codes and regulaons, and be
sure that the product, installaon, and use will comply with them.
Certain aspects of disclaimers are not applicable to consumer products; e.g., (a) some jurisdicons do not
allow the exclusion or limitaon of incidental or consequenal damages, so the above limitaon or exclusion
may not apply to you; (b) also, some jurisdicons do not allow a limitaon on how long an implied warranty
lasts, consequently the above limitaon may not apply to you; and (c) by law, during the period of this Limited
Warranty, any implied warranes of implied merchantability or tness for a parcular purpose applicable to
consumer products purchased by consumers, may not be excluded or otherwise disclaimed.
Prompt Disposion. A good faith eort will be made for prompt correcon or other adjustment with the
respect to any product which proves to be defecve within limited warranty. For any product believed to be
defecve within limited warranty, rst write or call dealer from whom the product was purchased. Dealer will
give addional direcons. If unable to resolve sasfactorily, write to Global industrial at the address below,
giving dealer’s name, address, date, and number of dealer’s invoice, and describing the nature of the defect.
Title and risk of loss pass to buyer on delivery to common carrier. If product was damaged in transit to you,
le claim with carrier.
Manufactured in Global industrial co., Ltd., 11 Harbor Park Drive Port Washington, NY 11050 USA
1.888.628.3466 Customer Support Printed in December 2021
