GLOBAL PLASMA SOLUTIONS GPS-FC48-AC Troubleshooting guide

122019-GPSIMOD-IOM REV G.docx
GLOBAL PLASMA SOLUTIONS
GPS-iMOD®
Installation
Operation &
Maintenance
Manual
3101 Yorkmont Road
Suite 400
Charlotte, NC 28208
[phone]
www.globalplasmasolutions.com
Operations
and
Maintenance
Manual
Submittals
Operations
&
Maintenance
Manual
GPS-FC48-AC
Operation
&
Maintenance
Operation
&
Maintenance

GPS-FC48-AC
4,800 CFM Auto-Cleaning Needlepoint
Bipolar Ionization System
Product Description
The GPS-FC48-AC is an auto-cleaning, no maintenance, needlepoint bipolar ionization system designed to handle up to
4,800 CFM. The unit is designed for multiple mounting options including fan inlet, interior duct wall or interior duct
floor. The all-composite and carbon fiber construction allows the product to be mounted in corrosive environments.
Specifications Commercial Applications
• Schools and Universities
• Arenas and Stadiums
• Transportation Hubs
• Office Buildings
• Manufacturing
• Food Service
• Animal Care
• Institutional
• Senior Care
• Healthcare
• Hospitality
• Child Care
• Worship
• Theatre
Input Voltage 24VAC to 240VAC
Amps 0.41A to 0.041A
Power 10 Watts
Frequency 50/60HZ
Temperature/Humidity -20°F to 200°F / 0-100% RH
Ion Output > 400 Million ions/cc/sec
Airflow Capacity 0 to 4,800 CFM or up to 12 tons
Electrical Listings UL, cUL, CE
Alarm Contact Rating 250VAC/ 1A
Standard Features
Universal voltage input, in-line On/Off switch, programmable auto-cleaning cycle, plasma on indication light,
alarm contacts, magnets for ease of installation and replaceable carbon fiber brush emitters.*
*Life cycle testing shows no mechanical degradation of the carbon fiber brushes due to repeated cleaning cycles
Benefits
Unit Dimensions/Weight 11.1”L x 1.84”W x 3.52”H / 1.32 lbs
Compliance & Certifications UL 867, OSHPD Seismic (OSP), IAQP
Pathogens Killed (Bacteria, Viruses, Mold), Helps to Control Allergens/ Asthma*, Prevents Dirty Sock Syndrome
Particle Reduction and Smoke Control
Odors Neutralized by destroying VOCs
Energy Savings of 30% by Reducing Outdoor Air Intake by up to 75%, reduces pressure loss by keeping coils clean
without expensive UV system, and requires No Maintenance!
*These statements are based on numerous customer testimonials and have not been evaluated by the FDA
TM
Global Plasma Solutions, Inc.
www.GlobalPlasmaSolutions.com
© 2019 Global Plasma Solutions, Inc.
GPS, GPS-FC48-AC, Global Plasma Solutions and its logos are trademarks of Global Plasma Solutions, Inc.
Engineering Air for a Cleaner World™
Total

GlobalPlasmaSolutions.com
WIRING
1.Confirm the power is off prior to wiring. Follow all local and national electrical and building
codes.
2.The GPS-FC48-AC will self-adjust to voltages from 24VAC to 240VAC. Connect the power
wires as follows:
Black 24 - 240VAC
White Neutral or L2
Green Ground
Brown Dry Contacts/BAS terminals
3.Wire in BAS terminals (optional). The GPS-FC48-AC is equipped with dry contacts that are
normally open and close when the GPS-FC48-AC is on and has no faults. The contacts are
rated up to 250VAC and 1A.
OPERATION
CAUTION! NEVER TOUCH BRUSHES WHILE OPERATING, SHOCK MAY OCCUR
Once powered and the inline switch is in the on position, the unit initiates an internal check of
all systems. If the autocleaning wiper blade is not in the “home” position, it will move to the
home position in series with the airflow.
CLEANING CYCLE
The GPS-FC48-AC comes with a preset cleaning cycle designed to clean the brushes every three
days. The cleaning process may be activated by pushing the test button located on the top of
the unit. To change the cycle frequency, press the cleaning cycle button once. While cleaning is
in progress press and hold the cleaning cycle button for 5 seconds. The LED will start flashing.
Pressing the cleaning cycle button again will change the days between cleaning. The number
of flashes indicates the cleaning interval in days (3 flashes=3 days, 5 flashes=5 days).
TROUBLESHOOTING
1.Unit will not power up, LED not illuminated:
a.Confirm proper voltage is applied to the correct terminal(s).
a.Try an alternate power source. If using 24v try using 120v or vice versa.
2. Wiper sticks or stops on emitters:
a.Adjust height of emitters: loosen screw at base of emitter gently push or pull emitter to
a height where wiper just contacts emitter. Hold the emitter in place and tighten screw.
Verify correct height after tightening screw.
3.Wiper does not clean/ contact emitters:
a.Adjust height of emitters: loosen screw at base of emitter gently push or pull emitter to
a height where wiper just contacts emitter. Hold the emitter in place and tighten screw.
Verify correct height after tightening screw.
a.If the emitter is worn to the point where there is no adjustment, replacement emitters can
be ordered from GPS. Remove the screw and the emitter base, unplug the emitter from
the connector. Plug the new emitter in, reinstall base, adjust emitter height and tighten
screw.
4.If unit does not operate properly after verifying the above instructions please contact GPS
for additional assistance.
Thank you for purchasing a GPS-FC48-AC from Global Plasma Solutions. The GPS-FC48-AC
is an auto-cleaning air purifier mounted in the fan coil units, forced air furnace or ducts. The
GPS-FC48-AC requires no maintenance or periodic replacement parts.

3101 Yorkmont Road • Suite 400
Charlotte, NC 28208
980-279-5622
GlobalPlasmaSolutions.com
GPS, GPS-FC48-AC and its logos are trademarks of Global Plasma Solutions, Inc.
©2020 Global Plasma Solutions, Inc.
030120-GPSFC48-IOM REV A
