Global Power Products SURGE SAFE SM Series User manual

SURGE SAFE™
SM Series Surge Protective Device (SPD)
Installation, Operation and Maintenance Manual
Introduction
Surge Safe™ SM Series Surge Protective Device is a high quality, high energy surge current diverting
system designed to protect sensitive equipment from damaging transient voltage surges resulting from load
switching, lightning strikes, and other sources.
Installer should perform the following instructions carefully to ensure a quality installation. Please read all
instructions before starting the installation of this product. These instructions do not replace national or local
electrical codes. Please check applicable electrical codes to ensure compliance.
Part Number
100-SM3W
300-SM4W
310-SM4W
Applied Voltage
120/240VAC
120/208VAC
277/480VAC
Phase
Single Phase
Three/Wye
Three/Wye
Wiring
2 Wire + Neutral
3 Wire + Neutral
3 Wire + Neutral
Operating Frequency 47-60Hz
Nominal Discharge Current (In) 20kA
Maximum Surge Current Capacity (8 x 20µs) 50kA
Short Circuit Current Rating (SCCR)1 200kA
Voltage Protection Rating (VPR) 100-SM3W, 300-SM4W @ L-N 700V, L-L 1200V
310-SM4W @ L-N 1200V, L-L 2000V
Wire type #12 Wire leads, 24” long
Enclosure Size (in) 3.543 L x 3.543 W x 2.362 H
Enclosure Rating UL Type IP66, NEMA 4, 4X, 12, 13
Conduit Hub Weather Tight
Operation Temperature -40°C to +85°C
UL Location Type Type 1 Surge Protective Device (SPD)
1Suitable for Use on a Circuit capable of delivery not more than 200kA rms symmetrical Amperes.
WARNING
ONLY QUALIFIED PERSONNEL/ELECTRICAN SHOULD INSTALL OR SERVICE SURGE SAFE™
DEVICES.
ELECTRICAL SAFETY PRE-CAUTIONS MUST BE FOLLOWED WHEN INSTALLING OR SERVICING
THIS EQUIPMENT.
TO PREVENT RISK OF FIRE, ELECTRICAL SHOCK, OR DEATH; ALL POWER SOURCES TO THE
UNIT MUST BE TURN OFF AND LOCK OUT BEFORE MAKING ELECTRICAL CONNECTIONS OR
SERVICING.
SURGE SAFE™ DEVICES ARE NOT TO BE USED WITH A HI-LEG DELTA VOLTAGE
CONFIGURATION.
THIS SPD MAY NOT SURVIVE SUSTAINED OVERVOLTAGES.
Caution –Ungrounded power systems are inherently unstable and can produce excessively high line to ground voltages
during certain fault conditions. During these fault conditions any electrical equipment, including an SPD, may be subjected to
voltages which exceed their designated ratings. This information is being provided to the user so that an informed decision can
be made installing any electrical equipment on an ungrounded power system.
Verify the system voltage and wiring configuration is the same as the enclosed Surge Safe™ by checking it
against the product label.
USE SUPPLY WIRE SUITABLE FOR 90°C
EMPLOYER DES FILS D'ALIMENTATION POUR 90°C
Wiring
#12 AWG wring is provided with the unit. All wiring must comply with the National Electrical Code (NEC)
and applicable local codes.
GENERAL SPECIFICATION
INSTALLATION

Mounting
1. Locate the SPD between the meter and the main service circuit breaker panel. The SPD should be
mounted to an electrical box or enclosure.
2. For the best performance, try to mount the unit as close as possible to the service panel, in close proximity
to the breaker that will feed the Surge Protective Device.
3. Avoid sharp bends and turns, which will degrade the performance of the SPD. The weight of the SPD
should be supported to avoid necessary stress on the wiring connections.
Installing
1. Measure voltage at installation location between each Line and Neutral. System voltage must not exceed
the specified maximum continuous RMS voltage listed on the SPD label.
2. TURN OFF POWER at the installation location (usually by removing services to meter or disconnection of
service supply by utility).
3. Switch all distribution panel circuit breakers to OFF position to reduce possibly of accidental voltage on the
circuit.
4. Connect the SPD White (Neutral) wire to the Neutral service conductor, a grounding electrode conductor,
or the equipment grounding terminal in the service equipment.
For a Split-Phase system: Connect Line 1 to one of the SPD’s Black wires and Line 2 to the remaining
Black wire. See Figure 1
For a Three-Phase system: Connect Line 1 to one of the SPD’s Black wires, connect Line 2 to the
other Black wires, and Line 3 to the remaining Black wire. See Figure 2.
Keep all hook-up leads as short and straight as possible.
5. Restore power to the SPD and switch circuit breakers to “ON” position to reconnect load. Verify that the
Green LED is illuminated.
If Green LED is not lit, remove power, re-check installation, repeat Step 2, and test again.
If Red LED is lit and the buzzer sounds, contact the manufacturer and replace the unit immediately.
Figure 1 –Split-Phase System Figure 2 –Three-Phase System
Environment
The unit is designed for indoor or outdoor use in ambient temperature of -40C to +85C with a relative
humidity of 0% to 95%. The unit is provided in an industrial enclosure, which should not be installed in areas with
excessive dust, corrosive vapors, flammable materials or explosive atmospheres.
Global Power Products will repair or replace any Surge Protective Device that is defective in material or workmanship
or is damaged by an electrical surge (including those caused by lightning) for a period of seven (7) years from the date of
installation or seven (7) years and six (6) months from the date of manufacture, whichever comes first.
For any further inquiries or question, call Global Power Products at
1-800-886-3837
All damaged/returned products returned to the factory for repair/replacement must be accompanied by a Return Authorization
number to the following address
225 Arnold Road
Lawrenceville, GA 30044
Phone [phone]
Fax [phone]
www.globalpowerproducts.com
Copyright © 2012. Global Power Products, Inc. All rights reserved
This instruction manual is published solely for information purposes and should not be considered all-inclusive. No part of this manual may be
reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or by an information
storage or retrieval system without the prior written permission of Global Power Products unless such copying is expressly permitted by
federal copyright law.
