FOLI USER
FOLI MECHANISM
WITH ECS+

FOLI MECHANISM WITH ECS+ — USER MANUAL
CONTENTS
1 Important Information. SAFETY FIRST!...........................................................................................................................................................................................3
1.1 Important safety instructions, please save these instruction .............................................................................................................................3
1.2 User Information.....................................................................................................................................................................................................................5
1.3 Before you start: ................................................................................................................................................................................................................... 6
1.4 Electrical rating...................................................................................................................................................................................................................... 6
2 Assembly & Adjustment......................................................................................................................................................................................................................... 6
2.1 Assembly Instruction........................................................................................................................................................................................................... 6
2.2 Setup procedure................................................................................................................................................................................................................... 6
2.3 Optional mounting guidelines .........................................................................................................................................................................................7
2.4 System configuration (example).....................................................................................................................................................................................7
2.5 Adjustments ............................................................................................................................................................................................................................7
3 Operation Instructions............................................................................................................................................................................................................................ 8
3.1 Basic functions ....................................................................................................................................................................................................................... 8
4 Maintenance & Repairs.......................................................................................................................................................................................................................... 12
4.1 Cleaning, Inspection and Storage................................................................................................................................................................................. 12
4.2 User Maintenance................................................................................................................................................................................................................ 12
4.3 Repairs..................................................................................................................................................................................................................................... 12
4.4 Servicing of double-insulated products ................................................................................................................................................................... 13
2

FOLI MECHANISM WITH ECS+ — USER MANUAL
3
1 Important Information. SAFETY FIRST!
Your safety and the safety of others are very important. Please familiarize yourself with all instructions and safety warnings before
operating the table. Please keep this manual for future reference.
To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in
this user’s manual. This information alerts you to potential hazards that could hurt you or others. It is not practical or possible to
warn you about all the hazards associated with operating or maintaining a table. Please use your own good judgment.
You will find important safety information in a variety of forms. Safety Messages are preceded by a safety alert symbol and one
of three signal words: DANGER, WARNING, or CAUTION. These safety messages are listed in order of severity, identify the general
risks and what actions you are to take to avoid the risks. These signal words mean:
DANGER - Indicates an imminent hazardous with a high risk of serious injury or death.
WARNING - Indicates a potential hazardous may result in serious injury.
CAUTION - Indicates a potential hazardous, which may result in minor or moderate injury. It may also be used to
alert against unsafe practices.
NOTICE - Indicates an alert to call attention to proper assembly instructions or particular operation procedures to assure
correct equipment function and to avoid equipment damage or wear.
The information and specifications included in this manual were in eect at the time of approval for printing. ROL reserves the right
to discontinue or change specifications or design at anytime without notice and without incurring any obligation whatever.
1.1 Important safety instructions please save these instruction.
When using an electrical table, basic precautions should always be followed, including the following:
Read all instructions before using table.
DANGER - To reduce the risk of electric shock:
1. Always unplug this furnishing from the electrical outlet before cleaning.
WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Unplug from outlet before putting on or taking o parts.
2. This table is not intended for use by children or individuals with a physical or other impairment that may aect the
ability to safely operate equipment. ,
3. Use this table only for its intended use as described in these instructions. Do not use attachments not recommended by
the manufacturer.
4. Never operate this table if it has a damaged cord or plug, if it is not working properly, if it has been dropped
or damaged, or exposed to water. In the event of any such event please return the table to a service center for
examination and repair.
5. Keep the cord away from heated surfaces.
6. Never operate the table with the air openings blocked. Keep the air openings free of lint, hair, and the like.
7. Never drop or insert any object into any opening.
8. Do not use outdoors.
9. Do not operate the table in a potentially explosive atmosphere.

FOLI MECHANISM WITH ECS+ — USER MANUAL
4
10. To disconnect, turn all controls to the o position, then remove plug from outlet.
WARNING - Risk of Electric Shock:
1. Connect this table to a proper outlet only. For loading always put heavier items at the bottom and not at the top in
order to help prevent the possibility of the furnishing tipping over.
WARNING - Risk of Injury to Persons:
1. Do not use this table to lift people and do not use the table to lift heavy parts or use this table as a platform for storage.
2. Maximum intended load is 265 pounds uniformly distributed (120 kilograms) including the table top.
DANGER - Risk of electric shock, injury, or death:
1. Improper usage, abuse, or misuse of the power supply, handset, motors and other electrical components may result in
an electrical shock injury or possible death.
2. Do not open the power supply unit or handset under any circumstances. The power supply and handset contain no
serviceable parts.
3. Do not modify or make any changes to the power supply, handset or other electrical devices.
4. During installation, repair, cleaning, or maintenance work, the power cable must be disconnected from the outlet.
5. The engines/motors control unit is not designed for continuous operation. Changing the desktop position without
interruption must not exceed the duty cycle indicated on the power supply. The unit is thermally protected and will
temporarily shut down if use exceeds the duty cycle. Allow a 9-minute cooling period for the control unit to reset.
6. The power supply unit may only be operated with voltage as specified on the power supply label.
7. Only use the power cord supplied with the power supply. Check that it is not damaged. Do not operate the power
supply unit if the power cord is damaged.
8. Connect the power supply to a proper outlet only. To disconnect turn all controls to the o position, then remove plug
from outlet.
9. In the event of a malfunction (e.g. if the control unit keeps adjusting the desk because a movement button has jammed),
please unplug the unit immediately.
10. Do not expose the power supply, control unit/ECS+, handset or other electrical device to water or other liquids
including moisture, drips, splashes or spills. Only clean electrical device with a dry cloth.
11. Do not operate the power supply, control unit/ECS+, handset or other electrical device in a potentially explosive
atmosphere. Do not operate where aerosol spray products are being used or where oxygen is being administered.
12. Do not use the desk with if it has been dropped or damaged. Contact the manufacturer for examination or repair
13. It is not allowed to connect self-constructed products to the power supply, control unit/ECS+, handset or other
electrical device. To prevent damage, use only approved OEM components
WARNING - Risk of injury, or death:
1. During the raising or lowering of the table there exists a risk of squeezing or pinching between the moving desktop and
fixed objects.
2. The necessary safety margins depend on the greatest type of injury risk that can be predicted. Where possible small
pinch points exist (i.e. fingers) use at least a one inches (2,5 cm) safety margin and for body or head (especially where
children may be present) use a minimum of 16 inches (41 cm) count from the floor or from their top of the table feet if
that is relevant
3. During the lowering or rising of the desktop, the operator must ensure that no person or object risk being harmed by
the operation.

FOLI MECHANISM WITH ECS+ — USER MANUAL
5
4. This tag (at right) should be located on the table during the initial
installation.
5. Keep children away from moving parts and underneath the table.
6. The intended use of the table is adjusting a work surface between
sitting and a standing position. The table is not designed for other
uses.
7. The table must only be operated while in an upright position and
must under no circumstances be operated while upside down.
8. The table must not be overloaded. The maximum allowable load is
shown on the power supply label.
9. The table must be operated in a dry, enclosed space, such as an
oce or similar, Do not operate outdoors.
10. As option the table can be equipped with Anti Collision (AC)
function. In the event of a faulty the desktop may move slightly
before the safety feature is engaged. Stay clear of pinch points when
the desktop is moving.
11. This table is not intended for use by individuals (including children)
with limited physical, sensory or mental abilities or with a lack of
experience and/or lack of expertise, unless they are supervised by a
person responsible for their safety or have received instructions from
that person on how to use the control unit.
12. Children must be supervised at all times to ensure that they do not
play with the control unit.
13. The table may not be used to lift people. Do not sit or stand on a
table while it is be raised or lowered.
14. The table must not be structurally or technically altered or modified
in any way.
1.2 User Information
This column system is rated for commercial use only and is rated for a maximum load of 265 pounds, uniformly distributed (120kg)
including the tabletop
The motors may only be used continuously for 1 minute after which the table wills automatically shut-o 9 minutes.
Typical Product Label with Date of Manufacture Typical Power Supply Label for 1.25”/sec speed

FOLI MECHANISM WITH ECS+ — USER MANUAL
6
1.3 Before you start
Check for and remove obstacles in path of the table top.
If divergence between the columns will be discovered, please do a manual reset as listed in section 3.2.
1.4 Electrical rating
Electrical rating, input: 120VAC, 50-60Hz, 3,2A. Output 29V or 35V.
2 Assembly & Adjustment
2.1 Assembly Instruction
The ocial assembly instruction will be found with the
base components.
Base is for use with an approved surface, provided by
the Global Furniture Group.
2.2 Setup procedure
CAUTION - Risk of electrical shock:
The power cord must be unplugged while the control
unit is being commissioned.
This table is equipped with the ECS+ system, to setup
the controlling device proceed as follows.
1. Connect the motor cables to the control unit 8-pin motor cables
2. Connect the handset to the relevant socket at the control unit / ECS+
3. Connect the Power Supply to the control unit / ECS+
4. Plug in the power supply to a standard outlet.
At first use, the control unit must register the lowest point of elevation. To reset, press “down” icon and go to lowest level.

FOLI MECHANISM WITH ECS+ — USER MANUAL
7
2.3 Optional mounting guidelines
NOTICE - When components like power supply, control unit / ECS+ or motor cables shall be disconnected, be sure to unlock
the 8pin connector on the cable properly! There is a fixing hook on this connector that must be pressed.
DANGER - Grounding Instruction
This product does NOT require grounding to earth. This product is double insulated and equipped with
a nonpolarized 120V plug and 2-conductor cord. The plug must be plugged into an appropriate building
outlet that is properly installed in accordance with all local codes and ordinances.
DANGER - RISK OF ELECTRICAL SHOCK
Improper connection of the equipment can result in a risk of electric shock. Check with a qualified electrician for any concerns. Do
not modify the plug provided with the product – if it will not fit the outlet have a proper outlet installed by a qualified electrician.
This product is designed for the voltage indicated on the power supply label. No adapters should be used with this product.
CAUTION - Risk of electrical shock
Before you plug in the power cord, check the following again:
• The voltage must be as specified on the power supply label.
• When the power cord is plugged in, the electrical control devices are operational.
NOTICE - in case of a main power breakdown, or if the power cord is unplugged during the movement of the drives, a manual
reset may be necessary! Please see section 3.2 manual reset.
2.4 System configuration (example)
The figure below shows the motor driving assignment for a configuration example. This configuration consists of:
1 Power Supply
2 Motor cables
3 Handset
4 Control unit
2.5 Adjustments
The table control, handset and motors are sealed units and have no parts that can be serviced or adjusted by the user. In case of
failure or unexpected operation that cannot be corrected using the instructions in this manual, please contact Global Furniture
Group Customer Care.

FOLI MECHANISM WITH ECS+ — USER MANUAL
8
3 Operation Instructions
To ensure safe operation of the ECS+ control unit, please observe the following safety instructions:
CAUTION - Risk of injury and electric shock.
Keep children away from electric height-adjustable desks, control units and handset.
CAUTION - Risk of Pinching
When you change the desktop position (especially without using pinch protection), you must ensure that no people or objects are
located in the hazardous area nor may reach into it.
NOTICE - in case of a main power breakdown, or if the power cord is unplugged during the movement of the drives, a manual
reset may be necessary! Please see section 3.2.
NOTICE - The control unit might be damaged by power surges. Unplug the power cord during a thunderstorm or if you do not
intend to use the desk for a longer period.
3.1 Basic functions
NOTICE - You must read the user manual carefully before installing or operating the control unit.
Overload protection! If the total load on the equipment is to high you will only be able to drive for 2 seconds. The system will then
stop and you need to release the table from load before new drive. After load release, press button again.
Overheat protection! If heavy loaded and driven continuously for a long period of time the motor might get overheated. The
software observes this and if overheated system will shut down and you will have to wait about 9 minutes before being able to run
again.
Anti Collision “AC” (optional)! The ECS+ can be equipped with intelligent software for pinch protection. If a collision is detected
system will stop and back o about 1 inch.
IMPORTANT! Make sure to remove the blocking item causing the pinch before trying to operate the table again. Failure to do so may
cause injury to user or equipment.
During low ration the currents to each connected motor is continuously measured and any variation of current is evaluated about 50
times each second.

PHATB460 HANDSET DISPLAY INSTRUCTIONS
Settings
By pressing Up and Down buttons simultaneously you
enter the Settings menu.
You are now able to step between the Settings menu with the
Up and Down button.
To exit the menu, just step all the way down by pressing the
Down button a number of steps.
The Settings menu have the following steps in this order:
Err
ECS
SOF
rES
SL
SU
CAL
Un – Settings menu entry level
Exit
To enter a menu, press Up and Down button
simultaneously.
To adjust value, press Up or Down button.
To save and/or exit setting, press Up and
Down buttons simultaneously.
Mount the Handset
Use the 2 attached screws for fixing to the table top. If the
thickness of the table top is less than 3/4 inch (18mm) please
use shorter screws.
Start Up
Initial display communication “view.” Under normal condition the
display automatically shows the layout as below in 2 to 5 sec.
If the system is in reset mode the reset icon will be visible.
In that case, press the Down button until the symbol goes away.
ECS
ECS for ECS Software, will show the software version of the
ECS box. Version is shown as Year and Week. Y.W.
Press Up and Down buttons simultaneously to enter
the Settings menu. Press Up button until you reach ECS.
To enter, press Up and Down buttons simultaneously.
The version of the software is now shown on the display.
To exit setting, press Up and Down buttons
simultaneously.
Connect the handset
Connect the cable to the ECS+ box.
Error Codes
1. Hard stop
2. Back o
3. Soft stop
4. Waiting for button
5. Waiting for button release
6. Motor lost
7. Overcurrent
8. Overheating. Thermometer flashing, wait 10 minutes
for motor cooling
9. Low voltage (under 16vdc)
10. High Voltage (over 40vdc)
11. Motors far apart /sync error
12. Destination above upper limit
13. Destination below lower limit
14. Internal error
15. Collision detected by sensor
This manual is a quick guide of the functionality for the PHATB460 Handset Display.
This handset is intended to be used with ECS+ control box only, included with the PHATB460.
Default error
code example
Error code 8,
flashing thermometer
Handset
9

Handset layout
Display layout
Explanation of the symbols.
Menu Mode Imperial, Inch
Memory Thermometer
Error Codes Metric, Centimeter
Reset
10 sec - sleep mode
The display will go to sleep mode after 10 sec of inactivity.
Er - Error Logs
Err for Error, will open error statistics menu, where you are
able to see the number of error situations encountered.
Press Up and Down buttons simultaneously to enter the
Settings menu. Press Up button until you reach Err.
To enter, press Up and Down button simultaneously.
Browse through the codes with the Up and Down
buttons.
LOH Leg Over Heat - a motor have been over- heated this
number of times
COH Card Over Heat - the ECS box have been overheated
this number of times
COL Collition detection - executed this number of times
tot Total adjusted distance
The error counter is stored in the ECS box, so it is not important
if this Display Handset have recently been attached to the
system or not.
SOF - Software
SOF for Software, will show the software version installed in the
handset. Version is shown as Year and Week. Y.W.
Press Up and Down buttons simultaneously to enter the
Settings menu. Press Up button until you reach SOF.
To enter, press Up and Down button simultaneously. The
version of the software is now shown on the display.
To exit setting, press Up and Down buttons
simultaneously.
rES - Reset
rES for Reset, will force the sytem into Reset mode.
Press Up and Down buttons simultaneously to enter the
Settings Menu. Press Up button until you reach rES.
To enter, press Up and Down buttons simultaneously.
Press the Down button and hold until the columns have
reached the lowest position.
CAL - Calibration
CAL for Calibration, you are able to adjust the height value in
the display to correspond to actual height of table top on this
particular setup.
Press Up and Down buttons simultaneously to enter the
Settings menu. Press Up button until you reach CAL.
To enter, press Up and Down buttons simultaneously.
When you are in calibration mode the height numbers flashes
and you are able to drive the value Up or Down until shown
height correspond to the actual heigth of the desk at that time.
To save and/or exit setting, press Up and Down buttons
simultaneously.
PHATB460 HANDSET DISPLAY INSTRUCTIONS
10
This manual is a quick guide of the functionality for the PHATB460 Handset Display.
This handset is intended to be used with ECS+ control box only, included with the PHATB460.

SU - Simple Memory Upper
SU for Simple Memory Upper. You are able to set a stored
Simple Memory for the Up button. The desk will stop at
this set height when driving upwards.
Press Up and Down buttons simultaneously to enter the
Settings menu. Press Up button until you reach SU.
To enter, press Up and Down buttons simultaneously.
When you are in SU mode the height numbers flashes and
your current Upper limit is shown on the display.
If you want to adjust the height, use the Up and Down
buttons to change the value.
To save and/or exit setting, press Up and Down buttons
simultaneously.
Shortcut Functionality
The system also have a shortcut functionality for setting
memory position and to enter reset mode.
Upper and Lower Limit
To store the current height as a Simple Memory, press
Up and Down buttons simultaneously 3 times in fast
sequence. This will show a S in the display.
You are now able to store this position as a Lower or Upper
limit by pressing one of the buttons.
Press Up button to store Upper limit or
Press Down button to store Lower limit.
Reset Mode
Press and hold Up and Down buttons simultaneously
for 8 seconds, this will initiate the Reset mode.
SL - Simple Memory Lower
SL for Simple Memory Lower. You are able to set a stored
Simple Memory for the Down button. The desk will stop at
this set height when driving downwards.
Press Up and Down buttons simultaneously to enter the
Settings menu. Press Up button until you reach SL.
To enter, press Up and Down buttons simultaneously.
When you are in SL mode the height numbers flashes and
your current Lower limit is shown on the display.
If you want to adjust the height, use the Up and Down
buttons to change the value.
To save and/or exit setting, press Up and Down buttons
simultaneously.
Un - Units
Un for Units, this is where you change preferred unit, cm or
Inch.
Press Up and Down buttons simultaneously to enter the
Settings menu.
To enter, press Up and Down buttons simultaneously.
Choose between the units with the Up and Down
buttons.
To save and/or exit setting, press Up and Down buttons
simultaneously.
PHATB460 HANDSET DISPLAY INSTRUCTIONS
11
This manual is a quick guide of the functionality for the PHATB460 Handset Display.
This handset is intended to be used with ECS+ control box only, included with the PHATB460.

FOLI MECHANISM WITH ECS+ — USER MANUAL
12
4 Maintenance & Repairs
4.1 Cleaning, Inspection and Storage
Clean the table frame by wiping it down with a microfiber cloth. Never use solvent or abrasive or corrosive compounds.
Products must be cleaned at regular intervals to remove dust and dirt and inspected for mechanical damage and normal
wear and tear. Worn-out parts must be replaced.
Unplug the power cord if you do not intend to use the desk for a longer period.
4.2 User Maintenance
Products are closed units and require no internal maintenance.
Columns must be inspected at attachment points, wires, piston rod, cabinet, and plugs, check that columns function
correctly.
• Inspect columns for loose connections and damaged plugs/wires.
• Inspect power supply for loose connections and damaged plugs/wires.
• The power supply and the handset is sealed and maintenance free.
4.3 Repairs
Check all screws and bolts after the first week of use and tighten screws and bolts where necessary to ensure safe operation
of the table.
If the table cannot be raised or lowered, check the cable connection between:
• the power supply and the outlet.
• the power supply and the control unit / ECS+.
• the handset and the control unit / ECS+.
• the columns/motors and the control unit /ECS+.
If the table still doesn’t operational, the control system may have triggered the overheating or duty cycle protection. Unplug
the power cable and
wait for at least 9 minutes and try again fore proceeding.
If a control unit is replaced, a manual reset is required. Follow these steps as section 3.2.
If the table is still not operational, please contact your vendor for further assistance.
The control system is equipped with safety features; the intermittency function and the overheating protection and memory
function
Overheat protection – The table will become inoperable if the overheating protection is triggered and will return to
operation automatically once the heat has dissipated suciently. If heavy loaded and driven continuously for a long period
of time the motor might get very hot. The software observes this and if overheated system will shut down and you will have
to wait about 9 minutes before being able to run again.
Memory function – The control system / ECS+ (each column) will retain information regarding the elevation of the table at
all times. This information will remain stored even in case of power failure or if the power cable is disconnected from the
power outlet.
Overload protection -If the total load on the equipment is to high you will only be able to drive for a short moment. The
system will then stop and you need to release the table from load. Press button again.
Anti collision (optional) The ECS+ can be equipped with an intelligent software pinch protection. During low ration the
currents to each connected motor is continuously measured and any variation of current is evaluated about 50 times each
second. If a collision is detected the system will stop and back o about 1 inch (25 mm).
IMPORTANT! Make sure to remove the blocking item causing the pinch before trying to operate the table again. Failure to
do so may cause injury to user or equipment.

FOLI MECHANISM WITH ECS+ — USER MANUAL
13
Soft start — Progressive acceleration allows for soft starts and stops.
Speed — the speed of the table varies with load.
4.4 Servicing of double-insulated products
In a double-insulated product, two systems of insulation are provided instead of grounding. No grounding means is
provided on a double-insulated product, nor is a means for grounding to be added to the product.
Servicing a double-insulated product requires extreme care and knowledge of the system, and is to be done only by
qualified service personnel.
Replacement parts for a double-insulated product must be identical to the parts they replace. A double insulated product is
marked with the words
”DOUBLE INSULATION” or ”DOUBLE INSULATED”. The symbol (square within a square) is also able to be marked on the
product.
