globalwater WS700 User manual

Global Water
800-876-1172 •globalw.com
- 1 -
Global Water
Instrumentation, Inc.
11390 Amalgam Way
Gold River, CA 95670
T: 800-876-1172
Int’l: [phone], F: [phone]
globalw.com
WS700 Sampler
01-455 02/12/06

Global Water
800-876-1172 •globalw.com
- 2 -
Table of Contents
I. WS700 Checklist •••••Page 3
II. Inspection ••••••3
III. Description ••••••4
IV. Installing the Water Sampler ••••5
V. Installing the Pickup Hose ••••5
VI. The Control Panel •••••6
VII. Composite Sampling •••••8
VIII. Discrete Sampling •••••8
IX. External Trigger mode •••••9
X. Specifications ••••••11
XI. Maintenance ••••••12
XII. Troubleshooting ••••••13
XIII. Warranty •••••••14
XIV. Appendix A: Sample Size vs. Head Height ••15
XV. Appendix B: Battery Life ••••16
XVI. Appendix C: Input and Output Connection ••16
XVII. Appendix D: Accessories ••••17
* Copyright ©Global Water Instrumentation, Inc. 2006

Global Water
800-876-1172 •globalw.com
- 3 -
Congratulations on your purchase of the Global Water WS700
Water Sampler. This instrument has been quality tested and approved for
accurate and reliable operation. We are confident that you will find the
WS700 to be a valuable asset for your applications. Should you require
assistance, our technical staff will be happy to help.
I. WS700 Checklist
a. WS700 Water Sampler
b. 12V Battery (Inside Enclosure)
c. Battery Cable
d. Battery Charger
e. Two Shorting Plugs
f. WS700 Manual
II. Inspection
The WS700 unit was carefully inspected and certified by Global Water’s Quality
Assurance Team before shipping. If any damage has occurred during shipping,
please notify Global Water Instrumentation, Inc. and file a claim with the carrier
involved.
Use the checklist to ensure that everything needed to operate the WS700 was
received.

Global Water
800-876-1172 •globalw.com
- 4 -
III. Description
The Global Water WS700 Sampler is designed specifically to meet a wide variety
of sampling requirements including industrial discharge, process control, water
and wastewater treatment plants, sewers, rivers and streams.
The WS700 Sampler can take individual “time weighted” composite samples, or it
can be set to take a full-bottle discrete or “Grab” sample. This is accomplished
with a Sample Size control having one position being reserved for “Full” bottle. A
Sample Interval control sets the time between individual composite samples and
has a provision for allowing the sampler to be triggered from external sources.
A Start Delay timer can be set to start sampling after a preset time. This allows
multiple samplers to be deployed in the field and have them turn on at the same
time. The delay can also be used to hold off sampling to let the water source
flush out debris or other contaminants.
After each sample, the pump will reverse for 15 seconds. This clears any debris
from the strainer at the end of the pickup hose and also empties water from the
hose so the next sample is not contaminated by the previous one.
Inputs are provided for triggering the sampler based on water level, a rain gauge
sensor or a signal from an external process controller or other monitoring device.
An output is also available for monitoring when the pump is taking samples, using
a data logger or similar recording device.
The WS700 Sampler is easily set up near industrial discharges or streams. It
can also be suspended in a manhole for sewer flow sampling. The sampler
consists of a rugged, rainproof and lockable carrying enclosure. The enclosure
houses a peristaltic sampling pump, sample bottle, a control panel, and a
rechargeable battery. A battery charger and sample pickup hoses are also
provided.

Global Water
800-876-1172 •globalw.com
- 5 -
IV. Installing the Water Sampler
a. The sampler should be placed upright (it will not work if placed on its back or
side).
b. Open the sampler and remove the battery charger from the unit. Store the
charger for later use.
c. To secure the sample bottle:
1. Screw the bottle cap/float switch onto the sample bottle
2. Place the bottle into the sampler enclosure
3. Insert the end of the peristaltic pump’s hose in the hole at the top of the
bottle cap
4. Plug the float switch lead into the jack on the front of the control panel
d. The sampling unit can be secured from vandalism and strong winds by one of
the following methods:
1. Mount unit on post and lock closed
2. Lock closed and chain handles to a solid structure (such as a tree, post, or
building)
3. Enclose and lock unit in a steel electrical box
e. Avoid drilling holes in the enclosure if possible. If holes must be drilled in the
enclosure avoid drilling through the control panel enclosure. Any holes drilled
through the enclosure must be sealed with some type of silicone glue to
prevent water from entering the case and causing equipment failure.
f. The unit is water resistant, not water proof. The unit must be located well
above the expected water level to continue to provide reliable service.
V. Installing the Pickup Hose
The pickup hose should be installed in a wastewater discharge channel or stream. The
pickup strainer should be submerged under water and should be situated to avoid
contact with the channel bottom.

Global Water
800-876-1172 •globalw.com
- 6 -
VI. The Control Panel
1. Pump.
2. Start Delay: This setting delays sampling by a preset amount of
time. If no delay is desired, set the control to zero. Only the first
sample taken by the pump is delayed, except as described later in
the section titled “External Trigger Mode”.
3. Sample Interval: Sets the time interval between composite samples.
The “External Trigger” position is reserved for using the Trigger and
Rain Sensor inputs to initiate sampling as described later in the
section titled “External Trigger Mode”.
4. Sample Size: Sets the size for a single composite sample. The
sample size settings are approximate and apply to a head height of
four feet. The switch position marked “Full” causes the pump to work
as a discrete sampler, filling the bottle full in one sample. Note: In
the Full position, the sampler will shut off the pump after one hour,
even if the bottle is not full.
5. Trigger In: This input works in “External Trigger” mode only, as
selected by the Sample Interval control. A signal from an external
device will cause a single sample to be taken according to the Size
control. The External Trigger mode is described in more detail later
in the section titled “External Trigger Mode”. Refer to the
Specifications section for details about the input pulse requirements.

Global Water
800-876-1172 •globalw.com
- 7 -
6. Pulse Out: This output sends a pulse to an optional recording or
monitoring device each time the pump starts, allowing the time of the
sample event to be recorded. Refer to the Specifications section for
details about the output pulse.
7. Status: This red LED indicates the status of the sampler. While the
sampler is waiting to be triggered, the light remains off. Once
triggered, the LED will blink once every two seconds while the Delay
or Interval timers are running and while the pump is operating. The
LED remains lit constantly when the sample bottle is full or if the
bottle switch is not plugged in.
8. Power: This turns the power to the sampler on and off. Turning the
switch off for one second resets all functions and timers.
9. Battery: Connect the battery here using the supplied battery cable.
10.Water Sensor: When an optional water sensor is plugged into this
jack, sampling will not begin until the presence of water is detected
(the Rain Sensor must also detect water). If this sensor input is not
being used, plug one of the two shorting plugs supplied with the
sampler into this jack. This input has no affect when triggering the
sampler using the Trigger Input in External Trigger mode.
11.Rain Sensor: When an optional water sensor is plugged into this
jack, sampling will not begin until the presence of water is detected,
usually in a rain gauge (the Water Sensor must also detect water). If
this sensor input is not being used, plug one of the two shorting
plugs supplied with the sampler into this jack. This input has no
affect when triggering the sampler using the Trigger Input in External
Trigger mode. This input can also be used to take individual
composite samples and is described in detail later in the section
titled “External Trigger Mode”.
12.Bottle Switch: The sample bottle float switch plugs into the control
panel here. For sampling to occur a float switch must be plugged in
and the bottle must not be full. If the Status LED remains lit all the
time, check this connection.
13.Test Pump: Pressing this button tests the operation of the pump.
This button will run the pump regardless of whether the bottle switch
is plugged in or not. The pump runs forward for as long as the
button is held down, then reverses for an equal amount of time or 15
seconds, which ever is less.

Global Water
800-876-1172 •globalw.com
- 8 -
VII. Composite Sampling
A composite sample is a series of smaller samples put into the same bottle, thus showing
an “average” sample over time. Set the Interval control to the desired time between
samples (do not select the External Trigger position). Set the Size control to the desired
sample size. Note that the sample size settings are approximate and apply to a head height
of four feet. For heights other than four feet, refer to the chart inside the front of the
sampler.
The sampler starts timing when both of the optional Rain and Water Sensors detect
moisture. If you do not have the optional water sensors or do not need them for your
application, defeat them by plugging one of the two shorting plugs supplied with the sampler
into their jack. If both inputs are defeated, the sampler starts up triggered when the power
switch is turned on. The Status LED starts blinking every 2 seconds once the sampler is
triggered.
The Start Delay timer begins running when the sampler is triggered by the Rain and Water
Sensors and the first sample is taken when the timer expires. If the Delay control is set to
zero, sampling begins immediately. The delay timer only applies to the first sample taken,
except as described later in the section titled “External Trigger Mode”. At the end of each
sample, the pump reverses for 15 seconds.
Sampling continues as Trigger-Delay-Sample-Reverse-Interval-Sample-Reverse-Interval-
Sample-Reverse … until the sample bottle is full. When the bottle is full, the Status LED
remains lit constantly.
VIII.Discrete Sampling
A discrete sample is a single sample put into the same bottle, thus being a sample at one
point in time. Set the Sample Size control to “Full”. Once started, the pump will continue to
run until the sample bottle if full.
As with composite sampling, the Start Delay timer begins when the sampler is trigger by the
Rain and Water Sensors and the first sample is taken when the timer expires. If the Delay
control is set to zero, sampling begins immediately. The Status LED blinks every 2 seconds
while the delay timer or the pump is running and remains lit constantly once the sample
bottle has been filled. At the end of sampling, the pump reverses for 15 seconds.

Global Water
800-876-1172 •globalw.com
- 9 -
IX. External Trigger Mode
When the Sample Interval control is set to the “External Trigger” position, the sampler can
be triggered externally by either the Trigger In jack or the Rain Sensor input. This mode is
useful in applications where sampling occurs based on readings from a process controller,
SCADA system, flow monitor, auto-dumping rain gauge or other remote monitoring devices.
Using the Rain Sensor as a trigger source:
This mode is normally used with an auto-dumping rain gauge that empties itself every 24
hours. Set the Sample Interval control to External Trigger. Set each pumps Size control
based on desired composite sample size or set to Full for a discrete sample.
The sampler will be triggered when both the Rain and Water Sensors detect moisture. If the
Water Sensor is not needed, use one of the shorting plugs supplied with the sampler to
defeat it by plugging it into the Water Sensor input jack. Place the Rain Sensor at the
desired height in the rain gauge. When the Rain Sensor detects moisture, the sampler will
start.
Once triggered by the Rain Sensor, the Start Delay timer begins running and the Status
LED begins blinking every 2 seconds. When the timer expires, the pump takes a sample
based on the Sample Size settings. When the sample is complete, the pump reverses for
15 seconds, then stops. The sampler cannot be re-triggered until the rain gauge empties
itself and the Rain Sensor goes dry. The next time the sensor detects moisture, the Start
Delay timer will start over again and another sample will be taken when it expires.
If the pump’s Sample Size control is set to take a full-bottle discrete sample, further triggers
will have no affect. If the pump is set to take composite samples, each one will represent
the conditions at the time of that “qualified rain event”. This process will continue until the
sample bottle is full and the Status LED remains lit all the time.
Using the Trigger Input as a source:
This input is generally used for connecting to a flow monitor, processor controller, or other
external monitoring device.
When using the Trigger In input jack, leave the Rain Sensor input jack disconnected.
Upon being triggered by the Trigger Input, the Start Delay timer begins running. When the
delay timer has expired, the pump takes a sample based on the Sample Size setting.

Global Water
800-876-1172 •globalw.com
- 10 -
Holding the Trigger Input active past the end of the sample will cause the pump to continue
until the Trigger Input is released. When the sample is complete, the pump reverses, then
stops.
Flow Proportional Sampling
a. To set the WS700 up to take flow proportional samples, a flow monitor must
be attached to the control panel. In this configuration, the sampler is
designed to take a sample every time a specific amount of flow has passed
through the flow monitor.
b. The flow monitor must provide a momentary switch closure (250ms or longer)
or a pulse of 4-30VDC, whenever a sample is to be taken. The output of the
flow monitor must be wired to a 2-wire RCA jack as shown in Appendix C.
The phone plug is then inserted into the Trigger In jack on the control panel.
c. Set the Sample Interval knob to External Trigger mode and the Sample Size
knob to the desired sample size. The sample will be taken, flow
proportionally, as directed by the flow meter.
