Globe SP10 User manual

Instruction Manual for Globe Mixers
Models SP10, SP20, SP25, SP30, SP30P,
SP40, SP60, SP62P, and SP80PL
Model SP20
For Service on Your Mixer:
1. Visit our website at www.globeslicers.com
(select the Parts / Support drop down).
2. Or call the Globe Service Department at 937-299-8625 and ask for contact
information for your local service company.
Model #:
Serial #:
Visit our website for information on additional products available from Globe.
www.globeslicers.com
Slicers, Mixers, Countertop Cooking Equipment, Meat Choppers & Scales
This manual contains important safety instructions which
must be strictly followed when using this equipment.
- IMPORTANT SAFETY NOTICE -

Page 3
ATTENTION OWNERS AND OPERATORS................................................................................................................4
KEY COMPONENTS OF THE MIXER ........................................................................................................................5
INSTALLATION ....................................................................................................................................................... 6-7
OPERATING INSTRUCTIONS.............................................................................................................................. 7-14
CLEANING INSTRUCTIONS ....................................................................................................................................15
IMPORTANT POINTS ...............................................................................................................................................16
RECOMMENDED MAINTENANCE ..........................................................................................................................16
CAPACITY CHART....................................................................................................................................................17
TROUBLESHOOTING ........................................................................................................................................ 18-19
LIMITED MIXER WARRANTY...................................................................................................................................20
GLOBE FOOD EQUIPMENT COMPANY
2153 DRYDEN RD.
DAYTON, OH 45439
PHONE: [phone]
TOLL FREE: 800-347-5423
FAX: [phone]
E-MAIL: [email protected]
WEBSITE: www.globeslicers.com
© Globe Food Equipment Company, 2013 12062012/05102013
Ver. 1 Rev. 3_2012
Index

Page 4
Globe’s equipment is designed to provide safe and productive processing of food products as long as the equipment is
used in accordance with the instructions in this manual and is properly maintained. Unless the operator is adequately
trained and supervised there is a possibility of serious injury. Owners of this equipment bear the responsibility to
make certain that this equipment is used properly and safely, and to strictly follow all of the instructions contained in
this manual and the requirements of local, state or federal law.
Owners should not permit anyone to touch this equipment unless they are 18 years of age or older, are adequately
trained and supervised, and have read and understood this manual. Owners should also ensure that no customers,
visitors or other unauthorized personnel come in contact with this equipment. Please remember that Globe cannot
anticipate every circumstance or environment in which its equipment will be operated. It is the responsibility of the
owner and the operator to remain alert to any hazards posed by the function of this equipment. If you are ever uncertain
about a particular task or the proper method of operating this equipment, ask your supervisor.
This manual contains a number of precautions to follow to help promote safe use of this equipment. Throughout the
manual you will see additional warnings to help alert you to potential hazards.
Warnings affecting your personal safety are indicated by:
Warnings related to possible damage to the equipment are indicated by:
Globe has put several warning labels in the English language on its mixers. French labels are also available
and can replace the English labels at the owner’s discretion. If the warning labels or this manual are misplaced,
damaged, or illegible, or if you require additional copies, please contact your nearest representative or Globe
directly for these items at no charge.
Please remember that this manual and the warning labels DO NOT replace the need to be alert, to properly train
and supervise operators, and to use common sense when using this equipment.
Attention Owners and Operators
or

Page 5
Key Components of the Mixer
SP20 FRONT VIEW
SP20 SIDE VIEW
Minute Up/
Down Controls
Start Button
Stop Button
Attachment Hub
Planetary Grease Fitting
Planetary Shaft
Bowl Handle
Bowl Clamp
Speed Control
Bowl Guard
Built in Ingredient Chute
Bowl
Rubber Feet
Digital Timer Display
Seconds Up/Down Controls
Attachment Hub
Thumbscrew
Bowl Lift Lever
Bowl Guard Handle
Splash Guard
Bowl Cradle
Bowl Slides
Power Cord
Bowl Lift Wheel
(Models SP40 and
SP60)
Gear Oil Meter
(Models SP62P
and SP80PL)
Power Bowl Lift, Mode &
Timer Controls
(Models SP62P and
SP80PL)

Page 6
Installation
UNPACKING
Unpack the mixer immediately after receipt. If the machine is found to be damaged, save the packaging material
and contact the carrier within fteen (15) days of delivery. Immediately contact your source of the equipment.
You have no recourse for damage after fteen (15) days.
TO AVOID SERIOUS PERSONAL INJURY:
• ALWAYS install equipment in work area with adequate light and space.
• ONLY operate the mixer on a solid, LEVEL, non-skid surface that is nonammable.
• NEVER bypass, alter, or modify this equipment in any way from its original condition. Doing so may create
hazards and will void the warranty.
• NEVER operate the mixer without all warnings attached to it.
• DO NOT attempt to lift the mixer alone.
INSTALLATION
1. Read this manual thoroughly before installation and operation. DO NOT proceed with installation and
operation if you have any questions or do not understand anything in this manual. Contact your local
representative or Globe rst.
2. Remove the corrugated box from the skid by removing the bands on the box. NOTE: The SP62P and SP80PL
are shipped in a wooden crate; only the bolts at the bottom of the crate (all four sides) need to be removed.
3. Carefully unbolt the mixer from the skid using an 11/16'' or 3/4'' wrench.
4. Select a location for the mixer keeping these points in mind:
• Floor or counter must be level.
• Easy access for maintenance and service.
• Clearance for operating controls, installing and removing agitators, bowl, or attachments.
• Sufcient space for adding ingredients during mixing periods.
• Ensure rear ventilation outlet of mixer is not blocked.
5. Use at least two other people to tilt the unit and install the rubber feet.
6. A bolt down template and bolts are available for the SP10, SP20, or SP25. Contact Globe if needed.
7. Inspect the mixer to ensure all parts have been provided (i.e. bowl, beater, whip, and dough hook). The SP62P
only has a bowl, dough hook, and bowl truck.
8. Read the electrical information found on the data plate located at the rear of the machine. The incoming
power should match the rating on the data plate.
CONNECTING TO ELECTRICAL POWER
Cord Connected Units: This machine is provided with a three-prong grounding plug. The outlet that
this plug is connected to must be properly grounded. If the receptacle is not the proper grounding type,
contact an electrician. Do not under any circumstances cut or remove the third ground prong from the
power cord or use any adapter plug. Never use an extension cord. Low power supply could damage the
mixer or cause a re.

Page 7
Installation
CONNECTING TO ELECTRICAL POWER cont’d.
If the unit needs to be hard-wired, have a licensed electrician connect the unit to the power supply.
Three Phase Units:
You must conrm proper rotation of all 3 phase mixers prior to using the mixer. There
is a 50% chance your 3 phase mixer is properly rotating if you are using it on 3 phase
power.
1. Make sure there is not a mixing tool on the mixer shaft and the bowl is empty.
2. Put the speed lever on one speed and turn the unit on.
3. Make sure the large, gray planetary casting is going in the direction of the arrow on
the mixer as you stand in front of the mixer (clockwise). (Do not pay attention to the
shaft rotation.) If it is traveling in the wrong direction, have a licensed electrician switch
the electrical connection and retest.
9. Complete and register the warranty information online at www.globeslicers.com/warranty.asp.
10. Clean the mixer prior to using it. Follow the cleaning instructions starting on page 14.
NOTE: It is normal for the factory to apply a generous amount of grease in and on the machine.
Excess grease (brown in color) will be on all metal surfaces (e.g. top portion of bowl guard, speed control,
bowl clamps, bowl lift lever, and attachment hub thumbscrew). Excess high-pressured grease
(brownish-black) may also be found on the planetary shaft and some drippings may be found in the bowl.
Operating Instructions
TO AVOID SERIOUS PERSONAL INJURY:
• DO NOT operate the mixer before reading the instruction manual rst.
• ALWAYS disconnect or unplug electrical power before cleaning, servicing, or
adjusting any parts or attachments.
• ALWAYS keep hands, hair, and clothing away from moving parts.
ABOUT THE REMOVABLE BOWL GUARD (if applicable)
The bowl guard can be rotated or removed to accommodate the operator’s function. The interlocking bowl guard is
easy to remove and reattach for easy cleaning in a sink or dishwasher.
NOTE: When guard is open or not properly installed, the mixer will not operate.
NOTE: Rotate the bowl guard clockwise (open) and counterclockwise (closed) to
attach agitators to the mixer.
Opening / Rotating the Bowl Guard:
Rotating the bowl guard clockwise (open) and counterclockwise (closed), allows the
operator to easily add ingredients and properly remove the agitator and bowl from the
mixer.
1. When the separated handles are lined up together and pushed securely to the right
of the mixer, the bowl guard is in the locked position and ready to operate (g. 7-1)
g. 7-1

Page 8
Operating Instructions
2. To rotate the bowl guard to its open position, grasp the separated handles on the bowl guard and move them,
together as one, clockwise to open/rotate the bowl guard. To close the bowl guard, grasp the separated
handles and move them together as one, counterclockwise to close/rotate the bowl guard back into a locked
position.
Removing and Attaching the Bowl Guard:
NOTE: Before removing or attaching the bowl guard, make sure the bowl is in the down/
lowered position and the agitator tool is off the shaft.
1. To remove the bowl guard for cleaning, push the lower part of the separated handle
out (clockwise) dividing the handle and releasing the guard from the rotation ring.
(see g. 8-1)
2. Once separated, take hold of the lower separated handle and continue turning the
guard clockwise until the bowl guard releases from the ring catch on the mixer.
(see g. 8-2)
3. To reattach the bowl guard, line up the ring catch on the left of the mixer; lift
guard gently into place and rotate the guard’s lower handle counterclockwise
until it snaps back into place with the upper part of the handle.
ATTACHING THE BOWL TO THE MIXER
NOTE: Install the bowl BEFORE attaching the agitator.
1. Lower the bowl by pulling the bowl lift lever forward and down to its resting
position. For models SP40 and SP60 rotate the bowl lift wheel
counterclockwise until it stops. For the SP62P and SP80PL press the down
arrow (blue button) to lower the bowl until it stops.
2. Lift the bowl by the bowl handles and:
a. slowly position the locking pin (located on the rear of the bowl) into the hole in the
middle rear of the cradle (see g 8-3).
b. lower the bowl onto the pins located on either side of the bowl cradle.
3. Once the bowl is positioned on the cradle, secure the bowl by pulling each bowl clamp
forward until the bowl is locked tight (see g 8-4).
g. 8-1
g. 8-2
g. 8-3 g. 8-4

Page 9
Operating Instructions
ATTACHING THE AGITATOR TO THE MIXER (i.e., Beater, Hook, Whip)
NOTE: It is easier to install the agitator prior to adding the ingredients into the bowl.
1. Rotate the bowl guard to the left so it rests in the open position (see g 9-1).
Excessive force used to open and close the bowl guard may damage the
spring lock and bowl guard microswitch, and will void the warranty.
2. Slide the agitator slowly upwards onto the planetary shaft, tting the shaft pin through the
slot in the agitator (see g 9-2).
3. Rotate the agitator clockwise to secure it onto the planetary shaft.
MIXING INGREDIENTS
Follow the capacity chart located on page 17 in this manual.
Overloading or not following this chart will damage the mixer and void
the warranty.
Agitators should always rotate in a counterclockwise direction around the bowl.
If the agitator moves clockwise, contact a licensed electrician immediately to remedy
incorrect wiring.
IMPORTANT: Make sure the speed control lever is on the rst (1) speed.
1. Add the appropriate mixing ingredients into the bowl.
2. Rotate the bowl lift lever up until the bowl locks into position. On the SP40 and SP60
rotate the bowl lift wheel clockwise until the bowl is all the way up into position. For the
SP62P and SP80PL press the up arrow (blue button) until the bowl is up into position.
3. Rotate the bowl guard to the right until it locks into the closed position (see g 9-3).
You will hear it ‘clicking’ into place.
NOTE: The mixer will not start if the bowl guard is open or the bowl is in the lowered position.
Before ‘Starting’ the mixer: Always change to the desired speed BEFORE ‘Starting’
the mixer! Failure to do so may damage the gears or other parts and WILL void the
warranty!
SETTING and CHANGING THE SPEED
4. Select the appropriate speed setting by lifting or lowering the speed control lever. Three xed speeds are
available for use: rst (1), second (2), and third (3). NOTE: The SP62P has two speeds and the SP80PL has
four xed speeds.
Gear Speed Product Type/Ingredient
1 (low) Heavy: mixing pizza, bread, pasta and donut doughs, wafe/cake batter, mashing potatoes
2 (medium) Medium: 2nd stage of mixing for donut dough, etc.
3 (high) Light: whipping cream, egg whites, meringue
IMPORTANT: When mixing product always follow the recommended agitator and speed setting according
to the capacity chart located on page 17 of this manual.
5. Press the green start button to begin mixing.
g. 9-2
g. 9-1
g. 9-3

Page 10
Operating Instructions
Always STOP the mixer BEFORE changing speeds! Failure to do so may damage the
gears or other parts and WILL void the warranty!
6. To change the speed while mixing:
a. press the red stop button, then wait for the agitator to come to a complete stop.
b. change the speed by raising or lowering the speed control lever
c. press the green start button to restart the mixer
NOTE: The SP62P and SP80PL will automatically shut off if the speed is changed while the mixer is in operation.
NOTE: The mixer is equipped with a motor overload protection. If the mixer shuts off during operation, reduce the
batch size and:
a. SP25 and smaller models: Press the stop button then press the overload reset button located
on the back of the mixer.
b. Larger models: Wait two minutes then press the ‘Start” button on the control panel.
NOTE: 2nd speed should never be used on 50% AR or lower with the exception of the SP60. The SP60
requires a 50% reduction in batch size to mix in speed 2 with 50% AR doughs.
NOTE: Reduce batch size by 10% if chilled our, water below 70°F, ice, or high gluten our is used.
IMPORTANT: For heavier loads, the mixer should not run longer than fteen minutes without
pausing for a cool down period of at least fteen minutes or more before resuming mixing.
For lighter loads, the mixer should not run longer than thirty minutes without pausing for a
cool down period of at least thirty minutes or more before resuming mixing.
7. When the ingredients have been thoroughly mixed, press the red stop button to stop the mixer.
NOTE: If the timer was used, the mixer will automatically stop when the time has expired.
8. Lower the bowl by pulling the bowl lift lever forward and down to its resting position. For models SP40 and
SP60, rotate the bowl lift wheel counterclockwise until it stops. For models SP62P and SP80PL, press the
down arrow (blue button) until the bowl stops.
9. Rotate the bowl guard to the left so it is in the open position.
10. Remove the agitator from the planetary shaft by lifting it upwards, then rotating it counterclockwise until it is
unlocked. Lower the agitator and remove from planetary shaft.
11. Push each bowl clamp backwards to unlock the bowl from the bowl cradle.
12. Lift up slightly on the bowl so it clears the pins on the bowl cradle.
Most batches are heavy. Always use two people to remove and transport the loaded
bowl after mixing is complete. A bowl truck is included with the SP60, SP62P and
SP80PL models and should be used to unload bowls containing more than 50 lbs.
per batch.

Page 11
Operating Instructions
Before ‘Starting’ the mixer: Always change speeds BEFORE Starting the Mixer! Failure
to do so may damage the gears or other parts and WILL void the warranty!
USING THE MIXER’S DIGITAL CONTROLS AND TIMER
SP62P and SP80PL mixer owners only: read through this section and continue to page 13 for further
operating instructions for use of the digital controls on your mixer.
The mixer is equipped with a digital timer display, minutes and seconds buttons (to adjust the timed operations)
and Start / Stop buttons. The mixer can function in either timed operation or untimed operation.
Untimed Operation: For simple on/off mixing operation in a untimed operating mode, verify that the bowl guard
and bowl lift are closed and locked into position.
- The display should read 00:00 to operate in untimed mode. Pressing the ‘Stop’ button twice within one
second will reset the timer back to zero.
- Press the ‘Start’ button to begin mixing. The display will scroll zeros across the display from left to right while
mixing. Press the ‘Stop’ button once the desired mixing is complete.
Timed Operation: The timer on the mixer can be set from 5 seconds to 60 minutes.
1. Set desired time. Minutes advance by one and seconds advance by ves before rolling over to zero.
NOTE: Press and continuously hold the up arrow buttons to the desired minutes and seconds. Press and
continuously hold of the button scrolls through the number cycles quickly. (To slow down the selection and to better
control the setting time, press the up or down arrow button (Do not continuously hold the button down).
2. Once the desired time is set, verify that the bowl guard and bowl lift are closed and locked into position,
and then press ‘Start’.
3. Wait for the timed cycle to end or press ‘Stop’ to pause the mixing cycle.
- Pressing the ‘Stop’ button once stops the mixer and pauses the timer during operation.
- Pressing the ‘Stop’ button once while the mixer is not in operation will reset the timer to the
last programed/set time.
- Double clicking the ‘Stop’ button twice within one second while the mixer is not in operation
will resets the timer back to zero (00:00).
NOTE: If a cycle is interrupted by the bowl guard being opened or by lowering the bowl lift lever, the mixer will
stop. As soon as the fault is corrected, the “Start” button can be pressed to continue the programmed time.
To add additional minutes or seconds to a mix time, “Stop” the mixer, and adjust the cycle mixing time.
4. Once a timed cycle ends, the mixer will beep for 5 seconds and the digital display will ash for two
minutes if not reset indicating the timed cycle is complete.

Page 12
Operating Instructions
HOW TO USE THE ATTACHMENT HUB
Never put your hand into the feed chute when using any mixer attachment.
Only operate the attachment hub in MANUAL mode.
DO NOT attempt to mix ingredients in the bowl while using the hub.
The mixer must be OFF before installing attachments! Do NOT use attachments while mixing!
1. Loosen and remove the attachment hub thumbscrew (see g 12-1).
2. Remove the plastic cover from the attachment hub (see g 12-1).
3. Lubricate the attachment shaft with a food quality grease or mineral oil.
4. Insert the attachment shaft into the hub making sure to line up the alignment pin with
the hub hole.
5. Tighten the thumbscrew back into the hub and securely tighten it.
6. Select the appropriate speed setting by lifting or lowering the speed control lever.
Recommended Speed while using attachments:
Attachment Recommended Speed
Vegetable Slicer 1 or 2
Cheese Shredder/Grater 1 or 2
Meat Grinder 1 only
NOTE: Make sure the bowl is up and the bowl guard is closed. The mixer will not start if the bowl and the
bowl guard are not in the proper operating position.
7. Adjust the timer using the untimed operation described on the previous page.
8. Press the green start button located on the control panel.
Always STOP the mixer BEFORE changing speeds! Failure to do so may damage the
gears or other parts and WILL void the warranty!
9. To change the speed while using mixer attachments:
a. press the red stop button, then wait for the agitator to come to a complete stop.
b. change the speed by raising or lowering the speed control lever
c. press the green start button to restart the mixer
NOTE: The SP62P and SP80PL will automatically shut off if
the speeds are changed while the mixer is in operation.
Plastic Cover
Thumbscrew
g. 12-1

Page 13
Operating Instructions
SP62P AND SP80PL DIGITAL CONTROL INSTRUCTIONS
Untimed / Manual Mode instructions and controls for the SP62P and SP80PL
The mixer must be OFF before installing attachments! Do NOT use attachments while mixing!
NOTE: Make sure the bowl is up and the bowl guard is closed. The mixer will not start if the bowl and the bowl guard
are not in the proper operating position.
Press the BOWL “Up” arrow to activate the power bowl lift.
Set the speed control to the desired speed.
Untimed - MANUAL MODE
1. To begin operation of the mixer in Manual mode, press
the “MAN” button. The display will illuminate a small
dot of light in the lower right-hand corner of the seconds
timer display.
NOTE: Mixer will not start if bowl is not all the way up.
Additionally, the bowl guard must be completely closed.
2. Press the “Start” button to begin mixing. Press “Stop” to
discontinue mixing.
Always STOP the mixer BEFORE changing speeds!
NOTE: The SP62P and SP80PL will automatically shut off if
the speeds are changed while the mixer is in operation.
NOTE: The timer does not work in Manual Mode.
To use the timer feature, follow the Timer Mode instructions.
TIMER MODE
1. To begin operating the mixer in TIMER mode, press
the TIMER button.
If starting mixer for the rst time, or if power is lost, the
TIMER display will only illuminate in all zeros “0”; otherwise,
it will display the last mixing time that was entered.
2. Select the number of minutes and seconds by using the up
and down arrows located under the timer digital display.
The rst set of up-down arrow buttons controls the minutes
and the second set of up/down arrow buttons controls
the seconds.
Press and continuously hold the up arrow buttons to the desired minutes and seconds. Press and continuously
hold of the button scrolls through the number cycles quickly. (To slow down the selection and to better control the
setting time, press the up or down arrow button (Do not continuously hold the button down).
3. Once the desired mix time has been set on the timer, press the “Start” button to begin mixing.
Always STOP the mixer BEFORE changing speeds!
NOTE: The SP62P and SP80PL will automatically shut off if the speeds are changed while the mixer is in operation.
11
2
2
12

Page 14
4. Once the “Start” button has been pressed, the mixer timer numbers will begin to descend.
The timer and mixer can be interrupted at any time by pressing the “Stop” button. If the timer cycle is interrupted and
the mixer has not yet nished its set mixing time, the mixing cycle can be continued from where it left off by pressing
the “Start” button.
NOTE: If a cycle is interrupted by the bowl guard being opened or the speed of the mixer being changed, the mixer
will stop. As soon as the fault is corrected, the “Start” button can be pressed to continue the programmed time.
To add additional minutes or seconds to a mix time, “Stop” the mixer, press “TIMER” and adjust the cycle mixing time.
Press the “Start” button to begin mixing once again.
5. At the end of a timed mixing cycle the timer will count down to “00” minutes and “00” seconds, the mixer will stop,
and the timer will return to displaying the last mix cycle time that was entered.
6. To begin another mix cycle with the same set time as the previous mix, press the “Start” button.
If the mix cycle time needs to be adjusted up or down, set the new desired time and then press the “Start” button
to begin mixing.
The mixer timer will always reset back to the last mix time that was set unless the plug or power is disconnected to the
mixer. If power is lost to the mixer, the mixing time will need to be reset to the desired time.
3
Operating Instructions

Page 15
• Dilute detergent per supplier’s instruction.
• DO NOT hose down or pressure wash any part of the mixer.
• NEVER use a scrubber pad, steel wool, or abrasive material to clean the mixer.
• NEVER use bleach (sodium hypochlorite) or bleach-based cleaner.
• ALWAYS remove the agitator after each batch as the agitator can become stuck on the shaft and become
difcult to remove.
The entire mixer, including removable parts, must be thoroughly cleaned and sanitized using the
procedures identied by your local health department and the ServSafe Essentials published by the
National Restaurant Association Educational Foundation (NRAEF). Visit www.servsafe.com for
more details.
It is extremely important to sanitize the mixer and to follow the instructions on the quaternary
sanitizer container to ensure proper sanitation is achieved.
ALWAYS DISCONNECT OR UNPLUG THE ELECTRICAL POWER FROM THE MIXER BEFORE
CLEANING.
RECOMMENDED CLEANING
PART REQUIRED ACTION FREQUENCY
Agitators Hand-wash using mild soap and water, rinse, dry and
sanitize.
Clean after each use.
Removable Bowl Guard Hand-wash using mild soap and water, rinse, dry and
sanitize or place in dishwasher.
Clean after each use.
Bowl Using a sponge or cloth, mild soap and water, apply
pressure to ensure the bowl is clean, rinse, dry, and
sanitize. The bowl can also be placed in a dishwasher.
Clean after each use.
Rear Splash Guard Hand-wash using mild soap and water, rinse, dry and
sanitize.
Clean after each use.
Bowl Cradle Hand-wash using mild soap and water, rinse, dry and
sanitize.
Daily
Planetary Shaft Wipe with clean damp cloth, dry and sanitize. Apply a light
quantity of Globe oil (mineral oil) to the planetary shaft after
cleaning.
Clean after each use.
Exterior Hand-wash using mild soap and water, rinse, dry, and
sanitize. DO NOT use a water hose!
Daily
Hub Interior Wipe with clean damp cloth, dry, and sanitize. Daily
Cleaning Instructions

Page 16
Your new Globe mixer will provide years of uninterrupted service, but only if you do the following:
Installation
• Do not use an extension cord to connect electrical power.
• Make sure all 3 Phase units (see data plate) run in the direction of the arrow on front of the machine.
Operation
• Turn off the mixer prior to changing speeds.
• Follow the capacity chart on page 17, especially for mixing dough.
• Use only rst (1) speed for mixing dough. 2nd speed should never be used on 50% AR or lower with the
exception of the SP60. The SP60 requires a 50% reduction in batch size to mix in speed 2 with 50% AR
dough.
• If the unit shuts off during mixing (overload protection trips), reduce the batch size.
Maintenance
• Add only 2 pumps of grease to the planetary grease tting once a year.
Important Points
Recommended Maintenance
PART REQUIRED ACTION FREQUENCY
Planetary Ring Reapply grease (e.g. black axle grease). Once a year.
Inject grease (2 pumps only) into zerk tting
on the side of planetary. DO NOT overll!
Bowl Slide Rods Apply Globe oil (mineral oil) on the bowl slide rods. If the bowl becomes difcult to
Raise and lower the bowl to distribute the oil onto raise or lower.
the rods.
Gear Oil Meter Contact a Globe authorized servicer to change the Once a year. When the gear oil
(SP62P and gear oil. meter shows the oil being below
SP80PL only) half of the circle.

Page 17
Capacity Chart
The following maximum capacities are intended as a guideline only. Varying factors such as the type of our used,
temperature of water used and other conditions may require the batch to be reduced.
Product Agitator
and Speed
SP5 SP8 SP10 SP20 SP25 SP30/
SP30P
SP40 SP60 SP62P SP80PL
Wafe or Hotcake Batter Flat Beater 2 qts. 3 qts. 5 qts. 8 qts. 10 qts. 12 qts. 16 qts. 24 qts. ---- 30 qts.
Whipped Cream Wire Whip 2 qts. 2 qts. 2 qts. 4 qts. 5 qts. 6 qts. 9 qts. 12 qts. ---- 16 qts.
Mashed Potatoes Flat Beater 4 lbs. 4 lbs. 8 lbs. 15 lbs. 18 lbs. 23 lbs. 30 lbs. 40 lbs. ---- 50 lbs.
Egg Whites Wire Whip ¾ pts. ¾ pts. 1 pt. 1 qt. 1¼ qts. 1½ qts. 1¾ qts. 2 qts. ---- 2 qts.
Meringue
(Qty. of Water)
Wire Whip ¼ pts. ½ pts. ¾ pts. 1½ pts. 1¾ pts. 1 qt. 1¼ qts. 1¾ qts. ---- 3 qts.
Raised Donut Dough
(65% AR) *
Dough Hook
1st and 2nd
2 lbs. 2 lbs. 4½ lbs. 9 lbs. 12 lbs. 15 lbs./
20 lbs.
25 lbs. 60 lbs. 75 lbs. 80 lbs.
Heavy Bread Dough
(55% AR) *•
Dough Hook
1st only
4 lbs. 3 lbs. 7½ lbs. 15 lbs. 20 lbs. 30 lbs./
35 lbs.
40 lbs. 70 lbs. 75 lbs. 80 lbs.
Bread and Roll Dough
(60% AR) *•
Dough Hook
1st only
5 lbs. 5 lbs. 12½ lbs. 25 lbs. 25 lbs. 45 lbs. 60 lbs. 80 lbs. 90 lbs. 90 lbs.
Pizza Dough, Thin
(40% AR) *•
Dough Hook
1st only
3 lbs. 2 lbs. 5 lbs. 9 lbs. 12 lbs. 16 lbs./
25 lbs.
30 lbs. 40 lbs. (1st) 50 lbs.
35 lbs. (2nd)
50 lbs.
Pizza Dough, Medium
(50% AR) *•
Dough Hook
1st only
4 lbs. 4 lbs. 5 lbs 10 lbs. 15 lbs. 25 lbs./
36 lbs.
40 lbs. 70 lbs. (1st)
35 lbs. (2nd)
80 lbs. (1st)
60 lbs. (2nd)
90 lbs.
Pizza Dough, Thick
(60% AR) *•
Dough Hook
1st only
5 lbs. 5 lbs. 10 lbs 20 lbs. 25 lbs. 40 lbs./
45 lbs.
50 lbs. 70 lbs. 90 lbs. 100 lbs.
Fondant Icing Flat Beater 4 lbs. 3 lbs. 6 lbs 12 lbs. 15 lbs. 18 lbs. 25 lbs. 36 lbs. ---- 60 lbs.
Cake Flat Beater 5 lbs. 6 lbs. 10 lbs. 20 lbs. 25 lbs. 30 lbs. 40 lbs. 60 lbs. ---- 90 lbs.
Pie Dough Flat Beater 5 lbs. 4 lbs. 10 lbs. 18 lbs. 22 lbs. 27 lbs. 35 lbs. 50 lbs. 60 lbs. 70 lbs.
Pasta, Basic Egg Noodle Dough Hook 1 lb. 2 lbs. 3 lbs. 5 lbs. 6 lbs. 8 lbs./
15 lbs.
17 lbs. 35 lbs. 40 lbs. 50 lbs.
* NOTE: The mixer capacity depends on the moisture content of the dough. When mixing dough (pizza, bread,
or bagels) check your AR%! %AR (% Absorption Ratio) = Water weight divided by our weight. The capacities
listed above are based on our at room temperature and 70°F water temperature. NOTE: 1 gallon of water
weighs 8.33 lbs.
Maximum Mixing Time - 7 Minutes
• If high gluten our is used, reduce the batch size by 10%.
If using chilled our, water below 70°F, or ice, reduce batch size by 10%.
2nd speed should never be used on 50% AR or lower with the exception of the SP60. The SP60 requires a
50% reduction in batch size to mix in speed 2 with 50% AR dough.
Do not use attachments on hub while mixing!

Page 18
Troubleshooting
Problem Possible Causes Action Required
Mixer will not operate Bowl guard not in closed position. Rotate guard to the right until fully
closed.
Bowl not raised. Raise bowl to highest position.
Power not connected properly. Check all power connections. Plug into a
live socket. (Do not use extension cord!)
Test socket with another item.
Building circuit breaker is off. Check breaker box.
Internal overload tripped. SP25 & smaller models: Press stop
button, then press reset button located on
the back of the mixer.
Larger models: Wait two minutes. then
press the ‘Start’ to restart the mixer.
(If overload continues to trip, reduce batch
size and/or adjust recipe!)
Gear not engaged. Switch gear fully into position. (Mixer will
not operate if the speed control lever is
positioned in between speeds)
Mixer stops during mixing cycle Internal overload tripped. SP25 & smaller models: Press stop
button, then press reset button located on
the back of the mixer.
Larger models: Wait two minutes. Wait
two minutes. then press the ‘Start’ to
restart the mixer.
(If overload continues to trip, reduce batch
size and/or adjust recipe!)
Damaged or broken transmission
belt.
Contact a technician to replace
belt.
Speeds were changed during mixing,
SP80PL only.
Return speed control lever to a speed
model position and restart the mixer.
Mixer is noisy Mixer is not installed on level surface. Adjust surface or relocate mixer. Make
sure rubber feet are installed.
Bowl not seated correctly or clamps
not in place.
Ensure bowl is seated into bowl cradle
correctly and bowl clamps are locked into
place.
Agitator not tted properly. Remove and attach agitator into position
properly.
Overloading bowl. Reduce batch size. (See Capacity Chart,
page 17)
Damaged or worn belt. Replace belt
Planetary ring gear needs more
grease.
Contact a technician to inspect for source
of noise. Reapply high-pressure grease.
Safety guard seized (will not
move freely).
Clean & lubricate slide sheath. Technician must drop down planetary
assembly to access mat & sheath.
Contact technician.
Agitators won’t go onto the
planetary shaft easily.
Lack of lubrication and/or cleaning of
the planetary shaft.
Wipe planetary shaft with a clean damp
cloth and lubricate the shaft with mineral
oil or food quality grease.
Display not lit. No power to unit Check power
Internal fuse blown Call for service

Page 19
Troubleshooting
Problem Possible Causes Action Required
Mixing time is too long Three-phase mixer is wired wrong Agitators should rotate clockwise
around bowl. If not, electrician must
rewire
Batch size too small Increase batch size or use smaller
bowl adapter kit. (Contact dealer for
purchase)
Incorrect recipe portions or
temperatures
Follow portions and temperatures per
recipe instructions
Bowl raise sticking or not operational Lack of lubrication on bowl slides Lubricate bowl slides with mineral
oil or food quality grease. If still
sticking, technician must clean bowl-
raise mechanism
One or more gears not working Broken belt Technician to replace belt
Damaged or broken gear Technician to replace gear. Always
stop mixer before shifting gears!
Mixer will not mix medium or heavy
loads.
Incorrect or low voltage Contact electrician
Belt slipping Technician to replace belt
Residue leaking from hub Contaminated hub due to build-up
of meat and/or vegetable juices
(especially tomatoes)
Technician to remove hub and clean
interior. To avoid problem, always
wipe hub and dry after each use.
*Note: Acid from tomato juices will
corrode/contaminate interior parts!
Don’t mix tomatoes in meat grinder!
Agitators touching bottom or sides of
bowl
Defective or dented bowl Remove dents or replace bowl
Defective agitator Replace agitator
Broken whip wires Batch size too large for mixer. Adjust
recipe.
Reduce batch size. (See Capacity
Chart, page 17) Mixture too rm,
speed too high. Reduce speed
Hand utensil dropped into bowl while
mixing
Stop mixer before working on mixture
Broken at beater Ingredients too cold or too large
(e.g. frozen butter, cream cheese cut
in chunks)
Wait for ingredients to reach
room temperature before
mixing. Reduce chunk size
Broken dough hook Batch size too large for mixer Reduce batch size. (See Capacity
Chart, page 17) Adjust recipe
Ingredients too cold or too large Wait for ingredients to reach room
temperature before mixing. Reduce
chunk size
Mixture climbs up dough hook Three-phase mixer is wired
incorrectly
Electrician to rewire
Discoloration of mixed product Bowl has not been thoroughly
cleaned
Clean bowl again (refer to page 15)
Mixer beeps when ‘Start’ button is
pressed
Bowl guard not in closed position. Rotate guard to the right until fully
closed.
Bowl not raised. Raise bowl to highest position.
In the event of a power failure, the unit will shut down, and the timer display will not be illuminated. Once power has
been restored, the timer will display the last programmed/set time. Pressing the ‘Start’ button will begin the mixing
operation.

Page 20
Limited Mixer Warranty
Globe Food Equipment Company (“GFE”) warrants to the original purchaser of new equipment that said equipment,
when installed in accordance with our instructions within North America and subjected to normal use, is free from
defects in material or workmanship for a period of 2 years on parts (excludes wear/expendable parts). The labor
warranty is 1 year on labor from original installation, or 18 months from actual shipment date, whichever date occurs
rst. Mixer attachments have a 1 year replacement warranty from invoice date. There is no labor warranty for mixer
attachments. The vegetable slicing assembly, shredder/grater assembly, and meat grinder are considered mixer
attachments.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED. GFE
EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR EXPRESSED OR IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
GFE’S OBLIGATION AND LIABILITY UNDER THIS WARRANTY IS EXPRESSLY LIMITED TO REPAIRING AND
REPLACING EQUIPMENT WHICH PROVES TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP WITHIN
THE APPLICABLE WARRANTY PERIOD. All repairs pursuant to this Warranty will be performed by an Authorized
Designated GFE Service Location during normal working hours. IN NO EVENT SHALL GFE BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES TO BUYER OR ANY THIRD PARTY, INCLUDING, WITHOUT
LIMITATION, LOSS OF PROPERTY, PERSONAL INJURY, LOSS OF BUSINESS OR PROFITS OR OTHER
ECONOMIC LOSSES, OR STATUTORY OR EXEMPLARY DAMAGES, WHETHER IN NEGLIGENCE, WARRANTY,
STRICT LIABILITY, OR OTHERWISE.
This warranty is given only to the rst purchaser from a retail dealer. No warranty is given to subsequent transferees.
This warranty does not cover product failures caused by: failure to maintain, neglect, abuse, damage due to excess
water, re, normal wear, improper set up and use. Periodic maintenance is not covered.
This warranty is not in force until such time as a properly completed and signed installation/warranty registration or
an online registration form has been received by GFE within 30 days from the date of installation. Register online
at www.globeslicers.com/warranty.asp.
THE FOREGOING WARRANTY PROVISIONS ARE A COMPLETE AND EXCLUSIVE STATEMENT BETWEEN
THE BUYER AND SELLER. GFE NEITHER ASSUMES NOR AUTHORIZES ANY PERSONS TO ASSUME FOR
IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SAID EQUIPMENT.
Example of items not covered under warranty, but not limited to just these items:
1. Acts of God, re, water damage, vandalism, accident, theft.
2. Freight damage.
3. Improper installation or alteration of equipment.
4. Use of generic or after market parts.
5. Repairs made by anyone other than a GFE designated servicer.
6. Lubrication.
7. Expendable wear parts. (This includes the bowl, at beater, wire whip, spiral dough hook,
and the pastry knife.)
8. Cleaning of equipment.
9. Misuse or abuse.
