Glomex VENUS V9000 Operating manual

VENUS V9000
SATURN V9100 V9104 V9104SKEW
MARS V9801 V9804 V9804SKEW
RHINE R9804
SATELLITE TV ANTENNAS
FOR MARINE AND RIVER BOATS
SERIES MK2+
USER AND INSTALLATION MANUAL

VENUS SATURN MARS RHINE
44 www.glomex.it
ENGLISH

VENUS SATURN MARS RHINE
45
www.glomex.it
ENGLISH
INDEX
1. FOREWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1.1 DELIVERY LETTER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1.2 ANTENNA IDENTIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1.3 WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1.4 GENERAL SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
1.5 ENVIRONMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
2. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.1 VENUS V9000 - SATURN V9100 - MARS V9801 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.2 SATURN V9104 - V9104SKEW - MARS V9804 - V9804SKEW . . . . . . . . . . . . . . . . . . 49
2.3 RHINE R9804. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3. CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3.1 OPTIONAL ACCESSORIES (NOT INCLUDED) TO USE GLOMEX ANTENNAS. . . . . 54
4. NECESSARY TOOLS FOR ASSEMBLY (NOT PROVIDED) . . . . . . . . . . . . . . . . . . . . . . 54
5. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6. ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.1 LOWER RADOME CUTTING TEMPLATE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.2 CONTROL UNIT CUTTING TEMPLATE FOR INSTALLATION
ON A VERTICAL WALL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.3 SKEW CALIBRATION (MANUAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
6.4 SKEW ADJUSTMENT GRID FOR EUROPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7. USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8. TIPS FOR CORRECT USAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
8.1 FOOTPRINTS: SATELLITE TRANSMISSION AREAS . . . . . . . . . . . . . . . . . . . . . . . . . 75
9. MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
9.1 PREVENTIVE MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
9.2 SPARE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
10. TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
11. RESHIPPING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
12. TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
13. TECHNICAL SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

VENUS SATURN MARS RHINE
46 www.glomex.it
ENGLISH

VENUS SATURN MARS RHINE
47
ENGLISH
www.glomex.it
1. FOREWORD
1.1 DELIVERY LETTER
Welcome: with the installation of this antenna, the
world of satellite television comes on board your
boat.
This manual has been drafted in order to help you
with the correct installation and operation of the
antenna.
1.2 ANTENNA IDENTIFICATION
When calling GLOMEX or an authorized Service
Centre, always provide the serial number and the
model of the antenna, shown on the second page
of the manual, on the packaging, on the backside
of the dish, under the control unit and under the
power supply.
1.3 WARRANTY
GLOMEX guarantees the satellite antennas series
VENUS V9000, SATURN V9100, V9104 and
V9104SKEW, MARS V9801, V9804, V9804SKEW
and RHINE R9804 against conformity defects for a
period of 24 (twenty-four) months from the date of
shipment.
Warranty is intended as the repair or replacement
of the equipment showing conformity defects when
entering the sales contract, with no charge for the
materials.
In case of conformity defects, the customer is enti-
tled to the replacement of the goods with no
charge.
The warranty is only valid if the product comes
with a valid proof of purchase, (receipt or
invoice).
The non-conforming product must be sent back to
a Service Centre or authorized retailer, who will for-
ward it to:
GLOMEX S.r.l.
Via Faentina 165/G
48124, Ravenna (Italy)
along with all the accessories supplied at pur-
chase.
The serial number must neither be erased nor
made illegible, otherwise the warranty will be
voided.
SWARNING
Conserve the installation and user manual with
care! Losing the serial number makes the warranty
null and void!
The warranty does not apply in case of damage
due to carelessness, use or installation not compli-
ant with the instructions given, tampering, product
or serial number modification, damage due to acci-
dental causes or to the buyer’s negligence.
Moreover, warranty does not apply in case of dam-
age consequent to connections of the equipment to
different voltages than those indicated or to sudden
voltage variations of the network the equipment is
connected to, as well as in case of damage caused
by leakage, fire, inductive/electrostatic discharges
or discharges due to lightning, use of cables differ-
ent to those provided, overvoltages or other phe-
nomena not related to the equipment.
The parts subject to wear consequent to use such
as connection cables, driving belts, connectors,
external parts and plastic supports are covered by
a one-year period warranty.
The warranty does not include: periodical checks,
software updates, product settings, maintenance.
After the expiration of the warranty period, the tech-
nical support activities will be carried out charging
the customer for the replaced parts, the labour
costs and freight charges, according to current
rates.
The equipment will be replaced or repaired
under warranty only and exclusively on Glomex
quality department’s approval.
Should any dispute rise, the place of jurisdiction will
exclusively be Ravenna (Italy).
The warranty is provided by:
GLOMEX S.r.l.
Via Faentina 165/G
48124 Ravenna (Italy)

VENUS SATURN MARS RHINE
48
ENGLISH
www.glomex.it
1.4 GENERAL SAFETY INSTRUCTIONS
Carefully read the instructions given and follow the
precautions indicated to prevent potential hazards
and to safeguard your health and safety, before
carrying out any installation and maintenance oper-
ation.
This manual contains the following indications:
SWARNING
This symbol warns against potential damage to the
equipment which could involve the operator’s
safety.
SDANGER
With specific warnings against potential dangers
for the safety of the operator or other directly
involved persons.
Failure to comply with the instructions preceded by
the above-mentioned keywords (WARNING and
DANGER) can cause serious accidents or even
the death of the persons involved.
Moreover, in this Manual, some instructions are
given with text in italics, preceded by the words
NOTE.
The information and specifications given in this
manual are based upon the information available at
the moment it is written.
In case of doubts, do not hesitate to contact
GLOMEX S.r.l.
1.5 ENVIRONMENT
Do not throw the appliance away with the normal
household waste at the end of its life, but hand it in
at an official point for recycling. By doing this, you
will help preserve the environment.
Fig. 1

VENUS SATURN MARS RHINE
49
ENGLISH
www.glomex.it
2. PRODUCT DESCRIPTION
2.1 VENUS V9000 - SATURN V9100 -
MARS V9801
They are satellite TV antennas that guarantee
renewed performance in satellite signal reception
and tracking when cruising, when riding the anchor
and when moored.
They are provided with the new HPD (High-Per-
formance Dish) parabolic dish, combined with the
innovative STO (Silent Tracking Operation) noise
reduction system.
They are equipped with an efficient compensation
system of the boat’s rolling and pitching move-
ments consisting of electronic gyro-stabilizers
(EGS) and a single coaxial rotating joint (CRJ),
which allows the antenna to stabilize signal recep-
tion by turning infinitely on the azimuth axis, with no
need to wind the single coaxial cable (SCC). They
allow connecting one receiver at a time.
They are also equipped with a control unit which
can be embedded into the on-board electric panel.
8 satellites are already available on the control unit
and are recognized through the NIT (Network Iden-
tification Table) system.
They are prearranged for future updating.
2.2 SATURN V9104 - V9104SKEW - MARS
V9804 - V9804SKEW
They are satellite TV antennas that not only guar-
antee high performance standards in signal recep-
tion and tracking while cruising, when riding the
anchor and when moored, but also allow the con-
nection of up to 16 independent decoders on the
same boat.
They are provided with the new HPD (High-Per-
formance Dish) parabolic dish, combined with the
innovative STO (Silent Tracking Operation) noise
reduction system.
They are equipped with an efficient compensation
system of the boat’s rolling and pitching move-
ments consisting of electronic gyro-stabilizers
(EGS), a multiple coaxial rotating joint (MCRJ) and
a multiswitch box for the connection of more inde-
pendent decoders (4 outputs for multiswitch, up to
a maximum quantity of 16 per antenna).
The antenna can turn infinitely around its axis,
since no coaxial cable winding and no interruption
of TV reception are needed. They are equipped
with a control unit which can be embedded into the
on-board electric panel.
In the SKEW version, they are provided with the
innovative compensation system which, according
to the geographic position, directly operates on the
LNB, automatically changing its inclination and
optimizing polarization to obtain the best possible
signal quality.
8 satellites are already available on the control unit
and are recognized through the NIT (Network Iden-
tification Table) system.
They are prearranged for future updating.
2.3 RHINE R9804
Rhine R9804 is the best satellite TV antenna for
river boats designed by Glomex. Identical in dimen-
sions to Mars V9804 (dish diameter 600 mm), it
allows the connection of up to 16 independent
decoders on the same boat. This antenna is
equipped with a multiple coaxial rotating joint
(MCRJ) and with a multiswitch box for the connec-
tion of more independent decoders (4 outputs for
multiswitch, up to a maximum quantity of 16 per
antenna). Rhine R9804 has been designed to
obtain an outstanding performance in river naviga-
tion thanks to the new hardware and software of
mobile inspiration, which prevent losing the satellite
TV signal even in the presence of bridges and
obstacles along the banks. These characteristics
make Rhine the ideal choice to watch TV in river
boats and in case of bad weather conditions.
It is designed for future updates.

VENUS SATURN MARS RHINE
50
ENGLISH
www.glomex.it
3. CONTENTS
The satellite antenna is sent packed in a cardboard
box and sealed with the GLOMEX “SAFETY SEAL”
hoop, which has the function of CONTENT WAR-
RANTY seal.
Upon receipt, check that:
- the packaging is whole and the warranty hoop is
present;
- the supply matches the order specifications;
- the antenna and its accessories are not dam-
aged.
In case of damage or missing parts, immediately
inform the Retailer, if possible with appropriate
photos.
The following tables list the components contained
in the package, indicating the quantities and the
GLOMEX code (if provided).

VENUS SATURN MARS RHINE
51
ENGLISH
www.glomex.it
VENUS V9000 - SATURN V9100 - MARS V9801
Fig. 1B
Satellite receiver
(not provided)
VENUS V9000/SATURN V9100/MARS V9801 Fig. 1B
Component GLOMEX code
Antenna unit V9000 (1) 3.010.0015
Antenna unit V9100 (1) 3.010.0016
Antenna unit V9801 (1) 3.010.0017
Base seal (2) 4.010.0415
M8 x 100 threaded bars (4 pcs) (3) 4.100.0118
Fastening reinforcements (4 pcs) (4) 4.020.0247
M8 self-locking nuts (4 pcs) (5) 4.100.0019
Control unit (6) 4.120.0042
Power supply for control unit (7) 4.120.0043
Vimar support for control unit fastening (8) 4.010.0153
Frame for built-in installation (9) 4.010.0154
10 m cable for antenna - control unit connection (10) V9139/10
1.5 m cable for line amplifier - decoder connection (11) V9143
Power supply cable for control unit - power supply (12) 4.070.0100
Connection cable for power supply - magneto-thermal switch on the on-board
panel (13) 4.070.0101
Brackets for fastening the control unit on a horizontal surface (14) 4.020.0611

VENUS SATURN MARS RHINE
52
ENGLISH
www.glomex.it
SATURN V9104 - MARS V9804 - SATURN V9104SKEW - MARS V9804SKEW
Fig. 1C
Satellite receiver
(not provided)
SATURN V9104 - V9104 SKEW/MARS V9804 - V9804 SKEW Fig. 1C
Component GLOMEX code
Antenna unit V9104 (1) 3.010.0018
Antenna unit V9104 SKEW (1) 3.010.0019
Antenna unit V9804 (1) 3.010.0020
Antenna unit V9804 SKEW (1) 3.010.0021
Base seal (2) 4.010.0415
M8 x 100 threaded bars (4 pcs) (3) 4.100.0118
Fastening reinforcements (4 pcs) (4) 4.020.0247
M8 self-locking nuts (4 pcs) (5) 4.100.0019
Control unit (6) 4.120.0042
Power supply for control unit (7) 4.120.0043
Multiswitch (8) V9191
Vimar support for control unit fastening (9) 4.010.0153
Frame for built-in installation (10) 4.010.0154
10 m cables for antenna - control unit and antenna - multiswitch connection (11)
(4 pcs) V9139/10
1.5 m cable for control unit - multiswitch connection (12) V9143
1.5 m cable for multiswitch - decoder connection (13) V9143
Power supply cable for control unit - power supply (14) 4.070.0100
Connection cable for power supply - magneto-thermal switch on the on-board panel (15) 4.070.0101
Brackets for fastening the control unit on a horizontal surface (16) 4.020.0611

VENUS SATURN MARS RHINE
53
ENGLISH
www.glomex.it
RHINE R9804
Fig. 1D
Satellite receiver
(not provided)
RHINE R9804 Fig. 1D
Component GLOMEX code
Antenna unit R9804 (1) 3.010.0023
Base seal (2) 4.010.0415
M8 x 100 threaded bars (4 pcs) (3) 4.100.0118
Fastening reinforcements (4 pcs) (4) 4.020.0247
M8 self-locking nuts (4 pcs) (5) 4.100.0019
Control unit (6) 4.120.0042
Power supply for control unit (7) 4.120.0043
Multiswitch (8) V9191
Vimar support for control unit fastening (9) 4.010.0153
Frame for built-in installation (10) 4.010.0154
10 m cables for antenna - control unit and antenna - multiswitch
connection (11) (4 pcs) V9139/10
1.5 m cable for control unit - multiswitch connection (12) V9143
1.5 m cable for multiswitch - decoder connection (13) V9143
Power supply cable for control unit - power supply (14) 4.070.0100
Connection cable for power supply - magneto-thermal switch on the on-
board panel (15) 4.070.0101
Brackets for fastening the control unit on a horizontal surface (16) 4.020.0611

VENUS SATURN MARS RHINE
54
ENGLISH
www.glomex.it
3.1 OPTIONAL ACCESSORIES (NOT
INCLUDED) TO USE GLOMEX
ANTENNAS
To be able to use your new GLOMEX satellite
antenna for boats, you will have to procure or buy
also:
- a TV set;
- a satellite receiver for channel selection.
The table below lists all the GLOMEX optional
components, with relevant code.
4. NECESSARY TOOLS FOR ASSEM-
BLY (NOT PROVIDED)
Procure all tools and materials listed below. They
will be necessary to complete installation.
- Electric drill (1).
- 8.5 mm drill tip for radome assembly (2).
- 28 mm hollow mill for drilling the passage hole
for the antenna connector cable (3).
- Phillips screwdriver (with adequate dimensions
for control unit installation) (4).
- 11 mm wrench (for the installation of the coaxial
cable connectors) (5).
- Reciprocating saw (to create the compartment
in case of wall built-in installation of the control
unit; use the template provided on page 67) (6).
- LOCTITE ® 638 (7)
Optional accessory GLOMEX code
Satellite decoder i-CAN 1110SV TIVÙSAT 230 VAC
- 12 VDC V9193
XDome terrestrial digital - satellite HD combi
decoder (DVB-T + DVB-S + DVB-S2) compatible
with SKY ITALIA - 230 VAC
V9192
Stainless steel support 0°- 5° V9500
Twin radome V9... TWIN - R9804 TWIN
Radome painting - RAL colour chosen by the
customer SATPAINT
Line amplifier V9115
Fig. 2

VENUS SATURN MARS RHINE
55
ENGLISH
www.glomex.it
SWARNING
Plan the whole installation before proceeding!
Please consider the lay-out of the various compo-
nents, the distance between them, the length of the
various cables and the accessibility to the equip-
ment once it is installed.
SWARNING
Always lift the antenna from the lower radome and
never from the upper radome or any part inside it.
Fig. 3
Upper radome
Lower radome

VENUS SATURN MARS RHINE
56
ENGLISH
www.glomex.it
5. INSTALLATION
Before proceeding with the installation, please
respect the following guidelines:
- please remember that the best position for the
satellite TV antenna is in the middle of the boat,
in the lowest possible position.
- minimize obstruction. The antenna requires a
clear view of the sky in order to receive satellite
TV signals. The fewer the obstacles, the better
the system operation.
Any foreign body (flags, antennas, radar anten-
nas, sailboat masts, cranes, bridges, etc.)
between the antenna and the satellite obstructs
the signal and prevents correct receipt.
- make sure that the mounting surface is wide
enough for the antenna base to be installed.
- make sure that the mounting surface is resistant
and rigid enough to support the weight of the
antenna and the vibrations which could occur.
- do not install the antenna near speakers or mag-
netic sources. In case it is not possible, it is nec-
essary to compensate the magnetic source,
paying attention not to interfere with the on-board
compass.
- the antenna requires a lifting angle αbetween 5°
and 90° to receive satellite signals (Fig. 4).
Roll-bar
Fig. 4
TV antenna
Obstructed signal!
α= lifting angle

VENUS SATURN MARS RHINE
57
ENGLISH
www.glomex.it
Typical antenna lifting
- please also consider the position of the antenna
with respect to the position of all various attach-
ments or wiring harnesses inside the boat.
- the control unit should be mounted in a conven-
ient position for the adjusting operations. It
should be near the receiver/TV-set unit, so that
the TV screen may be watched while carrying out
the operations on the control unit.
SWARNING
The radio frequency beam transmitted by the radar
may damage the inner electronics of the antenna,
especially the LNB.
Fig. 5
NORTHERN EUROPE (~ 15°) CENTRAL EUROPE (~ 35°) SOUTHERN EUROPE (~ 50°)
We recommend not to install the antenna at the
same level of the radar, as the radar’s energy
could damage the antenna. The antenna should
be positioned at a distance of at least 1.5 m from
the other transmitting antennas (VHF, radar) (Fig.
6).
Fig. 6
OK NO
Typical radar vertical
irradiation angle

VENUS SATURN MARS RHINE
58
ENGLISH
www.glomex.it
6. ASSEMBLY
SDANGER
While installing the antenna, wear the appropriate
safety equipment for the job to be carried out.
1. First of all, make sure you have chosen a cor-
rect position to install the antenna (see section
5: “Installation”).
2. Remove the antenna from the packaging box.
Remove the screws from the lower radome.
3. Underneath the base of the antenna, insert the
4 M8 threaded bars and use a liquid thread
locking product (Loctite®638).
4. Use cutting template 6.1 on page 66 and use a
felt-tip pen to mark the holes for the threaded
bars and cable passage.
5. Drill the 4 holes for the passage of the threaded
bars by means of an electric drill and a 8.5 mm
drill tip on the supporting surface.
6. Drill the hole for cable passage by means of an
electric drill and a 28 mm hollow mill.
7. Position the rubber seal so that the holes
match.
Fig. 7
Fig. 8
Fig. 9
Fig. 10

VENUS SATURN MARS RHINE
59
ENGLISH
www.glomex.it
8. Position the antenna onto the seal, inserting the
4 threaded bars through the holes, and pay
attention to direct the orientation symbol of the
antenna towards the bow.
9. Install the fastening reinforcements onto the
threaded bars and screw in the M8 self-locking
nuts.
10. Completely tighten.
SWARNING
GLOMEX declines any liability for an incorrect
mounting of the radome on the boat.
11. Have the 10 m cable pass through the previ-
ously drilled hole (V9000, V9100, V9801).
12. Have the four 10 m cables pass through the
previously drilled hole (V9104, V9104SKEW,
V9804, V9804SKEW, R9804).
13. To connect the coaxial cable it is necessary to
remove the upper radome and to connect it to
the connector (1) found on the lower radome,
trying to give it a path that follows the curvature
of the radome.
14. Should it be necessary to shorten the cable,
please refer to the instructions given in Fig. 14.
Fig. 11
Fig. 12
Fig. 13
GL00095
Fig. 14

VENUS SATURN MARS RHINE
60
ENGLISH
www.glomex.it
15. Make sure that the cable core is correctly
inserted in the central hole of the female con-
nector on the antenna.
Manually screw in the ring nut of connector F.
Once the ring nut has been manually screwed
in, tighten by ¼ turn by means of a 11 mm
wrench.
16. Remove the two safety straps found on the azi-
muth and lifting gears.
SWARNING
For a correct assembly, respect the installation
direction indicated in Fig. 11.
A different installation from the recommended one
could cause an incorrect operation of the antenna
due to the risk of water penetration into the
radome.
Operations to be carried out inside the boat.
1. Determine the correct position for the control
unit:
- it must be positioned near the satellite
receiver, as the provided coaxial cable is
1.5 m long;
- it must be reached by the power supply cable
coming from the power supply;
- it must be reached by the coaxial cable com-
ing from the antenna (10 m long);
- it must be positioned in a dry and ventilated
area (maximum operating temperature
45° C).
2. Determine the correct position for the power
supply:
- it must be close to the control unit;
- it must be reached by the (red - black) cable
coming from the batteries or from the on-
board panel;
- it must be positioned in a dry and ventilated
area (maximum operating temperature
45 °C).
3. Connect the coaxial cable of the antenna (pre-
viously installed) to the ANTENNA IN input on
the control unit and a coaxial cable between the
RECEIVER OUT output on the control unit and
the decoder.
Make sure that the cable cores are correctly
inserted in the central holes of the relevant
female connectors on the control unit.
Manually screw in the ring nuts of connectors F.
Once the ring nuts have been manually
screwed in, tighten by ¼ turn by means of a 11
mm wrench.
SWARNING
The inversion of the two cables jeopardizes the
operation of the equipment. Make sure you have
correctly installed the coaxial cables. In case of
damage, GLOMEX will not be directly liable for the
damage suffered by the receiver.
SWARNING
Antennas V9000, V9100 and V9801 are designed
to operate with a single decoder; therefore, do not
install signal splitters upstream or downstream the
control unit.
Central coaxial
cable conductor
Fig. 15

VENUS SATURN MARS RHINE
61
ENGLISH
www.glomex.it
4. Connect the power supply cable (10-30 VDC)
to a free switch for the on-board electronic
devices (min. 5A): connect the positive terminal
to the red cable and the negative terminal to the
black cable. The power supply line must have
cables with a minimum cross section of
2.5 mm2with a length up to 4 m, of 4 mm2for
longer cables.
SWARNING
Do not use power supply from secondary circuits.
This could jeopardize the operation of the equip-
ment.
SWARNING
In order to prevent that current leakage or charge
build-up may damage the electronic components of
the antenna, make sure there is an efficient
grounding system.
SWARNING
Pay attention not to bend the coaxial cables at a
right angle; the bending angle must always be
higher than 120°.
NOTE (applies to V9000): in case a cable longer
than 10 m should be necessary for connecting the
control unit to the satellite receiver, we recommend
installing line amplifier V9115 between them.
Fig. 16
Power supply Backside of the power
supply Backside of the control unit
From the antenna To the decoder (V9000-V9100-V9801)
To the multiswitch (V9104-V9804) HH
To the multiswitch (R9804) VL
Red
Black 10 ÷ 30 VDC
Fig. 17

VENUS SATURN MARS RHINE
62
ENGLISH
www.glomex.it
NOTE: Do not cut the connectors of the coaxial
cables (the operation would not be guaranteed any
more) and always use the original GLOMEX cables
supplied, even with inappropriate dimensions (too
long). Do not use different cables, as it would
jeopardize the operation of the equipment.
SWARNING
If the control unit shows the error message ERR1,
there is no communication between the antenna
and the control unit.
It is therefore necessary to check that the connec-
tion cable between antenna and control unit is cor-
rectly fastened and is not interrupted or short-
circuited.
Fig. 18
