GLP YPOC 250 User manual

Instruction Manual
from software version 1.5
(instruction version 1.6)
e-mail: servic[email protected]
Internet: http://www.GLP.de

GLP German Light Production (V1.6) 2
This side is intentionally unlabelled.

GLP German Light Production (V1.6) 3
Table of contents
1Description of Device.............................................................................................5
1.1 Safety Instructions............................................................................................6
2Preparation and Installation ..................................................................................7
2.1 Mounting ..........................................................................................................7
2.1.1 Clamps...................................................................................................7
2.1.2 Mounting plate.......................................................................................7
2.2 Secure the Y YP PO OC C 2 25 50 0......................................................................................8
2.3 Connections.....................................................................................................9
2.3.1 Power supply.........................................................................................9
2.3.2 DMX.......................................................................................................9
2.4 Fuse.................................................................................................................9
3The Menu Field......................................................................................................10
3.1 Adjust the DMX- Address (D001).....................................................................11
3.2 The Test Program (TEST) ................................................................................11
3.3 The Audio Program (AUDI)..............................................................................11
3.4 Lamp On/Off (LAMP) ........................................................................................12
3.5 Reset (RESE) ...................................................................................................12
3.6 Running time of lamp and unit (TIME) .............................................................12
3.7 Invert Pan Movement (RPAN)...........................................................................12
3.8 Invert Tilt Movement (RTLT) ............................................................................13
3.9 DMX Mode (MODE) ...........................................................................................13
3.10 Special Functions (SPEC).................................................................................13
3.10.1Manual Drive (MANU) .............................................................................14
3.10.2Lamp On automatically (LAAU)..............................................................14
3.10.3Lamp Off via DMX (DLOF) .....................................................................14
3.10.4DMX Input (DMXI) .................................................................................15
3.10.5Display (DISP).......................................................................................15
3.10.6Fixture Temperature (TEMP) ..................................................................15
3.10.7Fan Control (FANS)................................................................................16
3.10.8Adjustments and Calibrations (ADJU)....................................................16
3.10.9Default Settings (DFSE) .........................................................................17
3.10.10 Feedback (FEED)..............................................................................17
3.10.11 Correction of faults (EFLG) ...............................................................17
3.11 Error and Information Messages....................................................................17

GLP German Light Production (V1.6) 4
4DMX Channel Selection (DMX Protocol).............................................................18
5Change the Lamp..................................................................................................21
5.1 Safety Regulations .........................................................................................21
5.2 Realize the Lamp Change..............................................................................21
5.3 Lamp adjustment............................................................................................22
6Change a Gobo .....................................................................................................23
6.1 Safety Regulations .........................................................................................23
6.2 Realize the Gobo Change..............................................................................23
7Maintenance and Cleaning the Y YP PO OC C 2 25 50 0 ..........................................................24
7.1 Safety Regulations .........................................................................................24
7.2 Circumference and Interval (rule-of-thumb)....................................................25
7.3 Cleaning the Optical System..........................................................................25
8Technical Specification........................................................................................26
9Index ......................................................................................................................28

GLP German Light Production (V1.6) 5
1 Description of Device
1
2
34
1. Moving Head
2. Arm
3. Base
4. Carrying handles
5. Up- button
6. Down- button
7. Enter- button
8. Mode- button
9. LED- Display
10.Software-Update
connector
11.Microphone- Intensity
12.DMX- Input
13.DMX- Output
14.Power On/Off
15.Fuse F3,15 A
16.Fan (air inlet)
MaxMin
DMX IN DMX O UT
SoftwareUpdate
1.Ground
2.Data-
3.Data+
POWER
210V ~
230V ~
250V ~
50Hz
60Hz
Power i nput
FUSE:
T3. 15A @2 50V
LAMP:
MSD 25 0W
Serial
number:
Fuse
Mic S ensitive
12
3
PUSH
FUSE
MOD E ENTER UPDOWN
MO
DE
ENTER
UPDOW
N
87 65
9
10
11
12 13 14
15
16

GLP German Light Production (V1.6) 6
1.1 Safety Instructions
The Y YP PO OC C 2 25 50 0 is a High-Tech Product. To guarantee a smooth
operation, it is necessary to keep following rules.
The manufacturer of this device will not take responsibility of
damages through disregard of the information in this manual.
Warranty adjustments will be canceled.
1. Make sure before putting into operation, that the fan and the air inlets are
clean and not blocked by anything.
2. Attention: Don’t touch the device during the operation. This can cause
injuries or damages.
3. Unplug the
Y
YP PO OC C 2 25 50 0 from the AC outlet before any service.
4. It is necessary to wait at least 30 minutes after disconnecting the AC before
you open the Y YP PO OC C 2 25 50 0. Please do not touch the bulb of the lamp if you are
not absolutely sure it is cold. -Danger of BURNING-
5. Never look directly into the beam of the lamp. You risk injury of your retina and
blindness.
6. Pay attention of the maximum lamp operation time. You have to change it if
the lamp shows any deformations or damages. The same is with all glass
components, color filters, lenses and mirrors.
7. To allow a secure operation, follow also the Installation guide described in
chapter 2. Operating the Y YP PO OC C 2 25 50 0 without suited safety aids like Safety
cables or clamps/hooks can increase the risk of an accident.
8. The installation should be done by qualified staff only. You need to pay
attention to the common rules of technology that are not explicit mentioned in
this manual.
9. Use only original spare parts. Any structural modification will cancel all
warranty adjustments.
LA SERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 3R
NACH DIN-EN 60825-1/11:2001
P 5mW; = 635-650 nm
0
λ
Attention: Laser of class 3R may
injure your retina after a short resi-
dence time even without any optical
instrument. Avoid any direct ex-
posure of your eyes!

GLP German Light Production (V1.6) 7
2 Preparation and Installation
2.1 Mounting
The Y YP PO OC C 2 25 50 0 is fully operational whether it hangs or is mounted to the wall. It
can also be operated while standing on the floor. Keep a safety distance of 0.5 m
towards any easy inflammable materials (decoration etc.). Install a safety wire that
can hold at least 10 times the weight of the fixture. Never use the carrying handles
for secondary attachment.
Pay attention to the regulations of: BGV C1 (former VBG 70)
and DIN VDE 0711-217. Regulations of show laser BGV B2
(11.2001), E DIN 56912 part 6, DIN-EN 60825 part 1+2.
The installation should be done by qualified staff only.
2.1.1 Clamps
Use two clamps on the backside of the Y YP PO OC C 2 25 50 0to mount the unit on a
truss (each two opposite threads max. M10x20). See also printing on the
backside of the case.
2.1.2 Mounting plate
For a permanent installation of the Y YP PO OC C 2 25 50 0you can use a optional
mounting plate to fix the unit on a wall. The plate uses 4x screws M6x20.

GLP German Light Production (V1.6) 8
2.2 Secure the
Y
YP PO OC C 2 25 50 0
Regardless of the rigging of the Y YP PO OC C 2 25 50 0 you have to use a stipulated safety
wire. Therefore you have to thread to safety wire through to two provided holes on
the backside of the fixture and connect it with the truss-support. Pay attention to a
safe and proper fastening.

GLP German Light Production (V1.6) 9
2.3 Connections
2.3.1 Power supply
230 Volt, 50 Hz,
Connected load 500W <=> 2,2 A (blind current compensation).
or 115V, 60 Hz
Connected load 500W <=> 4,4 A (blind current compensation).
Please see printing on the case for the right Power supply !
2.3.2 DMX
DMX 512 Standard input/output. See also printing on the case for the right
pin assignment.
[+] = Pin 3 / [-] = Pin 2 / [Ground] = Pin 1
The DMX- Addressing starts at the DMX- Address [001].
2.4 Fuse
The Y YP PO OC C 2 25 50 0 electronic system is protected by a 5x20 mm fuse.
230V / T 3,15A (EU model) or 115V / T 6,3A (US model)
Please see the printing on the Y YP PO OC C 2 25 50 0 for more details.
Attention:
• Disconnect AC outlet before changing a fuse!
• Use only the original declared fuse type!

GLP German Light Production (V1.6) 10
3 The Menu Field
You find the control board on the side part of the base. It allows
you to make all necessary adjustments of the Y YP PO OC C 2 25 50 0. .With the
Mode-key you get into the main menu. Afterwards you can navi-
gate through the menu with the Up/Down-keys. Push the Enter-
key to get in the next menu level or to confirm your settings. Make
them and set functions ON/OFF with the Up/Down-keys. Confirm
and save it with the Enter-key (the display shows OK). Push the
Mode-key to cancel the entry and go back to the main menu.
MODE ENTER UPDOWN
MODEENTERUPDOWN
LED-Displa
y
Mode-ke
y
Enter-ke
y
Down-ke
y
Up-ke
y
Level 1 Level 2 Level 3 Remark
D001
Define the DMX start address
TEST MOD1 Test program of all functions
AUDI ASLW Self-running audio program (slow)
AFST Self-running audio program (fast)
MSTR Master for the audio program
SVPT Basic position for the audio program
SIZE Size for the audio program (NORM-BIG-MIDL-SMAL)
LAMP
Switch on/of the lamp direct at the Y
YP PO OC C 2 25 50 0
RESE
Reset
TIME POWR Running time of the fixture (no destructible)
LA1 Running time of the lamp (erasable)
LA2 Running time of the lamp (no destructible)
RPAN
Reverse Pan-direction
RTLT
Reverse Tilt-direction
MODE GDMX DMX Mode, Standard GLP
MDMX DMX Mode 'M'
HDMX DMX Mode 'H'
SPEC MANU Manual drive of all device functions
LAAU Automatic lamp start
DLOF Switch off lamp via DMX
DMXI Reed out actual DMX-values
DISP D ON Display On/Off
REV Twist the display
TEMP Reed out internal temperature
FANS HIGH Maximum cooling fan velocity
REG Automatic cooling fan control
LOOF Low cooling fan speed Ælamp off
LOHI Low cooling fan speed Æautomatic
ADJU CODE xxxx Use the code for entering the calibration menu (for
authorized person only)
COLO Calibration of the color wheel
GOBO Calibration of the gobo wheel
PRIS Calibration of the prism wheel
SHT1 Calibration of the shutter 1
SHT2 Calibration of the shutter 2
clre Settings in the internal memory (superuser only)
facc Must read on. Protected with a code.
DFSE Call on the default function values
FEED Pan/Tilt feedback (error correction) On/Off
ÅDOWN - UP Æ
EFLG Correction of faults

GLP German Light Production (V1.6) 11
3.1 Adjust the DMX- Address (D001)
Right after turning on the Y YP PO OC C 2 25 50 0 you can see the current DMX- Address. If
there is no DMX- Signal the display flashes.
D001
For the address setting please follow this procedure:
1. Switch On the Y YP PO OC C 2 25 50 0 and wait until the fixture reset has finished ('RESE'is
flashing in the display).
2. Press the Mode-key in order to access the main menu. Browse through the
menu by pressing the Up/Down-keys until the display shows D001. Confirm by
pressing the Enter-key (the decimal point is flashing)
3. Use the Up/Down-keys to select the desired address. Confirm the setting by
pressing the Enter-key (the display shows OK) or press the Mode-key to
cancel.
The DMX- Address is stored also while switching off the Y YP PO OC C 2 25 50 0!
3.2 The Test Program (TEST)
test
The Test-Program allows you to run a complete self test procedure of all
functions. Press Enter to confirm or Mode to cancel.
3.3 The Audio Program (AUDI)
Audi
The Audio-menu allows you to run a stand alone audio program. This chaser can
run either fast or slow. AFST: Every soundimpulse on step of the chaser. Aslw:
Every second soundimpulse one step of the chaser.
Additional you can choose a basic position for this audio chaser. Use therefore
either the internal manual mode or an external controller to set the desired
Pan/Tilt position. Confirm this setting in the SVPT menu by pressing the Enter-key.
You can also set the size of the audio chaser in the SIZE menu. You have the
choice between: NORM (no basic position has to bee chosen), 'BIG', 'MIDL' and
'SMAL').

GLP German Light Production (V1.6) 12
If you want to run the systems simultaneously, one of the Y YP PO OC Cs smust be
switched as the master. All others must be "Slave" Master = OFF. Notice: The
Audio function is only working if no DMX is connected. This function can work e.g.
on small events or as an emergency program.
3.4 Lamp On/Off (LAMP)
LAMP
Use the Up/Down-keys to select lamp On or lamp Off Press Enter to confirm or
Mode to cancel and return to the main menu. (The lamp OFF command is only
working if the shutter is closed at the same time. Use an external controller or the
manual drive mode, see 3.10.1)
3.5 Reset (RESE)
RESE
Press the Enter-key to run a reset of all fixture functions (RST is shown in the
display).
3.6 Running time of lamp and unit (TIME)
TIME
By this option can read out three different running times of the fixture.
POWR Running time of the fixture (no destructible).
LA 1 Running time of the lamp (erasable). Push the Up/Down-keys at one
time to delete this running time.
LA 2 Running time of the lamp (no destructible).
3.7 Invert Pan Movement (RPAN)
RPAN
This function allows you to invert the Pan movement. Use the Up/Down-keys to
select invert On or Off. Press Enter to confirm or Mode to cancel and return to the
main menu.

GLP German Light Production (V1.6) 13
3.8 Invert Tilt Movement (RTLT)
RTLT
This function allows you to invert the Tilt movement. Use the Up/Down-keys to
select invert On or Off. Press Enter to confirm or Mode to cancel.
3.9 DMX Mode (MODE)
mode
This function allows you to choose between three different DMX modes. The three
modes are different in order of the DMX channels. Use this function for example
to adapt the Y YP PO OC C 2 25 50 0to an older setup of other fixtures or if you use a fader
DMX desk. The standard mode is the GLP mode GDMX.
DMX GLP- Mode (GDMX) M- Mode (MDMX) H- Mode (HDMX)
1 Pan (coarse) Shutter Pan (coarse)
2 Pan (fine) Dimmer Pan (fine)
3 Tilt (coarse) Color Tilt (coarse)
4 Tilt (fine) Gobo Tilt (fine)
5 Color Gobo wheel rotation ---
6 Gobo Focus Color
7 Gobo positioning/rotation Prism, Prism rotation ---
8 Prism, Prism rotation Pan (coarse) Gobo
9 Shutter Pan (fine) Gobo, positioning/rotation
10 Dimmer Tilt (coarse) ---
11 Focus Tilt (fine) Prism
12 Special Speed Pan/Tilt Focus
13 Movement Special ---
14 Speed Pan/Tilt --- Shutter
15 Laser --- Dimmer
16 --- --- Speed Pan/Tilt
17 --- --- ---
18 --- --- Special
3.10 Special Functions (SPEC)
SPEC
This menu allows you to enter further special functions of the Y Yp po oc c 2 25 50 0. .
In detail they are:

GLP German Light Production (V1.6) 14
3.10.1 Manual Drive (MANU)
MANU
This function allows you to drive all the fixture functions manually. Select
the desired function with the Up/Down-keys and confirm with Enter. Now
choose the desired value with the Up/Down-keys and confirm again with
Enter or cancel and return to the menu with the Mode-key.
Function Value Remark
PAN 000 - 255 Pan Position
TILT 000 - 255 Tilt Position
COLO 000 - 255 Color wheel
GOBO 000 - 255 Gobo wheel
GROT 000 - 255 Gobo rotation
PRIS 000 - 255 Prism rotation
SHUT 000 - 255 Shutter / Strobe function (the lamp strikes at
DMX 255 if dimmer is "open" = DMX 255)
DIMR 000 - 255 Dimmer
FOCU 000 - 255 Focus
SPEC 000 - 255 Lamp Off, Reset, ...
LASR 000 - 255 Laser
3.10.2 Lamp On automatically (LAAU)
LAAU
This function enables to switch On the lamp automatically after switching
On the fixture. Use the Up/Down-keys to select ON if you want to switch on
the lamp automatically after switching on the fixture or Off if you don't want
this function. Press Enter to confirm or Mode to cancel and return to the
menu.
If you have chosen off you have the possibility to start the lamp either via
DMX or direct at the Y Yp po oc c 2 25 50 0in the Lamp menu.
3.10.3 Lamp Off via DMX (DLOF)
DLOF
This function enables to switch off the lamp via DMX or not. Use the
Up/Down-keys to select ON if you want to switch off the lamp via DMX or
Off if you don't want this function. Press Enter to confirm or Mode to
cancel and return to the menu.

GLP German Light Production (V1.6) 15
If you have chosen off you have the possibility to switch off the lamp either
direct at the Y Yp po oc c 2 25 50 0in the Lamp menu or switch off the main switch.
3.10.4 DMX Input (DMXI)
DMXI
Readout DMX values of each channel received by the fixture. Use the
Up/Down-keys to select desired channel and press Enter to read its value.
Function Value Remark
PAN 000 - 255 Pan Position
TILT 000 - 255 Tilt Position
COLO 000 - 255 Color wheel
GOBO 000 - 255 Gobo wheel
GROT 000 - 255 Gobo rotation
PRIS 000 - 255 Prism wheel
SHUT 000 - 255 Shutter / Strobe function
DIMR 000 - 255 Dimmer
FOCU 000 - 255 Focus
SPEC 000 - 255 Lamp Off, Reset, ...
MOVE 000 - 255 Movement
SPED 000 - 255 Speed Pan/Tilt
LasR 000 - 255 Laser
3.10.5 Display (DISP)
DISP
Use this function to choose between different display indications. Use the
Up/Down-keys to select desired function and press Enter to confirm or
Mode to cancel and return to the menu.
D ON Display On/Off (If you've chosen off, the display will go out within
15 seconds after the last input. The next key touch will reactivate
the display).
REV Turn around the display
3.10.6 Fixture Temperature (TEMP)
TEMP
This function allows you to read out the actual temperature of the Y Yp po oc c
2
25 50 0. Press Enter to confirm or Mode to cancel. Inside temperatures below

GLP German Light Production (V1.6) 16
80°C are not critical. 80°C and more lead the lamp being switched off at a
critical point. Please note for a save operation that the outside temperature
should not exceed 45°C.
3.10.7 Fan Control (FANS)
FANS
By using this function you can choose between 4 types of fan speed
operations. Use the Up/Down-keys to select desired function and press
Enter to confirm or Mode to cancel and return to the menu.
HIGH The cooling fan works continuously at max. speed.
REG The fan automatically raises its speed in order to control inside
temperature of the fixture.
LOOF The fan keeps the adjusted low speed until the temperature
exceeds max. inside temperature, then the Y Yp po oc c 2 25 50 0automatic-
ally switch off the lamp.
LOHI The fan keeps the adjusted low speed until the temperature
exceeds max. inside temperature, then the Y Yp po oc c 2 25 50 0automatic-
ally switch from low to high fan speed.
3.10.8 Adjustments and Calibrations (ADJU)
ADJU
By this function you can adjust and calibrate the positions of the different
wheels and other motors. This can be necessary after a service or repair
work.
For this function you have to entry the fixture code. This work should be
done only by authorized persons.
Use the Up/Down-keys to select desired function and press Enter to
confirm or Mode to cancel and return to the menu. Use now the Up/Down-
keys to set the adjustment values and confirm once more with the Enter-
key or cancel with the Mode-key.
Function Value Remark
COLO - 99 - + 99 Color wheel
GOBO - 99 - + 99 Gobo wheel
PRIS - 99 - + 99 Prism wheel
SHT1 - 99 - + 99 Shutter 1
SHT2 - 99 - + 99 Shutter 2
clre Adjustments in the internal circuit.

GLP German Light Production (V1.6) 17
3.10.9 Default Settings (DFSE)
DFSE
Press Enter to reset all fixture personalities (not the adjusted functions) to
the default values. On the display will appear ok to indicate that the de-
faults are set.
Function Display Default Settings
DMX Address D001 D001
Pan reverse RPAN ON OFF 9
Tilt reverse RTLT ON OFF 9
Automatic lamp on LAAU ON OFF 9
Lamp on via DMX DLOF ON 9OFF
Display DISP D ON 9
Cooling fan FANS HIGH REG 9LOOF LOHI
Feedback FEED ON 9OFF
3.10.10Feedback (FEED)
FEED
The Y YP PO OC C 2 25 50 0is provided with a automatic position correction (feedback)
for the Pan and Tilt movement. Use the Up/Down-keys to select ON if you
want to enable the feedback function or Off if you don't want this function.
Press Enter to confirm or Mode to cancel and return to the menu.
3.10.11Correction of faults (EFLG)
EFLG
(Function available for authorized persons only)
3.11 Error and Information Messages
HEAt This message appears if you try to switch on the lamp within 5 minutes
after having switched off (lamp too hot). The message will appear on
the display if the lamp doesn’t ignite within 20 seconds. The fixture will
store this command and automatically ignite the lamp after 5 minutes.
LaeR After the ignition of the lamp was two times not successful the display
will show LAER. That means the lamp could be damaged or even
missed, the fixture is overheating or there could be a failure on the

GLP German Light Production (V1.6) 18
igniter or ballast. Switch off the power supply and solve the possible
problem.
OTMP This error message informs you that the fixture was overheating and
that the relay switches off the lamp. Pleas look for possible reasons
(fan faulty, air in/outlets blocked or very dirty, lamp broken or very old,
too high ambient temperature. Switch off the power supply and solve
the possible problem.
RsER This message informs you that one of the fixture function wasn’t able to
do its reset correct (magnetic sensor, stepping motor, driver on the
PCB, cables, etc.). Repair the defect and start the fixture again.
4 DMX Channel Selection (DMX Protocol)
Channel Function Time and Value DMX HEX %
1) PAN-
coarse 0 .. 530° min. 2,65 s 0..255 00..FF 0..100
2) PAN-fine High- Pos ... High- Pos + 2,1° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse 0 .. 285° min. 1,8 s 0..255 00..FF 0..100
4) Tilt-fine High- Pos … High- Pos + 1,1° (16 Bit) 0..255 00..FF 0..100
5) Color open (fast) 0..1 00..01 0,2
open / color 1 (fast) 2..3 02..03 1,0
color 1, Brilliant Blue (fast)
Chaser from color to
color max. 140 BPM
=> 0,43 s 4..5 04..05 1,8
color 1 / color 2 (fast) 6..7 06..07 2,5
color 2, Blue (fast) 8..9 08..09 3,3
color 2 / color 3 (fast) 10..11 0A..0B 4,1
color 3, Blue Purple (fast) 12..13 0C..0D 4,9
color 3 / color 4 (fast) 14..15 0E..0F 5,7
color 4, Magenta (fast) 16..17 10..11 6,5
color 4 / color 5 (fast) 18..19 12..13 7,3
color 5, Pink (fast) 20..21 14..15 8,0
color 5 / color 6 (fast) 22..23 16..17 8,8
color 6, Orange (fast) 24..25 18..19 9,6
color 6 / color 7 (fast) 26..27 1A..1B 10,4
color 7, Canary (fast) 28..29 1C..1D 11,2
color 7 / color 8 (fast) 30..31 1E..1F 12,0
color 8, Italian Blue (fast) 32..33 20..21 12,7
color 8 / color 9 (fast) 34..35 22..23 13,5
color 9, Turquoise (fast) 36..37 24..25 14,3
color 9 / color 10 (fast) 38..39 26..27 15,1
color 10, Jade (fast) 40..41 28..29 15,9
color 10 / color 11 (fast) 42..43 2A..2B 16,7
color 11, Red (fast) 44..45 2C..2D 17,5
color 11 / open (fast) 46..47 2E..2F 18,2
open (fast) 48..63 30..3F 19,0
open (slow) Chaser from color to 64..65 40..41 25,3

GLP German Light Production (V1.6) 19
Channel Function Time and Value DMX HEX %
open / color 1 (slow) 66..67 42..43 26,1
color 1, Brilliant Blue (slow) color max. 70 BPM
=> 0,86 s 68..69 44..45 26,9
color 1 / color 2 (slow) 70..71 46..47 27,6
color 2, Blue (slow) 72..73 48..49 28,4
color 2 / color 3 (slow) 74..75 4A..4B 29,2
color 3, Blue Purple (slow) 76..77 4C..4D 30,0
color 3 / color 4 (slow) 78..79 4E..4F 30,8
color 4, Magenta (slow) 80..81 50..51 31,6
color 4 / color 5 (slow) 82..83 52..53 32,4
color 5, Pink (slow) 84..85 54..55 33,1
color 5 / color 6 (slow) 86..87 56..57 33,9
color 6, Orange (slow) 88..89 58..59 34,7
color 6 / color 7 (slow) 90..91 5A..5B 35,5
color 7, Canary (slow) 92..93 5C..5D 36,3
color 7 / color 8 (slow) 94..95 5E..5F 37,1
color 8, Italian Blue (slow) 96..97 60..61 37,8
color 8 / color 9 (slow) 98..99 62..63 38,6
color 9, Turquoise (slow) 100..101 64..65 39,4
color 9 / color 10 (slow) 102..103 66..67 40,2
color 10, Jade (slow) 104..105 68..69 41,0
color 10 / color 11 (slow) 106..107 6A..6B 41,8
color 11, Red (slow) 108..109 6C..6D 42,5
color 11 / open (slow) 110..111 6E..6F 43,3
open (slow) 112.127 70..7F 44,1
color rotation, slow-fast, CW min. 1,4 turns/h 128..191 80..BF 50..75
color rotation, fast-slow, CCW max. 2,9 turns/sec. 192..253 C0..FD 76..98
Audio color chaser slow each 4th sound impulse
Ænew color 254 FE 99
Audio color chaser fast each sound impulse Æ
new color 255 FF 100
6) Gobo Gobo 1 (open, fast) 0..7 0..7 0..2,9
Gobo 2 (fast) 8..15 8..F 3..5,9
Gobo 3 (fast)
Chaser from gobo to
gobo max. 100 BPM
=> 0,6 s 16..23 10..17 6..8,9
Gobo 4 (fast) 24..31 18..1F 9..11,9
Gobo 5 (fast) 32..39 20..27 12..14,9
Gobo 6 (fast) 40..47 28..2F 15..17,9
Gobo 7 (fast) 48..55 30..37 18..20,9
Gobo 1 (open, fast) 56..63 38..3F 21..23
Gobo 1 (open, slow) 64..71 40..47 24..26,9
Gobo 2 (slow) 72..79 48..4F 27..29,9
Gobo 3 (slow)
Chaser from gobo to
gobo max. 40 BPM
=> 1,51 s 80..87 50..57 30..33,9
Gobo 4 (slow) 88..95 58..5F 34..36,9
Gobo 5 (slow) 96..103 60..67 37..39,9
Gobo 6 (slow) 104..111 68..6F 40..42,9
Gobo 7 (slow) 112..119 70..77 43..45,9
Gobo 1 (open, slow) 120..127 78..7F 46..49
Gobo rotation, slow-fast, CW min. 1,4 turns/h 128..191 80..BF 50..75
Gobo rotation, fast-slow, CCW max. 1.0 turns/sec. 192..253 C0..FD 76..98
Audio gobo chase, slow each 4th sound impulse
Ænew gobo 254 FE 99
Audio gobo chase, fast each sound impulse Æ
new gobo 255 FF 100
7) Gobo Gobo position 0 ... 540° 0..131 00..7F 0..50
Posi./Rot Gobo rotation, slow-fast, CW min. 2,0 turns/h 132..191 80..BF 51..75

GLP German Light Production (V1.6) 20
Channel Function Time and Value DMX HEX %
Gobo rotation, fast-slow, CCW max. 3,8 turns/sec. 192..253 C0..FD 76..100
Audio gobo rotation, slow each 4th sound impulse
Ænew position 254 FE 99
Audio gobo rotation, fast each sound impulse Æ
new position 255 FF 100
8) Prism Prism swing out 0..5 00..02 0..2
Prism position 0 ... 540° 6..129 00..7F 0..50
Prism rotation, slow-fast, CW min. 1,6 turns/h 130..191 80..BF 51..75
Prism rotation, fast-slow, CCW max. 4,4 turns/sec. 192..253 C0..FD 76..100
Audio prism rotation, slow each 4th sound impulse
Ænew prism 254 FE 99
Audio prism rotation, fast each sound impulse Æ
new prism 255 FF 100
9) Shutter Shutter closed 0..15 00..0F 0..6
Random Strobe (different pattern) 16..31 10..1F 7..11,9
Strobe Pulse effect , slow - fast min. frequent 0,7 Hz 32..47 20..2F 12..12,9
Strobe effect , slow - fast max. frequent 10 Hz 48..239 30..EF 13..93
Shutter open (lamp start) 240..255 F0..FF 94..100
10) Dimmer Dimmer closed (0%) 0..3 0..3 0..1
Dimmer 1%...99% movement time 0,3 sec. 4..251 4..FB 2..98
Dimmer open (100%) 252..255 FC..FF 99..100
11) Focus in - out full distance 1,5 sec. 0..255 0..FF 0..100
12) Special no function 0..15 00..0F 0..6
Gobo-seesaw+/- 10°
slow – fast 3,5 moves / min. up to 60 moves / max. 16..31 10..1F 7..12
Gobo-seesaw +/- 20°
slow – fast 3,5 moves / min. up to 60 moves / max. 32..47 20..2F 13..18
Gobo-seesaw +/- 30°
slow – fast 3,5 moves / min. up to 60 moves / max. 48..63 30..3F 19..24
Color-chaser C / C+1
slow – fast 0,7 BPS ... 2,3 BPS => 1,43 s ... 0,43 s 64..79 40..4F 25..31
Color-chaser C / C+2
slow – fast 0,7 BPS ... 2,0 BPS => 1,43 s ... 0,5 s 80..95 50..5F 32..37
Audio Pan / Tilt slow each 4th sound impulse
Ænew position 96..111 60..6F 38..43
Audio Pan / Tilt fast each sound impulse Æ
new position 112..127 70..7F 44..50
no function 128..249 80..E5 50..97
Lamp OFF (3 sec.) 230..249 E6..F9 92..97
Reset 250..255 FA..FF 98..100
13) Move- no movement 0 00 0
ment Movement Size Phase
PAN 1 0° 01..01 01..01 0,5
1 90° 02..03 02..03 1,0
1 180° 04..05 04..05 1,7
1 270° 06..07 06..07 2,5
PAN 2 0° 08..09 08..09 3,3
2 90° 10..11 0A..0B 4,1
2 180° 12..13 0C..0D 4,9
2 270° 14..15 0E..0F 5,7
PAN 3 0° 16..17 11..11 6,5
3 90° 18..19 12..13 7,3
3 180° 20..21 14..15 8,0
3 270° 22..23 16..17 8,8
