Gocycle 4223 User manual
FRAME PROTECTION PACK
(PRODUCT CODE 4223)
Version 1.0
Assembly of the Gocycle Frame Protection Pack
Assembly Guide: Gocycle Frame Protection Pack
© Karbon Kinetics Limited. All Rights Reserved. i
CONTENTS
Overview.............................................................................................................1
Parts List .............................................................................................................1
Tool List .............................................................................................................1
1. Frame preparation ..........................................................................................2
2. Applying the protectors ...................................................................................3
Assembly Guide: Gocycle Frame Protection Pack
© Karbon Kinetics Limited. All Rights Reserved. 1
OVERVIEW
This document details assembly of the Gocycle Frame Protection Pack.
PARTS LIST
To successfully complete the procedure you will require the following parts.
Note: You may
be able to reuse parts on your Gocycle and as such only need to order parts specific to your
repair:
Part Code
Part Description
Quantity
4223
Frame protection pack
1
TOOL LIST
To successfully complete this procedure, you will require the following tools.
You can
purchase special KKL tools by their tool number detailed below.
Part Code
Tool Description
n/a
If you have any questions, or require any further assistance, please contact
techsupport@gocycle.com
Assembly Guide: Gocycle Frame Protection Pack
© Karbon Kinetics Limited. All Rights Reserved. 2
1. FRAME PREPARATION
1.1. Use the alcohol wipe
included in the pack to clean
all the areas of the frame
where the Protection Pack
will be applied
1.2. Please refer to the
sheet included in the pack to
help identify the correct
protector numbers
1
4
2
5
3
Assembly Guide: Gocycle Frame Protection Pack
© Karbon Kinetics Limited. All Rights Reserved. 3
2. APPLYING THE PROTECTORS
2.1. Protector number 1 is
applied to the raised section
on the left side of the frame,
approximately half way down
2.2. Apply the protector
perpendicular to the raised
section
2.3. To apply protector
number 2, it helps to move
the Lockshock out of the
way. The protector is applied
in the area highlighted.
1
2
Assembly Guide: Gocycle Frame Protection Pack
© Karbon Kinetics Limited. All Rights Reserved. 4
2.4. Apply protector
number 2 as shown. There
should be a small gap
between the protector and
the frame number sticker and
the screw.
2.5. Protector number 3 is
applied to the area
highlighted on the end of the
Cleandrive
2.6. Apply protector
number 3 so it covers the
end of the Cleandrive
2
3
Assembly Guide: Gocycle Frame Protection Pack
© Karbon Kinetics Limited. All Rights Reserved. 5
2.7. Protector number 4 is
applied to the Cleandrive in
the area shown
2.8. Apply protector
number 4 to the Cleandrive
2.9. Protector number 5 is
applied to the front of the
Cleandrive
4
4
Assembly Guide: Gocycle Frame Protection Pack
© Karbon Kinetics Limited. All Rights Reserved. 6
IMPORTANT NOTE: THE ABOVE ASSEMBLY STEPS MUST BE CARRIED OUT IN ORDER.
FAILING TO DO SO MAY RESULT IN DAMAGE TO THE GOCYCLE.
If you have any further queries or comments, please contact Gocycle Technical Support:
techsupport@gocycle.com
2.10. Apply protector
number 5 to the Cleandrive
as shown, ensuring to cover
the split line
2.11. Protector number 5
applied centrally, covering
the split line
