Godox V860IIIF User manual




Before using this product:
Please read this user manual carefully in order to ensure your safety
and the proper operation of this product. Keep for future reference.
TTL
TTL Li-ion Camera Flash
Made in China

:2
:0755-29609320(8062):0755-25723423:[e-mail]
godox.com
Add: Building 2, Yaochuan Industrial Zone, Tangwei Community,
Fuhai Street, Bao’an District, Shenzhen 518103, China
Tel: [phone](8062) Fax: [phone]
E-mail: [email protected]
GODOX Photo Equipment Co., Ltd.
705-V8603F-00
INSTRUCTION MANUAL
   

QCPASS

Always keep this product dry. Do not use in rain or in damp
conditions.
Do not disassemble. Should repairs become necessary, this
product must be sent to an authorized maintenance center.
Keep out of reach of children.
Stop using this product if it breaks open due to extrusion, falling
or strong hit. Otherwise, electric shock may occur if you touch
the electronic parts inside it.
Do not fire the flash directly into the eyes (especially those of
babies) within short distances. Otherwise visual impairment
may occur.
Do not use the flash unit in the presence of flammable gases,
chemicals and other similar materials. In certain circumstance,
these materials may be sensitive to the strong light emitting
from this flash unit and fire or electromagnetic interference may
result.
Do not leave or store the flash unit if the ambient temperature
reads over 50℃. Otherwise the electronic parts may be
damaged.
Turn off the flash unit immediately in the event of malfunction.
Thank you for purchasing this product.
This V860IIIF camera flash applies to FUJIFILM series cameras
and is compatible with TTL autoflash. With this TTL compatible flash,
your shooting will become simpler. You can easily achieve a correct
flash exposure even in complex light-changing environments. This
camera flash features:
● Achieve soft, even and more creative light effects. It has a 2W LED
modeling lamp, which can be used off the camera.
● Approx. GN60 (m ISO 100, @200mm), 81 steps from 1/1 to 1/256.
● 6 max 480Pro 2 00mAh Li-ion Battery- .1.5s recycle- full power pops.
● Fully support FUJIFILM TTL camera flash. Workable as
Transmitter or Receiver unit in a wireless flash group.
● Use dot-matrix LCD panel to make clear and convenient
operations.
● With built-in 2.4GHz wireless remote system to support
transmitting and receiving.
● Provided multiple functions, include HSS (up to 1/8000s), FEC,
FEB, etc.
● Stable consistency and color temperature with good even lighting.
● Support with firmware upgrade.
Warning
Foreword
- 29 - - 30 -

Always keep this product dry. Do not use in rain or in damp
conditions.
Do not disassemble. Should repairs become necessary, this
product must be sent to an authorized maintenance center.
Keep out of reach of children.
Stop using this product if it breaks open due to extrusion, falling
or strong hit. Otherwise, electric shock may occur if you touch
the electronic parts inside it.
Do not fire the flash directly into the eyes (especially those of
babies) within short distances. Otherwise visual impairment
may occur.
Do not use the flash unit in the presence of flammable gases,
chemicals and other similar materials. In certain circumstance,
these materials may be sensitive to the strong light emitting
from this flash unit and fire or electromagnetic interference may
result.
Do not leave or store the flash unit if the ambient temperature
reads over 50℃. Otherwise the electronic parts may be
damaged.
Turn off the flash unit immediately in the event of malfunction.
Thank you for purchasing this product.
This V860IIIF camera flash applies to FUJIFILM series cameras
and is compatible with TTL autoflash. With this TTL compatible flash,
your shooting will become simpler. You can easily achieve a correct
flash exposure even in complex light-changing environments. This
camera flash features:
● Achieve soft, even and more creative light effects. It has a 2W LED
modeling lamp, which can be used off the camera.
● Approx. GN60 (m ISO 100, @200mm), 81 steps from 1/1 to 1/256.
● 6 max 480Pro 2 00mAh Li-ion Battery- .1.5s recycle- full power pops.
● Fully support FUJIFILM TTL camera flash. Workable as
Transmitter or Receiver unit in a wireless flash group.
● Use dot-matrix LCD panel to make clear and convenient
operations.
● With built-in 2.4GHz wireless remote system to support
transmitting and receiving.
● Provided multiple functions, include HSS (up to 1/8000s), FEC,
FEB, etc.
● Stable consistency and color temperature with good even lighting.
● Support with firmware upgrade.
Warning
Foreword
- 29 - - 30 -

Foreword
Warning
Name of Parts
Body
Control Panel
Dot-matrix LCD Panel
LCD Panel in Three Modes
What's in the Box of V860IIIF Kit?
Separately Sold Accessories
Battery
LED Modeling Lamp
Attaching to a Camera
Power Management
Flash Mode — TTL Autoflash
FEC (Flash Exposure Compensation)
High-Speed Sync
Second-Curtain Sync
M: Manual Flash
Multi: Stroboscopic Flash
Wireless Flash Shooting: Radio (2.4G) Transmission
Wireless Settings
Group Mode Selection
Setting the Communication Channel
Wireless ID Settings
Scan the Spare Channel
Fully Automatic Wireless Flash Shooting
M: Wireless Flash Shooting with Manual Flash
Multi: Wireless Flash Shooting with Manual Flash
TTL/M Shortcut Function
Lock Function
Other Applications
Sync Triggering
Modeling Flash
Auto Focus Assist Beam
Bounce Flash
ZOOM: Setting the Flash Coverage
Low Battery Warning
C.Fn: Setting Custom Functions
Protection Function
Technical Data
Troubleshooting
Firmware Upgrade
Compatible Camera Models
Maintenance
Contents
Conventions used in this Manual
● This manual is based on the assumption that both the camera
and camera flash’s power switches are powered on.
● Reference page numbers are indicated by “p.**”.
● The following alert symbols are used in this manual:
The Caution symbol gives supplemental information.
The Note symbol indicates a warning to prevent shooting
problem.
Pioneering TTL Li-ion Round Head Camera Flash
- 31 - - 32 -
29
30
33
37
38
38
38
39
41
42
43
50
51
52
53
54
55
56
56
56

Foreword
Warning
Name of Parts
Body
Control Panel
Dot-matrix LCD Panel
LCD Panel in Three Modes
What's in the Box of V860IIIF Kit?
Separately Sold Accessories
Battery
LED Modeling Lamp
Attaching to a Camera
Power Management
Flash Mode — TTL Autoflash
FEC (Flash Exposure Compensation)
High-Speed Sync
Second-Curtain Sync
M: Manual Flash
Multi: Stroboscopic Flash
Wireless Flash Shooting: Radio (2.4G) Transmission
Wireless Settings
Group Mode Selection
Setting the Communication Channel
Wireless ID Settings
Scan the Spare Channel
Fully Automatic Wireless Flash Shooting
M: Wireless Flash Shooting with Manual Flash
Multi: Wireless Flash Shooting with Manual Flash
TTL/M Shortcut Function
Lock Function
Other Applications
Sync Triggering
Modeling Flash
Auto Focus Assist Beam
Bounce Flash
ZOOM: Setting the Flash Coverage
Low Battery Warning
C.Fn: Setting Custom Functions
Protection Function
Technical Data
Troubleshooting
Firmware Upgrade
Compatible Camera Models
Maintenance
Contents
Conventions used in this Manual
● This manual is based on the assumption that both the camera
and camera flash’s power switches are powered on.
● Reference page numbers are indicated by “p.**”.
● The following alert symbols are used in this manual:
The Caution symbol gives supplemental information.
The Note symbol indicates a warning to prevent shooting
problem.
Pioneering TTL Li-ion Round Head Camera Flash
- 31 - - 32 -
29
30
33
37
38
38
38
39
41
42
43
50
51
52
53
54
55
56
56
56

● LCD Panel
Name of Parts
(1)TTL Autoflash
Zoom : zoom display (Page 51)
: Automatic
: Manual(Page 41)
TTL : TTL
autoflash
Focus length (Page 1)5
Distance indicator
display
Flash exposure
compensation amount
(2)M Manual Flash
● The display will only show the settings currently applied.
● When a button or dial is operated, the LCD panel illuminated.
M : Manual flash
Manual flash output
(3) Multi Flash
Multi: Stroboscopic flash
Number of flashes
Flash frequency
- 33 - - 34 -
01. Flash Head
02. LED Modeling Lamp
03. Focus Assist Beam
04. Wireless Sensor
05. Sync Cord Jack
06. Type-C USB Port
07. Battery Remove Button
08. Hotshoe
09. LCD Panel
10. Hotshoe Fixing Buckle
11. Lithium Battery
12. TTL/M Shortcut
● Body
● Control Panel
09
05
07
08
04
03
01
06
02 10
12
11
19
20
22 21
18
24 25
16
14
13
26
17
23
15
13. <MENU>Flash Menu
Button/Locking Button
14. < >Wireless Selection
Button
15. Select Dial
16. Set Button
17. ON/OFF Power Switch
18. < > Test Button / Flash
Ready Indicator
19. <ZOOM> Focus Length
Setting
20. <MODE>Mode Selection
Button
21. < >Modeling Lamp Setting
22. <+/->Power Output
23. Function Button 1
24. Function Button 2
25. Function Button 3
26. Function Button 4

● LCD Panel
Name of Parts
(1)TTL Autoflash
Zoom : zoom display (Page 51)
: Automatic
: Manual(Page 41)
TTL : TTL
autoflash
Focus length (Page 1)5
Distance indicator
display
Flash exposure
compensation amount
(2)M Manual Flash
● The display will only show the settings currently applied.
● When a button or dial is operated, the LCD panel illuminated.
M : Manual flash
Manual flash output
(3) Multi Flash
Multi: Stroboscopic flash
Number of flashes
Flash frequency
- 33 - - 34 -
01. Flash Head
02. LED Modeling Lamp
03. Focus Assist Beam
04. Wireless Sensor
05. Sync Cord Jack
06. Type-C USB Port
07. Battery Remove Button
08. Hotshoe
09. LCD Panel
10. Hotshoe Fixing Buckle
11. Lithium Battery
12. TTL/M Shortcut
● Body
● Control Panel
09
05
07
08
04
03
01
06
02 10
12
11
19
20
22 21
18
24 25
16
14
13
26
17
23
15
13. <MENU>Flash Menu
Button/Locking Button
14. < >Wireless Selection
Button
15. Select Dial
16. Set Button
17. ON/OFF Power Switch
18. < > Test Button / Flash
Ready Indicator
19. <ZOOM> Focus Length
Setting
20. <MODE>Mode Selection
Button
21. < >Modeling Lamp Setting
22. <+/->Power Output
23. Function Button 1
24. Function Button 2
25. Function Button 3
26. Function Button 4

Firing group
Flash mode
Channel
: Radio transmission
wireless shooting
(4) Radio Transmission Shooting
● Transmitter Unit (TX)
● Receiver Unit (RX)
: Receiver
: Receiver icon
● LCD Panel in Three Modes
● Attached to the Camera
● 2.4G Radio Transmission: As a Transmitter Unit
● 2.4G Radio Transmission: As a Receiver Unit
● What’s in the Box of V860IIIF Kit?
1. Flash Unit 2. Lithium Battery 3. USB Battery Charger
4. USB Cable 5. Charger 6. Mini Stand
7. Protection Case 8. Instruction Manual
● Separately Sold Accessories
The product can be used in combination with the following accessories
sold separately, so as to achieve best photography effects:
XProF, X2T-F & X1F TTL wireless flash trigger, etc.
- 35 - - 36 -
Note: The flash unit attached to the camera is referred to as the "Transmitter",
and other flash units controlled wirelessly are referred to as "Receivers".
RX
RX
RX
Gr CH
M A B C
Gr CH
1 2 3
67 5

Firing group
Flash mode
Channel
: Radio transmission
wireless shooting
(4) Radio Transmission Shooting
● Transmitter Unit (TX)
● Receiver Unit (RX)
: Receiver
: Receiver icon
● LCD Panel in Three Modes
● Attached to the Camera
● 2.4G Radio Transmission: As a Transmitter Unit
● 2.4G Radio Transmission: As a Receiver Unit
● What’s in the Box of V860IIIF Kit?
1. Flash Unit 2. Lithium Battery 3. USB Battery Charger
4. USB Cable 5. Charger 6. Mini Stand
7. Protection Case 8. Instruction Manual
● Separately Sold Accessories
The product can be used in combination with the following accessories
sold separately, so as to achieve best photography effects:
XProF, X2T-F & X1F TTL wireless flash trigger, etc.
- 35 - - 36 -
Note: The flash unit attached to the camera is referred to as the "Transmitter",
and other flash units controlled wirelessly are referred to as "Receivers".
RX
RX
RX
Gr CH
M A B C
Gr CH
1 2 3
67 5

● Features
1. This flash unit uses Li-ion battery which has long runtime.
The available charge-and-discharge times are 480.
2. It is reliably safe. The inner circuit is against overcharge,
overdischarge, overcurrent, and short circuit.
3. Take only 3.5 hours to fully charge the battery by using the
standard battery charger.
● Cautions
1. Do not short circuit.
2. Do not expose to rain or immerse into water. This battery is not
water proof.
3. Keep out of reach of children.
4. No over 24 hours’ continuous charging.
5. Store in dry, cool, ventilated places.
6. Do not put aside or into fire.
7. Dead batteries should be disposed according to local regulations.
8. If the battery had ceased using for over 3 months, please make a
full recharge.
9. If do not use it for a long time, please charge the battery to
approx. 60% before placing it.
10. It is recommended to use a brand-new battery after charging
and discharging over 500 times or being used over 3 years.
● Loading and Unloading the Battery
Battery
To unload the battery, hold
1down the battery remove
button and push the battery
downwardly to take it out.
According to the triangle sign
2on the battery pack, insert it
into the compartment until a
white knob locks the battery
with a click sound.
● Battery Level Indication
Make sure the battery pack is securely loaded in the flash. Check
the battery level indication on the LCD panel to see the remaining
battery level.
Battery Level Indication
3 grids
2 grids
1 grid
Blank grid
Blinking
Attaching to a Camera
Attach the Camera Flash.
1● Rotate the hotshoe fixing
buckle to the left and insert
the camera flash into the
camera's hotshoe.
Secure the Camera Flash.
2● Rotate the hotshoe fixing
buckle to the right until it
locks up.
Detach the Camera Flash.
3● Press the button and
rotate the hotshoe fixing
buckle to the left until it is
loosened.
Power Management
Use ON/OFF Power Switch to power the flash unit on or off. Turn
off if it will not be used for an extended period of time. Setting as a
transmitter flash, it will turn the power off automatically after a
certain period (approx. 90 seconds) of idle use. Pressing the
camera shutter halfway or pressing any flash button will wake up
the flash unit. Setting as a receiver flash, it will enter sleep mode
after a certain period (adjustable, 60 minutes by default) of idle use.
Pressing any flash button will wake it up.
The battery level is going to be used out
immediately. And the flash will auto power off
in 1 minute.
Note: Please recharge the battery as soon as
possible (within 10 days). Then, the battery can be
used or be placed for long period.
Meaning
Full
Middle
Low
Lower battery, please recharge it.
Press the Modeling Lamp Setting button to set the modeling lamp.
Short press the Set Button to turn on or off the modeling lamp.
When turning the modeling lamp on, turn the select dial to set its
brightness. There are 10 levels(01~10) for choice.
- 37 - - 38 -
LED Modeling Lamp
MODEL
ON/OFF

● Features
1. This flash unit uses Li-ion battery which has long runtime.
The available charge-and-discharge times are 480.
2. It is reliably safe. The inner circuit is against overcharge,
overdischarge, overcurrent, and short circuit.
3. Take only 3.5 hours to fully charge the battery by using the
standard battery charger.
● Cautions
1. Do not short circuit.
2. Do not expose to rain or immerse into water. This battery is not
water proof.
3. Keep out of reach of children.
4. No over 24 hours’ continuous charging.
5. Store in dry, cool, ventilated places.
6. Do not put aside or into fire.
7. Dead batteries should be disposed according to local regulations.
8. If the battery had ceased using for over 3 months, please make a
full recharge.
9. If do not use it for a long time, please charge the battery to
approx. 60% before placing it.
10. It is recommended to use a brand-new battery after charging
and discharging over 500 times or being used over 3 years.
● Loading and Unloading the Battery
Battery
To unload the battery, hold
1down the battery remove
button and push the battery
downwardly to take it out.
According to the triangle sign
2on the battery pack, insert it
into the compartment until a
white knob locks the battery
with a click sound.
● Battery Level Indication
Make sure the battery pack is securely loaded in the flash. Check
the battery level indication on the LCD panel to see the remaining
battery level.
Battery Level Indication
3 grids
2 grids
1 grid
Blank grid
Blinking
Attaching to a Camera
Attach the Camera Flash.
1● Rotate the hotshoe fixing
buckle to the left and insert
the camera flash into the
camera's hotshoe.
Secure the Camera Flash.
2● Rotate the hotshoe fixing
buckle to the right until it
locks up.
Detach the Camera Flash.
3● Press the button and
rotate the hotshoe fixing
buckle to the left until it is
loosened.
Power Management
Use ON/OFF Power Switch to power the flash unit on or off. Turn
off if it will not be used for an extended period of time. Setting as a
transmitter flash, it will turn the power off automatically after a
certain period (approx. 90 seconds) of idle use. Pressing the
camera shutter halfway or pressing any flash button will wake up
the flash unit. Setting as a receiver flash, it will enter sleep mode
after a certain period (adjustable, 60 minutes by default) of idle use.
Pressing any flash button will wake it up.
The battery level is going to be used out
immediately. And the flash will auto power off
in 1 minute.
Note: Please recharge the battery as soon as
possible (within 10 days). Then, the battery can be
used or be placed for long period.
Meaning
Full
Middle
Low
Lower battery, please recharge it.
Press the Modeling Lamp Setting button to set the modeling lamp.
Short press the Set Button to turn on or off the modeling lamp.
When turning the modeling lamp on, turn the select dial to set its
brightness. There are 10 levels(01~10) for choice.
- 37 - - 38 -
LED Modeling Lamp
MODEL
ON/OFF

Flash Mode — TTL Autoflash
This flash has three flash modes: TTL, Manual (M), and Multi
(Stroboscopic). In TTL mode, the camera and the flash will work
together to calculate the correct exposure for the subject and the
background. In this mode, multiple TTL functions are available:
FEC, HSS, second curtain sync, modeling flash.
* Press < MODE > Mode Selection Button and three flash modes
will display on the LCD panel one by one with each pressing.
TTL Mode
Press < MODE > Mode Selection Button to enter TTL mode. The
LCD panel will display.
● Press the camera release button halfway to focus. The aperture
and effective flash range will be displayed in the viewfinder.
● When the shutter button is fully pressed, the flash will fire a pre-
flash that the camera will use to calculate exposure and flash
output the instant before the photo is taken.
FEC: Flash Exposure Compensation
With FEC function, this flash can adjust from -3 to +3 in 1/3rd stops.
It is useful in situations where minor adjusting of the TTL system is
needed based on the environment.
Setting FEC:
Set the flash exposure
2compensation amount.
● Turn the Select Dial to set
the amount.
● “0.3”means 1/3 step,
“0.7”means 2/3 step.
● To cancel the flash
exposure compensation,
set the amount to “+0”.
Press Set Button again to
3confirm the setting.
Press the <+/-> button. The
1flash exposure compensation
amount will be highlighted on
the LCD panel.
C.Fn
C.Fn
Disabling Auto Power Off function is recommended when
the flash is used off camera. (C.Fn-STBY, Page 52)
Receiver Auto Power Off Timer is set to 60 minutes by
default. Another option “30 minutes” is available. (C.Fn-
RX STBY, Page 52)
- 39 - - 40 -

Flash Mode — TTL Autoflash
This flash has three flash modes: TTL, Manual (M), and Multi
(Stroboscopic). In TTL mode, the camera and the flash will work
together to calculate the correct exposure for the subject and the
background. In this mode, multiple TTL functions are available:
FEC, HSS, second curtain sync, modeling flash.
* Press < MODE > Mode Selection Button and three flash modes
will display on the LCD panel one by one with each pressing.
TTL Mode
Press < MODE > Mode Selection Button to enter TTL mode. The
LCD panel will display.
● Press the camera release button halfway to focus. The aperture
and effective flash range will be displayed in the viewfinder.
● When the shutter button is fully pressed, the flash will fire a pre-
flash that the camera will use to calculate exposure and flash
output the instant before the photo is taken.
FEC: Flash Exposure Compensation
With FEC function, this flash can adjust from -3 to +3 in 1/3rd stops.
It is useful in situations where minor adjusting of the TTL system is
needed based on the environment.
Setting FEC:
Set the flash exposure
2compensation amount.
● Turn the Select Dial to set
the amount.
● “0.3”means 1/3 step,
“0.7”means 2/3 step.
● To cancel the flash
exposure compensation,
set the amount to “+0”.
Press Set Button again to
3confirm the setting.
Press the <+/-> button. The
1flash exposure compensation
amount will be highlighted on
the LCD panel.
C.Fn
C.Fn
Disabling Auto Power Off function is recommended when
the flash is used off camera. (C.Fn-STBY, Page 52)
Receiver Auto Power Off Timer is set to 60 minutes by
default. Another option “30 minutes” is available. (C.Fn-
RX STBY, Page 52)
- 39 - - 40 -

The flash output is adjustable from 1/1 full power to 1/256th power
in 1/10th stop increments. To obtain a correct flash exposure, use a
hand-held flash meter to determine the required flash output.
M: Manual Flash
Press < MODE > button so
1that < M > is displayed.
Press the <+/-> button and turn
2the Select Dial to choose a
desired flash output amount.
Press Set Button again to
3confirm the setting.
Optic S1 Secondary Unit Setting
In M manual flash mode, press <S1/S2> button so that this flash can
function as an optic S1 secondary flash with optic sensor. With this
function, the flash will fire synchronously when the main flash fires,
the same effect as that by the use of radio triggers. This helps create
multiple lighting effects.
Optic S2 Secondary Unit Setting
Press <S1/S2> button so that this flash can also function as an optic
S2 secondary flash with optic sensor in M manual flash mode. This
is useful when cameras have pre-flash function. With this function,
the flash will ignore a single “preflash” from the main flash and will
only fire in response to the second, actual flash from the main unit.
● S1 and S2 optic triggering is only available in M manual
flash mode.
Press the <+/-> button and
3turn the Select Dial to choose
a desired flash output.
● After you finish the setting,
press Set Button and all the
settings will be displayed.
Multi: Stroboscopic Flash
With stroboscopic flash, a rapid series of flashes is fired. It can be
used to capture a multiple images of a moving subject in a single
photograph.
You can set the firing frequency (number of flashes per sec.
expressed as Hz), the number of flashes, and the flash output.
Press <MODE> button so
1that < > is displayed.
Calculating the Shutter Speed
During stroboscopic flash, the shutter remains open until the firing
stops. Use the formula below to calculate the shutter speed and set
it with the camera.
For example, if the number of flashes is 10 and the firing frequency is
5 Hz, the shutter speed should be at least 2 seconds.
Number of Flashes / Flash Frequency = Shutter Speed
To avoid overheating and deteriorating the flash head, do not
use stroboscopic flash more than 10 times in succession.
After 10 times, allow the camera flash to rest for at least 15
minutes. If you try to use the stroboscopic flash more than 10
times in succession, the firing might stop automatically to
protect the flash head. If this happens, allow at least 15
minutes’ rest for the camera flash.
● Stroboscopic flash is most effective with a highly reflective
subject against a dark background.
● Using a tripod and a remote control is recommended.
● A flash output of 1/1 and 1/2 cannot be set for stroboscopic
flash.
● Stroboscopic flash can be used with“buLb”.
● If the number of flashes is displayed as “--”, the firing will
continue until the shutter closes or the battery is
exhausted. The number of flashes will be limited as shown
by the following table.
Multi
Set the flash frequency and
2flash times.
● Press the Function Button
2 <Times> to select the
flash times. Turn the Select
Dial to set the number.
● Press the Function Button
3 <Hz> to select the flash
frequency. Turn the Select
Dial to set the number.
- 41 - - 42 -

The flash output is adjustable from 1/1 full power to 1/256th power
in 1/10th stop increments. To obtain a correct flash exposure, use a
hand-held flash meter to determine the required flash output.
M: Manual Flash
Press < MODE > button so
1that < M > is displayed.
Press the <+/-> button and turn
2the Select Dial to choose a
desired flash output amount.
Press Set Button again to
3confirm the setting.
Optic S1 Secondary Unit Setting
In M manual flash mode, press <S1/S2> button so that this flash can
function as an optic S1 secondary flash with optic sensor. With this
function, the flash will fire synchronously when the main flash fires,
the same effect as that by the use of radio triggers. This helps create
multiple lighting effects.
Optic S2 Secondary Unit Setting
Press <S1/S2> button so that this flash can also function as an optic
S2 secondary flash with optic sensor in M manual flash mode. This
is useful when cameras have pre-flash function. With this function,
the flash will ignore a single “preflash” from the main flash and will
only fire in response to the second, actual flash from the main unit.
● S1 and S2 optic triggering is only available in M manual
flash mode.
Press the <+/-> button and
3turn the Select Dial to choose
a desired flash output.
● After you finish the setting,
press Set Button and all the
settings will be displayed.
Multi: Stroboscopic Flash
With stroboscopic flash, a rapid series of flashes is fired. It can be
used to capture a multiple images of a moving subject in a single
photograph.
You can set the firing frequency (number of flashes per sec.
expressed as Hz), the number of flashes, and the flash output.
Press <MODE> button so
1that < > is displayed.
Calculating the Shutter Speed
During stroboscopic flash, the shutter remains open until the firing
stops. Use the formula below to calculate the shutter speed and set
it with the camera.
For example, if the number of flashes is 10 and the firing frequency is
5 Hz, the shutter speed should be at least 2 seconds.
Number of Flashes / Flash Frequency = Shutter Speed
To avoid overheating and deteriorating the flash head, do not
use stroboscopic flash more than 10 times in succession.
After 10 times, allow the camera flash to rest for at least 15
minutes. If you try to use the stroboscopic flash more than 10
times in succession, the firing might stop automatically to
protect the flash head. If this happens, allow at least 15
minutes’ rest for the camera flash.
● Stroboscopic flash is most effective with a highly reflective
subject against a dark background.
● Using a tripod and a remote control is recommended.
● A flash output of 1/1 and 1/2 cannot be set for stroboscopic
flash.
● Stroboscopic flash can be used with“buLb”.
● If the number of flashes is displayed as “--”, the firing will
continue until the shutter closes or the battery is
exhausted. The number of flashes will be limited as shown
by the following table.
Multi
Set the flash frequency and
2flash times.
● Press the Function Button
2 <Times> to select the
flash times. Turn the Select
Dial to set the number.
● Press the Function Button
3 <Hz> to select the flash
frequency. Turn the Select
Dial to set the number.
- 41 - - 42 -

Hz
Maximum Stroboscopic Flashes:
Flash
output
Hz
Flash
output
Wireless Flash Shooting: Radio (2.4G) Transmission
● You can set up five receiver groups for TTL autoflash shooting.
With TTL autoflash, you can easily create various lighting effects.
● Any flash settings for the receiver units(auto flash, manual flash
and stroboscopic flash) on the transmitter flash in TTL mode will
be automatically sent to the receiver units. So the only thing you
need to do is to set the transmitter unit for each receiver group
without any operation for the receiver units at all during the
shooting.
● This flash can work in TTL /M /Multi/ OFF flash modes when set
as a transmitter unit.
Note:
● Even with multiple receiver units, the X series flash trigger
can control all of them via wireless.
● In this user manual, “transmitter unit” refers to the camera
flash on a camera and “receiver unit” will be controlled by
the transmitter unit.
1/4
1/8
1/16
1/32
1/64
1/128
1/256
1
8
14
30
60
90
90
90
2
6
14
30
60
90
90
90
3
4
12
30
60
90
90
90
4
3
10
20
50
80
90
90
5
3
8
20
50
80
90
90
6-7
2
6
20
40
70
90
90
8-9
2
5
10
30
60
80
80
1/4
1/8
1/16
1/32
1/64
1/128
1/256
10
2
4
8
20
50
70
70
20-50
2
4
8
16
30
40
40
60-100
2
4
8
12
20
40
40
Positioning and Operation Range (Example of wireless flash
shooting)
● Autoflash Shooting with One Receiver Unit
● Use the supplied mini stand to position the receiver unit.
● Before shooting, perform a test flash and test shooting.
● The transmission distance might be shorter depending on
the conditions such as positioning of receiver units, the
surrounding environment and whether conditions.
● Auto Shooting with Two Receiver Groups
● Auto Shooting with Three Receiver Groups
You can divide the receiver units into two or three groups and
perform TTL autoflash while changing the flash ratio (factor). In
addition, you can set and shoot with a different flash mode for each
firing group, for up to 5 groups.
Wireless Multiple Flash Shooting
- 43 - - 44 -
Transmission distance is about 100m.
A
B
TRANSMITTER
RECEIVER
A
B
C

Hz
Maximum Stroboscopic Flashes:
Flash
output
Hz
Flash
output
Wireless Flash Shooting: Radio (2.4G) Transmission
● You can set up five receiver groups for TTL autoflash shooting.
With TTL autoflash, you can easily create various lighting effects.
● Any flash settings for the receiver units(auto flash, manual flash
and stroboscopic flash) on the transmitter flash in TTL mode will
be automatically sent to the receiver units. So the only thing you
need to do is to set the transmitter unit for each receiver group
without any operation for the receiver units at all during the
shooting.
● This flash can work in TTL /M /Multi/ OFF flash modes when set
as a transmitter unit.
Note:
● Even with multiple receiver units, the X series flash trigger
can control all of them via wireless.
● In this user manual, “transmitter unit” refers to the camera
flash on a camera and “receiver unit” will be controlled by
the transmitter unit.
1/4
1/8
1/16
1/32
1/64
1/128
1/256
1
8
14
30
60
90
90
90
2
6
14
30
60
90
90
90
3
4
12
30
60
90
90
90
4
3
10
20
50
80
90
90
5
3
8
20
50
80
90
90
6-7
2
6
20
40
70
90
90
8-9
2
5
10
30
60
80
80
1/4
1/8
1/16
1/32
1/64
1/128
1/256
10
2
4
8
20
50
70
70
20-50
2
4
8
16
30
40
40
60-100
2
4
8
12
20
40
40
Positioning and Operation Range (Example of wireless flash
shooting)
● Autoflash Shooting with One Receiver Unit
● Use the supplied mini stand to position the receiver unit.
● Before shooting, perform a test flash and test shooting.
● The transmission distance might be shorter depending on
the conditions such as positioning of receiver units, the
surrounding environment and whether conditions.
● Auto Shooting with Two Receiver Groups
● Auto Shooting with Three Receiver Groups
You can divide the receiver units into two or three groups and
perform TTL autoflash while changing the flash ratio (factor). In
addition, you can set and shoot with a different flash mode for each
firing group, for up to 5 groups.
Wireless Multiple Flash Shooting
- 43 - - 44 -
Transmission distance is about 100m.
A
B
TRANSMITTER
RECEIVER
A
B
C

Press < > button so that < >
or < > are displayed on
the LCD panel.
Receiver Unit Setting
Transmitter Unit Setting
Press < > button so that < >
is displayed on the LCD panel.
2. Group Mode Selection
Short press the Function
1Button 1 and <M> group
can be changed in
OFF/TTL/M. Choose one of
them as transmitter unit's
flash mode.
Short press the <MODE>
2button to gain Multi mode.
1. Wireless Settings
You can switch between normal flash and wireless flash. For normal
flash shooting, be sure to set the wireless setting to OFF.
3. Setting the Communication Channel
If there are other wireless flash systems nearby, you can change the
channel IDs to prevent signal interference. The channel IDs of the
transmitter unit and the receiver unit(s) must be set to the same.
Press <MENU> Button to
1enter C.Fn CH setting.
In C.Fn CH, turn the Select
2Dial to choose channel ID
from 1 to 32.
Press the Set Button to
3confirm.
4. Wireless ID Settings
Change the wireless channels and wireless ID to avoid interference
for it can only be triggered after the wireless IDs and channels of the
transmitter unit and the receiver unit are set to the same.Press the
<MENU> button to enter C.Fn ID. Press the Set Button to choose OFF
channel expansion shutdown, and choose any figure from 01 to 99.
5. Scan the Spare Channel
To avoid the interference of using the same channel by others, this
function can be used: enter the C.Fn settings and find the SCAN
option. When setting it to START, it will scan from 1% to 100%. And
the 8 spare channels will be displayed after the scan is completed.
6. TTLFully Automatic Wireless Flash Shooting
Using Automatic Wireless Flash with a Single Receiver Unit
Transmitter Unit Setting
1● Attach a camera V860IIIF
flash on the camera and
set it as the transmitter
unit.
● M/A/B/C can be set as TTL
mode independently.
C.Fn Ver 0.5
CLEAR
CH
ID
BEEP
STBY
07
SCAN
C.Fn Ver 0.5
CLEAR
CH
ID
BEEP
SCAN
22 08 32 23
30 21 07 06
C.Fn Ver 0.5
CLEAR
CH
ID
BEEP
STBY
99
SCAN
- 45 - - 46 -
RX
RX

Press < > button so that < >
or < > are displayed on
the LCD panel.
Receiver Unit Setting
Transmitter Unit Setting
Press < > button so that < >
is displayed on the LCD panel.
2. Group Mode Selection
Short press the Function
1Button 1 and <M> group
can be changed in
OFF/TTL/M. Choose one of
them as transmitter unit's
flash mode.
Short press the <MODE>
2button to gain Multi mode.
1. Wireless Settings
You can switch between normal flash and wireless flash. For normal
flash shooting, be sure to set the wireless setting to OFF.
3. Setting the Communication Channel
If there are other wireless flash systems nearby, you can change the
channel IDs to prevent signal interference. The channel IDs of the
transmitter unit and the receiver unit(s) must be set to the same.
Press <MENU> Button to
1enter C.Fn CH setting.
In C.Fn CH, turn the Select
2Dial to choose channel ID
from 1 to 32.
Press the Set Button to
3confirm.
4. Wireless ID Settings
Change the wireless channels and wireless ID to avoid interference
for it can only be triggered after the wireless IDs and channels of the
transmitter unit and the receiver unit are set to the same.Press the
<MENU> button to enter C.Fn ID. Press the Set Button to choose OFF
channel expansion shutdown, and choose any figure from 01 to 99.
5. Scan the Spare Channel
To avoid the interference of using the same channel by others, this
function can be used: enter the C.Fn settings and find the SCAN
option. When setting it to START, it will scan from 1% to 100%. And
the 8 spare channels will be displayed after the scan is completed.
6. TTLFully Automatic Wireless Flash Shooting
Using Automatic Wireless Flash with a Single Receiver Unit
Transmitter Unit Setting
1● Attach a camera V860IIIF
flash on the camera and
set it as the transmitter
unit.
● M/A/B/C can be set as TTL
mode independently.
C.Fn Ver 0.5
CLEAR
CH
ID
BEEP
STBY
07
SCAN
C.Fn Ver 0.5
CLEAR
CH
ID
BEEP
SCAN
22 08 32 23
30 21 07 06
C.Fn Ver 0.5
CLEAR
CH
ID
BEEP
STBY
99
SCAN
- 45 - - 46 -
RX
RX

Receiver Unit Setting
2● Set the V860IIIF that to be
controlled as the wireless
receiver unit.
● The receiver unit can be
set as A/B/C/D/E.
Check the communication
3channel.
● If the transmitter unit and
receiver unit(s) are set to a
different channel, set them
to the same channel.
(Page 45)
Check that the flash is
5ready.
● Check that the transmitter
flash ready indicator is
lightened.
Check the flash operation.
6● Press the transmitter unit’s
Test Button < >.
● Then, the receiver unit will
fire. If not, adjust the
receiver unit’s angle toward
the transmitter unit and
distance from the
transmitter unit.
Position the camera and
4flashes.
● Position the camera and
flashes as the picture
shows. (Page 44)
Using Automatic Wireless Flash with Multiple Receiver Units
When stronger flash output or
more convenient lighting operation
is needed, increase the number of
receiver units and set it as a
single receiver unit.
To add receiver units, use the
same steps as setting “automatic
wireless flash with a single
receiver unit”. Any flash group can
be set (A/B/C/D/E).
When the number of receiver units
is increased and the transmitter
unit flash firing is ON, automatic
control is implemented to make all
groups of flashes fire the same
flash output and ensure the total
flash output up is to standard
exposure.
● If the receiver unit’s auto power off function is workable, press the
transmitter unit’s test button to power it on. Please note that test firing is
unavailable during the camera’s regular metering time.
● The effective time of receiver auto power off is changeable. (C.Fn-RX
STBY Page 55)
Using Fully Automatic Wireless Flash
The FEC and other settings that set on the transmitter unit will also
be appeared on the receiver unit automatically. The receiver unit
does not need any operation. Use the following settings to make
wireless flashes according to the same methods with normal flash
shooting.
● Flash Exposure Compensation ( Page 39)
About Transmitter Unit
Use two or more transmitter units. By preparing several cameras
that with transmitter units flash attached, cameras can be changed
in shooting while keeping the same lighting source (receiver unit).
- 47 - - 48 -
RX
Gr CH
