Godox WH-M1 User manual

WH-M1⽆线⼿持⻨克⻛发射器说明书±2mmA75x150mm项⽬类型项⽬名称产品料号尺⼨(mm)尺⼨公差材质⼯艺说明105g铜版纸正反印刷,单⾊骑⻢钉赖慧怡版本设计师备注/⾊值校对GODOX设计⽂件图注赖慧怡

神牛微信公众号Follow Wechat Public Account地址: 深圳市宝安区福海街道塘尾社区耀川工业区厂房2栋电话: [phone](8062) 传真: [phone] 深圳市神⽜摄影器材有限公司邮箱: [email protected] GODOXPhotoEquipmentCo.,Ltd.Made In ChinaAdd: Building 2, Yaochuan Industrial Zone,Tangwei Communi-ty, Fuhai Street, Bao’an District, Shenzhen 518103, ChinaTel: [phone](8062) Fax: [phone] E-mail: [email protected] godox.comInstruction ManualWireless Handheld Microphone Transmitter

前言警告② 广播级音质，清晰稳定③ 无线距离最大可达80m ④ OLED显示屏提供各项参数设置⑤ 输出音量控制，提供静音功能⑥ 发射功率可调节产品特点
只能使用本手册中列出的电池。请勿混用新旧电池或不同类型的
电池。请仔细阅读并遵守由厂商提供的警告或指示。切勿使电池短路或拆卸电池。切勿将电池投入火中或加热升温。切勿试图以反方向安装电池。
当电量用尽时，电池容易漏液。所以为了避免产品受损，请在长
期不使用本产品或电量用尽时取出电池。
如果受损电池中的液体接触到皮肤或衣服，请立即用大量清水冲洗。
请勿私自拆卸产品，如产品出现故障须由本公司或授权的维修人
员进行检查维修。
请保持干燥：请勿用湿手接触产品，亦不可将产品浸入水中或暴
露于雨中。请勿让儿童接触本产品。
请勿在易燃易爆环境中使用。在这些场合下，请注意相关警告标识。
请勿放置在超过40度的高温环境中。若发生任何故障，请立即关闭电源。使用电池的注意事项：- - - - - - - ACDBEF① 机身② 液晶屏③ 电源/静音按钮④ 操作面板⑤ 天线⑥ 电池仓B.静⾳图标
产品结构
⑦ 提供出色的噪音抑制处理
① UHF频率范围：514MHz-596MHz，
96个无线频道可随意切换，互不干扰
WH-M1非常适用于摄影录制，现场采访及语音录制等场合。请仔细阅
读本说明书，以便能正确的操作，发挥本产品的优越性能。
欢迎使用神牛UHF无线手持麦克风发射器WH-M1，本产品设有
易于阅读的液晶显示屏，美观便捷的内置天线和晶体控制锁相环合
成器，具备噪音抑制功能及锁定功能。采用人体工学设计①机⾝②液晶屏
指⽰当前的传输功率级别:H为⾼功率,L为低功率
静⾳模式关闭静⾳模式开启C.锁定图标D.电池电量指⽰条
显⽰电池电量，当电池图标闪烁时请尽快更换电池
E.组别和频道
此OLED显⽰屏指⽰当前所处的组别和通道为：B-03
F.频率指⽰当前频率1.进⼊设置模式前，将Lock按键拨⾄OFF;
2.双击电源键进⼊设置界⾯：出现跳闪后，可以单击或⻓按进⾏设置GRP，
GRP/CH设置：-组别GRP：有A/B两组可选。-频道CH：A/B两组各有01-48个频道可选。CH-B-03577.210MHZ双击则切换设置CH，再次双击电源键即可退出设置。123456锁定设置和锁定关机注：进⼊设置时，如果15秒不操作则⾃动回到主屏幕A.

RX1TX1
③电源/静⾳键WH-M1WH-M1RX1+++WH-M1RX1+WH-M1+电源：⻓按2秒开/关机。静⾳：
使⽤时，短按该按键，将开启静⾳模式，再按⼀次关闭静⾳模式。
④操作⾯板A.Lock锁定开关按键
拨动按键至ON，可防止使用麦克风
时错误操作。
将射频功率设置为HIGH或LOW。
拨到ON时，此时设备处于锁定状态,无法进行设置，无法关机。锁定开关设置：拨到HIGH高功率，拨到LOW低功率。
拨到OFF时，设备解除锁定，可以进行设置组别和频道，可以关机。
RF功率设置：⑤天线⑥电池仓本产品使用两节AA电池（电池需自行购买）
操作。
使用说明
WH-M1作为神⽜的⼀款UHF⽆线产品，可与其它同类型⽆线产品搭配使⽤。
使⽤时，请将WH-M1和接收器RX1设置相同的GRP和CH。
接收器设置请查收UHF⽆线⻨克⻛系统WMicS1说明书。
操作步骤1.按箭头⽅向转动并向下拉动⼿柄，在电池槽2.按电源键打开WH-M1；3.将锁定开关设置为ON或OFF；4.将RF功率设置为HIGH或LOW；
5.打开接收器与WH-M1设置相同的组别和频道；
6.顺时针⽅向合上⼿柄；7.现在可以开始使⽤了。（注意：
静⾳时，不会输出⾳频信号，但仍会传输射频信号。）
（注意：锁定开关不会锁定静音功能）
WH-M1与神⽜UHF⽆线⻨克⻛系统组合使⽤⽰例：WMicS1
WH-M1RX1WH-M1RX1WH-M1WH-M1RX1TX1
•按箭头方向转动手柄，向下拉动手柄，直到可以看到电池盒。•将两个新的AA电池插入电池盒，电池极性方向正确。
WH-M1作为⼀款⽤于神⽜⽆线系统的⼿持式⽆线⻨克⻛发射WH-M1与⽆线⻨克⻛系统WMicS1RX1/Kit1组合使⽤⽰例：AB
内插⼊新的两节AA电池(电池需⾃⾏购买);
B.RF功率按键

Batteries are prone to leakage when fully discharged. To avoid damage
to the product, be sure to remove batteries when the product is not
-
used for a long time or when batteries run out of charge.
2.检查发射器是否设置的静⾳。
3.如您的发射器受到他⼈⼲扰，改变发射器和接收器的频道设置即可。
4.如您发现发射⾳频距离有限或者有漏发现象,请检查是否电池耗尽，
请尝试更换电池。故障排除避免跌落：如果受到强烈碰撞或振动,设备可能会发⽣故障。
维护保养
Do not disassemble. Should repairs become necessary,this product
must be sent to an authorized maintenance center.
Always keep this product dry. Do not use in rain or in damp conditions.
Keep out of reach of children.
Do not use the flash unit in the presence of flammable gas.In certain
circumstance, please pay attention to the relevant warnings.
Do not leave or store the product if the ambient temperature reads over 40℃.
Turn off the flash trigger immediately in the event of malfunction.
Observe precautions when handling batteriesWarningPreface规格参数
Thank you for choosing Godox UHF Wireless Handheld WH-M1 Transmitter.
It features a readable OLED screen, a beautifully and conveniently built-in
antenna and PLL synthesizer, and also functions with noise suppression and
locking function.Product Featuresh
②Broadcastqualitysound,clearandstable
③Wirelesstransmissionrangeupto80m
④OLEDdisplaywithparametersettings
⑤Outputvolumecontrolwithmutefunction⑥AdjustableRFpower⑦Excellentnoisereduction
①UHFfrequencyrange:514MHz-596MHz,
96selectablechannelswithoutinterference
-
Read and follow all warnings and instructions provided by the manufacturer.
-
Batteries cannot be short-circuited or disassembled.
-
Do not put batteries into a fire or apply direct heat to them.
-
Do not attempt to insert batteries upside down or backwards.
-
Use only batteries listed in this manual. Do not use old andnew batteries
or batteries of different types at the same time.
保持⼲燥：本产品是⾮防⽔产品,如果将其浸⼊⽔中或放置于⾼温度的
环境中将可能发⽣故障。内部构造⽣锈可能会导致⽆法修理的损害。
避免温度骤变：温度的突变，诸如在寒冷天进出温暖的⼤楼将可能会
使产品内部结露。为避免结露，请将产品事先装⼊⼿提袋或塑料包内，
以防温度突变。远离强磁场：⽆线电⼴播发射机等设备产⽣的强静电或强磁场可能会
⼲扰本产品正常⼯作。经发现擅⾃检修此产品，将取消⼀年保修期，
维修需要收取相关费⽤。
如果本品出现故障或者被⽔淋湿，在专业⼈员维修后⽅可继续使⽤。
如有技术更改，恕不另⾏通知。
1.如不能接收到⾳频信号，请检查电池是否正确安装以及是否打开发
射器电源;发射器是否设置在同⼀组别和频道；⽿机是否已正确牢
固连接到位；功能模式是否设置正确。
型号频道组频道数RF频率范围振荡器类型⾳频频率范围声⾳延迟天线电池⼯作温度范围储存温度范围信噪⽐
失真
尺⼨重量WH-M1A/B96（A组48B组48）514MHz-596MHz晶体控制锁相环合成器40Hz-18KHz12ms1/4λ两节AA(5号)电池0℃-40℃-10℃-40℃＞70dB
≤0.5%
260x55x55mm345g（不含电池）
Should liquid from the batteries come into contact with skin or clothing,
rinse immediately with fresh water.
-

12345Product Structure123456①BodyConstruction②OLEDScreen③Power/MuteButton⑤Antenna⑥BatteryCompartment④OperatingPanel①BodyConstructionErgonomic design②Mute is offC. Lock IconE. Group & ChannelACDBEFCH-B-03577.210MHZA. RF Frequency Indicator
Indicating current power levels:
H for high power, L for low power.
B. Mute IndicatorMute is onD. Battery Level IndicatorShowing battery level.
The OLED screen indicates the device
is connected to Group B, Channel 3.
F. Frequency
Indicating current frequency.
-CHChannel:1-48selectablechannelsforA/Bgroups.GRP/CH Settings: -GRPGroup:A/Bgroupsforselection.③Power/MuteButton
Power : Long press the button for two seconds to power it on/off.
(Note: When muted, the audio signals will not be outputted.
But the RF signal will still be transmitted) Mute : Press the button to enter or exit silent mode.④OperatingPanelABA. Lock Button
When Lock is ON, the device will be locked.
It will prevent misoperation when using the
microphone.B. RF Power Button
Set the RF Power to HIGH/ LOW.
When Lock is ON, the device is locked and the settings cannot be changed, and it can not be powered off.Lock Button Settings:Switch HIGH for high power, and switch LOW for low power.When Lock is OFF, the device is unlocked and GRP/CH can be resetted, andit can be powered off.RF Power Settings:⑤AntennaOLEDScreen
2. Double press the power button to enter the Settings. When the screen
begins to flicker, press the buttonor or long press it to set the GRP,or double
Then double press the button again to exit the Settings.
Note: When entering the Settings, it will automatically return to the home screen
1. Switch LOCK button to OFF before entering the Settings.
AB
Settings and power functionare locked.
When the battery's icon flickers,
please change the battery soon.
612345AB123456
if no operation is applied within 15 seconds.
press it to set the CH.

Changes made to the specifications or designs may not be reflected in thismanual.⑥BatteryCompartment
The device is charged by two AA batteries
(need to be purchased separately).
Instructions
Godox WH-M1 UHF Wireless Handheld Microphone can also be collocated
with other wireless products.
For example, it can be collocated with Godox WMicS1 UHF Wireless Microphone
When using, please set the WH-M1 and receiver RX1 into same GRP and
WMicS1 user manual. Operation Guide
1. Rotate the handle in the direction of the arrow as shown in the
2. Press the Power Button to turn on the WH-M1;
3. Set the RF power to HIGH or LOW;4. Set the lock switch to ON or OFF;
5. Turn on Receiver and WH-M1 Handheld Microphone
Transmitter and set them on the same group and channel；
6. Close the grip in the direction of clockwise;7. Start to use WH-M1.Specification
Troubleshooting
Unable to receive audio signal. Make sure batteries are installed correctly
and Power Switch is turned on. Check if the transmitter and the receiver are
set to the same channel, if the microphone or earphone is well conne-
Check if the transmitter is set to silent mode or not.
Signal disturbance or shooting interference. Change a different channel of
the transmitter and receiver.
Operating audio distance limited or signal missing. Check if batteries are
exhausted. If so, replace them.
Avoid sudden drops. The device may fail to work after strong shocks,
impacts, or excess stress. Keep dry.
The product isn’t water-proof. Malfunction, rust, and corrosion may occur and go
beyond repair if soaked in water or exposed to high humidity.
Avoid sudden temperature changes. Condensation happens if sudden
temperature changes such as the circumstance when taking the product out
of a building with higher temperature to outside in winter.
Please put the product in a handbag or plastic bag beforehand.
Keep away from strong magnetic field. The strong static or magnetic field
produced by devices such as radio transmitters leads to malfunction.
Maintenance
As for how to set up the receiver, please refer to UHF wireless system
RX1TX1WH-M1WH-M1RX1WH-M1RX1WH-M1
Godox Wireless Handheld Microphone Transmitter WH-M1
is compatible with Godox Wireless System Receiver
RX1, and it can also be collocated with WMicS1 Kit 1
as wireless microphone system kits.
When using, please set the WH-M1 and receiver RX1
into same GRP and CH frequency. wireless system WMicS1 user manual. As for how to set up the receiver, please refer to UHFRX1TX1WH-M1WH-M1RX1WH-M1RX1WH-M1
System to set up new combinations:WH-M1RX1WH-M1RX1WH-M1WH-M1RX1TX1Distortion
WH-M1A/B96514MHz-596MHz40Hz-18KHz12ms1/4λ0℃-40℃-10℃-40℃＞70dB
≤0.5%
260x55x55mm345g（Batteryisnotcontained）
ModelGroupChannelsFrequency RangeOsallator TypeFrequency ResponseVoice DelayAntennaPower Supply
Operating Temperature
Storage TemperatureSignal To Noise RatioDimensionsWeightTowAAsizesbatteriesPLLSynthesizedControlOsallator（GroupA48；GroupB48）CH frequency.
cted, or if the devices are set to the correct mode.
picture, then pull the handle to open the battery compartment.
And install two AA batteries. (need to be purchased separately)

FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
This device and its antenna(s) must not be co-located or operating in conjunction with any other
antenna or transmitter.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to
meet general RF exposure requirement. The device can be used in portable exposure condition without
restriction
