Godrej GMX 23CA MKM User manual

the above image is for representative purpose, actual image of the product may vary

T
Th ha an nk ky yo ou uf fo or rp pu ur rc ch ha as si in ng gG Go od dr re ej jM Mi ic cr ro ow wa av ve eO Ov ve en n
Please record the model number and
serial number of this unit for future
reference.
Staple your receipt here for proof of
purchase.
Model No: _______________________
Serial No: _______________________
Dealer:__________________________
________________________________
________________________________
________________________________
Dealer Phone No:__________________
S
SP PE EC CI IF FI IC CA AT TI IO ON NS S
Power Consumption :
Rated Microwave Output :
Operation Frequency :
Product Dimensions :
Oven Capacity :
Cooking Uniformity :
Net Weight:
1
230V/50Hz, 1300W (Microwave)
1200W (Grill)
1200W (Convection)
800W
2450MHz
29.0cm(H) x 48.0cm(W) x 40.5cm(D)
23 Litres
Turnable System
Approx.14.0Kg

T
TA AB BL LE EO OF FC CO ON NT TE EN NT T
IMPORTANT SAFETY INSTRUCTIONS 3
UTENSIL GUIDE 5
INSTALLATION INFORMATION 5
GROUNDING INSTRUCTIONS 6
ELECTRICAL REQUIREMENTS 6
RADIO INTERFERENCE 6
EXTENSION CORD INFORMATION 6
PART NAMES 6
OPERATION INSTRUCTIONS 7
INSTACOOK MENUS 10
CLEANING AND CARE 77
TROUBLESHOOTING 78
FAQs 79
WARRANTY 80
2

3

4

5

6
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Grill Rack( Only for Grill series )
P
PA AR RT TA AN ND DA AC CC CE ES SS SO OR RI IE ES SN NA AM ME ES S
1. A short power supply cord is provided to reduce
the risks resulting from becoming entangled in
or tripping over a longer cord
2. DO NOT USE AN EXTENTION CORD
E
EX XT TE EN NS SI IO ON NC CO OR RD DI IN NF FO OR RM MA AT TI IO ON N
Operation of the microwave oven can cause
interference to your radio, TV, or similar equipment.
When there is interference, it may be reduced or
eliminated by taking the following measures:
1. Clean door and sealing surface of the oven.
2. Reorient the receiving antenna of radio or
television.
3. Relocate the microwave oven with respect to
the receiver.
4. Move the microwave oven away from the
receiver.
5. Plug the microwave oven into a different outlet
so that microwave oven and receiver are on
different branch circuits.
R
RA AD DI IO OI IN NT TE ER RF FE ER RE EN NC CE E
The oven is designed to operate on a standard
230V/50Hz household outlet. Be sure the circuit is at least 15A or 20A and the microwave oven is the
only appliance on the circuit
.
E
EL LE EC CT TR RI IC CA AL LR RE EQ QU UI IR RE EM ME EN NT TS S
This appliance must be grounded. This oven is
equipped with a cord having a grounding wire with a
grounding plug. It must be plugged into a wall
receptacle that is properly installed and grounded. In
the event of an electrical short circuit, grounding
reduces risk of electric shock by providing an
escape wire for the electric current. It is
recommended that a separate circuit serving only
the oven be provided. Using a high voltage is
dangerous and may result in a fire or other accident
causing oven damage.
WARNING Improper use of the grounding plug can
result in a risk of electric shock.
Note:
1) If you have any questions about the grounding
or electrical instructions, consult a qualified
electrician or service person.
2) Neither the manufacturer nor the dealer can
accept any liability for damage to the oven or
personal injury resulting from failure to observe the
electrical connection procedures.
The wires in this mains cable are colored in
accordance with the following code:
Green and/or Yellow = EARTH
Blue and/or Black = NEUTRAL
Brown and/or Red = LIVE
G
GR RO OU UN ND DI IN NG GI IN NS ST TR RU UC CT TI IO ON NS S

O
OP PE ER RA AT TI IN NG GI IN NS ST TR RU UC CT TI IO ON NS S
This microwave oven uses modern electronic control
to adjust cooking parameters to meet your cooking
needs better.
1. CLOCK SETTING
When the power is switched on, the oven will display
"0:00" and buzzer will ring once.
1) Press "CLOCK/KITCHEN TIMER" once to choose
24-hour format.
2) Turn the knob to adjust the hour figures, the input
time should be within 0--23(24-hour).
3) Press "CLOCK/KITCHEN TIMER ", the minute
figures will flash.
4) Turn the knob to adjust the minute figures, the
input time should be within 0--59
5) Press "CLOCK/KITCHEN TIMER" to finish clock
setting. ":" will flash.
Note:
1) If the clock is not set, it would not function when
powered.
2) During the process of clock setting, if you press
"STOP/CLEAR ", the oven will go back to the
previous status automatically.
2. MICROWAVE COOKING
1) Press the "MICROWAVE" key once and "P100"
will be displayed.
2) Press "MICROWAVE" button to select the
microwave power from 100% to 10%. "P100",
"P80", "P50", "P30", "P10" will be displayed in order.
3) Press "START/+30SEC./ CONFIRM" to confirm
4) Turn the knob clockwise to adjust the
cooking time. (The time setting should be 0:05-
95:00.)
5) Press "START/+30SEC./ CONFIRM" to start
cooking.
NOTE: The step increase in the cooking time while
using the knob is as follows:
Between 0---1 min : 5 seconds increase
Between 1---5 min : 10 seconds increase
Between 5---10 min : 30 seconds increase
Between 10---30 min : 1 minute increase
Between 30---95 min : 5 minutes increase
Microwave Power Chart
3. GRILL COOKING
1) Press the "GRILL/COMBI." key once, and "G-1" is
displayed.
2) Press "START/+30SEC./CONFIRM" to confirm.
3) Rotate the jog dial clockwise to adjust the
cooking time. (The time setting should be 0:05-
95:00.)
4) Press "START/+30SEC./CONFIRM" to start
cooking.
Note: If half the grill time passes, the oven beeps
twice to tell you to turn the food over. To pause the
microwave, press the STOP/CLEAR button once.
In order to have a better effect of grilling food, you
should turn the food over, close the door, and then
press "START/+30SEC./CONFIRM" to continue
cooking. If you don’t turn it over, the oven will
continue operation.
4. COMBINATION COOKING
1) Press the "GRILL/COMBI." key once and "G-1"
Press
Once
T
wice
Thrice
4
times
5
times
Microwave Power 100% 80% 50% 30% 10%
7

will be displayed.
2) Press "GRILL/COMBI." Twice to get "C-1", thrice
to get "C-2" and so on till "C-3" or "C-4" are
displayed.
3) Press "START/+30SEC./CONFIRM" to confirm.
4) Turn the jog dial to adjust the cooking time.
(The time setting should be 0:05- 95:00.)
5) Press "START/+30SEC./CONFIRM" to start
cooking.
Note: Combination instructions
Instructions
Display
Microwave
Grill
Convection
1 C-1 YES YES
2 C-2 YES YES
3 C-3 YES YES
4 C-4 YES YES YES
5. CONVECTION COOKING (WITH
PREHEATING FUNTION)
The convection cooking lets you cook the food as in
a traditional oven. Microwave is not used. It is
recommended that you should preheat the oven to
the appropriate temperature before placing the food
in the oven.
1) Press the "CONVECTION" key once and "110"
will be displayed.
2) Keep pressing "CONVECTION" or turn the
knob to select the convection function.
Note: The temperature can be chosen from 110
degrees to 200 degrees.
3) Press the "START/+30SEC./CONFIRM" to
confirm the temperature.
4) Press the "START/+30SEC./CONFIRM" to start
preheating. When the preheating temperature
arrives, the buzzer will sound twice to remind you to
put the food into the oven. And the preheated
temperature is displayed.
5) Put the food into the oven and close the door.
Turn the knob to adjust the cooking time. (The
maximum setting time is 95 minutes.)
6) Press the "START/+30SEC./CONFIRM" key to
start cooking.
Note:
a. Cooking time cannot be set until the preheating
temperature arrives. If the temperature arrives, door
must be opened to set the cooking time.
b. If the time is not set in 5 minutes, the oven will
stop preheating. The buzzer sound five times and
turn back to waiting state.
6. CONVECTION COOKING (WITHOUT
PRE-HEATING FUNCTION)
1) Press the "CONVECTION" key once and "110"
will be displayed.
2) Keep pressing "CONVECTION" or turn the
knob to select the convection function.
Note: The temperature can be chosen from 110
degrees to 200 degrees.
3) Press the "START/+30SEC./CONFIRM" to
confirm the temperature
4) Turn the knob to adjust the cooking time. (The
maximum setting time is 95 minutes.)
5) Press the "START/+30SEC./CONFIRM " key to
start cooking.
7. KITCHEN TIMER
1) Press "CLOCK/KITCHEN TIMER" twice, LED will
display 00:00.
2) Turn the jog dial to enter the correct time. (The
maximum cooking time is 95 minutes)
3) Press "START/+30SEC./CONFIRM" to confirm
setting.
4) When the set time has elapsed, the buzzer will
8

ring 5 times. If the clock is set (24-hour system), LED
will display the current time.
8. WEIGHT DEFROST
1) Press "W.T./Time Defrost"to choose the
defrosting by weight. "dEF1" will be displayed.
2) Turn the knob to input the
weight."100","200","300","400","500","600","800"
"1000","1200","1400","1600","1800 and "2000"
will be displayed in order.
3) Press "Start/+30Sec./Confirm"to start
defrosting. If "Stop/Clear"is pressed, it will go
back to waiting state. At this time, press
"Start/+30Sec./Confirm"again or if the delay is
more than 5minutes, it will turn back to the
waiting state. Press "Start/+30Sec./Confirm"in 5
minutes, the unit goes on working and time
counts down. When it is finished, the buzzer
sounds five times and turns back to the waiting
state.
4) When half the defrost time has passed, the buzzer
will sound twice to remind you to turn the food over,
if no action is taken, the unit will continue working
and the defrost result may not be as per your
expectation.
9. TIME DEFROST
1) Press "W.T./Time Defrost"twice to choose
the function of defrost by time. "dEF2" will be
displayed.
2) Turn the knob to input the cooking time. The
max time is 95 minutes.
3) Press "Start/+30Sec./Confirm"to start
defrosting. If "Stop/Clear"is pressed, it will go
back to waiting state. At this time, press
"Start/+30Sec./Confirm"again or if the delay is
more than 5minutes, it will turn back to the
waiting state. Press "Start/+30Sec./Confirm"
within 5minutes, the unit goes on working and
time counts down.
10. INSTACOOK MENU
1) In waiting state, turn the jog dial right to
choose the function wanted, and
"A1","A2","A3"...."A10" will be displayed.
2) Press "START/ +30 SEC./CONFIRM"to
confirm the menu you need.
3) Turn the knob to choose the weight of menu.
Weight and "g" will be displayed to indicate weight
in grams
4) Press "START/ +30 SEC./CONFIRM"to start
cooking.
Note:
1. When you choose Insta 9 (A9), please do not put
the ingredients into the oven at the start. The oven
needs to be preheated to 160ofirst. After sevarel
minutes, the buzzer sounds twice to remind you to
put the ingredients into the oven. After putting the
ingredients in the oven, press start again.
2. During Insta 10 (A10), the oven beeps twice, and
this is normal.
11. EXPRESS COOKING
1) In waiting state, press
"START/+30SEC./CONFIRM" key to cook with
100% power level for 30 seconds. Each press on
the same key can increase 30 seconds. The
maximum cooking time is 95 minutes.
2) During microwave, grill, convection and
combination states, press
"START/+30SEC./CONFIRM" key to cook with
100% power level for 30 seconds. Each press on
9
