gofanco PRO-mDPUSBDock User manual

PRO-mDPUSBDock
4K video docking with USB 3.0 hub and Ethernet
®
Made in Taiwan
User‘s Guide

®
PRO-mDPUSBDock
Congratulaons for owning a gofanco product. Our products
aim to meet all your connecvity needs wherever you go.
Have fun with our products!
Please read this manual carefully before rst use.
If you need more informaon about our products, please visit
www.gofanco.com.
For technical support, please email us at
[e-mail].
For drivers/manuals download, please go to
hp://www.gofanco.com/download.

®
PRO-mDPUSBDock
• DisplayPort 1.2a & HDMI 1.4 compliant
• Supports HDMI or DisplayPort output1
• Output resolution:
- HDMI output: up to 4K2K@30
- DP output: up to 4K2K@60
• 2-Port USB 3.0 Hub
• Supports USB 3.0 data transfer rates up to 5Gbps
• Supports Gigabit Ethernet up to 1000 Mbps
• Supports multi display modes (Mirror, Extended, Primary)
through either HDMI or DisplayPort output
2. Features
1. Introduction
3
The PRO-mDPUSBDock 4K video docking with USB 3.0 hub and
Ethernet converts a Mini DisplayPort to either HDMI or Dis-
playPort output. It allows Mini DisplayPort-equipped compu-
ters, such as MacBook (NOT for MacBook 2015 line) or Surface
Pro series, to connect to an HDMI or DisplayPort display. The
PRO-mDPUSBDock is also equipped with a Gigabit Ethernet
and a 2-Port USB 3.0 Hub. Compact, lightweight and portable
design makes it easy to carry with you. This Mini DisplayPort
Video Dock with USB 3.0 LAN Hub is a versatile tool to expand
and enhance your computer’s connectivity performance for
home use, in the oce, or on the road.

®
PRO-mDPUSBDock
4
• 1x PRO-mDPUSBDock
• 1x USB 2.0 A Type to Micro-USB B cable
• 1x USB 3.0 A Type to Micro B cable
• 1x User Manual
3. Package Contents
• HDCP 1.4 compliant
• No external power adapter required
• Ultra-compact and lightweight design
1. Only ONE video output can be used, either HDMI or DisplayPort.
Does not support both outputs simultaneously. DisplayPort has
the rst priority.
2. Mac OS requires a driver update to enable the Ethernet port.
Download this driver from www.gofanco.com/downloads. No
driver installation required in Windows.
!

®
PRO-mDPUSBDock
4. Specications
Item Description
Role of usage Mini DisplayPort Video Dock
HDMI compliance HDMI 1.4
DisplayPort compliance DisplayPort 1.2a
HDCP compliance Yes
Input Video bandwidth Single-link 600MHz
Video support HDMI: up to 4K2K@30
DP: up to 4K2K@60
ESD protection Human body model — ±15kV [air-gap discharge] &
±8kV [contact discharge]
Input 1x Mini DisplayPort + 1x USB 3.0 (Micro Type B)
Output 1x DisplayPort + 1x HDMI + 2x USB 3.0 + 1x RJ-45
HDMI connector Type A [19-pin female]
DisplayPort connector Mini DisplayPort & DisplayPort
RJ-45 connector WE/SS 8P8C
Mechanical
Housing Metal enclosure
Dimensions
[L x D x H]
Model 121 x 46 x 17mm [4.7 x 1.8" x 0.6"]
Package 170 x 240mm [6.7" x 9.4" ]
Carton 535 x 320 x 495mm [1‘8“ x 1‘ x 1‘6“]
Weight Model 85g [3 oz]
Package 149g [5.2 oz]
Power supply 5V DC
Power consumption 2 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
5

®
PRO-mDPUSBDock
6
5. Panel Description
2
1
3
6
7
4
5
1.RJ45 (Gigabit): Connect to Ethernet network
2.USB 3.0 Hub: Connect to USB devices such as mice, keyboards,
and pen drives
3.USB 3.0 Micro B: Connect to USB 3.0 Host (for USB 3.0 Hub)
*Note: This connection is required to enable the USB 3.0 Hub and Ethernet port
4.Micro USB: Connect to +5V power supply (for external power
if needed)
5.Mini DisplayPort input: Connect to the system’s Mini-DP port
6.HDMI output: Connect to a HDMI display
7.DisplayPort output: Connect to a DisplayPort display

®
PRO-mDPUSBDock
7
6. Connection Diagram
PRO-mDPUSBDock

®
PRO-mDPUSBDock
8
7. Limited Warranty
The SELLER warrants the PRO-mDPUSBDock 4K video docking with USB 3.0
hub and Ethernet to be free from defects in the material and workmanship
for 1 year from the date of purchase from the SELLER or an authorized dealer.
Should this product fail to be in good working order within 1 year warranty
period, The SELLER, at its option, repair or replace the unit, provided that the
unit has not been subjected to accident, disaster, abuse or any unauthorized
modications including static discharge and power surge. This warranty is of-
fered by the SELLER for its BUYER with direct transaction only. This warranty
is void if the warranty seal on the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at
the current price of parts and labor in eect at the time of repair. Such repairs
are warranted for 90 days from the day of reshipment to the BUYER. If the unit
is delivered by mail, customers agree to insure the unit or assume the risk of
loss or damage in transit. Under no circumstances will a unit be accepted wi-
thout a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including
without limitations, any other implied warranty or tness or merchantability
for any particular purpose, all of which are expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside
Taiwan are responsible for shipping charges to and from the SELLER. Cables
and power adapters are limited to a 30 day warranty and must be free from
any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be
accurate. However, The SELLER assumes no responsibility for any inaccura-
cies that may be contained in this manual. The SELLER will NOT be liable for
direct, indirect, incidental, special, or consequential damages resulting from
any defect or omission in this manual, even if advised of the possibility of
such damages. Also, the technical information contained herein regarding
the PRO-mDPUSBDock features and specications is subject to change wi-
thout further notice

®
PRO-mDPUSBDock
9
The product name and brand name may be registered trademarks of related manufacturers. TM and ®
may be omied on the user‘s guide. The pictures on the user‘s guide are just for reference, and there
may be some slight dierences with the actual products.
We reserve the rights to make changes without prior noce to a product or system described herein to
improve reliability, funcon, or design.
Disclaimer

®
PRO-mDPUSBDock
10

®
PRO-mDPUSBDock
11

Thank you for choosing gofanco
®
www.gofanco.com
Jul, 2020 Ver. A Copyright © by gofanco, LLC. All rights reserved.
