Goldair select GSHV45B User manual

Operating Instructions
45cmTripodPedestalFan
Item: GSHV45B

General Care and Safety Guide
Thank you for choosing this Goldair Select product. This Goldair Select
appliance has been designed and manufactured to high standards of
engineering and with proper use and care, as described in this leaflet, will give
you years of useful service. Please read these instructions carefully and keep
them for future reference.
1. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the
appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
4. Ensure that the fan is switched off from the supply mains before removing
the guard.
5. Use only the voltage specified on the rating plate of the appliance.
6. Keep all objects at least 1 Metre from the front, sides and rear of the
appliance
7. This appliance is intended for household use only and not for commercial or
industrial use.
8. Use this appliance only as described in this manual. Any other use is not
recommended by the manufacturer and may cause fire, electric shock or
injury.
9. The common cause of overheating is deposits of dust or fluff in the
appliance. Ensure these deposits are removed regularly by unplugging the
appliance and vacuum cleaning the air vents and grills.
10. Always unplug appliance when not in use.
11. When the appliance has been unpacked, check it for transport damage and
ensure all parts have been delivered. If parts are missing or the appliance
has been damaged, contact the Goldair Customer Services Team.
12. If your appliance does not work, or is not working properly, contact the place
of purchase. Repair work on the appliance by unqualified persons can
cause serious risk to the user.
13. Ensure hands are dry before handling the plug or the main unit.
14. Carry out regular checks of the supply cord to ensure no damage is evident.
15. Ensure that the cord is fully extended (not coiled) while in use.
16. Avoid contact with the moving parts. Keep hands, hair, clothing, away from
blade of the fan during operation to reduce the risk of injury to person and/or
damage to the unit.
17. Switch off and use handles provided when moving.
18. It is recommended that this fan is plugged directly into the wall socket.
19. A correctly specified, undamaged extension cord may be used with this fan
provided it is used in a safe manner.

TECHNICAL SPECIFICATION
Model: GSHV45B
Supply: 220-240VAC 50-60Hz
Wattage: 60W
General Care and Safety Guide
20. Never place appliance close to radiant heat source.
21. Never operate in areas where petrol, paint or other flammable liquids are
used or stored.
22. Never use the appliance to dry clothes.
23. Never insert or allow foreign objects to enter any ventilation or exhaust
opening, as this may cause an electric shock, fire or damage to the
appliance.
24. Never use abrasive cleaning products on this appliance. Clean with a damp
cloth (not wet) rinsed in hot soapy water only. Always remove plug from the
mains supply before cleaning.
25. Never connect the appliance to mains supply until completely assembled
and adjusted.
26. Never remove plug from power socket until the appliance has been switched
off.
27. Never remove plug from power socket by pulling cord –always grip plug.
28. Never twist, kink or wrap the cord around the appliance, as this may cause
the insulation to weaken and split. Always ensure that all cord has been
removed from any cord storage area and is unrolled before use.
29. Never use this appliance in the immediate surrounds of a bath, a shower, or
a swimming pool or other liquids. The appliance must not be immersed in
any liquids.
30. Due to the risk of injury, never use this appliance for any purpose other than
its intended use. This appliance is intended for use in household and similar
applications such as staff kitchen areas in shops, offices and other working
environments; farm houses, by clients in hotels, motels, bed and breakfast
type environments and other residential type environments
31. Never use this appliance outdoors.
32. Never operate the appliance with a damaged cord or plug, after it
malfunctions, or if it has been damaged in any manner. Have the appliance
checked and repaired by a qualified electrician if repair is necessary.
33. Never place the unit in wardrobes or other enclosed spaces as this may
cause fire hazards.

v
v
10
12
11
Components
Firstly, remove the wing screws (4) from
the motor housing. Fit the rear grill (5) onto
the motor shaft (6). Make sure the holes on
the motor match up with the holes on the
grill. Fit the wing screws (4) and secure
tightly.
Put the blade (2) onto the motor shaft (6)
and carefully tighten the blade screw (3).
Fit the front grill (1) onto the rear grill (5)
and fix them together using the fan grill
ring. Tighten the small screw at the bottom
of the grill.
Extend the legs of the tripod base (11) and
stand upright. Place the motor housing
onto the base (11)by pushing the top of
the pole into the neck (9). Fasten screws
provided tightly.
1.Front Grill
2.Blade
3.Blade Screw
4.Wing Screws
5.Rear Grill
6.Motor Shaft
7.Speed Control
8.Oscillation Pin
9.Neck
10. Height Adjustment Knob
11.Tripod Base
12.Rubber Feet
Assembly

WARNING: Keep all objects at least 1 metre from the front,
sides and rear of the appliance
Fan control switch
The control switch positions are:
•0 = OFF
•1 = Low Speed
•2 = Medium Speed
•3 = High Speed
Check that the fan control switch is set to the off position before plugging into the mains
supply.
Place the fan on a dry, level and sturdy surface.
Plug the power cord into the socket, making sure the speed control is at off position.
To operate the fan, turn the speed control to the desired setting.
To activate the oscillation function, push down the oscillation pin on the top of the motor.
The fan will then oscillate until the pin is pulled back up.
To adjust the height of the fan, loosen the height adjustment knob and raise/lower the
pole to the desired height. Secure by tightening the knob.
Always choose a safe location for the fan, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. This
appliance requires no installation, it should be used solely as a portable
appliance.
Operating your Fan

Cleaning & Maintenance
Goldair –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
Goldair –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[e-mail]
SUPPORT AND TECHNICAL ADVICE
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase. (Refer to back of booklet).
The fan requires regular cleaning to
ensure trouble free operation.
Ensure that the fan is switched off from
the supply mains before removing the
guard.
Unplug the fan from the mains supply
before cleaning.
Use a damp cloth (not wet) to wipe the
exterior of the fan to remove dust and
dirt.
Use a vacuum cleaner to remove dust
and fluff from around the grills.
Ensure the fan is dry before plugging
back into the mains supply.
Do not attempt to dismantle the fan.
There are no user serviceable parts.
For service or repair, contact an
authorised electrical service
technician.

Thank you for purchasing this Goldair Select product. Your product is warranted against faults and manufacture when
used in normal domestic use for a period of one year. In non-domestic use Goldair limits the voluntary warranty to three
months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during
the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by
anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits to you given by this warranty are in addition to other rights and remedies available to you under a law in
relation to the goodsor services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
One Year Warranty
Goldair One Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
