Goldair PLATINUM GMT4 User manual

GMT Straight Square Towel Warmer
Operating Instructions
For Models: GMT4, GMT6, GMT8

When using any electrical appliance, basic safety precautions should always be observed.
READ THESE INSTRUCTIONS CAREFULLY.
•Keep them handy for future reference.
•This appliance is intended to warm and dry towels and therefore is hot to the touch. When
used by or near young children or infirm persons, close supervision is necessary. Young
children should be supervised to ensure that they do not play with the appliance.
•NOTE The surface temperature of your towel rail will be 20-25 degrees higher than the
ambient air temperature. Any rise in ambient air temperature is directly reflected in the
appliance and as a result of this the appliance will feel hotter to the touch during warmer
periods. Also, the insulation effect of towels will cause the operating temperature to
increase. Example, if the ambient air temperature is 20 degrees, this will mean the towel
rail surface will be approximately 40-50 degrees.
•The towel rail is to be installed so that switches and other controls cannot be touched by a
person in the bath or shower.
•DO NOT use this appliance for any purpose other than its intended use.
•To avoid a hazard this heated towel rail MUST NOT be used to carry towels or any other
articles that have been in contact with oil, petroleum-based products or dry-cleaning fluids.
•Use this appliance only with the voltage specified on the rating label, or elsewhere in these
instructions.
•Regulations require that electrical work be carried out only by authorised persons. For your
own safety and that of others ensure this is done.
•DO NOT immerse in any liquid.
•For service contact your nearest Authorised Service Agent.
WARNING: In order to avoid a hazard for young children, this appliance must be installed so
that the bottom rail is at least 600mm above the floor.
General Care and Safety Guide

SPECIFICATIONS/DIMENSIONS
Model: GMT4 GMT6 GMT8
Height: 436mm 674mm 912mm
Width: 620mm 620mm 620mm
Depth: 110mm 110mm 110mm
ELECTRICAL
Wattage: 40W 55W 100W
Colour: Stainless Steel Stainless Steel Stainless Steel
Power Supply 230-240 VAC
50Hz
230-240 VAC
50Hz
220-240 VAC
50Hz
Ingress Protection Rating: IP55
Dimensions and Specifications
GMT4
240
436
590
620

Dimensions (continued)
GMT8
GMT6 620
590
590
674
480
715
620
912

Components
1 x U Shape mouth leg (C)
1 x Leg (B) 2 x Regular Legs (A)
1 x U Shape mounting bush
3 x Regular mounting bush 1 x Outlet hole cover
1 x Washer
5 x Long Screws 5 x Wall Plugs
2 x Long screws
2 x Short screws 4 x Grub Screws
1 x Allen Key
A A
CB

Mounting:
Please note: Goldair advise that the towel rail should be installed by a professional.
Please read the safety information on the previous page carefully before mounting.
1.First, select which method of cord entry your installation situation requires –exposed or
concealed. (please see images below as an indication to the differences)
2.The accessory pack contains a set of 4 legs for your heated towel rail –one of which is a
universal leg
a) For a concealed cord entry, you require the additional plastic cover to conceal the cord
cutout as shown below.
Typically, a concealed cord entry is used for a new home or new bathroom installation where no
existing outlet is present
OR
b)For an exposed cord entry you require the addition of a cord grommet to the cord cutout.
Typically, an exposed cord entry is used for retro-fit installations where an existing permanent
connection outlet is already wired
Example
AA B C
Installation

3. You must next select which side of the towel rail is needed to be wired in. The heated towel
rail within this box has two wiring options (left or right hand). The location of existing wiring
through or on the wall will dictate which side you will use.
For Left hand wiring no change is required from how the rail comes out of the box.
Fix the leg over the looped wire (Picture A) and secure to the towel rail.
Now set the other Leg (C) either as exposed in internal wiring
For Right hand wiring, you must push feed (do not pull) cord through to the side with the loop.
Then shorten cable to the desired length for termination (Picture A,B)
You may need to remove some of the black sheath covering if doing exposed wiring (Picture C,D
with grommet included)
Picture A Picture B
Picture C Picture D
Mounting Bush & Leg C
Note: Ensure the ON/OFF switch is
located at the top of the towel rail
Leg A
Leg B
Leg A
Installation (continued)

4. Select desired spot to mount towel rail with at least 300mm clearance from all permanent
objects in surrounding area and 600mm above the floor. The Ladder Towel Rail should be
installed in accordance to local governing New Zealand regulations. The Goldair Heated Ladder
Towel Rail can only be mounted 1 way with wiring at the bottom.
7.It is recommended that to mount your Goldair towel rail, first measure the distance between
the mounting brackets. Then, relay the points onto the wall you are mounting your towel rail
too, use a spirit or laser level and only make drill holes when you are 100% sure of your
measurements
–no responsibility will be taken by Goldair for instances where installers drill incorrectly
Side View of Towel Rail
Top View of Towel Rail
Bracket Leg
Bracket Leg Bracket LegBracket Leg
Figure A
Grub screw
Figure B
7. To mount to the wall use legs (figure A) over mounting bushes Figure B
then tighten grub screw with allen key
To be used on leg with wiring
5. Use mounting bushes and longest screw to attach to wall
Figure B
6. To connect the Leg to towel rail use screwdriver through the leg and
tighten
C
AB
A
Installation (continued)

This appliance MUST be installed in accordance with the relevant wiring rules and regulations
and in particular those regulations which cover installation of appliances and accessories in
damp situations such as bathrooms, showers, laundries and other areas with fixed water
containers. It is to be fitted in accordance with applicable Australian/New Zealand standards
(AS/NZS).
The means for disconnection must be incorporated in the fixed wiring in accordance with the
wiring rules.
WARNING: In order to avoid a hazard for very young children, this appliance should be
installed so that the lowest heated rail is at least 600 mm above the floor.
Special purpose tools are required for the replacement of the power supply cord and
element. Contact an Authorised Service Agent for service.
PLEASE NOTE: There is a blue indicator light ON/OFF switch located on the top of the towel
rail.
PLEASE NOTE: Goldair takes no responsibility for instances where walls/tiles have been
drilled without correct measurements being taken by the installer –ensure you have the
correct measurements before drilling any holes.
PLEASE NOTE: Goldair takes no responsibility for instances that occur where heated towel
rails have not been installed according to AS/NZS standards.
ELECTRICIAN INFORMATION
•A copy of this User Manual should be left with the consumer for future reference.
•A means for disconnection must be incorporated in the fixed wiring in accordance with the
wiring guidelines AS/NZS 3000:2007.
Electrical Installation

Operating your Towel Rail
HEAT CONTROL
These towel rails run at a single temperature. Be aware they do get very hot to the
touch.
CAUTION: The Towel Rail generates heat during use. Proper precautions must be taken
to prevent the risk of burns, scalds, fires or other damage to persons
Do not attempt to dismantle the Towel Rail. There are no user serviceable parts. For
service or repair, contact an authorised electrical service technician.
CARE AND CLEANING
The Towel Rail requires regular cleaning to ensure longevity of the product.
Turn off the isolating switch before cleaning. For additional protection, turn the mains
supply off before cleaning.
Ensure that the towel rail has been allowed to cool down completely before cleaning.
Use a damp cloth (not wet) to wipe the exterior of the towel rail to remove dust and
dirt.
Never use solutions such as benzene, thinners or polishing agents.
Never use abrasive materials like steel wool / scourers to scrub the towel rail.
Ensure the Towel Rail is dry before switching back on the mains supply and isolating
switch.
DO NOT USE ANY ABRASIVE OR CORROSIVE CLEANERS.
Goldair –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
Goldair –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]om.au
SUPPORT AND TECHNICAL ADVICE
RUST
Surface rust can occur on stainless steel over time. To avoid this the Heated Towel Rail is
best wiped down from time to time with a damp cloth and a stainless-steel cleaner. Fine
scratching can be removed using a metal polish such as ‘Autosol’ or ‘Brasso’ Paste which
are available from most supermarkets and car care shops.
PROOF OF PURCHASE
To receive warranty, retain receipt as proof of purchase.

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when
used in normal domestic use for a period of three years. In non-domestic use Goldair limits the voluntary warranty
to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing
fault during the warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried
out by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in
relation to the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act
(1993).
Three Year Warranty
Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
