Goldair GPH150 User manual

Operating Instructions
Model: GPH150, GPH250, GPH350, GPH450
Mechanical Panel Heater

CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they are supervised or have been given instruction
concerning the use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the
appliance.
•If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING: You must not cover this appliance. Covering this appliance
presents fire risk and will activate the safety fuse; permanently disabling the
unit.
WARNING: Do not use this appliance in small rooms when they are
occupied by persons not capable of leaving the room on their own, unless
constant supervision is provided.
WARNING: To reduce the risk of fire, keep textiles, curtains, or any
flammable material a minimum distance of 1 metre from the air outlet.
General Care and Safety Guide
•Use only the voltage specified on the rating label of the appliance.
•Keep all objects at least 1 metre from the front, sides and rear of the
appliance.
•This appliance is intended for household use only and not for commercial or
industrial use.
•Indoor use only.
•Use this appliance only as described in this manual. Any other use is not
recommended by the manufacturer and may cause fire, electric shock or
injury.
•Do not use the appliance if it has been dropped or damaged.
•The common cause of overheating is deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE
INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.

•Never use the appliance to dry clothes.
•Always unplug appliance when not in use.
•When the appliance has been unpacked, check it for transport damage and
ensure all parts have been delivered. If parts are missing or the appliance has
been damaged, contact the Customer Services Team.
•Do not use if there are visible signs of damage to the appliance.
•Do not connect the appliance to mains supply until completely assembled and
adjusted.
•Ensure hands are dry before handling the plug or main unit.
•Ensure appliance is on a flat, stable, heat-resistant surface.
•Do not operate with cord set coiled up as a heat build up is likely, which could
be sufficient to become a hazard.
•Carry out regular checks of the supply cord to ensure no damage is evident
•Do not operate this appliance with a damaged cord, plug or after the appliance
malfunctions or has been dropped or damaged in any manner. Take to a
qualified electrical person for examination, electrical service or repair.
•Do not twist, kink or wrap the cord around the appliance, as this may cause the
insulation to weaken and split. Always ensure that all cord has been removed
from any cord storage area and is unrolled before use.
•It is recommended that this appliance is plugged directly into the wall socket.
Power boards are not rated to supply power to high wattage appliances.
•A correctly specified, undamaged extension cord may be used with this
appliance provided it is used in a safe manner.
•Do not remove plug from power socket until the appliance has been switched
off.
•Do not remove plug from power socket by pulling cord; always grip plug.
•Do not place cord under carpet or cover with rugs or furniture. Arrange the cord
so it cannot be tripped over.
•Don’t place appliance on bedding or on thick & long carpet where the openings
may get blocked.
•Switch off and use handle provided when moving
•Do not place appliance close to radiant heat source.
•Do not insert or allow foreign objects to enter any ventilation or exhaust
opening, as this may cause an electric shock, fire or damage to the appliance.
•Do not sit on the appliance.
•Do not use abrasive cleaning products on this appliance. Clean with a damp
cloth (not wet) rinsed in hot soapy water only. Always remove plug from the
mains supply before cleaning.
•Do not operate in areas where petrol, paint or other flammable liquids are used
or stored.
•Do not use this appliance in the immediate surrounds of a bath, a shower, or a
swimming pool or other liquids.
General Care and Safety Guide

•The appliance must not be immersed in any liquids.
•There are no user serviceable parts installed in the unit.
•Do not place the unit in wardrobes or other enclosed spaces as this may cause
fire hazards.
•This unit is not supposed to be used in or around locations where foodstuffs,
works of art or delicate articles of science, etc. are stored.
•If your appliance does not work, or is not working properly, contact the place of
purchase or the Customer Services Team.
General Care and Safety Guide

CONTROL PANEL
HEAT OUTLET
AIR INLET
Components
CASTOR WHEELS
CASTOR WHEEL
BRACKET
WALL MOUNTING
BRACKET

Before using this appliance, it must either be wall mounted or have the castor plates
and castors fitted.
This appliance has been supplied with ‘1 way screws’ for permanent installation of the
feet. This is a safety requirement for the New Zealand and Australian market.
Assembly Instructions
FREE STANDING
1. Ensure the appliance is unplugged and power switches are off.
2. Carefully turn the main body upside-down on a scratch-free and stable surface. Be
careful to prevent damage to the cosmetic finish or your floor surfacing.
3. Align the screw hole on the Castor Wheel Bracket with the screw hole on the base
of the appliance.
4. Attach Castor Wheel Bracket with the ‘1 way screws’ provided and ensure the
bracket sits firmly in place (do not over tighten). Firmly press Castor Wheels into
the slots provided on the Castor Wheel Bracket until they click into place. Some
force may be required.
5. Set appliance upright.
NOTE: The wall bracket edges may be sharp. It is recommended that if using as a free
standing appliance please remove the wall bracket from the back of the heater.

Installation Instructions
The appliance must not be located immediately below a socket outlet.
NOTE: Your Panel Heater should be installed with at least 150mm clearance from the
floor and any other surrounding parts including other appliances and side walls.
At least 300mm clearance from ceilings, shelves and soft furnishings.
Note: Do not run the power cord behind the heater.
WALL MOUNTED HEATERS ARE
ONLY TO BE MOUNTED ON HEAT
RESISTANT WALLS THAT COMPLY
WITH CURRENT AS/NZS
SPECIFICATIONS & BUILDING
REGULATIONS
150mm
300mm
150mm
150mm
WALL MOUNTED
1. Make sure the appliance is unplugged and power switches are off.
2. Position the panel appliance within one metre of a wall socket. Do not mount in front of or
below the wall socket. Ensure there is at least 150mm clearance on all sides of the
appliance.
3. Detach the mounting bracket from the back of the panel appliance by unscrewing the two
locking screws (located on the top of the mounting bracket).
4. Position the mounting bracket on the wall and mark the hole positions with a pen or pencil
and check they are horizontal with a spirit level. Ensure the two bottom mount holes are at
least 150mm from the floor and drill holes as required.
5. Secure the mounting bracket to the wall with the mounting screws. (For masonry walls use
the plastic sheaths).
6. Slot the back of the appliance onto the mounting bracket locating the bottom plugs first
and secure with two locking screws.
7. Plug appliance into a standard 240 volt AC electrical outlet.

Operating Your Heater
CONTROL PANEL
O - Off
I–Low Heat
II –High Heat
Ensure the switch is in the Off position before plugging into the mains supply.
Use the 2 way switch to select your desired heat setting. When you are finished, return the switch
to the Off position.
Always choose a safe location for the heater, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. Please
follow the below instructions.
WARNING: In order to avoid overheating or fire, do not cover the heater.
WARNING: Keep all objects at least 1 metre from the front and 150mm
from the sides of the appliance.
WARNING: Do not use this heater with a programmer, separate timer,
remote-control system or any other device that switches the heater on
automatically, since a fire risk exists if the heater is covered or positioned
incorrectly.
WARNING:Never leave this heater unattended when in use.
If mounted on castors, ensure heater is on a flat, stable, heat-resistant
surface.
Once the heater is in a safe operating position and all switches are in the off
position, insert the power plug into the mains outlet and switch on.
CAUTION: Ensure the power cord is not tight because if pulled it may
partially pull the plug from the socket. A partially inserted plug will overheat
the plug and socket and could result in fire.
THERMOSTATIC CONTROL
1. Rotate thermostat knob clockwise until you reach the
maximum position.
2. When the room reaches a temperature that is comfortable
for you, slowly turn the knob anti-clockwise until the heater
just turns off (you will hear a click).
3. The heater will now cycle on and off to maintain the comfort
level you have set.
4. Take note of this setting position for future use.

TECHNICAL SPECIFICATION
Model No: GPH150, GPH250, GPH350, GPH450
Supply: 220-240VAC 50Hz
Wattage: 500W, 900-1000W, 1350-1500W, 1800-2000W
SUPPORT AND TECHNICAL ADVICE
Goldair –New Zealand
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
Goldair –Australia
Monday –Friday 8am-5pm
Phone [phone]
Phone [phone]
[email protected]
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase.
Operating Your Heater
SAFETY DEVICES
This appliance has two protection devices:
•Tilt Switch - this will automatically turn the appliance off if the appliance is not in
the correct operating position.
•Thermal Fuse - this disconnects the appliance permanently in case of overheating.
(It is non resettable).
CAUTION: The appliance generates heat during use. Precautions must be
taken to prevent the risk of burns, scalds, fires or other damage to persons.
CARE AND CLEANING
The heater requires regular cleaning to ensure trouble free operation:
•Unplug the heater from the mains supply before cleaning.
•Ensure that the heater has been allowed to cool down completely before cleaning.
•The common cause of overheating is deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
•Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and
dirt.
•Never use solutions such as petrol, thinners or polishing agents.
•Ensure the heater is dry before plugging back into the mains supply.
•Do not attempt to dismantle the heater.
•There are no user serviceable parts. For service or repair, contact an authorised
electrical service technician.

Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in normal
domestic use for a period of two years. In non-domestic use Goldair limits the voluntary warranty to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the
warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone
other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in relation to the
goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Two Year Warranty
Goldair Two Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Goldair –New Zealand
CDB Goldair
PO Box 100-707
N.S.M.C
Auckland
Phone [phone]
Phone [phone]
www.goldair.co.nz
Goldair –Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone [phone]
Phone 1300 GOLDAIR (1300 465 324)
www.goldair.com.au

New Zealand
PO Box 100707,
North Shore Mail Centre,
Auckland, 0745
www.goldair.co.nz
Australia
PO Box 574,
South Morang,
Victoria, 3752
www.goldair.com.au
