Golf-Lift GL-1 User manual

INSTRUCTION
MODEL: GL-1
1,000-Lbs. Capacity Equipment Lift
GOLF-LIFT
2950 S.E. LOOP 820
FORT WORTH, TX 76140
TOLL FREE: 800-788-9789
WWW.GOLF-LIFT.COM
March 2014 All rights reserved. CO8958 IN50036 Rev. - 3.12.14

ATTENTION: READ THIS INSTRUCTION BOOK COMPLETELY BEFORE OPERATING THE LIFT
THIS IS A 1,000-LBS. CAPACITY EQUIPMENT LIFT. FAILURE TO FOLLOW ALL SAFETY AND SERVICE PRECAUTIONS MAY RESULT IN
SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
BASIC SPECIFICATIONS GL-1
Length 93”
Full Raise 33”
Fully Lowered 7-1/4”
Width 48”
Weight Capacity 1,000 lbs
Inspection upon receipt of the lift
1. Always inspect the lift for freight damage and make note of any
damage on the bill of lading.
2. In case of freight damage, call the truck line immediately and
report the damage as a freight claim.

Final Set-Up for model GL-1

This lift is more than 90% factory pre-assembled. The following
steps will guide you
through the final set-up.
1. Unpack the lift from the shipping skid. With the lift table up side
down, connect the air hose to the air cylinder (Part # 26).
2. After tightening the hose to the cylinder, flip the lift over with
the table surface up.
3. Connect the other end of the air hose to the foot-operated
valve. Then connect the foot- operated valve to 100 PSI air supply.
DO NOT USE AIR SUPPLY WITH PRESSURE MORE THAN 100 PSI.
4. Release the safety bar by pushing the handle down. Operate
the foot valve by stepping on the foot pad forward to raise the lift.
The safety bar should engage the ladder automatically while lift is
rising. Step on the footpad again to set the pad in middle position
to stop the lift when it reaches the desired height. ALWAYS LOW-
ER LIFT IN THE NEAREST LOCKED POSITION BEFORE BEGINNING
WORK. NEVER USE THE LIFT UNLESS YOU ARE IN A LOCKED PO-
SITION. The lift should never be left unattended while attached to
air pressure. Disconnect the air pressure when lift is not attended
by qualified persons.
5. Install the approach ramp by dropping it into the holes punched
on the rear edge of the table.
6. Run the Extension panel tubes (Total Three, Part # 58) through
the holes on the side of the table. Install the side extensions onto
the protruding tubes. Using the clips supplied (part # 59) to secure
the tubes.
7. Drop the ramps for the side extensions in place as shown
above.
8. Run the Stabilizing tube through the square tube in the bottom
of the lift. Secure it with screws supplied (parts # 64)

The final Set-Up for the GL-1 model is complete

PARTS LIST GL-1
ITEM PART NUMBER DESCRIPTION QTY
1 AL-1000 SCISSOR A 1
2 AL-2000 SCISSOR B 1
3 AL-3000 LIFT TABLE 1
4 AL-4000 SAFETY BAR 1
5 AL-5202 APPROACH RAMP B 1
16 GB1152-89 OIL ZERK M6 4
17 GB91-86 COTTER PIN 2
18 GB882-86 PIN 2
19 AL-4004 PLASTIC GRIP 2
20 GB78-85 SET SCREW 2
21 YG09-9102-4 END RETAINER 2
22 AL-6006 BEARING 4
23 AL-6004 WASHER 2
24 GB95-85 WASHER 2
25 GB894.1-86 SPACER 2
26 YG09-9100 AIR CYLINDER 1
27 AL-6007 BEARING 2
28 YG09-9106 FITTING 1
29 GB894.1-86 SPACER 8
30 AL-5501 WHEEL 4
31 GB894.1-86 SPACER 2
32 30400-1005C WASHER 2
33 AL-6003 SHAFT 1
34 AL-6002 SHAFT 1
35 GB77-85 SET SCREW 2
36 YG09-9301 AIR HOSE 1
37 YG09-9107 FITTING 1
38 YG09-9300 FOOT-OPERATED VALVE 1
39 GB41-86 NUT M5 1
40 GB93-87 LOCK WASHER 1
41 GB95-85 WASHER 2
42 AL-6001 SAFETY BAR HOLDER 1
43 GB5781-86 BOLT M5*16 1
44 GB67-85 BOLT M6*10 1
45 GB96-85 WASHER 1
46 AL-5402 PLASTIC HANDLE 1
47 GB879-86 PIN 6*20 1
48 AL-5420 HANDLE 1
49 GB95-85 WASHER 1
50 AL-5401 SCREW 1
51 AL-5410 BASE, MOVING JAW 1
52 AL-5302C NUT 1
53 AL-5302B SLEEVE 1
54 GB879-86 PIN 4*40 1
55 AL-5302-1 WELDMENT, MOVING JAW 1
56 AL-5302D SUPPORT STUD 1
57 AL-5101 SIDE EXTENSION 2
58 AL-5601 EXTENSION PANEL TUBE 3
59 AL-5605 LOCKING CLIPS 6
60 AL-5201 APPROACH RAMP, SIDE EXT 2
61 AL-5602 STABILIZING TUBE 1
62 AL-5603 END CAP, STABILIZING TUBE 2
63 GB41-86 NUT M6 6
64 GB5781-86 LOCKING BOLTS M6*50 2
65 GB5781-86 BOLT M6*16 4
66 GB93-87 WASHER 4
67 AL-5510 DOLLY 1
68 PLASTIC HANDLE GRIP 2
