GoMax Electronics SW-5004DE User manual

HDMI 4x1 Seamless Switcher
with Quad-view support
User Manual
rev: 170719
Made in Taiwan
SW-5004DE

Safety and Notice
The SW-5004DE HDMI 4x1 Seamless Switcher with Quad-view support has been tested for
conformance to safety regulations and requirements, and has been certified for international use.
However, like all electronic equipments, the SW-5004DE should be used with care. Please read and
follow the safety instructions to protect yourself from possible injury and to minimize the risk of
damage to the unit.
●Follow all instructions and warnings marked on this unit.
●Do not attempt to service this unit yourself, except where explained in this manual.
●Provide proper ventilation and air circulation and do not use near water.
●Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
●Use only the power adapter and power cords and connection cables designed for this unit.
●Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION.................................................................................................................1
FEATURES.........................................................................................................................1
PACKAGE CONTENTS......................................................................................................1
SPECIFICATIONS..............................................................................................................2
PANEL DESCRIPTIONS.....................................................................................................3
CONNECTION DIAGRAM ..................................................................................................4
OPERATION APPROACH..................................................................................................5
WARRANTY .....................................................................................................................13

1
INTRODUCTION
The SW-5004DE HDMI 4x1 Seamless Switcher with Quad-view support provides the most
flexible and cost effective solution in the market to route high definition video source from one of the four
HDMI sources to the remote display in real time. This solution can be utilized in digital signage,
conference room presentation systems or other similar applications. In addition,
With 1080p output resolution, users can display the resulted mixed video with improved presentation
quality. In the meantime, the unit can be controlled thru the IR remote control, front panel button, software
control or cloud control to provide the most flexible control way to fit into any applications.
FEATURES
4x HDMI inputs and 1x HDMI output
Input resolution support from 640x480 to 1920x1200, interlaced or progressive
Output resolution supports up to 1920x1080
Supports seamless switching
Supports HDCP 1.4
Firmware upgradable for support of new features and technology enhancements
Supports IR remote control
The output display is forced to layout
This switcher can control by RS-232, push button, IR remote control and cloud control*
PACKAGE CONTENTS
1x SW-5004DE
1x DC 12V 5A
1x Installation software CD
1x User Manual
1x IR Remote control (28 keys)
1x IR Receiving cable
*Cloud support is thru an encrypted communication to provide the best private protection when
using SW-5004DE

2
SPECIFICATIONS
Model Name
SW-5004DE
Technical
Role of usage
Seamless Switcher
HDCP compliance
HDCP 1.4
Video bandwidth
6.75Gbps
Input Video Support
Up to 1920x1200@60
Output Video Support
720p60, 1080i60, 1080p60
Audio support
Bypass
Control
Software / Front Panel / IR Remote Control / Cloud Control
Input TMDS signal
1.2 Volts [peak to peak]
ESD protection
Human body model — ±15kV [air-gap discharge] & ±8kV [contact discharge]
Input
4x HDMI + 1x RS-232 + 1x Ethernet
Output
1x HDMI + 1x 3.5mm(Stereo)
HDMI connector
Type A [19-pin female]
RJ-45 connector
WE/SS 8P8C with 2 LED indicator
RS-232 connector
DE-9 [9-pin D-sub female]
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
312 x 143 x 27mm [1' x 5.6" x 1"]
Package
376 x 240 x 112mm [1'2" x 9.4" x 4.4"]
Carton
590 x 510 x 405mm [1'9" x 1'7" x 1'3"]
Weight
Model
808g [4.6oz]
Package
1385g [3lbs]
Power supply
12V 5A DC
Power consumption
10 W
Operation temperature
0~40°C [32~104°F]
Storage temperature
-20~60°C [-4~140°F]
Relative humidity
20~90% RH [no condensation]

3
PANEL DESCRIPTIONS
Front Panel
1. Input Selection Button: Input 1~4 source selection (from the left to the right is input 1, input 2, input 3,
input 4). If you press the input 1 button about 5 seconds, the output layout will change to Quad-view
mode ( ).
2. IR SENSOR: IR sensor for receiving the IR commands from IR remote
3. IR Receiver: 3.5mm socket for plugging in the extension cable of IR receiver
Rear Panel
4. Input 1-4: HDMI inputs (from the left to the right is input 4, input 3, input 2, input 1)
5. RS-232: RS-232 control port
6. Stereo Audio Out: Connect to analog stereo audio speaker
7. Output: HDMI output
8. Ethernet: Ethernet control port
9. Factory Reset: Switch the pin to do factory default reset
10. +12V DC: 12V DC power jack
For Quad-view mode, Upper left is Input 1; Rright upper is Input 2;
Lower left is Input 3; Right lower is Input 4.

4
CONNECTION DIAGRAM

5
OPERATION APPROACH
Method A: IR Remote Control
Button
Function
Power
Power on/off the device
Input 1
Select HDMI input 1 to be the input source
Input 2
Select HDMI input 2 to be the input source
Input 3
Select HDMI input 3 to be the input source
Input 4
Select HDMI input 4 to be the input source
Seamless
Seamless switching effect
Fade
Fade switching effect
Dissolve
Dissolve switching effect
1080p
Select 1080p@60 output resolution
720p
Select 720p@60 output resolution
1080i
Select 1080i@60 output resolution
Change the output layout to
Method B: Software Control through RS-232 port
1. System Requirement
(1) OS information : MS Win XP/7/8/10
(2) Baud rates: 115200
(3) Software size: 7MB
(4) Minimum RAM requirement: 256MB
2. Control interface
1
2
3

6
1 Mapping 3 Port Setting
2
System
When clicking on the software control program, the following dialog will pop-up (under
Microsoft Windows 7, please run as administrator).
RS-232 serial Mode: Use RS-232 to connect the port on device and computer. Select
correct COM port and click the Connect button.
Ethernet Mode: Enter the IP address of the device and click the Connect button.
(1)Mapping
You can assign arbitrary video source here and we provides three switching effects
for user select. You also can set the output resolution.

7
(2)System
Network Setting
User can use the Ethernet to control the switcher. Firstly, user should click on
the “IP Setting” button to setup network set. Next, users can setup the Ethernet
for the unit as below example shows. After the step of IP setting, please click
the “Apply” button.
Association Code
To get an “association code”. The device can use this code to pair with cloud
server for you can do cloud control.
Reset Cloud
Reset the cloud server
Factory Reset
Click Factory Reset button to do factory default reset.

8
The process of default reset will take about 25 seconds.
Firmware Version
Get the firmware version information.
Firmware Update
Firmware update device
Please select the correct COM port or click “Scan” button to connect
device.
Click “update” button to do firmware update.

9
If you want to change OSD font, please click “OSD Font Update” and
“update” button to change it.
(3)Port Setting
The function can reconnect this device. You can click button to update the
control connection. A “Port Setting” window will pop up for you to select the
approach to connect this device.

10
Method C: Cloud Control (Eagleyes) through Ethernet port
Create Account
The first time to use the Eagleyes service, please create a new account.
1. Access Eagleyes (http://www.eagleyes.io) and click “Create new account”.
2. The Registration page will pop up and please fill in your email and password information to
create your private account.

11
Add Device to Eagleyes
1. Firstly, please make sure the device is connected to the Ethernet. Then please executing the
software with device to get the association code (Note: the status of software is connected).
2. Access Eagleyes (http://www.eagleyes.io), and then log in your account on the right top
corner. Click Add device to add the device which you just got its association code.
3. Enter the Installer Email for online support in the future, and the Association Code for pairing
with your device.

12
4. After adding the device, the list of device related to your account will show on the right top
corner. You can click the button to switch device for control.
SW

13
WARRANTY
The SELLER warrants the SW-5004DE HDMI 4x1 Seamless Switcher with Quad-view support
free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER
or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period,
The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to
accident, disaster, abuse or any unauthorized modifications including static discharge and power surge.
This warranty is offered by the SELLER for its BUYER with direct transaction only. This warranty is void if
the warranty seal on the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at the current price of parts
and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment
to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss
or damage in transit. Under no circumstances will a unit be accepted without a return authorization
number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations, any
other implied warranty or fitness or merchantability for any particular purpose, all of which are expressly
disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible
for shipping charges to and from the SELLER. Cables and power adapters are limited to a 30 day
warranty and must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However, The
SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting
from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the
technical information contained herein regarding the SW-5004DE features and specifications is
subject to change without further notice.
