Goobay 30490 User manual

®
Schnellstart-Anleitung für
LED-Taschenlampen
Art.-Nr.: 30490+30491
ACHTUNG! Lesen Sie die Bedienungsanleitung vollständig und sorgfältig. Sie ist Bestandteil des Produktes und enthält wichtige Hinweise
zur Benutzung. Bewahren Sie dieses Dokument auf. Diese Bedienungsanleitung ist eine Schnellstart-Anleitung. Weitere Informationen
nden Sie auf beiliegender CD-ROM und/oder bekommen Sie ggf. über www.wentronic.com als Download oder über den Postweg über die
Adresse am Seitenende.
1 Sicherheitshinweise:
ACHTUNG! Die Montage und Demontage des Produktgehäuses darf nur durch ausgebildetes Fachpersonal erfolgen!
ACHTUNG! Kurzschlussgefahr! Überbrücken Sie keine Kontakte! Stecken Sie keine Gegenstände in Lüftungsschlitze oder Anschlussbuchsen!
ACHTUNG! Verletzungsgefahr durch herabstürzende Teile und Stoß! Achten Sie auf solide Befestigung! Die Schlaufe dient nur zum Aufhängen!
ACHTUNG! Gefahr durch Blendung! Nicht direkt ins Licht blicken! Nicht auf Lebewesen richten! Nicht im Straßenverkehr verwenden!
2 Beschreibung und Funktion:
Dieses Produkt ist eine spritzwassergeschützte LED-Taschenlampe im
robusten ABS-Kunststoffgehäuse. Aufgrund ihres geringen Gewichts
und der kompakten Bauweise ist sie ideal für unterwegs.
Nur im Trockenen verwenden!
3 Bedienung:
1. Vergleichen Sie die technischen Daten aller verwendeter Produkte und stellen Sie die Kompatibilität sicher.
2. Batteriewechsel:
2.1. Schrauben Sie die Gehäusevorderseite entgegen dem Uhrzeigersinn ab.
2.2. Stecken Sie die Batterien wie folgt mit richtiger Polarität in das Batteriefach:
30490: 2 x AA (Mignon) 1,5 V
30491: 2 x D (Mono) 1,5 V
2.3. Schrauben Sie die Gehäusevorderseite im Uhrzeigersinn zu.
3. Schalten Sie die Taschenlampe mit dem AN-/AUS-Schalter an oder aus.
5. Nutzen Sie die Schlaufe nur zum Aufhängen und Halten der Taschenlampe.
4 Gewährleistung und Haftung:
• Da der Hersteller keinen Einuss auf die Installation des Produktes hat, deckt die Gewährleistung nur das Produkt selbst ab.
• Der Hersteller haftet nicht für Personen- oder Sachschäden, die durch unsachgemäße Installation, Bedienung oder Wartung entstanden sind.
• Ändern und modizieren Sie das Produkt und dessen Zubehör nicht.
• Ein anderer als in dieser Betriebsanleitung beschriebener Einsatz ist unzulässig und führt zu Gewährleistungsverlust, Garantieverlust und Haftungsausschluss.
• Druckfehler und Änderungen an Gerät, Verpackung oder Anleitung behalten wir uns vor.
5 Entsorgungshinweise:
Elektrische und elektronische Geräte dürfen nach der europäischen WEEE Richtlinie nicht mit dem Hausmüll entsorgt werden. Deren Bestandteile müssen getrennt der
Wiederverwertung oder Entsorgung zugeführt werden, weil giftige und gefährliche Bestandteile bei unsachgemäßer Entsorgung die Umwelt nachhaltig schädigen können.
Sie sind als Verbraucher nach dem Elektrogesetz (ElektroG) verpichtet, elektrische und elektronische Geräte am Ende ihrer Lebensdauer an den Hersteller, die Verkaufs-
stelle oder an dafür eingerichtete, öffentliche Sammelstellen kostenlos zurückzugeben. Einzelheiten dazu regelt das jeweilige Landesrecht. Das Symbol auf dem Produkt,
der Betriebsanleitung oder/und der Verpackung weist auf diese Bestimmungen hin. Mit dieser Art der Stofftrennung, Verwertung und Entsorgung von
Altgeräten leisten Sie einen wichtigen Beitrag zum Schutz unserer Umwelt.
WEEE Richtlinie: 2002/96/EG
WEEE Nr.: 82898622
6 CE-Konformitätserklärung:
Dieses Produkt ist mit der nach Richtlinie 2004/108/EG und 2006/95/EG vorgeschriebenen Kennzeichnung versehen: Mit dem CE Zeichen erklärt Goobay®, eine einge-
tragene Handelsmarke der Wentronic GmbH, dass das Produkt die grundlegenden Anforderungen und Richtlinien der europäischen Bestimmungen erfüllt. Diese können
online auf www.wentronic.com angefordert werden. Alle Handelsmarken und registrierten Marken sind das Eigentum ihrer jeweiligen Inhaber.
7 Technische Daten:
* Die genannten Marken sind Eigentum Ihrer jeweiligen Inhaber und nur als Referenz erwähnt. Die Nutzung dieses Produktes geschieht auf Risiko des Benutzers.
Revision Date: 2011-05-25
Version 1
Modell 30490 30491
Betriebsspannung 3 V DC (2 x 1,5 V DC) 3 V DC (2 x 1,5 V DC)
LED 1 x Nichia-LED 3 x Nichia-LED
Lichtstrom 15 lm 45 lm
Betriebsdauer ca. 8 h ca. 15 h
Lebensdauer bis zu 100.000 h bis zu 100.000 h
Gehäuse ABS ABS
Gewicht 38 g 84 g
Maße 152 x Ø 39 mm 189 x Ø 60 mm
Goobay®
Pillmannstrasse 12
D-38112 Braunschweig/Germany
Schrauböffnung und
Batteriefach
LEDs
Halteöse
AN-/AUS-Schalter
30490
30491

®
Quick Start Guide for
LED torch
Article no.: 30490+30491
ATTENTION! Read the instructions carefully and completely. It is part of the product and contains important notes for use. Keep this docu-
ment! This manual is a quick start guide. Find more information on enclosed CD-ROM and/or via www.wentronic.com as download version,
or by mail where applicable. Find the address at the bottom of the page.
1 Safety Instructions:
ATTENTION! Only skilled electricians may assemble and disassemble the housing of the product.
ATTENTION! Risk of short-circuit! Never bridge contacts! Do not put things into slots or ports!
ATTENTION! Risk of injury by falling parts or impacts! Mind respectable connections! The hanger is only for hanging the torch up.
ATTENTION! Risk of blinding! Do not look into the light directly! Do not point to any creature! Do not use in trafcs!
2 Description and Function:
This product is a splash water resistant LED torch in robust ABS plastic housing.
Due to its low weight and the compact construction it is ideal for on the way.
Only use it in dry ambiences!
3 Operating:
1. Compare the specications of all products in use and make sure they are compatible to each other.
2. Changing the battery:
2.1. Unscrew the screw cap anticlockwise.
2.2. Insert batteries into the battery case in right polarity as follows:
30490: 2 x AA (Mignon) 1.5 V
30491: 2 x D (Mono) 1.5 V
2.3. Screw the screw cap clockwise.
3. Switch on/off the torch by using the ON/OFF switch.
5. Only use the hanger for hanging up and holding the torch.
4 Warranty and Responsibility:
• As the manufacturer has no inuence on installation, warranty only applies to the product itself.
• The manufacturer is not liable for damages to persons or property caused by improper installation, operation or maintenance.
• Do not alter or modify the product or its accessories.
• Any use other than described in this user`s manual is not permitted and causes loss of warranty, loss of guarantee, and non-liability.
• We reserve our right for misprints and changes of the device, packing, or user`s manual.
5 Disposal Instructions:
According to the European WEEE directive, electrical and electronic equipment must not be disposed with consumers waste. Its components must be recycled or disposed
apart from each other. Otherwise contaminative and hazardous substances can pollute our environment.
You as a consumer are committed by law to dispose electrical and electronic devices to the producer, the dealer, or public collecting points at the end of the devices lifetime
for free. Particulars are regulated in national right. The symbol on the product, in the user`s manual, or at the packaging alludes to these terms. With this kind of waste
separation, application, and waste disposal of used devices you achieve an important share to environmental protection.
WEEE Directive: 2002/96/EC
WEEE No: 82898622
6 CE Declaration:
This device corresponds to EU directive 2004/108/EC and 2006/95/EC: With the CE sign Goobay®, a registered trademark of the Wentronic GmbH ensures, that the
product is conformed to the basic standards and directives. These standards can be requested online on www.wentronic.com. All trademarks and registered brands are
the property of their respective owners.
7 Specications:
* The mentioned brands are the property of their respective owners and mentioned as reference only. Use of the product is at users own risk.
Revision Date: 2011-05-25
Version 1
Goobay®
Pillmannstrasse 12
D-38112 Braunschweig/Germany
screw cap and
battery case
LEDs
hanger
ON/OFF switch
30490
30491
Model 30490 30491
Operating voltage 3 V DC (2 x 1.5 V DC) 3 V DC (2 x 1.5 V DC)
LED 1 x Nichia LED 3 x Nichia LED
Lighting current 15 lm 45 lm
Operating time around 8 h around 15 h
Life time up to 100,000 h up to 100,000 h
Housing ABS ABS
Weight 38 g 84 g
Dimensions 152 x Ø 39 mm 189 x Ø 60 mm
