Goodman GGM Series Installation instructions

PRODUCT SPECIFICATIONS
SS-GGM www.goodmanmfg.com 7/08
Supersedes 2/08
HIGH-EFFICIENCY RETURN
GRILLE-MOUNT ELECTRONIC AIR CLEANER
GGM SERIES
The Goodman®High-Eciency Return Grille-
Mount Electronic Air Cleaner is designed to
remove airborne contaminants down to 0.01
micron. The GGM Series helps protect and
prolong the operating eciency of your heating
and cooling equipment.
Standard Features
Pre-lters (2) are constructed of aluminum mesh to pre-
vent lint and large particles from entering the collecting
cells
Collecting cells (2) are constructed of heavy-gauge
aluminum for durability and ease of maintenance
Plastic intake grille is easy to wipe clean
Hinged, swing-out door allows easy access to lters
Automatic interlock switch disconnects power when
door is opened
Electronic Air-proving Switch (AS) allows for quick
wiring; automatically cycles air cleaner on/o with the
system fan
Performance indicator light (green LED) indicates high
voltage to the collecting cells, ensuring air cleaner is
operating properly at a glance
Solid-state power board is manufactured on site for high
reliability and long life; uniquely equipped with a variable
resistor (potentiometer) to adjust high voltage output, if
necessary
Cabinet Features
Durable powder coat paint nish on heavy gauge steel
resists abrasion and provides trouble-free wall or ceiling
mount installation
Holes are provided to facilitate mounting to duct work
Easily installs on the wall or ceiling in the main return
duct of a central forced air heating/cooling system;
slides into ceiling box installed within trusses on 24”
centers without structural alterations
•
•
•
•
•
•
•
•
•
•
•

2 www.goodmanmfg.com SS-GGM
PRODUCT SPECIFICATIONS
Goodman Manufacturing Company, L.P., reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations.
Copyright © 2008 • Goodman Manufacturing Company, L.P. • Houston, Texas • Printed in the USA.
DIMENSIONS
FOR MORE INFORMATION, CALL THE AIR CLEANER HELP LINE TOLL FREE @ 1-800-267-8305
SPECIFICATIONS
Specifications AGM20AS-A Model
House Size N/A
Airflow up to 2000 cfm (up to 3398 m³/hr)
Duct Size 22” x 29.1” (55.9 x 73.9 cm)
Cabinet Dimensions 31.4” x 24.4” x 7” (79.8 x 62 x 17.8 cm)
Weight 38 lbs (17.5 kg)
Power 120 v / 60 hz / 30 watts
ACCESSORIES
DAX Detergent Size Part # To keep the lifetime filter system at its best, wash
collecting cells and pre-filters with DAX Electronic
Air Cleaner Detergent.
32 oz (1 L) Spray Bottle Part #9900
1.1 gal (4 L) Jug Part #9901
Cabinet
Performance
Indicator Light
ON/OFF Sw itch
Collecting Cells(2)
Prefilters (2)
Hinged Access Door
PlasticIntakeGrille
Cell Handles
Access Door
Screw
