PRODUCT SPECIFICATIONS
SS-GSAS www.goodmanmfg.com 5/08
Supersedes 1/08
WHOLE-HOUSE, HIGH-EFFICIENCY
ELECTRONIC AIR CLEANER
GSAS SERIES
The Goodman® high-eciency electronic air
cleanerisdesignedtoremoveaircontaminants
down to 0.01 micron. The GSAS series helps
protect and prolong the operating eciency
of the heating and cooling equipment.
Standard Features
Pre-lters (2) constructed of aluminum mesh to prevent
lint and large particles from entering the collecting cells
Collecting cells (2) constructed of heavy-gauge alumi-
num for durability and ease of maintenance
Activated carbon lters help remove unpleasant odors
Air-proving switch cycles air cleaner on/o with
system fan
ON/OFF switch light indicates power to air cleaner
Performance indicator light indicates high voltage to
collecting cells, ensuring proper air cleaner operation
Equipped with a variable resistor (potentiometer) to
adjust high-voltage output
Output is preset for optimum eciency; voltage may
vary in extreme conditions of dryness, humidity, or
proximity to hydro towers
Removable power box contains the ON/OFF switch,
performance indicator light, safety interlock switch,
high-voltage power board, and air-proving switch
Cabinet Features
Cell guides ensure proper placement of collecting
cells in cabinet
Heavy-gauge galvanized steel resists corrosion and
provides trouble-free vertical or horizontal installation
Durable powder-coat paint nish resists corrosion
•
•
•
•
•
•
•
•
•
•
•
•
For full details on our warranties, visit www.goodmanmfg.com

2 www.goodmanmfg.com SS-GSAS
PRODUCT SPECIFICATIONS
Goodman Manufacturing Company, L.P., reserves the right to discontinue, or change at any time, specifications or designs without notice or without
incurring obligations. Copyright © 2008 • Goodman Manufacturing Company, L.P. • Houston, Texas • Printed in the USA.
SPECIFICATIONS
ACCESSORIES
For more information, call the air cleaner help line toll-free 1-800-267-8305
Model Dimensions — inches / cm
ABCDEFGH
GSAS-10ASC 21 / 53.0 17 / 43.5 23¼ / 59.0 13⅛/ 33.5 20¾ / 53.0 1¼ / 3.0 23¾ / 60.5 2⅜/ 6.0
GSAS-11ASC 21 / 53.0 17 / 43.5 26 / 66.0 13⅝/ 34.5 24 / 61.0 1 / 2.5 26½ / 67.5 2⅛/ 5.5
GSAS-12ASC 25⅞/ 66.0 22 / 56.0 21¼ / 54.0 18 / 46.0 18¾ / 47.5 1¼ / 3.0 21¾ / 55.0 2⅜/ 6.0
GSAS-18ASC 25⅞/ 66.0 22 / 56.0 26 / 66.0 18 / 46.0 23½ / 59.5 1¼ / 3.0 26½ / 67.5 2⅜/ 6.0
Model GSAS-10 GSAS-11 GSAS-12 GSAS-18
House Size <2,400 ft²
<222.96 m²
<3,000 ft²
<278.70 m²
<3,000 ft²
<278.70 m²
>3,000 ft²
>278.70 m²
Airflow up to 1,200 CFM
up to 2,039 m³/hr
up to 1,400 CFM
up to 2,379 m³/hr
up to 1,400 CFM
up to 2,379 m³/hr
up to 2,000 CFM
up to 3,398 m³/hr
Duct Size 16” x 20”
40.5 x 51 cm
16” x 25”
40.5 x 63.5 cm
20” x 20”
51 x 51 cm
20” x 25”
51 x 63.5 cm
Weight 28 lbs / 12.9 kg 30 lbs / 13.5 kg 33 lbs / 15.3 kg 38 lbs / 17.5 kg
Power 120-volt
60 hz / 30 watts
120-volt
60 hz / 30 watts
120-volt
60 hz / 30 watts
120-volt
60 hz / 30 watts
Model Replacement Filter Forthemostpowerfulaircleaningsystem
available, add an Amana®brand True
HEPA Air Cleaner to the Amana®brand
Electronic Air Cleaner.
DAX Detergent Size Part #
GSAS-10
GSAS-11 Part #1156-3 32 oz (1L) Spray Bottle #9900
GSAS-12
GSAS-18 Part #1856-3 1.1 gal (4L) Jug #9901
To keep your lifetime filter system at its best, wash collecting cells and pre-filters with DAX Electronic Air Cleaner Detergent. Activated carbon
filters should be replaced every 3 to 6 months. Additional activated carbon filters are available in three-packs.
DIMENSIONS
Carbon Filters (3)
Door Cabinet
Power Box
