PRODUCT IDENTIFICATION
2
The model number is used for positive identification of component parts used in manufacturing. Please use this number
when requesting service or parts information.
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed ONLY by in-
dividuals meeting (at a minimum) the requirements of an
"entry level technician" as specified by the Air-Condition-
ing, Heating, and Refrigeration Institute (AHRI). Attempt-
ing to install or repair this unit without such background
may result in product damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING WARNING
WARNING
PG15240704 1 * *G / A
PRODUCT
TYPE:
Single Package
Cooling/Heating
PRODUCT
FAMILY:
G: Gas/Electric
PRODUCT
SERIES:
SEER
Rating
BRAND:
G: Goodman®
Brand or
Distinctions
A: Amana®
Brand
NOMINAL
CAPACITY:
24: 24,000 BTUH
30: 30,000 BTUH
36: 36,000 BTUH
37: 36,000 BTUH
42: 42,000 BTUH
48: 48,000 BTUH
49: 48,000 BTUH
60: 60,000 BTUH
HEATING INPUT
070: 69,000 BTUH
090: 92,000 BTUH
115: 115,000 BTUH
140: 138,000 BTUH
R
EFRIGERANT:
4: R-410A
MAJOR
REVISION:
M INOR
REVISION:
VOLTAGE:
1: 208-230V/1ph/60Hz
3: 208-230v/3ph/60Hz
4: 460v/3ph/60Hz

PRODUCT IDENTIFICATION
3
The model number is used for positive identification of component parts used in manufacturing. Please use this number
when requesting service or parts information.
APG152407041A*
APG153009041A*
APG153609041A*
APG153709041A*
APG154209041A*
APG154811541A*
APG154911541A*
APG156014041A*
GPG152407041A*
GPG153009041A*
GPG153609041A*
GPG153709041A*
GPG154209041A*
GPG154811541A*
GPG154911541A*
GPG156014041A*
* Indicates minor revision & is not used for order entry or inventory management
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING
APG152407041A*
APG153007041A*
APG153709041A*
APG154209041A*
APG154911541A*
The models listed below qualify
for the 2009 and 2010 Federal Tax Credits
for Energy Efficiency**
GPG152407041A*
GPG153007041A*
GPG153709041A*
GPG154209041A*
GPG154911541A*
**Note that these tax credits are subject to specific requirements set
forth in the American Recovery and Reinvestment Act of 2009 and
in the Internal Revenue Code. Goodman recommends that consum-
ers consult a tax professional if they have questions about the
applicability of these credits.

PRODUCT DESIGN
4
*PG15 Package Gas Units are designed for outdoor installa-
tions only in either residential or light commercial applica-
tions and are available in 2, 2-1/2, 3, 3-1/2, 4 & 5 ton sizes.
They are designed for 208/230 volt single phase applications.
The connecting ductwork (Supply and Return) can be con-
nected for either horizontal or vertical airflow. In the vertical
application, a matching Roof Curb is recommended.
A return air filter must be installed behind the return air grille(s)
or provision must be made for a filter in an accessible loca-
tion within the return air duct. The minimum filter area should
not be less than those sizes listed in the Specification Sec-
tion. Under no circumstances should the unit be operated
without return air filters.
A 3/4" pipe is provided for removal of condensate water from
the indoor coil. (Do not reduce the drain line size).
Refrigerant flow control is achieved by use of a TXV or ori-
fice.
*PG15 units use the FasTest Access Fitting System which
consists of a saddle that is either soldered to the suction and
liquid lines or is fastened with a locking nut to the access
fitting box (core) and then screwed into the saddle. NOTE:
The core must not be removed from the saddle until
the refrigerant charge has been removed. Failure to do
so could result in property damage or personal injury.
The single phase units use permanent split capacitors (PSC)
design compressors. Starting components are therefore not
required. A low MFD run capacitor assists the compressor
to start and remains in the circuit during operation.
The *PG15*****41AA models are equipped with X-13 blower
motors. X-13 motors are constant torque motors with very
low power consumption and are energized by a 24V signal
from the ignition control board. The X-13 features an inte-
grated control module.
Air for condensing (cooling cycle) is drawn through the out-
door coil by a propeller fan, and is discharged vertically out
the top of the unit. The outdoor coil is designed for .0 static.
No additional restriction (ductwork) shall be applied.
Conditioned air is drawn through the filter(s), field installed,
across the coil and back into the conditioned space by the
indoor blower.
The *PG15 series package units use the Compliant Scroll
compressor; there are a number of design characteristics
which are different from the traditional reciprocating compres-
sor.
- Due to their design Scroll compressors are inherently more
tolerant of liquid refrigerant. NOTE: Even though the com-
pressor section of a Scroll compressor is more tolerant of
liquid refrigerant, continued flood back or flooded start condi-
tions may wash oil from the bearing surfaces causing prema-
ture bearing failure.
- These Scroll compressors use "POE" orpolyolester oil which
is NOT compatible with mineral oilbased lubricants like 3GS.
"POE" oil must be used if additional oil is required.
- Compliant scroll compressors perform “quiet” shutdowns
that allow the compressor to restart immediately without the
need for a time delay. This compressor will restart even if the
system has not equalized.
- Operating pressures and amp draws may differ from stan-
dard reciprocating compressors. This information may be
found in the “Cooling Performance Data” section.
Some other models of the *PG15 series package units use a
2 stage scroll compressor. The basic scroll design has been
modified with the addition of an internal unloading mecha-
nism that opens a by-pass port in the first compression
pocket, effectively reducing the displacement of the scroll.
The opening and closing of the by-pass port is controlled by
an internal electrically operated solenoid.
The ZPS modulated scroll uses a single step of unloading
to go from full capacity to approximately 67% capacity. A
single speed, high efficiency motor continues to run while
the scroll modulates between the two capacity steps.

PRODUCT DESIGN
5
NOTE: To ensure proper condensate drainage, unit must be
installed in a level position.
In installations where the unit is installed above ground level
and not serviceable from the ground (Example: Roof Top in-
stallations) the installer must provide service platform for ser-
vice person with rails or guards in accordance with local codes
or ordinances or in their absence with the latest edition of the
National Fuel Gas Code ANSIZ223.1.
NOTE: Unit can also use roof curb (and platform for leveling,
where necessary) to utilize bottom discharge.
WARNING
TO PREVENT POSSIBLE PROPERTY DAMAGE, THE
UNIT SHOULD REMAIN IN AN UPRIGHT POSITION
DURING ALL RIGGING AND MOVING OPERATIONS.
TO FACILITATE LIFTING AND MOVING IF A CRANE IS
USED, PLACE THE UNIT IN AN ADEQUATE CABLE
SLING.
IMPORTANT: If using bottom discharge with roof curb,
ductwork should be attached to the curb prior to installing
the unit.
Refer to Roof Curb Installation Instructions for proper curb
installation. Curbing must be installed in compliance with
the National Roofing Contractors Association Manual.
Location and Clearances
NOTE: To ensure proper condensate drainage, unit must be
installed in a level position.
3"
MIN
12" MIN
1
2" MIN
36" MIN
(FOR SERVICE)
.
48" MIN
36" MIN
(FOR
SERVICE)
Outside Slab Installation
NOTE: Roof overhang should be no more than 36" and provi-
sions made to deflect the warm discharge air out from the
overhang. Minimum clearances are required to avoid air recir-
culation and keep the unit operating at peak efficiency.
Rooftop Installation

PRODUCT DESIGN
6
High Altitude Derate - U.S. Installations Only
IMPORTANT NOTE: The gas/electric units naturally derate
with altitude. Do not attempt to increase the firing rate by
changing orifices or increasing the manifold pressure. This
can cause poor combustion and equipment failure. At all
altitudes, the manifold pressure must be within 0.3 inches
W.C. of that listed on the nameplate for the fuel used. At all
altitudes and with either fuel, the air temperature rise must
be within the range listed on the unit nameplate. Refer to the
Installation Manual provided with the LP kit for conversion
from natural gas to propane gas and for altitude adjustments.
When this package unit is installed at high altitude, the ap-
propriate High Altitude orifice kit must be installed. As alti-
tude increases, there is a natural reduction in the density of
both the gas fuel and combustion air. This kit will provide the
proper design certified input rate within the specified altitude
range. High altitude kits are not approved for use in Canada.
For installations above 2,000 feet, use kit HA-02. The HA-02
kit is used for both Natural and LP gas at high altitudes.
Use LPM-06 propane conversion kit for propane conversions
at altitudes below 2000 feet. Natural gas installations below
2000 feet do not require a kit.
For propane conversions above 2000 feet, high altitude kit
HA-02 is required in addtion to LPM-05 propane conversion
kit.
2000 3000 4000 4500 5000 6000 7000 8000
U.S. BURNER ORIFICE 45/55 47/55 47/56 - 47/56 48/57 48/58 49/58
CANADA BURNER ORIFICE 45/55 - - 48/57 - - - -
2000 3000 4000 4500 5000 6000 7000 8000
U.S. BURNER ORIFICE 44/55 44/55 45/56 - 45/56 46/57 47/58 47/58
CANADA BURNER ORIFICE 44/55 - - 47/57 - - - -
2000 3000 4000 4500 5000 6000 7000 8000
U.S. BURNER ORIFICE 43/55 43/55 44/56 - 44/56 44/56 45/57 45/57
CANADA BURNER ORIFICE 43/55 - - 46/57 - - - -
ELEVATION ABOVE SEA-LEVEL (FEET)
20,000 BTUH NAT/20,OOO BTUH/L.P.
INPUT/BURNER
INPUT/BURNER
HIGH ALTITUDE
KIT
HA02
HIGH ALTITUDE
KIT
22,500 BTUH NAT/20,OOO BTUH/L.P.
ELEVATION ABOVE SEA-LEVEL (FEET)
HA02
HA02
INPUT/BURNER
25,000 BTUH NAT/20,OOO BTUH/L.P.
ELEVATION ABOVE SEA-LEVEL (FEET)
HIGH ALTITUDE
KIT
NATURAL GAS AND LP GAS INSTALLATIONS AT ALTITUDES > 2000 FT

7
PACKAGE GAS SPECIFICATIONS
COMBUSTION
AIR INTAKE
EXHAUST FLUE HOOD
CONTROL WIRE ENTRANCE
POWER WIRE ENTRANCE
7 7/8
7 5/16
SUCTION/LIQUID PRESSURE PORTS
BEHIND COMPRESSOR ACCESS PANEL
HEAT EXCHANGE ACCESS PANEL
GAS SUPPLY ENTRANCE
CONDENSATE DRAIN CONNECTION
3/4" NPT FEMALE
16 1/8
19 1/8
EVAPORATOR/CONTROL PANEL ACCESS PANEL
4 3/4
B
7 15/16
16
B
5 1/2
1 3/8
16
2 3/4
A
18 7/16
FLUE EXHAUST
51
47
BLOWER ACCESS PANEL
22
22
11
11
3SUPPLY
RETURN
SUPPLY RETURN
5 3/4
5 1/4
C
20
24
DIMENSION
(INCHES) MEDIUM LARGE
A3240
B1618
C91/214
CENTEROF
GRAVITY
COMBUSTION AIR INTAKE
FLUE EXHAUST
HOOD
UNIT DIMENSIONS
MEDIUM CHASSIS
*PG15[24-37]
LARGE CHASSIS
*PG15[42-60]

8
PACKAGE GAS SPECIFICATIONS
(1) Units installed in Canada are certifed only to 4500 feet.
(2) Calculated external filter size based on air velocity of 300 ft/min. and applies to disposable filters only.
(3) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit
breakers in accordance with the National Electrical Code and/or all local codes.
*PG15[24-37]***41AA
*PG152407041AA *PG153009041AA *PG153609041AA *PG153709041AA
COOLING COOLING CAPACITY, BTUH
CAPACITY HIGH STAGE 23,200 29,000 35,400 35,000
LOW STAGE N/A N/A 24,400 N/A
SEER / EER 15.0 / 12.0 14.5 / 12.0 15.0 / 11.0 14.5 / 12.0
HEATING BTUH INPUT (US) HIGH FIRE 69,000 92,000 92,000 92,000
CAPACITY OUTPUT (US) HIGH FIRE (Natural Gas) 55,000 73,500 73,500 73,500
OUTPUT (US) HIGH FIRE (LP) 50,000 69,000 69,000 69,000
BTUH INPUT (US) LOW FIRE 52,000 69,000 69,000 69,000
OUPUT (US) LOW FIRE (Natural) 41,500 55,000 55,000 55,000
OUTPUT (US) LOW FIRE (LP) 37,000 50,000 50,000 50,000
A.F.U.E. 80 80 80 80
RATED EXTERNAL STATIC (" w.c.) 0.50 0.50 0.50 0.50
TEMPERATURE RISE (°F) 35- 65 45- 75 45-75 45-75
PRESSURE SWITCH TRIP POINT (" w.c.) -.33" -.33" -.33" -.33"
UNIT VOLTAGE (NAMEPLATE) 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60
EL EC TRI C AL UNIT AMPS (TOTAL) 18.7 17.5 22.2 20.1
SP E CI FI C ATI ON MINIMUM CIRCUIT AMPACITY 22.1 21 26.5 24.2
MAXIMUM OVERCURRENT PROTECTION(3) 30 35 40 40
HEATING NUMBER OF BURNERS 3 4 4 4
SE C TI O N ORIFICE SIZE NATURAL 43 43 43 43
ORIFICE SIZE LP 55 55 55 55
COMPR ESSOR TYPE Scroll Scr oll Sc roll Scroll
RATED LOAD AMPS 13.5 14.1 16.7 16.7
LOCKED ROTOR AMPS 58.3 73 82 79
CONDENSER HORSEPOWER 1/6 1/4 1/4 1/4
FAN MOTOR RPM 815 830 1075 830
FULL LOAD AMPS 1.10 1.5 1.4 1.5
LOCKED ROTOR AMPS 1.7 3.0 2.9 3.0
CONDENSER BLADE DIAMETER (INCHES) 22 22 22 22
FAN NUMBER OF BLADES 3 3 3 3
CFM 2400 2700 2700 2700
CONDENSER FAC E AREA - SQ. FT. 12.3 12.3 12.3 12.3
COIL NUMBER OF ROWS 1 2 1 2
FINS PER INCH 22 16 22 16
EVAPORAT OR HORSEPOWER - NO. OF SPEEDS 1/2 - X-13 1/2 - X-13 1/2 - X-13 1/2 - X-13
BLOWER FULL LOAD AMPS 4.1 1.86 4.1 1.86
MOTOR LOCKED ROTOR AMPS N/A N/A N/A N/A
MOTOR SPEED TAP - COOLING T4 T3, T4 T3, T4 T3, T4
RPM / AMPS 724 / 1.21 960 / 3.06 640 / 0.98
960 / 3 .06 960 / 3.06
EVAPORAT OR DIAMETER X WIDTH (INCHES) 10 x 8 10 x 9 10 x 9 10 x 9
BLOWER RATED SCFM COOLING 845 1050 800 / 1225 1050
MAX EXTERNAL STATIC PRESS ("w.c.) 0.5 0.5 0.5 0.5
EVAPORAT OR FAC E AREA - SQ. FT. 4.33 4.33 4.33 4.33
COIL NUMBER OF ROWS 2 3 4 4
FINS PER INCH 14 14 14 14
FILTER SIZE - SQ. FT.(2) 2.7 4.2 4.2 4.2
DRAIN SIZE (INCHES) 3/4 3/4 3/4 3/4
HEATING PRIMARY LIMIT SETTING (°F) 160 160 160 160
LIMITS AUXILIARY LIMIT SETTING (°F) 150 150 150 150
ROLLOUT LIMIT SETTING (°F) 300 300 300 300
GENERAL EXPANSION DEVICE TXV 0.065 TXV TXV
INFORMATION REFRIGERANT CHARGE R-410A (Oz.) 81 102 99 112
POWER SUPPLY ENTRANCE SIZE (INCHES) 1 1/8 1 1/8 1 1/8 1 1/8
LOW VOLTAGE ENTRANCE SIZE (INCHES) 7/8 7/8 7/8 7/8
SHIPPING WEIGHT LBS. 439 475 480 480
OPERATING WEIGHT LBS. 417 453 458 458

PACKAGE GAS SPECIFICATIONS
9
(1) Units installed in Canada are certifed only to 4500 feet.
(2) Calculated external filter size based on air velocity of 300 ft/min. and applies to disposable filters only.
(3) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit
breakers in accordance with the National Electrical Code and/or all local codes.
*PG15[42-60]***41AA
*PG154211541AA *PG154811541AA *PG154911541AA *PG156014041AA
COOLIN G CA PAC IT Y, B TU H
HIGH STAGE 40,000 47,500 47,000 56,500
LOW STAGE N/A 35,000 33,000 41 ,000
SEER/EE R 14.5 / 12 .0 15 .0 / 1 1.0 15 .0 / 1 2.0 1 4.0 / 1 0 .1
BT UH INP U T (US) HI GH F IR E 1 15 ,000 1 1 5, 0 00 11 5, 00 0 13 8 ,000
OU TP UT ( US ) H IGH FI RE (N at u ra l G as ) 9 2,0 00 9 2, 0 0 0 9 2 ,00 0 110 , 20 0
OU TP UT ( US ) H IGH FI RE (L P) 8 3,0 00 8 3, 0 0 0 8 3 ,00 0 99 , 00 0
BT UH INP U T (US) LO W FIR E 8 6, 0 00 8 6,0 0 0 8 6 , 00 0 10 3 ,00 0
OU P UT ( US ) L O W FIRE (N at u ra l) 6 9,0 00 6 9, 0 0 0 6 9 ,00 0 83 , 00 0
OU TP UT ( US ) L O W FI RE (L P ) 6 2,0 00 6 2, 0 0 0 6 2 ,00 0 74 ,00 0
A.F. U .E. 80 8 0 8 0 8 0
RATED EXTERNAL ST ATIC (" w.c.) 0.5 0 0.50 0.50 0.50
TEMPERATURE RISE (°F) 45-75 45-75 45-75 45-75
PR E SSUR E SW ITC H TR IP P OINT ( " w .c . ) -. 33" - .33 " - .33" -. 33"
VOL TA GE (NA M EP L ATE ) 2 08- 23 0/ 1/6 0 20 8 -2 30 /1/ 6 0 2 08 -2 3 0/1 / 60 2 0 8- 23 0/ 1/ 60
UNIT AM PS ( TOTAL) 22.2 29.4 25.5 3 5.6
MINIM UM CIRCUIT AMPACITY 26.6 34.8 30.8 42.1
MAXIMUM OVERCUR RENT PROT ECTION(3) 40 50 50 60
NUM BER OF BURNER S 5 5 5 6
ORIFICE SIZE NATURAL 43 43 43 43
ORIFICE SIZE LP 55 55 55 55
TYPE Scr oll Scroll Scroll Scroll
RATED LOAD AMPS 17.9 21.2 21.2 2 5.6
LO C KE D R O TO R AMP S 1 12 9 6 9 6 11 8
HORSEPOWER 1/4 1/3 1/4 1/3
RPM 1075 1075 1075 1075
FULL LOAD AMPS 1.4 2.5 1.4 2.5
LOC KED R OTOR AMPS 2.9 5.8 2.9 5. 2
BL ADE DIA ME TE R ( I NCH E S) 22 22 2 2 22
NUMBER OF BLADES 3 4 3 4
CFM 3500 3500 3500 3500
FACE AREA - SQ. FT. 15.3 15.3 15.3 15.3
NUM BER OF ROWS 2 2 2 2
FINS PER INCH 16 16 16 16
HORSEPOWER - NO. OF SPEED S 3/4 - X-13 3/4 - X-13 3/4 - X-13 1 - X-13
FULL LOAD AMPS 2.87 6.00 2.87 7.60
LO C KE D R O TO R AMP S N/ A N/A N / A N/ A
MOTOR SPEED TAP - COOL ING T3, T4 T3, T 4 T3, T4 T3,T4
RPM / AMPS 89 0 / 3.8 647 / 1.66
890 / 3 .8 890 / 3.8 778 / 1.98 1030 / 5.7
DIAMETER X WIDTH (INCHES) 11 x 10 11 x 10 11 x 10 11 x 10
RATED SCFM COOLING 1200 1100 / 1510 1300 1300 / 1810
MAX EXTERNAL STATIC PRESS ("w.c.) 0.5 0.5 0.5 0.5
FACE AREA - SQ. FT. 5.67 5.67 5.67 5.67
NUM BER OF ROWS 4 4 4 4
FINS PER INCH 14 14 14 14
FILTER SIZE - SQ. FT.(2) 5.1 5.1 5.1 6.3
DRAIN SIZE (INC HES) 3/4 3/4 3/4 3/4
PR IMA RY L IM I T S ETTING (° F) 170 170 170 16 0
AU XIL IARY LIM IT S ET TING (°F ) 1 50 150 1 50 15 0
ROLLOUT LIMIT SETTIN G (°F) 300 300 300 300
EXPA NSION DEV ICE 0. 072 TXV TX V T XV
REFRIGERANT CHARGE R- 410A (Oz.) 162 169 167 177
POW ER S U PPL Y E N TRANC E S IZE (IN CHE S) 1 1/ 8 1 1/ 8 1 1/8 1 1 /8
LOW VOL TAGE E NTR A NCE S IZE (INC HES ) 7 /8 7/8 7/8 7 /8
SH IPPING W E IGHT L B S. 560 560 560 56 5
OPERATING WEIGHT LBS. 538 538 538 543

10
PACKAGE GAS SPECIFICATIONS
(1) Units installed in Canada are certifed only to 4500 feet.
(2) Calculated external filter size based on air velocity of 300 ft/min. and applies to disposable filters only.
(3) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit
breakers in accordance with the National Electrical Code and/or all local codes.
*PG15[36-60]***41AB
*PG153609041AB * PG154811541AB *PG156014041AB
COOLING COOLING CAPA CITY , BT UH
CAPACITY HIGH STAGE 35,400 47,500 56,500
LOW STAGE 24,400 35,000 41,00 0
SEER/EER 15.0 / 11.0 15.0 / 11.0 14.0 / 10.1
HEATING BTUH INPUT (US) HIGH FIRE 92,000 115,000 138,000
CAPACITY OUTPUT (US) HIGH FIRE (Natural Gas) 73,500 92,000 110,200
OUTPUT (US) HIGH FIRE (LP) 69,000 83,000 99,000
BTUH INPUT (US) LOW FIRE 69,000 86,000 103,500
OUPUT (US) LOW FIRE (Natural) 55,000 69,000 83,000
OUTPUT (US) LOW FIRE (LP) 50,000 62,000 74,000
A.F.U.E. 80 80 80
RATED EXTERN AL STATIC (" w.c.) 0.50 0.50 0.50
TEMPERATURE RISE (°F) 45-75 45-75 45-75
PRESSURE SWITCH TRIP POINT (" w.c.) -.33" -.33" -.33"
UNIT VOLTAGE (NAMEPLATE) 208-230/1/60 208-230/1/60 208-230/1/60
EL EC TRI C AL UNIT AMPS (TOTAL) 22.3 20.1 34.6
SP ECI FI C ATION MIN IMUM CIRC UIT AMPACITY 26.5 34.8 42.1
MAXIMUM OVERCU RREN T PROTECTION(3) 40 50 60
HEATING NUMBER OF BURN ERS 4 5 6
SE C TI ON ORIFICE SIZE NATURAL 43 43 43
ORIFICE SIZE LP 55 55 55
COMPRESSOR TYPE Scroll Scroll Scroll
RATED LOAD AMPS 16.7 21.2 25.8
LOCKED ROTOR AMPS 82 96 118
CONDENSER HORSEPOW ER 1/4 1/4 1/4
FAN MOTOR RPM 830 1075 1075
FULL LOAD AMPS 1.5 1.4 1.4
LOCKED ROTOR AMPS 3.0 5.2 5.2
CONDENSER BLADE DIAMETER (INCHES) 22 22 22
FAN NUMBER OF BLADES 3 3 3
CFM 2700 3500 3500
CONDENSER FACE AREA - SQ. FT. 12.3 15.3 15.3
COIL NUMBER OF ROWS 1 2 2
FINS PER INCH 22 16 16
EV APO RAT OR HORSEPOWER - N O. OF SPEEDS 1/2 - X-13 3/4 - X-13 1 - X-13
BLOWER FULL LOAD AMPS 4.1 6 7.6
MOTOR LOCKED ROTOR AMPS N/A N/A N/A
MOT OR SPEED TAP - COOL ING T3 , T4 T3, T4 T3,T 4
RPM / AM PS 640 / 0.98
960 / 3.06
647 / 1.66
890 / 3 .8
778 / 1.98
1030 / 5.7
EV APO RAT OR DIAMETER X WIDT H (IN CHES) 10 x 9 11 x 10 11 x 10
BLOWER RATED SCFM COOLING 800 / 1225 1100 / 1510 1300 / 1810
MAX EXT ERNAL STATIC PRESS ("w.c.) 0.5 0.5 0.5
EV APO RAT OR FACE AREA - SQ. FT. 4.33 5.67 5.67
COIL NUMBER OF ROWS 4 4 4
FINS PER INCH 14 14 14
FILTER SIZE - SQ. FT.(2) 4.2 5 .1 6 .3
DRAIN SIZE ( IN CHES) 3/4 3/4 3/4
HEATING PRIMARY LIMIT SETTING (°F) 160 170 160
LIMITS AUXILIARY LIMIT SETTING (°F) 150 150 150
ROLLOU T LIMIT SETTING (°F ) 3 00 300 300
GENERAL EXPANSION DEVICE TXV TXV TXV
IN FO RM ATIO N REFRIGERANT CH ARGE R-410A (Oz.) 102 172 180
POWER SUPPLY ENTRANCE SIZE (INCHE
S
1 1/8 1 1/8 1 1/8
LOW VOLTAGE ENTRANCE SIZE (INCHES) 7/8 7/8 7/8
SHIPPING WEIGHT LBS. 480 560 565
OPERATING WEIGHT LBS. 458 538 543

ACCESSORIES
11
NOTE: Complete lineup of thermostats can be found in the Thermostat Specification Sheets.
Part Number Description
LPM-06 Propane Conversion Kit
HA-02 High Altitude Kit
PGC101/10 2/103 Roof Curb
PGED101/102 Downflow Economi zer, Small and Medium Chassis
PGED103 Downflow Economi zer, Large Chassis
PGEH10 1/102 Horizon tal Ec onomi zer, Small and Medium Chassi s
PGEH10 3 Horizon tal Ec onomi zer, Large Chassis
PGMDD101/102 Manual 25% Fresh Air Damper Do wnflow Appli cation, Sma ll and Medium Chassis
PGMDD103 Manual 25% Fresh Air Damper Do wnflow Application, Large Chassis
PGMDH101 Manual 25% Fresh Air Damper Horizontal Application, Small Chassis
PGMDH102 Manual 25% Fresh Air Damper Horizontal Application, Medium Chassis
PGMDH103 Manual 25% Fresh Air Damper Horizontal Application, Large Chassis
PGMDMD101/102 Motorized 25% Fresh Air Damper Downflow Appli cation,Sma ll a nd Medium Chassi s
PGMDMD103 Motorized 25% Fresh Air Down flow Application, La rge Chas si s
PGMDMH101 Motorized 25% Fresh Air Damper Horizontal Application, Small Chassis
PGMDMH102 Motorized 25% Fresh Air Damper Ho rizontal Application, Medium Chassis
PGMDMH103 Motorized 25% Fresh Air Damper Ho rizontal Application, Large Chassis
SQRPG 101/102 Squa re to Round Adapter w/ 16" Ro und Downfl ow Appl ication, Sm all and Medium Chassis
SQRPG103 Square to Round Adapter w/ 18" Ro und Downflow Application, Large Chassis
SQRPGH101/102 Squa re to Round Adapter w/ 16" Ro und Horizontal Application, Small and Medium Ch assis
SQRPGH103 Squa re to Round Adapter w/ 18" Ro und Horizontal Appl ication, Large Chassis
PGFR101/102/103 Internal Filter Rack All Chassis
GPGHFR101-103 External Horizontal Filter Rack for Goo dman/Amana Gas/Electric
& Multi-positio n Package Units All Chassis
CDK36 Flush Mount Concentric Duct Kit
CDK36515 Flush Mount Concentric Duct Kit w/ Filter
CDK36530 Step Down Concentric Duct Kit
CDK36535 Step Down Concentric Duct Kit w/ Filter
CDK4872 Flush Mount Concentric Duct Kit
CDK4872515 Flush Mount Concentric Duct Kit w/ Filter
CDK4872530 Step Down Concentric Duct Kit
CDK4872535 Step Down Concentric Duct Kit w/ Filter
ACCESSORIES

12
BLOWER PERFORMANCE DATA
X = Outside of Temperature Rise Range - Not Recommended.
NOTE: The shaded area indicates ranges in excess of maximum external static pressure allowable when heating. For satisfactory operation,
external static pressure should not exceed 0.5" w.c.
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM W ATTS AMPS CFM WATTS AMPS CFM WATTS AMPS
0.1 742 84 0.75 52 907 134 1.18 57 857 116 1.04 907 134 1.18 1,040 185 1.33
0.2 677 89 0.82 57 857 140 1.24 61 816 126 1.16 857 140 1.24 988 198 1.40
0.3 631 97 0.90 62 814 149 1.32 64 760 131 1.18 814 149 1.32 949 208 1.42
0.4 575 101 0.92 X 761 154 1.33 X 721 140 1.25 761 154 1.33 903 213 1.49
0.5 526 111 1.01 X 727 165 1.41 X 670 145 1.31 727 165 1.41 871 222 1.55
0.6 - - - - 678 169 1.47 X 629 155 1.39 678 169 1.47 824 228 1.58
0.7 - - - - - - - - - - - - - - - - -
0.8 ---------------- -
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS AMPS CFM WATTS AMPS CFM WATTS AMPS
0.1 1,065 168 1.42 49 1,255 257 2.10 55 1,148 170 1.55 1,148 170 1.55 1,333 304 2.4 1
0.2 1,003 174 1.48 52 1,217 269 2.19 57 1,092 176 1.66 1,092 176 1.66 1,293 314 2.4 8
0.3 961 185 1.55 54 1,165 274 2.21 59 1,044 184 1.72 1,044 184 1.72 1,237 321 2.5 4
0.4 913 195 1.62 57 1,113 285 2.30 62 994 194 1.77 994 194 1.77 1,193 333 2.71
0.5 855 202 1.69 60 1,073 296 2.36 64 929 210 1.89 929 210 1.89 1,158 341 2.77
0.6 814 212 1.76 63 1,018 302 2.41 68 811 222 1.99 811 222 1.99 1,101 345 2.78
0.7 749 218 1.82 69 991 313 2.48 70 763 224 2.03 763 224 2.03 -- -
0.8 713 227 1.87 72 -- - -
715 236 2.07 715 236 2.07 -- -
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS AMPS CFM WATTS AMPS CFM WATTS AMPS
0.1 1,065 168 1.42 49 1,255 257 2.10 55 924 120 1.08 1,333 304 2.41 1,418 360 2.92
0.2 1,003 174 1.48 52 1,217 269 2.19 57 863 128 1.14 1,293 314 2.48 1,375 371 3.00
0.3 961 185 1.55 54 1,165 274 2.2 1 59 812 138 1.24 1,237 321 2.54 1,316 376 3.05
0.4 913 195 1.62 57 1,113 285 2.3 0 62 745 145 1.27 1,193 333 2.71 1,279 387 3.13
0.5 855 202 1.69 60 1,073 296 2.3 6 64 702 154 1.35 1,158 341 2.77 1,245 392 3.19
0.6 814 212 1.76 63 1,018 302 2.4 1 68 643 159 1.37 1,101 345 2.78 1,193 400 3.22
0.7 749 218 1.82 69 991 313 2.48 70 601 168 1.44 - - - - - -
0.8 713 227 1.87 72 -- - -
502 173 1.52 - - - -- -
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS AMPS CFM WATTS AMPS CFM WATTS AMPS
0.1 1,065 168 1.42 49 1,255 257 2.10 55 1,148 170 1.55 1,148 170 1.55 1,418 360 2.92
0.2 1,003 174 1.48 52 1,217 269 2.19 57 1,092 176 1.66 1,092 176 1.66 1,375 371 3.00
0.3 961 185 1.55 54 1,165 274 2.21 59 1,044 184 1.72 1,044 184 1.72 1,316 376 3.05
0.4 913 195 1.62 57 1,113 285 2.30 62 994 194 1.77 994 194 1.77 1,279 387 3.13
0.5 855 202 1.69 60 1,073 296 2.36 64 929 210 1.89 929 210 1.89 1,245 392 3.19
0.6 814 212 1.76 63 1,018 302 2.41 68 811 222 1.99 811 222 1.99 1,193 400 3.22
0.7 749 218 1.82 69 991 313 2.48 70 763 224 2.03 763 224 2.03 -- -
0.8 713 227 1.87 72 -- - -
715 236 2.07 715 236 2.07 -- -
T1 - 1st Stage Heating Speed T2 - 2nd Stage Heating Speed T3 Cooling Spped T4 - Cooling Speed T5 - Cooling Speed
T1 - 1st Stage Heating Speed T2 - 2nd Stage Heating Speed T3 Cooling Spped T4 Cooling Speed T5 - Cooling Speed
T2 - 2nd Stage Heating Speed
*PG15240701A* - Rise Range: 35° - 65°
T1 - 1st Stage Heating Speed
*PG153609041A* - Rise Range: 45° -75°
T1 - 1st Stage Heating Speed T2 - 2nd Stage Heating Speed
*PG153709041A* - Rise Range: 45° -75°
*PG153009041A* - Rise Range: 45° -75°
T3 - Cooling Speed T4 - Cooling Spped T5 - Cooling Spped
T3 - 1st Stage Cooling T4 - 2nd Stage Cooling T5 - Cooling Speed
*PG15[24-36]***41A*

13
BLOWER PERFORMANCE DATA
X = Outside of Temperature Rise Range - Not Recommended.
NOTE: The shaded area indicates ranges in excess of maximum external static pressure allowable when heating. For satisfactory operation,
external static pressure should not exceed 0.5" w.c.
*PG15[42-60]***41A*
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS AMPS CFM WATTS AMPS CFM WATTS AMPS
0.1 1,065 168 1.42 49 1,255 257 2.10 55 1,335 260 1.01 1,468 337 1.28 1,619 431 1.64
0.2 1,003 174 1.48 52 1,217 269 2.19 57 1,274 268 1.04 1,412 349 1.33 1,560 445 1.69
0.3 961 185 1.55 54 1,165 274 2.21 59 1,204 281 1.10 1,346 359 1.37 1,504 456 1.71
0.4 913 195 1.62 57 1,113 285 2.30 62 1,136 287 1.11 1,275 363 1.40 1,441 463 1.76
0.5 855 202 1.69 60 1,073 296 2.36 64 1,069 300 1.15 1,221 370 1.44 1, 38 0 475 1 .80
0.6 814 212 1.76 63 1,018 302 2.41 68 1,009 312 1.19 1,170 386 1.47 1, 32 5 489 1 .84
0.7 749 218 1.82 69 991 313 2.48 70 946 319 1.22 1,105 397 1.52 1,268 495 1.88
0.8 713 227 1.87 72 -- - -
886 331 1.27 1,042 406 1.54 1, 19 8 502 1 .90
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS A MPS CFM WATTS AMPS CFM WATTS AMPS
0.1 1140 178 1.52 56 1417 305 2.46 61 1,140 178 1.52 1,616 436 3.34 1,696 503 4.04
0.2 1090 188 1.57 59 1374 318 2.56 63 1,090 188 1.57 1,573 449 3.46 1,650 517 4.15
0.3 1038 199 1.67 62 1322 327 2.68 65 1,038 199 1.67 1,527 462 3.59 1,608 530 4.25
0.4 980 212 1.76 65 1273 338 2.72 68 980 212 1.76 1,485 474 3.69 1,566 543 4.39
0.5 914 220 1.79 70 1224 352 2.82 70 914 220 1.79 1,443 489 3.80 1,523 556 4.43
0.6 852 231 1.9 75 1176 365 2.88 73 852 231 1.90 1,399 502 3.86 1,480 569 4.55
0.7 806 242 1.97 X1121 379 2.93 X8062421.971,3565133.991,441580 4.65
0.8 741 248 2.01 X1068 391 2.98 X7412482.011,3075254.05 - - -
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS A MPS CFM WATTS AMPS CFM WATTS AMPS
0.1 1140 178 1.52 56 1417 305 2.46 61 1140 178 1.52 1,468 337 1.28 1,696 503 4.04
0.2 1090 188 1.57 59 1374 318 2.56 63 1090 188 1.57 1,412 349 1.33 1,650 517 4.15
0.3 1038 199 1.67 62 1322 327 2.68 65 1038 199 1.67 1,346 359 1.37 1,608 530 4.25
0.4 980 212 1.76 65 1273 338 2.72 68 980 212 1.76 1,275 363 1.40 1,566 543 4.39
0.5 914 220 1.79 70 1224 352 2.82 70 914 220 1.79 1,221 370 1.44 1,523 556 4.43
0.6 852 231 1.9 75 1176 365 2.88 73 852 231 1.9 1,170 386 1.47 1,480 569 4.55
0.7 806 242 1.97 X 1121 379 2.93 X 806 242 1.97 1,105 397 1.52 1,441 580 4.65
0.8 741 248 2.01 X1068 391 2.98 X741 248 2.01 1,042 406 1.54 -- -
Un it
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS A MPS CFM WATTS AMPS CFM WATTS AMPS
0.1 1773 488 3.64 43 1773 488 3.64 58 1,3 79 246 1.95 1,919 700 4.81 2,115 783 5.54
0.2 1713 501 3.73 45 1713 501 3.73 61 1,3 22 258 2.03 1,862 714 4.94 2,078 787 5.57
0.3 1693 509 3.78 45 1693 509 3.78 61 1,2 68 266 2.10 1,810 720 5.01 2,009 802 5.67
0.4 1653 518 3.84 46 1653 518 3.84 63 1,1 87 280 2.19 1,755 734 5.07 1,953 813 5.87
0.5 1597 529 3.91 48 1597 529 3.91 65 1,1 33 287 2.23 1,705 743 5.09 1,933 805 5.77
0.6 1534 541 3.99 50 1534 541 3.99 68 1,0 68 294 2.29 1,647 748 5.16 - - -
0.7 1485 552 4.09 52 1485 552 4.09 70 1,0 26 307 2.38 - - - - - -
0.8 - - - --- - -
-- - -- - - - -
T3 - 1st Stage Cooling T4 - 2nd Sta ge Coolin g T5 - Cooling Spped
T3 - 1st Stage Cooling T4 - 2nd Sta ge Co oling T5 - Cooling Speed
T3 - 1st Stage Cooling T4 - 2nd Sta ge Co oling T5 - Cooling Speed
*PG154811541A* - Rise Range: 45° - 75°
*PG154211541A* - Rise Range: 45° -75°
T1 - 1st Stage Heating Spee
d
T2 - 2n d Sta ge Heatin g Speed
*PG156014041A* - Rise Range: 45° - 75° High 30° - 60° Low
T1 - 1st Stage Heating Speed T2 - 2nd Stage Heating Speed
*PG154911541A* - Rise Range: 45° - 75°
T1 - 1st Stage Heating Speed T2 - 2nd Stage Heating Speed
T1 - 1st Stage Heating Speed T2 - 2nd Stage Heating Speed T3 Cooling Spped T4 Cooling Speed T5 - Cooling Speed

14
BLOWER PERFORMANCE DATA
30 40 50 60 70 80 90 110 120
100 130 140 150
100
90 80
70 60 50
40 30 20
10
OUTPUT BTU/HR x 1000
BTU OUTPUT vs TEMPERATURE RISE CHART
TEMPERATURE RISE
600 CFM
700
900
1000
1100
1200
1400
1600
1800
2000
2200
2400 CFM
FORMULAS
BTU OUTPUT = CFM x 1.08 x RISE
RISE = BTU OUTPUT
1.08 ÷ CFM
800

COOLING PERFORMANCE DATA
15
*PG1524***41A*
MODEL: *PG1524***41A* EXPANDED PERFORMANCE DAT
A
COOLING OPERATION
Design Subcooling, 10 °F + 3 @ the liquid access fitting connection AHRI 95 test conditions. Design Superheat 10 °F + 3 @ the compressor suction access fitting connection.
Outd oor Amb ie nt Te mpe ra ture
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB* Airflow 59 6
3
67 71 5
9
6
3
67 71 59 6
3
67 71 59 6
3
67 71 59 63 6
7
71 59 63 67 71
MBh 22.7 23.6 25.8 - 22.2 23.0 25.2 - 21.7 22.5 24.6 - 21.1 21.9 24.0 - 20.1 20.8 22.8 - 18.6 19.3 21.1 -
S/T 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.83 0.70 0.48 - 0.86 0.72 0.50 - 0.89 0.74 0.52 - 0.90 0.75 0.52 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
951 KW 1.51 1.54 1.59 - 1.62 1 .66 1. 71 - 1.72 1.76 1.82 - 1.82 1.86 1.92 - 1.89 1.93 2.00 - 1.96 2.00 2.07 -
AMPS 7.0 7.2 7.4 - 7.5 7.7 7.9 - 8.0 8.2 8.4 - 8.5 8.7 8.9 - 9.0 9.2 9.4 - 9.4 9.6 9.9 -
HI PR 227 244 257 - 254 274 289 - 289 311 328 - 329 354 374 - 370 399 421 - 409 440 465 -
LO PR 109 116 127 - 115 123 134 - 120 128 139 - 126 134 146 - 132 140 153 - 137 145 159 -
MBh 22.1 22.9 25.1 - 21.6 22.3 24.5 - 21.0 21.8 23.9 - 20.5 21.3 23.3 - 19.5 20.2 22.2 - 18.1 18.7 20.5 -
S/T 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 845 KW 1.49 1.53 1.57 - 1.61 1 .64 1.70 - 1.71 1.75 1.80 - 1.80 1.84 1.90 - 1.88 1.92 1 .98 - 1.94 1.99 2.05 -
AMPS 7.0 7.1 7.3 - 7.4 7.6 7.8 - 8.0 8.1 8.4 - 8.4 8.6 8.9 - 8.9 9.1 9.3 - 9.4 9.6 9.8 -
HI PR 224 241 255 - 252 271 286 - 286 308 325 - 326 351 370 - 367 395 417 - 405 436 460 -
LO PR 108 115 126 - 114 122 133 - 119 126 138 - 125 133 145 - 131 139 152 - 135 144 157 -
MBh 20.4 21.1 23.1 - 19.9 20.6 22.6 - 19.4 20.1 22.1 - 19.0 19.6 21.5 - 18.0 18.7 20.4 - 16.7 17.3 18.9 -
S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.47 - 0.83 0.69 0.48 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
739 KW 1.46 1.49 1.54 - 1.57 1 .60 1. 66 - 1.67 1.70 1.76 - 1.76 1.79 1.85 - 1.83 1.87 1.93 - 1.89 1.94 2.00 -
AMPS 6.8 7.0 7.1 - 7.3 7.4 7.6 - 7.8 8.0 8.2 - 8.2 8.4 8.6 - 8.7 8.9 9.1 - 9.1 9.3 9.6 -
HI PR 218 234 247 - 244 263 277 - 278 299 315 - 316 340 359 - 356 383 404 - 393 423 447 -
LO PR 105 112 122 - 111 118 129 - 115 123 134 - 121 129 140 - 127 135 147 - 131 139 152 -
MBh 23.1 23.8 25.8 27.7 22.6 23.3 25.2 27.0 22.0 22.7 24.6 26.4 21.5 22.1 24.0 25.7 20 .4 21.0 22.8 2 4.4 18.9 19.5 21.1 22.6
S/T 0.89 0.80 0.60 0.39 0.92 0.83 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.87 0.66 0.43 1.00 0.91 0 .69 0 .44 1. 00 0.91 0.69 0.45
Delta T 20 18 15 10 20 19 15 10 20 19 15 11 20 19 15 11 20 18 15 10 18 17 14 10
951 KW 1.52 1.55 1.60 1.6 5 1.64 1 .67 1.72 1.78 1.74 1.78 1.84 1.90 1.83 1.87 1.93 2.00 1.91 1.95 2 .02 2 .08 1.98 2.02 2.09 2.16
AMPS 7.1 7.2 7.4 7.6 7.6 7.7 7.9 8.2 8.1 8.3 8.5 8.8 8.6 8.7 9.0 9.3 9.0 9.2 9.5 9.8 9.5 9.7 10.0 10.3
HI PR 229 246 260 271 257 276 292 304 292 314 332 346 333 358 378 3 94 3 74 403 425 44 3 41 3 4 45 470 490
LO PR 110 117 128 136 117 124 135 144 121 129 141 150 127 13 5 148 157 133 142 155 165 138 147 160 171
MBh 22.4 23.1 25.0 26.8 21.9 22.6 24.4 26.2 21.4 22.0 23.9 25.6 20.9 21.5 23.3 25.0 19 .8 20.4 22.1 2 3.7 18.4 18.9 20.5 22.0
S/T 0.85 0.76 0.57 0.37 0.88 0.79 0.60 0.38 0.90 0.81 0.61 0.39 0.93 0.83 0.63 0.41 0.97 0.86 0 .65 0 .42 0. 98 0.87 0.66 0.42
Delta T 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
75 845 KW 1.51 1.54 1.59 1.64 1.62 1 .66 1.71 1.77 1.72 1.76 1.82 1.88 1 .82 1.86 1.92 1.98 1.89 1.93 2.00 2 .07 1.96 2.00 2.07 2 .14
AMPS 7.0 7.2 7.4 7.6 7.5 7.7 7.9 8.1 8.0 8.2 8.4 8.7 8.5 8.7 8.9 9.2 9.0 9.2 9.4 9.7 9.4 9.6 9.9 10.2
HI PR 227 244 257 269 254 274 289 301 289 311 329 343 329 354 374 3 90 3 70 399 421 43 9 40 9 4 41 465 485
LO PR 109 116 127 135 115 123 134 143 120 128 139 148 126 13 4 146 156 132 140 153 163 137 145 159 169
MBh 20.7 21.3 23.1 24.8 20.2 20.8 22.6 24.2 19.8 20.3 22.0 23.6 19.3 19.8 21.5 23.1 18 .3 18.9 20.4 2 1.9 17.0 17.5 18.9 20.3
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0 .63 0 .41 0. 94 0.84 0.64 0.41
Delta T 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10
739 KW 1.47 1.50 1.55 1.6 0 1.58 1 .62 1.67 1.72 1.68 1.72 1.77 1.83 1.77 1.81 1.87 1.93 1.84 1.89 1 .95 2 .01 1.91 1.95 2.02 2.09
AMPS 6.9 7.0 7.2 7.4 7.3 7.5 7.7 7.9 7.9 8.0 8.2 8.5 8.3 8.5 8.7 9.0 8.8 8.9 9.2 9.5 9.2 9.4 9.7 10.0
HI PR 220 237 250 260 247 265 280 292 280 302 319 332 319 344 363 3 79 3 59 387 408 42 6 39 7 4 27 451 471
LO PR 106 113 123 131 112 119 130 138 116 124 135 144 122 13 0 142 151 128 136 149 158 132 141 154 164
*EnteringIndoorDryBulbTemperature NOTE: ShadedareaisACCA(TVA)conditions KW=Totalsystempower
High and low pressures are measured at the l iquid and suction access fittings. AMPS: Unit amps (comp.+ evaporator + condenser fan motors)

16
COOLING PERFORMANCE DATA *PG1524***41A*
MODEL: *PG1524***41A* EXPANDED PERFORMANCE DATA COOLING OPERATION Design Subcooling, 10 °F + 3 @ the liquid access fitting connection AHRI 95 test conditions. Design Superheat 10 °F + 3 @ the compressor suction access fitting connection.
Outdoor Ambient Tem
p
erature
65 75 85 95 105 115
Ent ering Indoor Wet Bulb Temperature
IDB* Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 23.5 24.0 25.7 27.5 23.0 23.5 25.1 26.8 22.4 22.9 24.5 26.2 21.9 22.4 23.9 25.5 20.8 21.2 22.7 24.3 19.3 19.7 21.0 22.5
S/T 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.85 0.63 1.00 1.00 0.86 0.64
Delta T 23 21 19 15 22 22 19 15 22 22 19 15 21 22 19 15 20 21 19 15 19 19 17 14
951 KW 1.53 1.56 1.61 1.66 1.65 1.68 1.74 1.80 1.75 1.79 1.85 1.91 1.85 1.89 1.95 2.01 1.92 1.97 2 .03 2.10 1.99 2.04 2.11 2.18
AMPS 7.1 7.3 7.5 7.7 7.6 7.8 8.0 8.2 8.2 8.3 8.6 8.8 8.6 8.8 9.1 9.4 9.1 9.3 9.6 9.9 9.6 9.8 10.1 10.4
HI PR 231 249 263 274 259 279 295 307 295 317 335 350 336 362 382 398 378 407 430 448 418 449 475 495
LO PR 111 119 129 138 118 125 137 146 122 130 142 151 129 137 149 159 135 143 156 167 139 148 162 172
MBh 22.8 23.3 24.9 26.7 22.3 22.8 24.4 26.0 21.8 22.3 23.8 25.4 21.3 21.7 23.2 24.8 20.2 20.6 2 2.0 23.6 18.7 19.1 20.4 21.8
S/T 0.93 0.87 0.71 0.53 0.97 0.91 0.74 0.55 0.99 0.93 0.76 0.56 1.00 0.96 0.78 0.58 1.00 0.99 0 .81 0.61 1.00 1.00 0.82 0.61
Delta T 23 22 19 15 23 22 20 16 23 22 20 16 23 23 20 16 22 22 19 16 20 21 18 1 4
80 845 KW 1.52 1. 55 1.60 1.65 1.64 1.67 1.73 1.78 1.74 1.78 1.84 1.9 0 1 .83 1.87 1.93 2.00 1.91 1.95 2 .02 2 .08 1.98 2.02 2.09 2 .16
AMPS 7.1 7.2 7.4 7.7 7.6 7.7 7.9 8.2 8.1 8.3 8.5 8.8 8.6 8.8 9.0 9.3 9.0 9.2 9.5 9.8 9.5 9.7 10.0 10.3
HI PR 229 246 260 271 257 276 292 304 292 314 332 346 333 358 378 394 374 403 425 444 413 445 470 490
LO PR 110 117 128 136 117 124 135 144 121 129 141 150 127 135 148 157 133 142 155 165 138 147 160 171
MBh 21.1 21.5 23.0 24.6 20.6 21.0 22.5 24.0 20.1 20.5 21.9 23.5 19.6 20.0 21.4 22.9 18.6 19.0 20.3 21.7 17.3 17.6 18.8 20.1
S/T 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.95 0.90 0.73 0.54 0.99 0.92 0.75 0.56 1.02 0.96 0.78 0.58 1.03 0.97 0.79 0.59
Delta T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15
739 KW 1.48 1.51 1.56 1.61 1.60 1.63 1.68 1.74 1.70 1.73 1.79 1.85 1.78 1.82 1.88 1.95 1.86 1.90 1 .96 2.03 1.93 1.97 2.03 2.10
AMPS 6.9 7.1 7.3 7.5 7.4 7.5 7.7 8.0 7.9 8.1 8.3 8.6 8.4 8.5 8.8 9.1 8.8 9.0 9.3 9.6 9.3 9.5 9.7 10.1
HI PR 222 239 252 263 249 268 283 295 283 305 322 336 323 347 367 382 363 391 412 430 401 432 456 475
LO PR 107 114 124 132 113 120 131 140 118 125 136 145 123 131 143 153 129 138 150 160 134 142 155 165
MBh 23.9 24.4 25.6 27.3 23.4 23.8 25.0 26.6 22.8 23.3 24.4 26.0 22.3 22.7 23.8 25.4 21.2 21.6 22.6 24.1 19.6 20.0 20.9 22.3
S/T 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.79 1.00 1.00 1.00 0.82 1.00 1.00 1.00 0.83
Delta T 23 23 22 19 23 23 22 19 22 23 22 19 22 22 22 19 20 21 22 19 19 19 20 18
951 KW 1.54 1.58 1.63 1.68 1.66 1.70 1.75 1.81 1.77 1.81 1.87 1.93 1.86 1.90 1.97 2.03 1.94 1.98 2 .05 2.12 2.01 2.05 2.12 2.20
AMPS 7.2 7.3 7.5 7.8 7.7 7.8 8.0 8.3 8.2 8.4 8.6 8.9 8.7 8.9 9.1 9.4 9.2 9.4 9.7 10.0 9.7 9.9 10.2 10.5
HI PR 233 251 265 277 262 282 298 310 298 321 339 353 339 365 386 402 382 411 434 452 422 454 479 500
LO PR 113 120 131 139 119 126 138 147 124 131 144 153 130 138 151 161 136 145 158 168 141 150 163 174
MBh 23.2 23.7 24.8 26.5 22.7 23.1 24.2 25.9 22.2 22.6 23.7 25.2 21.6 22.0 23.1 24.6 20.5 20.9 21.9 23.4 19.0 19.4 20.3 21.7
S/T 0.98 0.94 0.85 0.69 1.00 0.98 0.88 0.72 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.97 0.79 1.00 1.00 0.98 0.79
Delta T 25 24 23 20 25 25 23 20 24 25 23 20 24 24 23 20 22 23 23 20 21 21 22 19
85 845 KW 1.53 1. 56 1.61 1.66 1.65 1.68 1.74 1.80 1.75 1.79 1.85 1.9 1 1 .85 1.89 1.95 2.01 1.92 1.97 2 .03 2 .10 1.99 2.04 2.11 2 .18
AMPS 7.1 7.3 7.5 7.7 7.6 7.8 8.0 8.2 8.2 8.3 8.6 8.8 8.6 8.8 9.1 9.4 9.1 9.3 9.6 9.9 9.6 9.8 10.1 10.4
HI PR 231 249 263 274 259 279 295 307 295 317 335 350 336 362 382 398 378 407 430 448 418 449 475 495
LO PR 111 119 129 138 118 125 137 146 122 130 142 151 129 137 149 159 135 143 156 167 139 148 162 172
MBh 21.5 21.9 22.9 24.4 21.0 21.4 22.4 23.9 20.5 20.9 21.8 23.3 20.0 20.3 21.3 22.7 19.0 19.3 20.2 21.6 17.6 17.9 18.7 20.0
S/T 0.94 0.91 0.82 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.94 0.76
Delta T 25 25 23 20 25 25 24 20 25 25 24 20 25 25 24 21 24 24 23 20 22 22 22 19
739 KW 1.49 1.53 1.57 1.62 1.61 1.64 1.70 1.75 1.71 1.75 1.80 1.86 1.80 1.84 1.90 1.96 1.88 1.92 1 .98 2.05 1.94 1.99 2.05 2.12
AMPS 7.0 7.1 7.3 7.5 7.4 7.6 7.8 8.0 8.0 8.1 8.4 8.6 8.4 8.6 8.9 9.1 8.9 9.1 9.3 9.7 9.3 9.5 9.8 10.2
HI PR 224 241 255 266 252 271 286 298 286 308 325 339 326 351 370 386 367 395 417 435 405 436 460 480
LO PR 108 115 126 134 114 121 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
*EnteringIndoorDryBulbTemperature NOTE: ShadedareaisAHRIRatingConditions KW=Totalsystempower
High and low pressures are measured at the liquid and suction access fittings. AMPS: Unit amps (comp.+ evaporator + condenser fan motors)

COOLING PERFORMANCE DATA
17
*PG1530***41A*
KW = Total system power AMP S: Unit a mps (com p. + eva pora tor + conden ser f an mo to rs)
MODEL: *PG153009041A* EXPANDED PERFORMANCE DAT
A
COOLING OPERATION
Design Subcooling, 7 °F @ the liquid access fitt ing connection AHRI 95 test conditions. Design Superheat 5°F @ the compressor suction access fitting connection.
Outdoor Ambient Tempe ra ture
65 75 85 95 105 115
Ent ering Indoor Wet Bulb Temperature
IDB
*
Airflow 59 6
3
67 71 59 6
3
6
7
71 59 6
3
67 71 59 6
3
67 71 59 63 67 71 59 63 67 7 1
MBh 28.9 30.0 32.8 - 28.2 29.3 32.1 - 27.6 28.6 31.3 - 26.9 27.9 30.5 - 25.5 26.5 29.0 - 23.7 24.5 26.9 -
S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
1125 KW 1.85 1.89 1.94 - 1.99 2.03 2.09 - 2.11 2.16 2.23 - 2.2 2 2.27 2.34 - 2.31 2.37 2.44 - 2.39 2.45 2.53 -
AMPS 9.0 9.1 9.4 - 9.5 9.7 10.0 - 10.2 10.4 10.7 - 10.7 11.0 11.2 - 11.3 11.5 11.8 - 11.8 12.1 12.4 -
HI PR 226 243 256 - 253 273 288 - 2 88 310 327 - 328 353 373 - 369 397 419 - 408 439 463 -
LO PR 105 112 122 - 111 118 129 - 116 123 134 - 122 129 141 - 127 136 148 - 132 140 153 -
MBh 28.1 29.1 31.9 - 27.4 28.4 31.1 - 26.8 27.7 30.4 - 26.1 27.1 29.6 - 24.8 25.7 28.2 - 23.0 23.8 26.1 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -
Delta T 19 16 12 - 19 16 13 - 19 17 13 - 19 17 13 - 19 16 12 - 18 15 12 -
70 1000 KW 1.83 1.87 1.93 - 1 .97 2 .01 2.08 - 2.09 2.14 2.21 - 2 .20 2.25 2.32 - 2.30 2.3 5 2 .42 - 2.37 2. 43 2.51 -
AMPS 8.9 9.1 9.3 - 9.5 9.6 9.9 - 10.1 10.3 10.6 - 10.7 10.9 11.2 - 11.2 11.4 11.8 - 11.8 12.0 12.3 -
HI PR 223 240 254 - 251 270 285 - 2 85 307 324 - 325 350 369 - 365 393 415 - 404 434 459 -
LO PR 104 111 121 - 110 117 128 - 115 122 133 - 120 128 140 - 126 134 147 - 130 139 152 -
MBh 25.9 26.8 29.4 - 25.3 26.2 28.7 - 24.7 25.6 28.0 - 24.1 25.0 27.4 - 22.9 23.7 26.0 - 21.2 22.0 24.1 -
S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -
Delta T 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
875 KW 1.79 1.83 1.88 - 1.9 2 1.97 2.03 - 2.04 2.09 2.15 - 2 .15 2.20 2.27 - 2.24 2.2 9 2 .36 - 2.32 2. 37 2.44 -
AMPS 8.7 8.9 9.1 - 9.3 9.4 9.7 - 9.9 10.1 10.3 - 10.4 10.6 10.9 - 11.0 11.2 11.5 - 11.5 11.7 12.0 -
HI PR 217 233 246 - 243 262 276 - 2 77 298 314 - 315 339 358 - 354 381 403 - 392 421 445 -
LO PR 101 108 118 - 107 114 124 - 111 118 129 - 117 124 136 - 122 130 142 - 127 135 147 -
MBh 29.4 30.3 32.8 35.2 28.7 29.6 32.0 34.3 28.0 28.9 31.2 33.5 27.3 28.2 30.5 32.7 26.0 26.7 2 9.0 3 1.1 24.1 24 .8 26.8 28.8
S/T 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.92 0.83 0.63 0.40 0.95 0.85 0.65 0.42 0.99 0.8 9 0 .67 0 .43 1.00 0.89 0.68 0 .43
Delta T 21 19 16 11 21 19 16 11 21 19 16 11 21 20 16 11 21 19 16 11 20 18 15 10
1125 KW 1.86 1.90 1.96 2.02 2.00 2.05 2.11 2.18 2.13 2.18 2.25 2.32 2.24 2.29 2.36 2.44 2.33 2.3 9 2 .46 2 .55 2.41 2.47 2.55 2 .64
AMPS 9.0 9.2 9.4 9.7 9.6 9.8 10.0 10.3 10.3 10.5 10.7 11.1 10.8 11.0 11.3 11.7 11.4 11.6 1 1.9 1 2.3 11.9 12.2 12.5 12.9
HI PR 228 245 259 270 256 275 291 303 291 313 331 345 331 35 7 377 3 93 3 73 401 424 442 412 443 468 488
LO PR 106 113 124 132 112 120 131 139 117 124 136 145 123 13 1 14 3 152 129 137 149 159 133 142 155 165
MBh 28.5 29.4 31.8 34.1 27.9 28.7 31.1 33.3 27.2 28.0 30.3 32.6 26.6 27.3 29.6 31.8 25.2 26.0 2 8.1 3 0.2 23.4 24 .1 26.0 27.9
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.94 0.8 4 0 .64 0 .41 0.95 0.85 0.64 0 .41
Delta T 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 17 11 20 19 15 11
75 1000 KW 1.85 1.89 1.95 2.0 1 1.99 2 .03 2.10 2.16 2. 11 2.16 2.23 2.30 2.22 2.27 2.34 2.42 2.31 2.37 2 .44 2.53 2.39 2.45 2.53 2.61
AMPS 9.0 9.1 9.4 9.6 9.5 9.7 10.0 10.3 10.2 10.4 10.7 11.0 10.7 11.0 11.2 11.6 11.3 11.5 1 1.8 1 2.2 11.8 12.1 12.4 12.8
HI PR 226 243 257 268 253 273 288 300 288 310 327 341 328 35 3 373 3 89 3 69 397 419 438 408 439 463 483
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 122 12 9 14 1 150 127 136 148 158 132 140 153 163
MBh 26.3 27.1 29.4 31.5 25.7 26.5 28.7 30.8 25.1 25.9 28.0 30.0 24.5 25.2 27.3 29.3 23.3 24.0 2 5.9 2 7.8 21.6 22 .2 24.0 25.8
S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.78 0.59 0.38 0.91 0.8 1 0 .62 0 .40 0.92 0.82 0.62 0 .40
Delta T 22 20 17 12 22 21 17 12 22 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11
875 KW 1.80 1.84 1.90 1. 96 1.9 4 1.98 2.04 2.11 2.06 2.11 2.17 2.24 2.1 7 2.21 2.29 2.36 2.26 2.3 1 2 .38 2 .46 2.34 2.39 2.47 2 .55
AMPS 8.8 9.0 9.2 9.4 9.3 9.5 9.8 10.0 10.0 10.2 10.4 10.7 10.5 10.7 11.0 11.3 11.0 11.3 1 1.6 1 1.9 11.6 11.8 12.1 12.5
HI PR 219 236 249 260 246 264 279 291 279 301 318 331 318 34 3 362 3 77 3 58 385 407 424 396 426 450 469
LO PR 102 109 119 126 108 115 125 134 112 119 130 139 118 12
5
137 146 124 132 144 15 3 12 8 136 148 158
*EnteringIndoorDryBulbTemperature NOTE: ShadedareaisACCA(TVA)conditions
High and low pressures are measured at the l iquid and suction access fittings.

18
COOLING PERFORMANCE DATA *PG1530***41A*
MODEL: *PG153009041A* EXPANDED PERFORMANCE DATA COOLING OPERATION Design Subcooling, 7 °F @ the liquid access fitt ing connection AHRI 95 test conditions. Design Superheat 5°F @ t he compressor suction access fitting connection.
Outdoor Ambient Tem
p
erature
65 75 85 95 105 115
Ent ering Indoor Wet Bulb Temperature
IDB* Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 29.9 30.6 32.7 34.9 29.2 29.9 31.9 34.1 28.5 29.2 31.1 33.3 27.8 28.4 30.4 32.5 26.4 27.0 28.9 30.9 24.5 25.0 26.7 28.6
S/T 0.95 0.89 0.73 0.54 1.00 0.93 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.62
Delta T 23 22 19 16 24 23 20 16 23 23 20 16 23 23 20 16 22 22 20 16 20 20 18 15
1125 KW 1.88 1.92 1.98 2.04 2.0 2 2.06 2.13 2.20 2.15 2.19 2.26 2.34 2.26 2.31 2.38 2.46 2.35 2.41 2.48 2.57 2.44 2.49 2.57 2.66
AMPS 9.1 9.3 9.5 9.8 9.7 9.9 10.1 10.4 10.3 10.5 10.8 11.1 10.9 11.1 11.4 11.8 11.5 11.7 12.0 12.4 12.0 12.3 12.6 13.0
HI PR 230 248 262 273 258 278 294 306 294 316 334 348 335 360 380 397 377 405 428 446 416 448 473 493
LO PR 108 114 125 133 114 121 132 141 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166
MBh 29.0 29.7 31.7 33.9 28.4 29.0 31.0 33.1 27.7 28.3 30.2 32.3 27.0 27.6 29.5 31.5 25.7 26.2 2 8.0 30.0 23.8 24.3 26.0 27.8
S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.76 0.57 1.00 0.97 0 .79 0.59 1.00 0.98 0.80 0.60
Delta T 24 23 20 16 25 24 20 16 25 24 21 16 25 24 21 16 24 23 20 16 22 22 19 1 5
80 1000 KW 1.86 1.90 1.96 2.0 2 2 .00 2 .05 2.11 2.18 2.13 2.18 2.25 2.32 2.24 2.29 2.36 2.44 2.33 2.39 2 .46 2.55 2.42 2. 47 2.55 2.64
AMPS 9.0 9.2 9.4 9.7 9.6 9.8 10.0 10.3 10.3 10.5 10.7 11.1 10.8 11.0 11.3 11.7 11 .4 11.6 1 1.9 1 2.3 11.9 12.2 12.5 12.9
HI PR 228 245 259 270 256 275 291 303 291 313 331 345 331 357 377 393 373 401 424 442 412 443 468 488
LO PR 106 113 124 132 113 120 131 139 117 124 136 145 123 131 143 152 129 137 149 159 133 142 155 165
MBh 26.8 27.4 29.3 31.3 26.2 26.8 28.6 30.6 25.6 26.1 27.9 29.8 24.9 25.5 27.2 29.1 23.7 24.2 25.9 27.7 21.9 22.4 24.0 25.6
S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.94 0.76 0.57 1.01 0.94 0.77 0.57
Delta T 25 24 21 16 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 19 15
875 KW 1.82 1.86 1.91 1.97 1.96 2.00 2.06 2.13 2.08 2.12 2.19 2.26 2.18 2.23 2.31 2.38 2.28 2.33 2 .40 2.48 2.35 2.41 2.49 2.57
AMPS 8.9 9.0 9.2 9.5 9.4 9.6 9.8 10.1 10.0 10.2 10.5 10.8 10.6 10.8 11.1 11.4 11.1 11.3 11.7 12.0 11.7 11.9 12.2 12.6
HI PR 221 238 251 262 248 267 282 294 282 304 321 335 322 346 365 381 362 389 411 429 400 430 454 474
LO PR 103 110 120 128 109 116 127 135 113 121 132 140 119 127 138 147 125 133 145 154 129 137 150 160
NOTE: Shaded area reflects AHRI rating conditions
MBh 30.4 31.0 32.5 34.7 29.7 30.3 31.7 33.9 29.0 29.6 31.0 33.1 28.3 28.9 30.2 32.3 26.9 27.4 28.7 30.6 24.9 25.4 26.6 28.4
S/T 1.00 0.96 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.81
Delta T 25 24 23 20 24 25 23 20 24 24 23 20 23 24 24 20 22 22 23 20 20 21 22 19
1125 KW 1.89 1.93 1.99 2.06 2.0 4 2.08 2.15 2.22 2.16 2.21 2.28 2.36 2.28 2.33 2.40 2.48 2.37 2.43 2.51 2.59 2.46 2.51 2.59 2.68
AMPS 9.2 9.3 9.6 9.9 9.7 9.9 10.2 10.5 10.4 10.6 10.9 11.2 11.0 11.2 11.5 11.9 11.6 11.8 12.1 12.5 12.1 12.4 12.7 13.1
HI PR 233 250 264 276 261 281 297 309 297 319 337 352 338 364 384 401 380 409 432 451 420 452 478 498
LO PR 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 153 162 136 144 158 168
MBh 29.6 30.1 31.6 33.7 28.9 29.4 30.8 32.9 28.2 28.7 30.1 32.1 27.5 28.0 29.4 31.3 26.1 26.6 27.9 29.7 24.2 24.7 25.8 27.6
S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.95 0.77
Delta T 26 25 24 21 26 26 24 21 26 26 24 21 25 26 25 21 24 24 24 21 22 23 23 20
85 1000 KW 1.88 1.92 1.98 2.0 4 2 .02 2 .06 2.13 2.20 2.15 2.19 2.26 2.34 2.26 2.31 2.38 2.46 2.35 2.4 1 2 .48 2.57 2.44 2.49 2.57 2.6 6
AMPS 9.1 9.3 9.5 9.8 9.7 9.9 10.1 10.4 10.3 10.5 10.8 11.1 10.9 11.1 11.4 11.8 11.5 11.7 12.0 12.4 12.0 12.3 12.6 13.0
HI PR 230 248 262 273 258 278 294 306 294 316 334 348 335 360 380 397 377 405 428 446 416 448 473 493
LO PR 108 114 125 133 114 121 132 141 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166
MBh 27.3 27.8 29.1 31.1 26.6 27.2 28.4 30.3 26.0 26.5 27.8 29.6 25.4 25.9 27.1 28.9 24.1 24.6 25.7 27.5 22.3 22.8 23.8 25.4
S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.75
Delta T 26 26 24 21 27 26 25 21 27 26 25 21 27 26 25 22 25 26 25 21 23 24 23 20
875 KW 1.83 1.87 1.93 1.99 1.97 2.01 2.08 2.14 2.09 2.14 2.21 2.28 2.20 2.25 2.32 2.40 2.29 2.35 2 .42 2.50 2.37 2.43 2.51 2.59
AMPS 8.9 9.1 9.3 9.6 9.5 9.6 9.9 10.2 10.1 10.3 10.6 10.9 10.7 10.9 11.2 11.5 11.2 11.4 11.7 12.1 11.8 12.0 12.3 12.7
HI PR 223 240 254 265 251 270 285 297 285 307 324 338 325 349 369 385 365 393 415 433 404 434 459 478
LO PR 104 111 121 129 110 117 128 136 115 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161
*EnteringIndoorDryBulbTemperature NOTE: ShadedareaisAHRIRatingConditions KW=Totalsystempower
High and low pressures are measured at the liquid and suction access fittings. AMPS: Unit amps (comp.+ evaporator + condenser fan motors)

COOLING PERFORMANCE DATA
19
1ST STAGE *PG1536***41A*
MODEL: *PG1536***41A* EXPANDED PERFORMANCE DATA COOLING OPERATION Design Subcooling, 15°F + 3 @ the l iq ui d acc ess fi tt ing connec ti on AHRI 95 t est c ondi ti ons. Design Superhea t 9 °F + 3 @ the compressor suction access fitting connection.
Outdoor Ambient Temperature
65 7 5 85 95 105 1 15
Ente ring Indoor Wet Bul b Te mpe ra ture
IDB* Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 23.9 24.8 27.2 - 23.4 24.2 26.5 - 22.8 23.6 25.9 - 22.2 23.1 25.3 - 21.1 21.9 24.0 - 19.6 20.3 22.2 -
S/T 0 .76 0.64 0.44 - 0.79 0.66 0.4 6 - 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0.87 0.73 0 .50 - 0.88 0.73 0.51 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 13 - 19 16 12 - 18 15 12 -
900 K W 1 .5 9 1 .63 1.68 - 1.71 1.75 1 .80 - 1.82 1.86 1.92 - 1.91 1.95 2.02 - 1.99 2.03 2 .10 - 2.06 2.10 2.17 -
AMPS 7.2 7.3 7.5 - 7.7 7.8 8.1 - 8.2 8.4 8.7 - 8.7 8.9 9.2 - 9.2 9.4 9.7 - 9.7 9.9 10.2 -
HI PR 225 242 256 - 253 272 287 - 287 309 326 - 327 352 372 - 368 396 418 - 407 438 462 -
LO P R 111 11 8 12 8 - 117 124 13 6 - 1 21 12 9 14 1 - 1 28 13 6 14 8 - 134 142 155 - 1 38 147 161 -
MBh 23.2 24.1 26.4 - 22.7 23.5 25.7 - 22.1 22.9 25.1 - 21.6 22.4 24.5 - 20.5 21.3 23.3 - 19.0 19.7 21.6 -
S/T 0 .73 0.61 0.42 - 0.75 0.63 0.4 4 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0 .48 - 0.84 0.70 0.48 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
70 800 KW 1 .5 8 1 .62 1.66 - 1.70 1.74 1 .79 - 1.80 1.84 1.90 - 1.90 1.94 2.00 - 1.97 2.02 2 .0 8 - 2.04 2.09 2.15 -
AMPS 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.2 8.3 8.6 - 8.7 8.8 9.1 - 9.1 9.3 9.6 - 9.6 9.8 10.1 -
HI PR 223 240 253 - 250 269 284 - 284 306 323 - 324 349 368 - 364 392 414 - 403 433 458 -
LO P R 109 11 6 12 7 - 116 123 13 4 - 1 20 12 8 14 0 - 1 26 13 4 14 7 - 132 141 154 - 1 37 146 159 -
MBh 21.4 22.2 24.3 - 20.9 21.7 23.8 - 20.4 21.2 23.2 - 19.9 20.7 22.6 - 18.9 19.6 21.5 - 17.5 18.2 19.9 -
S/T 0 .70 0.59 0.41 - 0.73 0.61 0.4 2 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0 .46 - 0.81 0.67 0.47 -
Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
700 K W 1 .5 5 1 .58 1.63 - 1.66 1.70 1 .75 - 1.76 1.80 1.86 - 1.85 1.89 1.95 - 1.93 1.97 2 .03 - 1.99 2.04 2.10 -
AMPS 7.0 7.1 7.3 - 7.4 7.6 7.8 - 8.0 8.1 8.4 - 8.4 8.6 8.9 - 8.9 9.1 9.4 - 9.4 9.6 9.9 -
HI PR 216 233 246 - 243 261 276 - 276 297 314 - 314 338 357 - 353 380 402 - 391 420 444 -
LO P R 106 11 3 12 3 - 112 119 13 0 - 1 17 12 4 13 5 - 1 22 13 0 14 2 - 128 137 149 - 1 33 141 154 -
MBh 24.3 25.0 27.1 29.1 23.7 24.5 26.5 28.4 23.2 23.9 25.8 27.7 22.6 23.3 25.2 27 .1 21.5 22.1 2 3.9 25.7 19.9 20.5 22.2 2 3.8
S/T 0 .87 0 .78 0.59 0.38 0.90 0 .80 0.61 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.99 0.88 0 .67 0.43 1.00 0.89 0.67 0 .43
Delta T 22 20 16 11 22 20 16 11 22 20 16 11 22 20 17 11 22 20 1 6 11 20 19 15 11
900 K W 1 .6 1 1 .64 1.69 1.74 1.73 1.76 1 .8 2 1.88 1.83 1.87 1.93 2.00 1.93 1.97 2.03 2.10 2.01 2.05 2.1 2 2.19 2.08 2.12 2.19 2.26
AMPS 7.2 7.4 7.6 7.8 7.7 7.9 8.1 8.4 8.3 8.5 8.7 9.0 8.8 9.0 9.2 9.5 9.3 9.5 9.8 10.1 9.8 10.0 10.3 10.6
HI PR 227 245 258 270 255 275 290 302 290 312 330 344 331 356 376 392 372 400 423 441 411 442 467 487
LO P R 112 11 9 13 0 1 38 1 18 126 137 14 6 1 23 130 142 152 129 137 150 159 135 144 157 167 140 149 162 173
MBh 23.6 24.3 26.3 28.2 23.1 23.7 25.7 27.6 22.5 23.2 25.1 26.9 22.0 22.6 24.5 26 .3 20.9 21.5 2 3.2 25.0 19.3 19.9 21.5 2 3.1
S/T 0 .83 0 .74 0.56 0.36 0.86 0 .77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.61 0.40 0.94 0.84 0 .64 0.41 0.95 0.85 0.64 0 .41
Delta T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 1 7 12 21 19 16 11
75 800 KW 1 .6 0 1 .63 1.68 1.73 1.71 1.75 1 .80 1.86 1.82 1.86 1.92 1.98 1.91 1.95 2.02 2.08 1.99 2.03 2.1 0 2.17 2.06 2.10 2.17 2.25
AMPS 7.2 7.3 7.5 7.8 7.7 7.8 8.1 8.3 8.2 8.4 8.7 8.9 8.7 8.9 9.2 9.5 9.2 9.4 9.7 10.0 9.7 9.9 10.2 10.5
HI PR 225 242 256 267 253 272 287 299 287 309 326 341 327 352 372 388 368 396 418 436 407 438 462 482
LO P R 111 11 8 12 8 1 37 1 17 124 136 14 5 1 21 129 141 150 128 136 148 158 134 142 155 165 138 147 161 171
MBh 21.8 22.4 24.3 26.1 21.3 21.9 23.7 25.5 20.8 21.4 23.2 24.8 20.3 20.9 22.6 24 .2 19.3 19.8 2 1.5 23.0 17.8 18.4 19.9 2 1.3
S/T 0 .80 0 .71 0.54 0.35 0.83 0 .74 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0 .62 0.40 0.92 0.82 0.62 0 .40
Delta T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 18 12 23 21 1 7 12 21 20 16 11
700 K W 1 .5 6 1 .59 1.64 1.69 1.67 1.71 1 .7 6 1.82 1.78 1.81 1.87 1.93 1.87 1.91 1.97 2.03 1.94 1.98 2.0 5 2.12 2.01 2.05 2.12 2.19
AMPS 7.0 7.2 7.4 7.6 7.5 7.7 7.9 8.1 8.0 8.2 8.4 8.7 8.5 8.7 8.9 9.2 9.0 9.2 9.4 9.8 9.5 9.7 9.9 10.3
HI PR 218 235 248 259 245 264 278 290 279 300 317 330 317 342 361 376 357 384 406 423 395 425 448 468
LO P R 107 11 4 12 5 1 33 1 13 121 132 14 0 1 18 125 137 146 124 132 144 153 130 138 151 160 134 143 156 166
*EnteringIndoorDryBulbTemperature NOTE: ShadedareaisACCA(TVA)conditions KW=Totalsystempower
High and low pressures are measured at the liquid and suction access fittings. AMPS: Unit amps (comp.+ evaporator + condenser fan motors)

20
COOLING PERFORMANCE DATA 1ST S TAGE *PG1536***41A*
MODEL: *PG1536***41A* EXPANDED PERFORMANCE DATA COOLING OPERATION Design Subcooling, 15°F + 3 @ the l iqui d acc ess fi tt ing co nn ec ti on AHRI 95 t est c on di tion s. Design Superheat 9 ° F + 3 @ the compressor suction access fitting connection.
Outdoor Ambient Temperature
65 7 5 85 95 105 1 15
Ente ring Indo or Wet Bul b Te mpe rature
IDB* Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 24.7 25.3 27.0 28.9 24.2 24.7 26.4 28.2 23.6 24.1 25.8 27.5 23.0 23.5 25.1 26.9 21.9 22.3 23.9 25.5 20.3 20.7 22.1 23.6
S/T 0 .95 0 . 89 0.73 0.54 1.00 0.93 0.7 5 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1 .00 0 .83 0.62 1.00 1.00 0.83 0 .62
Delta T 24 23 20 16 25 23 20 16 24 23 20 16 24 24 20 16 22 23 20 16 21 21 19 15
900 KW 1 .62 1 .65 1.70 1.76 1.74 1.78 1.8 3 1.89 1.85 1.89 1.95 2.01 1.94 1.99 2.05 2.12 2.02 2.07 2.1 4 2.21 2.09 2.14 2.21 2 .28
AMPS 7.3 7.4 7.7 7.9 7.8 8.0 8.2 8.4 8.4 8.5 8.8 9.1 8.9 9.1 9.3 9.6 9.4 9.6 9.8 10.2 9.9 10.1 10.4 10.7
HI PR 230 247 261 272 258 277 293 305 293 315 333 347 334 359 379 396 376 404 427 445 415 447 472 492
LO P R 113 12 0 131 140 119 127 138 147 124 13 2 14 4 153 130 138 15 1 161 136 145 158 16 9 141 150 164 174
MBh 24.0 24.6 26.2 28.0 23.5 24.0 25.6 27.4 22.9 23.4 25.0 26.7 22.4 22.8 24.4 26.1 21.2 21.7 23.2 24.8 19.7 20.1 21.5 23.0
S/T 0 .91 0 . 85 0.69 0.52 0.94 0.88 0.7 2 0.54 0.96 0.90 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0 .79 0.59 1.00 0.98 0.80 0 .59
Delta T 25 24 21 17 25 24 21 17 25 24 21 17 26 25 21 17 24 24 21 17 23 23 20 16
80 800 KW 1 .61 1 .64 1.69 1.74 1.73 1.76 1.8 2 1.88 1.83 1.87 1.93 2.00 1.93 1.97 2.03 2.10 2.01 2.05 2.12 2.19 2.08 2.12 2.19 2.26
AMPS 7.2 7.4 7.6 7.8 7.7 7.9 8.1 8.4 8.3 8.5 8.7 9.0 8.8 9.0 9.2 9.5 9.3 9.5 9. 8 10.1 9.8 10.0 10 .3 10.6
HI PR 227 245 258 270 255 275 290 302 290 312 330 344 331 356 376 392 372 400 423 441 411 442 467 487
LO P R 112 11 9 13 0 1 38 1 18 126 137 14 6 1 23 130 142 152 129 137 150 159 135 144 157 167 140 149 162 173
MBh 22.2 22.7 24.2 25.9 21.7 22.1 23.6 25.3 21.1 21.6 23.1 24.7 20.6 21.1 22.5 24.1 19.6 20.0 21.4 22.9 18.2 18.6 19.8 21.2
S/T 0 .88 0 . 82 0.67 0.50 0.91 0.85 0.6 9 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0 .93 0 .76 0.57 1.00 0.94 0.77 0 .57
Delta T 25 24 21 17 26 25 22 17 26 25 22 17 26 25 22 17 26 25 21 17 24 23 20 16
700 KW 1 .57 1 .60 1.65 1.70 1.69 1.72 1.7 8 1.83 1.79 1.83 1.89 1.95 1.88 1.92 1.98 2.05 1.96 2.00 2.0 7 2.13 2.03 2.07 2.14 2 .21
AMPS 7.1 7.2 7.4 7.7 7.6 7.7 7.9 8.2 8.1 8.3 8.5 8.8 8.6 8.8 9.0 9.3 9.1 9.3 9.5 9.8 9.5 9.7 10.0 10.4
HI PR 221 237 251 261 248 266 281 293 282 303 320 334 321 345 364 380 361 388 410 428 399 429 453 472
LO P R 108 11 5 126 134 114 122 133 142 119 12 7 13 8 147 125 133 14 5 155 131 139 152 16 2 135 144 157 168
MBh 25.2 25.7 26.9 28.7 24.6 25.1 26.3 28.0 24.0 24.5 25.6 27.3 23.4 23.9 25.0 26.7 22.3 22.7 23.8 25.3 20.6 21.0 22.0 23.5
S/T 1 .00 0 . 96 0.87 0.70 1.00 1.00 0.9 0 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1 .00 0 .99 0.80 1.00 1.00 1.00 0 .81
Delta T 26 25 24 21 25 26 24 21 25 25 24 21 24 24 24 21 23 23 24 21 21 21 22 19
900 KW 1 .63 1 .67 1.72 1.77 1.76 1.79 1.8 5 1.91 1.86 1.90 1.96 2.03 1.96 2.00 2.07 2.13 2.04 2.09 2.1 5 2.22 2.11 2.16 2.23 2 .30
AMPS 7.4 7.5 7.7 8.0 7.9 8.0 8.2 8.5 8.4 8.6 8.9 9.2 8.9 9.1 9.4 9.7 9.4 9.6 9.9 10.3 9.9 10.1 10.5 10.8
HI PR 232 250 264 275 260 280 296 309 296 319 336 351 337 363 383 400 379 408 431 450 419 451 476 497
LO P R 114 12 1 132 141 120 128 140 149 125 13 3 14 5 155 131 140 15 3 163 138 147 160 17 0 142 152 165 176
MBh 24.4 24.9 26.1 27.8 23.9 24.3 25.5 27.2 23.3 23.8 24.9 26.5 22.7 23.2 24.3 25.9 21.6 22.0 23.1 24.6 20.0 20.4 21.4 22.8
S/T 0 .95 0 . 92 0.83 0.67 0.99 0.95 0.8 6 0.70 1.00 0.98 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1 .00 0 .94 0.77 1.00 1.00 0.95 0 .77
Delta T 27 26 25 22 27 27 25 22 27 27 25 22 26 27 25 22 25 25 25 22 23 23 23 20
85 800 KW 1 .62 1 .65 1.70 1.76 1.74 1.78 1.8 3 1.89 1.85 1.89 1.95 2.01 1.94 1.99 2.05 2.12 2.02 2.07 2.1 4 2.21 2.09 2.14 2.21 2 .28
AMPS 7.3 7.4 7.7 7.9 7.8 8.0 8.2 8.4 8.4 8.5 8.8 9.1 8.9 9.1 9.3 9.6 9.4 9.6 9.8 10.2 9.9 10.1 10.4 10.7
HI PR 230 247 261 272 258 277 293 305 293 315 333 347 334 359 379 396 376 404 427 445 415 447 472 492
LO P R 113 12 0 131 140 119 127 138 147 124 13 2 14 4 153 130 138 15 1 161 136 145 158 16 9 141 150 164 174
MBh 22.6 23.0 24.1 25.7 22.0 22.5 23.5 25.1 21.5 21.9 23.0 24.5 21.0 21.4 22.4 23.9 19.9 20.3 21.3 22.7 18.5 18.8 19.7 21.0
S/T 0 .92 0 . 89 0.80 0.65 0.95 0.92 0.8 3 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1 .00 0 .91 0.74 1.00 1.00 0.92 0 .74
Delta T 27 27 25 22 28 27 26 22 28 27 26 22 28 27 26 22 26 27 25 22 24 25 24 21
700 KW 1 .58 1 .61 1.66 1.72 1.70 1.74 1.7 9 1.85 1.80 1.84 1.90 1.96 1.90 1.94 2.00 2.06 1.97 2.02 2.0 8 2.15 2.04 2.09 2.15 2 .23
AMPS 7.1 7.3 7.5 7.7 7.6 7.8 8.0 8.2 8.2 8.3 8.6 8.9 8.7 8.8 9.1 9.4 9.1 9.3 9.6 9.9 9.6 9.8 10.1 10.5
HI PR 223 240 253 264 250 269 284 296 284 306 323 337 324 348 368 384 364 392 414 432 403 433 457 477
LO P R 109 11 6 127 135 116 123 134 143 120 12 8 14 0 149 126 134 14 7 156 132 141 154 16 4 137 146 159 169
*EnteringIndoorDryBulbTemperature NOTE: ShadedareaisAHRIRatingConditions KW=Totalsystempower
High and low pressures are measured at the liquid and suction access fitti ngs. AMPS: Unit amps (comp.+ evaporator + condenser fan motors)
