PRODUCT SPECIFICATIONS
SS-CKF50 www.goodmanmfg.com 11/07
Supersedes 6/07
50 HZ,
2- TO 6-TON
[10.6 KW TO 20.5 KW]
COOLING-ONLY
CONDENSING UNIT
This 50-Hz split system air conditioner allows for ground-level or rooftop applications and has been tested
for optimum performance by an independent third party.
Standard Features
Quiet-operating top discharge
Brass suction and liquid line shut-off valves
High-pressure manual reset control
Copper tube/aluminum fin coils
Factory-installed liquid line filter dryer
Contactor with lug connections
Ground lug connection
Sweat connections on all units
Totally enclosed, permanently lubricated condenser motor
designed for PSC operation
with internal thermal overload protection
Isolated compressor compartment
Energy-efficient compressor with internal
overload protection
Designed for use with A Series air handlers
CE Certified
•
•
•
•
•
•
•
•
•
•
•
•
•
CKF SERIES
NOMINAL CAPACITY:
24,600 TO 64,000 BTU/H
Cabinet Features
Unique Goodman®sound control design
Heavy-gauge, galvanized-steel cabinet properly reinforced
and braced
Steel louver coil guard
Attractive architectural gray powder-paint finish
with 500-hour salt spray approval
Removable access panels
Accessories
Cooling-only room thermostat (CT18-60)
Cooling/Heating room thermostat (CHT18-60)
Cooling/Heating digital thermostat (CHT18-60-HD)
Contents
Dimensions ..................................................................2
Performance Ratings ...................................................2
Product Specifications .................................................3
Expanded Cooling Data ...............................................4
Schematic Wiring Diagram........................................16
•
•
•
•
•
•
•
•

2 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
DIMENSIONS
PERFORMANCE RATINGS
Outdoor Unit Indoor Unit Cooling Capacity (BTU/h) dBs
Total Sensible EER¹ kWI²
CKF24-2* A24-00-2RA 24,000 16,800 9.0 2.66 76
CA*F1824*6* 24,600 17,400 9.0 2.73 76
CKF36-2* A36-00-2RA 33,000 23,400 9.0 3.67 76
CA*F3030*6* 34,000 24,200 9.0 3.78 76
CKF36-5* A36-00-2RA 33,000 23,400 9.0 3.67 76
CA*F3030*6* 34,000 24,200 9.0 3.78 76
CKF48-5* A48-00-2A 44,000 32,400 9.0 4.89 78
CA*F3636*6* 44,000 32,400 9.0 4.89 78
CKF60-5* A60-00-2R 55,000 37,800 9.0 6.11 78
CA*F3642*6* 55,000 37,800 9.0 6.11 78
CKF70-5*
A60-00-2R 61,000 41,500 9.0 6.78 80
CA*F4860*6* 62,000 42,000 9.0 6.89 80
A90-00-2R 64,000 43,500 9.0 7.11 80
¹ Energy Efficiency Ratio @ 80°F / 67°F / 95°F
² kWI = Compressor + Indoor Blower + Outdoor Fan Watts
Note:
When mix-matching outdoor and indoor units, the indoor unit check-flowrator must match the out-
door unit size.
•
Model Width Depth Height
CKF24-2* 26 26 29¾
CKF36-2* 26 26 29¾
CKF36-5* 26 26 29¾
CKF48-5* 29 29 29¾
CKF60-5* 29 29 32¼
CKF70-5* 29 29 38¼

SS-CKF50 www.goodmanmfg.com 3
P RODUCT S PECIFICATIONS
SPECIFICATIONS
CKF24-2* CKF36-2* CKF36-5* CKF48-5* CKF60-5* CKF70-5*
Capacities
Nominal Cooling (BTU/h) 24,600 34,000 34,000 44,000 55,000 64,000
EER¹ 9.0 9.0 9.0 9.0 9.0 9.0
Decibels 76 76 78 78 80 80
Compressor
RLA 12.5 17.9 5.3 7.4 9 10.9
LRA 61 97.4 42 50 74 101
Volts 220-240 220-240 380-420 380-420 380-420 380-420
Condenser Fan Motor
Horsepower 1/4 1/4 1/4 1/4 1/4 1/3
FLA 0.9 0.9 0.8 0.8 0.8 1.2
Volts 220-240 220-240 380 380 380 380
Refrigeration System
Liquid Valve Size (“O.D.) 3/8 3/8 3/8 3/8 3/8 3/8
Suction Valve Size (“O.D.) 3/4 3/4 7/8 7/8 7/8 7/8
Valve Type Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge 88 89 89 113 121 153
Shipped with Orifice Size 0.059 0.068 0.068 0.078 0.093 0.096
Condenser Fan / Coil
Horsepower - RPM 1/4-950 1/4-950 1/4-950 1/4-950 1/4-950 1/3-1075
Fan Diameter/ # Fan Blades 20/3 20/3 20/3 22/3 22/3 22/3
Outdoor Nominal CFM 1800 1800 1800 2400 2600 3200
Face Area (ft²) 13.3 13.3 13.3 15.6 17.1 20
Rows Deep/ Fins per Inch 1/19 1/19 1/19 1/19 1/19 1/22
Fin Type Ripple Ripple Ripple Ripple Ripple Ripple
Coil No. of Tubes 22 22 22 22 24 36
Coil Tube Diameter (in.) 0.375 0.375 0.375 0.375 0.375 0.375
Electrical Data
Voltage-Hz / Phase 220/240-50/1 220/240-50/1 380/415-50/3 380/415-50/3 380/415-50/3 380/415-50/3
Min. Circuit Ampacity² 16.6 23.3 7.5 10 12 14.8
Max. Overcurrent Protection (amps)³ 25 40 15 15 20 20
Min / Max Volts 198/264 198/264 342/456 342/456 342/456 342/456
Power Supply Conduit Size 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Ship Weight (lbs-[kg]) 180 (82) 184 (84) 184 (84) 191 (87) 210 (95) 228 (104)
¹ Energy Efficiency Ratio
² Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
³ Must use time-delay fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.

4 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
821
MBh 59.8 62.0 67.9 - 58.4 60.5 66.3 - 57.0 59.1 64.7 - 55.6 57.6 63.1 - 52.8 54.8 60.0 - 48.9 50.7 55.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆T 20 [-7] 18 [5] 13 [6] - 20 [-7] 18 [6] 13 [6] - 20 [-7] 18 [6] 13 [6] - 21 [-7] 18 [2] 14 [2] - 20 [-7] 18 [7] 13 [7] - 19 [-7] 16 [7] 12 [7] -
kW 5.26 5.37 5.54 - 5.67 5.80 5.99 - 6.04 6.17 6.38 - 6.36 6.50 6.72 - 6.63 6.78 7.01 - 6.87 7.03 7.27 -
Amps 11.1 11.3 11.6 - 11.8 12.0 12.3 - 12.6 12.9 13.2 - 13.3 13.6 14.0 - 14.1 14.3 14.7 - 14.8 15.1 15.5 -
Hi PR 169 182 192 - 190 204 215 - 216 232 245 - 246 264 279 - 276 297 314 - 305 329 347 -
Lo PR 52 55 60 - 55 58 63 - 57 60 66 - 60 63 69 - 63 67 73 - 65 69 75 -
730
MBh 58.0 60.2 65.9 - 56.7 58.8 64.4 - 55.3 57.4 62.8 - 54.0 56.0 61.3 - 51.3 53.2 58.2 - 47.5 49.2 53.9 -
S/T 0.65 0.54 0.38 - 0.68 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.62 0.43 -
∆T 21 [-6] 18 [5] 14 [5] - 21 [-6] 18 [6] 14 [6] - 21 [-6] 18 [6] 14 [6] - 21 [-7] 19 [2] 14 [2] - 21 [-6] 18 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.21 5.33 5.50 - 5.62 5.75 5.94 - 5.99 6.12 6.32 - 6.31 6.45 6.66 - 6.58 6.73 6.95 - 6.81 6.97 7.20 -
Amps 11.0 11.2 11.5 - 11.7 11.9 12.3 - 12.5 12.8 13.1 - 13.2 13.5 13.9 - 13.9 14.2 14.6 - 14.6 14.9 15.4 -
Hi PR 167 180 190 - 188 202 213 - 214 230 243 - 243 262 276 - 274 294 311 - 302 325 344 -
Lo PR 51 54 59 - 54 58 63 - 56 60 65 - 59 63 69 - 62 66 72 - 64 68 74 -
639
MBh 53.6 55.5 60.8 - 52.3 54.2 59.4 - 51.1 52.9 58.0 - 49.8 51.6 56.6 - 47.3 49.1 53.8 - 43.8 45.4 49.8 -
S/T 0.63 0.52 0.36 - 0.65 0.54 0.38 - 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.72 0.60 0.42 -
∆T 21 [-6] 19 [5] 14 [5] - 22 [-6] 19 [6] 14 [6] - 22 [-6] 19 [6] 14 [6] - 22 [-7] 19 [2] 14 [2] - 22 [-6] 19 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.09 5.20 5.36 - 5.48 5.61 5.79 - 5.84 5.97 6.16 - 6.15 6.28 6.49 - 6.41 6.55 6.77 - 6.64 6.79 7.02 -
Amps 10.8 11.0 11.2 - 11.4 11.7 12.0 - 12.2 12.5 12.8 - 12.9 13.2 13.6 - 13.6 13.9 14.3 - 14.3 14.6 15.0 -
Hi PR 162 175 184 - 182 196 207 - 207 223 235 - 236 254 268 - 265 286 302 - 293 316 333 -
Lo PR 50 53 58 - 52 56 61 - 55 58 63 - 57 61 67 - 60 64 70 - 62 66 72 -
75
821
MBh 60.8 62.6 67.7 72.7 59.4 61.1 66.2 71.0 58.0 59.7 64.6 69.3 56.5 58.2 63.0 67.6 53.7 55.3 59.9 64.3 49.8 51.2 55.5 59.5
S/T 0.78 0.69 0.53 0.3 0.80 0.72 0.54 0.4 0.83 0.74 0.56 0.4 0.85 0.76 0.58 0.4 0.88 0.79 0.60 0.4 0.89 0.80 0.60 0.4
∆T 23 [-5] 22 [5] 18 [6] 12 [-
11] 24 [-4] 22 [6] 18 [6] 12 [6] 24 [-4] 22 [6] 18 [6] 12 [7] 24 [-7] 22 [2] 18 [2] 12 [-] 24 [-4] 22 [7] 18 [7] 12 [7] 22 [-6] 20 [7] 17 [7] 11 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.84 6.04 6.2 6.09 6.22 6.43 6.6 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.5 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.3 192 206 218 227.0 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 350 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.5 63 67 73 78.1 65 69 76 80.8
730
MBh 59.0 60.8 65.8 70.6 57.6 59.4 64.2 68.9 56.3 57.9 62.7 67.3 54.9 56.5 61.2 65.7 52.2 53.7 58.1 62.4 48.3 49.7 53.8 57.8
S/T 0.74 0.66 0.50 0.3 0.77 0.69 0.52 0.3 0.79 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.85 0.76 0.58 0.4
∆T 24 [-4] 22 [5] 18 [6] 13 [-
11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4] 23 [6] 19 [6] 13 [7] 25 [-7] 23 [2] 19 [2] 13 [-] 24 [-4] 23 [7] 18 [7] 13 [7] 23 [-5] 21 [7] 17 [7] 12 [8]
kW 5.26 5.37 5.54 5.7 5.67 5.80 5.99 6.2 6.04 6.17 6.38 6.6 6.36 6.50 6.72 7.0 6.63 6.79 7.01 7.3 6.87 7.03 7.27 7.5
Amps 11.1 11.3 11.6 11.9 11.8 12.0 12.3 12.7 12.6 12.9 13.2 13.6 13.3 13.6 14.0 14.4 14.1 14.3 14.8 15.2 14.8 15.1 15.5 16.0
Hi PR 169 182 192 200.3 190 204 216 224.8 216 232 245 255.7 246 264 279 291.2 276 297 314 327.6 305 329 347 361.9
Lo PR 52 55 60 64.0 55 58 63 67.6 57 60 66 70.3 60 63 69 73.8 63 67 73 77.3 65 69 75 80.0
639
MBh 54.5 56.1 60.7 65.2 53.2 54.8 59.3 63.6 51.9 53.5 57.9 62.1 50.7 52.2 56.5 60.6 48.1 49.6 53.6 57.6 44.6 45.9 49.7 53.3
S/T 0.71 0.64 0.48 0.3 0.74 0.66 0.50 0.3 0.76 0.68 0.51 0.3 0.78 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.82 0.73 0.55 0.4
∆T 25 [-4] 23 [5] 19 [5] 13 [-
11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-7] 23 [2] 19 [2] 13 [-] 25 [-4] 23 [7] 19 [7] 13 [7] 23 [-5] 21 [7] 18 [7] 12 [7]
kW 5.13 5.24 5.41 5.6 5.53 5.65 5.84 6.0 5.89 6.02 6.22 6.4 6.20 6.34 6.55 6.8 6.47 6.61 6.83 7.1 6.69 6.85 7.08 7.3
Amps 10.8 11.0 11.3 11.7 11.5 11.8 12.1 12.4 12.3 12.6 12.9 13.3 13.0 13.3 13.7 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.1 15.6
Hi PR 164 176 186 194.3 184 198 209 218.1 209 225 238 248.0 238 256 271 282.4 268 289 305 317.8 296 319 337 351.1
Lo PR 50 53 58 62.1 53 56 62 65.6 55 59 64 68.2 58 62 67 71.6 61 65 70 75.0 63 67 73 77.6
Shaded area reflects ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents
EXPANDED COOLING DATA — CKF24-2* / A24-00-2RA

SS-CKF50 www.goodmanmfg.com 5
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF24-2* / A24-00-2RA (CONT.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
821
MBh 61.9 63.2 67.5 72.2 60.4 61.7 66.0 70.5 59.0 60.3 64.4 68.8 57.6 58.8 62.8 67.2 54.7 55.9 59.7 63.8 50.6 51.8 55.3 59.1
S/T 0.85 0.80 0.65 0.5 0.88 0.83 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.97 0.91 0.74 0.6 1.00 0.92 0.75 0.6
∆T 26 [-3] 25 [5] 22 [6] 17 [-8]26 [-3] 25 [6] 22 [6] 18 [6] 26 [-3] 25 [6] 22 [6] 18 [7] 27 [-7] 26 [2] 22 [2] 18 [-] 26 [-3] 25 [7] 22 [7] 17 [7] 25 [-4] 24 [7] 20 [7] 16 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
730
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5
∆T 27 [-3] 26 [5] 23 [6] 18 [-8]28 [-2] 26 [6] 23 [6] 18 [6] 28 [-2] 26 [6] 23 [6] 18 [7] 28 [-7] 27 [2] 23 [2] 18 [-] 27 [-3] 26 [7] 23 [7] 18 [7] 26 [-3] 24 [7] 21 [7] 17 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.85 6.04 6.2 6.09 6.22 6.43 6.7 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8
639
MBh 55.4 56.7 60.5 64.7 54.2 55.3 59.1 63.2 52.9 54.0 57.7 61.7 51.6 52.7 56.3 60.2 49.0 50.1 53.5 57.2 45.4 46.4 49.5 53.0
S/T 0.78 0.73 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.90 0.84 0.69 0.5
∆T 252421172625211726252117262522172524211724232016
kW 5.17 5.28 0.80 5.6 5.58 5.70 5.89 6.1 5.94 6.07 6.27 6.5 6.25 6.39 6.61 6.8 6.52 6.67 6.89 7.1 6.75 6.91 7.14 7.4
Amps 10.9 11.1 11.4 11.8 11.6 11.8 12.2 12.5 12.4 12.7 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.3 15.8
Hi PR 166 178 188 196.3 186 200 211 220.3 211 227 240 250.5 241 259 274 285.3 271 291 308 321.0 299 322 340 354.6
Lo PR 51 54 59 62.7 54 57 62 66.2 56 59 65 68.8 58 62 68 72.3 61 65 71 75.8 63 67 74 78.4
85
821
MBh 62.9 64.2 67.2 71.7 61.5 62.7 65.6 70.0 60.0 61.2 64.1 68.4 58.6 59.7 62.5 66.7 55.6 56.7 59.4 63.4 51.5 52.5 55.0 58.7
S/T 0.89 0.86 0.78 0.6 0.93 0.89 0.81 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.89 0.7
∆T 28 [-2] 27 [6] 26 [6] 22 [-6]28 [-2] 28 [6] 26 [6] 23 [6] 28 [-2] 28 [6] 26 [7] 23 [7] 28 [-7] 28 [2] 26 [2] 23 [-] 28 [-2] 28 [7] 26 [7] 23 [7] 26 [-3] 26 [7] 24 [7] 21 [8]
kW 5.39 5.50 5.68 5.9 5.81 5.94 6.14 6.3 6.19 6.33 6.54 6.8 6.52 6.67 6.90 7.1 6.81 6.96 7.20 7.4 7.05 7.21 7.46 7.7
Amps 11.3 11.5 11.8 12.2 12.1 12.3 12.6 13.0 12.9 13.2 13.5 14.0 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.6 15.1 15.4 15.9 16.4
Hi PR 174 187 198 206.4 195 210 222 231.6 222 239 253 263.4 253 272 288 300.0 285 306 324 337.5 315 339 358 372.9
Lo PR 53 57 62 65.9 56 60 65 69.7 59 62 68 72.4 61 65 71 76.0 64 69 75 79.7 67 71 77 82.4
730
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7
∆T 29 [-2] 29 [5] 27 [6] 23 [-5]29 [-2] 29 [6] 27 [6] 24 [6] 29 [-2] 29 [6] 27 [6] 24 [7] 30 [-7] 29 [2] 28 [2] 24 [-] 29 [-2] 29 [7] 27 [7] 23 [7] 27 [-3] 27 [7] 25 [7] 22 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
639
MBh 56.4 57.5 60.2 64.2 55.1 56.2 58.8 62.8 53.8 54.8 57.4 61.3 52.5 53.5 56.0 59.8 49.9 50.8 53.2 56.8 46.2 47.1 49.3 52.6
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.76 0.6 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.91 0.82 0.7
∆T 29 [-2] 29 [5] 27 [5] 24 [-4]30 [-1] 29 [6] 28 [6] 24 [6] 30 [-1] 29 [6] 28 [6] 24 [7] 30 [-7] 30 [2] 28 [2] 24 [-] 30 [-1] 29 [7] 28 [7] 24 [7] 28 [-2] 27 [7] 26 [7] 22 [7]
kW 5.21 5.33 5.50 5.7 5.62 5.75 5.93 6.1 5.98 6.12 6.32 6.5 6.30 6.45 6.66 6.9 6.58 6.73 6.95 7.2 6.81 6.97 7.20 7.5
Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9
Hi PR 167 180 190 198.3 188 202 213 222.5 213 230 243 253.0 243 262 276 288.2 274 294 311 324.2 302 325 343 358.2
Lo PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.5 59 63 69 73.0 62 66 72 76.5 64 68 74 79.2
Shaded area reflects ARI conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

6 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF36-2* / A36-00-2
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
821
MBh 59.8 62.0 67.9 - 58.4 60.5 66.3 - 57.0 59.1 64.7 - 55.6 57.6 63.1 - 52.8 54.8 60.0 - 48.9 50.7 55.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆T 20 [-7] 18 [5] 13 [6] - 20 [-7] 18 [6] 13 [6] - 20 [-7] 18 [6] 13 [6] - 21 [-7] 18 [2] 14 [2] - 20 [-7] 18 [7] 13 [7] - 19 [-7] 16 [7] 12 [7] -
kW 5.26 5.37 5.54 - 5.67 5.80 5.99 - 6.04 6.17 6.38 - 6.36 6.50 6.72 - 6.63 6.78 7.01 - 6.87 7.03 7.27 -
Amps 11.1 11.3 11.6 - 11.8 12.0 12.3 - 12.6 12.9 13.2 - 13.3 13.6 14.0 - 14.1 14.3 14.7 - 14.8 15.1 15.5 -
Hi PR 169 182 192 - 190 204 215 - 216 232 245 - 246 264 279 - 276 297 314 - 305 329 347 -
Lo PR 52 55 60 - 55 58 63 - 57 60 66 - 60 63 69 - 63 67 73 - 65 69 75 -
730
MBh 58.0 60.2 65.9 - 56.7 58.8 64.4 - 55.3 57.4 62.8 - 54.0 56.0 61.3 - 51.3 53.2 58.2 - 47.5 49.2 53.9 -
S/T 0.65 0.54 0.38 - 0.68 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.62 0.43 -
∆T 21 [-6] 18 [5] 14 [5] - 21 [-6] 18 [6] 14 [6] - 21 [-6] 18 [6] 14 [6] - 21 [-7] 19 [2] 14 [2] - 21 [-6] 18 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.21 5.33 5.50 - 5.62 5.75 5.94 - 5.99 6.12 6.32 - 6.31 6.45 6.66 - 6.58 6.73 6.95 - 6.81 6.97 7.20 -
Amps 11.0 11.2 11.5 - 11.7 11.9 12.3 - 12.5 12.8 13.1 - 13.2 13.5 13.9 - 13.9 14.2 14.6 - 14.6 14.9 15.4 -
Hi PR 167 180 190 - 188 202 213 - 214 230 243 - 243 262 276 - 274 294 311 - 302 325 344 -
Lo PR 51 54 59 - 54 58 63 - 56 60 65 - 59 63 69 - 62 66 72 - 64 68 74 -
639
MBh 53.6 55.5 60.8 - 52.3 54.2 59.4 - 51.1 52.9 58.0 - 49.8 51.6 56.6 - 47.3 49.1 53.8 - 43.8 45.4 49.8 -
S/T 0.63 0.52 0.36 - 0.65 0.54 0.38 - 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.72 0.60 0.42 -
∆T 21 [-6] 19 [5] 14 [5] - 22 [-6] 19 [6] 14 [6] - 22 [-6] 19 [6] 14 [6] - 22 [-7] 19 [2] 14 [2] - 22 [-6] 19 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.09 5.20 5.36 - 5.48 5.61 5.79 - 5.84 5.97 6.16 - 6.15 6.28 6.49 - 6.41 6.55 6.77 - 6.64 6.79 7.02 -
Amps 10.8 11.0 11.2 - 11.4 11.7 12.0 - 12.2 12.5 12.8 - 12.9 13.2 13.6 - 13.6 13.9 14.3 - 14.3 14.6 15.0 -
Hi PR 162 175 184 - 182 196 207 - 207 223 235 - 236 254 268 - 265 286 302 - 293 316 333 -
Lo PR 50 53 58 - 52 56 61 - 55 58 63 - 57 61 67 - 60 64 70 - 62 66 72 -
75
821
MBh 60.8 62.6 67.7 72.7 59.4 61.1 66.2 71.0 58.0 59.7 64.6 69.3 56.5 58.2 63.0 67.6 53.7 55.3 59.9 64.3 49.8 51.2 55.5 59.5
S/T 0.78 0.69 0.53 0.3 0.80 0.72 0.54 0.4 0.83 0.74 0.56 0.4 0.85 0.76 0.58 0.4 0.88 0.79 0.60 0.4 0.89 0.80 0.60 0.4
∆T23 [-5] 22 [5] 18 [6] 12 [-11] 24 [-4] 22 [6] 18 [6] 12 [6] 24 [-4] 22 [6] 18 [6] 12 [7] 24 [-7] 22 [2] 18 [2] 12 [-] 24 [-4] 22 [7] 18 [7] 12 [7] 22 [-6] 20 [7] 17 [7] 11 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.84 6.04 6.2 6.09 6.22 6.43 6.6 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.5 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.3 192 206 218 227.0 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 350 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.5 63 67 73 78.1 65 69 76 80.8
730
MBh 59.0 60.8 65.8 70.6 57.6 59.4 64.2 68.9 56.3 57.9 62.7 67.3 54.9 56.5 61.2 65.7 52.2 53.7 58.1 62.4 48.3 49.7 53.8 57.8
S/T 0.74 0.66 0.50 0.3 0.77 0.69 0.52 0.3 0.79 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.85 0.76 0.58 0.4
∆T24 [-4] 22 [5] 18 [6] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4] 23 [6] 19 [6] 13 [7] 25 [-7] 23 [2] 19 [2] 13 [-] 24 [-4] 23 [7] 18 [7] 13 [7] 23 [-5] 21 [7] 17 [7] 12 [8]
kW 5.26 5.37 5.54 5.7 5.67 5.80 5.99 6.2 6.04 6.17 6.38 6.6 6.36 6.50 6.72 7.0 6.63 6.79 7.01 7.3 6.87 7.03 7.27 7.5
Amps 11.1 11.3 11.6 11.9 11.8 12.0 12.3 12.7 12.6 12.9 13.2 13.6 13.3 13.6 14.0 14.4 14.1 14.3 14.8 15.2 14.8 15.1 15.5 16.0
Hi PR 169 182 192 200.3 190 204 216 224.8 216 232 245 255.7 246 264 279 291.2 276 297 314 327.6 305 329 347 361.9
Lo PR 52 55 60 64.0 55 58 63 67.6 57 60 66 70.3 60 63 69 73.8 63 67 73 77.3 65 69 75 80.0
639
MBh 54.5 56.1 60.7 65.2 53.2 54.8 59.3 63.6 51.9 53.5 57.9 62.1 50.7 52.2 56.5 60.6 48.1 49.6 53.6 57.6 44.6 45.9 49.7 53.3
S/T 0.71 0.64 0.48 0.3 0.74 0.66 0.50 0.3 0.76 0.68 0.51 0.3 0.78 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.82 0.73 0.55 0.4
∆T25 [-4] 23 [5] 19 [5] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-7] 23 [2] 19 [2] 13 [-] 25 [-4] 23 [7] 19 [7] 13 [7] 23 [-5] 21 [7] 18 [7] 12 [7]
kW 5.13 5.24 5.41 5.6 5.53 5.65 5.84 6.0 5.89 6.02 6.22 6.4 6.20 6.34 6.55 6.8 6.47 6.61 6.83 7.1 6.69 6.85 7.08 7.3
Amps 10.8 11.0 11.3 11.7 11.5 11.8 12.1 12.4 12.3 12.6 12.9 13.3 13.0 13.3 13.7 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.1 15.6
Hi PR 164 176 186 194.3 184 198 209 218.1 209 225 238 248.0 238 256 271 282.4 268 289 305 317.8 296 319 337 351.1
Lo PR 50 53 58 62.1 53 56 62 65.6 55 59 64 68.2 58 62 67 71.6 61 65 70 75.0 63 67 73 77.6
Shaded area reflects ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

SS-CKF50 www.goodmanmfg.com 7
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF36-2* / A36-00-2 (CONT.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
821
MBh 61.9 63.2 67.5 72.2 60.4 61.7 66.0 70.5 59.0 60.3 64.4 68.8 57.6 58.8 62.8 67.2 54.7 55.9 59.7 63.8 50.6 51.8 55.3 59.1
S/T 0.85 0.80 0.65 0.5 0.88 0.83 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.97 0.91 0.74 0.6 1.00 0.92 0.75 0.6
∆T 26 [-3] 25 [5] 22 [6] 17 [-8]26 [-3] 25 [6] 22 [6] 18 [6] 26 [-3] 25 [6] 22 [6] 18 [7] 27 [-7] 26 [2] 22 [2] 18 [-] 26 [-3] 25 [7] 22 [7] 17 [7] 25 [-4] 24 [7] 20 [7] 16 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
730
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5
∆T 27 [-3] 26 [5] 23 [6] 18 [-8]28 [-2] 26 [6] 23 [6] 18 [6] 28 [-2] 26 [6] 23 [6] 18 [7] 28 [-7] 27 [2] 23 [2] 18 [-] 27 [-3] 26 [7] 23 [7] 18 [7] 26 [-3] 24 [7] 21 [7] 17 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.85 6.04 6.2 6.09 6.22 6.43 6.7 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8
639
MBh 55.4 56.7 60.5 64.7 54.2 55.3 59.1 63.2 52.9 54.0 57.7 61.7 51.6 52.7 56.3 60.2 49.0 50.1 53.5 57.2 45.4 46.4 49.5 53.0
S/T 0.78 0.73 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.90 0.84 0.69 0.5
∆T 252421172625211726252117262522172524211724232016
kW 5.17 5.28 0.80 5.6 5.58 5.70 5.89 6.1 5.94 6.07 6.27 6.5 6.25 6.39 6.61 6.8 6.52 6.67 6.89 7.1 6.75 6.91 7.14 7.4
Amps 10.9 11.1 11.4 11.8 11.6 11.8 12.2 12.5 12.4 12.7 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.3 15.8
Hi PR 166 178 188 196.3 186 200 211 220.3 211 227 240 250.5 241 259 274 285.3 271 291 308 321.0 299 322 340 354.6
Lo PR 51 54 59 62.7 54 57 62 66.2 56 59 65 68.8 58 62 68 72.3 61 65 71 75.8 63 67 74 78.4
85
821
MBh 62.9 64.2 67.2 71.7 61.5 62.7 65.6 70.0 60.0 61.2 64.1 68.4 58.6 59.7 62.5 66.7 55.6 56.7 59.4 63.4 51.5 52.5 55.0 58.7
S/T 0.89 0.86 0.78 0.6 0.93 0.89 0.81 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.89 0.7
∆T 28 [-2] 27 [6] 26 [6] 22 [-6]28 [-2] 28 [6] 26 [6] 23 [6] 28 [-2] 28 [6] 26 [7] 23 [7] 28 [-7] 28 [2] 26 [2] 23 [-] 28 [-2] 28 [7] 26 [7] 23 [7] 26 [-3] 26 [7] 24 [7] 21 [8]
kW 5.39 5.50 5.68 5.9 5.81 5.94 6.14 6.3 6.19 6.33 6.54 6.8 6.52 6.67 6.90 7.1 6.81 6.96 7.20 7.4 7.05 7.21 7.46 7.7
Amps 11.3 11.5 11.8 12.2 12.1 12.3 12.6 13.0 12.9 13.2 13.5 14.0 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.6 15.1 15.4 15.9 16.4
Hi PR 174 187 198 206.4 195 210 222 231.6 222 239 253 263.4 253 272 288 300.0 285 306 324 337.5 315 339 358 372.9
Lo PR 53 57 62 65.9 56 60 65 69.7 59 62 68 72.4 61 65 71 76.0 64 69 75 79.7 67 71 77 82.4
730
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7
∆T 29 [-2] 29 [5] 27 [6] 23 [-5]29 [-2] 29 [6] 27 [6] 24 [6] 29 [-2] 29 [6] 27 [6] 24 [7] 30 [-7] 29 [2] 28 [2] 24 [-] 29 [-2] 29 [7] 27 [7] 23 [7] 27 [-3] 27 [7] 25 [7] 22 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
639
MBh 56.4 57.5 60.2 64.2 55.1 56.2 58.8 62.8 53.8 54.8 57.4 61.3 52.5 53.5 56.0 59.8 49.9 50.8 53.2 56.8 46.2 47.1 49.3 52.6
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.76 0.6 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.91 0.82 0.7
∆T 29 [-2] 29 [5] 27 [5] 24 [-4]30 [-1] 29 [6] 28 [6] 24 [6] 30 [-1] 29 [6] 28 [6] 24 [7] 30 [-7] 30 [2] 28 [2] 24 [-] 30 [-1] 29 [7] 28 [7] 24 [7] 28 [-2] 27 [7] 26 [7] 22 [7]
kW 5.21 5.33 5.50 5.7 5.62 5.75 5.93 6.1 5.98 6.12 6.32 6.5 6.30 6.45 6.66 6.9 6.58 6.73 6.95 7.2 6.81 6.97 7.20 7.5
Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9
Hi PR 167 180 190 198.3 188 202 213 222.5 213 230 243 253.0 243 262 276 288.2 274 294 311 324.2 302 325 343 358.2
Lo PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.5 59 63 69 73.0 62 66 72 76.5 64 68 74 79.2
Shaded area reflects ARI conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

8 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF36-5* / AR36-00-2
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
821
MBh 59.8 62.0 67.9 - 58.4 60.5 66.3 - 57.0 59.1 64.7 - 55.6 57.6 63.1 - 52.8 54.8 60.0 - 48.9 50.7 55.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆T 20 [-7] 18 [5] 13 [6] - 20 [-7] 18 [6] 13 [6] - 20 [-7] 18 [6] 13 [6] - 21 [-7] 18 [2] 14 [2] - 20 [-7] 18 [7] 13 [7] - 19 [-7] 16 [7] 12 [7] -
kW 5.26 5.37 5.54 - 5.67 5.80 5.99 - 6.04 6.17 6.38 - 6.36 6.50 6.72 - 6.63 6.78 7.01 - 6.87 7.03 7.27 -
Amps 11.1 11.3 11.6 - 11.8 12.0 12.3 - 12.6 12.9 13.2 - 13.3 13.6 14.0 - 14.1 14.3 14.7 - 14.8 15.1 15.5 -
Hi PR 169 182 192 - 190 204 215 - 216 232 245 - 246 264 279 - 276 297 314 - 305 329 347 -
Lo PR 52 55 60 - 55 58 63 - 57 60 66 - 60 63 69 - 63 67 73 - 65 69 75 -
730
MBh 58.0 60.2 65.9 - 56.7 58.8 64.4 - 55.3 57.4 62.8 - 54.0 56.0 61.3 - 51.3 53.2 58.2 - 47.5 49.2 53.9 -
S/T 0.65 0.54 0.38 - 0.68 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.62 0.43 -
∆T 21 [-6] 18 [5] 14 [5] - 21 [-6] 18 [6] 14 [6] - 21 [-6] 18 [6] 14 [6] - 21 [-7] 19 [2] 14 [2] - 21 [-6] 18 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.21 5.33 5.50 - 5.62 5.75 5.94 - 5.99 6.12 6.32 - 6.31 6.45 6.66 - 6.58 6.73 6.95 - 6.81 6.97 7.20 -
Amps 11.0 11.2 11.5 - 11.7 11.9 12.3 - 12.5 12.8 13.1 - 13.2 13.5 13.9 - 13.9 14.2 14.6 - 14.6 14.9 15.4 -
Hi PR 167 180 190 - 188 202 213 - 214 230 243 - 243 262 276 - 274 294 311 - 302 325 344 -
Lo PR 51 54 59 - 54 58 63 - 56 60 65 - 59 63 69 - 62 66 72 - 64 68 74 -
639
MBh 53.6 55.5 60.8 - 52.3 54.2 59.4 - 51.1 52.9 58.0 - 49.8 51.6 56.6 - 47.3 49.1 53.8 - 43.8 45.4 49.8 -
S/T 0.63 0.52 0.36 - 0.65 0.54 0.38 - 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.72 0.60 0.42 -
∆T 21 [-6] 19 [5] 14 [5] - 22 [-6] 19 [6] 14 [6] - 22 [-6] 19 [6] 14 [6] - 22 [-7] 19 [2] 14 [2] - 22 [-6] 19 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.09 5.20 5.36 - 5.48 5.61 5.79 - 5.84 5.97 6.16 - 6.15 6.28 6.49 - 6.41 6.55 6.77 - 6.64 6.79 7.02 -
Amps 10.8 11.0 11.2 - 11.4 11.7 12.0 - 12.2 12.5 12.8 - 12.9 13.2 13.6 - 13.6 13.9 14.3 - 14.3 14.6 15.0 -
Hi PR 162 175 184 - 182 196 207 - 207 223 235 - 236 254 268 - 265 286 302 - 293 316 333 -
Lo PR 50 53 58 - 52 56 61 - 55 58 63 - 57 61 67 - 60 64 70 - 62 66 72 -
75
821
MBh 60.8 62.6 67.7 72.7 59.4 61.1 66.2 71.0 58.0 59.7 64.6 69.3 56.5 58.2 63.0 67.6 53.7 55.3 59.9 64.3 49.8 51.2 55.5 59.5
S/T 0.78 0.69 0.53 0.3 0.80 0.72 0.54 0.4 0.83 0.74 0.56 0.4 0.85 0.76 0.58 0.4 0.88 0.79 0.60 0.4 0.89 0.80 0.60 0.4
∆T23 [-5] 22 [5] 18 [6] 12 [-11] 24 [-4] 22 [6] 18 [6] 12 [6] 24 [-4] 22 [6] 18 [6] 12 [7] 24 [-7] 22 [2] 18 [2] 12 [-] 24 [-4] 22 [7] 18 [7] 12 [7] 22 [-6] 20 [7] 17 [7] 11 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.84 6.04 6.2 6.09 6.22 6.43 6.6 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.5 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.3 192 206 218 227.0 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 350 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.5 63 67 73 78.1 65 69 76 80.8
730
MBh 59.0 60.8 65.8 70.6 57.6 59.4 64.2 68.9 56.3 57.9 62.7 67.3 54.9 56.5 61.2 65.7 52.2 53.7 58.1 62.4 48.3 49.7 53.8 57.8
S/T 0.74 0.66 0.50 0.3 0.77 0.69 0.52 0.3 0.79 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.85 0.76 0.58 0.4
∆T24 [-4] 22 [5] 18 [6] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4] 23 [6] 19 [6] 13 [7] 25 [-7] 23 [2] 19 [2] 13 [-] 24 [-4] 23 [7] 18 [7] 13 [7] 23 [-5] 21 [7] 17 [7] 12 [8]
kW 5.26 5.37 5.54 5.7 5.67 5.80 5.99 6.2 6.04 6.17 6.38 6.6 6.36 6.50 6.72 7.0 6.63 6.79 7.01 7.3 6.87 7.03 7.27 7.5
Amps 11.1 11.3 11.6 11.9 11.8 12.0 12.3 12.7 12.6 12.9 13.2 13.6 13.3 13.6 14.0 14.4 14.1 14.3 14.8 15.2 14.8 15.1 15.5 16.0
Hi PR 169 182 192 200.3 190 204 216 224.8 216 232 245 255.7 246 264 279 291.2 276 297 314 327.6 305 329 347 361.9
Lo PR 52 55 60 64.0 55 58 63 67.6 57 60 66 70.3 60 63 69 73.8 63 67 73 77.3 65 69 75 80.0
639
MBh 54.5 56.1 60.7 65.2 53.2 54.8 59.3 63.6 51.9 53.5 57.9 62.1 50.7 52.2 56.5 60.6 48.1 49.6 53.6 57.6 44.6 45.9 49.7 53.3
S/T 0.71 0.64 0.48 0.3 0.74 0.66 0.50 0.3 0.76 0.68 0.51 0.3 0.78 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.82 0.73 0.55 0.4
∆T25 [-4] 23 [5] 19 [5] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-7] 23 [2] 19 [2] 13 [-] 25 [-4] 23 [7] 19 [7] 13 [7] 23 [-5] 21 [7] 18 [7] 12 [7]
kW 5.13 5.24 5.41 5.6 5.53 5.65 5.84 6.0 5.89 6.02 6.22 6.4 6.20 6.34 6.55 6.8 6.47 6.61 6.83 7.1 6.69 6.85 7.08 7.3
Amps 10.8 11.0 11.3 11.7 11.5 11.8 12.1 12.4 12.3 12.6 12.9 13.3 13.0 13.3 13.7 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.1 15.6
Hi PR 164 176 186 194.3 184 198 209 218.1 209 225 238 248.0 238 256 271 282.4 268 289 305 317.8 296 319 337 351.1
Lo PR 50 53 58 62.1 53 56 62 65.6 55 59 64 68.2 58 62 67 71.6 61 65 70 75.0 63 67 73 77.6
Shaded area reflects ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

SS-CKF50 www.goodmanmfg.com 9
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF36-5* / AR36-00-2 (CONT.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
821
MBh 61.9 63.2 67.5 72.2 60.4 61.7 66.0 70.5 59.0 60.3 64.4 68.8 57.6 58.8 62.8 67.2 54.7 55.9 59.7 63.8 50.6 51.8 55.3 59.1
S/T 0.85 0.80 0.65 0.5 0.88 0.83 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.97 0.91 0.74 0.6 1.00 0.92 0.75 0.6
∆T 26 [-3] 25 [5] 22 [6] 17 [-8]26 [-3] 25 [6] 22 [6] 18 [6] 26 [-3] 25 [6] 22 [6] 18 [7] 27 [-7] 26 [2] 22 [2] 18 [-] 26 [-3] 25 [7] 22 [7] 17 [7] 25 [-4] 24 [7] 20 [7] 16 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
730
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5
∆T 27 [-3] 26 [5] 23 [6] 18 [-8]28 [-2] 26 [6] 23 [6] 18 [6] 28 [-2] 26 [6] 23 [6] 18 [7] 28 [-7] 27 [2] 23 [2] 18 [-] 27 [-3] 26 [7] 23 [7] 18 [7] 26 [-3] 24 [7] 21 [7] 17 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.85 6.04 6.2 6.09 6.22 6.43 6.7 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8
639
MBh 55.4 56.7 60.5 64.7 54.2 55.3 59.1 63.2 52.9 54.0 57.7 61.7 51.6 52.7 56.3 60.2 49.0 50.1 53.5 57.2 45.4 46.4 49.5 53.0
S/T 0.78 0.73 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.90 0.84 0.69 0.5
∆T 252421172625211726252117262522172524211724232016
kW 5.17 5.28 0.80 5.6 5.58 5.70 5.89 6.1 5.94 6.07 6.27 6.5 6.25 6.39 6.61 6.8 6.52 6.67 6.89 7.1 6.75 6.91 7.14 7.4
Amps 10.9 11.1 11.4 11.8 11.6 11.8 12.2 12.5 12.4 12.7 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.3 15.8
Hi PR 166 178 188 196.3 186 200 211 220.3 211 227 240 250.5 241 259 274 285.3 271 291 308 321.0 299 322 340 354.6
Lo PR 51 54 59 62.7 54 57 62 66.2 56 59 65 68.8 58 62 68 72.3 61 65 71 75.8 63 67 74 78.4
85
821
MBh 62.9 64.2 67.2 71.7 61.5 62.7 65.6 70.0 60.0 61.2 64.1 68.4 58.6 59.7 62.5 66.7 55.6 56.7 59.4 63.4 51.5 52.5 55.0 58.7
S/T 0.89 0.86 0.78 0.6 0.93 0.89 0.81 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.89 0.7
∆T 28 [-2] 27 [6] 26 [6] 22 [-6]28 [-2] 28 [6] 26 [6] 23 [6] 28 [-2] 28 [6] 26 [7] 23 [7] 28 [-7] 28 [2] 26 [2] 23 [-] 28 [-2] 28 [7] 26 [7] 23 [7] 26 [-3] 26 [7] 24 [7] 21 [8]
kW 5.39 5.50 5.68 5.9 5.81 5.94 6.14 6.3 6.19 6.33 6.54 6.8 6.52 6.67 6.90 7.1 6.81 6.96 7.20 7.4 7.05 7.21 7.46 7.7
Amps 11.3 11.5 11.8 12.2 12.1 12.3 12.6 13.0 12.9 13.2 13.5 14.0 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.6 15.1 15.4 15.9 16.4
Hi PR 174 187 198 206.4 195 210 222 231.6 222 239 253 263.4 253 272 288 300.0 285 306 324 337.5 315 339 358 372.9
Lo PR 53 57 62 65.9 56 60 65 69.7 59 62 68 72.4 61 65 71 76.0 64 69 75 79.7 67 71 77 82.4
730
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7
∆T 29 [-2] 29 [5] 27 [6] 23 [-5]29 [-2] 29 [6] 27 [6] 24 [6] 29 [-2] 29 [6] 27 [6] 24 [7] 30 [-7] 29 [2] 28 [2] 24 [-] 29 [-2] 29 [7] 27 [7] 23 [7] 27 [-3] 27 [7] 25 [7] 22 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
639
MBh 56.4 57.5 60.2 64.2 55.1 56.2 58.8 62.8 53.8 54.8 57.4 61.3 52.5 53.5 56.0 59.8 49.9 50.8 53.2 56.8 46.2 47.1 49.3 52.6
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.76 0.6 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.91 0.82 0.7
∆T 29 [-2] 29 [5] 27 [5] 24 [-4]30 [-1] 29 [6] 28 [6] 24 [6] 30 [-1] 29 [6] 28 [6] 24 [7] 30 [-7] 30 [2] 28 [2] 24 [-] 30 [-1] 29 [7] 28 [7] 24 [7] 28 [-2] 27 [7] 26 [7] 22 [7]
kW 5.21 5.33 5.50 5.7 5.62 5.75 5.93 6.1 5.98 6.12 6.32 6.5 6.30 6.45 6.66 6.9 6.58 6.73 6.95 7.2 6.81 6.97 7.20 7.5
Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9
Hi PR 167 180 190 198.3 188 202 213 222.5 213 230 243 253.0 243 262 276 288.2 274 294 311 324.2 302 325 343 358.2
Lo PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.5 59 63 69 73.0 62 66 72 76.5 64 68 74 79.2
Shaded area reflects ARI conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

10 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF48-5* / A48-00-2
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
821
MBh 59.8 62.0 67.9 - 58.4 60.5 66.3 - 57.0 59.1 64.7 - 55.6 57.6 63.1 - 52.8 54.8 60.0 - 48.9 50.7 55.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆T 20 [-7] 18 [5] 13 [6] - 20 [-7] 18 [6] 13 [6] - 20 [-7] 18 [6] 13 [6] - 21 [-7] 18 [2] 14 [2] - 20 [-7] 18 [7] 13 [7] - 19 [-7] 16 [7] 12 [7] -
kW 5.26 5.37 5.54 - 5.67 5.80 5.99 - 6.04 6.17 6.38 - 6.36 6.50 6.72 - 6.63 6.78 7.01 - 6.87 7.03 7.27 -
Amps 11.1 11.3 11.6 - 11.8 12.0 12.3 - 12.6 12.9 13.2 - 13.3 13.6 14.0 - 14.1 14.3 14.7 - 14.8 15.1 15.5 -
Hi PR 169 182 192 - 190 204 215 - 216 232 245 - 246 264 279 - 276 297 314 - 305 329 347 -
Lo PR 52 55 60 - 55 58 63 - 57 60 66 - 60 63 69 - 63 67 73 - 65 69 75 -
730
MBh 58.0 60.2 65.9 - 56.7 58.8 64.4 - 55.3 57.4 62.8 - 54.0 56.0 61.3 - 51.3 53.2 58.2 - 47.5 49.2 53.9 -
S/T 0.65 0.54 0.38 - 0.68 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.62 0.43 -
∆T 21 [-6] 18 [5] 14 [5] - 21 [-6] 18 [6] 14 [6] - 21 [-6] 18 [6] 14 [6] - 21 [-7] 19 [2] 14 [2] - 21 [-6] 18 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.21 5.33 5.50 - 5.62 5.75 5.94 - 5.99 6.12 6.32 - 6.31 6.45 6.66 - 6.58 6.73 6.95 - 6.81 6.97 7.20 -
Amps 11.0 11.2 11.5 - 11.7 11.9 12.3 - 12.5 12.8 13.1 - 13.2 13.5 13.9 - 13.9 14.2 14.6 - 14.6 14.9 15.4 -
Hi PR 167 180 190 - 188 202 213 - 214 230 243 - 243 262 276 - 274 294 311 - 302 325 344 -
Lo PR 51 54 59 - 54 58 63 - 56 60 65 - 59 63 69 - 62 66 72 - 64 68 74 -
639
MBh 53.6 55.5 60.8 - 52.3 54.2 59.4 - 51.1 52.9 58.0 - 49.8 51.6 56.6 - 47.3 49.1 53.8 - 43.8 45.4 49.8 -
S/T 0.63 0.52 0.36 - 0.65 0.54 0.38 - 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.72 0.60 0.42 -
∆T 21 [-6] 19 [5] 14 [5] - 22 [-6] 19 [6] 14 [6] - 22 [-6] 19 [6] 14 [6] - 22 [-7] 19 [2] 14 [2] - 22 [-6] 19 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.09 5.20 5.36 - 5.48 5.61 5.79 - 5.84 5.97 6.16 - 6.15 6.28 6.49 - 6.41 6.55 6.77 - 6.64 6.79 7.02 -
Amps 10.8 11.0 11.2 - 11.4 11.7 12.0 - 12.2 12.5 12.8 - 12.9 13.2 13.6 - 13.6 13.9 14.3 - 14.3 14.6 15.0 -
Hi PR 162 175 184 - 182 196 207 - 207 223 235 - 236 254 268 - 265 286 302 - 293 316 333 -
Lo PR 50 53 58 - 52 56 61 - 55 58 63 - 57 61 67 - 60 64 70 - 62 66 72 -
75
821
MBh 60.8 62.6 67.7 72.7 59.4 61.1 66.2 71.0 58.0 59.7 64.6 69.3 56.5 58.2 63.0 67.6 53.7 55.3 59.9 64.3 49.8 51.2 55.5 59.5
S/T 0.78 0.69 0.53 0.3 0.80 0.72 0.54 0.4 0.83 0.74 0.56 0.4 0.85 0.76 0.58 0.4 0.88 0.79 0.60 0.4 0.89 0.80 0.60 0.4
∆T 23 [-5] 22 [5] 18 [6] 12 [-11] 24 [-4] 22 [6] 18 [6] 12 [6] 24 [-4]22 [6] 18 [6] 12 [7] 24 [-7] 22 [2] 18 [2] 12 [-] 24 [-4] 22 [7] 18 [7] 12 [7] 22 [-6] 20 [7] 17 [7] 11 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.84 6.04 6.2 6.09 6.22 6.43 6.6 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.5 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.3 192 206 218 227.0 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 350 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.5 63 67 73 78.1 65 69 76 80.8
730
MBh 59.0 60.8 65.8 70.6 57.6 59.4 64.2 68.9 56.3 57.9 62.7 67.3 54.9 56.5 61.2 65.7 52.2 53.7 58.1 62.4 48.3 49.7 53.8 57.8
S/T 0.74 0.66 0.50 0.3 0.77 0.69 0.52 0.3 0.79 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.85 0.76 0.58 0.4
∆T 24 [-4] 22 [5] 18 [6] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4]23 [6] 19 [6] 13 [7] 25 [-7] 23 [2] 19 [2] 13 [-] 24 [-4] 23 [7] 18 [7] 13 [7] 23 [-5] 21 [7] 17 [7] 12 [8]
kW 5.26 5.37 5.54 5.7 5.67 5.80 5.99 6.2 6.04 6.17 6.38 6.6 6.36 6.50 6.72 7.0 6.63 6.79 7.01 7.3 6.87 7.03 7.27 7.5
Amps 11.1 11.3 11.6 11.9 11.8 12.0 12.3 12.7 12.6 12.9 13.2 13.6 13.3 13.6 14.0 14.4 14.1 14.3 14.8 15.2 14.8 15.1 15.5 16.0
Hi PR 169 182 192 200.3 190 204 216 224.8 216 232 245 255.7 246 264 279 291.2 276 297 314 327.6 305 329 347 361.9
Lo PR 52 55 60 64.0 55 58 63 67.6 57 60 66 70.3 60 63 69 73.8 63 67 73 77.3 65 69 75 80.0
639
MBh 54.5 56.1 60.7 65.2 53.2 54.8 59.3 63.6 51.9 53.5 57.9 62.1 50.7 52.2 56.5 60.6 48.1 49.6 53.6 57.6 44.6 45.9 49.7 53.3
S/T 0.71 0.64 0.48 0.3 0.74 0.66 0.50 0.3 0.76 0.68 0.51 0.3 0.78 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.82 0.73 0.55 0.4
∆T 25 [-4] 23 [5] 19 [5] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4]23 [6] 19 [6] 13 [6] 25 [-7] 23 [2] 19 [2] 13 [-] 25 [-4] 23 [7] 19 [7] 13 [7] 23 [-5] 21 [7] 18 [7] 12 [7]
kW 5.13 5.24 5.41 5.6 5.53 5.65 5.84 6.0 5.89 6.02 6.22 6.4 6.20 6.34 6.55 6.8 6.47 6.61 6.83 7.1 6.69 6.85 7.08 7.3
Amps 10.8 11.0 11.3 11.7 11.5 11.8 12.1 12.4 12.3 12.6 12.9 13.3 13.0 13.3 13.7 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.1 15.6
Hi PR 164 176 186 194.3 184 198 209 218.1 209 225 238 248.0 238 256 271 282.4 268 289 305 317.8 296 319 337 351.1
Lo PR 50 53 58 62.1 53 56 62 65.6 55 59 64 68.2 58 62 67 71.6 61 65 70 75.0 63 67 73 77.6
Shaded area reflects ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

SS-CKF50 www.goodmanmfg.com 11
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF48-5* / A48-00-2 (CONT.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
821
MBh 61.9 63.2 67.5 72.2 60.4 61.7 66.0 70.5 59.0 60.3 64.4 68.8 57.6 58.8 62.8 67.2 54.7 55.9 59.7 63.8 50.6 51.8 55.3 59.1
S/T 0.85 0.80 0.65 0.5 0.88 0.83 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.97 0.91 0.74 0.6 1.00 0.92 0.75 0.6
∆T 26 [-3] 25 [5] 22 [6] 17 [-8]26 [-3] 25 [6] 22 [6] 18 [6] 26 [-3] 25 [6] 22 [6] 18 [7] 27 [-7] 26 [2] 22 [2] 18 [-] 26 [-3] 25 [7] 22 [7] 17 [7] 25 [-4] 24 [7] 20 [7] 16 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
730
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5
∆T 27 [-3] 26 [5] 23 [6] 18 [-8]28 [-2] 26 [6] 23 [6] 18 [6] 28 [-2] 26 [6] 23 [6] 18 [7] 28 [-7] 27 [2] 23 [2] 18 [-] 27 [-3] 26 [7] 23 [7] 18 [7] 26 [-3] 24 [7] 21 [7] 17 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.85 6.04 6.2 6.09 6.22 6.43 6.7 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8
639
MBh 55.4 56.7 60.5 64.7 54.2 55.3 59.1 63.2 52.9 54.0 57.7 61.7 51.6 52.7 56.3 60.2 49.0 50.1 53.5 57.2 45.4 46.4 49.5 53.0
S/T 0.78 0.73 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.90 0.84 0.69 0.5
∆T 252421172625211726252117262522172524211724232016
kW 5.17 5.28 0.80 5.6 5.58 5.70 5.89 6.1 5.94 6.07 6.27 6.5 6.25 6.39 6.61 6.8 6.52 6.67 6.89 7.1 6.75 6.91 7.14 7.4
Amps 10.9 11.1 11.4 11.8 11.6 11.8 12.2 12.5 12.4 12.7 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.3 15.8
Hi PR 166 178 188 196.3 186 200 211 220.3 211 227 240 250.5 241 259 274 285.3 271 291 308 321.0 299 322 340 354.6
Lo PR 51 54 59 62.7 54 57 62 66.2 56 59 65 68.8 58 62 68 72.3 61 65 71 75.8 63 67 74 78.4
85
821
MBh 62.9 64.2 67.2 71.7 61.5 62.7 65.6 70.0 60.0 61.2 64.1 68.4 58.6 59.7 62.5 66.7 55.6 56.7 59.4 63.4 51.5 52.5 55.0 58.7
S/T 0.89 0.86 0.78 0.6 0.93 0.89 0.81 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.89 0.7
∆T 28 [-2] 27 [6] 26 [6] 22 [-6]28 [-2] 28 [6] 26 [6] 23 [6] 28 [-2] 28 [6] 26 [7] 23 [7] 28 [-7] 28 [2] 26 [2] 23 [-] 28 [-2] 28 [7] 26 [7] 23 [7] 26 [-3] 26 [7] 24 [7] 21 [8]
kW 5.39 5.50 5.68 5.9 5.81 5.94 6.14 6.3 6.19 6.33 6.54 6.8 6.52 6.67 6.90 7.1 6.81 6.96 7.20 7.4 7.05 7.21 7.46 7.7
Amps 11.3 11.5 11.8 12.2 12.1 12.3 12.6 13.0 12.9 13.2 13.5 14.0 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.6 15.1 15.4 15.9 16.4
Hi PR 174 187 198 206.4 195 210 222 231.6 222 239 253 263.4 253 272 288 300.0 285 306 324 337.5 315 339 358 372.9
Lo PR 53 57 62 65.9 56 60 65 69.7 59 62 68 72.4 61 65 71 76.0 64 69 75 79.7 67 71 77 82.4
730
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7
∆T 29 [-2] 29 [5] 27 [6] 23 [-5]29 [-2] 29 [6] 27 [6] 24 [6] 29 [-2] 29 [6] 27 [6] 24 [7] 30 [-7] 29 [2] 28 [2] 24 [-] 29 [-2] 29 [7] 27 [7] 23 [7] 27 [-3] 27 [7] 25 [7] 22 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
639
MBh 56.4 57.5 60.2 64.2 55.1 56.2 58.8 62.8 53.8 54.8 57.4 61.3 52.5 53.5 56.0 59.8 49.9 50.8 53.2 56.8 46.2 47.1 49.3 52.6
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.76 0.6 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.91 0.82 0.7
∆T 29 [-2] 29 [5] 27 [5] 24 [-4]30 [-1] 29 [6] 28 [6] 24 [6] 30 [-1] 29 [6] 28 [6] 24 [7] 30 [-7] 30 [2] 28 [2] 24 [-] 30 [-1] 29 [7] 28 [7] 24 [7] 28 [-2] 27 [7] 26 [7] 22 [7]
kW 5.21 5.33 5.50 5.7 5.62 5.75 5.93 6.1 5.98 6.12 6.32 6.5 6.30 6.45 6.66 6.9 6.58 6.73 6.95 7.2 6.81 6.97 7.20 7.5
Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9
Hi PR 167 180 190 198.3 188 202 213 222.5 213 230 243 253.0 243 262 276 288.2 274 294 311 324.2 302 325 343 358.2
Lo PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.5 59 63 69 73.0 62 66 72 76.5 64 68 74 79.2
Shaded area reflects ARI conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

12 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF60-5* / A60-00-2
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
821
MBh 59.8 62.0 67.9 - 58.4 60.5 66.3 - 57.0 59.1 64.7 - 55.6 57.6 63.1 - 52.8 54.8 60.0 - 48.9 50.7 55.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆T 20 [-7] 18 [5] 13 [6] - 20 [-7] 18 [6] 13 [6] - 20 [-7] 18 [6] 13 [6] - 21 [-7] 18 [2] 14 [2] - 20 [-7] 18 [7] 13 [7] - 19 [-7] 16 [7] 12 [7] -
kW 5.26 5.37 5.54 - 5.67 5.80 5.99 - 6.04 6.17 6.38 - 6.36 6.50 6.72 - 6.63 6.78 7.01 - 6.87 7.03 7.27 -
Amps 11.1 11.3 11.6 - 11.8 12.0 12.3 - 12.6 12.9 13.2 - 13.3 13.6 14.0 - 14.1 14.3 14.7 - 14.8 15.1 15.5 -
Hi PR 169 182 192 - 190 204 215 - 216 232 245 - 246 264 279 - 276 297 314 - 305 329 347 -
Lo PR 52 55 60 - 55 58 63 - 57 60 66 - 60 63 69 - 63 67 73 - 65 69 75 -
730
MBh 58.0 60.2 65.9 - 56.7 58.8 64.4 - 55.3 57.4 62.8 - 54.0 56.0 61.3 - 51.3 53.2 58.2 - 47.5 49.2 53.9 -
S/T 0.65 0.54 0.38 - 0.68 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.62 0.43 -
∆T 21 [-6] 18 [5] 14 [5] - 21 [-6] 18 [6] 14 [6] - 21 [-6] 18 [6] 14 [6] - 21 [-7] 19 [2] 14 [2] - 21 [-6] 18 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.21 5.33 5.50 - 5.62 5.75 5.94 - 5.99 6.12 6.32 - 6.31 6.45 6.66 - 6.58 6.73 6.95 - 6.81 6.97 7.20 -
Amps 11.0 11.2 11.5 - 11.7 11.9 12.3 - 12.5 12.8 13.1 - 13.2 13.5 13.9 - 13.9 14.2 14.6 - 14.6 14.9 15.4 -
Hi PR 167 180 190 - 188 202 213 - 214 230 243 - 243 262 276 - 274 294 311 - 302 325 344 -
Lo PR 51 54 59 - 54 58 63 - 56 60 65 - 59 63 69 - 62 66 72 - 64 68 74 -
639
MBh 53.6 55.5 60.8 - 52.3 54.2 59.4 - 51.1 52.9 58.0 - 49.8 51.6 56.6 - 47.3 49.1 53.8 - 43.8 45.4 49.8 -
S/T 0.63 0.52 0.36 - 0.65 0.54 0.38 - 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.72 0.60 0.42 -
∆T 21 [-6] 19 [5] 14 [5] - 22 [-6] 19 [6] 14 [6] - 22 [-6] 19 [6] 14 [6] - 22 [-7] 19 [2] 14 [2] - 22 [-6] 19 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.09 5.20 5.36 - 5.48 5.61 5.79 - 5.84 5.97 6.16 - 6.15 6.28 6.49 - 6.41 6.55 6.77 - 6.64 6.79 7.02 -
Amps 10.8 11.0 11.2 - 11.4 11.7 12.0 - 12.2 12.5 12.8 - 12.9 13.2 13.6 - 13.6 13.9 14.3 - 14.3 14.6 15.0 -
Hi PR 162 175 184 - 182 196 207 - 207 223 235 - 236 254 268 - 265 286 302 - 293 316 333 -
Lo PR 50 53 58 - 52 56 61 - 55 58 63 - 57 61 67 - 60 64 70 - 62 66 72 -
75
821
MBh 60.8 62.6 67.7 72.7 59.4 61.1 66.2 71.0 58.0 59.7 64.6 69.3 56.5 58.2 63.0 67.6 53.7 55.3 59.9 64.3 49.8 51.2 55.5 59.5
S/T 0.78 0.69 0.53 0.3 0.80 0.72 0.54 0.4 0.83 0.74 0.56 0.4 0.85 0.76 0.58 0.4 0.88 0.79 0.60 0.4 0.89 0.80 0.60 0.4
∆T 23 [-5] 22 [5] 18 [6] 12 [-11] 24 [-4] 22 [6] 18 [6] 12 [6] 24 [-4]22 [6] 18 [6] 12 [7] 24 [-7] 22 [2] 18 [2] 12 [-] 24 [-4] 22 [7] 18 [7] 12 [7] 22 [-6] 20 [7] 17 [7] 11 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.84 6.04 6.2 6.09 6.22 6.43 6.6 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.5 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.3 192 206 218 227.0 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 350 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.5 63 67 73 78.1 65 69 76 80.8
730
MBh 59.0 60.8 65.8 70.6 57.6 59.4 64.2 68.9 56.3 57.9 62.7 67.3 54.9 56.5 61.2 65.7 52.2 53.7 58.1 62.4 48.3 49.7 53.8 57.8
S/T 0.74 0.66 0.50 0.3 0.77 0.69 0.52 0.3 0.79 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.85 0.76 0.58 0.4
∆T 24 [-4] 22 [5] 18 [6] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4]23 [6] 19 [6] 13 [7] 25 [-7] 23 [2] 19 [2] 13 [-] 24 [-4] 23 [7] 18 [7] 13 [7] 23 [-5] 21 [7] 17 [7] 12 [8]
kW 5.26 5.37 5.54 5.7 5.67 5.80 5.99 6.2 6.04 6.17 6.38 6.6 6.36 6.50 6.72 7.0 6.63 6.79 7.01 7.3 6.87 7.03 7.27 7.5
Amps 11.1 11.3 11.6 11.9 11.8 12.0 12.3 12.7 12.6 12.9 13.2 13.6 13.3 13.6 14.0 14.4 14.1 14.3 14.8 15.2 14.8 15.1 15.5 16.0
Hi PR 169 182 192 200.3 190 204 216 224.8 216 232 245 255.7 246 264 279 291.2 276 297 314 327.6 305 329 347 361.9
Lo PR 52 55 60 64.0 55 58 63 67.6 57 60 66 70.3 60 63 69 73.8 63 67 73 77.3 65 69 75 80.0
639
MBh 54.5 56.1 60.7 65.2 53.2 54.8 59.3 63.6 51.9 53.5 57.9 62.1 50.7 52.2 56.5 60.6 48.1 49.6 53.6 57.6 44.6 45.9 49.7 53.3
S/T 0.71 0.64 0.48 0.3 0.74 0.66 0.50 0.3 0.76 0.68 0.51 0.3 0.78 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.82 0.73 0.55 0.4
∆T 25 [-4] 23 [5] 19 [5] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4]23 [6] 19 [6] 13 [6] 25 [-7] 23 [2] 19 [2] 13 [-] 25 [-4] 23 [7] 19 [7] 13 [7] 23 [-5] 21 [7] 18 [7] 12 [7]
kW 5.13 5.24 5.41 5.6 5.53 5.65 5.84 6.0 5.89 6.02 6.22 6.4 6.20 6.34 6.55 6.8 6.47 6.61 6.83 7.1 6.69 6.85 7.08 7.3
Amps 10.8 11.0 11.3 11.7 11.5 11.8 12.1 12.4 12.3 12.6 12.9 13.3 13.0 13.3 13.7 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.1 15.6
Hi PR 164 176 186 194.3 184 198 209 218.1 209 225 238 248.0 238 256 271 282.4 268 289 305 317.8 296 319 337 351.1
Lo PR 50 53 58 62.1 53 56 62 65.6 55 59 64 68.2 58 62 67 71.6 61 65 70 75.0 63 67 73 77.6
Shaded area reflects ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

SS-CKF50 www.goodmanmfg.com 13
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF60-5* / A60-00-2 (CONT.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
821
MBh 61.9 63.2 67.5 72.2 60.4 61.7 66.0 70.5 59.0 60.3 64.4 68.8 57.6 58.8 62.8 67.2 54.7 55.9 59.7 63.8 50.6 51.8 55.3 59.1
S/T 0.85 0.80 0.65 0.5 0.88 0.83 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.97 0.91 0.74 0.6 1.00 0.92 0.75 0.6
∆T 26 [-3] 25 [5] 22 [6] 17 [-8]26 [-3] 25 [6] 22 [6] 18 [6] 26 [-3] 25 [6] 22 [6] 18 [7] 27 [-7] 26 [2] 22 [2] 18 [-] 26 [-3] 25 [7] 22 [7] 17 [7] 25 [-4] 24 [7] 20 [7] 16 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
730
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5
∆T 27 [-3] 26 [5] 23 [6] 18 [-8]28 [-2] 26 [6] 23 [6] 18 [6] 28 [-2] 26 [6] 23 [6] 18 [7] 28 [-7] 27 [2] 23 [2] 18 [-] 27 [-3] 26 [7] 23 [7] 18 [7] 26 [-3] 24 [7] 21 [7] 17 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.85 6.04 6.2 6.09 6.22 6.43 6.7 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8
639
MBh 55.4 56.7 60.5 64.7 54.2 55.3 59.1 63.2 52.9 54.0 57.7 61.7 51.6 52.7 56.3 60.2 49.0 50.1 53.5 57.2 45.4 46.4 49.5 53.0
S/T 0.78 0.73 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.90 0.84 0.69 0.5
∆T 252421172625211726252117262522172524211724232016
kW 5.17 5.28 0.80 5.6 5.58 5.70 5.89 6.1 5.94 6.07 6.27 6.5 6.25 6.39 6.61 6.8 6.52 6.67 6.89 7.1 6.75 6.91 7.14 7.4
Amps 10.9 11.1 11.4 11.8 11.6 11.8 12.2 12.5 12.4 12.7 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.3 15.8
Hi PR 166 178 188 196.3 186 200 211 220.3 211 227 240 250.5 241 259 274 285.3 271 291 308 321.0 299 322 340 354.6
Lo PR 51 54 59 62.7 54 57 62 66.2 56 59 65 68.8 58 62 68 72.3 61 65 71 75.8 63 67 74 78.4
85
821
MBh 62.9 64.2 67.2 71.7 61.5 62.7 65.6 70.0 60.0 61.2 64.1 68.4 58.6 59.7 62.5 66.7 55.6 56.7 59.4 63.4 51.5 52.5 55.0 58.7
S/T 0.89 0.86 0.78 0.6 0.93 0.89 0.81 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.89 0.7
∆T 28 [-2] 27 [6] 26 [6] 22 [-6]28 [-2] 28 [6] 26 [6] 23 [6] 28 [-2] 28 [6] 26 [7] 23 [7] 28 [-7] 28 [2] 26 [2] 23 [-] 28 [-2] 28 [7] 26 [7] 23 [7] 26 [-3] 26 [7] 24 [7] 21 [8]
kW 5.39 5.50 5.68 5.9 5.81 5.94 6.14 6.3 6.19 6.33 6.54 6.8 6.52 6.67 6.90 7.1 6.81 6.96 7.20 7.4 7.05 7.21 7.46 7.7
Amps 11.3 11.5 11.8 12.2 12.1 12.3 12.6 13.0 12.9 13.2 13.5 14.0 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.6 15.1 15.4 15.9 16.4
Hi PR 174 187 198 206.4 195 210 222 231.6 222 239 253 263.4 253 272 288 300.0 285 306 324 337.5 315 339 358 372.9
Lo PR 53 57 62 65.9 56 60 65 69.7 59 62 68 72.4 61 65 71 76.0 64 69 75 79.7 67 71 77 82.4
730
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7
∆T 29 [-2] 29 [5] 27 [6] 23 [-5]29 [-2] 29 [6] 27 [6] 24 [6] 29 [-2] 29 [6] 27 [6] 24 [7] 30 [-7] 29 [2] 28 [2] 24 [-] 29 [-2] 29 [7] 27 [7] 23 [7] 27 [-3] 27 [7] 25 [7] 22 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
639
MBh 56.4 57.5 60.2 64.2 55.1 56.2 58.8 62.8 53.8 54.8 57.4 61.3 52.5 53.5 56.0 59.8 49.9 50.8 53.2 56.8 46.2 47.1 49.3 52.6
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.76 0.6 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.91 0.82 0.7
∆T 29 [-2] 29 [5] 27 [5] 24 [-4]30 [-1] 29 [6] 28 [6] 24 [6] 30 [-1] 29 [6] 28 [6] 24 [7] 30 [-7] 30 [2] 28 [2] 24 [-] 30 [-1] 29 [7] 28 [7] 24 [7] 28 [-2] 27 [7] 26 [7] 22 [7]
kW 5.21 5.33 5.50 5.7 5.62 5.75 5.93 6.1 5.98 6.12 6.32 6.5 6.30 6.45 6.66 6.9 6.58 6.73 6.95 7.2 6.81 6.97 7.20 7.5
Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9
Hi PR 167 180 190 198.3 188 202 213 222.5 213 230 243 253.0 243 262 276 288.2 274 294 311 324.2 302 325 343 358.2
Lo PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.5 59 63 69 73.0 62 66 72 76.5 64 68 74 79.2
Shaded area reflects ARI conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

14 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF70-5* / A60-00-2
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
821
MBh 59.8 62.0 67.9 - 58.4 60.5 66.3 - 57.0 59.1 64.7 - 55.6 57.6 63.1 - 52.8 54.8 60.0 - 48.9 50.7 55.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆T 20 [-7] 18 [5] 13 [6] - 20 [-7] 18 [6] 13 [6] - 20 [-7] 18 [6] 13 [6] - 21 [-7] 18 [2] 14 [2] - 20 [-7] 18 [7] 13 [7] - 19 [-7] 16 [7] 12 [7] -
kW 5.26 5.37 5.54 - 5.67 5.80 5.99 - 6.04 6.17 6.38 - 6.36 6.50 6.72 - 6.63 6.78 7.01 - 6.87 7.03 7.27 -
Amps 11.1 11.3 11.6 - 11.8 12.0 12.3 - 12.6 12.9 13.2 - 13.3 13.6 14.0 - 14.1 14.3 14.7 - 14.8 15.1 15.5 -
Hi PR 169 182 192 - 190 204 215 - 216 232 245 - 246 264 279 - 276 297 314 - 305 329 347 -
Lo PR 52 55 60 - 55 58 63 - 57 60 66 - 60 63 69 - 63 67 73 - 65 69 75 -
730
MBh 58.0 60.2 65.9 - 56.7 58.8 64.4 - 55.3 57.4 62.8 - 54.0 56.0 61.3 - 51.3 53.2 58.2 - 47.5 49.2 53.9 -
S/T 0.65 0.54 0.38 - 0.68 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.75 0.62 0.43 -
∆T 21 [-6] 18 [5] 14 [5] - 21 [-6] 18 [6] 14 [6] - 21 [-6] 18 [6] 14 [6] - 21 [-7] 19 [2] 14 [2] - 21 [-6] 18 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.21 5.33 5.50 - 5.62 5.75 5.94 - 5.99 6.12 6.32 - 6.31 6.45 6.66 - 6.58 6.73 6.95 - 6.81 6.97 7.20 -
Amps 11.0 11.2 11.5 - 11.7 11.9 12.3 - 12.5 12.8 13.1 - 13.2 13.5 13.9 - 13.9 14.2 14.6 - 14.6 14.9 15.4 -
Hi PR 167 180 190 - 188 202 213 - 214 230 243 - 243 262 276 - 274 294 311 - 302 325 344 -
Lo PR 51 54 59 - 54 58 63 - 56 60 65 - 59 63 69 - 62 66 72 - 64 68 74 -
639
MBh 53.6 55.5 60.8 - 52.3 54.2 59.4 - 51.1 52.9 58.0 - 49.8 51.6 56.6 - 47.3 49.1 53.8 - 43.8 45.4 49.8 -
S/T 0.63 0.52 0.36 - 0.65 0.54 0.38 - 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.72 0.60 0.42 -
∆T 21 [-6] 19 [5] 14 [5] - 22 [-6] 19 [6] 14 [6] - 22 [-6] 19 [6] 14 [6] - 22 [-7] 19 [2] 14 [2] - 22 [-6] 19 [7] 14 [7] - 20 [-7] 17 [7] 13 [7] -
kW 5.09 5.20 5.36 - 5.48 5.61 5.79 - 5.84 5.97 6.16 - 6.15 6.28 6.49 - 6.41 6.55 6.77 - 6.64 6.79 7.02 -
Amps 10.8 11.0 11.2 - 11.4 11.7 12.0 - 12.2 12.5 12.8 - 12.9 13.2 13.6 - 13.6 13.9 14.3 - 14.3 14.6 15.0 -
Hi PR 162 175 184 - 182 196 207 - 207 223 235 - 236 254 268 - 265 286 302 - 293 316 333 -
Lo PR 50 53 58 - 52 56 61 - 55 58 63 - 57 61 67 - 60 64 70 - 62 66 72 -
75
821
MBh 60.8 62.6 67.7 72.7 59.4 61.1 66.2 71.0 58.0 59.7 64.6 69.3 56.5 58.2 63.0 67.6 53.7 55.3 59.9 64.3 49.8 51.2 55.5 59.5
S/T 0.78 0.69 0.53 0.3 0.80 0.72 0.54 0.4 0.83 0.74 0.56 0.4 0.85 0.76 0.58 0.4 0.88 0.79 0.60 0.4 0.89 0.80 0.60 0.4
∆T 23 [-5] 22 [5] 18 [6] 12 [-11] 24 [-4] 22 [6] 18 [6] 12 [6] 24 [-4]22 [6] 18 [6] 12 [7] 24 [-7] 22 [2] 18 [2] 12 [-] 24 [-4] 22 [7] 18 [7] 12 [7] 22 [-6] 20 [7] 17 [7] 11 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.84 6.04 6.2 6.09 6.22 6.43 6.6 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.5 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.3 192 206 218 227.0 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 350 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.5 63 67 73 78.1 65 69 76 80.8
730
MBh 59.0 60.8 65.8 70.6 57.6 59.4 64.2 68.9 56.3 57.9 62.7 67.3 54.9 56.5 61.2 65.7 52.2 53.7 58.1 62.4 48.3 49.7 53.8 57.8
S/T 0.74 0.66 0.50 0.3 0.77 0.69 0.52 0.3 0.79 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.84 0.75 0.57 0.4 0.85 0.76 0.58 0.4
∆T 24 [-4] 22 [5] 18 [6] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4]23 [6] 19 [6] 13 [7] 25 [-7] 23 [2] 19 [2] 13 [-] 24 [-4] 23 [7] 18 [7] 13 [7] 23 [-5] 21 [7] 17 [7] 12 [8]
kW 5.26 5.37 5.54 5.7 5.67 5.80 5.99 6.2 6.04 6.17 6.38 6.6 6.36 6.50 6.72 7.0 6.63 6.79 7.01 7.3 6.87 7.03 7.27 7.5
Amps 11.1 11.3 11.6 11.9 11.8 12.0 12.3 12.7 12.6 12.9 13.2 13.6 13.3 13.6 14.0 14.4 14.1 14.3 14.8 15.2 14.8 15.1 15.5 16.0
Hi PR 169 182 192 200.3 190 204 216 224.8 216 232 245 255.7 246 264 279 291.2 276 297 314 327.6 305 329 347 361.9
Lo PR 52 55 60 64.0 55 58 63 67.6 57 60 66 70.3 60 63 69 73.8 63 67 73 77.3 65 69 75 80.0
639
MBh 54.5 56.1 60.7 65.2 53.2 54.8 59.3 63.6 51.9 53.5 57.9 62.1 50.7 52.2 56.5 60.6 48.1 49.6 53.6 57.6 44.6 45.9 49.7 53.3
S/T 0.71 0.64 0.48 0.3 0.74 0.66 0.50 0.3 0.76 0.68 0.51 0.3 0.78 0.70 0.53 0.3 0.81 0.73 0.55 0.4 0.82 0.73 0.55 0.4
∆T 25 [-4] 23 [5] 19 [5] 13 [-11] 25 [-4] 23 [6] 19 [6] 13 [6] 25 [-4]23 [6] 19 [6] 13 [6] 25 [-7] 23 [2] 19 [2] 13 [-] 25 [-4] 23 [7] 19 [7] 13 [7] 23 [-5] 21 [7] 18 [7] 12 [7]
kW 5.13 5.24 5.41 5.6 5.53 5.65 5.84 6.0 5.89 6.02 6.22 6.4 6.20 6.34 6.55 6.8 6.47 6.61 6.83 7.1 6.69 6.85 7.08 7.3
Amps 10.8 11.0 11.3 11.7 11.5 11.8 12.1 12.4 12.3 12.6 12.9 13.3 13.0 13.3 13.7 14.1 13.7 14.0 14.4 14.9 14.4 14.7 15.1 15.6
Hi PR 164 176 186 194.3 184 198 209 218.1 209 225 238 248.0 238 256 271 282.4 268 289 305 317.8 296 319 337 351.1
Lo PR 50 53 58 62.1 53 56 62 65.6 55 59 64 68.2 58 62 67 71.6 61 65 70 75.0 63 67 73 77.6
Shaded area reflects ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

SS-CKF50 www.goodmanmfg.com 15
P RODUCT S PECIFICATIONS
EXPANDED COOLING DATA — CKF70-5* / A60-00-2 (CONT.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
821
MBh 61.9 63.2 67.5 72.2 60.4 61.7 66.0 70.5 59.0 60.3 64.4 68.8 57.6 58.8 62.8 67.2 54.7 55.9 59.7 63.8 50.6 51.8 55.3 59.1
S/T 0.85 0.80 0.65 0.5 0.88 0.83 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.97 0.91 0.74 0.6 1.00 0.92 0.75 0.6
∆T 26 [-3] 25 [5] 22 [6] 17 [-8]26 [-3] 25 [6] 22 [6] 18 [6] 26 [-3] 25 [6] 22 [6] 18 [7] 27 [-7] 26 [2] 22 [2] 18 [-] 26 [-3] 25 [7] 22 [7] 17 [7] 25 [-4] 24 [7] 20 [7] 16 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
730
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5
∆T 27 [-3] 26 [5] 23 [6] 18 [-8]28 [-2] 26 [6] 23 [6] 18 [6] 28 [-2] 26 [6] 23 [6] 18 [7] 28 [-7] 27 [2] 23 [2] 18 [-] 27 [-3] 26 [7] 23 [7] 18 [7] 26 [-3] 24 [7] 21 [7] 17 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.85 6.04 6.2 6.09 6.22 6.43 6.7 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8
639
MBh 55.4 56.7 60.5 64.7 54.2 55.3 59.1 63.2 52.9 54.0 57.7 61.7 51.6 52.7 56.3 60.2 49.0 50.1 53.5 57.2 45.4 46.4 49.5 53.0
S/T 0.78 0.73 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.90 0.84 0.69 0.5
∆T 252421172625211726252117262522172524211724232016
kW 5.17 5.28 0.80 5.6 5.58 5.70 5.89 6.1 5.94 6.07 6.27 6.5 6.25 6.39 6.61 6.8 6.52 6.67 6.89 7.1 6.75 6.91 7.14 7.4
Amps 10.9 11.1 11.4 11.8 11.6 11.8 12.2 12.5 12.4 12.7 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.3 15.8
Hi PR 166 178 188 196.3 186 200 211 220.3 211 227 240 250.5 241 259 274 285.3 271 291 308 321.0 299 322 340 354.6
Lo PR 51 54 59 62.7 54 57 62 66.2 56 59 65 68.8 58 62 68 72.3 61 65 71 75.8 63 67 74 78.4
85
821
MBh 62.9 64.2 67.2 71.7 61.5 62.7 65.6 70.0 60.0 61.2 64.1 68.4 58.6 59.7 62.5 66.7 55.6 56.7 59.4 63.4 51.5 52.5 55.0 58.7
S/T 0.89 0.86 0.78 0.6 0.93 0.89 0.81 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.89 0.7
∆T 28 [-2] 27 [6] 26 [6] 22 [-6]28 [-2] 28 [6] 26 [6] 23 [6] 28 [-2] 28 [6] 26 [7] 23 [7] 28 [-7] 28 [2] 26 [2] 23 [-] 28 [-2] 28 [7] 26 [7] 23 [7] 26 [-3] 26 [7] 24 [7] 21 [8]
kW 5.39 5.50 5.68 5.9 5.81 5.94 6.14 6.3 6.19 6.33 6.54 6.8 6.52 6.67 6.90 7.1 6.81 6.96 7.20 7.4 7.05 7.21 7.46 7.7
Amps 11.3 11.5 11.8 12.2 12.1 12.3 12.6 13.0 12.9 13.2 13.5 14.0 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.6 15.1 15.4 15.9 16.4
Hi PR 174 187 198 206.4 195 210 222 231.6 222 239 253 263.4 253 272 288 300.0 285 306 324 337.5 315 339 358 372.9
Lo PR 53 57 62 65.9 56 60 65 69.7 59 62 68 72.4 61 65 71 76.0 64 69 75 79.7 67 71 77 82.4
730
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7
∆T 29 [-2] 29 [5] 27 [6] 23 [-5]29 [-2] 29 [6] 27 [6] 24 [6] 29 [-2] 29 [6] 27 [6] 24 [7] 30 [-7] 29 [2] 28 [2] 24 [-] 29 [-2] 29 [7] 27 [7] 23 [7] 27 [-3] 27 [7] 25 [7] 22 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
639
MBh 56.4 57.5 60.2 64.2 55.1 56.2 58.8 62.8 53.8 54.8 57.4 61.3 52.5 53.5 56.0 59.8 49.9 50.8 53.2 56.8 46.2 47.1 49.3 52.6
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.76 0.6 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.91 0.82 0.7
∆T 29 [-2] 29 [5] 27 [5] 24 [-4]30 [-1] 29 [6] 28 [6] 24 [6] 30 [-1] 29 [6] 28 [6] 24 [7] 30 [-7] 30 [2] 28 [2] 24 [-] 30 [-1] 29 [7] 28 [7] 24 [7] 28 [-2] 27 [7] 26 [7] 22 [7]
kW 5.21 5.33 5.50 5.7 5.62 5.75 5.93 6.1 5.98 6.12 6.32 6.5 6.30 6.45 6.66 6.9 6.58 6.73 6.95 7.2 6.81 6.97 7.20 7.5
Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9
Hi PR 167 180 190 198.3 188 202 213 222.5 213 230 243 253.0 243 262 276 288.2 274 294 311 324.2 302 325 343 358.2
Lo PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.5 59 63 69 73.0 62 66 72 76.5 64 68 74 79.2
Shaded area reflects ARI conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents

16 www.goodmanmfg.com SS-CKF50
P RODUCT S PECIFICATIONS
QUALITY MAKES THE DIFFERENCE!
All of our systems are designed and manufactured with the same high-quality standards, regardless of size or efficiency. We have designed these units to significantly reduce the most
frequent causes of product failure and use quality materials and components. They are simple to service and forgiving to operate. Finally, every unit is run-tested before it leaves the factory.
That’s why we know... there’s no better quality.
Visit our website at www.goodmanmfg.com for information on:
Goodman Products • Customer Services • Parts
Goodman Manufacturing Company, L.P., reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations.
Copyright © 2007 Goodman Manufacturing Company, L.P. • Houston, Texas • Printed in the USA.
SCHEMATIC WIRING DIAGRAM
WIRE CODE: Y - Yellow • PU - Purple
POWER CIRCUIT
Component Legend
C - Contactor
Comp - Compressor
FC - Fan Motor Capacitor
HP - High-pressure Control
FM - Fan Motor
IO - Internal Overload
LOW-VOLTAGE CIRCUIT
SINGLE-PHASE LINE VOLTAGE
