GPC 14 SEER R-410A
Package Air Conditioners
with R-410A
Copyright © 2009 Goodman Manufacturing Company, L.P.
RT6322007r2
August2009
**Note that these tax credits are subject to specific requirements set forth in the American Recovery and
ReinvestmentActof2009andin the Internal RevenueCode. Goodman recommends that consumersconsult
a tax professional if they have questions about the applicability of these credits.
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does not
assume any responsibility for property damage or personal injury due to improper service procedures or
services performed by an unqualified person.
•RefertoServiceManualRS6300011 (Horizontal)
forinstallation,operation,andtroubleshooting information.
•Allsafety information must befollowed as provided inthe Service Manual.
•Refertotheappropriate Parts Catalog for partnumberinformation.
•Models listed on page 3.
•Modelsqualifyfor the 2009and2010 Federal Tax Creditsfor Energy Efficiency**
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUALAL
ALAL
AL

PRODUCT IDENTIFICATION
2
Themodelandmanufacturingnumberareusedforpositiveidentificationofcomponentpartsusedinmanufacturing. Please
usethesenumbers when requesting serviceorpartsinformation.
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed ONLY by
individuals meeting the requirements of an "entry level
technician"asspecifiedbytheAir-Conditioning,Heating,
and Refrigeration Institute (AHRI). Attempting to install
or repair this unit without such background may result
in product damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING WARNING
WARNING
GPC1424H41AA
PRODUCT
TYPE:
Package Unit
PRODUCT
FAMILY:
C:Cooling
PRODUCT
SERIES:
SEER Rating
BRAND:
G:Goodman®
Brand
N
OMINAL
C
APACIT
Y
2
4:24,000 BTUH
3
0:30,000 BTUH
3
6:36,000 BTUH
4
2:42,000 BTUH
4
8:48,000 BTUH
6
0:60,000 BTUH
CONFIGURATION:
H: Horizontal
REFRIGERANT:
4: R-410A
VOLTAGE:
1: 208-230v
1ph/60Hz
MAJOR REVISION:
A
: Initial Release
MINOR REVISION:
A
: Initial Release

PRODUCT IDENTIFICATION
3
Themodelandmanufacturingnumberareusedforpositiveidentificationofcomponentpartsusedinmanufacturing. Please
usethesenumbers when requesting serviceorpartsinformation.
GPC1424H41A*
GPC1430H41A*
GPC1436H41A*
GPC1442H41A*
GPC1448H41A*
GPC1460H41A*
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING
Modelsqualifyfor the 2009 and2010Federal Tax Credits
forEnergyEfficiency**
**Note that these tax credits are subject to specific requirements set forth in the American
Recovery and Reinvestment Act of 2009 and in the Internal Revenue Code. Goodman
recommends that consumers consult a tax professional if they have questions about the
applicability of these credits.

4
PRODUCT DESIGN
GPCPackageCoolingUnitsaredesignedfor outdoor instal-
lations only in either residential or light commercial applica-
tions.
The connecting ductwork (Supply and Return) can be con-
nected for either horizontal or vertical airflow. In the vertical
applicationamatching Roof Curb isrecommended.
Areturnairfiltermustbeinstalledbehindthereturnairgrille(s)
or provision must be made for a filter in an accessible loca-
tionwithinthereturnairduct.The minimum filter area should
not be less than those sizes listed in the Specification Sec-
tion. Under no circumstances should the unit be operated
withoutreturn air filters.
A3/4”PVCpipeisprovidedforremovalof condensate water
from the indoor coil In order to provide proper condensate
flow, a drain trap is supplied and shipped loose inside the
unit for field installation. (Do not reduce the drain line size.)
Refrigerant flow control is achieved by use of restrictor ori-
fices. GPC units use the FasTest Access Fitting System
witha saddle thatis either solderedto the suctionand liquid
lines or is fastened with a locking nut to the access fitting
box (core) and then screwed into the saddle. Do not re-
move the core from the saddle until the refrigerant
charge has been removed. Failure to do so could re-
sult in property damage or personal injury.
Thesingle phase units usepermanent split capacitor(PSC)
designcompressors. Startingcomponentsarethereforenot
required for these units. A low microfarad run capacitor as-
sists the compressor to start and remains in the circuit dur-
ingoperation.
AllGPC14unitshaveX-13indoorblowermotorsthatareen-
ergized by a 24V signal from the thermostat and are con-
stanttorque motorswithverylowpowerconsumption. The X-
13featuresan integral control module.
Air for condensing (cooling cycle) is drawn through the out-
door coil by a propeller fan, and is discharged vertically out
the top of the unit. The outdoor coil is designed for .0 static.
Noadditional restriction (ductwork) shallbe applied.
Conditioned air is drawn through the filter(s), field installed,
across the coil and back into the conditioned space by the
indoorblower.
GPC1424-30H41*useCopelandReciprocatingCompressors.
GPC1436-60H41*use Copeland Scroll Compressors.There
are a number of design characteristics which are different
fromthetraditional reciprocating compressor.
- Due to their design Scroll Compressors are inherently
moretolerantofliquidrefrigerant.NOTE:Eventhoughthe
compressorsectionofa Scroll compressor is more toler-
ant of liquid refrigerant, continued floodback or flooded
start conditions may wash oil from the bearing surfaces
causingprematurebearingfailure.
- Scroll Compressors use white oil which is compatible
with 3GS oil which may be used if additional oil is re-
quired.
- Operatingpressuresandampdrawsmaydifferfrom stan-
dardreciprocating compressors. Thisinformationmaybe
foundinthe "Cooling PerformanceData"section.
LocationandClearances
NOTE:To ensureproper condensatedrainage,unitmustbe
installed in a level position.
36"
36"
10"
UNIT
WALL
36"
Outside Slab Installation - Horizontal (H)
Minimumclearancesarerequiredtoavoidairrecirculationand
keep the unit operating at peak efficiency.

PRODUCT DESIGN
5
36"
36"
24"
PLENUM
UNIT
PLATFORM
CURB
Rooftop Installation - Horizontal (H)
Ininstallationswhere the unit isinstalledabove ground level
andnotserviceable from the ground(Example:RoofTop in-
stallations),the installermustprovideserviceplatform forser-
vicepersonwithrailsorguardsinaccordancewithlocalcodes
orordinancesorintheirabsencewiththelatest edition of the
UniformMechanicalCodeSection 305.
NOTE: Unit can also use roof curb.
WARNING
TOPREVENT POSSIBLEPROPERTY DAMAGE,THE
UNIT SHOULD REMAIN IN AN UPRIGHT POSITION
DURINGALL RIGGINGANDMOVING OPERATIONS.
TO FACILITATE LIFTING AND MOVING IF A CRANE
ISUSED,PLACETHE UNITINANADEQUATE CABLE
SLING.
Refer to Roof Curb Installation Instructions for proper curb
installation. Curbing must be installed in compliance with
theNationalRoofing Contractors Association Manual.

6
PRODUCT DESIGN
HKR ELECTRICAL DATA
All wires and overcurrent protection devices are sized for use with electric heaters only and without
refrigeration. If heaters are not installed with above wire size, overheating and fire could occur. See
PACKAGE COOLING SPECIFICATIONS section for minimum circuit ampacity and maximum overcurrent
protection during refrigeration cycle.
IMPORTANT NOTE: A separate power supply is required for the HKR heater kit.
WARNING
WARNING
GPC14[24-60]H41A*
Maximum Maximum
Overcurrent Overcurrent
Protection (amps) Protection (amps)
at 208 / 240V at 208 / 240V
GPH1424H41A*
HKR05*,C* 24 / 27 30 / 30 ---- ---- 4.75 / 16,200
HKR08*,C* 33 / 28 40 / 40 ---- ---- 7.00 / 23,800
HKR10*,C* 45 / 51 60 / 60 ---- ---- 9.50 / 32,400
GPH1430H41A*
HKR05*,C* 24 / 27 30 / 30 ---- ---- 4.75 / 16,200
HKR08*,C* 34 / 39 40 / 40 ---- ---- 7.00 / 23,800
HKR10*,C* 45 / 52 60 / 60 ---- ---- 9.50 / 32,400
HKR15*,C* 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
GPH1436H41A*
HKR05*,C* 24 / 27 30 / 30 ---- ---- 4.75 / 16,200
HKR08*,C* 34 / 39 40 / 40 ---- ---- 7.00 / 23,800
HKR10*,C* 45 / 52 60 / 60 ---- ---- 9.50 / 32,400
HKR15*,C* 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
GPH1442H41A*
HKR05*,C* 25 / 27 30 / 30 ---- ---- 4.75 / 16,200
HKR08*,C* 34 / 39 40 / 40 ---- ---- 7.00 / 23,800
HKR10*,C* 46 / 52 60 / 60 ---- ---- 9.50 / 32,400
HKR15*,C* 46 / 52 60 /60 22 / 25 30 / 30 14.25 / 48,600
HKR20*,C* 46 / 52 60 / 60 43 / 49 60 / 60 19.50 / 66,500
GPH1448H41A*
HKR05*,C* 25 / 28 30 / 30 ---- ---- 4.75 / 16,200
HKR08*,C* 34 / 40 40 / 40 ---- ---- 7.00 / 23,800
HKR10*,C* 46 / 53 60 / 60 ---- ---- 9.50 / 32,400
HKR15*,C* 46 / 52 60 /60 22 / 25 30 / 30 14.25 / 48,600
HKR20*,C* 46 / 52 60 /60 43 / 49 60 / 60 19.50 / 66,500
GPH1460H41A*
HKR05*,C* 26 / 30 30 / 30 ---- ---- 4.75 / 16,200
HKR08*,C* 36 / 40 40 / 40 ---- ---- 7.00 / 23,800
HKR10*,C* 48 / 54 60 / 60 ---- ---- 9.50 / 32,400
HKR15*,C* 48 / 54 60 /60 22 / 25 30 / 30 14.25 / 48,600
HKR20*,C* 48 / 54 60 / 60 43 / 49 60 / 60 19.50 / 66,500
Actual
kW & BTU
at 240V
Minimum Circuit
Ampacity
at 208 / 240V
Minimum Circuit
Ampacity
at 208 / 240V
Model and Heat Kit Usage
Circuit #1 Circuit #2

PRODUCT DIMENSIONS
7
GPC14[24-60]H41A*
Chassis Model A B
GPC1424 33 30½
GPC1430 33 30½
GPC1436 33 35½
GPC1442 33 35½
GPC1448 33 38½
GPC1460 33 38½
Dimensions in inches
Large
Small
Medium
34.075
66.542
4.512
14.000
14.000
SUPPLY 6.500 RETURN
4.500
BACK VIEW
(DUCT OPENINGS)
A
14.000
B

PACKAGE COOLING SPECIFICATIONS
8
All wires and overcurrent protection devices are sized for use with electric heaters only and without
refrigeration. If heaters are not installed with above wire size, overheating and fire could occur. See
PACKAGE COOLING SPECIFICATIONS section for minimum circuit ampacity and maximum overcurrent
protection during refrigeration cycle.
WARNING
WARNING
GPC14[24-36]H41A*
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters.
(1) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
*Calculated external filter size based on air velocity of 300 ft/min.
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.
GPC1424H41* GPC1430H41* GPC1436H41*
COOLING COOLING CAPACITY, BTUH 24,600 28,400 35,600
CAPACITY SEER / EER 14.5 / 12.1 14.0 / 12.0 14.0 / 12.0
UNIT VOLTAGE (NAMEPLATE) 208-230/1/60 208-230/1/60 208-230/1/60
ELECTRICAL AMPS (TOTAL) 10.5 13.16 20.06
SPECIFICATION MINIMUM CIRCUIT AMPACITY 12.5 15.6 24.2
MAXIMUMOVERCURRENT PROTECTION (1) 20 25 40
COMPRESSOR TYPE RECIP RECIP SCROLL
RATED LOAD AMPS 7.9 9.8 16.7
LOCKED ROTOR AMPS 41 55 79
CONDENSER HORSEPOWER 1/6 1/4 1/4
FAN MOTOR RPM 815 830 830
FULL LOAD AMPS 1.1 1.5 1.5
LOCKED ROTOR AMPS 1.7 3.0 3.0
CONDENSER FAN BLADE DIAMETER (INCHES) / NUMBER OF BLADES 22 / 3 22 / 3 22 / 3
CONDENSER FACE AREA - SQ. FT. 13.4 13.4 13.4
COIL NUMBER OF ROWS 1 1 1
FINS PER INCH 24 24 24
EVAPORATOR HORSEPOWER - NO. OF SPEEDS 1/2 - 5 1/2 - 5 1/2 - 5
BLOWER FULL LOAD AMPS 1.5 1.86 1.86
MOTOR LOCKED ROTOR AMPS NA NA NA
MOTOR SPEED TAP - COOLING T2 T2 T2
RPM 105010501050
EVAPORATOR DIAMETER X WIDTH (INCHES) 10 X 8 10 X 8 10 X 8
BLOWER HI EFFICIENCY COOLING CFM 850 1,050 1,200
5 TON NOMINAL COOLING CFM NA NA NA
FAN ONLY COOLING CFM 800 950 1,100
MAX EXTERNAL STATIC PRESS ("w.c.) 0.5 0.5 0.5
EVAPORATOR FACE AREA - SQ. FT. 5.25 4.67 5.2
COIL NUMBER OF ROWS 3 4 3
FINS PER INCH 16 16 14
GENERAL FILTER SIZE - SQ. FT. * 20 x 20 x 1 20 x 25 x 1 25 x 25 x 1
INFORMATION DRAIN SIZE (INCHES) 3/4" 3/4" 3/4"
EXPANSION DEVICE ORIFICE (0.057) ORIFICE (0.060) ORIFICE (0.065)
REFRIGERANT CHARGE R-410A (Oz.) 83 78 80
POWERSUPPLY CONDUIT KNOCKOUT SIZE (INCHES
)
3/4, 1, 1-1/4 3/4, 1, 1-1/4 3/4, 1, 1-1/4
LOW VOLTAGECONDUIT KNOCKOUT SIZE (INCHES) 1/2 1/2 1/2
SHIPPING WEIGHT LBS. 310 310 370
OPERATING WEIGHT LBS. 300 300 360

PACKAGE COOLING SPECIFICATIONS
9
All wires and overcurrent protection devices are sized for use with electric heaters only and without
refrigeration. If heaters are not installed with above wire size, overheating and fire could occur. See
PACKAGE COOLING SPECIFICATIONS section for minimum circuit ampacity and maximum overcurrent
protection during refrigeration cycle.
WARNING
WARNING
GPC14[42-60]H41*
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters.
(1) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
*Calculated external filter size based on air velocity of 300 ft/min.
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.
GPC1442H41* GPC1448H41* GPC1460H41*
COOLING COOLING CAPACITY, BTUH 40,500 46,500 57,500
CAPACITY SEER / EER 14.5 / 12.0 14.5 / 12.1 14.2 / 12.0
UNIT VOLTAGE (NAMEPLATE) 208-230/1/60 208-230/1/60 208-230/1/60
ELECTRICAL AMPS (TOTAL) 22.2 24.2 30.7
SPECIFICATION MINIMUM CIRCUIT AMPACITY 26.6 29.1 37.3
MAXIMUM OVERCURRENT PROTECTION (1) 40 45 60
COMPRESSOR TYPE SCROLL SCROLL SCROLL
RATED LOAD AMPS 17.9 19.9 26.4
LOCKED ROTOR AMPS 112 109 134
CONDENSER HORSEPOWER 1/4 1/4 1/4
FAN MOTOR RPM 1075 1075 1075
FULL LOAD AMPS 1.4 1.4 1.4
LOCKED ROTOR AMPS 2.9 2.9 2.9
CONDENSER FAN BLADE DIAMETER (INCHES) /NUMBER OF BLADES 22 / 4 22 / 4 22 / 4
CONDENSER FACE AREA - SQ. FT. 17.0 19.1 19.1
COIL NUMBEROFROWS 112
FINS PER INCH 24 21 16
EVAPORATOR HORSEPOWER - NO. OF SPEEDS 1/2 - 5 3/4 - 5 3/4 - 5
BLOWER FULL LOAD AMPS 2.9 2.9 2.9
MOTOR LOCKED ROTOR AMPS NA NA NA
MOTOR SPEED TAP - COOLING T2 T2 T2
RPM 1050 1050 1050
EVAPORATOR DIAMETER X WIDTH (INCHES) 10 x 8 10 x 8 11 x 8
BLOWER HI EFFICIENCY COOLING CFM 1,300 1,600 1,600
5 TON NOMINAL COOLING CFM NA NA 1,800
FAN ONLY COOLING CFM 1,200 1,400 1,600
MAX EXTERNAL STATIC PRESS ("w.c.) 0.5 0.5 0.5
EVAPORATOR FACE AREA - SQ. FT. 6.2 6.2 7.0
COIL NUMBEROFROWS 444
FINS PER INCH 14 14 14
GENERAL FILTER SIZE - SQ. FT. * (2) 20 x 20 x 1 (2) 20 x 20 x 1 (2) 20 x 25 x 1
INFORMATION DRAIN SIZE (INCHES) 3/4" 3/4" 3/4"
EXPANSION DEVICE ORIFICE (0.072) ORIFICE (0.076) ORIFICE (0.088)
REFRIGERANT CHARGE R-410A (Oz.) 118 123 188
POWER SUPPLYCONDUIT KNOCKOUT SIZE (INCHES) 3/4, 1, 1-1/4 3/4,1, 1-1/4 3/4,1, 1-1/4
LOW VOLTAGE CONDUIT KNOCKOUT SIZE (INCHES) 1/2 1/2 1/2
SHIPPING WEIGHT LBS. 370 400 400
OPERATING WEIGHT LBS. 360 390 390

ACCESSORIES
10
Part Number Description
OT18-60A Outdoor Thermostat Kit w/Lockout Stat
OT/EHR18-60 Emergency Heat Relay Kit
HKR Electric Heat Kit
PCCP101-103 Roof Curb
PCP101-103 Downflow Plenum Kit
PCP101-103R8 Downflow Plenum Kit w/ R-8 Insulation
PCEC101-103 Downflow Economizer for GPC-(H) A/C - To Be Used With PCP101-103
PCEH101-103 Downflow Economizer for GPH-(H) Heat Pump - To Be Used With PCP101-103
PCMD101-103 Manual Damper - To Be Used With PCP101-103
PCMDM101-103 Motorized Damper - To Be Used With PCP101-103
GPHMD101-103 Manual Damper for Horizontal Applications
SQRPCH101 Square to Round Adapters 16"&14"
SQRPCH102-103 Square to Round Adapters 18"&14"
SQRPC101 Square to Round Adapter -For Use With PCCP101-103 Curb 16" Rounds
SQRPC102-103 Square to Round Adapter For Use With PCCP101-103 Curb 18" Rounds
PCFR101-103 External Horizontal Filter Rack
PCEF101-103 Elbow & Flashing w/ R-8 Liner
CDK36 Flush Mount Concentric Duct Kit
CDK36515 Flush Mount Concentric Duct Kit w/ Filter
CDK36530 Step Down Concentric Duct Kit
CDK36535 Step Down Concentric Duct Kit w/ Filter
CDK4872 Flush Mount Concentric Duct Kit
CDK4872515 Flush Mount Concentric Duct Kit w/ Filter
CDK4872530 Step Down Concentric Duct Kit
CDK4872535 Step Down Concentric Duct Kit w/ Filter
ACCESSORIES - GPC/GPH****H UNITS
GPC14[24-60]H41A*
