Goodman ARPF User manual

•RefertoServiceManualRS6100004&RS6200006forinstallation,operation&troubleshootinginformation.
•Allsafetyinformation must be followed asprovidedin the Service Manual.
•RefertotheappropriatePartsCatalogforpart number information.
•Models listed on page 3.
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUALAL
ALAL
AL
RT6121000r19
November2012
Copyright © 2007-2012 Goodman Company, L.P.
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman
does not assume any responsibility for property damage or personal injury due to improper
service procedures or services performed by an unqualified person.
ACNF,ADPF,AEPF,ARPF,ARUF,
ASPF, ATUF, AWUF Air Handlers

PRODUCT IDENTIFICATION
2
A W U F 3642 1 6 A A
PRODUCT
TYPE:
A: Air Handler
CABINET FINISH:
U: Unpainted
P: Painted
N: Uncased
EXPANSION
DEVICE:
F:Flowrater
T: TXV
(Expansion
Device)
Ceiling Mount & WallMount Applications
(Nominal Cooling Capacity/Electric HeatkW)
1803: 1 1/2Tons Cooling / 3 kW Electric Heat
1805: 1 1/2Tons Cooling / 5 kW Electric Heat
2405: 2 Tons Cooling /5 kW ElectricHeat
3608: 3 Tons Cooling /8 kW ElectricHeat
3105: 1.5 - 2.5 Tons Cooling / 5kW Electric Heat
3210: 2 - 2.5 Tons Cooling / 10kW Electric Heat
3705: 3 Tons Cooling /5 kW ElectricHeat
3708: 3 Tons Cooling /8 kW ElectricHeat
3710: 3 Tons Cooling / 10 kW Electric Heat
MAJOR
REVISION*
MINOR
REVISION*
ELECTRICAL:
1: 208-230V/1ph/60Hz
APPLICATION
C: Ceiling Mount PSC Motor
D: Downflow PSC Motor
E: Multi-Position Varible Speed Motor
S: Energy-Efficient Motor
R: Multi-Position PSC Motor
T: Coated Coils
W: Wall Mount PSC Motor
REFRIGERANT CHARGE:
No Digit: R-22 Only
6: R-410A or R-22
NOMINAL CAPACITY RANGE:
@ 13 SEER
Dedicated Application
3636:3 Tons
Multi-Position & Downflow Applications
3137: 3 Tons
3642: 3 -3 1/2 Tons
1830: 1 1/2 -3 1/2 Tons
@10 SEER
1729: 1 1/2 -2 1/2 Tons
(
for ex
p
ort s
y
stems
)
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed ONLY by in-
dividuals meeting the require-
ments of an "entry level technician", at a minimum, as
specifiedbytheAir-Conditioning,Heating,andRefrigera-
tion Institute (AHRI). Attempting to install or repair this
unit without such background may result in product
damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING WARNING
WARNING
All Airhandlers use DIRECT DRIVE MOTORS. Power supply is AC 208-230v, 60 hz, 1 phase.

PRODUCT IDENTIFICATION
3
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
ACNF18001**
ACNF18051**
ACNF18061**
ACNF18081**
ACNF24001**
ACNF24051**
ACNF24061**
ACNF24081**
ACNF24101**
ACNF30001**
ACNF30051**
ACNF30061**
ACNF30081**
ACNF30101**
ACNF180016D*
ACNF180516D*
ACNF180616D*
ACNF180816D*
ACNF240016D*
ACNF240516D*
ACNF240616D*
ACNF240816D*
ACNF241016D*
ACNF300016D*
ACNF300516D*
ACNF300616D*
ACNF300816D*
ACNF301016D*
ADPF18241**
ADPF30421**
ADPF48601**
ADPF182416**
ADPF304216**
ADPF486016**
AEPF18301**
AEPF30361**
AEPF31371**
AEPF42601**
ARPF18241**
ARPF30301**
ARPF37431**
ARPF48601**
ARPF182416**
ARPF193116**
ARPF303016**
ARPF363616**
ARPF364216**
ARPF374316**
ARPF486016**
ARPF496116**
ARUF18241**
ARUF30301**
ARUF36421**
ARUF37431**
ARUF48601**
ARUF172916**
ARUF182416**
ARUF193116**
ARUF303016**
ARUF363616**
ARUF364216**
ARUF374316**
ARUF486016**
ARUF496116**
ASPF183016*
ASPF303616*
ASPF313716*
ASPF426016*
ATUF182416**
ATUF193116**
ATUF303016**
ATUF363616**
ATUF364216**
ATUF374316**
ATUF486016**
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING
AWUF18051**
AWUF18081**
AWUF24051**
AWUF24081**
AWUF24101**
AWUF30051**
AWUF30081**
AWUF30101**
AWUF36051**
AWUF36081**
AWUF36101**
AWUF37051**
AWUF37081**
AWUF37101**
AWUF180316**
AWUF240316**
AWUF300316**
AWUF240316B*
AWUF240516B*
AWUF240816B*
AWUF241016B*
AWUF310516A*
AWUF310816A*
AWUF321016A*

PRODUCT DESIGN
4
WARNING
When installing or servicing this equipment, safety
clothing, including hand and eye protection, is
strongly advised. If installing this equipment in an
areathathasspecialsafetyrequirements(hardhats
etc.), observe these requirements. To protect the
unit when brazing close to the painted surfaces,
the use of a quenching cloth is strongly advised to
prevent scorching or marring of the equipment fin-
ish.
WARNING
If this appliance is installed in an enclosed area
such as a garage or utility room with any carbon
monoxide (CO) producing appliance (i.e. automo-
bile, furnace, water-heaters, etc.), ensure the area
is properly ventilated.
WARNING
The unit MUST have an uninterrupted, unbroken
electricalgroundtominimizethepossibilityofper-
sonal injury if an electrical fault should occur. The
electrical ground circuit may consist of an appro-
priately sized electrical wire connecting the
ground lug in the unit control box to the building
electricalservicepanel. Othermethodsofground-
ing are permitted if performed in accordance with
the “National Electric Code” (NEC)/“American Na-
tional Standards Institute” (ANSI)/“National Fire
Protection Association” (NFPA) 70 and local/state
codes. In Canada, electrical grounding is to be in
accordance with the Canadian Electric Code CSA
C22.1. Failure to observe this warning can result
in electrical shock that can cause personal injury
or death.
AIRHANDLERS
*See Air Handler Specification Sheet for Proper Combinations.
ALL AIR HANDLERS USE DIRECT DRIVE MO-
TORS. POWER SUPPLY IS 220-240 V, 60 HZ, 1
PHASE
Installation
Beforeinstallingthisapplianceinsurethatitisproperlysized
andadequatepowerisavailable.
Thisappliancecanbeinstalledinthe vertical orrighthorizon-
tal position without modification. The horizontal left and
downflowpositionsrequireproductmodification.
This product is designed for zero inches (0 inches) clear-
ance;however,adequateaccessforserviceor replacement
mustbe considered without removing permanent structure.
Thisunitcanbeinstalledonaplatformwhen deemed neces-
sary.
In an attic installation a secondary drain pan must be pro-
vided by the installer and placed under the entire unit with a
separatedrainlineproperlyslopedand terminated inanarea
visibleto the owner.This secondary drainpan is requiredin
theeventthat there is a leak ormaindrainblockage. Closed
cellinsulationshouldbeappliedtothedrainlinesinuncondi-
tionedspaces where sweating may occur.
Appliancesinstalled in garages, warehouses orotherareas
where they may be subjected to mechanical damage must
be suitably guarded against such damage by installing be-
hindprotective barriers, being elevated orlocated out of the
normalpathof vehicles. When installedona base, the base
must also be protected by similar means.
Heating and cooling equipment located in garages, which
maygenerateaglow,sparkorflamecapable of igniting flam-
mable vapors, must be installed with the ignition source at
least18"[46cm]abovethefloorlevel.
When more than one appliance is installed in a building it
shall be permanently identified as to the area or space ser-
vicedbytheequipment.
When this product is installed in the downflow installation in
anunconditionedspace,remove thehorizontaldrainpanand
install the following insulation kit
ARUF, ATUF
or ARPFModel AEPF / ASPF Insulation Kit
1729
1824
3030
1931
3636
3642 3036
3743 3137
4860
4961 4260
N/A
1830
DPI18-30/20
DPI36-42/20
DPI48-61/-20
Thiskitisusedtopreventsweatingonthe vertical drain pan.

PRODUCT DESIGN
5
Topreventthehorizontaldrainpanfromsweatinginhigh
humidity applications, it is recommended that a DPIH
insulationaccessorykitbeused.NOTE: The DPIH insu-
lation kit is not supplied with this product and must be
purchasedseparately.
See Chart below for the correct DPIH kit.
ARUF, ATUF
or ARPF Model AEPF / ASPF Insulation Kit
1729
1824
3030
1931
3636
3642 3036
3743 3137
4860
4961
DPIH18-32
DPIH36-42
DPIH48-61
4260
1830
N/A
ACNF AC electric heat air handlers are designed for ceiling
mounting and have a direct drive, multi-speed motor. They
are available in 1-1/2, 2 and 2 1/2 ton sizes.
AWUF is a vertical stud or wall-mount electric heat air han-
dlerandfeaturesadirectdrive,multi-speedmotor.TheAWUF
hasacheck flowrater for cooling only andheatpumpopera-
tion,with sequence controlled heatingelementsof 5, 8, and
10 kW. The AWUF is available in 1 1/2 to 3 ton sizes.
ADPF isa dedicated downflow, multi-speedairhandler and
is available in 1 1/2 to 5 ton sizes. Electric heat kits are
availableasafield-installedoption.
*ARPF air handlers are multi-position, multi-speed with di-
rect drive motors. They are available in 1 1/2 to 5 ton sizes
with optional 3 kW to 21kW electric heat kits available for
fieldinstallation. (See note below.)
ARUF isamulti-positionairhandlerandcanbeusedwithR-
410A or R-22 (models ending in 1/16) and features a direct
drive,multi-speedmotor.TheARUF hasacheckflowraterfor
cooling-only and heat pump operation. The ARUF is avail-
able in 1 1/2 to 5 ton sizes.
*AEPFisamulti-position,variable-speedair handler andcan
be used with R-410A or R-22 (models ending in 1/16). The
unit'sblowerdesignincludesavariable-speedDCmotor and
iscompatiblewithheatpumpsandvariable-capacitycooling
applications.(Seenote below.)
*ASPFisamulti-positionairhandlerthatcanbeusedwithR-
410A or R-22 and it features a energy efficient motor. This
motor is a constant torque motor with very low power
consumptionanditisenergizedbya24Vsignal.Theenergy
efficientmotorfeaturesanintegratedcontrolmoduleand is
compatiblewithheatpumpsandcoolingapplications.(See
notebelow.)
*NOTE: Factory-sealedtoachievea2%orlessleakagerate
at1.0" water gauge external duct static pressure.
Complies with the Factory-sealed Air Handling Credit as
listedinthe2001FloridaBuildingCode,Chapter13,Section
610.2.A.2.1.

PRODUCT DIMENSIONS
6
ACNF
DIMENSIONS
Model A B C D
ACNF18 37¼” 3411/16” 30” 6½”
ACNF24 43¼” 4011/16”36” 6½”
ACNF30 49¼” 4611/16” 42” 6½”
AC18 37¼” 3411/16” 30” 6½”
AC30 43¼” 4011/16”36” 6½”
AC36 49¼” 4611/16” 42” 6½”

PRODUCT SPECIFICATIONS
7
ACNF
ACNF18001 ACNF18051 ACNF18061 ACNF18081 ACNF24001 ACNF24051 ACNF24061 ACNF24081
ANF24101
ACNF30001 ACNF30051 ACNF30061 ACNF30081 ACNF30101
Blower
Diameter 5.75 5.75 5.75 5.75 6.31 6.31 6.31 6.31 6.31 6.75 6.75 6.75 6.75 6.75
Width 6.75 6.75 6.75 6.75 8.25 8.25 8.25 8.25 8.25 8.25 8.25 8.25 8.25 8.25
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Electrical Data
Min. Circuit Ampacity @ 240V 0.9 27 33.5 40.5 1.68 27.8 34.3 41.3 54.9 1.68 27.8 34.3 41.3 54.9
Min. Circuit Ampacity @ 208V 0.9 2405 30.5 36.8 1.68 25.3 31.36 37.6 49.8 1.68 25.3 31.3 37.6 49
Max. Overcurrent Device 240V 15 30 40 50 15 30 40 50 60 15 30 40 50 8
Max. Overcurrent Device @ 208V 15 30 40 40 15 30 40 40 50 15 30 40 40 60
Minimum VAC 197 197 197 197 197 197 197 197 197 197 197 197 197 50
Maximum VAC 253 253 253 253 253 253 253 253 253 253 253 253 253 253
Blower Motor
FLA 0.72 0.72 0.72 0.72 1.34 1.34 1.34 1.34 1.34 1.34 1.34 1.34 1.34 1.34
HP 1/81/81/81/81/41/41/41/41/41/41/41/41/41/4
Ship Weight (lbs) 59 59 59 59 69 69 69 69 69 79 79 79 79 79
ACNF*****DA (with aluminum coils)
ACNF*****AA/AB (copper coils)
ACNF180016 ACNF180516 ACNF180616 ACNF180816 ACNF240016 ACNF240516 ACNF240616 ACNF240816
ANF241016
ACNF300016 ACNF300516 ACNF300616 ACNF300816 ACNF301016
Blower
Diameter 5.75 5.75 5.75 5.75 6.31 6.31 6.31 6.31 6.31 6.75 6.75 6.75 6.75 6.75
Width 6.756.756.756.758.258.258.258.258.258.258.258.258.258.25
CoilDrainConnectionFPT 3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"
Electrical Data
Min. Circuit Ampacity @ 240V 0.9 27 33.5 40.6 1.68 27.8 34.3 41.3 54.9 1.68 27.8 34.3 41.3 54.9
Min. Circuit Ampacity @ 208V 0.9 23.5 29.2 35.3 1.68 24.3 36.1 47.8 49.8 1.68 24.3 29.9 36.1 47.8
Max. Overcurrent Device 240V 15 30 35 45 15 30 45 50 60 15 30 35 45 8
Max. Overcurrent Device @ 208V 15 25 30 40 15 25 40 40 50 15 25 30 40 60
Minimum VAC 197 197 197 197 197 197 197 197 197 197 197 197 197 50
Maximum VAC 253 253 253 253 253 253 253 253 253 253 253 253 253 253
BlowerMotor
FLA 0.720.720.720.721.341.341.341.341.341.341.341.341.341.34
HP 1/81/81/81/81/41/41/41/41/41/41/41/41/41/4
Ship Weight (lbs) 54 57 57 57 61 64 64 64 64 65 68 68 68 68

BLOWER PERFORMANCE DATA
8
ACNF
Model Speed
CFM delivered against External
Static Pressure
0.1” 0.2” 0.3” 0.4” 0.5”
ACNF18001 High 780 710 625 520 440
Low 675 585 510 460 400
ACNF18051 High 780 710 625 520 440
Low 675 585 510 460 400
ACNF18061 High 780 710 625 520 440
Low 675 585 510 460 400
ACNF18081 High 780 710 625 520 440
Low 675 585 510 460 400
ACNF24001 High 935 880 810 735 675
Low 720 680 630 565 490
ACNF24051 High 935 880 810 735 675
Low 720 680 630 565 490
ACNF24061 High 935 880 810 735 675
Low 720 680 630 565 490
ACNF24081 High 935 880 810 735 675
Low 720 680 630 565 490
ACNF24101 High 935 880 810 735 675
Low 720 680 630 565 490
ACNF30001 High 1,075 1,015 945 865 770
Low 830 785 720 665 605
ACNF30051 High 1,075 1,015 945 865 770
Low 830 785 720 665 605
ACNF30061 High 1,075 1,015 945 865 770
Low 830 785 720 665 605
ACNF30081 High 1,075 1,015 945 865 770
Low 830 785 720 665 605
ACNF30101 High 1,075 1,015 945 865 770
Low 830 785 720 665 605
Note: Assumes dry coil with filter in place; 208-volt operation x .96

BLOWER PERFORMANCE DATA
9
ACNF
0.1" 0.2" 0.3" 0.4" 0.5"
High 610 525 480 400 320
Low 545 470 400 340 250
High 610 525 480 400 320
Low 545 470 400 340 250
High 610 525 480 400 320
Low 545 470 400 340 250
High 610 525 480 400 320
Low 545 470 400 340 250
High 945 860 800 725 670
Low 850 800 725 680 600
High 945 860 800 725 670
Low 850 800 725 680 600
High 945 860 800 725 670
Low 850 800 725 680 600
High 945 860 800 725 670
Low 850 800 725 680 600
High 945 860 800 725 670
Low 850 800 725 680 600
High 1,060 985 895 805 720
Low 905 845 780 710 625
High 1,060 985 895 805 720
Low 905 845 780 710 625
High 1,060 985 895 805 720
Low 905 845 780 710 625
High 1,060 985 895 805 720
Low 905 845 780 710 625
High 1,060 985 895 805 720
Low 905 845 780 710 625
ACNF300816
ACNF31016
ACNF300016
ACNF300516
ACNF300616
ACNF240616
ACNF240816
ACNF241016
ACNF180516
ACNF180616
ACNF240016
ACNF240516
ACNF180616
CFM deliverd against External Static Pressure
Model Speed
ACNF180016
ACNF*****DA (with aluminum coils)
Heating Capacity/kW Correction Factor
Supply Voltage 240 230 220 210 208
Correction Factor 1.08 1.00 0.92 0.84 0.82

PRODUCT DIMENSIONS
10
ADPF
2 ȹ”
Model A B C D E F G H I L M
ADPF18241/16 42ȶ” 22” 13½” 15½” 10” 3½” 61/16”13ȶ”17
15/16”15½” 15 5/16”
ADPF30421/16 53¼” 24” 20” 22” 12” 9¼” 1113/16”19ȸ”19
15/16”21 7/16”21¼”
ADPF48601/16 53¼” 24” 20” 22” 12” 9¼” 1113/16”19ȸ”19
15/16”21 7/16”21¼”

PRODUCT SPECIFICATIONS
11
ADPF
ADPF1824
1/16 ADPF3042 1/16 ADPF4860 1/16
Blower
Diameter 9 1/2" 10 5/8" 10 5/8"
Width 6" 8" 10 5/8"
Coil Drain Connection FPT 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8"
Suction 3/4" 7/8" 7/8"
Electrical Data
Voltage 208/240 208/240 208/240
Min. Circuit Ampacity* 2.1/2.1 3.7/3.7 5.4/5.4
Max. Overcurrent Device (amps)* 15/15 15/15 15/15
Minimum VAC 197 197 197
Maximum VAC 253 253 253
Blower Motor
FLA 1.70 2.95 4.30
HP 1/3 1/2 3/4
Ship Weight (lbs) 100 131 160
* @ 208V/240V
ADPF
Note: Assumes dry coil with filter in place; SCFM correction for wet coil = 4% (208V/240V)
0.1" 0.2" 0.3" 0.4" 0.5"
High 1,155 1,090 1,025 950 895
ADPF18241/16 Med. 940 890 860 815 755
Low 695 665 650 610 550
High 1,700 1,660 1,625 1,545 1,505
ADPF30421/16 Med. 1,500 1,440 1,400 1,350 1,345
Low 1,370 1,300 1,250 1,230 1,220
High 2,150 2,120 2,070 2,000 1,940
ADPF48601/16 Med. 1,940 1,930 1,905 1,860 1,790
Low 1,610 1,600 1,590 1,575 1,550
CFM deliverd against External Static Pressure
Model Speed
BLOWER PERFORMANCE DATA

PRODUCT DIMENSIONS
12
AEPF
J
2 ȹ”
[7.30 cm]
Model A B C D E F G H I J
AEPF18301/16 463/4" 22" 17 1/2" 19 1/2" 10' 14 1/2" 11 15/16" 17 1/8" 17 15/16" 2"
AEPF30361/16 531/4" 24" 20" 22" 12" 19 5/8" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
AEPF31371/16 531/4" 24" 20" 22" 12" 19 5/8" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
AEPF42601/16 531/4" 24" 20" 22" 12" 19 5/8" 11 15/16" 19 5/8" 19 15/16" 1 13/16"

PRODUCT SPECIFICATIONS
13
AEPF
AEPF183016* AEPF303616* AEPF313716* AEPF426016*
Blower
Diameter 9 1/2" 10 5/8" 10 5/8" 10 5/8"
Width 8" 10 5/8" 10 5/8" 10 5/8"
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8"
Suction 3/4"7/8"7/8"7/8"
Electrical Data
Voltage 208/240 208/240 208/240 208/240
Min. Circuit Ampacity* 2.5/2.5 3.1/3.1 3.1/3.1 7.8/7.8
Max.OvercurrentDevice (amps)* 15/15 15/15 15/15 15/15
Minimum VAC 197 197 197 197
Maximum VAC 253 253 253 253
BlowerMotor
FLA 2.002.502.506.20
HP 1/2 3/4 3/4 3/4
Ship Weight (lbs) 125 176 176 195

BLOWER PERFORMANCE DATA
14
AEPF
TheAEPF air handler blowermotor is pre-programmedfor operation at fourdistinct airflow levels when operating in
the Cooling, Heat Pump heating, Backup heating (Electric Heating), and Backup + Heat Pump heating modes. Each
modes has four levels to deliver different CFM. Simply flip the dipswitch for a different CFM combination.
Setting the Motor
12345678
O
N
O
F
F
Dipswitch
Number Function Instructions
1 Electric Heat Mode
2 Electric Heat Mode
3N/AN/A
ON = The system operates with single-stage units using a single-stage
cooling or heat pump thermostat. (factory default)
OFF = The system operates with two-stage units with either a conventional two-stage
cooling/heat pump thermosat or with an encoded two-stage condensing unit in
retrofit applications where not enough existing wires are available for connections to
the indoor thermostat and outdoor units.
5 Cooling/Heat Pump Mode Find the airflow for your application in the tables (Dipswitch 5/6 & 7/8) below.
6 Cooling/Heat Pump Mode Set up the motor based on the outdoor unit capacity tons.
Increase or decrease your selected airflow to fit your requirement.
ON-OFF = Increases selected Cool/Heat Pump airflow by 10%
OFF-ON = Decreases selected cool/Heat Pump airflow by 15%
NOTE: Other settinghave no effect on the set airflow.
8
Trim CFM Adjust Mode
Trim CFM Adjust Mode
Select the tapsallow in the tables (dipswitch 1/2 & 7/8) below
4ThermostatMode
7
NOTE: When applying a humidistat (normally closed), refer to the installation and operating instructions. The humidstat can adjust the
cooling airflow to 85%.
Dipswitch 5/6 & 7/8
AEPF
1
830
5678CoolingHeatPump
OFF OFF OFF OFF 1100 1100
ON OFF OFF OFF 800 800
OFF ON OFF OFF 600 600
5678CoolingHeatPump
OFF OFF OFF OFF 1800 1800
ON OFF OFF OFF 1580 1580
OFF ON OFF OFF 1480 1480
ON ON OFF OFF 1200 1200
ON ON OFF ON 1020 1020
Indoor Airflow
Indoor Airflow
Switch
Position
Switch
Position
Switch
Position Switch Position
AEPF3036 / 3137 / 4260
Dipswitch 1/2 & 7/8
AEPF 1830
H
eat
i
ng
Element
(kw) 1278
UP TO10 OFF OFF OFF OFF 1100 1210
UP TO 10 ON OFF OFF OFF 890 935
5 OFF ON OFF OFF 700 770
AEPF3036 / 3137 / 4260
Heating
Element
(kw) 1278
UP TO20 OFF OFF OFF OFF 2050 2150
UP TO20 ON OFF OFF OFF 1750 1835
UP TO15 OFF ON OFF OFF 1600 1680
UP TO10 ON ON OFF OFF 1200 1260
UP TO10 ON ON OFF ON 1020 1070
Heat Pump
With Backup
Switch
Position
Switch
Position
Switch
Position Switch Position
Emergency
Backup Heat Pump With Backup
Emergency
Backup

PRODUCT DIMENSIONS
15
ARPF
Model A B C D E F G HIJ
ARPF18241* 42 1/8" 22" 13 1/2" 15 1/2" 10" 14 1/2" 11 15/16" 13 1/8" 17 15/16" 2"
ARPF19311* 46 3/4" 22" 17 1/2" 19 1/2" 10" 14 1/2" 11 15/16" 17 1/8" 17 15/16" 2"
ARPF30301* 46 3/4" 22" 17 1/2" 19 1/2" 10" 14 1/2" 11 15/16" 17 1/8" 17 15/16" 2"
ARPF36361* 46 3/4" 22" 17 1/2" 19 1/2" 10" 14 1/2" 11 15/16" 17 1/8" 17 15/16" 2"
ARPF36421* 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
ARPF37431* 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
ARPF48601* 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
ARPF49611* 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
A
B
E
SUCTION
LINE
LIQUID
LINE
INLET
TUBE
I
INLET
(RIGHT SIDE VIEW)
H
INLET
(FRONT VIEW)
D
C
FG

PRODUCT SPECIFICATIONS
16
ARPF
ARPF18241* ARPF19311* ARPF30301* ARPF36361*
Blower
Diameter 9 1/2" 9 1/2" 9 1/2" 9 1/2"
Width 6"6"8"6"
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8"
Suction 3/4" 7/8" 3/4" 3/4"
Electrical Data
Voltage 208 / 240 208 / 240 208 / 240 208 / 240
Min. Circuit Ampacity 2.1 / 2.1 1.9 / 1.9 3.3 / 3.3 3.3 / 3.3
Max. Overcurrent Device (amps) 15 / 15 15 / 15 15 / 15 15 / 15
Minimum VAC 197 197 197 197
Maximum VAC 253 253 253 253
Blower M otor
FLA 1.701.482.642.64
HP 1/3 1/4 1/3 1/3
Ship Weight (lbs) 120 155 144 164
ARPF36421* ARPF37431* ARPF48601* ARPF49611*
Blower
Diameter 10 5/8" 11 15/16" 10 5/8" 10 5/8"
Width 8" 10 11/16" 10 5/8" 10 5/8"
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8"
Suction 7/8"7/8"7/8"7/8"
Electrical Data
Voltage 208 / 240 208 / 240 208 / 240 208 / 240
Min. Circuit Ampacity 3.7 / 3.7 4.2 / 4.2 5.4 / 5.4 5.4 / 5.4
Max. Overcurrent Device (amp
s
15 / 15 15 / 15 15 / 15 15 / 15
Minimum VAC 197 197 197 197
Maximum VAC 253 253 253 253
Blower Motor
FLA 2.953.394.304.30
HP 1/2 1/2 3/4 3/4
Ship Weight (lbs) 160 195 192 192

BLOWER PERFORMANCE DATA
17
ARPF
Note: Assumes dry coil with filter in place; SCFM correction for wet coil = 4% (208V/240V)
0.1" 0.2" 0.3" 0.4" 0.5"
High 1155 1090 1025 950 895
ARPF18241* Med. 940 890 860 815 755
Low 695 665 650 610 550
High 1135 1085 1025 965 915
ARPF19311* Med. 860 825 780 750 680
Low 600 570 545 500 465
High 1385 1315 1240 1155 1065
ARPF30301* Med. 1340 1290 1230 1140 1050
Low 1075 1030 980 910 840
High 1310 1240 1155 1090 1020
ARPF36361* Med. 1270 1210 1140 1075 980
Low 1045 1005 955 885 805
High 1700 1660 1625 1545 1505
ARPF36421* Med. 1500 1440 1400 1350 1345
Low 1330 1300 1250 1230 1220
High 2065 2000 1925 1860 1780
ARPF37431* Med. 1685 1635 1550 1470 1410
Low 1490 1425 1345 1280 1205
High 2150 2120 2070 2000 1940
ARPF48601* Med. 1940 1930 1905 1860 1790
Low 1610 1600 1590 1575 1550
High 2150 2105 2040 1970 1880
ARPF49611* Med. 1960 1935 1895 1825 1750
Low 1670 1625 1585 1525 1455
CFM deliverd against External Static Pressure
Model Speed

PRODUCT DIMENSIONS
18
J
2 ȹ”
[7.30 cm]
ARUF
Model A B C D E F G HIJ
ARUF172916 42 1/8" 22" 13 1/2" 15 1/2" 10" 14 1/2" 11 15/16" 13 1/8" 17 15/16" 2"
ARUF182416 42 1/8" 22" 13 1/2" 15 1/2" 10" 14 1/2" 11 15/16" 13 1/8" 17 15/16" 2"
ARUF193116 46 3/4" 22" 17 1/2" 19 1/2" 10" 14 1/2" 11 15/16" 17 1/8" 17 15/16" 2"
ARUF303016 46 3/4" 22" 17 1/2" 19 1/2" 10" 14 1/2" 11 15/16" 17 1/8" 17 15/16" 2"
ARUF363616 46 3/4" 22" 17 1/2" 19 1/2" 10" 14 1/2" 11 15/16" 17 1/8" 17 15/16" 2"
ARUF364216 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
ARUF374316 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
ARUF486016 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"
ARUF496116 53 1/4" 24" 20" 22" 12" 14 1/2" 11 15/16" 19 5/8" 19 15/16" 1 13/16"

PRODUCT SPECIFICATIONS
19
ARUF
ARUF172916 ARUF182416 ARUF193116 ARUF303016
Blower
Diameter 9 1/2" 9 1/2" 9 1/2" 9 1/2"
Width 6"6"6"8"
CoilDrainConnectionFPT 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8"
Suction 3/4" 7/8" 3/4" 3/4"
Electrical Data
Voltage 208 / 240 208 / 240 208 / 240 208 / 240
Min. Circuit Ampacity 2.1 / 2.1 2.1 / 2.1 1.9 / 1.9 3.3 / 3.3
Max. Overcurrent Device (amps) 15 / 15 15 / 15 15 / 15 15 / 15
Minimum VAC 197 197 197 197
Maximum VAC 253 253 253 253
Blower M otor
FLA 1.70 1.70 1.48 2.64
HP 1/3 1/3 1/4 1/3
Ship Weight (lbs) 110 120 155 144
ARUF363616 ARUF364216 ARUF374316 ARUF486016 ARUF496116
Blower
Diameter 9 1/2" 10 5/8" 11 15/16" 10 5/8" 10 5/8"
Width 6" 8" 10 11/16" 10 5/8" 10 5/8"
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 3/4"7/8"7/8"7/8"7/8"
Electrical Data
Voltage 208 / 240 208 / 240 208 / 240 208 / 240 208 / 240
Min. Circuit Ampacity 3.3 / 3.3 3.7 / 3.7 4.2 / 4.2 5.4 / 5.4 5.4 / 5.4
Max. Overcurrent Device (amps) 15 / 15 15 / 15 15 / 15 15 / 15 15 / 15
Minimum VAC 197 197 197 197 197
Maximum VAC 253 253 253 253 253
Blower Motor
FLA 2.642.953.394.304.30
HP 1/3 1/2 1/2 3/4 3/4
Ship Weight (lbs) 164 160 195 192 192

BLOWER PERFORMANCE DATA
20
ARUF
Note: Assumes dry coil with filter in place; SCFM correction for wet coil = 4% (208V/240V)
0.1" 0.2" 0.3" 0.4" 0.5"
High 1155 1090 1025 950 895
ARUF172916 Med. 940 890 860 815 755
Low 695 665 650 610 550
High 1155 1090 1025 950 895
ARUF182416 Med. 940 890 860 815 755
Low 695 665 650 610 550
High 1135 1085 1025 965 915
ARUF193116 Med. 860 825 780 750 680
Low 600 570 545 500 465
High 1385 1315 1240 1155 1065
ARUF303016 Med. 1340 1290 1230 1140 1050
Low 1075 1030 980 910 840
High 1310 1240 1155 1090 1020
ARUF363616 Med. 1270 1210 1140 1075 980
Low 1045 1005 955 885 805
High 1700 1660 1625 1545 1505
ARUF364216 Med. 1500 1440 1400 1350 1345
Low 1330 1300 1250 1230 1220
High 2065 2000 1925 1860 1780
ARUF374316 Med. 1685 1635 1550 1470 1410
Low 1490 1425 1345 1280 1205
High 2150 2120 2070 2000 1940
ARUF486016 Med. 1940 1930 1905 1860 1790
Low 1610 1600 1590 1575 1550
High 2150 2105 2040 1970 1880
ARUF496116 Med. 1960 1935 1895 1825 1750
Low 1670 1625 1585 1525 1455
CFM deliverd against External Static Pressure
Model Speed
