Goodman ASX Operating instructions

RS6200006r11
April2009
This manual is to be used by qualified, professionally trained HVAC techni-
cians only. Goodman does not assume any responsibility for property
damage or personal injury due to improper service procedures or services
performed by an unqualified person.
Copyright © 2006 - 2009 Goodman Manufacturing Company, L.P.
SSX, ASX, GSX, DSX Condensing Units,
SSZ, ASZ, GSZ DSZ Split System Heat Pumps
with R-410A Refrigerant
Blowers, Coils, & Accessories
Service Instructions

Pride and workmanship go into every product to provide our customers with quality products. It is possible, however, that
during its lifetime a product may require service. Products should be serviced only by a qualified service technician who is
familiar with the safety procedures required in the repair and who is equipped with the proper tools, parts, testing instruments
andtheappropriateservicemanual. REVIEWALLSERVICEINFORMATIONINTHEAPPROPRIATESERVICEMANUALBEFORE
BEGINNINGREPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZESAFETYSYMBOLS,WORDSANDLABELS
WARNING
THIS UNIT SHOULD NOT BE CONNECTED TO. OR USED IN CONJUNCTION WITH, ANY DEVICES THAT ARE NOT DESIGN CERTIFIED FOR USE WITH THIS UNIT OR HAVE NOT BEEN
TESTED AND APPROVED BY GOODMAN. SERIOUS PROPERTY DAMAGE OR PERSONAL INJURY, REDUCED UNIT PERFORMANCE AND/OR HAZARDOUS CONDITIONS MAY RESULT
FROM THE USE OF DEVICES THAT HAVE NOT BEEN APPROVED OR CERTIFED BY GOODMAN.
WARNING
TO PREVENT THE RISK OF PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH,
DO NOT STORE COMBUSTIBLE MATERIALS OR USE GASOLINE OR OTHER
FLAMMABLE LIQUIDS OR VAPORS IN THE VICINITY OF THIS APPLIANCE.
WARNING
GOODMAN WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM IMPROPER SERVICE OR SERVICE PROCEDURES.
IF YOU INSTALL OR PERFORM SERVICE ON THIS UNIT, YOU ASSUME RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH
MAY RESULT. MANY JURISDICTIONS REQUIRE A LICENSE TO INSTALL OR SERVICE HEATING AND AIR CONDITIONING EQUIPMENT.
To locate an authorized servicer, please consult your telephone book or the dealer from whom you purchased this product.
For further assistance, please contact: CONSUMERINFORMATIONLINE
IMPORTANT INFORMATION
GOODMAN®BRAND PRODUCTS
TOLL FREE
1-877-254-4729 (U.S. only)
email us at: [email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-713-861-2500.
(Not a technical assistance line for dealers.)
Your telephone company will bill you for the call.
AMANA®BRAND PRODUCTS
TOLL FREE
1-877-254-4729 (U.S. only)
email us at: hac.consumer[email protected]
fax us at: (931) 438- 4362
(Not a technical assistance line for dealers.)
OutsidetheU.S., call1-931-433-6101.
(Not a technical assistance line for dealers.)
Your telephone company will bill you for the call.
IMPORTANTINFORMATION ..................................... 2 - 3
PRODUCTIDENTIFICATION .....................................4 - 11
ACCESSORIES......................................................13-23
PRODUCTDESIGN ................................................25-27
SYSTEMOPERATION ...........................................28 - 32
TROUBLESHOOTINGCHART .......................................33
SERVICETABLEOFCONTENTS.................................34
SERVICING ............................................................35 - 72
ACCESSORIESWIRINGDIAGRAMS ....................73 - 80

SAFE REFRIGERANT HANDLING
Whilethese items will notcoverevery conceivable situation, they shouldserveas a useful guide.
IMPORTANT INFORMATION
Thesuccessfuldevelopmentofhermeticallysealedrefrigera-
tioncompressorshascompletelysealedthe compressor's
movingpartsand electricmotorinsideacommon housing,
minimizing refrigerant leaks and the hazards sometimes
associated with moving belts, pulleys or couplings.
Fundamental to the design of hermetic compressors is a
method whereby electrical current is transmitted to the
compressormotorthroughterminalconductorswhichpass
throughthecompressorhousingwall. Theseterminalsare
sealedinadielectricmaterialwhichinsulatesthemfromthe
housing and maintains the pressure tight integrity of the
hermetic compressor. The terminals and their dielectric
embedmentarestronglyconstructed,butarevulnerableto
careless compressor installation or maintenance proce-
dures and equally vulnerable to internal electrical short
circuits caused by excessive system contaminants.
Ineither of these instances,an electricalshortbetweenthe
terminalandthe compressor housing may result in theloss
of integrity between the terminal and its dielectric embed-
ment. This loss may cause the terminals to be expelled,
thereby venting the vaporous and liquid contents of the
compressor housing and system.
Aventingcompressorterminalnormallypresentsnodanger
toanyone,providingtheterminalprotectivecoverisproperly
in place.
If, however, the terminal protective cover is not properly in
place,aventingterminal may discharge acombinationof
(a) hotlubricatingoilandrefrigerant
(b) flammable mixture (if system is contaminated
withair)
inastreamofspraywhichmaybedangeroustoanyoneinthe
vicinity. Death or serious bodily injury could occur.
Under no circumstances is a hermetic compressor to be
electrically energized and/or operated without having the
terminalprotectivecoverproperlyinplace.
SeeServiceSectionS-17forproperservicing.
WARNING
REFRIGERANTS ARE HEAVIER THAN AIR. THEY CAN "PUSH OUT" THE
OXYGEN IN YOUR LUNGS OR IN ANY ENCLOSED SPACE. TO AVOID
POSSIBLE DIFFICULTY IN BREATHING OR DEATH:
•NEVER PURGE REFRIGERANT INTO AN ENCLOSED ROOM OR SPACE. BY
LAW, ALL REFRIGERANTS MUST BE RECLAIMED.
•IF AN INDOOR LEAK IS SUSPECTED, THOROUGHLY VENTILATE THE AREA
BEFORE BEGINNING WORK.
•LIQUID REFRIGERANT CAN BE VERY COLD. TO AVOID POSSIBLE FROST-
BITE OR BLINDNESS, AVOID CONTACT WITH REFRIGERANT AND WEAR
GLOVES AND GOGGLES. IF LIQUID REFRIGERANT DOES CONTACT YOUR
SKIN OR EYES, SEEK MEDICAL HELP IMMEDIATELY.
•ALWAYS FOLLOW EPA REGULATIONS. NEVER BURN REFRIGERANT,
AS POISONOUS GAS WILL BE PRODUCED.
WARNING
SYSTEM CONTAMINANTS, IMPROPER SERVICE PROCEDURE AND/OR PHYSICAL
ABUSE AFFECTING HERMETIC COMPRESSOR ELECTRICAL TERMINALS MAY
CAUSE DANGEROUS SYSTEM VENTING.
WARNING
TO AVOID POSSIBLE INJURY, EXPLOSION OR DEATH, PRACTICE SAFE
HANDLING OF REFRIGERANTS.
WARNING
TO AVOID POSSIBLE EXPLOSION, USE ONLY RETURNABLE (NOT DISPOSABLE)
SERVICE CYLINDERS WHEN REMOVING REFRIGERANT FROM A SYSTEM.
• ENSURE THE CYLINDER IS FREE OF DAMAGE WHICH COULD LEAD TO A
LEAK OR EXPLOSION.
• ENSURE THE HYDROSTATIC TEST DATE DOES NOT EXCEED 5 YEARS.
• ENSURE THE PRESSURE RATING MEETS OR EXCEEDS 400 LBS.
WHEN IN DOUBT, DO NOT USE CYLINDER.
WARNING
TO AVOID POSSIBLE EXPLOSION:
• NEVER APPLY FLAME OR STEAM TO A REFRIGERANT CYLINDER. IF YOU
MUST HEAT A CYLINDER FOR FASTER CHARGING, PARTIALLY IMMERSE
IT IN WARM WATER.
• NEVER FILL A CYLINDER MORE THAN 80% FULL OF LIQUID REFRIGERANT.
• NEVER ADD ANYTHING OTHER THAN R-22 TO AN R-22 CYLINDER OR
R-410ATO AN R-410ACYLINDER. THE SERVICE EQUIPMENT USED MUST
BE LISTED OR CERTIFIED FOR THE TYPE OF REFRIGERANT USED.
• STORE CYLINDERS IN A COOL, DRY PLACE. NEVER USE A CYLINDER
AS A PLATFORM OR A ROLLER.
WARNING
THE UNITED STATES ENVIRONMENTAL PROTECTION AGENCY ("EPA")
HAS ISSUED VARIOUS REGULATIONS REGARDING THE INTRODUCTION AND
DISPOSAL OF REFRIGERANTS INTRODUCED INTO THIS UNIT. FAILURE TO
FOLLOW THESE REGULATIONS MAY HARM THE ENVIRONMENT AND CAN
LEAD TO THEH IMPOSITION OF SUBSTANTIAL FINES. THESE REGULATIONS
MAY VARY BY JURISDICTION. SHOULD QUESTIONS ARISE, CONTACT YOUR
LOCAL EPA OFFICE.

PRODUCT IDENTIFICATION
4
Model # Description
GSZ13**1AA Goodman Split ZR410A Heat Pump13 Seer R410A heat pump units. Initial
release with Regal Beloit motor.
GSZ13**1AB Goodman Split ZR410A Heat Pump13 Seer R410A heat pump units. Initial
release with Broad Oceanmotor.
SSZ140**1AA Special High Feature Split Z R410A heat pump 14 Seer heat pump units. Initial
release ofGoodman 14 SEER Heat Pump R410A.
SSZ140**1AB Special High Feature Split Z R410A heat pump 14 Seer heat pump units.
Introduces new revisions have screwlocations moved in the top panel, base pans,
louvers, and control box covers.
SSZ140**1AC Special High Feature Split Z R410A heat pump 14 Seer heat pump units. Models
contain Broad Ocean motors.
SSZ140181AC
SSZ140241AF
SSZ140301AD
Special High Feature Split Z R410A heat pump 14 Seer heat pump units.
Introduces new revisions adding mufflers to the discharge line.
SSZ140361AF
SSZ140421AD
SSZ140[48-60]1AE
Special High Feature Split Z R410A heat pump 14 Seer heat pump units. New
revisions replace TXV & compensator with flowrator & accumulator;adds mufflers
on SSZ14036`,421, 481,601.
SSZ160**1AA Special High Feature Split Z R410A heat pump 16 Seer heat pump units. Initial
release ofGoodman 16 SEER Heat Pump R410A.
SSZ160**1AB Special High Feature Split Z R410A heat pump 16 Seer heat pump units.
Introduces new revisions have screwlocations moved in the top panel, base pans,
louvers, and control box covers.
SSZ160[24-48]1AC
SSZ160601AD Special High Feature Split Z R410A heat pump 16 Seer heat pump units.
Introduces new revisions adding mufflers to the discharge line.
SSZ160**1AC
Special High Feature Split Z R410A heat pump 16 Seer heat pump
units.Introduces models containingthe Broad Ocean motor and added Muffler and
standardized TXV,Compensator using the ASZ18 Seer weldment to the
SSZ160601AC.
DSZ160**1AA Deluxe SplitZHeat Pump 16 Seerheatpump units. Introduces Goodman 2-stage
16 SEER heat pumps with R-410A.
Split System Heat Pumps R410A

PRODUCT IDENTIFICATION
5
Model # Description
ASZ130**1AA Amana® Brand Split ZR410Aheat pump 13 Seer heatpump units. Initial release
of Amana® Brand 13 SEER Heat Pump R410A.
ASZ140**1AA Amana® Brand Split ZR410A heat pump 14 Seer heatpump units. Initial release
of Amana® Brand 14 SEER Heat Pump R410A.
ASZ140**1AB Amana® Brand Split ZR410A heat pump 14 Seer heat pump units. Introduces new
revisions have screw locations moved in the top panel, base pans,louvers, and
control box covers.
ASZ140**1AC Amana® Brand Split ZR410A heat pump 14 Seer heatpump units. New revisions
have horizontal style louvers.
ASZ140181AD
ASZ140[24-36]1AE
ASZ14[42-48]1AD
ASZ140601AE
Amana® Brand Split ZR410A heat pump 14 Seer heatpump units. Adds new steel
muffler, and suction tubes w/shock loop.
ASZ160**1AA Amana® Brand Split ZR410A heat pump 16 Seer heatpump units. Initial release
of Amana® Brand 16 SEER Heat Pump R410A.
ASZ160**1AB Amana® Brand Split ZR410A heat pump 16 Seer heat pump units. Introduces new
revisions have screw locations moved in the top panel, base pans,louvers, and
control box covers.
ASZ160**1AC Amana® Brand Split ZR410A heat pump 16 Seer heatpump units. New revisions
have horizontal style louvers.
ASZ160**1AD Amana® Brand Split ZR410A heat pump 16 Seer heatpump units. New revisions
added Muffler and standardized TXV,Compensator using the ASZ18 Seer
weldment.
ASZ160241AD
ASZ160[36-60]AE Amana® Brand Split ZR410A heat pump 16 Seer heatpump units. Adds new steel
muffler, and suction tubes w/shock loop.
ASZ180**1AB Amana® Brand Split ZR410A heat pump 18 Seer heatpump units. Initial release
of Amana® Brand 18 SEER Heat Pump R410A.
Split System Heat Pumps R410A

PRODUCT IDENTIFICATION
6
Model # Description
GSX130**1AA Goodman Split XCondenser 13 Seer condensing units.Introduction of Goodman 13
SEER R-410A Condensers with Regal Beloit motors
GSX130**1AB Goodman Split X Condenser 13 Seer condensing units. Introduction ofGoodman 13
SEER R-410A Condensers with Broad Ocean motors.
GSX130**1BA Goodman Split XCondenser 13 Seer condensing units.Introduction of Goodman 13
SEER R-410A Condensers, using Quantum Leap coils. Units will have new louvers
because units are smaller. Piston size change. Other components unchanged.
SSX140**1AA Special High Feature Split XCondenser 14 Seer condensing units. Initial release of
Goodman 14 SEER AC 410A.
SSX140**1AB Special High Feature Split X Condenser 14 Seer condensing units. Revisions have
screw locations moved in the top panel,base pans, louvers, and control box covers.
SSX14018,241AC Special High Feature Split X Condenser 14 Seer condensing units. Revised condenser
coils by removing [1] haripin.
SSX140301AC Special High Feature Split X Condenser 14 Seer condensing units. Model contain the
Broad Ocean motor 0131M00060
SSX14036-601AC Special High Feature Split X Condenser14 Seercondensing units. Model contain the
Broad Ocean motor 0131M00061
SSX14030,361AD Special High Feature Split X Condenser14 Seercondensing units. Revised condenser
coils by removing [1] haripin.
SSX140421AD Special High Feature Split X Condenser 14 Seer condensing units. Introduces
SSX140421A in 29" base pan
SSX140421BA Special High Feature Split X Condenser 14 Seer condensing units. Revision for
SSZ140421B* in 29 base pan and it willthe reduce the unit charge from 180 oz.to 170
oz.and replace the 1/4 hp outdoorunitmotor with 1/6 hp motor.
SSX14030-421AE Special High Feature Split X Condenser 14 Seer condensing units. Revised condenser
coils by removing [1] haripin.
SSX140[18-36]1BA
SSX140421CA Special High Feature Split X Condenser 14 Seer condensing units. Introduction of
Goodman 14 SEER R-410A Condensers,using Quantum Leap Coils.
SSX160**1AA Special High Feature Split X Condenser 16 Seer condensing units. Introduces Goodman
16 SEER AC 410A
SSX160**1AB Special High Feature Split X Condenser16 Seer condensing units. New revisions have
screw locations moved in the top panel,base pans, louvers, and control box covers.
SSX160**1AB Special High Feature Split X Condenser16 Seer condensing units. New revisions have
screw locations moved in the top panel,base pans, louvers, and control box covers.
DSX160**1AA Deluxe Split XCondenser 16 Seer condensing units. Introduces Goodman 2-stage, 16
SEER condensing units with R-410A.
Split System Air Conditioners R410A

PRODUCT IDENTIFICATION
7
Model # Description
ASX130**1AA Amana® Brand Split XCondenser 13 Seer condensing units. Initial release new models
of Amana® Brand Deluxe 13 SEER AC R410A conditioners.
ASX130**1BA Amana® Brand Split XCondenser 13 Seer condensing units. Introduction of Amana®
Brand 13 SEER R-410A Condensers, using Quantum Leap Coils. Units will have new
louvers since units are smaller. Piston size change; other components unchanged.
ASX140**1AA Amana® Brand Split XCondenser 14 Seer condensing units. Initial release new models
of Amana® Brand Deluxe 14 SEER AC R410A conditioners.
ASX140**1AB Amana® Brand Split X Condenser 14 Seer condensing units. New revisions have
screw locations moved in the top panel,base pans, louvers, and control box covers.
ASX140**1AC Amana® Brand Split XCondenser 14 Seer condensing units. The new revisions have
horizontal style louvers.
ASX14018-361AD Amana® Brand Split XCondenser 14 Seer condensing units. Revised condenser coils
by removing (1) hairpin.Reduce R410A quantity by 6 ounces
ASX140421AD Amana® Brand Split XCondenser 14 Seer condensing units. Introduces ASX140421A
in 29" base pan
ASX140421BA Amana® Brand Split XCondenser 14 Seer condensing units. Revision for ASX140421
in 29"platform.Itwill the reduce the unit charge from180 oz. to 170 oz.and replace the
1/4 hp outdoor unit motor with 1/6 hp motor.
ASX140[18-36]1BA
ASX140421CA Amana® Brand Split XCondenser 14 Seer condensing units. Introduction of Amana®
Brand 14 SEER R-410A Condensers, using Quantum Leap Coils.
ASX160**1AB Amana® Brand Split XCondenser 16 Seer condensing units. New revisions have
screw locations moved in the top panel,base pans, louvers, and control box covers.
ASX160**1AC Amana® Brand Split XCondenser 16 Seer condensing units. The new revisions have
horizontal style louvers.
ASX180**1AB Amana® Brand Split XCondenser 18 Seer condensing units. Initial release new models
of Amana® Brand Deluxe 16 SEER AC R410A conditioners.
Split System Air Conditioners R410A

PRODUCT IDENTIFICATION
8
Model # Description
ARUF****16AA ASingle Piece R Multi-Position PSC Motor Unpainted Flowrater Introducation
of new 13 SEER Air Handler Models. All Models will be suitable for use with R-
22 and R-410A
ARUF364216AB ASingle Piece R Multi-Position PSC Motor Unpainted Flowrater.Revision
replaces the current spot welded blower housing with the same cinched or
crimped design used on the 80% furnace line.
ARUF486016AB ASingle Piece R Multi-Position PSC Motor Unpainted Flowrater.Revision
replaces the current spot welded blower housing with the same cinched or
crimped design used on the 80% furnace line.
ARUF364216AC ASingle Piece R Multi-Position PSC Motor Unpainted Flowrater.Revision
replaces the current spot welded blower housing with the same cinched or
crimped design used on the 80% furnace line.
ARUF****16BA A Single Piece R Multi-Position PSC Motor Unpainted Flowrater. Revision
replaces all ARUFcoils using wavy fin with louver enhanced fin.
ARUF****1BA ASingle Piece R Multi-Position PSC Motor Unpainted Flowrater Introducation
of R-22 Only Air Handlers.
ARPF****16AA ASingle Piece R Multi-Position PSC Motor Painted Flowrater Introducation of
new 13 SEER Air Handler Models. All Models will be suitable for use with R-22
and R-410A
ARPF364216AB ASingle Piece R Multi-Position PSC Motor Painted Flowrater. Revision
replaces the current spot welded blower housing with the same cinched or
crimped design used on the 80% furnace line.
ARPF486016AB ASingle Piece R Multi-Position PSC Motor Painted Flowrater. Revision
replaces the current spot welded blower housing with the same cinched or
crimped design used on the 80% furnace line.
ARPF****16BA ASingle Piece R Multi-Position PSC Motor Painted Flowrater. Revision
replaces all ARPFcoils using wavy fin with louver enhanced fin.
ARPF****1BA ASingle Piece R Multi-Position PSC Motor Painted Flowrater. Introducation of
R-22 Only Air Handlers.
ADPF****16AA ASingle Piece Downflow PSC Motor Unpainted Flowrater. Introducation of
new 13 SEER Air Handler Models. All Models will be suitable for use with R-22
and R-410A
ADPF364216AB ASingle Piece Downflow PSC Motor Unpainted Flowrater. Revision replaces
the current spot welded blower housing with the same cinched or crimped
design used on the 80% furnace line.
ADPF486016AB ASingle Piece Downflow PSC Motor Unpainted Flowrater. Revision replaces
the current spot welded blower housing with the same cinched or crimped
design used on the 80% furnace line.
ADPF304216AC ASingle Piece Downflow PSC Motor Unpainted Flowrater. Revision replaces
the current spot welded blower housing with the same cinched or crimped
design used on the 80% furnace line.
ADPF****1BA ASingle Piece Downflow PSC Motor Unpainted Flowrater Revision replaces
all ARPFcoils using wavy fin with louver enhanced fin.
Single Piece Air Handlers

PRODUCT IDENTIFICATION
9
Model # Description
AEPF****16AA ASingle Piece EMulti-Position Variable-Speed Painted Flowrator. Introducation of
new13 SEER AirHandler Models.All Models will be suitable for use with R-22 and
R-410A
AEPF****16BA ASingle Piece EMulti-Position Variable-Speed Painted Flowrator. Revision
introduces new models adding lower kwhit kits on the S&R plate
AEPF****16BB ASingle Piece EMulti-Position Variable-Speed Painted Flowrator. Revision
replacesthe current spot welded blower housing with the same cinched or crimped
design used on the 80% furnace line.
AEPF****16CA ASingle Piece EMulti-Position Variable-Speed Painted Flowrator. Revision
replacesall ARPFcoils usingwavy fin with louverenhanced fin.
AEPF****1BA ASingle Piece EMulti-Position Variable-Speed Painted Flowrator Introduction of R
-
22 Only Air Handlers.
AEPF313716AA
ASPF313716AA
ASingle Piece EMulti-Position Variable-Speed Painted Flowrator (AEPF) and A
Single Piece SMulti-Position EEM motor Painted Flowrator (ASPF). Introduction of
3-Ton Air Handler units with 3-row coil.
ASPF****16AA ASingle Piece SMulti-Position EEM motor Painted Flowrator. Introduces new
ASPF Air Handlers
ASPF****16BA ASingle Piece SMulti-Position EEM motor Painted Flowrator. Revision introuces
modified ASPF control scheme, to ensure blower operation during and after call for
heat on units with heat kits and replacing wavy fin with louver enhanced fin on coil
AWUF****1AA A Single Piece Air Handler Wall Mount Unpainted Flowrator.Introduces 13 SEER
Dayton wall mount air handlers
AWUF****16AA A Single Piece Air Handler Wall Mount Unpainted Flowrator.Introduces 13 SEER
Dayton wall mount air handlers. All Models will be suitable for use with R-22 and R-
410A
AWUF3005-101AA A Single Piece Air Handler Wall Mount Unpainted Flowrator.Introduces 13 SEER
Dayton wall mount air handlers using a Burr Oak Louvered Fin coil.
AWUF****1BA A Single Piece Air Handler Wall Mount Unpainted Flowrator.Revision replaces
current wavey fin designwith new louvered fin design
AWUF370**16AA ASingle Piece Air Handler Wall Mount Unpainted Flowrator. Introduction of
AWUF37 Air Handlersfor use with R-22 andR410A.
AWUF****16BA A Single Piece Air Handler Ceiling Mount NUncased Flowrater. Revision has
louver fins & replaces copper tube hairpins with aluminum hairpins.
ACNF****1AA A Single Piece Air Handler Ceiling Mount NUncased Flowrater.Revision release
allmodels of 13 SEER Dayton uncased air handlers.
ACNF****16AA A Single Piece Air Handler Ceiling Mount NUncased Flowrater.Revision release
allmodels of 13 SEER Dayton uncased air handlers.All Models will be suitable for
use with R-22 and R-410A
ACNF****1BA A Single Piece Air Handler Ceiling Mount NUncased Flowrater.Revision replaces
current wavey fin designwith new louvered fin design
AH**-1* ASingle Piece Air Handler Hydronic Air Handler. Revision replaces the time delay
relay in the AH air handlers with the UTEC time delay control board.
Single Piece Air Handlers

PRODUCT IDENTIFICATION
10
Model # Description
MBR****AA-1AA Modular Blower RMulti-Position PSC Motor. Introduces module blower with PSC
blower motor.
MBE****AA-1AA Modular Blower EMulti-Position Variable-Speed. Introduces module blower with
variable speed blower motor.
MBE****AA-1BA Modular Blower EMulti-Position Variable-Speed.Revision introduces new models
adding lower kwhitkits on the S&R plate
Model # Description
CAUF*****6AA CIndoor CoilA Upflow/Downflow Uncased Flowrator.Introduces 13 SEER CAUF
Dayton Upflow/Downflow coils.
CAUF*****6BA CIndoor CoilA Upflow/Downflow Uncased Flowrator.Revision releasesBurr Oak
Louvered Finin place of the Wavy Fin currently in production.
CAPF*****6AA CIndoor CoilA Upflow/Downflow Painted Flowrator. Introduces 13SEER CAPF
Dayton Upflow/Downflow coils.
CAPF*****6BA CIndoor CoilA Upflow/Downflow Painted Flowrator.Revision releases Burr Oak
Louvered Finin place of the Wavy Fin currently in production.
CAPF/CAUF36***CA CIndoor CoilA Upflow/Downflow [Painted or Uncased]Flowrator. Revision
redesigns for performance improvementfrom 2 row to 3 row.
CHPF*****6AA CIndoor CoilHorizontal A Coil Painted Flowrator. Release 13 SEER CHPF
horizontal A coil.
CHPF*****6BA
CIndoor CoilHorizontal A Coil Painted Flowrator. Release 13 SEER CHPF
horizontal A coil. Revision releases Burr Oak Louvered Fin in place of the Wavy
Fin currently in production. The rows change by one,(i.e. 4 row to 3 row;3 row to
2 row) where applicable.
,
CHPF2430B6CA
CHPF3636B6CA
CHPF3642[C-D]6CA
CHPF3743C6BA
CHPF3743D6CA
CIndoor CoilHorizontal A Coil Painted Flowrator. 13 SEER CHPFhorizontal A
coil, revision has louver fins & replaces copper tube hairpins with aluminum
hairpins.
CSCF*****6AA CIndoor CoilS Horizontal Slab Coil CUpainted Flowrator. Release 13 SEER
CSCFslab horizontal coil.
CSCF*****6BA CIndoor CoilS Horizontal Slab Coil CUpainted Flowrator. Revision releases Burr
Oak Louvered Fin in place of the WavyFin currently in production. The rows
change by one, (i.e. 4 row to 3 row;3 row to 2 row) where applicable.
MBR/MBE Air Handlers
Evaporator Coils

PRODUCT IDENTIFICATION
11
SSZ14361AA
PRODUCT
TYPE:
X: Condenser R-410A
Z: Heat PumpR-410A
PRODUCT
FAMILY:
S: Split System
SEER:
SEER Rating
BRAND:
G: Goodman®
(Standard
Feature Set)
S: Goodman®
(High
Feature Set)
A
: Amana®
Brand
Deluxe
D:Deluxe
Goodman®
NOMINAL
CAPACITY:
018:1.5 Tons
024: 2 Tons
030:2.5 Tons
036: 3 Tons
042:3.5 Tons
048: 4 Tons
060: 5 Tons
MAJOR
REVISION:
A
: Initial Release
MINOR
REVISION:
A
:InitialRelease
ELECTRICAL:
1: 208-230V/1ph/60Hz
3: 208-230v/3ph/60Hz
4: 460v/3ph/60Hz

PRODUCT IDENTIFICATION
12
MB R 8 00 A A 1
DESIGN SERIES:
MB: Modular Blower
MOTORTYPE:
R:Constant Speed
E: Variable Speed
AIRFLOW DELIVERED
08: 800 CFM
12: 1200 CFM
16: 1600 CFM
20: 2000 CFM
FACTORY HEAT
00: No Heat
ELECTRICAL SUPPLY:
1: 208-230V/60hZ/1 ph
CIRCUIT BREAKER
A: No Circuit Breaker
B: Circuit Breaker
DESIGN SERIES
A: First Series
C A P F 1824 A 6 A
PRODUCT
TYPE:
C: Indoor Coil
CABINET FINISH:
U:Unpainted
P:Painted
N:Unpainted Case
EXPANSION
DEVICE:
F: Flowrater
NOMINAL CAPACITY RANGE
@ 13 SEER
1824: 1 1/2 to 2 Tons
3030: 2 1/2 Tons
3636: 3 Tons
3642: 3 to 3 1/2 Tons
4860: 4 & 5 Tons
REVISION
A: Revision
NOMINAL WIDTH FOR GAS FURNACE
A:Fits 14" Furnace Cabinet
B:Fits 17 1/2" Furnace Cabinet
C: Fits 21" Furnace Cabinet
D: Fits 24 1/2" Furnace Cabinet
N: Does NotApply (Horizontal SlabCoils)
APPLICATION
A: Upflow/Downflow Coil
H: Horizontal A Coil
S: Horizontal Slab Coil
REFRIGERANT
CHARGE:
6: R-410A or R-22
2: R-22
4: R-410a

PRODUCT IDENTIFICATION
13
All Airhandlers use DIRECT DRIVE MOTORS.Power supplyis AC208-230v,60hz, 1 phase.
A W U F 3642 1 6 A A
PRODUCT
TYPE:
A: Air Handler
CABINET FINISH:
U:Unpainted
P: Paited
N:Uncased
EXPANSION
DEVICE:
F: Flowrater
T: TXV
(Expansion
Device)
NOMINAL CAPACITY RANGE:
@ 13 SEER
Dedicated Application
3636: 3 Tons
Multi-Position & Downflow Applications
3137: 3 Tons
3642: 3 - 3 1/2 Tons
1830: 1 1/2 - 3 1/2 Tons
@10 SEER
1729: 1 1/2 - 2 1/2 Tons (for export systems)
Ceiling Mount & Wall Mount Applications
(Nominal Cooling Capacity/Electric HeatkW)
1805: 1 1/2 Tons Cooling / 5 kW Electric Heat
2405: 2 Tons Cooling / 5 kW Electric Heat
3608: 3 Tons Cooling / 8 kW Electric Heat
3705: 3 Tons Cooling / 5 kW Electric Heat
3708: 3 Tons Cooling / 8 kW Electric Heat
MAJOR
REVISION*
MINOR
REVISION*
ELECTRICAL:
1: 208-230V/1ph/60Hz
APPLICATION
C: CeilingMount PSC Motor
D: Downflow PSC Motor
E: Multi-Position Varible-Speed Motor
S: Energy-Efficient Motor
R: Multi-Position PSC Motor
T: Coated Coils
W: Wall Mount PSC Motor
REFRIGERANT CHARGE:
No Digit: R-22 Only
6: R-410A or R-22

ACCESSORIES
14
ASX13
Model Description ASX13
018 ASX13 024 ASX13 030 ASX13 036 ASX13 042 ASX13 0418 ASX13 060
ASC01Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-start Kit X X X X
CSR-U-2 Hard-start Kit X X X X
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
TX2N4³ TXV Kit X
TX3N42TXVKit XXX
TX5N42TXV Kit XXX
GSX13
Model Description GSX13
018 GSX13 024 GSX13 030 GSX13 036 GSX13 042 GSX13 0418 GSX13 060
ASC01Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-start Kit X X X X
CSR-U-2 Hard-start Kit X X X X
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
TX2N4³ TXV Kit X
TX3N42TXVKit XXX
TX5N42TXV Kit XXX
SSX14
Model Description SSX14
018 SSX14 024 SSX14 030 SSX14 036 SSX14 042 SSX14 048 SSX14 060
ASC01Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-start Kit X X X X
CSR-U-2 Hard-start Kit X X X X
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
TX2N4³ TXV Kit X
TX3N42TXVKit XXX
TX5N42TXV Kit XXX
ASX14
Model Description ASX14
018 ASX14 024 ASX14 030 ASX14 036 ASX14 042 ASX14 048 ASX14 060
ASC01 Anti-Short Cycle Kit XXXXXXX
CSR-U-1 Hard-start Kit XXXX
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit XXX
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of

15
ACCESSORIES
DSX/SSX16
ASX16
Model Description D/SSX16
024 D/SSX16 030 D/SSX16 036 D/SSX16 042 D/SSX16 048 D/SSX16 060
ASC01 Anti-Short Cycle Kit XXXXXX
CSR-U-1 Hard-start Kit XXX
CSR-U-2 Hard-start Kit X X X X
CSR-U-3 Hard-start Kit XX
FSK01A1Freeze Protection Kit X X X X X X
TX2N4³ TXV Kit X
TX3N4³ TXV Kit XX
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of
start-assist components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering
device.
Model Description ASX16
024 ASX16 030 ASX16 036 ASX16 042 ASX16 048 ASX16 060
ASC01 Anti-Short Cycle Kit XXXXXX
CSR-U-1 Hard-start Kit XXX
CSR-U-2 Hard-start Kit X X X X
CSR-U-3 Hard-start Kit XX
FSK01A1Freeze Protection Kit X X X X X X
TX2N4³ TXV Kit X
TX3N4³ TXV Kit XX
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°Fwith 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of
start-assist componentswhen usedin conjunctionwithan indoor coilusing a non-bleedthermal expansion valverefrigerant metering
device.

ACCESSORIES
16
ASX18
Model Description ASX18
036 ASX18 048 ASX18 060
ASC01 Anti-Short Cycle Kit XXX
CSR-U-1 Hard-start Kit X
CSR-U-2 Hard-start Kit XXX
CSR-U-3 Hard-start Kit XX
FSK01A1Freeze Protection Kit XXX
TX2N4³ TXV Kit
TX3N4³ TXV Kit X
TX5N4³ TXV Kit XX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of
start-assist components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering
device.

17
ACCESSORIES
ASZ13
Model Description ASZ13
018 ASZ13 024 ASZ13 030 ASZ13 036 ASZ13 042 ASZ13 048 ASZ13 060
AFE18-60A All-FuelKit XXXXXXX
ASC01 Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-start Kit X X X X
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
OT/EHR18-60 Emergency Heat Relay kit X X X X X X X
OT18-60A² Outdoor Thermostat w/ Lockout Stat X X X X X X X
TX2N4³ TXV Kit X
TX3N4³ TXVKit XXX
TX5N4³ TXV Kit XXX
GSZ13
Model Description GSZ13
018 GSZ13 024 GSZ13 030 GSZ13 036 GSZ13 042 GSZ13 048 GSZ13 060
AFE18-60A All-FuelKit XXXXXXX
ASC01 Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-start Kit X X X X
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
OT/EHR18-60 Emergency Heat Relay kit X X X X X X X
OT18-60A² Outdoor Thermostat w/ Lockout Stat X X X X X X X
TX2N4³ TXV Kit X
TX3N4³ TXVKit XXX
TX5N4³ TXV Kit XXX
SSZ14
Model Description SSZ14
018 SSZ14 024 SSZ14 030 SSZ14 036 SSZ14 042 SSZ14 048 SSZ14 060
AFE18-60A All-FuelKit XXXXXXX
ASC01 Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-start Kit X X X X
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
OT18-60A2OutdoorThermostat XXXXXXX
OY-EHR18-60EmergencyHeatRelatKit XXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXVKit XXX
TX5N4³ TXV Kit XXX
ASZ14
Model Description ASZ14
018 ASZ14 024 ASZ14 030 ASZ14 036 ASZ14 042 ASZ14 048 ASZ14 060
AFE18-60A All-FuelKit XXXXXXX
ASC01 Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-start Kit X X X X
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
OT18-60A2OutdoorThermostat XXXXXXX
OY-EHR18-60EmergencyHeatRelatKit XXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXVKit XXX
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Condensing units and heatp pumps with reciprocating compressors require the use of start-assist components when used in conjunction with an indoor coil using a

ACCESSORIES
18
DSZ/SSZ16
ASZ16
Model Description D/SSZ16
024 D/SSZ16 030 D/SSZ16 036 D/SSZ16 042 D/SSZ16 048 D/SSZ16 060
AFE18-60A All-Fuel Kit X X X X X X
ASC01 Anti-Short Cycle Kit X X X X X X
CSR-U-1 Hard-start Kit X X X
CSR-U-2 Hard-start Kit X X X X
CSR-U-3 Hard-start Kit XX
FSK01A1Freeze Protection Kit X X X X X X
OT/EHR18-60 Emergency Heat Relay Kit X X X X X X
OY/EH R18-60 Emergency HeatRelay Kit X X X X X X
OT18-60A² Outdoor Thermostat w/ Lockout Stat X X X X X X
TX2N4³ TXV Kit X
TX3N4³ TXV Kit X X
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Field-installed, non-bleed, expansion valve kit — Condensing unitsand heat pumps with reciprocating compressorsrequire the use of start-assist
components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering device.
Model Description ASZ16
024 ASZ16 030 ASZ16 036 ASZ16 042 ASZ16 048 ASZ16 060
AFE18-60A All-FuelKit XXXXXX
ASC01 Anti-ShortCycleKit XXXXXX
CSR-U-1 Hard-start Kit X X X
CSR-U-2 Hard-startKit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXX
OT/EHR18-60EmergencyHeatRelayKit XXXXXX
OY/EH R18-60 Emergency HeatRelay Kit X X X X X X
OT18-60A² OutdoorThermostat w/ Lockout Stat X X X X X X
TX2N4³ TXV Kit X
TX3N4³ TXV Kit X X
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of start-assist
components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering device.

19
ACCESSORIES
ASZ18
Model Description ASZ18
036 ASZ18 048 ASZ18 060
AFE18-60A All-Fuel Kit X X X
ASC01 Anti-Short Cycle Kit X X X
CSR-U-1 Hard-start Kit X
CSR-U-2 Hard-start Kit X X X
CSR-U-3 Hard-start Kit X X
FSK01A1Freeze Protection Kit X X X
OT/EHR18-60 Emergency Heat Relay Kit X X X
OY/EH R18-60 Emergency Heat Relay Kit X X X
OT18-60A² Outdoor Thermostat w/ Lockout Stat X X X
TX2N4³ TXV Kit
TX3N4³ TXV Kit X
TX5N4³ TXV Kit X X
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of start-assist
components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering device.

ACCESSORIES
20
SUCTION LINE BULB
1/4 FLARE CONNECTION
EXPANSION VALVE
EVAPORATOR COIL
REMOVE BEFORE INSTALLING EXPANSION VALVE
SEAL SUPPLIED W/ KIT
SEAL SUPPLIED W/ KIT
BULB TO BE LOCATED
AT 10 OR 2 O'CLOCK
ForApplicationsrequiring
afieldinstalledaccessfitting
TAILPIECE
3/8"-
SWEAT
7/8" NUT
DISTRIBUTOR
BODY
PISTON
SEAL
EVAPORATOR COIL
1/4' FLARE
CONNECTION
BULB SUCTION LINE
EXPANSION VALVE
REMOVE BEFORE
INSTALLING
EXPANSION VALVE
SEAL SUPPLIED W/ KIT
SEAL SUPPLIED W/ KIT
BULB TOBE LOCATED
AT 10 OR 2 O'CLOCK
TAILPIECE
3/8"-
SWEAT
7/8" NUT
DISTRIBUTOR
BODY
PISTON
SEAL
For Applications not requiring
afieldinstalledaccessfitting
EXPANSIONVALVEKITS
OT/EHR18-60
OUTDOORTHERMOSTAT&
EMERGENCYHEATRELAY
Set Point
A
djustment
Screw Set Point
Indicator
Mark
(Shown @ Oº F)
Thermostat
Dial
DEAD
DIAL
315º
45º
COLD (Turn Clockwise)
WARM (Turn Counterclockwise)
OT18-60
