Goodman SS-GSH10C User manual

SS-GSH10C www.goodmanmfg.com 6/11
Supersedes 1/10
11 EER Split SyStEm
HEat pump
7½ to 10 tonS
GSH10 CommERCial
Standard Features
• Energy-efcientcompressorwithinternalpressure
reliefvalve
• High-capacity,steel-cased,bi-owheatpump
lterdryer
• Factory-installedsuctionlineaccumulator
• Liquidrefrigerantreturnprotection
• Checkowraterheatingmodeexpansiondevice
• Reliable,time-initiated,temperature-terminated
defrostcontrol
• Low-pressureswitch
• Dischargelinemufer
• Brassliquidandsuctionlineservicevalvesmounted
ata90°anglewithsweatconnectionsandserviceports
• High-efciencycoppertube/aluminumncoil
• ComplieswithASHRAEStandard90.1
• ETLListed
Cabinet Features
• Goodmanbrandsoundcontroltopdesign
• Steellouvercoilguardprotectscoilfromdamage
andaddsstrengthtotheunit
• Heavy-gauge,galvanized-steelcabinet
• AttractiveArchitecturalGraypowder-paint
nishwith500-hoursalt-sprayapproval
• Whenproperlyanchored,meetsthe2001FloridaBuilding
Codeunitintegrityrequirementsforhurricane-typewinds
(Anchorbracketkitsavailable.)
*Completewarrantydetailsavailablefromyourlocaldealerorat
www.goodmanmfg.com.
Contents
Nomenclature....................................................................2
ProductSpecications.......................................................3
ExpandedCoolingData.....................................................4
ExpandedHeatingData...................................................10
WiringDiagram................................................................11
Dimensions......................................................................12
Accessories.......................................................................12

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
2 www.goodmanmfg.com SS-GSH10C
nomEnClatuRE

Brand Engineering*
G Goodman®brand MinorRevision
Engineering*
ProductCategory MajorRevision
SSplitSystem
Electrical
UnitType 3=208/230V,3Phase,60Hz
C CondenserR22
H HeatPumpR22
NominalCapacity
Efficiency 090 7½Tons 12010Tons
10 11EER
* Neitherusedfororderentry
orinventorymanagement.
11
A
S
2
120
6,7,8
10
4,5
9
3
10
1
G
H
3
A

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
SS-GSH10C www.goodmanmfg.com 3
SpECifiCationS
GSH10
0903A*
GSH10
0903B*
GSH10
1203A*

Cooling (BTU/h) 87,000 90,000 110,000
Heang (BTU/h) 84,000 84,000 100,000
EER/IEER 11/-- 11/11 11/11.5
Decibels 76 76 77

RLA 25.6 25.6 30.1
LRA 196 196 225

Horsepower 1 1 1
FLA 5.6 5.6 5.6

Liquid Valve Size (“O.D.) ⅝" ⅝" ⅝"
Sucon Valve Size (“O.D.) (7½ tons) 1⅜" 1⅜" 1⅜"
Sucon Valve Size (“O.D.) (10 tons) 1⅝" 1⅝" 1⅝"
Valve Type Sweat Sweat Sweat

Voltage/Phase 208-230/3 208-230/3 208-230/3
Minimum Circuit Ampacity¹ 37.6 37.6 43.2
Max. Overcurrent Protecon² 60 60 70
Min / Max Volts 197/253 197/253 197/253
Electrical Conduit Size ½" or ¾" ½" or ¾" ½" or ¾"
 254 254 315
¹ Wire size should be determined in accordance with Naonal Electrical Codes; extensive wire runs will require
larger wire sizes
² May use fuses or HACR type Circuit Breakers of the same size as noted

• Always check the S&R plate for electrical data on the unit being installed.
• Installer will need to supply 1⅛” to 1⅜” or 1⅛” to 1⅝” as appropriate.
• Unit charge with dry nitrogen/helium; must safely dispel holding charge from unit. Evacuate and charge with
R-22 per Installaon Manual.
• Installaon of these units requires the specied TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS
DETERMINED BY THE OUTDOOR UNIT NOT THE INDOOR COIL.

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
4 www.goodmanmfg.com SS-GSH10C
ExpandEd CoolinG data — GSH100903a* / aR090

     

  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
3240
MBh 85.3 88.4 96.8 - 83.3 86.3 94.6 - 81.3 84.3 92.3 - 79.3 82.2 90.1 - 75.3 78.1 85.6 - 69.8 72.3 79.3 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -
∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
kW 6.80 6.93 7.14 - 7.29 7.44 7.67 - 7.73 7.89 8.13 - 8.11 8.28 8.54 - 8.44 8.62 8.89 - 8.72 8.90 9.19 -
Amps 15.7 16.1 16.6 - 17.0 17.4 18.0 - 18.4 18.9 19.5 - 19.7 20.2 20.9 - 21.0 21.5 22.3 - 22.3 22.8 23.6 -
Hi PR 153 164 174 - 171 185 195 - 195 210 222 - 222 239 252 - 250 269 284 - 276 297 314 -
Lo PR 57 61 66 - 60 64 70 - 62 66 73 - 66 70 76 - 69 73 80 - 71 76 83 -
2880
MBh 82.8 85.8 94.0 - 80.8 83.8 91.8 - 78.9 81.8 89.6 - 77.0 79.8 87.4 - 73.1 75.8 83.1 - 67.8 70.2 76.9 -
S/T 0.70 0.58 0.40 - 0.72 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.66 0.46 - 0.80 0.67 0.46 -
∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
kW 6.75 6.88 7.09 - 7.23 7.38 7.61 - 7.67 7.82 8.07 - 8.05 8.22 8.47 - 8.37 8.55 8.82 - 8.65 8.83 9.11 -
Amps 15.5 15.9 16.4 - 16.8 17.2 17.8 - 18.3 18.7 19.4 - 19.5 20.0 20.7 - 20.8 21.3 22.1 - 22.1 22.6 23.4 -
Hi PR 151 163 172 - 170 183 193 - 193 208 219 - 220 237 250 - 247 266 281 - 273 294 311 -
Lo PR 56 60 65 - 60 63 69 - 62 66 72 - 65 69 75 - 68 72 79 - 70 75 82 -
2520
MBh 76.4 79.2 86.8 - 74.6 77.3 84.7 - 72.8 75.5 82.7 - 71.1 73.7 80.7 - 67.5 70.0 76.7 - 62.5 64.8 71.0 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -
∆T 19 16 12 - 19 16 12 - 19 16 13 - 19 17 13 - 19 16 12 - 18 15 12 -
kW 6.60 6.73 6.92 - 7.07 7.21 7.43 - 7.49 7.64 7.88 - 7.86 8.02 8.27 - 8.17 8.34 8.60 - 8.44 8.62 8.89 -
Amps 15.1 15.5 16.0 - 16.3 16.7 17.3 - 17.8 18.2 18.8 - 19.0 19.5 20.1 - 20.2 20.7 21.4 - 21.5 22.0 22.7 -
Hi PR 147 158 167 - 165 177 187 - 187 202 213 - 213 230 242 - 240 258 273 - 265 285 301 -
Lo PR 55 58 63 - 58 61 67 - 60 64 70 - 63 67 73 - 66 70 77 - 68 73 79 -
75
3240
MBh 86.70 89.26 96.62 103.7 84.68 87.19 94.37 101.29 82.67 85.11 92.13 98.88 80.65 83.04 89.88 96.46 76.62 78.88 85.38 91.64 70.97 73.07 79.09 84.89
S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42
∆T 21 19 15 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
kW 6.85 6.99 7.19 7.41 7.35 7.50 7.73 7.97 7.79 7.95 8.20 8.45 8.17 8.35 8.61 8.89 8.50 8.69 8.96 9.25 8.79 8.98 9.26 9.57
Amps 15.8 16.2 16.7 17.4 17.1 17.5 18.1 18.8 18.6 19.1 19.7 20.5 19.9 20.4 21.1 21.9 21.2 21.7 22.5 23.3 22.5 23.1 23.8 24.8
Hi PR 154 166 175 183 173 186 197 205 197 212 224 233 224 241 255 266 252 272 287 299 279 300 317 331
Lo PR 57 61 67 71 61 65 71 75 63 67 73 78 66 71 77 82 69 74 81 86 72 76 83 89
2880
MBh 84.2 86.7 93.8 100.7 82.2 84.6 91.6 98.3 80.3 82.6 89.4 96.0 78.3 80.6 87.3 93.7 74.4 76.6 82.9 89.0 68.9 70.9 76.8 82.4
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.82 0.62 0.40
∆T 21 20 16 11 22 20 16 11 22 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10
kW 6.80 6.93 7.14 7.36 7.29 7.44 7.67 7.90 7.73 7.89 8.13 8.39 8.11 8.28 8.54 8.81 8.44 8.62 8.89 9.18 8.72 8.91 9.19 9.49
Amps 15.7 16.1 16.6 17.2 17.0 17.4 18.0 18.6 18.4 18.9 19.5 20.3 19.7 20.2 20.9 21.7 21.0 21.5 22.3 23.1 22.3 22.8 23.6 24.5
Hi PR 153 164 174 181 172 185 195 203 195 210 222 231 222 239 252 263 250 269 284 296 276 297 314 327
Lo PR 57 61 66 70 60 64 70 74 62 66 73 77 66 70 76 81 69 73 80 85 71 76 83 88
2520
MBh 77.7 80.0 86.6 92.9 75.9 78.1 84.6 90.8 74.1 76.3 82.6 88.6 72.3 74.41 80.5 86.4 68.7 70.7 76.5 82.1 63.6 65.5 70.9 76.1
S/T 0.77 0.69 0.52 0.33 0.79 0.71 0.54 0.35 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38
∆T 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 16 11 20 19 15 11
kW 6.65 6.78 6.98 7.19 7.12 7.27 7.49 7.72 7.55 7.70 7.94 8.19 7.92 8.08 8.34 8.60 8.24 8.41 8.67 8.95 8.51 8.69 8.97 9.26
Amps 15.3 15.6 16.1 16.7 16.5 16.9 17.5 18.1 17.9 18.4 19.0 19.7 19.2 19.7 20.3 21.1 20.4 20.9 21.6 22.5 21.7 22.2 22.9 23.8
Hi PR 148 160 168 176 166 179 189 197 189 204 215 224 215 232 245 255 242 261 275 287 268 288 304 317
Lo PR 55 59 64 68 58 62 68 72 61 64 70 75 64 68 74 79 67 71 77 83 69 73 80 85
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
SS-GSH10C www.goodmanmfg.com 5
ExpandEd CoolinG data — GSH100903a* / aR090 (Cont.)

     

  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
3240
MBh 88.24 90.17 96.33 102.98 86.19 88.07 94.09 100.58 84.13 85.97 91.85 98.19 82.08 83.87 89.61 95.79 77.98 79.68 85.13 91.00 72.23 73.81 78.86 84.30
S/T 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 1.00 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.80 0.60
∆T 23 22 19 15 23 22 19 15 24 22 19 15 23 22 19 16 22 23 19 15 20 21 18 14
kW 6.90 7.04 7.25 7.47 7.40 7.56 7.79 8.03 7.85 8.01 8.26 8.52 8.24 8.41 8.68 8.96 8.57 8.76 9.03 9.33 8.86 9.05 9.34 9.65
Amps 16.0 16.4 16.9 17.5 17.3 17.7 18.3 19.0 18.8 19.3 19.9 20.7 20.1 20.6 21.3 22.1 21.4 21.9 22.7 23.6 22.7 23.3 24.1 25.0
Hi PR 156 168 177 185 175 188 199 207 199 214 226 236 227 244 258 269 255 274 290 302 282 303 320 334
Lo PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 82 87 73 77 84 90
2880
MBh 85.7 87.5 93.5 100.0 83.7 85.5 91.4 97.7 81.7 83.5 89.2 95.3 79.7 81.4 87.0 93.0 75.7 77.4 82.7 88.4 70.1 71.7 76.6 81.8
S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57
∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 19 15
kW 6.85 6.99 7.20 7.41 7.35 7.50 7.73 7.97 7.79 7.95 8.20 8.46 8.18 8.35 8.61 8.89 8.51 8.69 8.96 9.25 8.79 8.98 9.27 9.57
Amps 15.8 16.2 16.7 17.4 17.1 17.5 18.1 18.8 18.6 19.1 19.7 20.5 19.9 20.4 21.1 21.9 21.2 21.7 22.5 23.3 22.5 23.1 23.8 24.8
Hi PR 154 166 175 183 173 186 197 205 197 212 224 234 224 241 255 266 252 272 287 299 279 300 317 331
Lo PR 57 61 67 71 61 65 71 75 63 67 73 78 66 71 77 82 69 74 81 86 72 76 83 89
2520
MBh 79.1 80.8 86.3 92.3 77.2 78.9 84.3 90.1 75.4 77.0 82.3 88.0 73.6 75.2 80.3 85.8 69.9 71.4 76.3 81.5 64.7 66.1 70.7 75.5
S/T 0.84 0.79 0.64 0.48 0.87 0.82 0.67 0.50 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.53 0.96 0.90 0.73 0.55 0.97 0.91 0.74 0.55
∆T 24 23 20 16 25 24 20 16 25 24 20 16 25 24 21 16 24 23 20 16 23 22 19 15
kW 6.70 6.83 7.03 7.24 7.18 7.32 7.55 7.78 7.61 7.76 8.00 8.25 7.98 8.15 8.40 8.67 8.30 8.48 8.74 9.03 8.58 8.76 9.04 9.33
Amps 15.4 15.8 16.3 16.9 16.7 17.1 17.6 18.3 18.1 18.5 19.2 19.9 19.4 19.8 20.5 21.3 20.6 21.1 21.8 22.7 21.9 22.4 23.2 24.1
Hi PR 150 161 170 177 168 181 191 199 191 206 217 227 218 234 247 258 245 264 278 290 271 291 307 321
Lo PR 56 59 65 69 59 63 68 73 61 65 71 76 64 68 75 80 67 72 78 83 70 74 81 86
85
3240
MBh 89.78 91.52 95.85 102.26 87.69 89.39 93.62 99.88 85.60 87.26 91.39 97.50 83.52 85.13 89.16 95.12 79.34 80.88 84.70 90.37 73.49 74.92 78.46 83.71
S/T 0.96 0.92 0.83 0.68 0.99 0.96 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78
∆T 24 24 23 20 25 24 23 20 24 24 23 20 24 24 23 20 23 23 23 20 21 21 21 18
kW 6.95 7.09 7.31 7.53 7.46 7.61 7.85 8.09 7.91 8.07 8.33 8.59 8.31 8.48 8.75 9.03 8.64 8.83 9.11 9.40 8.93 9.12 9.42 9.73
Amps 16.1 16.5 17.1 17.7 17.4 17.9 18.5 19.2 19.0 19.4 20.1 20.9 20.3 20.8 21.5 22.3 21.6 22.2 22.9 23.8 22.9 23.5 24.3 25.2
Hi PR 157 169 179 187 177 190 201 209 201 216 228 238 229 246 260 271 258 277 293 305 285 306 323 337
Lo PR 59 62 68 73 62 66 72 77 64 68 75 80 68 72 79 84 71 75 82 88 73 78 85 91
2880
MBh 87.2 88.9 93.1 99.3 85.1 86.8 90.9 97.0 83.1 84.7 88.7 94.7 81.1 82.7 86.6 92.4 77.0 78.5 82.2 87.7 71.4 72.7 76.2 81.3
S/T 0.91 0.88 0.80 0.65 0.95 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.91 0.74
∆T 25 25 24 20 26 25 24 21 26 25 24 21 26 26 24 21 25 25 24 21 23 23 22 19
kW 6.90 7.04 7.25 7.47 7.40 7.56 7.79 8.03 7.85 8.01 8.26 8.52 8.24 8.41 8.68 8.96 8.57 8.76 9.03 9.33 8.86 9.05 9.34 9.65
Amps 16.0 16.4 16.9 17.5 17.3 17.7 18.3 19.0 18.8 19.3 19.9 20.7 20.1 20.6 21.3 22.1 21.4 21.9 22.7 23.6 22.7 23.3 24.1 25.0
Hi PR 156 168 177 185 175 188 199 207 199 214 226 236 227 244 258 269 255 274 290 302 282 303 320 334
Lo PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 82 87 73 77 84 90
2520
MBh 80.5 82.0 85.9 91.6 78.6 80.1 83.9 89.5 76.7 78.2 81.9 87.4 74.8 76.3 79.9 85.2 71.1 72.5 75.9 81.0 65.9 67.1 70.3 75.0
S/T 0.88 0.85 0.77 0.62 0.91 0.88 0.80 0.65 0.94 0.90 0.82 0.66 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 0.98 0.88 0.71
∆T 26 25 24 21 26 26 24 21 26 26 24 21 26 26 25 21 26 26 24 21 24 24 23 20
kW 6.75 6.88 7.08 7.30 7.23 7.38 7.60 7.84 7.66 7.82 8.06 8.32 8.04 8.21 8.47 8.74 8.37 8.54 8.81 9.10 8.65 8.83 9.11 9.41
Amps 15.5 15.9 16.4 17.1 16.8 17.2 17.8 18.5 18.3 18.7 19.3 20.1 19.5 20.0 20.7 21.5 20.8 21.3 22.1 22.9 22.1 22.6 23.4 24.3
Hi PR 151 163 172 179 170 183 193 201 193 208 219 229 220 237 250 261 247 266 281 293 273 294 311 324
Lo PR 56 60 65 70 59 63 69 74 62 66 72 76 65 69 75 80 68 72 79 84 70 75 82 87
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
6 www.goodmanmfg.com SS-GSH10C
ExpandEd CoolinG data — GSH100903B* / aR090

     

  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
3000
MBh 84.9 88.0 96.4 - 82.9 86.0 94.2 - 81.0 83.9 92.0 - 79.0 81.9 89.7 - 75.0 77.8 85.2 - 69.5 72.1 78.9 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.64 0.45 -
∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
kW 6.23 6.35 6.54 - 6.67 6.81 7.01 - 7.07 7.21 7.43 - 7.42 7.57 7.81 - 7.71 7.87 8.12 - 7.97 8.14 8.39 -
Amps 19.0 19.4 20.0 - 20.4 20.8 21.4 - 22.0 22.5 23.1 - 23.3 23.9 24.6 - 24.7 25.3 26.1 - 26.1 26.7 27.5 -
HI PR 143 154 162 - 160 172 182 - 182 196 207 - 207 223 236 - 233 251 265 - 258 277 293 -
LO PR 55 59 64 - 59 62 68 - 61 65 71 - 64 68 74 - 67 71 78 - 69 74 81 -
3049
MBh 85.8 88.9 97.4 - 83.8 86.8 95.1 - 81.8 84.8 92.9 - 79.8 82.7 90.6 - 75.8 78.6 86.1 - 70.2 72.8 79.7 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -
∆T 18 15 12 - 18 15 12 - 18 15 12 - 18 16 12 - 18 15 12 - 17 14 11 -
kW 6.29 6.41 6.60 - 6.74 6.88 7.08 - 7.14 7.29 7.51 - 7.49 7.65 7.89 - 7.79 7.96 8.21 - 8.05 8.22 8.48 -
Amps 19.2 19.6 20.2 - 20.6 21.0 21.7 - 22.2 22.7 23.4 - 23.6 24.1 24.9 - 25.0 25.6 26.3 - 26.4 27.0 27.8 -
HI PR 145 156 164 - 162 175 184 - 185 199 210 - 210 226 239 - 236 254 269 - 261 281 297 -
LO PR 56 60 65 - 59 63 69 - 62 66 72 - 65 69 75 - 68 72 79 - 70 75 82 -
3200
MBh 85.8 88.9 97.4 - 83.8 86.8 95.1 - 81.8 84.8 92.9 - 79.8 82.7 90.6 - 75.8 78.6 86.1 - 70.2 72.8 79.7 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -
∆T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
kW 6.29 6.41 6.60 - 6.74 6.88 7.08 - 7.14 7.29 7.51 - 7.49 7.65 7.89 - 7.79 7.96 8.21 - 8.05 8.22 8.48 -
Amps 19.2 19.6 20.2 - 20.6 21.0 21.7 - 22.2 22.7 23.4 - 23.6 24.1 24.9 - 25.0 25.6 26.3 - 26.4 27.0 27.8 -
HI PR 145 156 164 - 162 175 184 - 185 199 210 - 210 226 239 - 236 254 269 - 261 281 297 -
LO PR 56 60 65 - 59 63 69 - 62 66 72 - 65 69 75 - 68 72 79 - 70 75 82 -
75
3000
MBh 86.4 88.9 96.2 103.3 84.4 86.9 94.0 100.9 82.3 84.8 91.8 98.5 80.3 82.7 89.5 96.1 76.3 78.6 85.1 91.3 70.7 72.8 78.8 84.6
S/T 0.76 0.68 0.52 0.33 0.79 0.71 0.54 0.34 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.78 0.59 0.38
∆T 20 19 15 11 20 19 15 11 20 19 15 11 21 19 16 11 20 19 15 11 19 18 14 10
kW 6.27 6.40 6.59 6.78 6.72 6.86 7.07 7.29 7.12 7.27 7.49 7.73 7.47 7.63 7.87 8.12 7.77 7.94 8.19 8.45 8.03 8.20 8.46 8.74
Amps 19.2 19.6 20.1 20.8 20.5 21.0 21.6 22.4 22.2 22.6 23.3 24.1 23.5 24.1 24.8 25.7 24.9 25.5 26.3 27.2 26.3 26.9 27.7 28.7
HI PR 144 155 164 171 162 174 184 192 184 198 209 218 210 226 238 248 236 254 268 279 260 280 296 309
LO PR 56 60 65 69 59 63 69 73 62 65 71 76 65 69 75 80 68 72 79 84 70 75 81 87
3049
MBh 87.2 89.8 97.2 104.3 85.2 87.7 95.0 101.9 83.2 85.6 92.7 99.5 81.1 83.6 90.4 97.1 77.1 79.4 85.9 92.2 71.4 73.5 79.6 85.4
S/T 0.77 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.82 0.73 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.79 0.60 0.38 0.89 0.79 0.60 0.39
∆T 20 19 15 11 21 19 16 11 21 19 16 11 21 19 16 11 20 19 15 11 19 18 14 10
kW 6.33 6.46 6.65 6.85 6.79 6.93 7.14 7.36 7.20 7.34 7.57 7.81 7.55 7.71 7.95 8.20 7.85 8.02 8.27 8.54 8.12 8.29 8.55 8.83
Amps 19.4 19.8 20.4 21.0 20.8 21.2 21.9 22.6 22.4 22.9 23.6 24.4 23.8 24.3 25.1 26.0 25.2 25.8 26.6 27.5 26.6 27.2 28.1 29.1
HI PR 146 157 166 173 164 176 186 194 186 201 212 221 212 228 241 252 239 257 271 283 264 284 300 313
LO PR 57 60 66 70 60 64 70 74 62 66 72 77 65 70 76 81 69 73 80 85 71 75 82 88
3200
MBh 87.2 89.8 97.2 104.3 85.2 87.7 95.0 101.9 83.2 85.6 92.7 99.5 81.1 83.6 90.4 97.1 77.1 79.4 85.9 92.2 71.4 73.5 79.6 85.4
S/T 0.77 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.82 0.73 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.79 0.60 0.38 0.89 0.79 0.60 0.39
∆T 19 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 19 18 15 10 18 17 14 9
kW 6.33 6.46 6.65 6.85 6.79 6.93 7.14 7.36 7.20 7.34 7.57 7.81 7.55 7.71 7.95 8.20 7.85 8.02 8.27 8.54 8.12 8.29 8.55 8.83
Amps 19.4 19.8 20.4 21.0 20.8 21.2 21.9 22.6 22.4 22.9 23.6 24.4 23.8 24.3 25.1 26.0 25.2 25.8 26.6 27.5 26.6 27.2 28.1 29.1
HI PR 146 157 166 173 164 176 186 194 186 201 212 221 212 228 241 252 239 257 271 283 264 284 300 313
LO PR 57 60 66 70 60 64 70 74 62 66 72 77 65 70 76 81 69 73 80 85 71 75 82 88
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
SS-GSH10C www.goodmanmfg.com 7
ExpandEd CoolinG data — GSH100903B* / aR090 (Cont.)

     

  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
3000
MBh 87.9 89.8 96.0 102.6 85.9 87.7 93.7 100.2 83.8 85.6 91.5 97.8 81.8 83.6 89.3 95.4 77.7 79.4 84.8 90.7 72.0 73.5 78.6 84.0
S/T 0.84 0.79 0.64 0.48 0.87 0.81 0.66 0.50 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.96 0.90 0.73 0.55
∆T 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 20 18 14
kW 6.32 6.45 6.64 6.84 6.78 6.91 7.12 7.34 7.18 7.33 7.55 7.79 7.53 7.69 7.93 8.18 7.84 8.00 8.25 8.52 8.10 8.27 8.53 8.81
Amps 19.3 19.7 20.3 21.0 20.7 21.2 21.8 22.5 22.3 22.8 23.5 24.3 23.7 24.3 25.0 25.9 25.1 25.7 26.5 27.4 26.5 27.1 28.0 29.0
HI PR 146 157 165 173 163 176 186 194 186 200 211 220 212 228 241 251 238 256 271 282 263 283 299 312
LO PR 57 60 66 70 60 64 69 74 62 66 72 77 65 69 76 81 68 73 79 85 71 75 82 88
3049
MBh 88.8 90.7 96.9 103.6 86.7 88.6 94.7 101.2 84.7 86.5 92.4 98.8 82.6 84.4 90.2 96.4 78.5 80.2 85.7 91.6 72.7 74.3 79.3 84.8
S/T 0.85 0.79 0.65 0.48 0.88 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.74 0.55 0.97 0.91 0.74 0.55
∆T 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 20 18 14
kW 6.38 6.51 6.70 6.91 6.84 6.98 7.20 7.42 7.25 7.40 7.63 7.87 7.61 7.77 8.02 8.27 7.92 8.09 8.34 8.61 8.18 8.36 8.62 8.90
Amps 19.5 19.9 20.5 21.2 20.9 21.4 22.0 22.8 22.6 23.1 23.8 24.6 24.0 24.5 25.3 26.2 25.4 26.0 26.8 27.8 26.8 27.4 28.3 29.3
HI PR 148 159 168 175 166 178 188 196 188 203 214 223 214 231 244 254 241 260 274 286 267 287 303 316
LO PR 57 61 67 71 61 64 70 75 63 67 73 78 66 70 77 82 69 74 80 86 72 76 83 89
3200
MBh 88.8 90.7 96.9 103.6 86.7 88.6 94.7 101.2 84.7 86.5 92.4 98.8 82.6 84.4 90.2 96.4 78.5 80.2 85.7 91.6 72.7 74.3 79.3 84.8
S/T 0.85 0.79 0.65 0.48 0.88 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.74 0.55 0.97 0.91 0.74 0.55
∆T 22 21 18 14 22 21 18 15 22 21 18 15 22 21 18 15 22 21 18 14 20 19 17 14
kW 6.38 6.51 6.70 6.91 6.84 6.98 7.20 7.42 7.25 7.40 7.63 7.87 7.61 7.77 8.02 8.27 7.92 8.09 8.34 8.61 8.18 8.36 8.62 8.90
Amps 19.5 19.9 20.5 21.2 20.9 21.4 22.0 22.8 22.6 23.1 23.8 24.6 24.0 24.5 25.3 26.2 25.4 26.0 26.8 27.8 26.8 27.4 28.3 29.3
HI PR 148 159 168 175 166 178 188 196 188 203 214 223 214 231 244 254 241 260 274 286 267 287 303 316
LO PR 57 61 67 71 61 64 70 75 63 67 73 78 66 70 77 82 69 74 80 86 72 76 83 89
85
3000
MBh 89.4 91.2 95.5 101.9 87.4 89.0 93.3 99.5 85.3 86.9 91.0 97.1 83.2 84.8 88.8 94.8 79.0 80.6 84.4 90.0 73.2 74.6 78.2 83.4
S/T 0.88 0.85 0.77 0.62 0.91 0.88 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 0.97 0.88 0.71
∆T 24 24 22 19 24 24 23 20 24 24 23 20 25 24 23 20 24 24 23 19 22 22 21 18
kW 6.37 6.49 6.69 6.89 6.83 6.97 7.18 7.40 7.23 7.38 7.61 7.85 7.59 7.75 7.99 8.25 7.90 8.07 8.32 8.59 8.16 8.34 8.60 8.88
Amps 19.5 19.9 20.5 21.2 20.9 21.3 22.0 22.7 22.5 23.0 23.7 24.5 23.9 24.5 25.2 26.1 25.4 25.9 26.7 27.7 26.8 27.4 28.2 29.2
HI PR 147 158 167 174 165 178 188 196 188 202 213 222 214 230 243 253 241 259 273 285 266 286 302 315
LO PR 57 61 66 71 60 64 70 75 63 67 73 78 66 70 77 82 69 73 80 85 71 76 83 88
3049
MBh 90.3 92.1 96.4 102.9 88.2 89.9 94.2 100.5 86.1 87.8 92.0 98.1 84.0 85.7 89.7 95.7 79.8 81.4 85.2 90.9 73.9 75.4 78.9 84.2
S/T 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.98 0.88 0.71 1.00 0.98 0.89 0.72
∆T 24 24 22 19 24 24 23 20 25 24 23 20 25 24 23 20 24 24 23 20 22 22 21 18
kW 6.43 6.56 6.75 6.96 6.90 7.04 7.25 7.48 7.31 7.46 7.69 7.93 7.67 7.83 8.08 8.34 7.98 8.15 8.41 8.68 8.25 8.42 8.69 8.98
Amps 19.7 20.1 20.7 21.4 21.1 21.6 22.2 23.0 22.8 23.3 24.0 24.8 24.2 24.8 25.5 26.4 25.6 26.2 27.0 28.0 27.1 27.7 28.5 29.6
HI PR 149 160 169 177 167 180 190 198 190 205 216 225 217 233 246 257 244 262 277 289 269 290 306 319
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 74 81 87 72 77 84 90
3200
MBh 90.3 92.1 96.4 102.9 88.2 89.9 94.2 100.5 86.1 87.8 92.0 98.1 84.0 85.7 89.7 95.7 79.8 81.4 85.2 90.9 73.9 75.4 78.9 84.2
S/T 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.98 0.88 0.71 1.00 0.98 0.89 0.72
∆T 23 23 21 19 23 23 22 19 23 23 22 19 24 23 22 19 23 23 22 19 21 21 20 17
kW 6.43 6.56 6.75 6.96 6.90 7.04 7.25 7.48 7.31 7.46 7.69 7.93 7.67 7.83 8.08 8.34 7.98 8.15 8.41 8.68 8.25 8.42 8.69 8.98
Amps 19.7 20.1 20.7 21.4 21.1 21.6 22.2 23.0 22.8 23.3 24.0 24.8 24.2 24.8 25.5 26.4 25.6 26.2 27.0 28.0 27.1 27.7 28.5 29.6
HI PR 149 160 169 177 167 180 190 198 190 205 216 225 217 233 246 257 244 262 277 289 269 290 306 319
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 74 81 87 72 77 84 90
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
8 www.goodmanmfg.com SS-GSH10C
ExpandEd CoolinG data — GSH101203a* / aR120

     

  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
4500
MBh 106.8 110.7 121.3 - 104.3 108.1 118.5 - 101.8 105.6 115.7 - 99.4 103.0 112.8 - 94.4 97.8 107.2 - 87.4 90.6 99.3 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
∆T 16 14 10 - 16 14 10 - 16 14 11 - 16 14 11 - 16 14 10 - 15 13 10 -
kW 8.51 8.69 8.95 - 9.14 9.32 9.61 - 9.68 9.89 10.19 - 10.17 10.38 10.71 - 10.58 10.81 11.15 - 10.94 11.17 11.53 -
Amps 18.4 18.8 19.5 - 19.9 20.4 21.1 - 21.7 22.3 23.0 - 23.3 23.8 24.7 - 24.8 25.4 26.3 - 26.3 27.0 27.9 -
Hi PR 138 148 157 - 155 166 176 - 176 189 200 - 200 216 228 - 225 243 256 - 249 268 283 -
Lo PR 61 64 70 - 64 68 74 - 67 71 77 - 70 74 81 - 73 78 85 - 76 81 88 -
4000
MBh 103.7 107.5 117.8 - 101.3 105.0 115.0 - 98.9 102.5 112.3 - 96.5 100.0 109.5 - 91.6 95.0 104.1 - 84.9 88.0 96.4 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.79 0.66 0.46 -
∆T 16 14 11 - 17 14 11 - 17 14 11 - 17 15 11 - 17 14 11 - 15 13 10 -
kW 8.45 8.62 8.88 - 9.07 9.25 9.53 - 9.61 9.81 10.11 - 10.09 10.30 10.63 - 10.50 10.72 11.06 - 10.85 11.08 11.44 -
Amps 18.2 18.7 19.3 - 19.7 20.2 20.9 - 21.5 22.0 22.8 - 23.0 23.6 24.4 - 24.6 25.2 26.1 - 26.1 26.7 27.7 -
Hi PR 136 147 155 - 153 165 174 - 174 187 198 - 198 213 225 - 223 240 254 - 247 265 280 -
Lo PR 60 64 70 - 63 67 74 - 66 70 77 - 69 74 80 - 73 77 84 - 75 80 87 -
3500
MBh 95.7 99.2 108.7 - 93.5 96.9 106.2 - 91.3 94.6 103.6 - 89.0 92.3 101.1 - 84.6 87.7 96.1 - 78.4 81.2 89.0 -
S/T 0.67 0.56 0.38 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.76 0.64 0.44 -
∆T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
kW 8.26 8.42 8.67 - 8.86 9.04 9.31 - 9.38 9.58 9.87 - 9.85 10.06 10.37 - 10.24 10.46 10.79 - 10.59 10.81 11.16 -
Amps 17.7 18.1 18.8 - 19.2 19.7 20.3 - 20.9 21.4 22.2 - 22.4 22.9 23.7 - 23.9 24.5 25.3 - 25.3 26.0 26.9 -
Hi PR 132 142 150 - 149 160 169 - 169 182 192 - 192 207 219 - 216 233 246 - 239 257 272 -
Lo PR 58 62 68 - 61 65 71 - 64 68 74 - 67 71 78 - 70 75 82 - 73 77 84 -
75
4500
MBh 108.62 111.84 121.05 129.92 106.10 109.24 118.24 126.90 103.57 106.63 115.42 123.88 101.04 104.03 112.61 120.86 95.99 98.83 106.98 114.81 88.92 91.55 99.09 106.35
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41
∆T 18 17 14 10 18 17 14 10 18 17 14 10 19 17 14 10 18 17 14 10 17 16 13 9
kW 8.58 8.75 9.02 9.29 9.21 9.40 9.69 9.99 9.76 9.97 10.28 10.60 10.25 10.47 10.80 11.15 10.67 10.90 11.24 11.61 11.03 11.26 11.63 12.01
Amps 18.6 19.0 19.7 20.4 20.1 20.6 21.3 22.1 21.9 22.5 23.2 24.1 23.5 24.1 24.9 25.9 25.0 25.7 26.6 27.6 26.6 27.2 28.2 29.3
Hi PR 139 150 158 165 156 168 178 185 178 191 202 211 202 218 230 240 228 245 259 270 252 271 286 298
Lo PR 61 65 71 76 65 69 75 80 67 71 78 83 71 75 82 87 74 79 86 92 77 81 89 95
4000
MBh 105.5 108.6 117.5 126.1 103.0 106.1 114.8 123.2 100.6 103.5 112.1 120.3 98.1 101.0 109.3 117.3 93.2 96.0 103.9 111.5 86.3 88.9 96.2 103.3
S/T 0.78 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.81 0.61 0.39
∆T 19 18 14 10 19 18 15 10 19 18 15 10 19 18 15 10 19 18 14 10 18 16 13 9
kW 8.52 8.69 8.95 9.22 9.14 9.33 9.61 9.91 9.69 9.89 10.20 10.52 10.17 10.39 10.71 11.06 10.58 10.81 11.15 11.51 10.94 11.17 11.53 11.91
Amps 18.4 18.8 19.5 20.2 19.9 20.4 21.1 21.9 21.7 22.3 23.0 23.9 23.3 23.8 24.7 25.6 24.8 25.4 26.3 27.3 26.3 27.0 27.9 29.0
Hi PR 138 148 157 163 155 166 176 183 176 189 200 209 200 216 228 237 225 243 256 267 249 268 283 295
Lo PR 61 64 70 75 64 68 74 79 67 71 77 82 70 74 81 86 73 78 85 91 76 81 88 94
3500
MBh 97.3 100.2 108.5 116.4 95.1 97.9 106.0 113.7 92.8 95.6 103.4 111.0 90.5 93.23 100.9 108.3 86.0 88.6 95.9 102.9 79.7 82.0 88.8 95.3
S/T 0.76 0.68 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.87 0.78 0.59 0.38
∆T 19 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 19 18 15 10 18 17 14 9
kW 8.32 8.49 8.74 9.01 8.93 9.11 9.39 9.68 9.46 9.65 9.95 10.27 9.93 10.14 10.45 10.79 10.33 10.55 10.88 11.23 10.67 10.90 11.25 11.61
Amps 17.9 18.3 18.9 19.7 19.4 19.8 20.5 21.3 21.1 21.6 22.4 23.2 22.6 23.2 24.0 24.9 24.1 24.7 25.6 26.6 25.6 26.2 27.1 28.2
Hi PR 134 144 152 158 150 161 171 178 171 184 194 202 194 209 221 230 219 235 248 259 242 260 275 286
Lo PR 59 63 68 73 62 66 72 77 65 69 75 80 68 72 79 84 71 76 83 88 73 78 85 91
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
SS-GSH10C www.goodmanmfg.com 9
ExpandEd CoolinG data — GSH101203a* / aR120 (Cont.)

     

  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
4500
MBh 110.55 112.97 120.69 129.02 107.98 110.34 117.88 126.02 105.41 107.71 115.08 123.02 102.84 105.08 112.27 120.02 97.70 99.83 106.66 114.02 90.50 92.47 98.80 105.61
S/T 0.90 0.85 0.69 0.51 0.93 0.88 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.75 0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59
∆T 20 20 17 14 21 20 17 14 21 20 17 14 21 20 17 14 20 20 17 14 18 18 16 13
kW 8.65 8.82 9.09 9.37 9.28 9.47 9.76 10.07 9.84 10.05 10.36 10.69 10.33 10.55 10.89 11.24 10.75 10.98 11.34 11.70 11.12 11.36 11.72 12.11
Amps 18.7 19.2 19.8 20.6 20.3 20.8 21.5 22.4 22.1 22.7 23.5 24.4 23.7 24.3 25.1 26.1 25.3 25.9 26.8 27.9 26.8 27.5 28.5 29.6
Hi PR 141 151 160 167 158 170 179 187 179 193 204 213 204 220 232 242 230 247 261 273 254 273 289 301
Lo PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 80 87 92 77 82 90 96
4000
MBh 107.3 109.7 117.2 125.3 104.8 107.1 114.5 122.3 102.3 104.6 111.7 119.4 99.8 102.0 109.0 116.5 94.9 96.9 103.6 110.7 87.9 89.8 95.9 102.5
S/T 0.86 0.81 0.66 0.49 0.89 0.84 0.68 0.51 0.91 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.75 0.56
∆T 21 20 18 14 21 21 18 14 21 21 18 14 22 21 18 14 21 20 18 14 20 19 17 13
kW 8.58 8.75 9.02 9.29 9.21 9.40 9.69 9.99 9.76 9.97 10.28 10.61 10.25 10.47 10.80 11.15 10.67 10.90 11.24 11.61 11.03 11.26 11.63 12.01
Amps 18.6 19.0 19.7 20.4 20.1 20.6 21.3 22.1 21.9 22.5 23.2 24.1 23.5 24.1 24.9 25.9 25.0 25.7 26.6 27.6 26.6 27.2 28.2 29.3
Hi PR 139 150 158 165 156 168 178 185 178 191 202 211 202 218 230 240 228 245 259 270 252 271 286 298
Lo PR 61 65 71 76 65 69 75 80 67 72 78 83 71 75 82 87 74 79 86 92 77 81 89 95
3500
MBh 99.1 101.2 108.2 115.6 96.8 98.9 105.6 112.9 94.5 96.5 103.1 110.2 92.2 94.2 100.6 107.5 87.5 89.5 95.6 102.2 81.1 82.9 88.5 94.6
S/T 0.83 0.78 0.63 0.47 0.86 0.81 0.66 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.94 0.89 0.72 0.54 0.95 0.89 0.73 0.54
∆T 22 21 18 14 22 21 18 15 22 21 18 15 22 21 18 15 22 21 18 14 20 19 17 14
kW 8.39 8.55 8.81 9.08 9.00 9.18 9.46 9.75 9.53 9.73 10.03 10.35 10.01 10.22 10.54 10.88 10.41 10.63 10.97 11.32 10.76 10.99 11.34 11.71
Amps 18.0 18.5 19.1 19.8 19.5 20.0 20.7 21.5 21.3 21.8 22.6 23.5 22.8 23.4 24.2 25.1 24.3 24.9 25.8 26.8 25.8 26.5 27.4 28.5
Hi PR 135 145 153 160 152 163 172 180 172 186 196 204 196 211 223 233 221 238 251 262 244 263 277 289
Lo PR 59 63 69 73 63 67 73 78 65 69 76 81 68 73 80 85 72 76 83 89 74 79 86 92
85
4500
MBh 112.48 114.66 120.09 128.11 109.87 111.99 117.29 125.14 107.25 109.33 114.50 122.16 104.64 106.66 111.71 119.18 99.40 101.33 106.12 113.22 92.08 93.86 98.30 104.88
S/T 0.95 0.91 0.82 0.67 0.98 0.95 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.94 0.77
∆T 22 21 20 17 22 22 20 18 22 22 20 18 21 22 21 18 20 21 20 18 19 19 19 16
kW 8.71 8.89 9.16 9.44 9.35 9.54 9.84 10.15 9.92 10.13 10.44 10.78 10.42 10.64 10.97 11.33 10.84 11.07 11.43 11.80 11.21 11.45 11.82 12.21
Amps 18.9 19.4 20.0 20.8 20.5 21.0 21.7 22.6 22.3 22.9 23.7 24.6 23.9 24.5 25.4 26.4 25.5 26.2 27.1 28.1 27.1 27.8 28.7 29.9
Hi PR 142 153 161 168 159 172 181 189 181 195 206 215 206 222 235 245 232 250 264 275 257 276 292 304
Lo PR 62 66 73 77 66 70 77 82 69 73 80 85 72 77 84 89 75 80 88 93 78 83 91 97
4000
MBh 109.2 111.3 116.6 124.4 106.7 108.7 113.9 121.5 104.1 106.1 111.2 118.6 101.6 103.6 108.5 115.7 96.5 98.4 103.0 109.9 89.4 91.1 95.4 101.8
S/T 0.90 0.87 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.90 0.73
∆T 23 22 21 18 23 23 21 18 23 23 21 18 23 23 21 19 22 22 21 18 21 21 20 17
kW 8.65 8.82 9.09 9.37 9.28 9.47 9.76 10.07 9.84 10.05 10.36 10.69 10.33 10.55 10.89 11.24 10.75 10.98 11.34 11.70 11.12 11.36 11.72 12.11
Amps 18.7 19.2 19.8 20.6 20.3 20.8 21.5 22.4 22.1 22.7 23.5 24.4 23.7 24.3 25.1 26.1 25.3 25.9 26.8 27.9 26.8 27.5 28.5 29.6
Hi PR 141 151 160 167 158 170 179 187 179 193 204 213 204 220 232 242 230 247 261 273 254 273 289 301
Lo PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 80 87 92 77 82 90 96
3500
MBh 100.8 102.7 107.6 114.8 98.5 100.4 105.1 112.1 96.1 98.0 102.6 109.5 93.8 95.6 100.1 106.8 89.1 90.8 95.1 101.5 82.5 84.1 88.1 94.0
S/T 0.87 0.84 0.76 0.61 0.90 0.87 0.78 0.64 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.96 0.87 0.71
∆T 23 23 21 19 23 23 22 19 23 23 22 19 23 23 22 19 23 23 22 19 22 21 20 17
kW 8.45 8.62 8.88 9.15 9.06 9.25 9.53 9.83 9.61 9.81 10.11 10.43 10.09 10.30 10.62 10.96 10.49 10.72 11.06 11.42 10.85 11.08 11.43 11.81
Amps 18.2 18.7 19.3 20.0 19.7 20.2 20.9 21.7 21.5 22.0 22.8 23.7 23.0 23.6 24.4 25.4 24.6 25.2 26.0 27.1 26.1 26.7 27.6 28.7
Hi PR 136 147 155 162 153 165 174 181 174 187 198 206 198 213 225 235 223 240 253 264 246 265 280 292
Lo PR 60 64 70 74 63 67 74 78 66 70 76 81 69 74 80 86 72 77 84 90 75 80 87 93
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
10 www.goodmanmfg.com SS-GSH10C
ExpandEd HEatinG data


                 
MBh 103.1 97.6 91.8 85.9 82.0 79.5 73.8 68.1 66.0 61.0 56.1 53.0 51.0 45.8 40.6 35.4 30.2 24.8
∆T 33.1 31.4 29.5 27.6 26.4 25.5 23.7 21.9 21.2 19.6 18.0 17.0 16.4 14.7 13.1 11.4 9.7 8.0
kW 8.04 7.89 7.74 7.59 7.50 7.44 7.29 7.14 7.48 7.32 7.16 7.06 7.00 6.83 6.67 6.51 6.34 6.18
Amps 24.4 22.6 21.1 19.8 19.1 18.7 17.6 16.7 16.0 15.3 14.5 14.2 14.0 13.3 12.4 11.6 10.7 9.6
COP 3.75 3.62 3.47 3.31 3.20 3.13 2.96 2.79 2.58 2.44 2.30 2.20 2.14 1.96 1.78 1.59 1.39 1.17
EER 12.8 12.4 11.9 11.3 10.9 10.7 10.1 9.5 8.8 8.3 7.8 7.5 7.3 6.7 6.1 5.4 4.8 4.0
Hi PR 244 234 225 215 210 206 198 190 182 174 167 163 160 154 148 142 137 132
Lo PR 72 66 62 57 54 52 48 43 38 34 30 28 27 23 20 17 15 11


                 
MBh 105.8 100.1 94.2 88.1 84.1 81.5 75.7 69.8 64.1 59.1 54.5 51.4 49.5 44.4 39.4 34.3 29.3 24.0
∆T 32.1 30.4 28.6 26.7 25.5 24.8 23.0 21.2 19.5 18.0 16.5 15.6 15.0 13.5 12.0 10.4 8.9 7.3
kW 8.03 7.88 7.73 7.58 7.49 7.42 7.28 7.12 7.95 7.77 7.59 7.49 7.42 7.24 7.06 6.88 6.70 6.52
Amps 30.2 28.1 26.4 24.9 24.1 23.7 22.4 21.4 20.5 19.7 18.8 18.4 18.2 17.4 16.3 15.5 14.4 13.2
COP 3.85 3.72 3.57 3.40 3.29 3.21 3.05 2.87 2.36 2.23 2.10 2.01 1.95 1.80 1.63 1.46 1.28 1.08
EER 13.2 12.7 12.2 11.6 11.2 11.0 10.4 9.8 8.1 7.6 7.2 6.9 6.7 6.1 5.6 5.0 4.4 3.7
Hi PR 268 257 247 236 230 226 217 209 200 191 183 179 176 169 162 156 150 145
Lo PR 72 67 63 57 54 52 48 43 39 34 30 28 27 23 20 17 15 11


                 
MBh 132.6 125.5 118.2 110.5 105.5 102.2 95.0 87.6 85.4 78.8 72.5 68.5 66.0 59.2 52.5 45.8 39.0 32.0
∆T 30.7 29.1 27.4 25.6 24.4 23.7 22.0 20.3 19.8 18.2 16.8 15.9 15.3 13.7 12.1 10.6 9.0 7.4
kW 10.41 10.21 10.01 9.81 9.70 9.62 9.43 9.23 9.69 9.47 9.26 9.13 9.05 8.83 8.62 8.41 8.19 7.98
Amps 28.3 26.2 24.5 23.0 22.1 21.7 20.4 19.3 18.4 17.6 16.7 16.3 16.1 15.2 14.1 13.3 12.2 10.9
COP 3.73 3.60 3.45 3.29 3.18 3.11 2.95 2.78 2.58 2.44 2.29 2.20 2.13 1.96 1.78 1.59 1.40 1.17
EER 12.7 12.3 11.8 11.3 10.9 10.6 10.1 9.5 8.8 8.3 7.8 7.5 7.3 6.7 6.1 5.4 4.8 4.0
Hi PR 221 212 203 195 190 186 179 172 165 157 151 147 145 139 134 128 124 120
Lo PR 66 62 58 53 50 48 44 39 36 32 28 26 25 21 18 15 13 11
High pressure is measured at the sucon service valve ( the larger valve). Amps = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connecon. kW = Total system power
Calculaons are based on nominal CFM and 70 °F indoor dry bulb.

pRoduCt SpECifiCationS pRoduCt SpECifiCationS
SS-GSH10C www.goodmanmfg.com 11
WiRinG diaGRam
WIRING DIAGRAMS
18
HIGH VOLTAGE!
DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS
UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO
DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
GSH10*****A*
Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
Wiring is subject to change. Always refer to the wiring diagram or the unit for the most up-to-date wiring. ⚠Warning
  Disconnect all power before servicing or installing this unit. Mulple power sources may be present. Failure to do so may cause property damage, personal injury, or death. ⚡

Product SPecificationS Product SPecificationS
12 www.goodmanmfg.com SS-GSH10C
Goodman Manufacturing Company, L.P., reserves the right to discontinue, or change at any time, specications or designs without
notice or without incurring obligations. © 2011 • Goodman Manufacturing Company, L.P. • Houston, Texas • Printed in the USA.
acceSSorieS
Model Description GSH10
090**
GSH10
120**
ABK-20 Anchor Bracket Kit •X X
AFE18-60A All-fuel Kit X X
FSK01A¹ Freeze Protecon Kit X X
OT18-60A² Outdoor Thermostat with Lockout Stat X X
•Contains 20 brackets; four brackets needed to anchor unit to pad
¹ Installed on indoor coil
² Required for heat pump applicaons where ambient temperatures fall below 0 °F with 50% or higher
relave humidity.
D
H
W
dimenSionS
Model Dimensions
W" D" H"
GSH100903** 35½ 35½ 41½
GSH101203** 35½ 35½ 37½
