Goodman ASX Operating instructions

Important Safety Instructions
The following symbols and labels are used throughout this
manualtoindicateimmediateorpotentialsafetyhazards. Itis
the owner’s and installer’s responsibility to read and comply
withallsafetyinformationand instructionsaccompanyingthese
symbols. Failuretoheedsafetyinformationincreasestherisk
ofpersonalinjury,propertydamage,and/orproductdamage.
HIGH VOLTAGE!
Disconnect ALL power before servicing.
Multiple power sources may be present.
Failure to do so may cause property damage,
personal injury or death.
WARNING
ONLY individuals meeting the requirements of an
“Entry Level Technician” as specified by the Air
Conditioning and Refrigeration Institute (ARI) may use
this information. Attempting to install or repair this
unit without such background may result in product
damage, personal injury, or death.
WARNING
Shipping Inspection
Always keep the unit upright; laying the unit on its side or top
maycauseequipment damage. Shippingdamage,andsubse-
quent investigation is the responsibility of the carrier. Verify
the model number, specifications, electrical characteristics,
and accessories are correct prior to installation. The distribu-
toror manufacturerwillnotacceptclaimsfromdealersfortrans-
portationdamageor installation of incorrectly shipped units.
Codes & Regulations
This product is designed and manufactured to comply with
nationalcodes.Installationinaccordancewith suchcodesand/
orprevailinglocalcodes/regulationsistheresponsibilityof the
installer. Themanufacturerassumesnoresponsibilityforequip-
mentinstalled in violation of anycodes or regulations.
TheUnited States EnvironmentalProtection Agency (EPA)
has issued various regulations regarding the introduc-
tion and disposal of refrigerants. Failure to follow these
regulations may harm the environment and can lead to
the imposition of substantial fines. Should you have any
questions please contact the local office of the EPA.
If replacing a condensing unit or air handler, the system must
bemanufacturerapproved andAirConditioningand Refrigera-
tionInstitute(ARI)matched. NOTE:Installation of unmatched
systems is strongly discouraged.
Operatingtheunitinastructurethatis not complete (either as
CONDENSING UNIT
AIR CONDITIONING
INSTALLATION & SERVICE REFERENCE
Goodman Manufacturing Company, L.P. © 2005-2006
2550 North Loop West, Suite 400, Houston, TX 77092
www.goodmanmfg.com -or- www.amana-hac.com
P/N:IO-258D Date: October 2006
partofnewconstructionorrenovation)willvoidthewarranty.
Installation Clearances
Special consideration must be given to location of the con-
densingunit(s)inregardtostructures,obstructions,otherunits,
andany/allotherfactorsthatmay interfere with air circulation.
Wherepossible,thetop of theunitshouldbecompletelyunob-
structed;however,ifverticalconditionsrequireplacementbe-
neath an obstruction there should be a minimum of 60
inches between the top of the unit and the obstruction(s).
Thespecifieddimensionsmeet requirements foraircirculation
only. Consult all appropriate regulatory codes prior to deter-
miningfinalclearances.
Anotherimportantconsiderationinselecting a location for the
unit(s) is the angle to obstructions. Either side adjacent the
valves can be placed toward the structure provided the side
awayfromthe structuremaintainsminimumservice clearance.
Cornerinstallationsarestronglydiscouraged.
OK!
OK!
AA AAA
A
CC
CCOK!
OK!
OK!
OK!
NOT
RECOMMENDED
AA
AA AA
AA
AA
B B B
B
Model Type A B C AA
Residential 10" 10" 18" 20"
Light Commercial 12" 12" 18" 24"
Minimum Airflow Clearance
Thisunitcanbelocatedat ground floor level or on flatroofs.At
groundfloorlevel,theunitmustbeonasolid,levelfoundation
that will not shift or settle. To reduce the possibility of sound
transmission,thefoundationslabshouldnot be in contact with
or be an integral part of the building foundation. Ensure the
foundation is sufficient to support the unit. A concrete slab
raisedabovegroundlevel provides a suitablebase.

2
Rooftop Installations
If it is necessary to install this unit on a roof structure, ensure
theroofstructure can support the weight and thatpropercon-
siderationisgiventotheweather-tightintegrityoftheroof.Since
theunitcan vibrate duringoperation,soundvibrationtransmis-
sion should be considered when installing the unit. Vibration
absorbing pads or springs can be installed between the con-
densingunit legs or frame and theroofmounting assembly to
reducenoisevibration.
Safe Refrigerant Handling
While these items will not cover every conceivable situation,
theyshould serve as a useful guide.
To avoid possible injury, explosion or death, practice
safe handling of refrigerants.
WARNING
Refrigerants are heavier than air. They can "push out"
the oxygen in your lungs or in any enclosed space.To
avoid possible difficulty in breathing or death:
• Never purge refrigerant into an enclosed room or
space. By law, all refrigerants must be reclaimed.
• If an indoor leak is suspected, throughly ventilate the
area before beginningwork.
• Liquid refrigerant can be very cold. To avoid possible
frostbite or blindness, avoid contact and wear gloves
and goggles. If liquid refrigerant does contact your
skin or eyes, seek medical help immediately.
• Always follow EPA regulations. Never burn refrig-
erant, as poisonous gas will be produced.
WARNING
To avoid possible explosion:
• Never apply flame or steam to a refrigerant cylinder.
If you must heat a cylinder for faster charging,
partially immerse it in warm water.
• Never fill a cylinder more than 80% full of liquid re-
frigerant.
• Never add anything other than R-22 to an R-22 cy-
linder or R-410A to an R-410A cylinder. The service
equipment used must be listed or certified for the
type of refrigerant used.
• Store cylinders in a cool, dry place. Never use a cy-
linder as a platform or a roller.
WARNING
To avoid possible explosion, use only returnable (not
disposable) service cylinders when removing refrig-
erant from a system.
• Ensure the cylinder is free of damage which could
lead to a leak or explosion.
• Ensure the hydrostatic test date does not exceed
5 years.
• Ensure the pressure rating meets or exceeds 400
lbs.
When in doubt, do not use cylinder.
WARNING
Refrigerant Lines
The compressor POE oil for R-410A units is extremely
susceptible to moisture absorption and could cause
compressor failure. Do not leave system open to atmos-
phere any longer than necessary for installation.
CAUTION
Useonly refrigerantgrade(dehydrated andsealed)copper tub-
ingtoconnectthecondensingunitwiththeindoorevaporator.
Aftercuttingthetubing, install plugs to keep refrigerant tubing
clean and dry prior to and during installation. Tubing should
alwaysbecutsquarekeepingendsround and free from burrs.
Cleanthetubingtopreventcontamination.
DoNOTletrefrigerantlinescome in direct contact with plumb-
ing,ductwork, floor joists, wallstuds, floors, and walls. When
runningrefrigerantlines throughafoundationorwall, openings
should allow for sound and vibration absorbing material to be
placed or installed between tubing and foundation. Any gap
betweenfoundationorwallandrefrigerantlinesshouldbefilled
withapliablesilicon-basedcaulk,RTVor a vibration damping
material. Avoid suspending refrigerant tubing from joists and
studs with rigid wire or straps that would come in contact with
thetubing.Useaninsulatedorsuspensiontypehanger.Keep
both lines separate and always insulate the suction line.
These sizes are suitable for line lengths of 74 feet or less. If a
runofmore than fifty feet is required,refertoRemote Cooling
ServiceManual,orTP-106LongLineSetApplicationR-22,or
TP-107LongLineSetApplicationR-410Aorcontactyourdis-
tributorforassistance.
Cond
Unit
Tons Suct Liq Suct Liq Suct Liq
1 1/2 5/8 1/4 3/4 3/8 3/4 3/8
2 5/8 1/4 3/4 3/8 3/4 3/8
2 1/2 5/8 1/4 3/4* 3/8 7/8 3/8
3 3/4 3/8 3/4** 3/8 7/8** 3/8
3 1/2 3/4 3/8 7/8** 3/8 1 1/8 3/8
4 7/8 3/8 1 1/8 3/8 1 1/8 3/8
5 7/8 3/8 1 1/8 3/8 1 1/8 3/8
Line Diameter (In. OD)
REFRIGERANT LINE LENGTH (Ft)
0-24 25-49 50-74***
* 7/8" required for full ratings
** 1 1/8" required for full ratings
*** Lines greater than 74 feet in length or vertical elevation changes more than 50 feet
refer to the Remote Cooling Service Manual or contact your distributor for
assistance.

3
Mounting the condensing unit above
the evaporator coil will require oil traps
at equal intervals along the suction line.
Install 1 oil trap for a height difference of
15–25 feet between indoor and outdoor
units. Install 2 oil traps for a difference of
26-50 feet, 3 for 51-100 feet, and 4 for
101-150 feet.
Suction Line
Liquid Line
Mounting the evaporator coil above the
condensing unit will require an inverted
loop in the suction line adjacent or near
the connection to the evaporator. The top
of the loop must be slightly higher than the
top of the coil.
Insulationisnecessary to prevent condensation from forming
and dropping from the suction line. Armflex (or satisfactory
equivalent) with 3/8” min. wall thickness is recommended. In
severeconditions(hot,highhumidityareas)1/2”insulationmay
be required. Insulation must be installed in a manner which
protectstubingfromdamageandcontamination.
Where possible, drain as much residual compressor oil from
existing systems, lines, and traps; pay close attention to low
areas where oil may collect. NOTE: If changing refrigerant
types, ensure the indoor coil and metering device is compat-
ible with the type of refrigerant being used; otherwise, the in-
door coil must be replaced.
Burying Refrigerant Lines
Ifburyingrefrigerant linescannotbe avoided,usethefollowing
checklist.
1. Insulate liquid and suction lines separately.
2. Enclose all underground portions of the refrigerant lines
inwaterproof material (conduitor pipe) sealing theends
wheretubingenters/exits the enclosure.
3. If the lines must pass under or through a concrete slab,
ensurelinesareadequatelyprotectedandsealed.
Refrigerant Line Connections
IMPORTANT:To avoid overheating the service valve, TXV
valve, or filter drier while brazing, wrap the component
with a wet rag, or use a thermal heat trap compound as
recommended by the compound manufacturer. Use a
brazing alloy of 2% minimum silver content. Do not use
flux.
1. Theendsof the refrigerant lines must becutsquare,de-
burred,cleaned,andberoundandfreefromnicksordents.
Anyotherconditionincreasesthechanceofarefrigerant
leak.
2. “Sweep”therefrigerantline withnitrogenorinert gasdur-
ing brazing to prevent the formation of copper-oxide in-
side the refrigerant lines. The POE oils used in R-410A
applicationswillcleananycopper-oxide present from the
insideoftherefrigerant lines andspreaditthroughoutthe
system. This may cause a blockage or failure of the me-
teringdevice.
3. After brazing, quench the joints with water or a wet cloth
topreventoverheatingoftheservice valve.
4. Ensure the filter drier paint finish is intact after brazing. If
thepaintofthesteelfilterdrierhasbeenburnedorchipped,
repaintortreatwith a rustpreventative. Thisisespecially
important on suction line filter driers which are continu-
ally wet when the unit is operating.
NOTE: Becarefulnottokinkordent refrigerant lines. Kinked
or dented lines will cause poor performance or compressor
damage.
Do NOT make final refrigerant line connection until plugs are
removedfromrefrigeranttubing.
NOTE: Before brazing, verify indoor piston size by checking
the piston kit chart packaged with indoor unit.
Leak Testing (Nitrogen or Nitrogen-Traced)
To avoid the risk of fire or explosion, never use
oxygen, high pressure air or flammable gases for leak
testing of a refrigeration system.
WARNING
To avoid possible explosion, the line from the
nitrogen cylinder must include a pressure regulator
and a pressure relief valve. The pressure relief valve
must be set to open at no more than 150 psig.
WARNING
Pressure test the system using dry nitrogen and soapy water
to locate leaks. If you wish to use a leak detector, charge the
system to 10 psi using the appropriate refrigerant then use
nitrogentofinish chargingthesystemtoworking pressurethen
apply the detector to suspect areas. If leaks are found, repair
them. After repair, repeat the pressure test. If no leaks exist,
proceedtosystemevacuation.
System Evacuation
Condensingunitliquid andsuctionvalvesare closedtocontain
the charge within the unit. The unit is shipped with the valve
stems closed and caps installed. Do not open valves until
the system is evacuated.
REFRIGERANT UNDER PRESSURE!
Failure to follow proper procedures may cause
property damage, personal injury or death.
WARNING
1. Connectthevacuum pump with 250 micron capability to
theservicevalves.

4
2. Evacuate the system to 250 microns or less using suc-
tion and liquid service valves. Using both valves is nec-
essary as some compressors create a mechanical seal
separating the sides of the system.
3. Closepumpvalveandhold vacuumfor10minutes. Typi-
cally pressure will rise during this period.
5000
4500
4000
3500
3000
2500
2000
1500
1000
500
0 1 2 3 4 5 6 7 8 9 10
LEAK(S)
PRESENT
MINUTES
VACUUM IN MICRONS
CONDENSIBLES OR SMALL
LEAK PRESENT
NO LEAKS
NO CONDENSIBLES
•Ifthepressurerisesto1000micronsorlessandremains
steady the system is considered leak-free; proceed to
startup.
• If pressure rises above 1000 microns but holds steady
below 2000 microns, moisture and/or noncondensibles
may be present or the system may have a small leak.
Returntostep2:Ifthesameresultisencounteredcheck
forleaksaspreviouslyindicatedand repair as necessary
thenrepeatevacuation.
•If pressure rises above 2000 microns, a leak is present.
Checkforleaksaspreviouslyindicated andrepairasnec-
essarythenrepeatevacuation.
Electrical Connections
HIGH VOLTAGE!
Disconnect ALL power before servicing.
Multiple power sources may be present.
Failure to do so may cause property damage,
personal injury or death due to electric shock.
Wiring must conform with NEC or CEC and all
local codes. Undersized wires could cause
poor equipment performance, equipment damage
or fire.
WARNING
To avoid the risk of fire or equipment damage, use
copper conductors.
WARNING
NOTICE
Units with reciprocating compressors and non-bleed TXV’s
require a Hard Start Kit.
The condensing unit rating plate lists pertinent electrical data
necessaryforproperelectrical service andovercurrentprotec-
tion. Wires should be sized to limit voltage drop to 2% (max.)
from the main breaker or fuse panel to the condensing unit.
Consult the NEC, CEC, and all local codes to determine the
correctwiregaugeandlength.
Localcodesoftenrequire a disconnectswitchlocatednearthe
unit; do not install the switch on the unit. Refer to the installa-
tioninstructionssupplied withtheindoorfurnace/airhandler for
specificwiringconnections andindoorunitconfiguration. Like-
wise, consult the instructions packaged with the thermostat
formountingandlocationinformation.
Overcurrent Protection
Thefollowingovercurrentprotectiondevicesareapprovedfor
use.
• Timedelayfuses
• HACRtype circuit breakers
These devices have sufficient time delay to permit the motor-
compressor to start and accelerate its load.
Three Phase Compressor Rotation
Use care when handling scroll compressors. Dome temp-
eratures could be hot.
CAUTION
Threephasescrolls arepowerphasedependent andcancom-
press in more than one direction.
Verifyproperrotation forthreephasecompressors byensuring
thesuctionpressuredrops and dischargepressureriseswhen
the compressor is energized. NOTE: When operated in re-
verse,athree phase scroll compressors is noisieranditscur-
rentdrawsubstantiallyreducedcomparedtomarkedvalues.
To correct, disconnect power and switch any two leads at the
unitcontactorandre-observe.
High Voltage Connections
Routepowersupply andgroundwiresthroughthe highvoltage
portandterminatein accordance with the wiring diagram pro-
videdinsidethecontrolpanelcover.
Low Voltage Connections
Condensingunit controlwiringrequires 24Voltminimum, 25VA
servicefrom theindoortransformer. Low voltagewiringfor two-
stage units depends on the thermostat used and the number
of control wires between the indoor unit and the condensing
unit. Routecontrolwiresthroughthe low voltage port and ter-
minateinaccordance with the wiring diagram providedinside
thecontrolpanelcover.

5
RG
W1
B/C G RW1 DEHUM
TWIN
O
YR
Thermostat
Single-Stage Heating
with
Single-Stage Cooling
(
REMOTE
FURNACE OR
AIR HANDLER
Y
Y
C
Single-Stage Thermostat
with Two Low Voltage Wires to Remote
NOTE:For two-stagecondensingunits,refer to theInstallation
Instructions supplied with the variable speed indoor units for
fieldwiringconnections.
RG
W1
Y/Y2
YL0/Y1 W2
B/C G RW1 W2 DEHUM
TWIN
OYLO/YI Y/Y2
YLO/YI Y/Y2 C
Thermostat
Two-Stage Heating
with
Two-Stage Cooling
(
OD UNIT
FURNACE OR
AIR HANDLER
R
Two-Stage Thermostat
with Three Low Voltage Wires to Remote
System Start Up
Adequaterefrigerantchargefora matching evaporator and15
feetlinesetissuppliedwiththecondensingunit.NOTE: Iflineset
exceeds 15 feet in length, refrigerant should be added at .6
ouncesper foot of liquid line.
Open each valve only until the top of the stem is 1/8” from the
retainer.To avoid loss ofrefrigerant, do not applypressure to
theretainer.
1. Break vacuum by fully opening liquid and suction base
valves.
2. Set thermostat to call for cooling. Check indoorandout-
door fan operation and allow system to stabilize for 10
minutes for fixed orifices and 20 minutes for expansion
valves.
Charge Verification
REFRIGERANT UNDER PRESSURE!
• Do not overcharge system with refrigerant.
• Do not operate unit in a vacuum or at negative pres-
sure.
Failure to follow proper procedures may cause
property damage, personal injury or death.
WARNING
Use refrigerant certified to ARI standards. Used refrigerant
may cause compressor damage, and will void the warranty.
Most portable machines cannot clean used refrigerant to
meet ARI standards.
CAUTION
NOTICE
Violation of EPA regulations may result in fines or other
penalties.
Operating the compressor with the suction valve closed will
void the warranty and cause serious compressor damage.
CAUTION
Final ChargeAdjustment
Theoutdoortemperature must be60°Forhigher. Set theroom
thermostat to COOL, fan switch to AUTO, and set the tem-
peraturecontrolwellbelowroomtemperature.
After system has stabilized per startup instructions, check
subcoolingandsuperheatasdetailedinthefollowing section.
Fixed Orifice
CAUTION
To prevent personal injury, carefullyconnect and disconnect
manifoldgauge hoses. Escaping liquid refrigerant can cause
burns. Do not vent refrigerant into the atmosphere. Recover
all refrigerant during system repair and before final unit
disposal.
1. Purge gauge lines. Connect service gauge manifold to
base-valveserviceports.Run systematleast10minutes
to allow pressure to stabilize.
2. Temporarily install thermometer on suction (large) line
nearsuctionlineservice valvewithadequatecontactand
insulateforbestpossible reading.
3. Refer to the superheat table provided for proper system
superheat. Add charge to lower superheat or recover
chargetoraisesuperheat.
65 70 75 80 85
115 3
100 55
95 555
90 71218
85 5 101720
80 5 122126
75 5 10172529
70 5 14202832
65 13 19 26 32 35
60 17 25 30 33 37
Return Air Temperature
(°FDrybulb)
SYSTEM SUPERHEAT
A
mbient Condenser
Inlet Temp.
(°FDrybulb)
4. Disconnect manifold set, installation is complete.
Superheat Formula = Suct. Line Temp. - Sat. Suct. Temp.

6
SUCTIONPRESSURE
PSIG R-22 R-410A
50 26 1
52 28 3
54 29 4
56 31 6
58 32 7
60 34 8
62 35 10
64 37 11
66 38 13
68 40 14
70 41 15
72 42 16
74 44 17
76 45 19
78 46 20
80 48 21
SATURATED SUCTIONPRESSURE
TEMPERATURE CHART
SATURATED SUCTION
TEMPERATURE ºF
Expansion Valve System
Single Speed Application
1. Purge gauge lines. Connect service gauge manifold to
base-valve service ports. Run system at least 10 min-
utes to allow pressure to stabilize.
2. Temporarilyinstallthermometer onliquid(small)linenear
liquidlineservice valve with adequate contactandinsu-
lateforbest possible reading.
3.Checksubcoolingand superheat. Systems with TXV ap-
plicationshouldhaveasubcoolingof7±2ºFandsuper-
heat of 7 to 9 ºF.
a. Ifsubcoolingandsuperheatarelow,adjust TXVto
7 to 9 ºF superheat, then check subcooling.
NOTE: To adjust superheat, turn the valve stem clock-
wisetoincreaseandcounterclockwise todecrease.
b. If subcooling is low and superheat is high, add
charge to raise subcooling to 7 ± 2ºF then check
superheat.
c. If subcooling and superheat are high, adjust TXV
valveto7to 9 ºFsuperheat,thenchecksubcooling.
d. If subcooling is high and superheat is low, adjust
TXVvalveto7to9ºFsuperheatandremovecharge
to lower the subcooling to 7 ± 2ºF.
NOTE:Do NOT adjustthechargebased onsuctionpres-
sureunless there is a gross undercharge.
4. Disconnect manifold set, installation is complete.
Subcooling Formula = Sat. Liquid Temp. - Liquid Line Temp.
NOTICE
Units with reciprocating compressors and non-bleed TXV’s
require a Hard Start Kit.
LIQUID PRESSURE
PSIG R-22 R-410A
200 101 70
210 105 73
220 108 76
225 110 78
235 113 80
245 116 83
255 119 85
265 121 88
275 124 90
285 127 92
295 130 95
305 133 97
325 137 101
355 144 108
375 148 112
405 155 118
SATURATED LIQUID PRESSURE
TEMPERATURE CHART
SATURATED LIQUID
TEMPERATURE ºF
Two Speed Application
Runtheremoteon lowstagecoolingfor10minutes until refrig-
erantpressuresstabilize. Follow the guidelines and methods
below to check unit operation and ensure that the refrigerant
charge is within limits. Charge the unit on low stage.
1. Purge gauge lines. Connect service gauge manifold to
base-valveservice ports.
2. Temporarilyinstallthermometeronliquid(small)linenear
liquid line service valve with adequate contact and insu-
lateforbest possible reading.
3.Check subcooling and superheat. Systems withTXVap-
plicationshouldhavea subcooling of 5to7ºFandsuper-
heat of 7 to 9 ºF.
a. Ifsubcoolingandsuperheatarelow, adjust TXV to
7 to 9 ºF superheat, then check subcooling.
NOTE: To adjust superheat, turn the valve stem clock-
wisetoincrease andcounterclockwiseto decrease.
b. Ifsubcoolingislowandsuperheatishigh,addcharge
to raise subcooling to 5 to 7 ºF then check super-
heat.
c. If subcooling and superheat are high, adjust TXV
valveto7to9 ºF superheat, then check subcooling.
d. If subcooling is high and superheat is low, adjust
TXVvalveto7to9ºFsuperheatandremove charge
to lower the subcooling to 5 to 7 ºF.
NOTE:DoNOT adjustthechargebasedon suction pres-
sureunless there is a gross undercharge.
4. Disconnect manifold set, installation is complete.
Subcooling Formula = Sat. Liquid Temp. - Liquid Line Temp.

7
Troubleshooting Information
For detailed service information refer to the Remote Condensing Unit Service manual.
Complaint Unsatisfactory
Cooling
POSSIBLE CAUSE
DOTS IN ANALYSIS
GUIDE INDICATE
"POSSIBLE CAUSE"
SYMPTOM
System will not start Compressor will not start - fan runs Compressor and Condenser Fan will not start Evaporator fan will not start Condenser fan will not start Compressor runs - goes off on overload Compressor cycles on overload System runs continuously - little cooling Too cool and then too warm Not cool enough on warm days Certain areas to cool others to warm Compressor is noisy Low suction pressure Low head pressure High suction pressure High head pressure
Test Method
Remedy
Power Failure •Test Volta
g
e
Blown Fuse ••• Impact Fuse Size & Type
Loose Connection • ••• Ins
p
ect Connection - Ti
g
hten
Shorted or Broken Wires •••••• Test Circuits with Ohmmeter
Open Overload •• Test Continuit
y
of Overloads
Faulty Thermostat ••• • Test Continuit
y
of Thermostat and Wirin
g
Faulty Transformer •• Check Control Circuit with Voltmeter
Shorted or Open Capacitor • ••• Test Ca
p
acitor
Internal Com
p
ressor Overload O
p
en •Test Continuit
y
of Overload
Shorted or Grounded Compressor •• Test Motor Windin
g
s
Compressor Stuck •• Use Test Cord
Faulty Compressor Contactor ••• • Test Continuit
y
of Coil and Contacts
Faulty Fan Relay •Test Continuit
y
of Coil and Contacts
Open Control Circuit Test Control Circuit with Voltmeter
Low Voltage ••• Test Volta
g
e
Faulty Evaporator Fan Motor •• Re
p
air or Re
p
lace
Shorted or Grounded Fan Motor •• • Test Motor Windin
g
s
Improper Cooling Anticipator •Check Resistance of Antici
p
ator
Shortage or Refrigerant •• •• Test For Leaks, Add Refrigerant
Restricted Liquid Line •• •• Re
p
lace Restricted Part
Undersized Liquid Line •• • Replace Line
Undersized Suction Line •Re
p
lace Line
Not Enough Air across Indoor Coil •••• Speed Blower, Check Duct Static Pressure
Too Much Air across Indoor Coil •Reduce Blower S
p
eed
Overcharge of Refrigerant •• • •• Recover Part of Charge
Noncondensibles •• • Recover Char
g
e, Evacuate, Rechar
g
e
Recirculation of Condensing Air •• • Remove Obstruction to Air Flow
Infiltration of Outdoor Air ••• Check Windows, Doors, Vent Fans, Etc.
Improperly Located Thermostat •Relocate Thermostat
Air Flow Unbalanced •• Read
j
ust Air Volume Dam
p
ers
System Undersized •• Refigure Cooling Load
Broken Internal Parts •Re
p
lace Com
p
ressor
Broken Valves •Test Compressor Efficiency
Inefficient Compressor ••• Test Com
p
ressor Efficienc
y
High Pressure Control Open •Reset and Test Control
Unbalanced Power, 3PH ••• Test Volta
g
e
Wrong Type Expansion Valve •• • Replace Valve
Expansion Valve Restricted ••• • •• Re
p
lace Valve
Oversized Expansion Valve •• Replace Valve
Undersized Expansion Valve ••• • • Re
p
lace Valve
Expansion Valve Bulb Loose •• Ti
g
hten Bulb Bracket
Inoperative Expansion Valve •• • Check Valve O
p
eration
Loose Hold-down Bolts •Tighten Bolts
No Cooling System Operating
Pressures

RS6200006
November2006
This manual is to be used by qualified, professionally trained HVAC technicians
only. Goodman does not assume any responsibility for property damage or
personal injury due to improper service procedures or services performed by an
unqualified person.
Copyright © 2006 Goodman Manufacturing Company, L.P.
Service
Instructions
SSX & ASX Condensing Units and
SSZ & ASZ Split System Heat Pumps
with R-410A Refrigerant
Blowers, Coils, & Accessories

Pride and workmanship go into every product to provide our customers with quality products. It is possible, however, that
during its lifetime a product may require service. Products should be serviced only by a qualified service technician who is
familiar with the safety procedures required in the repair and who is equipped with the proper tools, parts, testing instruments
andtheappropriateservicemanual. REVIEWALLSERVICEINFORMATIONINTHEAPPROPRIATESERVICEMANUALBEFORE
BEGINNINGREPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZESAFETYSYMBOLS,WORDSANDLABELS
WARNING
THIS UNIT SHOULD NOT BE CONNECTED TO. OR USED IN CONJUNCTION WITH, ANY DEVICES THAT ARE NOT DESIGN CERTIFIED FOR USE WITH THIS UNIT OR HAVE NOT BEEN
TESTED AND APPROVED BY GOODMAN. SERIOUS PROPERTY DAMAGE OR PERSONAL INJURY, REDUCED UNIT PERFORMANCE AND/OR HAZARDOUS CONDITIONS MAY RESULT
FROM THE USE OF DEVICES THAT HAVE NOT BEEN APPROVED OR CERTIFED BY GOODMAN.
WARNING
TO PREVENT THE RISK OF PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH,
DO NOT STORE COMBUSTIBLE MATERIALS OR USE GASOLINE OR OTHER
FLAMMABLE LIQUIDS OR VAPORS IN THE VICINITY OF THIS APPLIANCE.
WARNING
GOODMAN WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM IMPROPER SERVICE OR SERVICE PROCEDURES.
IF YOU INSTALL OR PERFORM SERVICE ON THIS UNIT, YOU ASSUME RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH
MAY RESULT. MANY JURISDICTIONS REQUIRE A LICENSE TO INSTALL OR SERVICE HEATING AND AIR CONDITIONING EQUIPMENT.
To locate an authorized servicer, please consult your telephone book or the dealer from whom you purchased this product.
For further assistance, please contact: CONSUMERINFORMATION LINE
IMPORTANT INFORMATION
GOODMAN®BRAND PRODUCTS
TOLL FREE
1-877-254-4729 (U.S. only)
email us at: [email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-713-861-2500.
(Not a technical assistance line for dealers.)
Your telephone company will bill you for the call.
AMANA®BRAND PRODUCTS
TOLL FREE
1-877-254-4729 (U.S. only)
email us at: hac.consumer[email protected]
fax us at: (931) 438- 4362
(Not a technical assistance line for dealers.)
OutsidetheU.S., call1-931-433-6101.
(Not a technical assistance line for dealers.)
Your telephone company will bill you for the call.
IMPORTANTINFORMATION ..................................... 2 - 3
PRODUCTIDENTIFICATION ...................................... 4 - 8
ACCESSORIES........................................................9 - 16
PRODUCTDESIGN ................................................17- 18
SYSTEMOPERATION ...........................................19 - 23
TROUBLESHOOTINGCHART .......................................24
SERVICETABLEOFCONTENTS.................................25
SERVICING ............................................................26 - 61
ACCESSORIESWIRINGDIAGRAMS ....................62 - 66

SAFE REFRIGERANT HANDLING
Whilethese items willnot cover every conceivable situation, they shouldserve as a useful guide.
IMPORTANT INFORMATION
Thesuccessfuldevelopmentofhermeticallysealedrefrigera-
tioncompressorshascompletelysealedthecompressor's
movingpartsand electric motorinsideacommonhousing,
minimizing refrigerant leaks and the hazards sometimes
associated with moving belts, pulleys or couplings.
Fundamental to the design of hermetic compressors is a
method whereby electrical current is transmitted to the
compressormotorthroughterminalconductorswhichpass
throughthecompressorhousingwall. Theseterminalsare
sealedinadielectricmaterialwhichinsulatesthemfromthe
housing and maintains the pressure tight integrity of the
hermetic compressor. The terminals and their dielectric
embedmentarestronglyconstructed,butarevulnerableto
careless compressor installation or maintenance proce-
dures and equally vulnerable to internal electrical short
circuits caused by excessive system contaminants.
Ineither of these instances,an electrical short between the
terminalandthe compressor housing may result intheloss
of integrity between the terminal and its dielectric embed-
ment. This loss may cause the terminals to be expelled,
thereby venting the vaporous and liquid contents of the
compressor housing and system.
Aventingcompressorterminalnormallypresentsnodanger
toanyone,providingtheterminalprotectivecoverisproperly
in place.
If, however, the terminal protective cover is not properly in
place,aventingterminal may discharge acombinationof
(a) hotlubricatingoilandrefrigerant
(b) flammable mixture (if system is contaminated
withair)
inastreamofspraywhichmaybedangeroustoanyoneinthe
vicinity. Death or serious bodily injury could occur.
Under no circumstances is a hermetic compressor to be
electrically energized and/or operated without having the
terminalprotectivecoverproperlyinplace.
SeeServiceSectionS-17forproperservicing.
WARNING
REFRIGERANTS ARE HEAVIER THAN AIR. THEY CAN "PUSH OUT" THE
OXYGEN IN YOUR LUNGS OR IN ANY ENCLOSED SPACE. TO AVOID
POSSIBLE DIFFICULTY IN BREATHING OR DEATH:
•NEVER PURGE REFRIGERANT INTO AN ENCLOSED ROOM OR SPACE. BY
LAW, ALL REFRIGERANTS MUST BE RECLAIMED.
•IF AN INDOOR LEAK IS SUSPECTED, THOROUGHLY VENTILATE THE AREA
BEFORE BEGINNING WORK.
•LIQUID REFRIGERANT CAN BE VERY COLD. TO AVOID POSSIBLE FROST-
BITE OR BLINDNESS, AVOID CONTACT WITH REFRIGERANT AND WEAR
GLOVES AND GOGGLES. IF LIQUID REFRIGERANT DOES CONTACT YOUR
SKIN OR EYES, SEEK MEDICAL HELP IMMEDIATELY.
•ALWAYS FOLLOW EPA REGULATIONS. NEVER BURN REFRIGERANT,
AS POISONOUS GAS WILL BE PRODUCED.
WARNING
SYSTEM CONTAMINANTS, IMPROPER SERVICE PROCEDURE AND/OR PHYSICAL
ABUSE AFFECTING HERMETIC COMPRESSOR ELECTRICAL TERMINALS MAY
CAUSE DANGEROUS SYSTEM VENTING.
WARNING
TO AVOID POSSIBLE INJURY, EXPLOSION OR DEATH, PRACTICE SAFE
HANDLING OF REFRIGERANTS.
WARNING
TO AVOID POSSIBLE EXPLOSION, USE ONLY RETURNABLE (NOT DISPOSABLE)
SERVICE CYLINDERS WHEN REMOVING REFRIGERANT FROM A SYSTEM.
• ENSURE THE CYLINDER IS FREE OF DAMAGE WHICH COULD LEAD TO A
LEAK OR EXPLOSION.
• ENSURE THE HYDROSTATIC TEST DATE DOES NOT EXCEED 5 YEARS.
• ENSURE THE PRESSURE RATING MEETS OR EXCEEDS 400 LBS.
WHEN IN DOUBT, DO NOT USE CYLINDER.
WARNING
TO AVOID POSSIBLE EXPLOSION:
• NEVER APPLY FLAME OR STEAM TO A REFRIGERANT CYLINDER. IF YOU
MUST HEAT A CYLINDER FOR FASTER CHARGING, PARTIALLY IMMERSE
IT IN WARM WATER.
• NEVER FILL A CYLINDER MORE THAN 80% FULL OF LIQUID REFRIGERANT.
• NEVER ADD ANYTHING OTHER THAN R-22 TO AN R-22 CYLINDER OR
R-410ATO AN R-410ACYLINDER. THE SERVICE EQUIPMENT USED MUST
BE LISTED OR CERTIFIED FOR THE TYPE OF REFRIGERANT USED.
• STORE CYLINDERS IN A COOL, DRY PLACE. NEVER USE A CYLINDER
AS A PLATFORM OR A ROLLER.

PRODUCT IDENTIFICATION
4
S S Z 14 036 1 A A
Major Revision
SEER
SEER Rating
Nominal Capacity
Electrical
1:208/230V/60Hz/1ph
3:208/230V/60Hz/3ph
4:460V/60Hz/3ph
Product Family
S: Split System
Product Type
Brand Name
018: 1.5 tons
024: 2 tons
036: 3 tons
042: 3.5 tons
048: 4 tons
060: 5 tons
090: 7.5 tons
120: 10 tons
S:Goodman
(High Feature Set Models)
A: Amana Deluxe
X:CondenserR-410A
Z:HeatPumpR-410A
A:InitialRelease
MinorRevision
A:InitialRelease

PRODUCT IDENTIFICATION
5
MB E 8 00
A
A
1
Design Series
MB: Modular Blower
Motor Types
E: Variable-speed
R: Constant-speed
Air Flow Delivered
08: 800 CFM
12: 1,200 CFM
16: 1,600 CFM
20: 2,000 CFM
Design Series
A
: First Series
Circuit Breaker
2: 208/230-60-1
Factory-installed
Electric Heat
00: No Heat
Voltage/Hz/Phase
1: 208-230/60/1
MODEL MFG. #
CA*F030B4* CA*F030B4*
CA*F036B4* CA*F036B4*
CA*F042C4* CA*F042C4*
CA*F048C4* CA*F048C4*
CA*F057D4* CA*F057D4*
CA*F060D4* CA*F060D4*
MODEL MFG. #
MBR0800 MBR0800
MBR1200 MBR1200
MBR1600 MBR1600
MBR2000 MBR2000
MODEL MFG. #
MBE1200 MBE1200
MBE1600 MBE1600
MBE2000 MBE2000
MODEL MFG. #
CHPF030A4* CHPF030A4*
CHPF036B4* CHPF036B4*
CHPF042A4* CHPF042A4*
CHPF048D4* CHPF048D4*
CHPF060D4* CHPF060D4*
CH36FCB CH36FCB
CH48FCB CH48FCB
CH60FCB CH60FCB
C
A
UF18
A
4
A
Product Type
CA: A Coil, Upflow/Downflow
CH: Horizontal A Coil, Cased
System Type
U: Uncased Coil
P: Painted Case Coil
Expansion Device
F: Flowrator Coil
Nominal Capacity
18: 18,000 BTUH
24: 24,000 BTUH
25: 25,000 BTUH
30: 30,000 BTUH
32: 32,000 BTUH
36: 36,000 BTUH
37: 37,000 BTUH
48: 48,000 BTUH
49: 49,000 BTUH
60: 60,000 BTUH
61: 61,000 BTUH
62: 62,000 BTUH
Revision
A: First Revision
B: Second Revision
C: Third Revision
Refrigerant
4: R-410A
Cabinet Description
CA Models
A: 14"
B: 17 1/2"
C: 21"
D: 24 1/2"
Cabinet Description
CH Models
(Cabinet Height)
A: 14"
B: 17 1/2"
C: 21"
D: 24 1/2"

PRODUCT IDENTIFICATION
6
C A P F 1824 A 6 A
Nominal Width for Gas Furnace
Expansion Device
Applicaton
Cabinet Finish
U:Unpainted
P: Painted
C:UnpaintedCase
1824: 1 1/2 - 2 Tons
3030: 2 1/2 Tons
3642: 3 - 3 1/2 Tons
Product Type
C:IndoorCoil
F:Flowrator
A: Fits14"FurnaceCabinet
B: Fits 17 1/2" Furnace Cabinet
C: Fits21"Furnace Cabinet
D: Fits 24 1/2" Furnace Cabinet
N: Does Not Apply (Horizontal Slab Coils)
Revision
A: Revision
Refrigerant
Nominal Capacity Range
@ 13 SEER
A: Upflow/DownflowCoil
H: HorizontalACoil
S: HorizontalSlabCoil 6: R-22orR-41A
4: R-410A

PRODUCT IDENTIFICATION
7
THIS NOMENCLATURE IS TO BE USED AFTER JULY 2006
A R U F 3642 1 6 A
Electrical Supply
Expansion Device
Cabinet Finish
U: Unpainted
P: Painted
N: Uncased
Nominal Capacity Range @ 13 SEER
3642: 3 - 3 1/2 Tons
1830: 1 1/2 - 3 1/2 Tons
Nominal Capacity Range @ 10 SEER
1729: 1 1/2 - 2 1/2 Tons (For Export Systems)
Product Type
A: Single Piece
AirHandler
F:Flowrator
1:208-230V/60Hz/1ph
MinorRevision
Refrigerant
Multi-Position&DownflowApplications
Ceiling Mount & Wall Mount Applications
Nominal Cooling Capacity/Electric Heat kw
1805: 1 1/2Tons Cooling/5kw Electric Heat
2405: 2 TonsCooling/5kwElectricHeat
3608: 3 TonsCooling/8kwElectricHeat
Application
C: CeilingMountPSCMotor
D: DownflowPSCMotor
E: Multi-Position
VariableSpeedMotor
R: Multi-Position PSC Motor
W:Wall Mount PSC Motor

PRODUCT IDENTIFICATION
8
Model No.
SSX14****1*
ASX14****1*
SSZ14****1*
ASZ14****1*
MBE****AA1
MBR****AA1
CAUF****4*
CAUX****4*
CAPF****4*
CAPX****4*
CHPF****4*
CHPX****4*
CH**FCB
CAUF****6*
CAPF****6*
CHPF****6*
CSPF****6*
{CA} A Coil {U} Uncased {F} Flowrator {***} BTU {*} Cabinet Size {6} Ultron or R-22 {*} Revision
{CA} A Coil {P} Painted {F} Flowrator {***} BTU {*} Cabinet Size {6} Ultron or R-22 {*} Revision
{CH} Horizontal {P} Painted {F} Flowrator {***} BTU {*} Cabinet Size {6} Ultron or R-22 {*} Revision
{CH} Horizontal {P} Painted {F} Flowrator {***} BTU {*} Cabinet Size {6} Ultron or R-22 {*} Revision
{S} Goodman - High feature set model {S} Split System {X} Condenser R-410A {**} SEER {****} Nominal Capacity {1} Voltage {*} Revision
{A} Amana® Brand Deluxel {S} Split System {X} Condenser R-410A {**} SEER {****} Nominal Capacity {1} Voltage {*} Revision
{S} Goodman - High feature set model {S} Split System {X} Heat Pump R-410A {**} SEER {****} Nominal Capacity {1} Voltage {*} Revision
{A} Amana® Brand Deluxel {S} Split System {X} Heat Pump R-410A {**} SEER {****} Nominal Capacity {1} Voltage {*} Revision
{CH} Horizontal {**} Capacity {F} Flowrator {C} Cased Coil {B} Series
Description
{CA} A Coil {P} Painted {F} Flowrator {***} BTU {*} Cabinet Size {4} Ultron {*} Revision
{CA} A Coil {P} Painted {X} TXV {***} BTU {*} Cabinet Size {4} Ultron {*} Revision
{CH} Horizontal {P} Painted {F} Flowrator {***} BTU {*} Cabinet Size {4} Ultron {*} Revision
{CH} Horizontal {P} Painted {X} TXV {***} BTU {*} Cabinet Size {4} Ultron {*} Revision
{MB} Modular Blower {E} Varialble Spd. {**} Airflow {**} Heat {A} Circuit Breaker {A} Series {1} Voltage
{MB} Modular Blower {R} Constant Spd. {**} Airflow {**} Heat {A} Circuit Breaker {A} Series {1} Voltage
{CA} A Coil {U} Uncased {F} Flowrator {***} BTU {*} Cabinet Size {4} Ultron {*} Revision
{CA} A Coil {U} Uncased {X} TXV {***} BTU {*} Cabinet Size {4} Ultron {*} Revision

9
ACCESSORIES
ASX14
SSX14
Model Description ASX14
018 ASX14 024 ASX14 030 ASX14 036 ASX14 042 ASX14 048 ASX14 060
ASC01 Anti-Short Cycle Kit XXXXXXX
CSR-U-1 Hard-start Kit XXXX
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit Xx
FSK01A1FreezeProtectionKit XXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit XXX
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of
start-assist components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering
device.
Model Description SSX14
018 SSX14 024 SSX14 030 SSX14 036 SSX14 042 SSX14 048 SSX14 060
ASC01Anti-ShortCycleKit XXXXXXX
CSR-U-1Hard-startKit XXXX
CSR-U-2Hard-startKit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1Freeze Protection Kit X X X X X X X
TX2N4³ TXV Kit X
TX3N42TXV Kit X X X
TX5N42TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of
start-assist components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering
device.

ACCESSORIES
10
SSX16
ASX16
Model Description SSX16
024 SSX16 030 SSX16 036 SSX16 042 SSX16 048 SSX16 060
ASC01 Anti-Short Cycle Kit XXXXXX
CSR-U-1 Hard-start Kit XXX
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit XX
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of
start-assist components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering
device.
Model Description ASX16
024 ASX16 030 ASX16 036 ASX16 042 ASX16 048 ASX16 060
ASC01 Anti-Short Cycle Kit XXXXXX
CSR-U-1 Hard-start Kit XXX
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit XX
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
³ Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of
start-assist components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering
device.

11
ACCESSORIES
SSZ14
ASZ14
Model Description SSZ14
018 SSZ14 024 SSZ14 030 SSZ14 036 SSZ14 042 SSZ14 048 SSZ14 060
AFE18-60A All-FuelKit XXXXXXX
ASC01 Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-startKit XXXX
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
OT/EHR18-60EmergencyHeatRelaykit XXXXXXX
OT18-60A² OutdoorThermostatw/LockoutStat XXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit X X X
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Condensing units and heatp pumps with reciprocating compressors require the use of start-assist components when used in conjunction with an indoor coil using a
non-bleed expansion valve refrigerant metering device.
Model Description ASZ14
018 ASZ14 024 ASZ14 030 ASZ14 036 ASZ14 042 ASZ14 048 ASZ14 060
AFE18-60A All-FuelKit XXXXXXX
ASC01 Anti-ShortCycleKit XXXXXXX
CSR-U-1 Hard-startKit XXXX
CSR-U-2 Hard-start Kit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXXX
OT18-60A2OutdoorThermostat XXXXXXX
OY-EHR18-60EmergencyHeatRelatKit XXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit X X X
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Condensing units and heatp pumps with reciprocating compressors require the use of start-assist components when used in conjunction with an indoor coil using a
non-bleed expansion valve refrigerant metering device.

ACCESSORIES
12
SSZ16
ASZ16
Model Description SSZ16
024 SSZ16 030 SSZ16 036 SSZ16 042 SSZ16 048 SSZ16 060
AFE18-60A All-FuelKit XXXXXX
ASC01 Anti-ShortCycleKit XXXXXX
CSR-U-1 Hard-start Kit X X X
CSR-U-2 Hard-startKit XXXX
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXX
OT/EHR18-60EmergencyHeatRelayKit XXXXXX
OY/EHR18-60EmergencyHeatRelayKit XXXXXX
OT18-60A² OutdoorThermostatw/LockoutStatXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit X X
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of start-assist
components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering device.
Model Description ASZ16
024 ASZ16 030 ASZ16 036 ASZ16 042 ASZ16 048 ASZ16 060
AFE18-60A All-FuelKit XXXXXX
ASC01 Anti-ShortCycleKit XXXXXX
CSR-U-1 Hard-start Kit X X X
CSR-U-2 Hard-start Kit X X X X
CSR-U-3 Hard-start Kit XX
FSK01A1FreezeProtectionKit XXXXXX
OT/EHR18-60EmergencyHeatRelayKit XXXXXX
OY/EHR18-60EmergencyHeatRelayKit XXXXXX
OT18-60A² OutdoorThermostatw/LockoutStatXXXXXX
TX2N4³ TXV Kit X
TX3N4³ TXV Kit X X
TX5N4³ TXV Kit XXX
1Installed on indoor coil
2Required for heat pump applications where ambient temperatures fall below 0°F with 50% or higher relative humidy.
3Field-installed, non-bleed, expansion valve kit — Condensing units and heat pumps with reciprocating compressors require the use of start-assist
components when used in conjunction with an indoor coil using a non-bleed thermal expansion valve refrigerant metering device.

13
ACCESSORIES
SUCTION LINE BULB
1/4 FLARE CONNECTION
EXPANSION VALVE
EVAPORATOR COIL
REMOVE BEFORE INSTALLING EXPANSION VALVE
SEAL SUPPLIED W/ KIT
SEAL SUPPLIED W/ KIT
BULB TO BE LOCATED
AT 10 OR 2 O'CLOCK
ForApplicationsrequiring
afieldinstalledaccessfitting
TAILPIECE
3/8"-
SWEAT
7/8" NUT
DISTRIBUTOR
BODY
PISTON
SEAL
EVAPORATOR COIL
1/4' FLARE
CONNECTION
BULB SUCTION LINE
EXPANSION VALVE
REMOVE BEFORE
INSTALLING
EXPANSION VALVE
SEAL SUPPLIED W/ KIT
SEAL SUPPLIED W/ KIT
BULB TOBE LOCATED
AT 10 OR 2 O'CLOCK
TAILPIECE
3/8"-
SWEAT
7/8" NUT
DISTRIBUTOR
BODY
PISTON
SEAL
For Applications not requiring
afieldinstalledaccessfitting
EXPANSIONVALVEKITS
OT/EHR18-60
OUTDOORTHERMOSTAT&
EMERGENCYHEATRELAY
Set Point
A
djustment
Screw Set Point
Indicator
Mark
(Shown @ Oº F)
Thermostat
Dial
DEAD
DIAL
315º
45º
COLD (Turn Clockwise)
WARM (Turn Counterclockwise)
OT18-60
