Goodman GSZ14 User manual
SS-GSZ14 www.goodmanmfg.com 2/18
Supersedes 9/17
Energy-Efficient
Split System Heat Pump
Up to 15 SEER & 9.0 HSPF
1½ to 5 Tons
Cooling Capacity: 18,000 to 60,000 BTU/h
Heating Capacity: 18,000 to 60,000 BTU/h
GSZ14
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive
the 10-Year Parts Limited Warranty, online registraon must be completed within 60 days of
installaon. Online registraon is not required in California or Quebec.
Standard Features Cabinet Features
• High-eciency scroll compressor
• SmartShi® technology to
ensure quiet reliable defrost
• Factory-installed bi-ow liquid-line lter drier
• Factory-installed sucon-line accumulator
• Factory-installed compressor crankcase heater
• Factory-installed high-capacity muer
• High- and low-pressure switches
• Service valves with sweat connecons
and easy access to gauge ports
• Copper tube/enhanced aluminum n coil
• Fully charged for 15’ of tubing length
• Contactor with lug connecon
• Ground lug connecon
• AHRI Cered; ETL Listed
• Goodman® brand sound control top design
• Steel louver coil guard
• Heavy-gauge galvanized-steel cabinet
• Aracve Architectural Gray powder-paint
nish with 500-hour salt-spray approval
• Top and side maintenance access
• Service ports and controls are
accessible while unit is operang
• When properly anchored, meets the 2010
Florida Building Code unit integrity
requirements for hurricane-type winds
(Anchor bracket kits available.)
Proper sizing and installaon of equipment is crical
to achieving opmal performance. Split system air
condioners and heat pumps must be matched with
appropriate coil components to meet ENERGY STAR criteria.
Ask your contractor for details or visit www.energystar.gov.
Contents
Nomenclature........................................ 2
Product Specicaons........................... 3
Expanded Cooling Data ......................... 5
Expanded Heang Data....................... 29
Performance Data ............................... 32
AHRI Rangs ........................................ 34
Wiring Diagram.................................... 51
Dimensions .......................................... 52
Accessories .......................................... 52
2www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 3
Nomenclature
G S Z 14 036 1 AA
1 2 3 4,5 6,7,8 9 10,11
Brand Engineering *
GGoodman® Brand Major & Minor revisions
* Not used for inventory control.
Product Category
S Split System Electrical
1 - 208/230 V, 1 Phase, 60 Hz
Unit Type
X Condenser R-410A Nominal Capacity
Z Heat Pump R-410A 018 - 1½ tons 042 3½ Tons
024 - 2 tons 048 4 Tons
030 - 2½ tons 060 5 Tons
13 13 SEER 16 16 SEER 036 - 3 tons
14 14 SEER 18 18 SEER
2www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 3
Product Specifications
GSZ14
0181K*
GSZ14
0191A*
GSZ14
0241K*
GSZ14
0251A*
GSZ14
0301K*
GSZ14
0311A*
Cooling (BTU/h) 18,000 17,400 24,000 23,200 30,000 28,000
Heang (BTU/h) 18,000 18,000 24,000 23,200 30,000 31,000
Decibels 72 72 72 72 74 75
RLA 9.0 9.0 10.9 10.9 13.5 13.5
LRA 47.5 47.5 62.9 62.9 72.5 72.5
Type Scroll Scroll Scroll Scroll Scroll Scroll
Horsepower 1/6 1/6 1/6 1/6 1/6 1/6
FLA 0.95 1.1 0.95 1.1 0.95 1.10
Refrigerant Line Size¹
Liquid Line Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Line Size (“O.D.) ¾" ¾" ¾" ¾" ¾" ¾"
Refrigerant Connecon Size
Liquid Valve Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Valve Size (“O.D.) ¾" ¾" ¾" ¾" ¾" ¾”
Standard Line Set Length (max. feet) 80 80 80 80 80 80
Long Line Set Length (max. feet) ²
Equivalent Length 250 250 250 250 250 250
Linear Length 200 200 200 200 200 200
Vercal Length (outdoor below indoor) 80 80 80 80 80 80
Vercal Length (outdoor above indoor) 80 200 80 200 80 200
Valve Connecon Type Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge (oz.) 108 108 108 108 108 160
Volts/Phase (60 Hz) 208-230/1 208-230/1 208-230/1 208-230/1 208-230/1 208-230/1
Minimum Circuit Ampacity ³ 12.2 12.4 14.6 14.7 17.8 17.9
Max. Overcurrent Protecon ⁴ 20 20 25 25 30 30
Min / Max Volts 197 / 253 197 / 253 197 / 253 197 / 253 197 / 253 197/253
Electrical Conduit Size ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾" 1/2" or 3/4"
Equipment Weight (lbs.) 143 143 143 143 171 186
Ship Weight (lbs) 154 154 154 154 182 206
NO NO NO
Proper sizing and installaon of equipment is crical to achieving opmal performance. Split system air condioners and heat pumps must
be matched with appropriate coil components to meet ENERGY STAR criteria. Ask your contractor for details or visit www.energystar.gov.
The www.energystar.gov website provides up-to-date system combinaons cered to meet ENERGY STAR requirements. See Page 24 for all ENERGY STAR cered combinaons
as of this document’s revision date.
¹ Tested and rated in accordance with ARI Standard 210/240
² Reference TP-107* for addional applicaon requirements
³ Wire size should be determined in accordance with Naonal Electrical Codes; extensive wire runs will require larger wire sizes
⁴ Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
• Always check the S&R plate for electrical data on the unit being installed.
• Installer will need to supply ⅞” to 1⅛” adapters for sucon line connecons.
• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be adjusted per Installaon Instrucons Final Charge Procedure.
• Installaon of these units may require the specied TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT
NOT THE INDOOR COIL.
4www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 5
Product Specifications (cont.)
GSZ14
0361K*
GSZ14
0371A*
GSZ14
0421K*
GSZ14
0481K*
GSZ14
0491K*
GSZ14
0601K*
Cooling (BTU/h) 36,000 33,000 42,000 48,000 48,000 60,000
Heang (BTU/h) 36,000 34,000 42,000 48,000 48,000 60,000
Decibels 74 73 75 75 76 76
RLA 15.4 14.1 16.7 18.5 19.9 26.4
LRA 83.9 72.2 109.0 124.0 109.0 134.0
Type Scroll Scroll Scroll Scroll Scroll Scroll
Horsepower 1/6 1/4 1/6 1/4 1/6 1/4
FLA 0.95 1.30 1.1 1.30 1.1 1.30
Refrigerant Line Size¹
Liquid Line Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Line Size (“O.D.) ⅞" ⅞" 1⅛" 1⅛" 1⅛" 1⅛"
Refrigerant Connecon Size
Liquid Valve Size (“O.D.) ⅜" ⅜" ⅜" ⅜" ⅜" ⅜"
Sucon Valve Size (“O.D.) ¾" ⅞" ⅞" ⅞” ⅞" ⅞"
Standard Line Set Length (max. feet) 80 80 80 80 80 80
Long Line Set Length (max. feet) ²
Equivalent Length 250 250 250 250 250 250
Linear Length 200 200 200 200 200 200
Vercal Length (outdoor below indoor) 80 80 80 80 80 80
Vercal Length (outdoor above indoor) 80 200 80 80 80 80
Valve Connecon Type Sweat Sweat Sweat Sweat Sweat Sweat
Refrigerant Charge 115 175 153 157 192 205
Volts/Phase (60 Hz) 208-230/1 208-230/1 208-230/1 208-230/1 208-230/1 208-230/1
Minimum Circuit Ampacity ³ 20.2 18.9 22.0 24.4 26.0 34.3
Max. Overcurrent Protecon ⁴ 35 30 35 40 45 60
Min / Max Volts 197 / 253 197/253 197 / 253 197 / 253 197 / 253 197 / 253
Electrical Conduit Size ½" or ¾" 1/2" or 3/4" ½" or ¾" ½" or ¾" ½" or ¾" ½" or ¾"
Equipment Weight (lbs.) 173 220 191 226 273 277
Ship Weight (lbs) 184 240 207 237 288 292
NO NO NO
Proper sizing and installaon of equipment is crical to achieving opmal performance. Split system air condioners and heat pumps must
be matched with appropriate coil components to meet ENERGY STAR criteria. Ask your contractor for details or visit www.energystar.gov.
The www.energystar.gov website provides up-to-date system combinaons cered to meet ENERGY STAR requirements. See Page 24 for all ENERGY STAR cered combinaons
as of this document’s revision date.
¹ Tested and rated in accordance with ARI Standard 210/240
² Reference TP-107* for addional applicaon requirements
³ Wire size should be determined in accordance with Naonal Electrical Codes; extensive wire runs will require larger wire sizes
⁴ Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
• Always check the S&R plate for electrical data on the unit being installed.
• Installer will need to supply ⅞” to 1⅛” adapters for sucon line connecons.
• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be adjusted per Installaon Instrucons Final Charge Procedure.
• Installaon of these units requires the specied TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT NOT
THE INDOOR COIL.
4www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 5
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
525
MBh 17.9 18.1 18.7 - 17.7 18.0 18.5 - 17.3 17.5 18.0 - 16.4 16.7 17.2 - 15.5 15.7 16.3 -14.6 14.8 15.4 -
S/T 0.62 0.54 0.40 - 0.62 0.55 0.40 - 0.65 0.57 0.43 - 1.00 0.59 0.45 - 1.00 0.61 0.47 - 1.00 0.67 0.53 -
∆T 19 17 14 - 19 17 14 - 19 18 14 - 19 17 14 - 19 17 14 - 20 18 15 -
kW 1.06 1.05 1.05 - 1.17 1.17 1.17 - 1.30 1.30 1.30 - 1.45 1.45 1.44 - 1.61 1.60 1.60 - 1.79 1.79 1.79 -
Amps 4.0 4.0 4.0 - 4.5 4.5 4.5 - 5.1 5.1 5.1 - 5.8 5.8 5.8 - 6.5 6.5 6.5 - 7.4 7.4 7.4 -
HI PR 244 245 247 - 283 284 286 - 323 325 326 -367 368 370 - 414 415 417 - 464 465 467 -
LO PR 125 126 129 - 132 134 137 - 139 141 144 - 145 146 149 - 150 152 155 - 157 159 162 -
610
MBh 18.1 18.4 18.9 - 18.0 18.2 18.8 - 17.5 17.8 18.3 - 16.7 17.0 17.5 - 15.7 16.0 16.5 - 14.8 15.1 15.6 -
S/T 0.69 0.61 0.47 - 0.69 0.62 0.48 - 0.72 0.64 0.50 - 1.00 0.66 0.52 - 1.00 0.69 0.54 - 1.00 0.74 0.60 -
∆T 18 16 13 - 18 16 13 - 18 16 13 - 18 16 13 - 18 16 13 - 19 17 14 -
kW 1.06 1.06 1.06 - 1.18 1.18 1.18 - 1.31 1.31 1.31 - 1.45 1.45 1.45 - 1.61 1.61 1.61 - 1.80 1.80 1.80 -
Amps 4.0 4.0 4.0 - 4.6 4.6 4.6 - 5.2 5.2 5.2 - 5.8 5.8 5.8 - 6.6 6.6 6.5 - 7.4 7.4 7.4 -
HI PR 247 248 250 - 285 286 288 - 326 327 329 - 369 370 372 - 416 417 419 - 466 468 469 -
LO PR 127 128 131 - 134 136 139 - 141 143 146 - 147 148 151 - 152 154 157 - 159 161 164 -
675
MBh 18.4 18.6 19.2 - 18.2 18.5 19.0 - 17.8 18.0 18.5 - 16.9 17.2 17.7 - 16.0 16.2 16.8 - 15.1 15.3 15.9 -
S/T 0.72 0.64 0.50 - 0.73 0.65 0.51 - 0.75 0.67 0.53 - 1.00 0.69 0.55 - 1.00 0.72 0.58 - 1.00 0.77 0.63 -
∆T 17 16 12 - 17 15 12 - 17 16 12 - 17 15 12 - 17 15 12 - 18 16 13 -
kW 1.07 1.07 1.06 - 1.18 1.18 1.18 - 1.32 1.31 1.31 - 1.46 1.46 1.46 -1.62 1.62 1.61 - 1.80 1.80 1.80 -
Amps 4.1 4.1 4.0 - 4.6 4.6 4.6 - 5.2 5.2 5.2 - 5.8 5.8 5.8 - 6.6 6.6 6.6 - 7.4 7.4 7.4 -
HI PR 248 250 251 - 287 288 290 - 328 329 330 - 371 372 374 - 418 419 421 - 468 469 471 -
LO PR 128 130 133 - 136 138 141 - 143 144 147 - 148 150 153 - 154 155 159 - 161 162 166 -
75
525
MBh 17.9 18.1 18.7 19.5 17.7 18.0 18.5 19.3 17.3 17.5 18.1 18.9 16.5 16.7 17.2 18.1 15.5 15.7 16.3 17.1 14.6 14.8 15.4 16.2
S/T 0.75 0.67 0.53 0.38 0.76 0.68 0.54 0.39 1.00 0.70 0.56 0.42 1.00 0.72 0.58 0.44 1.00 0.75 0.61 0.46 1.00 1.00 0.66 0.51
∆T 23 21 18 15 23 21 18 15 23 22 18 15 23 21 18 15 23 21 18 14 24 22 19 15
kW 1.05 1.05 1.05 1.06 1.17 1.17 1.17 1.18 1.30 1.30 1.30 1.31 1.45 1.45 1.44 1.45 1.61 1.60 1.60 1.61 1.79 1.79 1.79 1.80
Amps 4.0 4.0 4.0 4.0 4.5 4.5 4.5 4.6 5.1 5.1 5.1 5.2 5.8 5.8 5.8 5.8 6.5 6.5 6.5 6.5 7.4 7.4 7.4 7.4
HI PR 245 246 247 252 283 284 286 290 324 325 326 331 367 368 370 374 414 415 417 421 464 465 467 471
LO PR 125 126 129 135 132 134 137 142 139 141 144 149 145 146 149 155 150 152 155 160 157 159 162 167
610
MBh 18.2 18.4 18.9 19.8 18.0 18.2 18.8 19.6 17.5 17.8 18.3 19.1 16.7 17.0 17.5 18.3 15.7 16.0 16.5 17.3 14.8 15.1 15.6 16.4
S/T 0.82 0.74 0.60 0.46 1.00 0.75 0.61 0.46 1.00 0.78 0.64 0.49 1.00 0.80 0.66 0.51 1.00 0.82 0.68 0.53 1.00 1.00 0.73 0.58
∆T 22 20 17 13 22 20 17 13 22 20 17 14 22 20 17 13 22 20 17 13 23 21 18 14
kW 1.06 1.06 1.06 1.07 1.18 1.18 1.18 1.19 1.31 1.31 1.31 1.32 1.45 1.45 1.45 1.46 1.61 1.61 1.61 1.62 1.80 1.80 1.80 1.80
Amps 4.0 4.0 4.0 4.1 4.6 4.6 4.6 4.6 5.2 5.2 5.2 5.2 5.8 5.8 5.8 5.9 6.6 6.5 6.5 6.6 7.4 7.4 7.4 7.4
HI PR 247 248 250 254 286 287 288 293 326 327 329 333 370 371 372 377 417 418 419 424 467 468 469 474
LO PR 127 128 132 137 134 136 139 144 141 143 146 151 147 148 151 157 152 154 157 162 159 161 164 169
675
MBh 18.4 18.6 19.2 20.0 18.2 18.5 19.0 19.8 17.8 18.0 18.5 19.4 17.0 17.2 17.7 18.6 16.0 16.2 16.8 17.6 15.1 15.3 15.9 16.7
S/T 0.85 0.77 0.63 0.49 1.00 0.78 0.64 0.49 1.00 0.81 0.67 0.52 1.00 0.83 0.69 0.54 1.00 1.00 0.71 0.56 1.00 1.00 0.76 0.62
∆T 21 19 16 13 21 19 16 13 21 20 16 13 21 19 16 13 21 19 16 12 22 20 17 13
kW 1.07 1.06 1.06 1.07 1.18 1.18 1.18 1.19 1.32 1.31 1.31 1.32 1.46 1.46 1.45 1.46 1.62 1.62 1.61 1.62 1.80 1.80 1.80 1.81
Amps 4.1 4.0 4.0 4.1 4.6 4.6 4.6 4.6 5.2 5.2 5.2 5.2 5.8 5.8 5.8 5.9 6.6 6.6 6.6 6.6 7.4 7.4 7.4 7.5
HI PR 249 250 251 256 287 288 290 294 328 329 331 335 371 372 374 378 418 419 421 425 468 469 471 475
LO PR 129 130 133 139 136 138 141 146 143 144 147 153 148 150 153 158 154 155 159 164 161 162 166 171
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
Expanded Cooling Data — GSZ140181K* + ARUF25B14** + TXV
6www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 7
Expanded Cooling Data — GSZ140181K* + ARUF25B14** + TXV (cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
525
MBh 18.0 18.2 18.8 19.6 17.8 18.1 18.6 19.4 17.4 17.6 18.1 19.0 16.6 16.8 17.3 18.2 15.6 15.8 16.4 17.2 14.7 14.9 15.5 16.3
S/T 1.00 0.80 0.66 0.51 1.00 0.81 0.67 0.52 1.00 0.83 0.69 0.55 1.00 1.00 0.71 0.57 1.00 1.00 0.74 0.59 1.00 1.00 0.79 0.64
∆T 27 25 22 19 27 25 22 19 27 25 22 19 27 25 22 19 27 25 22 18 28 26 23 19
kW 1.06 1.05 1.05 1.06 1.17 1.17 1.17 1.18 1.30 1.30 1.30 1.31 1.45 1.45 1.44 1.45 1.61 1.60 1.60 1.61 1.79 1.79 1.79 1.80
Amps 4.0 4.0 4.0 4.0 4.5 4.5 4.5 4.6 5.1 5.1 5.1 5.2 5.8 5.8 5.8 5.8 6.5 6.5 6.5 6.6 7.4 7.4 7.4 7.4
HI PR 245 246 248 252 284 285 286 291 324 325 327 331 368 369 370 375 415 416 417 422 465 466 468 472
LO PR 125 127 130 135 133 134 138 143 140 141 144 150 145 147 150 155 151 152 155 161 158 159 162 168
610
MBh 18.2 18.5 19.0 19.8 18.1 18.3 18.9 19.7 17.6 17.9 18.4 19.2 16.8 17.1 17.6 18.4 15.8 16.1 16.6 17.4 14.9 15.2 15.7 16.5
S/T 1.00 0.87 0.73 0.59 1.00 0.88 0.74 0.59 1.00 0.91 0.77 0.62 1.00 1.00 0.79 0.64 1.00 1.00 0.81 0.66 1.00 1.00 0.86 0.71
∆T 26 24 21 17 26 24 21 17 26 24 21 18 26 24 21 17 26 24 20 17 27 25 22 18
kW 1.06 1.06 1.06 1.07 1.18 1.18 1.18 1.19 1.31 1.31 1.31 1.32 1.45 1.45 1.45 1.46 1.61 1.61 1.61 1.62 1.80 1.80 1.80 1.81
Amps 4.0 4.0 4.0 4.1 4.6 4.6 4.6 4.6 5.2 5.2 5.2 5.2 5.8 5.8 5.8 5.9 6.6 6.6 6.5 6.6 7.4 7.4 7.4 7.4
HI PR 247 248 250 254 286 287 289 293 326 328 329 334 370 371 373 377 417 418 420 424 467 468 470 474
LO PR 127 129 132 137 135 136 140 145 142 143 146 152 147 149 152 157 153 154 157 163 160 161 164 170
675
MBh 18.5 18.7 19.3 20.1 18.3 18.6 19.1 19.9 17.9 18.1 18.6 19.5 17.0 17.3 17.8 18.7 16.1 16.3 16.9 17.7 15.2 15.4 16.0 16.8
S/T 1.00 0.90 0.76 0.62 1.00 0.91 0.77 0.62 1.00 0.94 0.80 0.65 1.00 1.00 0.82 0.67 1.00 1.00 0.84 0.69 1.00 1.00 0.89 0.74
∆T 25 23 20 17 25 23 20 17 25 24 20 17 25 23 20 17 25 23 20 16 26 24 21 17
kW 1.07 1.07 1.06 1.07 1.18 1.18 1.18 1.19 1.32 1.31 1.31 1.32 1.46 1.46 1.46 1.46 1.62 1.62 1.61 1.62 1.80 1.80 1.80 1.81
Amps 4.1 4.1 4.0 4.1 4.6 4.6 4.6 4.6 5.2 5.2 5.2 5.2 5.8 5.8 5.8 5.9 6.6 6.6 6.6 6.6 7.4 7.4 7.4 7.5
HI PR 249 250 252 256 288 289 291 295 328 329 331 335 372 373 375 379 419 420 422 426 469 470 472 476
LO PR 129 131 134 139 137 138 141 147 143 145 148 153 149 150 154 159 154 156 159 165 161 163 166 171
85
525
MBh 18.3 18.5 19.1 19.9 18.1 18.4 18.9 19.7 17.7 17.9 18.4 19.3 16.9 17.1 17.6 18.5 15.9 16.1 16.7 17.5 15.0 15.2 15.8 16.6
S/T 1.00 0.91 0.77 0.62 1.00 1.00 0.77 0.63 1.00 1.00 0.80 0.65 1.00 1.00 0.82 0.67 1.00 1.00 0.84 0.69 1.00 1.00 1.00 0.75
∆T 31 29 25 22 30 29 25 22 31 29 26 22 30 29 25 22 30 28 25 22 31 30 26 23
kW 1.06 1.06 1.05 1.06 1.18 1.17 1.17 1.18 1.31 1.31 1.30 1.31 1.45 1.45 1.45 1.45 1.61 1.61 1.60 1.61 1.79 1.79 1.79 1.80
Amps 4.0 4.0 4.0 4.0 4.6 4.6 4.5 4.6 5.2 5.2 5.1 5.2 5.8 5.8 5.8 5.8 6.5 6.5 6.5 6.6 7.4 7.4 7.4 7.4
HI PR 246 247 249 253 285 286 288 292 325 326 328 332 369 370 372 376 416 417 419 423 466 467 469 473
LO PR 127 129 132 137 135 136 140 145 141 143 146 151 147 149 152 157 153 154 157 163 160 161 164 170
610
MBh 18.5 18.8 19.3 20.2 18.4 18.6 19.2 20.0 17.9 18.2 18.7 19.5 17.1 17.4 17.9 18.7 16.1 16.4 16.9 17.7 15.2 15.5 16.0 16.8
S/T 1.00 0.98 0.84 0.69 1.00 1.00 0.84 0.70 1.00 1.00 0.87 0.72 1.00 1.00 0.89 0.74 1.00 1.00 1.00 0.77 1.00 1.00 1.00 0.82
∆T 29 28 24 21 29 28 24 21 30 28 24 21 29 27 24 21 29 27 24 21 30 28 25 22
kW 1.06 1.06 1.06 1.07 1.18 1.18 1.18 1.19 1.31 1.31 1.31 1.32 1.46 1.45 1.45 1.46 1.61 1.61 1.61 1.62 1.80 1.80 1.80 1.81
Amps 4.0 4.0 4.0 4.1 4.6 4.6 4.6 4.6 5.2 5.2 5.2 5.2 5.8 5.8 5.8 5.9 6.6 6.6 6.6 6.6 7.4 7.4 7.4 7.4
HI PR 249 250 251 256 287 288 290 294 328 329 330 335 371 372 374 378 418 419 421 425 468 469 471 475
LO PR 129 131 134 139 137 138 142 147 143 145 148 154 149 151 154 159 155 156 159 165 162 163 166 172
675
MBh 18.8 19.0 19.6 20.4 18.6 18.9 19.4 20.2 18.2 18.4 18.9 19.8 17.4 17.6 18.1 19.0 16.4 16.6 17.2 18.0 15.5 15.7 16.3 17.1
S/T 1.00 1.00 0.87 0.72 1.00 1.00 0.88 0.73 1.00 1.00 0.90 0.75 1.00 1.00 0.92 0.77 1.00 1.00 1.00 0.80 1.00 1.00 1.00 0.85
∆T 29 27 23 20 29 27 23 20 29 27 24 20 28 27 23 20 28 26 23 20 29 28 24 21
kW 1.07 1.07 1.07 1.07 1.19 1.19 1.18 1.19 1.32 1.32 1.32 1.32 1.46 1.46 1.46 1.47 1.62 1.62 1.62 1.63 1.81 1.80 1.80 1.81
Amps 4.1 4.1 4.1 4.1 4.6 4.6 4.6 4.6 5.2 5.2 5.2 5.2 5.9 5.9 5.8 5.9 6.6 6.6 6.6 6.6 7.4 7.4 7.4 7.5
HI PR 250 251 253 257 289 290 292 296 329 330 332 336 373 374 376 380 420 421 423 427 470 471 473 477
LO PR 131 132 136 141 139 140 143 149 145 147 150 155 151 152 156 161 156 158 161 166 163 165 168 173
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
6www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 7
Expanded Cooling Data — GSZ140191A* / ARUF25B14A*+TXV
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
525
MBh 17.7 17.9 18.4 - 17.5 17.8 18.3 - 17.0 17.3 17.8 - 16.3 16.5 17.0 - 15.3 15.5 16.1 - 14.4 14.6 15.2 -
S/T 0.62 0.54 0.40 - 0.63 0.55 0.41 - 0.65 0.57 0.43 - 1.00 0.59 0.45 - 1.00 0.62 0.48 - 1.00 0.67 0.53 -
∆T 19 17 14 - 19 17 14 - 19 18 14 - 19 17 14 - 19 17 14 - 20 18 15 -
kW 1.13 1.12 1.12 - 1.24 1.24 1.24 - 1.38 1.38 1.37 - 1.52 1.52 1.52 - 1.68 1.68 1.68 - 1.87 1.87 1.86 -
Amps 4.3 4.3 4.3 - 4.9 4.9 4.8 - 5.5 5.5 5.4 - 6.1 6.1 6.1 -6.9 6.8 6.8 - 7.7 7.7 7.7 -
Hi PR 236 237 238 - 273 274 275 - 312 313 314 - 354 355 356 - 399 400 402 - 447 448 450 -
Lo PR 125 127 130 - 133 134 137 - 139 141 144 - 145 147 150 - 151 152 155 - 157 159 162 -
614
MBh 17.9 18.2 18.7 - 17.8 18.0 18.6 - 17.3 17.6 18.1 - 16.5 16.8 17.3 - 15.5 15.8 16.3 - 14.7 14.9 15.4 -
S/T 0.70 0.62 0.48 - 0.70 0.62 0.48 - 0.73 0.65 0.51 - 1.00 0.67 0.53 - 1.00 0.69 0.55 - 1.00 0.75 0.61 -
∆T 18 16 13 - 18 16 13 - 18 16 13 - 18 16 13 - 18 16 13 - 19 17 14 -
kW 1.13 1.13 1.13 - 1.25 1.25 1.25 - 1.38 1.38 1.38 - 1.53 1.53 1.52 - 1.69 1.69 1.68 - 1.87 1.87 1.87 -
Amps 4.3 4.3 4.3 - 4.9 4.9 4.9 - 5.5 5.5 5.5 - 6.2 6.1 6.1 -6.9 6.9 6.9 - 7.7 7.7 7.7 -
Hi PR 238 239 241 - 275 276 278 - 314 315 317 - 356 357 359 - 401 402 404 - 450 451 452 -
Lo PR 127 129 132 - 135 136 140 - 141 143 146 - 147 149 152 - 153 154 157 - 160 161 164 -
675
MBh 18.2 18.4 18.9 - 18.0 18.2 18.8 - 17.5 17.8 18.3 - 16.7 17.0 17.5 - 15.8 16.0 16.5 - 14.9 15.1 15.7 -
S/T 0.73 0.65 0.51 - 0.73 0.65 0.51 - 0.76 0.68 0.54 - 1.00 0.70 0.56 - 1.00 0.72 0.58 - 1.00 0.78 0.64 -
∆T 17 15 12 - 17 15 12 - 17 16 12 - 17 15 12 - 17 15 12 - 18 16 13 -
kW 1.14 1.14 1.13 - 1.26 1.25 1.25 - 1.39 1.39 1.38 - 1.53 1.53 1.53 - 1.69 1.69 1.69 - 1.88 1.88 1.88 -
Amps 4.4 4.4 4.4 - 4.9 4.9 4.9 - 5.5 5.5 5.5 - 6.2 6.2 6.2 -6.9 6.9 6.9 - 7.8 7.8 7.7 -
Hi PR 239 240 242 - 277 278 279 - 316 317 318 - 358 359 360 - 403 404 406 - 451 452 454 -
Lo PR 129 130 134 - 136 138 141 - 143 145 148 - 149 150 153 - 154 156 159 - 161 163 166 -
75
525
MBh 17.7 17.9 18.5 19.3 17.5 17.8 18.3 19.1 17.1 17.3 17.8 18.6 16.3 16.5 17.0 17.8 15.3 15.5 16.1 16.9 14.4 14.7 15.2 16.0
S/T 0.76 0.68 0.53 0.38 0.76 0.68 0.54 0.39 1.00 0.71 0.57 0.42 1.00 0.73 0.59 0.44 1.00 0.75 0.61 0.46 1.00 1.00 0.66 0.52
∆T 23 21 18 15 23 21 18 15 23 21 18 15 23 21 18 14 23 21 18 14 24 22 19 15
kW 1.12 1.12 1.12 1.13 1.24 1.24 1.24 1.25 1.38 1.37 1.37 1.38 1.52 1.52 1.52 1.52 1.68 1.68 1.68 1.68 1.87 1.87 1.86 1.87
Amps 4.3 4.3 4.3 4.3 4.9 4.8 4.8 4.9 5.5 5.5 5.4 5.5 6.1 6.1 6.1 6.1 6.8 6.8 6.8 6.9 7.7 7.7 7.7 7.7
Hi PR 236 237 238 243 273 274 276 280 312 313 315 319 354 355 357 361 399 400 402 406 448 449 450 454
Lo PR 125 127 130 135 133 134 137 143 139 141 144 149 145 147 150 155 151 152 155 161 158 159 162 168
614
MBh 17.9 18.2 18.7 19.5 17.8 18.0 18.6 19.4 17.3 17.6 18.1 18.9 16.5 16.8 17.3 18.1 15.6 15.8 16.3 17.1 14.7 14.9 15.4 16.3
S/T 0.83 0.75 0.61 0.46 1.00 0.76 0.62 0.47 1.00 0.79 0.64 0.49 1.00 0.81 0.66 0.51 1.00 0.83 0.69 0.54 1.00 1.00 0.74 0.59
∆T 22 20 17 13 22 20 17 13 22 20 17 14 22 20 17 13 21 20 16 13 23 21 17 14
kW 1.13 1.13 1.13 1.14 1.25 1.25 1.25 1.26 1.38 1.38 1.38 1.39 1.53 1.53 1.52 1.53 1.69 1.69 1.68 1.69 1.87 1.87 1.87 1.88
Amps 4.3 4.3 4.3 4.4 4.9 4.9 4.9 4.9 5.5 5.5 5.5 5.5 6.1 6.1 6.1 6.2 6.9 6.9 6.9 6.9 7.7 7.7 7.7 7.8
Hi PR 238 239 241 245 275 276 278 282 314 315 317 321 356 357 359 363 402 403 404 408 450 451 453 457
Lo PR 127 129 132 137 135 136 140 145 142 143 146 152 147 149 152 157 153 154 157 163 160 161 164 170
675
MBh 18.2 18.4 18.9 19.7 18.0 18.3 18.8 19.6 17.5 17.8 18.3 19.1 16.7 17.0 17.5 18.3 15.8 16.0 16.6 17.4 14.9 15.1 15.7 16.5
S/T 0.86 0.78 0.64 0.49 1.00 0.79 0.65 0.50 1.00 0.82 0.67 0.52 1.00 0.84 0.69 0.54 1.00 1.00 0.72 0.57 1.00 1.00 0.77 0.62
∆T 21 19 16 13 21 19 16 13 21 19 16 13 21 19 16 13 21 19 16 12 22 20 17 13
kW 1.14 1.14 1.13 1.14 1.25 1.25 1.25 1.26 1.39 1.39 1.38 1.39 1.53 1.53 1.53 1.54 1.69 1.69 1.69 1.70 1.88 1.88 1.88 1.88
Amps 4.4 4.4 4.4 4.4 4.9 4.9 4.9 4.9 5.5 5.5 5.5 5.5 6.2 6.2 6.2 6.2 6.9 6.9 6.9 6.9 7.8 7.8 7.7 7.8
Hi PR 240 241 242 246 277 278 280 284 316 317 319 323 358 359 361 365 403 404 406 410 451 452 454 458
Lo PR 129 130 134 139 136 138 141 147 143 145 148 153 149 150 153 159 154 156 159 164 161 163 166 171
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
8www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 9
Expanded Cooling Data — GSZ140191A* / ARUF25B14A*+TXV (cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
525
MBh 17.8 18.0 18.5 19.4 17.6 17.9 18.4 19.2 17.1 17.4 17.9 18.7 16.4 16.6 17.1 17.9 15.4 15.6 16.2 17.0 14.5 14.7 15.3 16.1
S/T 1.00 0.81 0.67 0.52 1.00 0.81 0.67 0.52 1.00 0.84 0.70 0.55 1.00 1.00 0.72 0.57 1.00 1.00 0.74 0.59 1.00 1.00 0.80 0.65
∆T 27 25 22 18 27 25 22 18 27 25 22 19 27 25 22 18 27 25 22 18 28 26 23 19
kW 1.13 1.12 1.12 1.13 1.24 1.24 1.24 1.25 1.38 1.38 1.37 1.38 1.52 1.52 1.52 1.53 1.68 1.68 1.68 1.69 1.87 1.87 1.86 1.87
Amps 4.3 4.3 4.3 4.3 4.9 4.9 4.8 4.9 5.5 5.5 5.4 5.5 6.1 6.1 6.1 6.1 6.9 6.8 6.8 6.9 7.7 7.7 7.7 7.7
Hi PR 236 237 239 243 273 274 276 280 312 313 315 319 354 355 357 361 400 401 402 406 448 449 451 455
Lo PR 126 127 130 136 133 135 138 143 140 141 145 150 146 147 150 156 151 153 156 161 158 160 163 168
614
MBh 18.0 18.3 18.8 19.6 17.9 18.1 18.7 19.5 17.4 17.7 18.2 19.0 16.6 16.9 17.4 18.2 15.6 15.9 16.4 17.2 14.8 15.0 15.5 16.3
S/T 1.00 0.88 0.74 0.59 1.00 0.89 0.75 0.60 1.00 0.92 0.77 0.63 1.00 1.00 0.80 0.65 1.00 1.00 0.82 0.67 1.00 1.00 0.87 0.72
∆T 26 24 21 17 26 24 21 17 26 24 21 17 26 24 21 17 25 24 20 17 26 25 21 18
kW 1.13 1.13 1.13 1.14 1.25 1.25 1.25 1.26 1.38 1.38 1.38 1.39 1.53 1.53 1.52 1.53 1.69 1.69 1.68 1.69 1.87 1.87 1.87 1.88
Amps 4.3 4.3 4.3 4.4 4.9 4.9 4.9 4.9 5.5 5.5 5.5 5.5 6.2 6.1 6.1 6.2 6.9 6.9 6.9 6.9 7.7 7.7 7.7 7.8
Hi PR 239 240 241 245 276 277 278 283 315 316 317 322 357 358 359 364 402 403 405 409 450 451 453 457
Lo PR 128 129 133 138 135 137 140 145 142 144 147 152 148 149 152 158 153 155 158 163 160 162 165 170
675
MBh 18.3 18.5 19.0 19.8 18.1 18.3 18.9 19.7 17.6 17.9 18.4 19.2 16.8 17.1 17.6 18.4 15.9 16.1 16.6 17.5 15.0 15.2 15.8 16.6
S/T 1.00 0.91 0.77 0.62 1.00 0.92 0.78 0.63 1.00 0.95 0.80 0.66 1.00 1.00 0.83 0.68 1.00 1.00 0.85 0.70 1.00 1.00 0.90 0.75
∆T 25 23 20 16 25 23 20 16 25 23 20 17 25 23 20 16 25 23 20 16 26 24 21 17
kW 1.14 1.14 1.13 1.14 1.26 1.25 1.25 1.26 1.39 1.39 1.38 1.39 1.53 1.53 1.53 1.54 1.69 1.69 1.69 1.70 1.88 1.88 1.88 1.88
Amps 4.4 4.4 4.4 4.4 4.9 4.9 4.9 4.9 5.5 5.5 5.5 5.5 6.2 6.2 6.2 6.2 6.9 6.9 6.9 6.9 7.8 7.8 7.7 7.8
Hi PR 240 241 243 247 277 278 280 284 316 317 319 323 358 359 361 365 404 405 406 410 452 453 455 459
Lo PR 129 131 134 139 137 139 142 147 144 145 148 154 149 151 154 159 155 156 160 165 162 163 167 172
85
525
MBh 18.1 18.3 18.8 19.7 17.9 18.2 18.7 19.5 17.4 17.7 18.2 19.0 16.7 16.9 17.4 18.2 15.7 15.9 16.5 17.3 14.8 15.0 15.6 16.4
S/T 1.00 0.91 0.77 0.62 1.00 1.00 0.78 0.63 1.00 1.00 0.80 0.66 1.00 1.00 0.83 0.68 1.00 1.00 0.85 0.70 1.00 1.00 1.00 0.75
∆T 30 29 25 22 30 28 25 22 30 29 25 22 30 28 25 22 30 28 25 22 31 29 26 23
kW 1.13 1.13 1.12 1.13 1.25 1.25 1.24 1.25 1.38 1.38 1.38 1.38 1.52 1.52 1.52 1.53 1.68 1.68 1.68 1.69 1.87 1.87 1.87 1.88
Amps 4.3 4.3 4.3 4.4 4.9 4.9 4.9 4.9 5.5 5.5 5.5 5.5 6.1 6.1 6.1 6.2 6.9 6.9 6.8 6.9 7.7 7.7 7.7 7.7
Hi PR 237 238 240 244 275 276 277 281 314 315 316 320 356 357 358 362 401 402 403 408 449 450 452 456
Lo PR 128 129 132 138 135 137 140 145 142 143 147 152 147 149 152 158 153 155 158 163 160 161 165 170
614
MBh 18.3 18.6 19.1 19.9 18.2 18.4 19.0 19.8 17.7 18.0 18.5 19.3 16.9 17.2 17.7 18.5 15.9 16.2 16.7 17.5 15.1 15.3 15.8 16.6
S/T 1.00 0.99 0.85 0.70 1.00 1.00 0.85 0.71 1.00 1.00 0.88 0.73 1.00 1.00 0.90 0.75 1.00 1.00 1.00 0.77 1.00 1.00 1.00 0.83
∆T 29 27 24 21 29 27 24 21 29 27 24 21 29 27 24 21 29 27 24 20 30 28 25 21
kW 1.13 1.13 1.13 1.14 1.25 1.25 1.25 1.26 1.39 1.38 1.38 1.39 1.53 1.53 1.53 1.54 1.69 1.69 1.69 1.70 1.88 1.88 1.87 1.88
Amps 4.4 4.4 4.3 4.4 4.9 4.9 4.9 4.9 5.5 5.5 5.5 5.5 6.2 6.2 6.1 6.2 6.9 6.9 6.9 6.9 7.8 7.7 7.7 7.8
Hi PR 240 241 242 246 277 278 280 284 316 317 319 323 358 359 361 365 403 404 406 410 451 452 454 458
Lo PR 130 131 134 140 137 139 142 147 144 145 149 154 150 151 154 160 155 157 160 165 162 164 167 172
675
MBh 18.6 18.8 19.3 20.1 18.4 18.6 19.2 20.0 17.9 18.2 18.7 19.5 17.1 17.4 17.9 18.7 16.2 16.4 16.9 17.8 15.3 15.5 16.1 16.9
S/T 1.00 1.00 0.88 0.73 1.00 1.00 0.88 0.74 1.00 1.00 0.91 0.76 1.00 1.00 0.93 0.78 1.00 1.00 1.00 0.80 1.00 1.00 1.00 0.86
∆T 28 27 23 20 28 27 23 20 29 27 23 20 28 26 23 20 28 26 23 20 29 27 24 21
kW 1.14 1.14 1.14 1.15 1.26 1.26 1.25 1.26 1.39 1.39 1.39 1.40 1.53 1.53 1.53 1.54 1.69 1.69 1.69 1.70 1.88 1.88 1.88 1.89
Amps 4.4 4.4 4.4 4.4 4.9 4.9 4.9 4.9 5.5 5.5 5.5 5.6 6.2 6.2 6.2 6.2 6.9 6.9 6.9 6.9 7.8 7.8 7.8 7.8
Hi PR 241 242 244 248 278 279 281 285 317 318 320 324 359 360 362 366 405 406 407 411 453 454 456 460
Lo PR 131 133 136 141 139 140 144 149 146 147 150 156 151 153 156 161 157 158 161 167 164 165 168 174
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
8www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 9
Expanded Cooling Data — GSZ140241K* + ARUF25B14** + TXV
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
700
MBh 23.7 24.0 24.7 - 23.4 23.8 24.5 - 22.8 23.2 23.9 - 21.7 22.1 22.8 - 20.4 20.8 21.5 - 19.2 19.6 20.3 -
S/T 0.59 0.51 0.37 - 0.60 0.52 0.37 - 0.62 0.54 0.40 - 0.65 0.56 0.42 - 1.00 0.59 0.44 - 1.00 0.64 0.50 -
∆T 19 17 14 - 19 17 14 - 19 17 14 - 19 17 14 - 19 17 14 - 20 18 15 -
kW 1.41 1.40 1.40 - 1.57 1.57 1.57 - 1.76 1.76 1.75 - 1.96 1.96 1.95 - 2.18 2.18 2.18 - 2.44 2.44 2.44 -
Amps 5.2 5.2 5.2 - 6.0 5.9 5.9 - 6.8 6.8 6.8 - 7.7 7.7 7.7 - 8.7 8.7 8.7 - 9.9 9.9 9.9 -
HI PR 249 250 252 - 288 290 291 - 330 331 333 - 374 375 377 - 422 423 425 - 474 475 476 -
LO PR 123 124 128 - 130 132 135 - 137 139 142 - 143 144 147 - 148 150 153 - 155 157 160 -
800
MBh 23.9 24.2 25.0 - 23.7 24.0 24.7 - 23.1 23.4 24.1 - 22.0 22.3 23.1 - 20.7 21.0 21.7 - 19.5 19.8 20.6 -
S/T 0.67 0.59 0.44 - 0.67 0.59 0.45 - 0.70 0.62 0.48 - 1.00 0.64 0.50 - 1.00 0.66 0.52 - 1.00 0.72 0.58 -
∆T 18 16 13 - 18 16 13 - 18 16 13 - 18 16 13 - 18 16 13 - 19 17 14 -
kW 1.41 1.41 1.41 - 1.58 1.58 1.58 - 1.77 1.76 1.76 - 1.97 1.96 1.96 - 2.19 2.19 2.19 - 2.45 2.45 2.45 -
Amps 5.2 5.2 5.2 - 6.0 6.0 6.0 -6.8 6.8 6.8 - 7.8 7.8 7.7 - 8.8 8.8 8.8 - 10.0 10.0 10.0 -
HI PR 251 252 254 - 290 292 293 - 332 333 335 - 376 377 379 - 424 426 427 - 476 477 479 -
LO PR 125 126 129 - 132 134 137 - 139 140 143 - 144 146 149 - 150 151 154 - 157 158 161 -
870
MBh 24.1 24.5 25.2 - 23.9 24.2 25.0 - 23.3 23.6 24.3 - 22.2 22.6 23.3 - 20.9 21.2 22.0 - 19.7 20.1 20.8 -
S/T 0.71 0.62 0.48 - 0.71 0.63 0.49 - 0.74 0.66 0.51 - 1.00 0.68 0.53 - 1.00 0.70 0.56 - 1.00 0.76 0.61 -
∆T 17 16 12 - 17 15 12 - 17 16 13 - 17 15 12 - 17 15 12 - 18 16 13 -
kW 1.42 1.42 1.42 - 1.59 1.58 1.58 - 1.77 1.77 1.77 - 1.97 1.97 1.97 - 2.20 2.19 2.19 - 2.46 2.46 2.45 -
Amps 5.3 5.3 5.2 - 6.0 6.0 6.0 -6.9 6.9 6.8 - 7.8 7.8 7.8 - 8.8 8.8 8.8 - 10.0 10.0 10.0 -
HI PR 252 253 255 - 292 293 295 - 333 334 336 - 378 379 381 - 426 427 429 - 477 478 480 -
LO PR 126 127 130 - 133 135 138 - 140 141 145 - 145 147 150 - 151 152 156 - 158 159 163 -
75
700
MBh 23.7 24.0 24.7 25.8 23.5 23.8 24.5 25.6 22.8 23.2 23.9 25.0 21.8 22.1 22.8 23.9 20.5 20.8 21.5 22.6 19.3 19.6 20.3 21.4
S/T 0.73 0.65 0.50 0.35 0.73 0.65 0.51 0.36 1.00 0.68 0.54 0.39 1.00 0.70 0.56 0.41 1.00 0.72 0.58 0.43 1.00 1.00 0.64 0.48
∆T 23 21 18 15 23 21 18 14 23 21 18 15 23 21 18 14 22 21 17 14 23 22 19 15
kW 1.40 1.40 1.40 1.41 1.57 1.57 1.57 1.58 1.76 1.75 1.75 1.76 1.96 1.95 1.95 1.96 2.18 2.18 2.18 2.19 2.44 2.44 2.44 2.45
Amps 5.2 5.2 5.2 5.2 5.9 5.9 5.9 6.0 6.8 6.8 6.8 6.8 7.7 7.7 7.7 7.8 8.7 8.7 8.7 8.8 9.9 9.9 9.9 10.0
HI PR 249 250 252 256 289 290 291 296 330 331 333 337 375 376 377 382 423 424 425 430 474 475 477 481
LO PR 123 125 128 133 131 132 135 140 137 139 142 147 143 144 147 153 148 150 153 158 155 157 160 165
800
MBh 23.9 24.3 25.0 26.1 23.7 24.0 24.8 25.8 23.1 23.4 24.1 25.2 22.0 22.4 23.1 24.2 20.7 21.1 21.8 22.8 19.5 19.9 20.6 21.7
S/T 0.80 0.72 0.58 0.43 0.81 0.73 0.59 0.44 1.00 0.76 0.61 0.46 1.00 0.78 0.63 0.48 1.00 0.80 0.66 0.51 1.00 1.00 0.71 0.56
∆T 22 20 17 13 21 20 17 13 22 20 17 14 21 20 17 13 21 20 16 13 22 21 17 14
kW 1.41 1.41 1.41 1.42 1.58 1.58 1.58 1.59 1.76 1.76 1.76 1.77 1.96 1.96 1.96 1.97 2.19 2.19 2.18 2.20 2.45 2.45 2.45 2.46
Amps 5.2 5.2 5.2 5.3 6.0 6.0 6.0 6.0 6.8 6.8 6.8 6.9 7.8 7.7 7.7 7.8 8.8 8.8 8.8 8.8 10.0 10.0 10.0 10.0
HI PR 251 252 254 258 291 292 294 298 332 333 335 339 377 378 379 384 425 426 427 432 476 477 479 483
LO PR 125 126 129 135 132 134 137 142 139 140 143 149 144 146 149 154 150 151 154 160 157 158 161 167
870
MBh 24.1 24.5 25.2 26.3 23.9 24.3 25.0 26.1 23.3 23.6 24.3 25.4 22.2 22.6 23.3 24.4 20.9 21.3 22.0 23.1 19.7 20.1 20.8 21.9
S/T 0.84 0.76 0.62 0.47 1.00 0.77 0.62 0.47 1.00 0.79 0.65 0.50 1.00 0.82 0.67 0.52 1.00 0.84 0.69 0.54 1.00 1.00 0.75 0.60
∆T 21 19 16 13 21 19 16 13 21 19 16 13 21 19 16 13 21 19 16 13 22 20 17 14
kW 1.42 1.42 1.41 1.43 1.58 1.58 1.58 1.59 1.77 1.77 1.77 1.78 1.97 1.97 1.97 1.98 2.19 2.19 2.19 2.20 2.46 2.46 2.45 2.47
Amps 5.3 5.2 5.2 5.3 6.0 6.0 6.0 6.1 6.9 6.9 6.8 6.9 7.8 7.8 7.8 7.8 8.8 8.8 8.8 8.8 10.0 10.0 10.0 10.0
HI PR 253 254 255 260 292 293 295 299 333 335 336 341 378 379 381 385 426 427 429 433 477 478 480 484
LO PR 126 127 130 136 133 135 138 143 140 141 145 150 146 147 150 155 151 153 156 161 158 159 163 168
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
10 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 11
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
700
MBh 23.8 24.1 24.8 25.9 23.6 23.9 24.6 25.7 23.0 23.3 24.0 25.1 21.9 22.2 22.9 24.0 20.6 20.9 21.6 22.7 19.4 19.7 20.4 21.5
S/T 1.00 0.78 0.64 0.49 1.00 0.79 0.64 0.49 1.00 0.81 0.67 0.52 1.00 0.83 0.69 0.54 1.00 1.00 0.71 0.56 1.00 1.00 0.77 0.62
∆T 26 25 22 18 26 25 21 18 27 25 22 18 26 25 21 18 26 24 21 18 27 25 22 19
kW 1.41 1.40 1.40 1.41 1.57 1.57 1.57 1.58 1.76 1.76 1.75 1.76 1.96 1.96 1.95 1.97 2.18 2.18 2.18 2.19 2.44 2.44 2.44 2.45
Amps 5.2 5.2 5.2 5.2 6.0 5.9 5.9 6.0 6.8 6.8 6.8 6.8 7.7 7.7 7.7 7.8 8.7 8.7 8.7 8.8 9.9 9.9 9.9 10.0
HI PR 250 251 252 257 289 290 292 296 330 332 333 338 375 376 378 382 423 424 426 430 474 475 477 482
LO PR 124 125 128 133 131 133 136 141 138 139 142 148 143 145 148 153 149 150 153 159 156 157 160 166
800
MBh 24.0 24.4 25.1 26.2 23.8 24.2 24.9 26.0 23.2 23.6 24.3 25.3 22.1 22.5 23.2 24.3 20.8 21.2 21.9 23.0 19.6 20.0 20.7 21.8
S/T 1.00 0.86 0.71 0.56 1.00 0.86 0.72 0.57 1.00 0.89 0.75 0.59 1.00 1.00 0.77 0.62 1.00 1.00 0.79 0.64 1.00 1.00 0.84 0.69
∆T 25 24 20 17 25 24 20 17 25 24 21 17 25 24 20 17 25 23 20 17 26 24 21 18
kW 1.41 1.41 1.41 1.42 1.58 1.58 1.58 1.59 1.77 1.76 1.76 1.77 1.97 1.96 1.96 1.97 2.19 2.19 2.19 2.20 2.45 2.45 2.45 2.46
Amps 5.2 5.2 5.2 5.3 6.0 6.0 6.0 6.0 6.8 6.8 6.8 6.9 7.8 7.8 7.7 7.8 8.8 8.8 8.8 8.8 10.0 10.0 10.0 10.0
HI PR 252 253 255 259 291 292 294 298 333 334 335 340 377 378 380 384 425 426 428 432 476 477 479 484
LO PR 125 127 130 135 133 134 137 143 139 141 144 149 145 146 150 155 150 152 155 160 157 159 162 167
870
MBh 24.3 24.6 25.3 26.4 24.0 24.4 25.1 26.2 23.4 23.8 24.5 25.6 22.4 22.7 23.4 24.5 21.0 21.4 22.1 23.2 19.9 20.2 20.9 22.0
S/T 1.00 0.89 0.75 0.60 1.00 0.90 0.76 0.61 1.00 0.93 0.78 0.63 1.00 1.00 0.80 0.65 1.00 1.00 0.83 0.68 1.00 1.00 0.88 0.73
∆T 25 23 20 17 25 23 20 17 25 23 20 17 25 23 20 16 24 23 20 16 25 24 21 17
kW 1.42 1.42 1.42 1.43 1.59 1.58 1.58 1.59 1.77 1.77 1.77 1.78 1.97 1.97 1.97 1.98 2.19 2.19 2.19 2.20 2.46 2.46 2.45 2.47
Amps 5.3 5.3 5.2 5.3 6.0 6.0 6.0 6.1 6.9 6.9 6.8 6.9 7.8 7.8 7.8 7.8 8.8 8.8 8.8 8.8 10.0 10.0 10.0 10.0
HI PR 253 254 256 260 293 294 295 300 334 335 337 341 378 380 381 386 426 428 429 434 478 479 481 485
LO PR 126 128 131 136 134 135 139 144 140 142 145 150 146 148 151 156 152 153 156 161 158 160 163 168
85
700
MBh 24.2 24.5 25.2 26.3 24.0 24.3 25.0 26.1 23.4 23.7 24.4 25.5 22.3 22.6 23.3 24.4 21.0 21.3 22.0 23.1 19.8 20.1 20.8 21.9
S/T 1.00 0.89 0.74 0.59 1.00 0.89 0.75 0.60 1.00 1.00 0.78 0.63 1.00 1.00 0.80 0.65 1.00 1.00 0.82 0.67 1.00 1.00 1.00 0.72
∆T 30 28 25 22 30 28 25 22 30 28 25 22 30 28 25 21 29 28 25 21 30 29 26 22
kW 1.41 1.41 1.40 1.42 1.57 1.57 1.57 1.58 1.76 1.76 1.76 1.77 1.96 1.96 1.96 1.97 2.18 2.18 2.18 2.19 2.45 2.45 2.44 2.45
Amps 5.2 5.2 5.2 5.2 6.0 6.0 5.9 6.0 6.8 6.8 6.8 6.9 7.7 7.7 7.7 7.8 8.8 8.7 8.7 8.8 10.0 10.0 9.9 10.0
HI PR 251 252 254 258 290 291 293 297 332 333 334 339 376 377 379 383 424 425 427 431 475 477 478 483
LO PR 125 127 130 135 133 134 138 143 140 141 144 149 145 147 150 155 151 152 155 161 157 159 162 167
800
MBh 24.5 24.8 25.5 26.6 24.2 24.6 25.3 26.4 23.6 24.0 24.7 25.7 22.5 22.9 23.6 24.7 21.2 21.6 22.3 23.4 20.0 20.4 21.1 22.2
S/T 1.00 0.96 0.82 0.67 1.00 1.00 0.83 0.68 1.00 1.00 0.85 0.70 1.00 1.00 0.87 0.72 1.00 1.00 0.90 0.75 1.00 1.00 1.00 0.80
∆T 29 27 24 20 29 27 24 20 29 27 24 21 29 27 24 20 28 27 23 20 29 28 25 21
kW 1.42 1.42 1.41 1.43 1.58 1.58 1.58 1.59 1.77 1.77 1.76 1.78 1.97 1.97 1.96 1.98 2.19 2.19 2.19 2.20 2.46 2.45 2.45 2.46
Amps 5.2 5.2 5.2 5.3 6.0 6.0 6.0 6.0 6.9 6.8 6.8 6.9 7.8 7.8 7.8 7.8 8.8 8.8 8.8 8.8 10.0 10.0 10.0 10.0
HI PR 253 254 256 260 292 293 295 300 334 335 337 341 378 379 381 385 426 427 429 433 478 479 480 485
LO PR 127 129 132 137 135 136 139 144 141 143 146 151 147 148 151 157 152 154 157 162 159 161 164 169
870
MBh 24.7 25.0 25.7 26.8 24.4 24.8 25.5 26.6 23.8 24.2 24.9 26.0 22.8 23.1 23.8 24.9 21.4 21.8 22.5 23.6 20.3 20.6 21.3 22.4
S/T 1.00 1.00 0.86 0.71 1.00 1.00 0.86 0.71 1.00 1.00 0.89 0.74 1.00 1.00 0.91 0.76 1.00 1.00 0.93 0.78 1.00 1.00 1.00 0.84
∆T 28 26 23 20 28 26 23 20 28 26 23 20 28 26 23 20 28 26 23 20 29 27 24 21
kW 1.42 1.42 1.42 1.43 1.59 1.59 1.58 1.60 1.77 1.77 1.77 1.78 1.97 1.97 1.97 1.98 2.20 2.20 2.19 2.21 2.46 2.46 2.46 2.47
Amps 5.3 5.3 5.3 5.3 6.0 6.0 6.0 6.1 6.9 6.9 6.9 6.9 7.8 7.8 7.8 7.8 8.8 8.8 8.8 8.9 10.0 10.0 10.0 10.1
HI PR 254 255 257 261 294 295 297 301 335 336 338 342 380 381 382 387 428 429 430 435 479 480 482 486
LO PR 128 130 133 138 136 137 140 146 142 144 147 152 148 149 153 158 153 155 158 163 160 162 165 170
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
Expanded Cooling Data — GSZ140241K* + ARUF25B14** + TXV (cont.)
10 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 11
Expanded Cooling Data — GSZ140251A* - ARUF25B14*+TXV
Outdoor Ambient Temperature
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
700
MBh 23.3 23.6 24.3 - 23.1 23.4 24.1 - 22.5 22.8 23.5 - 21.4 21.7 22.4 - 20.1 20.4 21.1 - 18.9 19.3 20.0 -
S/T 0.61 0.52 0.38 - 0.61 0.53 0.39 - 0.64 0.56 0.41 - 0.66 0.58 0.43 - 1.00 0.60 0.46 - 1.00 0.66 0.51 -
∆T 64 58 47 - 64 58 47 - 64 59 48 - 64 58 47 - 63 57 46 -66 61 50 -
kW 1.46 1.45 1.45 - 1.62 1.62 1.62 - 1.81 1.80 1.80 - 2.01 2.00 2.00 - 2.23 2.23 2.23 - 2.49 2.49 2.49 -
Amps 5.4 5.4 5.4 - 6.2 6.2 6.2 - 7.0 7.0 7.0 - 7.9 7.9 7.9 - 9.0 9.0 9.0 - 10.2 10.2 10.2 -
Hi PR 242 243 245 - 280 281 283 - 321 322 323 - 364 365 367 - 410 411 413 - 460 461 463 -
Lo PR 123 124 127 - 130 132 135 - 137 138 142 - 142 144 147 - 148 149 153 - 155 156 159 -
800
MBh 23.5 23.9 24.6 - 23.3 23.7 24.4 - 22.7 23.0 23.7 - 21.7 22.0 22.7 - 20.4 20.7 21.4 - 19.2 19.5 20.2 -
S/T 0.68 0.60 0.45 - 0.69 0.61 0.46 - 0.71 0.63 0.49 - 1.00 0.65 0.51 - 1.00 0.68 0.53 - 1.00 0.73 0.59 -
∆T 60 54 44 - 60 54 44 - 61 55 44 - 60 54 44 - 59 54 43 - 63 57 46 -
kW 1.46 1.46 1.46 -1.63 1.63 1.63 - 1.81 1.81 1.81 - 2.01 2.01 2.01 - 2.24 2.24 2.23 - 2.50 2.50 2.50 -
Amps 5.5 5.5 5.5 - 6.2 6.2 6.2 - 7.1 7.1 7.1 - 8.0 8.0 8.0 - 9.0 9.0 9.0 - 10.2 10.2 10.2 -
Hi PR 244 245 247 - 282 283 285 - 323 324 325 - 366 367 369 - 412 413 415 - 462 463 465 -
Lo PR 124 126 129 - 132 133 137 - 139 140 143 - 144 146 149 - 150 151 154 - 156 158 161 -
858
MBh 23.7 24.0 24.7 - 23.5 23.8 24.5 - 22.9 23.2 23.9 - 21.8 22.2 22.9 - 20.6 20.9 21.6 - 19.4 19.7 20.4 -
S/T 0.71 0.63 0.49 - 0.72 0.64 0.49 - 0.75 0.66 0.52 - 1.00 0.69 0.54 - 1.00 0.71 0.56 - 1.00 0.76 0.62 -
∆T 58 53 42 - 58 53 42 - 59 53 43 - 58 52 42 - 57 52 41 - 61 55 45 -
kW 1.47 1.47 1.46 -1.63 1.63 1.63 - 1.82 1.82 1.82 - 2.02 2.02 2.02 - 2.24 2.24 2.24 - 2.50 2.50 2.50 -
Amps 5.5 5.5 5.5 - 6.2 6.2 6.2 - 7.1 7.1 7.1 - 8.0 8.0 8.0 - 9.0 9.0 9.0 - 10.2 10.2 10.2 -
Hi PR 245 246 248 - 283 284 286 - 324 325 326 -367 368 370 - 414 415 416 -463 464 466 -
Lo PR 125 127 130 - 133 134 138 - 140 141 144 - 145 147 150 - 151 152 155 - 157 159 162 -
75
700
MBh 23.3 23.6 24.3 25.4 23.1 23.4 24.1 25.2 22.5 22.8 23.5 24.6 21.4 21.7 22.4 23.5 20.1 20.5 21.2 22.2 19.0 19.3 20.0 21.1
S/T 0.74 0.66 0.52 0.36 0.75 0.67 0.52 0.37 1.00 0.70 0.55 0.40 1.00 0.72 0.57 0.42 1.00 0.74 0.60 0.44 1.00 1.00 0.65 0.50
∆T 76 71 60 49 76 70 60 49 77 71 61 50 76 70 60 49 75 70 59 48 79 73 63 52
kW 1.45 1.45 1.45 1.46 1.62 1.62 1.62 1.63 1.80 1.80 1.80 1.81 2.00 2.00 2.00 2.01 2.23 2.23 2.22 2.24 2.49 2.49 2.49 2.50
Amps 5.4 5.4 5.4 5.5 6.2 6.2 6.2 6.2 7.0 7.0 7.0 7.1 7.9 7.9 7.9 8.0 9.0 9.0 8.9 9.0 10.2 10.2 10.1 10.2
Hi PR 242 243 245 249 281 282 283 288 321 322 323 328 364 365 367 371 411 412 413 418 460 461 463 467
Lo PR 123 124 127 133 130 132 135 140 137 138 142 147 142 144 147 152 148 149 153 158 155 156 159 165
800
MBh 23.5 23.9 24.6 25.6 23.3 23.7 24.4 25.4 22.7 23.1 23.8 24.8 21.7 22.0 22.7 23.8 20.4 20.7 21.4 22.5 19.2 19.5 20.2 21.3
S/T 0.82 0.74 0.59 0.44 0.83 0.74 0.60 0.45 1.00 0.77 0.63 0.47 1.00 0.79 0.65 0.49 1.00 0.82 0.67 0.52 1.00 1.00 0.73 0.57
∆T 73 67 56 45 73 67 56 45 73 68 57 46 73 67 56 45 72 66 55 44 75 70 59 48
kW 1.46 1.46 1.46 1.47 1.63 1.63 1.62 1.64 1.81 1.81 1.81 1.82 2.01 2.01 2.01 2.02 2.24 2.24 2.23 2.25 2.50 2.50 2.50 2.51
Amps 5.5 5.5 5.4 5.5 6.2 6.2 6.2 6.3 7.1 7.1 7.1 7.1 8.0 8.0 8.0 8.0 9.0 9.0 9.0 9.0 10.2 10.2 10.2 10.2
Hi PR 244 245 247 251 283 284 285 290 323 324 325 330 366 367 369 373 413 414 415 420 462 463 465 469
Lo PR 124 126 129 134 132 133 137 142 139 140 143 148 144 146 149 154 150 151 154 160 156 158 161 166
858
MBh 23.7 24.1 24.8 25.8 23.5 23.8 24.5 25.6 22.9 23.2 23.9 25.0 21.8 22.2 22.9 23.9 20.6 20.9 21.6 22.7 19.4 19.7 20.4 21.5
S/T 0.85 0.77 0.62 0.47 0.86 0.78 0.63 0.48 1.00 0.80 0.66 0.50 1.00 0.82 0.68 0.53 1.00 0.85 0.70 0.55 1.00 1.00 0.76 0.60
∆T 71 65 55 44 71 65 54 43 72 66 55 44 71 65 54 43 70 64 54 43 74 68 57 46
kW 1.47 1.47 1.46 1.48 1.63 1.63 1.63 1.64 1.82 1.82 1.81 1.83 2.02 2.02 2.01 2.03 2.24 2.24 2.24 2.25 2.50 2.50 2.50 2.51
Amps 5.5 5.5 5.5 5.5 6.2 6.2 6.2 6.3 7.1 7.1 7.1 7.1 8.0 8.0 8.0 8.0 9.0 9.0 9.0 9.1 10.2 10.2 10.2 10.3
Hi PR 245 246 248 252 284 285 286 291 324 325 327 331 367 368 370 374 414 415 417 421 464 465 466 471
Lo PR 125 127 130 135 133 134 138 143 140 141 144 149 145 147 150 155 151 152 155 161 157 159 162 167
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
12 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 13
Expanded Cooling Data — GSZ140251A* - ARUF25B14*+TXV (cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
700
MBh 23.4 23.7 24.4 25.5 23.2 23.5 24.2 25.3 22.6 22.9 23.6 24.7 21.5 21.9 22.6 23.6 20.2 20.6 21.3 22.3 19.1 19.4 20.1 21.2
S/T 1.00 0.80 0.65 0.50 1.00 0.80 0.66 0.51 1.00 0.83 0.69 0.53 1.00 0.85 0.71 0.55 1.00 1.00 0.73 0.58 1.00 1.00 0.78 0.63
∆T 89 83 73 62 89 83 72 61 90 84 73 62 89 83 72 61 88 82 72 61 92 86 75 64
kW 1.46 1.45 1.45 1.46 1.62 1.62 1.62 1.63 1.81 1.80 1.80 1.81 2.01 2.00 2.00 2.01 2.23 2.23 2.23 2.24 2.49 2.49 2.49 2.50
Amps 5.4 5.4 5.4 5.5 6.2 6.2 6.2 6.2 7.0 7.0 7.0 7.1 7.9 7.9 7.9 8.0 9.0 9.0 9.0 9.0 10.2 10.2 10.2 10.2
Hi PR 243 244 245 250 281 282 284 288 321 322 324 328 364 365 367 371 411 412 414 418 461 462 464 468
Lo PR 123 125 128 133 131 132 136 141 137 139 142 147 143 145 148 153 148 150 153 158 155 157 160 165
800
MBh 23.7 24.0 24.7 25.8 23.5 23.8 24.5 25.6 22.8 23.2 23.9 24.9 21.8 22.1 22.8 23.9 20.5 20.8 21.5 22.6 19.3 19.7 20.4 21.4
S/T 1.00 0.87 0.73 0.57 1.00 0.88 0.73 0.58 1.00 0.91 0.76 0.61 1.00 1.00 0.78 0.63 1.00 1.00 0.80 0.65 1.00 1.00 0.86 0.71
∆T 85 80 69 58 85 80 69 58 86 80 70 59 85 80 69 58 84 79 68 57 88 82 72 61
kW 1.46 1.46 1.46 1.47 1.63 1.63 1.63 1.64 1.81 1.81 1.81 1.82 2.01 2.01 2.01 2.02 2.24 2.24 2.23 2.25 2.50 2.50 2.50 2.51
Amps 5.5 5.5 5.5 5.5 6.2 6.2 6.2 6.3 7.1 7.1 7.1 7.1 8.0 8.0 8.0 8.0 9.0 9.0 9.0 9.1 10.2 10.2 10.2 10.3
Hi PR 245 246 247 252 283 284 286 290 323 324 326 330 366 367 369 373 413 414 416 420 463 464 466 470
Lo PR 125 127 130 135 133 134 137 142 139 141 144 149 145 146 149 155 150 152 155 160 157 158 162 167
858
MBh 23.8 24.2 24.9 25.9 23.6 24.0 24.7 25.7 23.0 23.4 24.1 25.1 22.0 22.3 23.0 24.1 20.7 21.0 21.7 22.8 19.5 19.8 20.5 21.6
S/T 1.00 0.90 0.76 0.61 1.00 0.91 0.76 0.61 1.00 0.94 0.79 0.64 1.00 1.00 0.81 0.66 1.00 1.00 0.84 0.68 1.00 1.00 0.89 0.74
∆T 84 78 67 56 84 78 67 56 84 79 68 57 83 78 67 56 83 77 66 55 86 81 70 59
kW 1.47 1.47 1.46 1.48 1.63 1.63 1.63 1.64 1.82 1.82 1.81 1.83 2.02 2.02 2.01 2.03 2.24 2.24 2.24 2.25 2.50 2.50 2.50 2.51
Amps 5.5 5.5 5.5 5.5 6.2 6.2 6.2 6.3 7.1 7.1 7.1 7.1 8.0 8.0 8.0 8.0 9.0 9.0 9.0 9.1 10.2 10.2 10.2 10.3
Hi PR 246 247 249 253 284 285 287 291 324 325 327 331 368 369 370 375 414 415 417 421 464 465 467 471
Lo PR 126 128 131 136 134 135 138 143 140 142 145 150 146 147 150 156 151 153 156 161 158 159 163 168
85
700
MBh 23.8 24.1 24.8 25.9 23.6 23.9 24.6 25.7 23.0 23.3 24.0 25.1 21.9 22.3 23.0 24.0 20.6 21.0 21.7 22.7 19.5 19.8 20.5 21.6
S/T 1.00 0.91 0.76 0.61 1.00 0.91 0.77 0.61 1.00 1.00 0.79 0.64 1.00 1.00 0.81 0.66 1.00 1.00 0.84 0.69 1.00 1.00 1.00 0.74
∆T 100 95 84 73 100 94 84 73 101 95 85 73 100 94 84 73 99 94 83 72 103 97 86 75
kW 1.46 1.46 1.45 1.47 1.62 1.62 1.62 1.63 1.81 1.81 1.80 1.82 2.01 2.01 2.00 2.02 2.23 2.23 2.23 2.24 2.49 2.49 2.49 2.50
Amps 5.4 5.4 5.4 5.5 6.2 6.2 6.2 6.2 7.0 7.0 7.0 7.1 8.0 8.0 7.9 8.0 9.0 9.0 9.0 9.0 10.2 10.2 10.2 10.2
Hi PR 244 245 247 251 282 283 285 289 322 323 325 329 366 367 368 373 412 413 415 419 462 463 465 469
Lo PR 125 127 130 135 133 134 137 143 139 141 144 149 145 146 150 155 150 152 155 160 157 159 162 167
800
MBh 24.1 24.4 25.1 26.2 23.9 24.2 24.9 26.0 23.2 23.6 24.3 25.3 22.2 22.5 23.2 24.3 20.9 21.2 21.9 23.0 19.7 20.1 20.8 21.8
S/T 1.00 0.98 0.84 0.68 1.00 1.00 0.84 0.69 1.00 1.00 0.87 0.72 1.00 1.00 0.89 0.74 1.00 1.00 0.91 0.76 1.00 1.00 1.00 0.82
∆T 97 91 80 69 97 91 80 69 97 92 81 70 96 91 80 69 96 90 79 68 99 94 83 72
kW 1.47 1.47 1.46 1.48 1.63 1.63 1.63 1.64 1.82 1.82 1.81 1.83 2.02 2.02 2.01 2.03 2.24 2.24 2.24 2.25 2.50 2.50 2.50 2.51
Amps 5.5 5.5 5.5 5.5 6.2 6.2 6.2 6.3 7.1 7.1 7.1 7.1 8.0 8.0 8.0 8.0 9.0 9.0 9.0 9.1 10.2 10.2 10.2 10.3
Hi PR 246 247 249 253 284 285 287 291 324 325 327 331 368 369 370 375 414 415 417 421 464 465 467 471
Lo PR 127 128 132 137 134 136 139 144 141 142 146 151 147 148 151 156 152 153 157 162 159 160 163 169
858
MBh 24.2 24.6 25.3 26.3 24.0 24.4 25.1 26.1 23.4 23.7 24.4 25.5 22.4 22.7 23.4 24.5 21.1 21.4 22.1 23.2 19.9 20.2 20.9 22.0
S/T 1.00 1.00 0.87 0.71 1.00 1.00 0.87 0.72 1.00 1.00 0.90 0.75 1.00 1.00 0.92 0.77 1.00 1.00 0.94 0.79 1.00 1.00 1.00 0.85
∆T 95 89 78 67 95 89 78 67 96 90 79 68 95 89 78 67 94 88 78 66 98 92 81 70
kW 1.47 1.47 1.47 1.48 1.64 1.64 1.63 1.65 1.82 1.82 1.82 1.83 2.02 2.02 2.02 2.03 2.25 2.24 2.24 2.25 2.51 2.51 2.50 2.52
Amps 5.5 5.5 5.5 5.5 6.3 6.3 6.2 6.3 7.1 7.1 7.1 7.1 8.0 8.0 8.0 8.1 9.0 9.0 9.0 9.1 10.2 10.2 10.2 10.3
Hi PR 247 248 250 254 285 286 288 292 325 326 328 332 369 370 371 376 415 416 418 422 465 466 468 472
Lo PR 128 129 133 138 135 137 140 145 142 143 147 152 148 149 152 157 153 155 158 163 160 161 164 170
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
12 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 13
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
870
MBh 28.4 28.8 29.7 - 28.2 28.6 29.4 - 27.5 27.9 28.7 - 26.2 26.6 27.4 - 24.7 25.1 25.9 - 23.3 23.6 24.5 -
S/T 0.65 0.57 0.44 - 0.66 0.58 0.45 - 0.68 0.61 0.47 - 0.70 0.62 0.49 - 0.72 0.65 0.51 - 1.00 0.70 0.56 -
∆T 19 17 13 - 19 17 13 - 19 17 14 - 19 17 13 - 18 17 13 - 20 18 14 -
kW 1.69 1.69 1.68 - 1.89 1.89 1.89 - 2.12 2.11 2.11 - 2.36 2.36 2.35 - 2.63 2.63 2.63 - 2.95 2.95 2.95 -
Amps 6.5 6.5 6.5 - 7.5 7.5 7.4 - 8.5 8.5 8.5 - 9.6 9.6 9.6 - 10.9 10.9 10.8 - 12.3 12.3 12.3 -
HI PR 250 251 253 - 289 290 292 - 330 331 333 - 374 375 377 - 422 423 425 - 473 474 475 -
LO PR 118 120 123 - 125 127 130 - 131 133 136 - 137 138 141 - 142 143 146 - 148 150 153 -
1000
MBh 29.0 29.4 30.2 - 28.7 29.1 30.0 - 28.0 28.4 29.2 - 26.7 27.1 28.0 - 25.2 25.6 26.4 - 23.8 24.2 25.0 -
S/T 0.69 0.61 0.48 - 0.69 0.62 0.49 - 0.72 0.64 0.51 - 0.74 0.66 0.53 - 1.00 0.68 0.55 - 1.00 0.73 0.60 -
∆T 18 16 12 - 18 16 12 - 18 16 13 - 18 16 12 - 17 15 12 - 18 17 13 -
kW 1.70 1.70 1.69 - 1.90 1.90 1.90 - 2.13 2.12 2.12 - 2.37 2.37 2.36 -2.64 2.64 2.64 -2.96 2.96 2.96 -
Amps 6.6 6.6 6.6 - 7.5 7.5 7.5 - 8.5 8.5 8.5 - 9.7 9.7 9.6 - 10.9 10.9 10.9 - 12.4 12.4 12.4 -
HI PR 252 254 255 - 292 293 294 - 333 334 335 - 377 378 380 - 424 425 427 - 475 476 478 -
LO PR 120 122 125 - 128 129 132 - 134 135 138 - 139 140 143 - 144 146 149 - 151 152 155 -
1125
MBh 29.6 30.0 30.9 - 29.4 29.8 30.6 -28.6 29.0 29.9 - 27.4 27.8 28.6 - 25.8 26.2 27.1 - 24.4 24.8 25.7 -
S/T 0.69 0.62 0.49 - 0.70 0.62 0.49 - 0.72 0.65 0.52 - 0.74 0.67 0.54 - 1.00 0.69 0.56 - 1.00 0.74 0.61 -
∆T 17 15 11 - 17 15 11 - 17 15 12 - 17 15 11 - 16 15 11 - 17 16 12 -
kW 1.71 1.71 1.70 - 1.91 1.91 1.90 - 2.13 2.13 2.13 - 2.38 2.38 2.37 - 2.65 2.65 2.65 - 2.97 2.97 2.97 -
Amps 6.6 6.6 6.6 -7.6 7.6 7.5 - 8.6 8.6 8.6 - 9.7 9.7 9.7 - 11.0 10.9 10.9 - 12.4 12.4 12.4 -
HI PR 255 256 258 - 294 295 297 - 335 336 338 - 379 380 382 - 427 428 430 - 478 479 480 -
LO PR 123 124 127 - 130 132 134 - 136 138 141 - 142 143 146 - 147 148 151 - 153 155 158 -
75
870
MBh 28.5 28.9 29.7 31.0 28.2 28.6 29.4 30.7 27.5 27.9 28.7 30.0 26.2 26.6 27.5 28.7 24.7 25.1 25.9 27.2 23.3 23.7 24.5 25.8
S/T 0.77 0.70 0.57 0.43 0.78 0.71 0.57 0.44 0.81 0.73 0.60 0.46 1.00 0.75 0.62 0.48 1.00 0.77 0.64 0.50 1.00 0.82 0.69 0.55
∆T 23 21 17 14 23 21 17 14 23 21 18 14 23 21 17 14 22 21 17 14 24 22 18 15
kW 1.69 1.69 1.68 1.70 1.89 1.89 1.88 1.90 2.11 2.11 2.11 2.12 2.36 2.36 2.35 2.37 2.63 2.63 2.63 2.64 2.95 2.95 2.95 2.96
Amps 6.5 6.5 6.5 6.6 7.5 7.5 7.4 7.5 8.5 8.5 8.5 8.5 9.6 9.6 9.6 9.7 10.9 10.9 10.8 10.9 12.3 12.3 12.3 12.4
HI PR 250 251 253 257 289 290 292 297 330 331 333 337 374 376 377 382 422 423 425 429 473 474 476 480
LO PR 118 120 123 128 125 127 130 135 131 133 136 141 137 138 141 146 142 143 146 151 148 150 153 158
1000
MBh 29.0 29.4 30.2 31.5 28.8 29.1 30.0 31.3 28.0 28.4 29.3 30.5 26.8 27.2 28.0 29.3 25.2 25.6 26.5 27.7 23.8 24.2 25.0 26.3
S/T 0.81 0.74 0.61 0.47 0.82 0.74 0.61 0.47 1.00 0.77 0.64 0.50 1.00 0.79 0.65 0.52 1.00 0.81 0.68 0.54 1.00 0.86 0.73 0.59
∆T 22 20 16 13 22 20 16 13 22 20 17 13 22 20 16 13 21 19 16 13 22 21 17 14
kW 1.70 1.70 1.69 1.71 1.90 1.90 1.89 1.91 2.12 2.12 2.12 2.14 2.37 2.37 2.36 2.38 2.64 2.64 2.64 2.65 2.96 2.96 2.96 2.97
Amps 6.6 6.6 6.6 6.6 7.5 7.5 7.5 7.6 8.5 8.5 8.5 8.6 9.7 9.7 9.6 9.7 10.9 10.9 10.9 11.0 12.4 12.4 12.3 12.4
HI PR 253 254 256 260 292 293 295 299 333 334 336 340 377 378 380 384 425 426 427 432 475 476 478 482
LO PR 120 122 125 130 128 129 132 137 134 135 138 143 139 140 143 148 144 146 149 153 151 152 155 160
1125
MBh 29.6 30.0 30.9 32.2 29.4 29.8 30.6 31.9 28.7 29.1 29.9 31.2 27.4 27.8 28.6 29.9 25.9 26.3 27.1 28.4 24.5 24.8 25.7 27.0
S/T 0.82 0.74 0.61 0.47 0.82 0.75 0.62 0.48 1.00 0.77 0.64 0.50 1.00 0.79 0.66 0.52 1.00 0.81 0.68 0.54 1.00 0.86 0.73 0.59
∆T 21 19 15 12 21 19 15 12 21 19 16 12 21 19 15 12 20 19 15 12 22 20 16 13
kW 1.71 1.70 1.70 1.72 1.91 1.91 1.90 1.92 2.13 2.13 2.13 2.14 2.38 2.38 2.37 2.39 2.65 2.65 2.64 2.66 2.97 2.97 2.96 2.98
Amps 6.6 6.6 6.6 6.7 7.6 7.5 7.5 7.6 8.6 8.6 8.6 8.6 9.7 9.7 9.7 9.7 10.9 10.9 10.9 11.0 12.4 12.4 12.4 12.5
HI PR 255 256 258 262 294 295 297 301 335 336 338 342 379 380 382 387 427 428 430 434 478 479 481 485
LO PR 123 124 127 132 130 132 135 139 136 138 141 146 142 143 146 151 147 148 151 156 153 155 158 163
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
Expanded Cooling Data — GSZ140301K* + ARUF29B14** + TXV
14 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 15
Expanded Cooling Data — GSZ140301K* + ARUF29B14** + TXV (cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
870
MBh 28.6 29.0 29.8 31.1 28.4 28.8 29.6 30.9 27.6 28.0 28.9 30.1 26.4 26.8 27.6 28.9 24.8 25.2 26.1 27.3 23.4 23.8 24.7 25.9
S/T 0.90 0.82 0.69 0.55 1.00 0.83 0.70 0.56 1.00 0.85 0.72 0.58 1.00 0.87 0.74 0.60 1.00 0.89 0.76 0.62 1.00 1.00 0.81 0.67
∆T 27 25 22 18 27 25 21 18 27 25 22 18 27 25 21 18 26 25 21 18 28 26 22 19
kW 1.69 1.69 1.68 1.70 1.89 1.89 1.88 1.90 2.12 2.11 2.11 2.13 2.36 2.36 2.35 2.37 2.63 2.63 2.63 2.64 2.95 2.95 2.95 2.96
Amps 6.5 6.5 6.5 6.6 7.5 7.5 7.4 7.5 8.5 8.5 8.5 8.5 9.6 9.6 9.6 9.7 10.9 10.9 10.8 10.9 12.3 12.3 12.3 12.4
HI PR 251 252 254 258 290 291 293 297 331 332 334 338 375 376 378 382 423 424 425 430 473 474 476 480
LO PR 119 120 123 128 126 127 130 135 132 133 136 141 137 139 142 147 142 144 147 152 149 150 153 158
1000
MBh 29.2 29.5 30.4 31.7 28.9 29.3 30.1 31.4 28.2 28.6 29.4 30.7 26.9 27.3 28.1 29.4 25.4 25.8 26.6 27.9 24.0 24.4 25.2 26.5
S/T 0.93 0.86 0.73 0.59 1.00 0.87 0.73 0.59 1.00 0.89 0.76 0.62 1.00 0.91 0.78 0.64 1.00 1.00 0.80 0.66 1.00 1.00 0.85 0.71
∆T 26 24 20 17 26 24 20 17 26 24 21 17 26 24 20 17 25 24 20 17 27 25 21 18
kW 1.70 1.70 1.69 1.71 1.90 1.90 1.90 1.91 2.13 2.12 2.12 2.14 2.37 2.37 2.36 2.38 2.64 2.64 2.64 2.65 2.96 2.96 2.96 2.97
Amps 6.6 6.6 6.6 6.6 7.5 7.5 7.5 7.6 8.5 8.5 8.5 8.6 9.7 9.7 9.6 9.7 10.9 10.9 10.9 11.0 12.4 12.4 12.4 12.4
HI PR 253 254 256 260 292 293 295 299 333 334 336 340 377 378 380 385 425 426 428 432 476 477 479 483
LO PR 121 122 125 130 128 129 132 137 134 136 139 144 139 141 144 149 145 146 149 154 151 153 155 160
1125
MBh 29.8 30.2 31.0 32.3 29.5 29.9 30.8 32.1 28.8 29.2 30.0 31.3 27.5 27.9 28.8 30.1 26.0 26.4 27.2 28.5 24.6 25.0 25.8 27.1
S/T 1.00 0.87 0.73 0.59 1.00 0.87 0.74 0.60 1.00 0.90 0.76 0.63 1.00 0.92 0.78 0.64 1.00 1.00 0.80 0.67 1.00 1.00 0.86 0.72
∆T 25 23 19 16 25 23 19 16 25 23 20 16 25 23 19 16 24 23 19 16 26 24 20 17
kW 1.71 1.71 1.70 1.72 1.91 1.91 1.90 1.92 2.13 2.13 2.13 2.14 2.38 2.38 2.37 2.39 2.65 2.65 2.65 2.66 2.97 2.97 2.97 2.98
Amps 6.6 6.6 6.6 6.7 7.6 7.5 7.5 7.6 8.6 8.6 8.6 8.6 9.7 9.7 9.7 9.8 11.0 10.9 10.9 11.0 12.4 12.4 12.4 12.5
HI PR 256 257 258 263 295 296 298 302 336 337 339 343 380 381 383 387 427 428 430 435 478 479 481 485
LO PR 124 125 128 133 131 132 135 140 137 138 141 146 142 144 146 151 147 149 152 157 154 155 158 163
85
870
MBh 29.1 29.5 30.3 31.6 28.8 29.2 30.1 31.3 28.1 28.5 29.3 30.6 26.8 27.2 28.1 29.4 25.3 25.7 26.5 27.8 23.9 24.3 25.1 26.4
S/T 1.00 0.92 0.79 0.65 1.00 0.93 0.80 0.66 1.00 0.95 0.82 0.68 1.00 1.00 0.84 0.70 1.00 1.00 0.86 0.72 1.00 1.00 0.91 0.77
∆T 30 29 25 22 30 28 25 22 31 29 25 22 30 28 25 22 30 28 25 21 31 29 26 22
kW 1.69 1.69 1.69 1.70 1.89 1.89 1.89 1.90 2.12 2.12 2.11 2.13 2.36 2.36 2.36 2.37 2.64 2.63 2.63 2.65 2.96 2.95 2.95 2.97
Amps 6.6 6.6 6.5 6.6 7.5 7.5 7.5 7.5 8.5 8.5 8.5 8.6 9.6 9.6 9.6 9.7 10.9 10.9 10.9 10.9 12.3 12.3 12.3 12.4
HI PR 252 253 255 259 291 292 294 298 332 333 335 339 376 377 379 383 424 425 427 431 474 476 477 482
LO PR 120 122 125 130 127 129 132 137 134 135 138 143 139 140 143 148 144 146 148 153 151 152 155 160
1000
MBh 29.6 30.0 30.9 32.1 29.4 29.8 30.6 31.9 28.6 29.0 29.9 31.2 27.4 27.8 28.6 29.9 25.8 26.2 27.1 28.4 24.4 24.8 25.7 26.9
S/T 1.00 0.96 0.83 0.69 1.00 0.96 0.83 0.69 1.00 1.00 0.86 0.72 1.00 1.00 0.88 0.74 1.00 1.00 0.90 0.76 1.00 1.00 0.95 0.81
∆T 29 27 24 20 29 27 24 20 29 28 24 21 29 27 24 20 29 27 24 20 30 28 25 21
kW 1.70 1.70 1.70 1.71 1.90 1.90 1.90 1.91 2.13 2.13 2.12 2.14 2.37 2.37 2.37 2.38 2.65 2.64 2.64 2.66 2.97 2.96 2.96 2.98
Amps 6.6 6.6 6.6 6.7 7.5 7.5 7.5 7.6 8.6 8.6 8.5 8.6 9.7 9.7 9.7 9.7 10.9 10.9 10.9 11.0 12.4 12.4 12.4 12.4
HI PR 254 255 257 261 293 295 296 301 334 335 337 342 379 380 381 386 426 427 429 433 477 478 480 484
LO PR 123 124 127 132 130 131 134 139 136 137 140 145 141 143 146 151 146 148 151 156 153 154 157 162
1125
MBh 30.3 30.7 31.5 32.8 30.0 30.4 31.2 32.5 29.3 29.7 30.5 31.8 28.0 28.4 29.3 30.5 26.5 26.9 27.7 29.0 25.1 25.5 26.3 27.6
S/T 1.00 0.96 0.83 0.69 1.00 0.97 0.84 0.70 1.00 1.00 0.86 0.72 1.00 1.00 0.88 0.74 1.00 1.00 0.90 0.76 1.00 1.00 1.00 0.81
∆T 28 27 23 20 28 26 23 19 29 27 23 20 28 26 23 19 28 26 23 19 29 27 24 20
kW 1.71 1.71 1.71 1.72 1.91 1.91 1.91 1.92 2.14 2.14 2.13 2.15 2.38 2.38 2.38 2.39 2.65 2.65 2.65 2.67 2.97 2.97 2.97 2.98
Amps 6.7 6.6 6.6 6.7 7.6 7.6 7.6 7.6 8.6 8.6 8.6 8.7 9.7 9.7 9.7 9.8 11.0 11.0 10.9 11.0 12.4 12.4 12.4 12.5
HI PR 257 258 260 264 296 297 299 303 337 338 340 344 381 382 384 388 429 430 431 436 479 480 482 486
LO PR 125 127 130 135 132 134 137 142 139 140 143 148 144 145 148 153 149 150 153 158 155 157 160 165
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
14 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 15
Expanded Cooling Data — GSZ140311A* / ARUF29B14A*+TXV
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
870
MBh 28.9 29.3 30.1 - 28.6 29.0 29.9 - 27.9 28.3 29.1 - 26.6 27.0 27.8 - 25.0 25.4 26.3 -23.6 24.0 24.8 -
S/T 0.65 0.57 0.44 - 0.65 0.58 0.45 - 0.68 0.60 0.47 - 0.70 0.62 0.49 - 0.72 0.65 0.51 - 1.00 0.70 0.56 -
∆T 19.01 17.15 13.67 -18.96 17.10 13.62 - 19.22 17.36 13.88 - 18.94 17.08 13.60 -18.69 16.83 13.35 - 19.86 18.00 14.52 -
kW 1.73 1.73 1.72 - 1.92 1.92 1.91 - 2.13 2.13 2.12 - 2.36 2.35 2.35 - 2.61 2.61 2.61 - 2.91 2.91 2.90 -
Amps 6.63 6.62 6.61 - 7.49 7.49 7.47 - 8.46 8.45 8.43 - 9.50 9.49 9.48 - 10.66 10.66 10.64 - 12.03 12.02 12.01 -
HI PR 242 243 244 - 280 281 282 - 319 320 322 - 362 363 365 - 408 409 411 - 457 458 460 -
LO PR 118 119 122 - 125 126 129 - 131 133 136 -136 138 141 - 142 143 146 - 148 149 152 -
1000
MBh 29.4 29.8 30.7 - 29.2 29.6 30.4 - 28.4 28.8 29.7 - 27.1 27.5 28.4 - 25.6 26.0 26.8 - 24.1 24.5 25.4 -
S/T 0.69 0.61 0.48 - 0.69 0.62 0.49 - 0.72 0.64 0.51 - 0.73 0.66 0.53 - 1.00 0.68 0.55 - 1.00 0.73 0.60 -
∆T 17.89 16.03 12.55 - 17.84 15.98 12.50 - 18.10 16.24 12.76 - 17.82 15.96 12.48 - 17.57 15.71 12.23 - 18.74 16.88 13.40 -
kW 1.74 1.74 1.73 - 1.93 1.93 1.92 - 2.14 2.14 2.13 - 2.36 2.36 2.36 -2.62 2.62 2.61 - 2.92 2.92 2.91 -
Amps 6.67 6.67 6.65 - 7.54 7.53 7.51 - 8.50 8.49 8.48 - 9.54 9.54 9.52 - 10.71 10.70 10.69 - 12.07 12.07 12.05 -
HI PR 244 245 247 - 282 283 285 - 321 323 324 - 364 365 367 - 410 411 413 - 459 460 462 -
LO PR 120 122 125 - 127 129 132 - 133 135 138 - 139 140 143 - 144 145 148 - 150 152 155 -
1125
MBh 30.1 30.5 31.3 - 29.8 30.2 31.1 - 29.1 29.5 30.3 - 27.8 28.2 29.0 - 26.2 26.6 27.5 - 24.8 25.2 26.0 -
S/T 0.69 0.62 0.49 - 0.70 0.62 0.49 - 0.72 0.65 0.52 - 0.74 0.67 0.53 - 1.00 0.69 0.56 - 1.00 0.74 0.61 -
∆T 16.95 15.09 11.61 -16.90 15.04 11.56 -17.16 15.30 11.82 - 16.88 15.02 11.54 - 16.63 14.77 11.29 - 17.80 15.93 12.46 -
kW 1.75 1.74 1.74 - 1.93 1.93 1.93 - 2.15 2.14 2.14 - 2.37 2.37 2.37 - 2.63 2.63 2.62 - 2.93 2.92 2.92 -
Amps 6.71 6.70 6.69 - 7.57 7.57 7.55 - 8.54 8.53 8.52 - 9.58 9.57 9.56 - 10.74 10.74 10.72 - 12.11 12.10 12.09 -
HI PR 246 247 249 - 284 285 287 - 324 325 327 - 367 368 369 - 413 414 415 - 462 463 464 -
LO PR 123 124 127 - 130 131 134 - 136 137 140 - 141 143 146 -146 148 151 - 153 154 157 -
75
870
MBh 28.9 29.3 30.1 31.4 28.6 29.0 29.9 31.2 27.9 28.3 29.1 30.4 26.6 27.0 27.9 29.2 25.0 25.4 26.3 27.6 23.6 24.0 24.9 26.2
S/T 0.77 0.70 0.57 0.43 0.78 0.71 0.57 0.43 0.80 0.73 0.60 0.46 1.00 0.75 0.62 0.48 1.00 0.77 0.64 0.50 1.00 0.82 0.69 0.55
∆T 23 21 18 14 23 21 18 14 23 21 18 14 23 21 18 14 23 21 17 14 24 22 19 15
kW 1.73 1.73 1.72 1.74 1.92 1.91 1.91 1.93 2.13 2.12 2.12 2.14 2.35 2.35 2.35 2.36 2.61 2.61 2.60 2.62 2.91 2.91 2.90 2.92
Amps 6.6 6.6 6.6 6.7 7.5 7.5 7.5 7.5 8.4 8.4 8.4 8.5 9.5 9.5 9.5 9.5 10.7 10.7 10.6 10.7 12.0 12.0 12.0 12.1
HI PR 242 243 245 249 280 281 282 287 319 320 322 326 362 363 365 369 408 409 411 415 457 458 460 464
LO PR 118 119 122 127 125 126 129 134 131 133 136 140 136 138 141 146 142 143 146 151 148 149 152 157
1000
MBh 29.4 29.8 30.7 32.0 29.2 29.6 30.4 31.7 28.4 28.8 29.7 31.0 27.1 27.5 28.4 29.7 25.6 26.0 26.8 28.1 24.2 24.6 25.4 26.7
S/T 0.81 0.74 0.60 0.47 0.82 0.74 0.61 0.47 1.00 0.77 0.64 0.50 1.00 0.79 0.65 0.51 1.00 0.81 0.68 0.54 1.00 0.86 0.73 0.59
∆T 22 20 17 13 22 20 17 13 22 20 17 13 22 20 17 13 22 20 16 13 23 21 17 14
kW 1.74 1.74 1.73 1.75 1.93 1.92 1.92 1.94 2.14 2.13 2.13 2.15 2.36 2.36 2.36 2.37 2.62 2.62 2.61 2.63 2.92 2.92 2.91 2.93
Amps 6.7 6.7 6.6 6.7 7.5 7.5 7.5 7.6 8.5 8.5 8.5 8.5 9.5 9.5 9.5 9.6 10.7 10.7 10.7 10.7 12.1 12.1 12.0 12.1
HI PR 244 245 247 251 282 283 285 289 322 323 324 329 364 365 367 371 410 411 413 417 459 460 462 466
LO PR 120 122 125 130 127 129 132 137 133 135 138 143 139 140 143 148 144 145 148 153 150 152 155 160
1125
MBh 30.1 30.5 31.3 32.6 29.8 30.2 31.1 32.4 29.1 29.5 30.3 31.6 27.8 28.2 29.1 30.4 26.2 26.6 27.5 28.8 24.8 25.2 26.1 27.4
S/T 0.82 0.74 0.61 0.47 0.82 0.75 0.62 0.48 1.00 0.77 0.64 0.50 1.00 0.79 0.66 0.52 1.00 0.81 0.68 0.54 1.00 0.86 0.73 0.59
∆T 21 19 16 12 21 19 16 12 21 19 16 12 21 19 16 12 21 19 15 12 22 20 17 13
kW 1.75 1.74 1.74 1.75 1.93 1.93 1.93 1.94 2.14 2.14 2.14 2.15 2.37 2.37 2.37 2.38 2.63 2.62 2.62 2.64 2.92 2.92 2.92 2.93
Amps 6.7 6.7 6.7 6.7 7.6 7.6 7.5 7.6 8.5 8.5 8.5 8.6 9.6 9.6 9.6 9.6 10.7 10.7 10.7 10.8 12.1 12.1 12.1 12.1
HI PR 247 248 249 254 284 285 287 291 324 325 327 331 367 368 369 374 413 414 415 420 462 463 465 469
LO PR 123 124 127 132 130 131 134 139 136 137 140 145 141 143 146 151 146 148 151 156 153 154 157 162
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
16 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 17
Expanded Cooling Data — GSZ140311A* / ARUF29B14A*+TXV (cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
870
MBh 29.0 29.4 30.3 31.6 28.8 29.2 30.0 31.3 28.0 28.4 29.3 30.6 26.7 27.1 28.0 29.3 25.2 25.6 26.4 27.7 23.8 24.2 25.0 26.3
S/T 0.90 0.82 0.69 0.55 1.00 0.83 0.70 0.56 1.00 0.85 0.72 0.58 1.00 0.87 0.74 0.60 1.00 0.89 0.76 0.62 1.00 1.00 0.81 0.67
∆T 27 25 22 18 27 25 22 18 27 26 22 18 27 25 22 18 27 25 22 18 28 26 23 19
kW 1.73 1.73 1.72 1.74 1.92 1.92 1.91 1.93 2.13 2.13 2.12 2.14 2.36 2.35 2.35 2.36 2.61 2.61 2.60 2.62 2.91 2.91 2.90 2.92
Amps 6.6 6.6 6.6 6.7 7.5 7.5 7.5 7.5 8.5 8.4 8.4 8.5 9.5 9.5 9.5 9.5 10.7 10.7 10.6 10.7 12.0 12.0 12.0 12.1
HI PR 242 243 245 249 280 281 283 287 320 321 323 327 362 363 365 369 408 409 411 415 458 459 460 464
LO PR 118 120 123 128 125 127 130 135 132 133 136 141 137 138 141 146 142 143 146 151 148 150 153 158
1000
MBh 29.6 30.0 30.8 32.1 29.3 29.7 30.6 31.9 28.6 29.0 29.8 31.1 27.3 27.7 28.5 29.8 25.7 26.1 27.0 28.3 24.3 24.7 25.6 26.9
S/T 0.93 0.86 0.73 0.59 1.00 0.86 0.73 0.59 1.00 0.89 0.76 0.62 1.00 0.91 0.78 0.64 1.00 1.00 0.80 0.66 1.00 1.00 0.85 0.71
∆T 26 24 21 17 26 24 21 17 26 24 21 17 26 24 21 17 26 24 20 17 27 25 22 18
kW 1.74 1.74 1.73 1.75 1.93 1.92 1.92 1.94 2.14 2.14 2.13 2.15 2.36 2.36 2.36 2.37 2.62 2.62 2.61 2.63 2.92 2.92 2.91 2.93
Amps 6.7 6.7 6.7 6.7 7.5 7.5 7.5 7.6 8.5 8.5 8.5 8.5 9.5 9.5 9.5 9.6 10.7 10.7 10.7 10.8 12.1 12.1 12.1 12.1
HI PR 245 246 247 252 283 284 285 289 322 323 325 329 365 366 368 372 411 412 414 418 460 461 463 467
LO PR 121 122 125 130 128 129 132 137 134 135 138 143 139 141 144 149 144 146 149 154 151 152 155 160
1125
MBh 30.2 30.6 31.5 32.8 30.0 30.4 31.2 32.5 29.2 29.6 30.5 31.8 27.9 28.3 29.2 30.5 26.4 26.8 27.6 28.9 25.0 25.4 26.2 27.5
S/T 1.00 0.86 0.73 0.59 1.00 0.87 0.74 0.60 1.00 0.90 0.76 0.62 1.00 0.91 0.78 0.64 1.00 1.00 0.80 0.66 1.00 1.00 0.85 0.71
∆T 25 23 20 16 25 23 20 16 25 24 20 16 25 23 20 16 25 23 20 16 26 24 21 17
kW 1.75 1.74 1.74 1.76 1.93 1.93 1.93 1.94 2.15 2.14 2.14 2.15 2.37 2.37 2.37 2.38 2.63 2.63 2.62 2.64 2.93 2.92 2.92 2.94
Amps 6.7 6.7 6.7 6.8 7.6 7.6 7.6 7.6 8.5 8.5 8.5 8.6 9.6 9.6 9.6 9.6 10.7 10.7 10.7 10.8 12.1 12.1 12.1 12.2
HI PR 247 248 250 254 285 286 288 292 325 326 327 331 367 368 370 374 413 414 416 420 462 463 465 469
LO PR 123 125 128 133 130 132 135 140 137 138 141 146 142 143 146 151 147 148 151 156 153 155 158 163
85
870
MBh 29.5 29.9 30.8 32.1 29.3 29.7 30.5 31.8 28.5 28.9 29.8 31.1 27.2 27.6 28.5 29.8 25.7 26.1 26.9 28.2 24.2 24.6 25.5 26.8
S/T 1.00 0.92 0.79 0.65 1.00 0.93 0.79 0.66 1.00 0.95 0.82 0.68 1.00 1.00 0.84 0.70 1.00 1.00 0.86 0.72 1.00 1.00 0.91 0.77
∆T 31 29 26 22 31 29 25 22 31 29 26 22 31 29 25 22 31 29 25 22 32 30 26 23
kW 1.73 1.73 1.73 1.74 1.92 1.92 1.92 1.93 2.13 2.13 2.13 2.14 2.36 2.36 2.35 2.37 2.61 2.61 2.61 2.62 2.91 2.91 2.91 2.92
Amps 6.6 6.6 6.6 6.7 7.5 7.5 7.5 7.6 8.5 8.5 8.4 8.5 9.5 9.5 9.5 9.6 10.7 10.7 10.7 10.7 12.0 12.0 12.0 12.1
HI PR 243 245 246 250 281 282 284 288 321 322 324 328 364 365 366 370 410 411 412 416 459 460 461 466
LO PR 120 122 125 129 127 129 132 137 133 135 138 143 139 140 143 148 144 145 148 153 150 152 155 160
1000
MBh 30.1 30.5 31.3 32.6 29.8 30.2 31.1 32.4 29.1 29.5 30.3 31.6 27.8 28.2 29.0 30.3 26.2 26.6 27.5 28.8 24.8 25.2 26.0 27.3
S/T 1.00 0.96 0.83 0.69 1.00 0.96 0.83 0.69 1.00 1.00 0.86 0.72 1.00 1.00 0.87 0.74 1.00 1.00 0.90 0.76 1.00 1.00 0.95 0.81
∆T 30 28 24 21 30 28 24 21 30 28 25 21 30 28 24 21 29 28 24 21 31 29 25 22
kW 1.74 1.74 1.74 1.75 1.93 1.93 1.93 1.94 2.14 2.14 2.14 2.15 2.37 2.37 2.36 2.38 2.62 2.62 2.62 2.63 2.92 2.92 2.92 2.93
Amps 6.7 6.7 6.7 6.7 7.6 7.5 7.5 7.6 8.5 8.5 8.5 8.6 9.6 9.6 9.5 9.6 10.7 10.7 10.7 10.8 12.1 12.1 12.1 12.1
HI PR 246 247 249 253 284 285 286 291 323 324 326 330 366 367 369 373 412 413 415 419 461 462 464 468
LO PR 122 124 127 132 130 131 134 139 136 137 140 145 141 142 145 150 146 148 150 155 153 154 157 162
1125
MBh 30.7 31.1 32.0 33.3 30.4 30.9 31.7 33.0 29.7 30.1 31.0 32.3 28.4 28.8 29.7 31.0 26.9 27.3 28.1 29.4 25.4 25.8 26.7 28.0
S/T 1.00 0.96 0.83 0.69 1.00 0.97 0.84 0.70 1.00 1.00 0.86 0.72 1.00 1.00 0.88 0.74 1.00 1.00 0.90 0.76 1.00 1.00 1.00 0.81
∆T 29 27 23 20 29 27 23 20 29 27 24 20 29 27 23 20 29 27 23 20 30 28 24 21
kW 1.75 1.75 1.74 1.76 1.94 1.94 1.93 1.95 2.15 2.15 2.14 2.16 2.38 2.37 2.37 2.39 2.63 2.63 2.63 2.64 2.93 2.93 2.92 2.94
Amps 6.7 6.7 6.7 6.8 7.6 7.6 7.6 7.6 8.6 8.5 8.5 8.6 9.6 9.6 9.6 9.6 10.8 10.8 10.7 10.8 12.1 12.1 12.1 12.2
HI PR 248 249 251 255 286 287 289 293 326 327 328 333 368 369 371 375 414 415 417 421 463 464 466 470
LO PR 125 126 129 134 132 134 136 141 138 140 143 148 144 145 148 153 149 150 153 158 155 157 159 164
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
16 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 17
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1070
MBh 36.3 36.8 37.9 - 36.0 36.5 37.5 - 35.0 35.5 36.6 - 33.4 33.9 35.0 - 31.5 32.0 33.0 - 29.7 30.2 31.2 -
S/T 0.65 0.57 0.44 - 0.66 0.58 0.45 - 0.68 0.61 0.47 - 0.70 0.62 0.49 - 1.00 0.65 0.51 - 1.00 0.70 0.56 -
∆T 19 18 14 - 19 17 14 - 20 18 14 - 19 17 14 - 19 17 14 - 20 18 15 -
kW 2.17 2.17 2.16 - 2.44 2.43 2.43 - 2.73 2.73 2.72 - 3.05 3.05 3.04 - 3.41 3.41 3.40 - 3.83 3.83 3.82 -
Amps 8.3 8.3 8.2 - 9.5 9.5 9.5 - 10.8 10.8 10.8 - 12.3 12.3 12.3 - 13.9 13.9 13.9 - 15.9 15.9 15.8 -
HI PR 263 265 266 - 305 306 308 - 348 349 351 - 394 395 397 - 444 446 447 - 498 499 501 -
LO PR 121 123 126 - 129 130 133 - 135 137 140 - 140 142 145 - 146 147 150 - 152 154 157 -
1200
MBh 36.8 37.3 38.4 - 36.5 37.0 38.1 - 35.6 36.1 37.2 - 34.0 34.5 35.5 - 32.0 32.5 33.6 - 30.2 30.7 31.8 -
S/T 0.68 0.61 0.48 - 0.69 0.61 0.48 - 0.71 0.64 0.51 - 0.73 0.66 0.52 - 1.00 0.68 0.55 - 1.00 0.73 0.60 -
∆T 18 17 13 - 18 17 13 - 19 17 13 - 18 17 13 - 18 16 13 - 19 17 14 -
kW 2.18 2.18 2.17 - 2.45 2.44 2.44 - 2.74 2.74 2.74 - 3.06 3.06 3.06 - 3.42 3.42 3.41 - 3.84 3.84 3.83 -
Amps 8.3 8.3 8.3 - 9.5 9.5 9.5 - 10.9 10.9 10.9 - 12.4 12.4 12.3 - 14.0 14.0 14.0 - 15.9 15.9 15.9 -
HI PR 266 267 268 - 307 308 310 - 350 351 353 - 396 398 399 - 447 448 450 - 500 501 503 -
LO PR 123 125 128 - 131 132 135 - 137 138 142 - 142 144 147 - 148 149 152 - 154 156 159 -
1350
MBh 37.6 38.1 39.2 - 37.3 37.8 38.9 - 36.3 36.8 37.9 - 34.7 35.2 36.3 - 32.8 33.3 34.3 - 31.0 31.5 32.5 -
S/T 0.69 0.62 0.49 - 0.70 0.62 0.49 - 0.72 0.65 0.52 - 1.00 0.67 0.54 - 1.00 0.69 0.56 - 1.00 0.74 0.61 -
∆T 18 16 12 - 17 16 12 - 18 16 12 - 17 16 12 - 17 15 12 - 18 16 13 -
kW 2.19 2.19 2.19 - 2.46 2.46 2.45 - 2.75 2.75 2.75 - 3.07 3.07 3.07 - 3.43 3.43 3.42 - 3.85 3.85 3.84 -
Amps 8.4 8.4 8.4 - 9.6 9.6 9.6 - 10.9 10.9 10.9 - 12.4 12.4 12.4 - 14.1 14.0 14.0 - 16.0 16.0 15.9 -
HI PR 268 269 271 - 309 310 312 - 352 354 355 - 399 400 402 - 449 450 452 - 503 504 505 -
LO PR 126 127 130 - 133 135 138 - 139 141 144 - 145 146 149 - 150 152 155 - 157 158 161 -
75
1070
MBh 36.3 36.8 37.9 39.5 36.0 36.5 37.6 39.2 35.0 35.6 36.6 38.3 33.4 33.9 35.0 36.6 31.5 32.0 33.0 34.7 29.7 30.2 31.3 32.9
S/T 0.77 0.70 0.57 0.43 0.78 0.71 0.57 0.44 1.00 0.73 0.60 0.46 1.00 0.75 0.62 0.48 1.00 0.77 0.64 0.50 1.00 0.82 0.69 0.55
∆T 24 22 18 14 24 22 18 14 24 22 18 15 24 22 18 14 23 21 18 14 24 23 19 15
kW 2.17 2.17 2.16 2.18 2.43 2.43 2.43 2.45 2.73 2.73 2.72 2.74 3.05 3.05 3.04 3.06 3.41 3.40 3.40 3.42 3.83 3.82 3.82 3.84
Amps 8.3 8.3 8.2 8.3 9.5 9.5 9.5 9.5 10.8 10.8 10.8 10.9 12.3 12.3 12.3 12.4 13.9 13.9 13.9 14.0 15.9 15.8 15.8 15.9
HI PR 264 265 267 271 305 306 308 312 348 349 351 356 395 396 398 402 445 446 448 452 498 499 501 506
LO PR 121 123 126 131 129 130 133 138 135 137 140 145 141 142 145 150 146 147 150 155 152 154 157 162
1200
MBh 36.9 37.4 38.4 40.1 36.5 37.0 38.1 39.7 35.6 36.1 37.2 38.8 34.0 34.5 35.6 37.2 32.0 32.5 33.6 35.2 30.2 30.7 31.8 33.4
S/T 0.81 0.73 0.60 0.46 0.81 0.74 0.61 0.47 1.00 0.76 0.63 0.49 1.00 0.78 0.65 0.51 1.00 0.80 0.67 0.53 1.00 1.00 0.72 0.58
∆T 23 21 17 14 23 21 17 13 23 21 17 14 23 21 17 13 22 20 17 13 24 22 18 14
kW 2.18 2.18 2.17 2.19 2.44 2.44 2.44 2.46 2.74 2.74 2.73 2.75 3.06 3.06 3.05 3.07 3.42 3.42 3.41 3.43 3.84 3.84 3.83 3.85
Amps 8.3 8.3 8.3 8.4 9.5 9.5 9.5 9.6 10.9 10.9 10.9 11.0 12.4 12.3 12.3 12.4 14.0 14.0 14.0 14.1 15.9 15.9 15.9 16.0
HI PR 266 267 269 273 307 308 310 314 350 351 353 358 397 398 400 404 447 448 450 454 500 501 503 508
LO PR 123 125 128 133 131 132 135 140 137 138 142 147 142 144 147 152 148 149 152 157 154 156 159 164
1350
MBh 37.6 38.1 39.2 40.8 37.3 37.8 38.9 40.5 36.4 36.9 37.9 39.6 34.8 35.3 36.3 38.0 32.8 33.3 34.4 36.0 31.0 31.5 32.6 34.2
S/T 0.82 0.74 0.61 0.47 0.82 0.75 0.62 0.48 1.00 0.78 0.64 0.50 1.00 0.79 0.66 0.52 1.00 0.82 0.68 0.54 1.00 1.00 0.73 0.59
∆T 22 20 16 13 22 20 16 13 22 20 16 13 22 20 16 13 21 19 16 12 23 21 17 13
kW 2.19 2.19 2.18 2.20 2.46 2.45 2.45 2.47 2.75 2.75 2.75 2.77 3.07 3.07 3.07 3.09 3.43 3.43 3.42 3.44 3.85 3.85 3.84 3.86
Amps 8.4 8.4 8.3 8.4 9.6 9.6 9.6 9.7 10.9 10.9 10.9 11.0 12.4 12.4 12.4 12.5 14.0 14.0 14.0 14.1 16.0 16.0 15.9 16.0
HI PR 268 269 271 276 309 311 312 317 353 354 356 360 399 400 402 407 449 450 452 457 503 504 506 510
LO PR 126 127 130 135 133 135 138 143 140 141 144 149 145 146 149 155 150 152 155 160 157 158 161 166
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
Expanded Cooling Data — GSZ140361K* + ARUF37C14** + TXV
18 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 19
Expanded Cooling Data — GSZ140361K* + ARUF37C14** + TXV (cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1070
MBh 36.5 37.0 38.1 39.7 36.2 36.7 37.7 39.4 35.2 35.7 36.8 38.4 33.6 34.1 35.2 36.8 31.7 32.2 33.2 34.9 29.9 30.4 31.4 33.1
S/T 0.90 0.82 0.69 0.55 1.00 0.83 0.70 0.56 1.00 0.85 0.72 0.58 1.00 0.87 0.74 0.60 1.00 1.00 0.76 0.62 1.00 1.00 0.81 0.67
∆T 28 26 22 19 28 26 22 19 28 26 23 19 28 26 22 19 28 26 22 18 29 27 23 20
kW 2.17 2.17 2.16 2.18 2.43 2.43 2.43 2.45 2.73 2.73 2.72 2.74 3.05 3.05 3.04 3.06 3.41 3.41 3.40 3.42 3.83 3.83 3.82 3.84
Amps 8.3 8.3 8.2 8.3 9.5 9.5 9.5 9.6 10.8 10.8 10.8 10.9 12.3 12.3 12.3 12.4 13.9 13.9 13.9 14.0 15.9 15.9 15.8 15.9
HI PR 264 265 267 272 305 306 308 313 349 350 351 356 395 396 398 403 445 446 448 453 499 500 502 506
LO PR 122 123 127 132 129 131 134 139 136 137 140 145 141 143 146 151 146 148 151 156 153 154 157 163
1200
MBh 37.0 37.5 38.6 40.2 36.7 37.2 38.3 39.9 35.8 36.3 37.4 39.0 34.2 34.7 35.7 37.4 32.2 32.7 33.8 35.4 30.4 30.9 32.0 33.6
S/T 1.00 0.86 0.72 0.58 1.00 0.86 0.73 0.59 1.00 0.89 0.75 0.61 1.00 0.90 0.77 0.63 1.00 1.00 0.79 0.65 1.00 1.00 0.84 0.71
∆T 27 25 21 18 27 25 21 18 27 25 22 18 27 25 21 18 27 25 21 17 28 26 22 19
kW 2.18 2.18 2.17 2.19 2.45 2.44 2.44 2.46 2.74 2.74 2.74 2.76 3.06 3.06 3.06 3.08 3.42 3.42 3.41 3.43 3.84 3.84 3.83 3.85
Amps 8.3 8.3 8.3 8.4 9.5 9.5 9.5 9.6 10.9 10.9 10.9 11.0 12.4 12.4 12.3 12.4 14.0 14.0 14.0 14.1 15.9 15.9 15.9 16.0
HI PR 266 267 269 274 307 309 310 315 351 352 354 358 397 398 400 405 447 448 450 455 501 502 504 508
LO PR 124 125 128 133 131 133 136 141 138 139 142 147 143 144 147 153 148 150 153 158 155 156 159 164
1350
MBh 37.8 38.3 39.4 41.0 37.5 38.0 39.1 40.7 36.5 37.1 38.1 39.8 34.9 35.4 36.5 38.1 33.0 33.5 34.5 36.2 31.2 31.7 32.8 34.4
S/T 1.00 0.87 0.73 0.60 1.00 0.87 0.74 0.60 1.00 0.90 0.77 0.63 1.00 1.00 0.78 0.64 1.00 1.00 0.81 0.67 1.00 1.00 0.86 0.72
∆T 26 24 20 17 26 24 20 17 26 24 21 17 26 24 20 17 26 24 20 16 27 25 21 18
kW 2.19 2.19 2.19 2.21 2.46 2.46 2.45 2.47 2.75 2.75 2.75 2.77 3.07 3.07 3.07 3.09 3.43 3.43 3.42 3.44 3.85 3.85 3.84 3.86
Amps 8.4 8.4 8.4 8.4 9.6 9.6 9.6 9.7 10.9 10.9 10.9 11.0 12.4 12.4 12.4 12.5 14.0 14.0 14.0 14.1 16.0 16.0 15.9 16.0
HI PR 269 270 272 276 310 311 313 317 353 354 356 361 400 401 403 407 450 451 453 457 503 504 506 511
LO PR 126 128 131 136 134 135 138 143 140 142 145 150 145 147 150 155 151 152 155 160 157 159 162 167
85
1070
MBh 37.1 37.6 38.7 40.3 36.8 37.3 38.3 40.0 35.8 36.3 37.4 39.0 34.2 34.7 35.8 37.4 32.3 32.8 33.8 35.5 30.5 31.0 32.0 33.7
S/T 1.00 0.92 0.79 0.65 1.00 0.93 0.80 0.66 1.00 1.00 0.82 0.68 1.00 1.00 0.84 0.70 1.00 1.00 0.86 0.72 1.00 1.00 1.00 0.77
∆T 32 30 26 22 32 30 26 22 32 30 26 23 31 30 26 22 31 29 26 22 32 31 27 23
kW 2.17 2.17 2.17 2.19 2.44 2.44 2.43 2.45 2.74 2.73 2.73 2.75 3.06 3.05 3.05 3.07 3.41 3.41 3.41 3.43 3.83 3.83 3.83 3.85
Amps 8.3 8.3 8.3 8.4 9.5 9.5 9.5 9.6 10.9 10.9 10.8 10.9 12.3 12.3 12.3 12.4 14.0 14.0 13.9 14.0 15.9 15.9 15.9 16.0
HI PR 265 266 268 273 307 308 310 314 350 351 353 357 396 397 399 404 446 448 449 454 500 501 503 507
LO PR 124 125 128 133 131 133 136 141 137 139 142 147 143 144 147 152 148 150 153 158 155 156 159 164
1200
MBh 37.6 38.1 39.2 40.8 37.3 37.8 38.9 40.5 36.4 36.9 38.0 39.6 34.8 35.3 36.4 38.0 32.8 33.3 34.4 36.0 31.0 31.5 32.6 34.2
S/T 1.00 0.95 0.82 0.68 1.00 0.96 0.83 0.69 1.00 1.00 0.85 0.71 1.00 1.00 0.87 0.73 1.00 1.00 0.89 0.75 1.00 1.00 1.00 0.80
∆T 31 29 25 21 31 29 25 21 31 29 25 22 31 29 25 21 30 28 25 21 31 30 26 22
kW 2.19 2.18 2.18 2.20 2.45 2.45 2.44 2.46 2.75 2.74 2.74 2.76 3.07 3.06 3.06 3.08 3.42 3.42 3.42 3.44 3.84 3.84 3.84 3.86
Amps 8.4 8.3 8.3 8.4 9.6 9.6 9.5 9.6 10.9 10.9 10.9 11.0 12.4 12.4 12.4 12.4 14.0 14.0 14.0 14.1 15.9 15.9 15.9 16.0
HI PR 267 269 270 275 309 310 312 316 352 353 355 359 398 399 401 406 448 450 451 456 502 503 505 509
LO PR 126 127 130 135 133 134 137 143 139 141 144 149 145 146 149 154 150 151 155 160 157 158 161 166
1350
MBh 38.4 38.9 40.0 41.6 38.1 38.6 39.7 41.3 37.2 37.7 38.7 40.4 35.5 36.0 37.1 38.8 33.6 34.1 35.2 36.8 31.8 32.3 33.4 35.0
S/T 1.00 0.97 0.83 0.69 1.00 1.00 0.84 0.70 1.00 1.00 0.86 0.72 1.00 1.00 0.88 0.74 1.00 1.00 0.90 0.77 1.00 1.00 1.00 0.82
∆T 30 28 24 21 30 28 24 20 30 28 24 21 30 28 24 20 29 27 24 20 31 29 25 21
kW 2.20 2.20 2.19 2.21 2.46 2.46 2.46 2.48 2.76 2.76 2.75 2.77 3.08 3.08 3.07 3.09 3.44 3.43 3.43 3.45 3.86 3.85 3.85 3.87
Amps 8.4 8.4 8.4 8.5 9.6 9.6 9.6 9.7 11.0 11.0 10.9 11.0 12.4 12.4 12.4 12.5 14.1 14.1 14.0 14.1 16.0 16.0 16.0 16.1
HI PR 270 271 273 277 311 312 314 319 354 355 357 362 401 402 404 408 451 452 454 458 504 506 507 512
LO PR 128 130 133 138 135 137 140 145 142 143 146 151 147 149 152 157 153 154 157 162 159 161 164 169
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
18 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 19
Expanded Cooling Data — GSZ140371A* / ARUF37C14A*+TXV
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
985
MBh 34.0 34.5 35.5 - 33.7 34.2 35.2 - 32.8 33.3 34.3 - 31.3 31.8 32.8 - 29.5 30.0 31.0 - 27.8 28.3 29.3 -
S/T 0.64 0.56 0.43 - 0.64 0.57 0.44 - 0.67 0.59 0.46 -0.69 0.61 0.48 - 1.00 0.63 0.50 - 1.00 0.68 0.55 -
∆T 20 18 14 - 20 18 14 - 20 18 14 - 20 18 14 - 19 17 14 - 21 19 15 -
kW 2.03 2.03 2.02 - 2.25 2.25 2.25 - 2.50 2.50 2.50 - 2.78 2.77 2.77 - 3.08 3.08 3.07 - 3.44 3.44 3.43 -
Amps 7.6 7.6 7.6 - 8.7 8.7 8.6 - 9.8 9.8 9.8 - 11.1 11.1 11.0 - 12.5 12.4 12.4 - 14.1 14.1 14.1 -
Hi PR 250 251 253 - 289 290 292 - 330 331 333 - 374 375 377 - 421 422 424 - 472 473 475 -
Lo PR 121 123 126 - 129 130 133 - 135 136 139 - 140 142 145 - 146 147 150 - 152 154 157 -
1200
MBh 35.0 35.5 36.5 - 34.7 35.2 36.2 - 33.8 34.3 35.3 - 32.3 32.8 33.8 - 30.5 31.0 32.0 - 28.8 29.3 30.3 -
S/T 0.68 0.61 0.48 - 0.69 0.61 0.48 - 0.71 0.64 0.51 - 1.00 0.66 0.53 - 1.00 0.68 0.55 - 1.00 0.73 0.60 -
∆T 18 16 13 - 18 16 12 - 18 16 13 - 18 16 12 - 18 16 12 - 19 17 13 -
kW 2.04 2.04 2.04 - 2.27 2.27 2.26 - 2.52 2.52 2.51 - 2.79 2.79 2.79 - 3.10 3.10 3.09 - 3.45 3.45 3.45 -
Amps 7.7 7.7 7.7 - 8.7 8.7 8.7 - 9.9 9.9 9.9 - 11.1 11.1 11.1 - 12.5 12.5 12.5 - 14.2 14.2 14.1 -
Hi PR 253 254 256 - 292 294 295 - 333 334 336 - 377 379 380 - 425 426 428 - 476 477 479 -
Lo PR 125 126 129 - 132 134 137 - 138 140 143 - 144 145 148 - 149 151 154 - 156 157 160 -
1350
MBh 35.9 36.4 37.4 - 35.6 36.1 37.1 - 34.7 35.2 36.2 - 33.2 33.7 34.7 - 31.4 31.9 32.9 - 29.7 30.2 31.2 -
S/T 0.67 0.60 0.47 - 0.68 0.61 0.48 - 0.70 0.63 0.50 - 1.00 0.65 0.52 - 1.00 0.67 0.54 - 1.00 0.72 0.59 -
∆T 17 15 12 - 17 15 11 - 17 15 12 - 17 15 11 - 17 15 11 - 18 16 12 -
kW 2.05 2.05 2.05 - 2.28 2.28 2.27 - 2.53 2.53 2.52 - 2.80 2.80 2.80 - 3.11 3.10 3.10 - 3.46 3.46 3.46 -
Amps 7.7 7.7 7.7 - 8.8 8.8 8.8 - 9.9 9.9 9.9 - 11.2 11.2 11.2 - 12.6 12.6 12.5 - 14.2 14.2 14.2 -
Hi PR 256 257 259 - 295 296 298 - 336 337 339 - 380 381 383 - 428 429 430 - 478 479 481 -
Lo PR 128 129 132 - 135 137 140 - 142 143 146 - 147 148 151 - 152 154 157 - 159 160 163 -
75
985
MBh 34.0 34.5 35.5 37.0 33.7 34.2 35.2 36.7 32.9 33.3 34.3 35.9 31.3 31.8 32.8 34.4 29.5 30.0 31.0 32.5 27.8 28.3 29.3 30.8
S/T 0.76 0.69 0.56 0.42 0.77 0.69 0.56 0.43 1.00 0.72 0.59 0.45 1.00 0.74 0.61 0.47 1.00 0.76 0.63 0.49 1.00 0.81 0.68 0.54
∆T 24 22 18 15 24 22 18 15 24 22 19 15 24 22 18 15 24 22 18 14 25 23 19 16
kW 2.03 2.02 2.02 2.04 2.25 2.25 2.25 2.26 2.50 2.50 2.50 2.51 2.77 2.77 2.77 2.79 3.08 3.08 3.07 3.09 3.44 3.43 3.43 3.45
Amps 7.6 7.6 7.6 7.7 8.7 8.6 8.6 8.7 9.8 9.8 9.8 9.9 11.1 11.0 11.0 11.1 12.4 12.4 12.4 12.5 14.1 14.1 14.1 14.1
Hi PR 250 251 253 257 289 290 292 296 330 331 333 337 374 375 377 381 422 423 424 429 472 473 475 479
Lo PR 121 123 126 131 129 130 133 138 135 136 139 145 140 142 145 150 146 147 150 155 152 154 157 162
1200
MBh 35.0 35.5 36.5 38.0 34.7 35.2 36.2 37.7 33.9 34.3 35.3 36.9 32.3 32.8 33.8 35.4 30.5 31.0 32.0 33.5 28.8 29.3 30.3 31.8
S/T 0.80 0.73 0.60 0.46 0.81 0.74 0.61 0.47 1.00 0.76 0.63 0.49 1.00 0.78 0.65 0.51 1.00 0.80 0.67 0.53 1.00 1.00 0.72 0.58
∆T 22 20 17 13 22 20 17 13 22 21 17 13 22 20 17 13 22 20 16 13 23 21 18 14
kW 2.04 2.04 2.04 2.05 2.27 2.27 2.26 2.28 2.52 2.52 2.51 2.53 2.79 2.79 2.79 2.80 3.10 3.09 3.09 3.11 3.45 3.45 3.45 3.46
Amps 7.7 7.7 7.7 7.8 8.7 8.7 8.7 8.8 9.9 9.9 9.9 9.9 11.1 11.1 11.1 11.2 12.5 12.5 12.5 12.6 14.2 14.1 14.1 14.2
Hi PR 254 255 256 261 293 294 295 300 334 335 336 341 378 379 380 385 425 426 428 432 476 477 479 483
Lo PR 125 126 129 134 132 134 137 142 138 140 143 148 144 145 148 153 149 151 154 159 156 157 160 165
1350
MBh 35.9 36.4 37.4 38.9 35.6 36.1 37.1 38.6 34.8 35.2 36.2 37.8 33.2 33.7 34.7 36.3 31.4 31.9 32.9 34.4 29.7 30.2 31.2 32.7
S/T 0.80 0.72 0.59 0.46 1.00 0.73 0.60 0.46 1.00 0.75 0.62 0.49 1.00 0.77 0.64 0.51 1.00 0.79 0.66 0.53 1.00 1.00 0.71 0.58
∆T 21 19 16 12 21 19 16 12 21 20 16 12 21 19 16 12 21 19 15 12 22 20 17 13
kW 2.05 2.05 2.05 2.06 2.28 2.28 2.27 2.29 2.53 2.53 2.52 2.54 2.80 2.80 2.80 2.81 3.11 3.10 3.10 3.12 3.46 3.46 3.46 3.47
Amps 7.7 7.7 7.7 7.8 8.8 8.8 8.7 8.8 9.9 9.9 9.9 10.0 11.2 11.2 11.1 11.2 12.6 12.6 12.5 12.6 14.2 14.2 14.2 14.3
Hi PR 256 257 259 263 295 296 298 302 336 337 339 343 380 381 383 387 428 429 431 435 479 480 481 486
Lo PR 128 129 132 138 135 137 140 145 142 143 146 151 147 148 151 157 152 154 157 162 159 160 163 168
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
20 www.goodmanmfg.com SS-GSZ14 SS-GSZ14 www.goodmanmfg.com 21
Expanded Cooling Data — GSZ140371A* / ARUF37C14A*+TXV (cont.)
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
985
MBh 34.2 34.7 35.7 37.2 33.9 34.4 35.4 36.9 33.0 33.5 34.5 36.0 31.5 32.0 33.0 34.5 29.7 30.2 31.2 32.7 28.0 28.5 29.5 31.0
S/T 0.88 0.81 0.68 0.54 1.00 0.81 0.68 0.55 1.00 0.84 0.71 0.57 1.00 0.86 0.73 0.59 1.00 1.00 0.75 0.61 1.00 1.00 0.80 0.66
∆T 28 26 23 19 28 26 23 19 28 26 23 19 28 26 23 19 28 26 22 19 29 27 24 20
kW 2.03 2.02 2.02 2.04 2.25 2.25 2.25 2.26 2.50 2.50 2.50 2.52 2.78 2.77 2.77 2.79 3.08 3.08 3.07 3.09 3.44 3.44 3.43 3.45
Amps 7.6 7.6 7.6 7.7 8.7 8.7 8.6 8.7 9.8 9.8 9.8 9.9 11.1 11.0 11.0 11.1 12.4 12.4 12.4 12.5 14.1 14.1 14.1 14.1
Hi PR 250 252 253 258 290 291 292 297 330 332 333 338 375 376 377 382 422 423 425 429 473 474 476 480
Lo PR 122 123 126 131 129 131 134 139 135 137 140 145 141 142 145 150 146 148 151 156 153 154 157 162
1200
MBh 35.2 35.7 36.7 38.2 34.9 35.4 36.4 37.9 34.0 34.5 35.5 37.0 32.5 33.0 34.0 35.5 30.7 31.1 32.1 33.7 29.0 29.5 30.5 32.0
S/T 1.00 0.85 0.72 0.58 1.00 0.86 0.73 0.59 1.00 0.88 0.75 0.61 1.00 1.00 0.77 0.63 1.00 1.00 0.79 0.65 1.00 1.00 0.84 0.70
∆T 27 25 21 17 26 25 21 17 27 25 21 17 26 25 21 17 26 24 21 17 27 25 22 18
kW 2.04 2.04 2.04 2.05 2.27 2.27 2.26 2.28 2.52 2.52 2.51 2.53 2.79 2.79 2.79 2.80 3.10 3.09 3.09 3.11 3.45 3.45 3.45 3.47
Amps 7.7 7.7 7.7 7.8 8.7 8.7 8.7 8.8 9.9 9.9 9.9 9.9 11.1 11.1 11.1 11.2 12.5 12.5 12.5 12.6 14.2 14.1 14.1 14.2
Hi PR 254 255 257 261 293 294 296 300 334 335 337 341 378 379 381 385 426 427 428 433 476 477 479 484
Lo PR 125 127 130 135 133 134 137 142 139 141 144 149 144 146 149 154 150 151 154 159 156 158 161 166
1350
MBh 36.1 36.6 37.6 39.1 35.8 36.3 37.3 38.8 34.9 35.4 36.4 37.9 33.4 33.9 34.9 36.4 31.6 32.0 33.1 34.6 29.9 30.4 31.4 32.9
S/T 1.00 0.84 0.71 0.58 1.00 0.85 0.72 0.58 1.00 0.87 0.74 0.61 1.00 1.00 0.76 0.63 1.00 1.00 0.78 0.65 1.00 1.00 0.83 0.70
∆T 26 24 20 16 25 24 20 16 26 24 20 17 25 24 20 16 25 23 20 16 26 24 21 17
kW 2.05 2.05 2.05 2.06 2.28 2.28 2.27 2.29 2.53 2.53 2.52 2.54 2.80 2.80 2.80 2.81 3.11 3.10 3.10 3.12 3.46 3.46 3.46 3.47
Amps 7.7 7.7 7.7 7.8 8.8 8.8 8.8 8.8 9.9 9.9 9.9 10.0 11.2 11.2 11.2 11.2 12.6 12.6 12.5 12.6 14.2 14.2 14.2 14.3
Hi PR 257 258 260 264 296 297 299 303 337 338 340 344 381 382 384 388 428 429 431 435 479 480 482 486
Lo PR 128 130 133 138 136 137 140 145 142 144 147 152 147 149 152 157 153 154 157 162 159 161 164 169
85
985
MBh 34.8 35.2 36.3 37.8 34.5 34.9 36.0 37.5 33.6 34.1 35.1 36.6 32.1 32.6 33.6 35.1 30.2 30.7 31.7 33.3 28.6 29.0 30.0 31.6
S/T 1.00 0.91 0.78 0.64 1.00 0.91 0.78 0.64 1.00 1.00 0.81 0.67 1.00 1.00 0.82 0.69 1.00 1.00 0.85 0.71 1.00 1.00 1.00 0.76
∆T 32 30 26 23 32 30 26 23 32 30 27 23 32 30 26 23 32 30 26 22 33 31 27 24
kW 2.03 2.03 2.03 2.04 2.26 2.25 2.25 2.27 2.51 2.51 2.50 2.52 2.78 2.78 2.77 2.79 3.08 3.08 3.08 3.10 3.44 3.44 3.44 3.45
Amps 7.6 7.6 7.6 7.7 8.7 8.7 8.7 8.7 9.8 9.8 9.8 9.9 11.1 11.1 11.1 11.1 12.5 12.5 12.4 12.5 14.1 14.1 14.1 14.2
Hi PR 252 253 254 259 291 292 293 298 332 333 334 339 376 377 379 383 423 424 426 430 474 475 477 481
Lo PR 124 125 128 133 131 132 135 140 137 139 142 147 143 144 147 152 148 149 152 158 155 156 159 164
1200
MBh 35.8 36.2 37.2 38.8 35.5 35.9 36.9 38.5 34.6 35.1 36.1 37.6 33.1 33.6 34.6 36.1 31.2 31.7 32.7 34.2 29.6 30.0 31.0 32.6
S/T 1.00 0.95 0.82 0.68 1.00 1.00 0.82 0.69 1.00 1.00 0.85 0.71 1.00 1.00 0.87 0.73 1.00 1.00 0.89 0.75 1.00 1.00 1.00 0.80
∆T 30 28 25 21 30 28 25 21 31 29 25 21 30 28 25 21 30 28 24 21 31 29 26 22
kW 2.05 2.05 2.04 2.06 2.27 2.27 2.27 2.28 2.52 2.52 2.52 2.54 2.80 2.79 2.79 2.81 3.10 3.10 3.10 3.11 3.46 3.46 3.45 3.47
Amps 7.7 7.7 7.7 7.8 8.8 8.7 8.7 8.8 9.9 9.9 9.9 10.0 11.2 11.1 11.1 11.2 12.5 12.5 12.5 12.6 14.2 14.2 14.2 14.2
Hi PR 255 256 258 262 294 295 297 301 335 336 338 342 379 380 382 386 427 428 430 434 478 479 480 485
Lo PR 127 129 132 137 134 136 139 144 141 142 145 150 146 148 151 156 151 153 156 161 158 160 163 168
1350
MBh 36.7 37.1 38.1 39.7 36.4 36.8 37.8 39.4 35.5 36.0 37.0 38.5 34.0 34.5 35.5 37.0 32.1 32.6 33.6 35.1 30.5 30.9 31.9 33.5
S/T 1.00 0.94 0.81 0.67 1.00 1.00 0.82 0.68 1.00 1.00 0.84 0.70 1.00 1.00 0.86 0.72 1.00 1.00 1.00 0.74 1.00 1.00 1.00 0.79
∆T 29 27 24 20 29 27 24 20 30 28 24 20 29 27 24 20 29 27 23 20 30 28 25 21
kW 2.06 2.06 2.05 2.07 2.28 2.28 2.28 2.29 2.53 2.53 2.53 2.55 2.81 2.80 2.80 2.82 3.11 3.11 3.11 3.12 3.47 3.47 3.46 3.48
Amps 7.8 7.8 7.7 7.8 8.8 8.8 8.8 8.9 10.0 9.9 9.9 10.0 11.2 11.2 11.2 11.2 12.6 12.6 12.6 12.6 14.2 14.2 14.2 14.3
Hi PR 258 259 261 265 297 298 300 304 338 339 341 345 382 383 385 389 430 431 432 437 480 481 483 487
Lo PR 130 132 135 140 137 139 142 147 144 145 148 153 149 151 154 159 155 156 159 164 161 163 166 171
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI Rang Condions. kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = Outdoor unit amps (compressor + fan)
Table of contents
Other Goodman Heat Pump manuals
Goodman
Goodman PC User manual
Goodman
Goodman CONDENSING UNIT User manual
Goodman
Goodman GPH15M User manual
Goodman
Goodman GPH 14 SEER R-410A User manual
Goodman
Goodman R-410A User manual
Goodman
Goodman GSH130181A Series Technical document
Goodman
Goodman SSZ 14 SEER User manual
Goodman
Goodman SSZ 16 SEER Technical document
Goodman
Goodman M Series User manual
Goodman
Goodman ASZC180361A User manual
Goodman
Goodman ASX Operating instructions
Goodman
Goodman DSZ180601A Series User manual
Goodman
Goodman GSX160181F Series User manual
Goodman
Goodman SS-GSH10C User manual
Goodman
Goodman CPLE090 Manual
Goodman
Goodman SS-DSZC18 User manual
Goodman
Goodman GPH16 M Series User manual
Goodman
Goodman GPH 13 M Series User manual
Goodman
Goodman SSZ 16 SEER User manual
Goodman
Goodman GSZ140311 User manual
Popular Heat Pump manuals by other brands
Carrier
Carrier AquaSnap 61AF-B Installation, operation and maintenance instructions
Dimplex
Dimplex SI 6TU Installation and operating instructions
Nibe
Nibe FIGHTER 1120 Maintenance Instruction
Atlantic
Atlantic alfea excellia duo 11 Installation and operating manual
Daikin
Daikin VHF Installation and maintenance manual
Daikin
Daikin VRV III-S RXYMQ6PV4A Service manual
Daikin
Daikin DZ17VSA Series installation instructions
CLIVET
CLIVET WBAN Series Installation, use & maintenance manual
Sanyo
Sanyo 26TW72R Specifications
Carrier
Carrier 25VNA8 infinity 18VS installation instructions
Zodiac
Zodiac ZS500 Instructions for installation and use
Bard
Bard WH185 installation instructions
