Goodman DSX16 User manual

DSX 16 SEER
Condensing Units
•RefertoServiceManualRS6200006forinstallation,operation,andtroubleshootinginformation.
•Allsafetyinformation must be followedasprovided in the ServiceManual.
•RefertotheappropriatePartsCatalog for part number information.
•See models on page 2.
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUALAL
ALAL
AL
RT6114006r3
September2009
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does
not assume any responsibility for property damage or personal injury due to improper service
procedures or services performed by an unqualified person.
Copyright © 2009 Goodman Manufacturing Company, L.P.

PRODUCT IDENTIFICATION
2
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed ONLY by
individuals meeting the requirements of an "entry level
technician"asspecifiedbytheAir-Conditioning,Heating,
and Refrigeration Institute (AHRI). Attempting to install
or repair this unit without such background may result
in product damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING WARNING
WARNING
DSX160241AA
PRODUCT
TYPE:
X: Condenser R-410A
Z: Heat PumpR-410A
PRODUCT
FAMILY:
S: Split System
SEER:
SEER Rating MAJOR
REVISION:
A
:InitialReleas
e
MINOR
REVISION:
A
: Initial Release
ELECTRICAL:
1: 208-230V/1ph/60Hz
3: 208-230v/3ph/60Hz
4: 460v/3ph/60Hz
NOMINAL
CAPACITY:
024: 2Tons
036: 3Tons
048: 4Tons
060: 5Tons
BRAND:
D:Deluxe
Goodman®
Brand

PRODUCT IDENTIFICATION
3
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
* Indicates minor revision & is not used for order entry or inventory management
DSX160241A*
DSX160361A*
DSX160481A*
DSX160601A*
DSX160241B*
DSX160361B*
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING

PRODUCT DESIGN
4
DSX16 models are available in 2, 3 4 and 5 ton sizes and
use R-410A refrigerant. They are designed for 208/230 volt
singlephaseapplications.
The condenser air is pulled through the condenser coil by a
direct drive propeller fan. This condenser air is then dis-
charged out of the top of the cabinet.
These units are designed for free air discharge, so no addi-
tional resistance like duct work shall be attached.
The suction and liquid line connections on present models
areof the sweat type for field pipingwithrefrigeranttypecop-
per. Front seating valves are factory installed to accept the
fieldruncopper. The total refrigerantcharge for a normal in-
stallationis factory installed in thecondensingunit.DSXunits
are charged for the matching evaporator coil and a 15 foot
refrigerantlineset.
Systems should be properly sized by heat gain and loss
calculations made according to methods of the Air Condi-
tioning Contractors Association (ACCA) or equivalent. It is
the contractors responsibility to ensure the system has ad-
equate capacity to heat or cool the conditioned space.
DSX16 models use the Copeland Scroll "Ultratech" Series
compressorswhichare specifically designed for R-410Are-
frigerant. Thereare anumberofdesign characteristicswhich
are different from the traditional reciprocating and/or scroll
compressors.
"Ultratech" Series scroll compressors with Copeland®
ComfortAlert diagnostics will not have a discharge thermo-
stat, some of the early model scroll compressors required
dischargethermostats.
"Ultratech" Series scroll compressors will not have a dis-
chargethermo-stat. Some of the earlymodelscrollcompres-
sorsrequireddischargethermostats.DuetotheirdesignScroll
compressorsareinherentlymoretolerantof small quantities
ofliquid refrigerant.
NOTE: Eventhough thecompressorsectionofa Scrollcom-
pressor is more tolerant of liquid refrigerant, continued
floodback or flooded start conditions may wash oil from the
bearingsurfacescausing premature bearing failure.
"Ultratech" Series scroll compressors use "POE" or
polyolesteroil whichisNOT compatiblewithmineraloilbased
lubricants like 3GS. "POE" oil must be used if additional oil
isrequired.
WARNING
To avoid possible injury, explosion or death, practice
safe handling of refrigerants.
Operating pressures and amp draws may differ from stan-
dardreciprocatingand/orscroll compressors. This informa-
tion may be found in the "Cooling Performance Data" sec-
tion.
This unit is for outdoor installation only. Refer to minimum
figure for clearances from the sides of the unit to full walls
andother objects.
NOTE: This unit cannot be completely enclosed. At least
one side must be unrestricted.
Theseclearanceswillhelpavoidairrecirculation.Ifinstalling
two or more units at the same location, allow at least 24
inches between units. If only one side is restricted (for ex-
ample, against the outside wall of a house), the unit may be
placed as close as 8" to that one wall.
DO NOT locate the unit:
* Directlyundera vent termination fora gas appliance.
* Within 3 feet of a clothes drier vent
* Wheretherefreezingofdefrostwaterwould create
ahazard
* Where water may rise into the unit.
OK!
OK!
AA AAA
A
CC
CCOK!
OK!
OK!
OK!
NOT
RECOMMENDED
AA
AA AA
AA
AA
B B B
B
Model Type A B C AA
Residential 10" 10" 18" 20"
Light Commercial 12' 12" 18" 24"
Model Dimensions - W x D x H
DSX160241A* 29 x 29 x 38¼
DSX160361A* 29 x 29 x 38¼
DSX160481A* 35½ x 35½ x 38¼
DSX160601A* 35½ x 35½ x 38¼
DSX160241B* 29 x 29 x 30¼
DSX160361B* 29 x 29 x 30¼

CONDENSING UNIT SPECIFICATIONS
5
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and
wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general
and electrical information.
DSX160241A* - DSX160601A*
* Up to 24' in equivalent line length
(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE
OUTDOORUNIT,NOTTHEINDOORCOIL.
DSX160241A* DSX160361A* DSX160481A* DSX160601A*
Cooling Capacity, BTUH 24,000 36,000 48,000 60,000
Compressor
R.L. Amps 10.3 16.7 21.2 25.6
L.R. Amps 52.0 82.0 96.0 118.0
Low Pressure Switch
Open 22 PSIG 22 PSIG 22 PSIG 22 PSIG
Close 50 PSIG 50 PSIG 50 PSIG 50 PSIG
High Pressure Switch
Open 610 PSIG 610 PSIG 610 PSIG 610 PSIG
Close 420 PSIG 420 PSIG 420 PSIG 420 PSIG
Condenser Fan Motor
Horsepower 1/12 1/6 1/6 1/6
F.L.Amps 0.6 1.0 1.0 1.0
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 3/4" 7/8" 1-1/8" 1-1/8"
Refrigerant Charge 137.0 157.0 202.0 197.0
PowerSupply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity(1) 13.5 21.9 27.5 33.0
Maximum Overcurrent Device(2) 20 35 45 50
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 282 282 296 296

CONDENSING UNIT SPECIFICATIONS
6
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and
wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general
and electrical information.
DSX160241B* - DSX160361B*
* Up to 24' in equivalent line length
(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE
OUTDOORUNIT,NOTTHEINDOORCOIL.
DSX160241B* DSX160361B*
Cooling Capacity, BTUH 24,000 36,000
Compressor
R.L. Amps 10.3 16.7
L.R. Amps 52.0 82.0
LowPressure Switch
Open 22 PSIG 22 PSIG
Close 50 PSIG 50 PSIG
High Pressure Switch
Open 610 PSIG 610 PSIG
Close 420 PSIG 420 PSIG
Condenser Fan Motor
Horsepower 1/6 1/6
F.L.Amps 1.1 0.9
Liquid Line, Inches O.D.* 3/8" 3/8"
Suction Line, Inches O.D.* 3/4" 7/8"
Refrigerant Charge 100.0 110.0
Power Supply 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity(1) 14.0 21.8
Maximum Overcurrent Device(2) 20 35
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 198 206

7
PERFORMANCE DATA DSX160241A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160241A* / CA*F3636C6** + TXV / MBE1200**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5°F @ Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 18.0 18.7 20.4 - 17.6 18.2 20.0 - 17.2 17.8 19.5 - 16.7 17.4 19.0 - 15.9 16.5 18.1 - 14.7 15.3 16.7 -
S/T 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.80 0.66 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
675 KW 1.10 1.12 1.16 - 1.19 1.21 1.25 - 1.26 1.29 1.34 - 1.33 1.37 1.41 - 1.39 1.43 1.48 - 1.44 1.48 1.53 -
AMPS 4.5 4.6 4.7 - 4.8 4.9 5.1 - 5.2 5.3 5.5 - 5.6 5.7 5.9 - 5.9 6.1 6.3 - 6.3 6.4 6.6 -
HI PR 228 245 248 - 258 277 281 - 293 315 319 - 334 359 364 - 375 404 409 - 420 452 458 -
LO PR 122 125 137 - 125 129 141 - 129 133 146 - 133 137 150 - 135 140 153 - 139 143 156 -
MBh 17.5 18.1 19.8 - 17.1 17.7 19.4 - 16.7 17.3 18.9 - 16.3 16.8 18.5 - 15.4 16.0 17.5 - 14.3 14.8 16.2 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
Delta T 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
70 600 KW 1.09 1.11 1.15 - 1.18 1.20 1.24 - 1.25 1.28 1.33 - 1.32 1.35 1.40 - 1.38 1.41 1.46 - 1.43 1.47 1.52 -
AMPS 4.4 4.5 4.7 - 4.8 4.9 5.0 - 5.2 5.3 5.5 - 5.5 5.7 5.8 - 5.9 6.0 6.2 - 6.2 6.4 6.6 -
HI PR 226 243 246 - 255 274 278 - 290 312 316 - 330 355 360 - 372 400 405 - 416 447 454 -
LO PR 120 124 136 - 124 128 140 - 128 132 144 - 132 136 148 - 134 138 151 - 137 142 155 -
MBh 16.1 16.7 18.3 - 15.8 16.3 17.9 - 15.4 15.9 17.5 - 15.0 15.6 17.0 - 14.3 14.8 16.2 - 13.2 13.7 15.0 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
525 KW 1.08 1.10 1.14 - 1.17 1.19 1.23 - 1.24 1.27 1.31 - 1.31 1.34 1.39 - 1.37 1.40 1.45 - 1.42 1.45 1.50 -
AMPS 4.4 4.5 4.6 - 4.7 4.8 5.0 - 5.1 5.3 5.4 - 5.5 5.6 5.8 - 5.8 6.0 6.2 - 6.2 6.3 6.5 -
HI PR 223 240 244 - 252 271 275 - 287 309 313 - 327 352 357 - 368 396 401 - 412 443 449 -
LO PR 119 123 134 - 123 127 138 - 127 131 143 - 130 134 147 - 133 137 150 - 136 140 153 -
MBh 18.3 18.8 20.4 21.9 17.9 18.4 19.9 21.4 17.5 18.0 19.4 20.9 17.0 17.5 19.0 20.4 16.2 16.7 18.0 19.3 15.0 15.4 16.7 17.9
S/T 0.850.760.580.370.880.790.600.380.900.810.610.390.93 0.84 0.63 0.41 0.97 0.87 0.66 0.42 0.98 0.87 0.66 0.43
DeltaT21201611212016112220161122 20 16 11 21 20 16 11 20 18 15 10
675 KW 1.10 1.12 1.16 1.20 1.19 1.21 1.25 1.30 1.26 1.29 1.34 1.38 1.33 1.37 1.41 1.46 1.39 1.43 1.48 1.53 1.44 1.48 1.53 1.58
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9
HI PR 228 245 248 254 258 277 281 287 293 315 319 326 334 359 364 372 375 404 409 418 420 452 458 468
LO PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166
MBh 17.8 18.3 19.8 21.3 17.4 17.9 19.3 20.8 16.9 17.4 18.9 20.3 16.5 17.0 18.4 19.8 15.7 16.2 17.5 18.8 14.5 15.0 16.2 17.4
S/T 0.810.730.550.350.840.750.570.370.860.770.580.380.89 0.80 0.60 0.39 0.92 0.83 0.63 0.40 0.93 0.83 0.63 0.41
DeltaT22201712222117122221171223 21 17 12 22 20 17 12 21 19 16 11
75 600 KW 1.09 1.11 1.15 1.19 1.18 1.20 1.24 1.29 1.25 1.28 1.33 1.37 1.32 1.35 1.40 1.45 1.38 1.41 1.46 1.51 1.43 1.47 1.52 1.57
AMPS 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8
HI PR 226 243 246 251 255 274 278 284 290 312 316 323 330 355 360 368 372 400 405 414 416 447 454 464
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 137 142 155 165
MBh 16.4 16.9 18.3 19.6 16.0 16.5 17.9 19.2 15.6 16.1 17.4 18.7 15.3 15.7 17.0 18.2 14.5 14.9 16.2 17.3 13.4 13.8 15.0 16.1
S/T 0.780.700.530.340.810.730.550.350.830.740.560.360.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
DeltaT22211712232117122321171223 21 17 12 23 21 17 12 21 19 16 11
525 KW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.39 1.44 1.37 1.40 1.45 1.50 1.42 1.45 1.50 1.56
AMPS 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.3 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8
HI PR 223 240 244 249 252 271 275 281 287 309 313 320 327 352 357 364 368 396 401 410 412 443 449 459
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
*Entering IndoorDry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

8
PERFORMANCE DATA DSX160241A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160241A* / CA*F3636C6** + TXV / MBE1200**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5°F @ Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 18.6 19.0 20.3 21.7 18.2 18.6 19.9 21.2 17.8 18.1 19.4 20.7 17.3 17.7 18.9 20.2 16.5 16.8 18.0 19.2 15.2 15.6 16.6 17.8
S/T 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.81 0.61 1.00 1.00 0.82 0.61
DeltaT24232016242320162423201624 23 20162223201621211915
675 KW 1.10 1.12 1.16 1.20 1.19 1.21 1.25 1.30 1.26 1.29 1.34 1.38 1.33 1.37 1.41 1.46 1.39 1.43 1.48 1.53 1.44 1.48 1.53 1.58
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9
HI PR 228 245 248 254 258 277 281 287 293 315 319 326 334 359 364 372 375 404 409 418 420 452 458 468
LO PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166
MBh 18.1 18.5 19.7 21.1 17.7 18.1 19.3 20.6 17.2 17.6 18.8 20.1 16.8 17.2 18.4 19.6 16.0 16.3 17.4 18.7 14.8 15.1 16.2 17.3
S/T 0.890.840.680.510.920.870.700.530.950.890.720.540.98 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58
DeltaT25242116252421172524211725 24 21 17 24 24 21 17 23 22 19 15
80 600 KW 1.09 1.11 1.15 1.19 1.18 1.20 1.24 1.29 1.25 1.28 1.33 1.37 1.32 1.35 1.40 1.45 1.38 1.41 1.46 1.51 1.43 1.47 1.52 1.57
AMPS 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.15.96.06.26.46.26.46.66.8
HI PR 226 243 246 251 255 274 278 284 290 312 316 323 330 355 360 368 372 400 405 414 416 447 454 464
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 137 142 155 165
MBh 16.7 17.1 18.2 19.5 16.3 16.7 17.8 19.0 15.9 16.3 17.4 18.6 15.5 15.9 17.0 18.1 14.8 15.1 16.1 17.2 13.7 14.0 14.9 15.9
S/T 0.86 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.91 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.92 0.75 0.56
DeltaT25242117252421172524211726 25 21172524211724232016
525 KW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.39 1.44 1.37 1.40 1.45 1.50 1.42 1.45 1.50 1.56
AMPS 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.3 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8
HI PR 223 240 244 249 252 271 275 281 287 309 313 320 327 352 357 364 368 396 401 410 412 443 449 459
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
MBh 19.0 19.3 20.2 21.6 18.5 18.9 19.8 21.1 18.1 18.4 19.3 20.6 17.6 18.0 18.8 20.1 16.8 17.1 17.9 19.1 15.5 15.8 16.6 17.7
S/T 0.98 0.94 0.85 0.69 1.00 0.98 0.88 0.72 1.00 1.00 0.91 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.97 0.79 1.00 1.00 0.98 0.79
DeltaT25252320252524212525242124 24 24212323242021222219
675 KW 1.10 1.12 1.16 1.20 1.19 1.21 1.25 1.30 1.26 1.29 1.34 1.38 1.33 1.37 1.41 1.46 1.39 1.43 1.48 1.53 1.44 1.48 1.53 1.58
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9
HI PR 228 245 248 254 258 277 281 287 293 315 319 326 334 359 364 372 375 404 409 418 420 452 458 468
LO PR 122 125 137 146 125 129 141 150 129 133 146 155 133 137 150 159 135 140 153 162 139 143 156 166
MBh 18.4 18.8 19.6 21.0 18.0 18.3 19.2 20.5 17.5 17.9 18.7 20.0 17.1 17.4 18.3 19.5 16.3 16.6 17.4 18.5 15.1 15.4 16.1 17.2
S/T 0.93 0.90 0.81 0.66 0.97 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.93 0.75 1.00 1.00 0.93 0.76
DeltaT26262421272625212726252126 26 25222525252123242320
85 600 KW 1.09 1.11 1.15 1.19 1.18 1.20 1.24 1.29 1.25 1.28 1.33 1.37 1.32 1.35 1.40 1.45 1.38 1.41 1.46 1.51 1.43 1.47 1.52 1.57
AMPS 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8
HI PR 226 243 246 251 255 274 278 284 290 312 316 323 330 355 360 368 372 400 405 414 416 447 454 464
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 137 142 155 165
MBh 17.0 17.3 18.1 19.3 16.6 16.9 17.7 18.9 16.2 16.5 17.3 18.4 15.8 16.1 16.9 18.0 15.0 15.3 16.0 17.1 13.9 14.2 14.8 15.8
S/T 0.90 0.87 0.78 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.90 0.73
Delta T 26.77 26 25 22 27 27 25 22 27 27 25 22 27 27 25 22 26 26 25 22 24 25 23 20
525 KW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.39 1.44 1.37 1.40 1.45 1.50 1.42 1.45 1.50 1.56
AMPS 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.2 5.1 5.3 5.4 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8
HI PR 223 240 244 249 252 271 275 281 287 309 313 320 327 352 357 364 368 396 401 410 412 443 449 459
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
*Entering IndoorDry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

9
PERFORMANCE DATA DSX160241B*-LOW STAGE
LOW STAGE EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160241B* / CA*F3636*6**+TXV+MBE1200**-1* Design Subcooling 5 - 7 °F @ the liquidservice valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 17.2 17.9 19.6 - 16.8 17.5 19.1 - 16.4 17.0 18.7 - 16.0 16.6 18.2 - 15.2 15.8 17.3 - 14.1 14.6 16.0 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
608 KW 1.06 1.09 1.12 - 1.15 1.17 1.21 - 1.22 1.25 1.29 - 1.29 1.31 1.36 - 1.34 1.37 1.42 - 1.39 1.42 1.47 -
AMPS 4.2 4.3 4.5 - 4.6 4.7 4.8 - 4.9 5.0 5.2 - 5.3 5.4 5.5 - 5.6 5.7 5.9 - 5.9 6.0 6.2 -
HI PR 202 217 229 - 227 244 258 - 258 277 293 - 294 316 334 - 330 355 375 - 365 393 415 -
LO PR 102 109 119 - 108 115 126 - 112 120 131 - 118 126 137 - 124 132 144 - 128 136 149 -
MBh 16.7 17.4 19.0 - 16.4 17.0 18.6 - 16.0 16.5 18.1 - 15.6 16.1 17.7 - 14.8 15.3 16.8 - 13.7 14.2 15.6 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
70 540 KW 1.05 1.08 1.11 - 1.14 1.16 1.20 - 1.21 1.24 1.28 - 1.27 1.30 1.35 - 1.33 1.36 1.41 - 1.38 1.41 1.46 -
AMPS 4.2 4.3 4.4 - 4.5 4.6 4.8 - 4.9 5.0 5.2 - 5.2 5.3 5.5 - 5.5 5.7 5.8 - 5.8 6.0 6.2 -
HI PR 200 215 227 - 224 241 255 - 255 275 290 - 291 313 330 - 327 352 372 - 361 389 411 -
LO PR 101 108 118 - 107 114 124 - 111 118 129 - 117 124 136 - 123 130 142 - 127 135 147 -
MBh 15.5 16.0 17.6 - 15.1 15.6 17.1 - 14.7 15.3 16.7 - 14.4 14.9 16.3 - 13.7 14.2 15.5 - 12.7 13.1 14.4 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.75 0.63 0.44 -
Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
473 KW 1.03 1.05 1.08 - 1.11 1.13 1.17 - 1.18 1.21 1.25 - 1.24 1.27 1.31 - 1.30 1.32 1.37 - 1.34 1.37 1.42 -
AMPS 4.1 4.2 4.3 - 4.4 4.5 4.6 - 4.8 4.9 5.0 - 5.1 5.2 5.4 - 5.4 5.5 5.7 - 5.7 5.8 6.0 -
HI PR 194 209 220 - 218 234 247 - 248 266 281 - 282 303 320 - 317 341 360 - 350 377 398 -
LO PR 98 105 114 - 104 111 121 - 108 115 125 - 113 121 132 - 119 126 138 - 123 131 143 -
MBh 17.518.119.521.017.117.619.120.516.717.218.620.016.3 16.8 18.2 19.5 15.5 16.0 17.3 18.5 14.4 14.8 16.0 17.2
S/T 0.810.730.550.350.840.750.570.370.860.770.580.380.89 0.80 0.60 0.39 0.92 0.83 0.62 0.40 0.93 0.83 0.63 0.41
DeltaT22201611222016112220161122 20 17 11 22 20 16 11 20 19 15 11
608 KW 1.07 1.09 1.13 1.17 1.16 1.18 1.22 1.26 1.23 1.26 1.30 1.34 1.30 1.33 1.37 1.42 1.35 1.38 1.43 1.48 1.40 1.43 1.48 1.53
AMPS4.34.44.54.74.64.74.95.05.05.15.35.45.3 5.4 5.6 5.8 5.6 5.8 5.9 6.2 5.9 6.1 6.3 6.5
HI PR 204 220 232 242 229 246 260 271 260 280 296 309 297 319 337 351 334 359 379 395 369 397 419 437
LO PR 103 110 120 128 109 116 127 135 114 121 132 141 119 127 139 148 125 133 145 155 129 138 150 160
MBh 17.017.519.020.416.617.118.519.916.216.718.119.415.8 16.3 17.7 18.9 15.0 15.5 16.8 18.0 13.9 14.4 15.5 16.7
S/T 0.770.690.520.340.800.720.540.350.820.730.560.360.85 0.76 0.57 0.37 0.88 0.79 0.60 0.38 0.89 0.79 0.60 0.39
DeltaT22211712232117122321171223 21 17 12 23 21 17 12 21 19 16 11
75 540 KW 1.06 1.09 1.12 1.16 1.15 1.17 1.21 1.25 1.22 1.25 1.29 1.33 1.29 1.31 1.36 1.40 1.34 1.37 1.42 1.47 1.39 1.42 1.47 1.52
AMPS4.24.34.54.64.64.74.85.04.95.05.25.45.3 5.4 5.6 5.8 5.6 5.7 5.9 6.1 5.9 6.0 6.2 6.5
HI PR 202 217 230 239 227 244 258 269 258 277 293 306 294 316 334 348 330 355 375 391 365 393 415 433
LO PR 102 109 119 127 108 115 126 134 112 120 131 139 118 126 137 146 124 132 144 153 128 136 149 158
MBh 15.716.217.518.815.415.817.118.415.015.416.717.914.6 15.1 16.3 17.5 13.9 14.3 15.5 16.6 12.9 13.2 14.3 15.4
S/T 0.750.670.500.320.770.690.520.340.790.710.540.350.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.86 0.77 0.58 0.37
DeltaT23211712232117122321171223 21 18 12 23 21 17 12 21 20 16 11
473 KW 1.04 1.06 1.09 1.13 1.12 1.14 1.18 1.22 1.19 1.22 1.26 1.30 1.25 1.28 1.32 1.37 1.31 1.34 1.38 1.43 1.35 1.38 1.43 1.48
AMPS4.14.24.44.54.44.54.74.94.84.95.15.35.1 5.2 5.4 5.6 5.4 5.6 5.7 5.9 5.7 5.9 6.1 6.3
HI PR 196 211 223 232 220 237 250 261 250 269 284 296 285 306 324 338 320 345 364 380 354 381 402 420
LO PR 99 106 115 123 105 112 122 130 109 116 127 135 115 122 133 142 120 128 139 149 124 132 144 154
*Entering Indoor Dry Bulb Temperature NOTE: Shaded area isACCA(TVA) conditions

10
PERFORMANCE DATA DSX160241B*-LOW STAGE
LOW STAGE EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160241B* / CA*F3636*6**+TXV+MBE1200**-1* Design Subcooling 5 - 7 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 17.918.219.520.817.417.819.020.317.017.418.619.916.6 17.0 18.119.415.816.117.218.414.614.916.017.1
S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.53 0.94 0.89 0.72 0.54 1.00 0.91 0.74 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58
DeltaT24232016242320162423201625 23 20162423201622221915
608 KW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.38 1.43 1.36 1.39 1.44 1.49 1.41 1.44 1.49 1.55
AMPS 4.3 4.4 4.5 4.7 4.6 4.7 4.9 5.1 5.0 5.1 5.3 5.5 5.4 5.5 5.6 5.9 5.7 5.8 6.0 6.2 6.0 6.1 6.3 6.6
HI PR 206 222 234 244 231 249 263 274 263 283 299 312 300 322 340 355 337 363 383 399 372 401 423 441
LO PR 104 111 121 129 110 117 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162
MBh 17.317.718.920.216.917.318.519.816.516.918.019.316.1 16.5 17.6 18.8 15.3 15.6 16.7 17.9 14.2 14.5 15.5 16.6
S/T 0.850.800.650.480.880.820.670.500.900.850.690.510.93 0.87 0.71 0.53 0.97 0.91 0.74 0.55 0.97 0.91 0.74 0.56
DeltaT25242117252421172524211726 24 21 17 25 24 21 17 24 23 20 16
80 540 KW 1.07 1.09 1.13 1.17 1.16 1.18 1.22 1.26 1.23 1.26 1.30 1.34 1.30 1.33 1.37 1.42 1.35 1.38 1.43 1.48 1.40 1.43 1.48 1.53
AMPS4.34.44.54.74.64.74.95.05.05.15.35.45.3 5.4 5.6 5.8 5.6 5.8 5.9 6.2 5.9 6.1 6.3 6.5
HI PR 204 220 232 242 229 246 260 271 260 280 296 309 297 319 337 351 334 359 379 395 369 397 419 437
LO PR 103 110 120 128 109 116 127 135 114 121 132 141 119 127 139 148 125 133 145 155 129 138 150 160
MBh 16.016.317.518.715.616.017.118.215.315.616.717.814.9 15.2 16.217.414.114.415.416.513.113.414.315.3
S/T 0.82 0.77 0.62 0.47 0.85 0.79 0.65 0.48 0.87 0.81 0.66 0.50 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.94 0.88 0.72 0.54
DeltaT25242117262521172625211726 25 22172625211724232016
473 KW 1.05 1.07 1.10 1.14 1.13 1.15 1.19 1.23 1.20 1.23 1.27 1.31 1.26 1.29 1.33 1.38 1.32 1.35 1.39 1.44 1.36 1.40 1.44 1.49
AMPS 4.2 4.3 4.4 4.5 4.5 4.6 4.7 4.9 4.8 5.0 5.1 5.3 5.2 5.3 5.5 5.6 5.5 5.6 5.8 6.0 5.8 5.9 6.1 6.3
HI PR 198 213 225 235 222 239 252 263 253 272 287 299 288 310 327 341 324 348 368 384 358 385 406 424
LO PR 100 107 117 124 106 113 123 131 110 117 128 136 116 123 134 143 121 129 141 150 125 133 146 155
MBh 18.218.519.420.717.718.118.920.217.317.718.519.716.9 17.2 18.019.216.116.417.118.314.915.215.916.9
S/T 0.93 0.90 0.81 0.66 0.97 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.76
DeltaT26252421262624212626242126 26 24212425242123232219
608 KW 1.09 1.11 1.15 1.19 1.18 1.20 1.24 1.28 1.25 1.28 1.32 1.37 1.32 1.35 1.39 1.44 1.38 1.41 1.45 1.50 1.42 1.46 1.51 1.56
AMPS 4.4 4.4 4.6 4.7 4.7 4.8 4.9 5.1 5.1 5.2 5.3 5.5 5.4 5.5 5.7 5.9 5.7 5.9 6.1 6.3 6.1 6.2 6.4 6.6
HI PR 208 224 237 247 234 251 265 277 266 286 302 315 303 326 344 359 340 366 387 403 376 405 427 446
LO PR 106 112 123 131 112 119 130 138 116 123 135 143 122 130 141 151 128 136 148 158 132 140 153 163
MBh 17.618.018.820.117.217.618.419.616.817.117.919.116.4 16.7 17.518.715.615.916.617.714.414.715.416.4
S/T 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.67 0.98 0.94 0.85 0.69 1.00 0.98 0.88 0.72 1.00 0.98 0.89 0.72
DeltaT27262521272725222727252227 27 25222726252225252320
85 540 KW 1.08 1.10 1.14 1.18 1.17 1.19 1.23 1.27 1.24 1.27 1.31 1.36 1.31 1.34 1.38 1.43 1.36 1.39 1.44 1.49 1.41 1.44 1.49 1.55
AMPS 4.3 4.4 4.5 4.7 4.6 4.7 4.9 5.1 5.0 5.1 5.3 5.5 5.4 5.5 5.6 5.9 5.7 5.8 6.0 6.2 6.0 6.1 6.3 6.6
HI PR 206 222 234 244 231 249 263 274 263 283 299 312 300 322 340 355 337 363 383 399 372 401 423 441
LO PR 104 111 121 129 110 117 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162
MBh 16.316.617.418.515.916.217.018.115.515.816.617.715.1 15.4 16.217.214.414.715.416.413.313.614.215.2
S/T 0.86 0.83 0.75 0.61 0.89 0.86 0.77 0.63 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.66 0.98 0.94 0.85 0.69 0.98 0.95 0.86 0.70
Delta T 27.14 27 25 22 27 27 26 22 28 27 26 22 28 27 26 22 27 27 25 22 26 25 24 21
473 KW 1.05 1.08 1.11 1.15 1.14 1.16 1.20 1.24 1.21 1.24 1.28 1.32 1.27 1.30 1.35 1.39 1.33 1.36 1.40 1.45 1.38 1.41 1.46 1.51
AMPS 4.2 4.3 4.4 4.6 4.5 4.6 4.8 4.9 4.9 5.0 5.2 5.3 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.1 5.8 6.0 6.2 6.4
HI PR 200 215 227 237 224 241 255 266 255 275 290 302 291 313 330 344 327 352 371 387 361 389 410 428
LO PR 101 108 118 125 107 114 124 132 111 118 129 138 117 124 136 145 123 130 142 152 127 135 147 157
*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

11
PERFORMANCE DATA DSX160361A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160361A* / CA*F3743*6A* + TXV / MBE1600**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5° - 7°F @ the Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 24.9 25.8 28.3 - 24.3 25.2 27.6 - 23.8 24.6 27.0 - 23.2 24.0 26.3 - 22.0 22.8 25.0 - 20.4 21.1 23.2 -
S/T 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.45 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
904 KW 1.50 1.53 1.58 - 1.61 1.65 1.70 - 1.72 1.75 1.81 - 1.81 1.85 1.91 - 1.88 1.93 1.99 - 1.95 2.00 2.06 -
AMPS 5.8 6.0 6.2 - 6.3 6.4 6.6 - 6.8 7.0 7.2 - 7.3 7.4 7.7 - 7.7 7.9 8.1 - 8.2 8.3 8.6 -
HI PR 220 237 240 - 249 268 271 - 283 304 309 - 322 347 352 - 348 374 380 - 413 444 450 -
LO PR 119 123 134 - 123 127 138 - 127 131 143 - 130 135 147 - 133 137 150 - 136 141 153 -
MBh 24.2 25.1 27.5 - 23.6 24.5 26.8 - 23.1 23.9 26.2 - 22.5 23.3 25.5 - 21.4 22.2 24.3 - 19.8 20.5 22.5 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
Delta T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
70 800 KW 1.49 1.52 1.57 - 1.60 1.64 1.69 - 1.70 1.74 1.80 - 1.79 1.83 1.89 - 1.87 1.91 1.97 - 1.93 1.98 2.04 -
AMPS 5.8 5.9 6.1 - 6.2 6.4 6.6 - 6.7 6.9 7.1 - 7.2 7.4 7.6 - 7.6 7.8 8.1 - 8.1 8.3 8.5 -
HI PR 218 234 238 - 246 265 269 - 280 301 306 - 319 343 348 - 345 371 376 - 409 439 446 -
LO PR 118 122 133 - 122 125 137 - 126 130 142 - 129 133 145 - 132 136 148 - 135 139 152 -
MBh 22.3 23.1 25.3 - 21.8 22.6 24.8 - 21.3 22.1 24.2 - 20.8 21.5 23.6 - 19.7 20.4 22.4 - 18.3 18.9 20.8 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.76 0.63 0.44 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
696 KW 1.47 1.51 1.55 - 1.59 1.62 1.67 - 1.69 1.73 1.78 - 1.78 1.82 1.88 - 1.85 1.89 1.96 - 1.92 1.96 2.03 -
AMPS 5.7 5.9 6.0 - 6.2 6.3 6.5 - 6.7 6.8 7.1 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.0 8.2 8.5 -
HI PR 216 232 235 - 244 262 266 - 277 298 303 - 316 340 345 - 341 367 372 - 404 435 441 -
LO PR 117 121 132 - 120 124 136 - 125 128 140 - 128 132 144 - 130 134 147 - 134 138 150 -
MBh 25.3 26.1 28.2 30.3 24.7 25.5 27.6 29.6 24.2 24.9 26.9 28.9 23.6 24.3 26.3 28.2 22.4 23.0 24.9 26.8 20.7 21.4 23.1 24.8
S/T 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.77 0.59 0.38 0.89 0.80 0.60 0.39 0.93 0.83 0.63 0.40 0.93 0.84 0.63 0.41
DeltaT21191611212016112120161121 20 16 11 21 19 16 11 20 18 15 10
904 KW 1.50 1.53 1.58 1.63 1.61 1.65 1.70 1.76 1.72 1.75 1.81 1.87 1.81 1.85 1.91 1.97 1.88 1.93 1.99 2.06 1.95 2.00 2.06 2.13
AMPS 5.8 6.0 6.2 6.4 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.4 7.3 7.4 7.7 7.9 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9
HI PR 220 237 240 245 249 268 271 277 283 304 309 315 322 347 352 359 348 374 380 388 413 444 450 460
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 153 163
MBh 24.6 25.3 27.4 29.4 24.0 24.7 26.8 28.7 23.5 24.1 26.1 28.0 22.9 23.6 25.5 27.4 21.7 22.4 24.2 26.0 20.1 20.7 22.4 24.1
S/T 0.78 0.69 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.89 0.80 0.60 0.39
DeltaT22201711222017122220171222 21 17 12 22 20 17 12 21 19 16 11
75 800 KW 1.49 1.52 1.57 1.62 1.60 1.64 1.69 1.74 1.70 1.74 1.80 1.86 1.79 1.83 1.89 1.96 1.87 1.91 1.97 2.04 1.93 1.98 2.04 2.11
AMPS 5.8 5.9 6.1 6.3 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4 8.1 8.3 8.5 8.9
HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455
LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
MBh 22.7 23.4 25.3 27.2 22.2 22.8 24.7 26.5 21.6 22.3 24.1 25.9 21.1 21.7 23.5 25.3 20.1 20.7 22.4 24.0 18.6 19.1 20.7 22.2
S/T 0.75 0.67 0.51 0.33 0.78 0.69 0.53 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.56 0.36 0.85 0.76 0.58 0.37 0.86 0.77 0.58 0.37
DeltaT22211712232117122321171223 21 17 12 23 21 17 12 21 19 16 11
696 KW 1.47 1.51 1.55 1.60 1.59 1.62 1.67 1.73 1.69 1.73 1.78 1.84 1.78 1.82 1.88 1.94 1.85 1.89 1.96 2.02 1.92 1.96 2.03 2.10
AMPS 5.7 5.9 6.0 6.3 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 341 367 372 380 404 435 441 451
LO PR 117 121 132 140 120 124 136 144 125 128 140 149 128 132 144 153 130 134 147 156 134 138 150 160
*Entering Indoor DryBulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

12
PERFORMANCE DATA DSX160361A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160361A* / CA*F3743*6A* + TXV / MBE1600**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5° - 7°F @ the Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 25.8 26.3 28.1 30.1 25.2 25.7 27.5 29.4 24.6 25.1 26.8 28.7 24.0 24.5 26.2 28.0 22.8 23.3 24.9 26.6 21.1 21.6 23.0 24.6
S/T 0.890.840.680.510.930.870.710.530.950.890.720.541.00 0.92 0.750.561.000.950.780.581.000.960.780.58
DeltaT23222016242320162423201624 23 20162323201621211815
904 KW 1.50 1.53 1.58 1.63 1.61 1.65 1.70 1.76 1.72 1.75 1.81 1.87 1.81 1.85 1.91 1.97 1.88 1.93 1.99 2.06 1.95 2.00 2.06 2.13
AMPS 5.8 6.0 6.2 6.4 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.4 7.3 7.4 7.7 7.9 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9
HI PR 220 237 240 245 249 268 271 277 283 304 309 315 322 347 352 359 348 374 380 388 413 444 450 460
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 153 163
MBh 25.0 25.6 27.3 29.2 24.4 25.0 26.7 28.5 23.9 24.4 26.1 27.9 23.3 23.8 25.4 27.2 22.1 22.6 24.1 25.8 20.5 20.9 22.4 23.9
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
DeltaT24232016252421172524211725 24 21 17 25 24 21 16 23 22 19 15
80 800 KW 1.49 1.52 1.57 1.62 1.60 1.64 1.69 1.74 1.70 1.74 1.80 1.86 1.79 1.83 1.89 1.96 1.87 1.91 1.97 2.04 1.93 1.98 2.04 2.11
AMPS 5.8 5.9 6.1 6.3 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.97.67.88.18.48.18.38.58.9
HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455
LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
MBh 23.1 23.6 25.2 27.0 22.6 23.1 24.6 26.3 22.0 22.5 24.1 25.7 21.5 22.0 23.5 25.1 20.4 20.9 22.3 23.8 18.9 19.3 20.6 22.1
S/T 0.820.770.630.470.850.800.650.490.870.820.670.500.90 0.84 0.690.510.930.880.710.530.940.880.720.54
DeltaT25242117252421172524211726 25 21172524211724232016
696 KW 1.47 1.51 1.55 1.60 1.59 1.62 1.67 1.73 1.69 1.73 1.78 1.84 1.78 1.82 1.88 1.94 1.85 1.89 1.96 2.02 1.92 1.96 2.03 2.10
AMPS 5.7 5.9 6.0 6.3 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 341 367 372 380 404 435 441 451
LO PR 117 121 132 140 120 124 136 144 125 128 140 149 128 132 144 153 130 134 147 156 134 138 150 160
MBh 26.2 26.7 28.0 29.9 25.6 26.1 27.4 29.2 25.0 25.5 26.7 28.5 24.4 24.9 26.1 27.8 23.2 23.6 24.8 26.4 21.5 21.9 22.9 24.5
S/T 0.940.900.820.660.970.940.840.690.990.960.870.701.00 0.99 0.890.731.001.000.930.751.001.000.940.76
DeltaT25252320252524202525242025 25 24212424232022222219
904 KW 1.50 1.53 1.58 1.63 1.61 1.65 1.70 1.76 1.72 1.75 1.81 1.87 1.81 1.85 1.91 1.97 1.88 1.93 1.99 2.06 1.95 2.00 2.06 2.13
AMPS 5.8 6.0 6.2 6.4 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.4 7.3 7.4 7.7 7.9 7.7 7.9 8.1 8.4 8.2 8.3 8.6 8.9
HI PR 220 237 240 245 249 268 271 277 283 304 309 315 322 347 352 359 348 374 380 388 413 444 450 460
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 135 147 156 133 137 150 160 136 141 153 163
MBh 25.5 26.0 27.2 29.0 24.9 25.4 26.6 28.3 24.3 24.8 25.9 27.7 23.7 24.2 25.3 27.0 22.5 22.9 24.0 25.6 20.8 21.3 22.3 23.7
S/T 0.890.860.780.630.930.890.810.650.950.920.830.670.98 0.94 0.850.691.000.980.890.721.000.990.890.72
DeltaT26262421262625212626252127 26 25212626242124242320
85 800 KW 1.49 1.52 1.57 1.62 1.60 1.64 1.69 1.74 1.70 1.74 1.80 1.86 1.79 1.83 1.89 1.96 1.87 1.91 1.97 2.04 1.93 1.98 2.04 2.11
AMPS 5.8 5.9 6.1 6.3 6.2 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.6 7.8 8.1 8.4 8.1 8.3 8.5 8.9
HI PR 218 234 238 243 246 265 269 275 280 301 306 312 319 343 348 356 345 371 376 384 409 439 446 455
LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
MBh 23.5 24.0 25.1 26.8 23.0 23.4 24.5 26.2 22.4 22.8 23.9 25.5 21.9 22.3 23.3 24.9 20.8 21.2 22.2 23.7 19.2 19.6 20.5 21.9
S/T 0.860.830.750.610.890.860.780.630.910.880.800.650.94 0.91 0.820.670.980.950.850.690.990.950.860.70
Delta T 26.74 26 25 22 27 27 25 22 27 27 25 22 27 27 25 22 27 26 25 22 25 25 23 20
696 KW 1.47 1.51 1.55 1.60 1.59 1.62 1.67 1.73 1.69 1.73 1.78 1.84 1.78 1.82 1.88 1.94 1.85 1.89 1.96 2.02 1.92 1.96 2.03 2.10
AMPS 5.7 5.9 6.0 6.3 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 216 232 235 241 244 262 266 272 277 298 303 309 316 340 345 352 341 367 372 380 404 435 441 451
LO PR 117 121 132 140 120 124 136 144 125 128 140 149 128 132 144 153 130 134 147 156 134 138 150 160
*Entering Indoor DryBulb Temperature NOTE: Shaded area is AHRI Rating Conditions

13
PERFORMANCE DATA DSX160361B*-LOW STAGE
LOW STAGE EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160361B* / CA*F3743*6**+TXV+MBE1600**-1* Design Subcooling 5 - 7 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*
A
irflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 25.3 26.2 28.7 - 24.7 25.6 28.0 - 24.1 25.0 27.4 - 23.5 24.4 26.7 - 22.3 23.2 25.4 - 20.7 21.5 23.5 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
878 KW 1.47 1.50 1.55 - 1.58 1.62 1.67 - 1.69 1.73 1.79 - 1.78 1.82 1.88 - 1.86 1.90 1.97 - 1.93 1.97 2.04 -
AMPS 5.8 5.9 6.1 - 6.3 6.4 6.6 - 6.8 6.9 7.1 - 7.2 7.4 7.6 - 7.6 7.8 8.1 - 8.1 8.3 8.5 -
HI PR 206 222 234 - 231 249 263 - 263 283 299 - 300 322 340 - 337 363 383 - 372 401 423 -
LO PR 108 115 125 - 114 121 132 - 118 126 138 - 124 132 145 - 130 139 151 - 135 143 157 -
MBh 24.5 25.4 27.9 - 24.0 24.8 27.2 - 23.4 24.3 26.6 - 22.8 23.7 25.9 - 21.7 22.5 24.6 - 20.1 20.8 22.8 -
S/T 0.70 0.58 0.40 - 0.72 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.66 0.46 - 0.80 0.67 0.46 -
Delta T 20 18 13 - 20 18 13 - 21 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -
70 780 KW 1.45 1.49 1.54 - 1.57 1.61 1.66 - 1.67 1.71 1.77 - 1.77 1.81 1.87 - 1.84 1.88 1.95 - 1.91 1.95 2.02 -
AMPS 5.8 5.9 6.1 - 6.2 6.3 6.5 - 6.7 6.9 7.1 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.0 8.2 8.5 -
HI PR 204 220 232 - 229 246 260 - 260 280 296 - 297 319 337 - 334 359 379 - 369 397 419 -
LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 134 142 155 -
MBh 22.7 23.5 25.7 - 22.1 22.9 25.1 - 21.6 22.4 24.5 - 21.1 21.8 23.9 - 20.0 20.8 22.7 - 18.5 19.2 21.1 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -
Delta T 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -
683 KW 1.42 1.45 1.50 - 1.53 1.57 1.62 - 1.63 1.67 1.72 - 1.72 1.76 1.82 - 1.79 1.84 1.90 - 1.86 1.90 1.97 -
AMPS 5.6 5.7 5.9 - 6.0 6.2 6.4 - 6.5 6.7 6.9 - 7.0 7.1 7.3 - 7.4 7.6 7.8 - 7.8 8.0 8.2 -
HI PR 198 213 225 - 222 239 252 - 253 272 287 - 288 310 327 - 324 348 368 - 358 385 406 -
LO PR 104 110 120 - 109 116 127 - 114 121 132 - 119 127 139 - 125 133 145 - 130 138 150 -
MBh 25.7 26.5 28.7 30.8 25.1 25.9 28.0 30.0 24.5 25.2 27.3 29.3 23.9 24.6 26.7 28.6 22.7 23.4 25.3 27.2 21.0 21.7 23.5 25.2
S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42
DeltaT22211712232117122321171223 21 17 12 23 21 17 12 21 19 16 11
878 KW 1.48 1.51 1.56 1.61 1.60 1.63 1.69 1.75 1.70 1.74 1.80 1.86 1.80 1.84 1.90 1.97 1.87 1.92 1.98 2.05 1.94 1.99 2.06 2.13
AMPS 5.9 6.0 6.2 6.4 6.3 6.5 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.4 7.7 8.0 7.7 7.9 8.2 8.5 8.2 8.4 8.6 8.9
HI PR 208 224 237 247 234 251 266 277 266 286 302 315 303 326 344 359 341 366 387 404 376 405 428 446
LO PR 109 116 127 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 169
MBh 25.0 25.7 27.8 29.9 24.4 25.1 27.2 29.2 23.8 24.5 26.5 28.5 23.2 23.9 25.9 27.8 22.1 22.7 24.6 26.4 20.4 21.0 22.8 24.4
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.82 0.62 0.40
DeltaT23221812242218122422181224 22 18 12 24 22 18 12 22 20 17 11
75 780 KW 1.47 1.50 1.55 1.60 1.58 1.62 1.67 1.73 1.69 1.73 1.79 1.85 1.78 1.82 1.88 1.95 1.86 1.90 1.97 2.04 1.93 1.97 2.04 2.11
AMPS 5.8 5.9 6.1 6.3 6.3 6.4 6.6 6.8 6.8 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.7 7.8 8.1 8.4 8.1 8.3 8.5 8.9
HI PR 206 222 234 244 231 249 263 274 263 283 299 312 300 323 341 355 337 363 383 400 373 401 423 442
LO PR 108 115 125 133 114 121 132 141 118 126 138 147 124 132 145 154 130 139 151 161 135 144 157 167
MBh 23.0 23.7 25.7 27.6 22.5 23.2 25.1 26.9 22.0 22.6 24.5 26.3 21.4 22.1 23.9 25.6 20.4 21.0 22.7 24.4 18.9 19.4 21.0 22.6
S/T 0.77 0.69 0.52 0.33 0.79 0.71 0.54 0.35 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38
DeltaT24221812242218132422181324 22 18 13 24 22 18 12 22 21 17 12
683 KW 1.43 1.46 1.51 1.56 1.54 1.58 1.63 1.69 1.65 1.68 1.74 1.80 1.73 1.77 1.83 1.90 1.81 1.85 1.92 1.98 1.88 1.92 1.99 2.05
AMPS 5.7 5.8 6.0 6.2 6.1 6.2 6.4 6.7 6.6 6.7 7.0 7.2 7.0 7.2 7.4 7.7 7.4 7.6 7.9 8.2 7.9 8.1 8.3 8.6
HI PR 200 215 227 237 224 242 255 266 255 275 290 303 291 313 330 345 327 352 372 388 361 389 411 428
LO PR 105 111 122 129 111 118 128 137 115 122 133 142 121 128 140 149 127 135 147 156 131 139 152 162
*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

14
PERFORMANCE DATA DSX160361B*-LOW STAGE
LOW STAGE EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160361B* / CA*F3743*6**+TXV+MBE1600**-1* Design Subcooling 5 - 7 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 26.2 26.7 28.6 30.5 25.6 26.1 27.9 29.8 25.0 25.5 27.2 29.1 24.3 24.9 26.6 28.4 23.1 23.6 25.2 27.0 21.4 21.9 23.4 25.0
S/T 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 1.00 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.80 0.60
DeltaT25242117252421172624211726 25 21 172425211722232016
878 KW 1.49 1.52 1.57 1.63 1.61 1.65 1.70 1.76 1.72 1.76 1.82 1.88 1.81 1.85 1.92 1.98 1.89 1.93 2.00 2.07 1.96 2.01 2.07 2.15
AMPS 5.9 6.0 6.2 6.4 6.4 6.5 6.7 7.0 6.9 7.0 7.3 7.5 7.3 7.5 7.7 8.0 7.8 8.0 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 210 226 239 249 236 254 268 280 268 289 305 318 306 329 347 362 344 370 391 408 380 409 432 450
LO PR 110 117 128 136 116 124 135 144 121 129 140 150 127 135 147 157 133 142 155 165 138 146 160 170
MBh 25.4 26.0 27.7 29.6 24.8 25.4 27.1 29.0 24.2 24.8 26.4 28.3 23.6 24.1 25.8 27.6 22.5 22.9 24.5 26.2 20.8 21.3 22.7 24.3
S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57
DeltaT26252217262522182625221827 26 22 18 26 25 22 17 25 24 20 16
80 780 KW 1.48 1.51 1.56 1.61 1.60 1.63 1.69 1.75 1.70 1.74 1.80 1.86 1.80 1.84 1.90 1.97 1.87 1.92 1.98 2.05 1.94 1.99 2.06 2.13
AMPS 5.9 6.0 6.2 6.4 6.3 6.5 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.4 7.7 8.0 7.7 7.9 8.2 8.5 8.2 8.4 8.6 8.9
HI PR 208 224 237 247 234 251 266 277 266 286 302 315 303 326 344 359 341 366 387 404 376 405 428 446
LO PR 109 116 127 135 115 123 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 169
MBh 23.4 24.0 25.6 27.4 22.9 23.4 25.0 26.7 22.4 22.8 24.4 26.1 21.8 22.3 23.8 25.5 20.7 21.2 22.6 24.2 19.2 19.6 21.0 22.4
S/T 0.84 0.79 0.64 0.48 0.87 0.82 0.67 0.50 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.53 0.96 0.90 0.73 0.55 0.97 0.91 0.74 0.55
DeltaT27252218272622182726221827 26 23 182726221825242117
683 KW 1.44 1.47 1.52 1.57 1.56 1.59 1.65 1.70 1.66 1.70 1.75 1.81 1.75 1.79 1.85 1.91 1.83 1.87 1.93 2.00 1.89 1.94 2.00 2.07
AMPS 5.7 5.8 6.0 6.2 6.1 6.3 6.5 6.7 6.6 6.8 7.0 7.3 7.1 7.2 7.5 7.7 7.5 7.7 7.9 8.2 7.9 8.1 8.4 8.7
HI PR 202 217 230 239 227 244 258 269 258 277 293 306 294 316 334 348 330 355 375 392 365 393 415 433
LO PR 106 112 123 131 112 119 130 138 116 123 135 144 122 130 142 151 128 136 148 158 132 141 154 163
MBh 26.6 27.1 28.4 30.3 26.0 26.5 27.8 29.6 25.4 25.9 27.1 28.9 24.8 25.2 26.4 28.2 23.5 24.0 25.1 26.8 21.8 22.2 23.3 24.8
S/T 0.96 0.92 0.83 0.68 0.99 0.96 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78
DeltaT27262522272725222727252226 26 25 222525252223232320
878 KW 1.50 1.54 1.59 1.64 1.63 1.66 1.72 1.78 1.73 1.77 1.83 1.90 1.83 1.87 1.93 2.00 1.91 1.95 2.02 2.09 1.98 2.02 2.09 2.17
AMPS 6.0 6.1 6.3 6.5 6.4 6.6 6.8 7.0 6.9 7.1 7.3 7.6 7.4 7.6 7.8 8.1 7.9 8.0 8.3 8.6 8.3 8.5 8.8 9.1
HI PR 212 229 241 252 238 257 271 283 271 292 308 321 309 332 351 366 347 374 395 412 384 413 436 455
LO PR 111 118 129 138 117 125 136 145 122 130 142 151 128 136 149 159 134 143 156 166 139 148 161 172
MBh 25.8 26.3 27.6 29.4 25.2 25.7 27.0 28.8 24.6 25.1 26.3 28.1 24.0 24.5 25.7 27.4 22.8 23.3 24.4 26.0 21.2 21.6 22.6 24.1
S/T 0.91 0.88 0.80 0.65 0.95 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.91 0.74
DeltaT28272622282826232828262328 28 26 232727262325252421
85 780 KW 1.49 1.52 1.57 1.63 1.61 1.65 1.70 1.76 1.72 1.76 1.82 1.88 1.81 1.85 1.92 1.98 1.89 1.93 2.00 2.07 1.96 2.01 2.07 2.15
AMPS 5.9 6.0 6.2 6.4 6.4 6.5 6.7 7.0 6.9 7.0 7.3 7.5 7.3 7.5 7.7 8.0 7.8 8.0 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 210 226 239 249 236 254 268 280 268 289 305 318 306 329 347 362 344 370 391 408 380 409 432 450
LO PR 110 117 128 136 116 124 135 144 121 129 140 150 127 135 147 157 133 142 155 165 138 146 160 170
MBh 23.9 24.3 25.5 27.2 23.3 23.8 24.9 26.5 22.7 23.2 24.3 25.9 22.2 22.6 23.7 25.3 21.1 21.5 22.5 24.0 19.5 19.9 20.9 22.2
S/T 0.88 0.85 0.77 0.62 0.91 0.88 0.80 0.65 0.94 0.90 0.82 0.66 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 0.98 0.88 0.71
Delta T 28.32 28 26 23 29 28 27 23 29 28 27 23 29 28 27 23 28 28 26 23 26 26 25 21
683 KW 1.45 1.49 1.54 1.59 1.57 1.61 1.66 1.72 1.67 1.71 1.77 1.83 1.76 1.81 1.87 1.93 1.84 1.88 1.95 2.02 1.91 1.95 2.02 2.09
AMPS 5.8 5.9 6.1 6.3 6.2 6.3 6.5 6.8 6.7 6.9 7.1 7.3 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 204 220 232 242 229 246 260 271 260 280 296 309 297 319 337 352 334 359 379 395 369 397 419 437
LO PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165
*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions

15
PERFORMANCE DATA DSX160481A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160481A* / CA*F4961*6A* + TXV / MBE2000**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5° - 7°F @ the Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 33.9 35.2 38.5 - 33.1 34.3 37.6 - 32.3 33.5 36.7 - 31.5 32.7 35.8 - 30.0 31.1 34.0 - 27.8 28.8 31.5 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
1238 KW 2.04 2.09 2.16 - 2.21 2.26 2.33 - 2.35 2.41 2.49 - 2.48 2.54 2.62 - 2.59 2.65 2.74 - 2.68 2.74 2.84 -
AMPS 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.5 9.7 10.0 - 10.1 10.4 10.7 - 10.8 11.0 11.4 - 11.4 11.7 12.1 -
HI PR 227 244 248 - 257 276 280 - 292 314 318 - 332 357 362 - 374 402 408 - 419 450 457 -
LO PR 122 125 137 - 125 129 141 - 129 134 146 - 133 137 150 - 136 140 153 - 139 143 156 -
MBh 32.9 34.1 37.4 - 32.2 33.3 36.5 - 31.4 32.5 35.7 - 30.6 31.7 34.8 - 29.1 30.2 33.0 - 27.0 27.9 30.6 -
S/T 0.70 0.58 0.40 - 0.72 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.66 0.46 - 0.80 0.67 0.46 -
Delta T 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
70 1100 KW 2.03 2.07 2.14 - 2.19 2.24 2.31 - 2.33 2.38 2.47 - 2.46 2.51 2.60 - 2.57 2.62 2.71 - 2.66 2.72 2.81 -
AMPS 8.1 8.2 8.5 - 8.7 8.9 9.2 - 9.4 9.6 10.0 - 10.1 10.3 10.6 - 10.7 10.9 11.3 - 11.3 11.6 12.0 -
HI PR 225 242 245 - 254 273 277 - 289 311 315 - 329 354 359 - 370 398 404 - 415 446 452 -
LO PR 120 124 136 - 124 128 140 - 128 132 144 - 132 136 148 - 134 138 151 - 138 142 155 -
MBh 30.4 31.5 34.5 - 29.7 30.8 33.7 - 29.0 30.0 32.9 - 28.3 29.3 32.1 - 26.9 27.8 30.5 - 24.9 25.8 28.3 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -
Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
963 KW 2.01 2.05 2.12 - 2.17 2.22 2.29 - 2.31 2.36 2.44 - 2.44 2.49 2.58 - 2.54 2.60 2.69 - 2.64 2.70 2.79 -
AMPS 8.0 8.2 8.4 - 8.6 8.8 9.1 - 9.3 9.6 9.9 - 10.0 10.2 10.5 - 10.6 10.8 11.2 - 11.2 11.5 11.9 -
HI PR 223 239 243 - 252 270 274 - 286 308 312 - 326 350 355 - 367 394 400 - 411 441 448 -
LO PR 119 123 134 - 123 127 138 - 127 131 143 - 130 134 147 - 133 137 150 - 136 140 153 -
MBh 34.5 35.5 38.4 41.3 33.7 34.7 37.5 40.3 32.9 33.9 36.6 39.3 32.1 33.0 35.8 38.4 30.5 31.4 34.0 36.5 28.2 29.1 31.5 33.8
S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42
DeltaT21201611222016112220161122 20 16 11 21 20 16 11 20 18 15 10
1238 KW 2.04 2.09 2.16 2.23 2.21 2.26 2.33 2.41 2.35 2.41 2.49 2.57 2.48 2.54 2.62 2.71 2.59 2.65 2.74 2.83 2.68 2.74 2.84 2.94
AMPS 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.8 11.0 11.4 11.8 11.4 11.7 12.1 12.5
HI PR 227 244 248 253 257 276 280 286 292 314 318 325 332 357 362 370 374 402 408 417 419 450 457 467
LO PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
MBh 33.5 34.5 37.3 40.1 32.7 33.7 36.4 39.1 31.9 32.9 35.6 38.2 31.1 32.1 34.7 37.3 29.6 30.5 33.0 35.4 27.4 28.2 30.5 32.8
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.82 0.62 0.40
DeltaT22201712232117122321171223 21 17 12 22 21 17 12 21 19 16 11
75 1100 KW 2.03 2.07 2.14 2.21 2.19 2.24 2.31 2.39 2.33 2.38 2.47 2.55 2.46 2.51 2.60 2.69 2.57 2.62 2.71 2.81 2.66 2.72 2.81 2.91
AMPS 8.1 8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 10.0 10.3 10.1 10.3 10.6 11.0 10.7 10.9 11.3 11.7 11.3 11.6 12.0 12.4
HI PR 225 242 245 251 254 273 277 283 289 311 315 322 329 354 359 367 370 398 404 413 415 446 452 462
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
MBh 30.9 31.8 34.4 37.0 30.2 31.1 33.6 36.1 29.5 30.3 32.8 35.2 28.8 29.6 32.0 34.4 27.3 28.1 30.4 32.7 25.3 26.0 28.2 30.3
S/T 0.77 0.69 0.52 0.33 0.79 0.71 0.54 0.35 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38
DeltaT23211712232117122321171223 21 17 12 23 21 17 12 21 20 16 11
963 KW 2.01 2.05 2.12 2.19 2.17 2.22 2.29 2.37 2.31 2.36 2.44 2.53 2.44 2.49 2.58 2.67 2.54 2.60 2.69 2.78 2.64 2.70 2.79 2.89
AMPS 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.8 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 223 239 243 248 252 270 274 280 286 308 312 319 326 350 355 363 367 394 400 409 411 441 448 458
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
*Entering Indoor DryBulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

16
PERFORMANCE DATA DSX160481A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160481A* / CA*F4961*6A* + TXV / MBE2000**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5° - 7°F @ the Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 35.1 35.9 38.3 41.0 34.3 35.0 37.4 40.0 33.5 34.2 36.5 39.1 32.7 33.4 35.6 38.1 31.0 31.7 33.9 36.2 28.7 29.4 31.4 33.5
S/T 0.910.860.700.520.950.890.720.541.000.910.740.551.00 0.94 0.770.571.001.000.790.591.001.000.800.60
DeltaT24232016242320162523201624 23 20162324201621221915
1238 KW 2.042.092.162.232.212.262.332.412.352.412.492.572.48 2.54 2.622.712.592.652.742.832.682.742.842.94
AMPS 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.8 11.0 11.4 11.8 11.4 11.7 12.1 12.5
HI PR 227 244 248 253 257 276 280 286 292 314 318 325 332 357 362 370 374 402 408 417 419 450 457 467
LO PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
MBh 34.1 34.8 37.2 39.8 33.3 34.0 36.3 38.8 32.5 33.2 35.5 37.9 31.7 32.4 34.6 37.0 30.1 30.8 32.9 35.1 27.9 28.5 30.5 32.6
S/T 0.87 0.82 0.67 0.50 0.90 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57
DeltaT25242117252421172524211725 24 21 17 25 24 21 17 23 22 19 16
80 1100 KW 2.03 2.07 2.14 2.21 2.19 2.24 2.31 2.39 2.33 2.38 2.47 2.55 2.46 2.51 2.60 2.69 2.57 2.62 2.71 2.81 2.66 2.72 2.81 2.91
AMPS 8.1 8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 10.0 10.3 10.1 10.3 10.6 11.0 10.7 10.9 11.3 11.7 11.3 11.6 12.0 12.4
HI PR 225 242 245 251 254 273 277 283 289 311 315 322 329 354 359 367 370 398 404 413 415 446 452 462
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
MBh 31.5 32.1 34.3 36.7 30.7 31.4 33.5 35.9 30.0 30.6 32.7 35.0 29.3 29.9 31.9 34.1 27.8 28.4 30.3 32.4 25.8 26.3 28.1 30.1
S/T 0.840.790.640.480.870.820.660.500.890.840.680.510.92 0.86 0.700.530.960.900.730.550.960.900.740.55
DeltaT25242117262421172625211726 25 21172524211724232016
963 KW 2.01 2.05 2.12 2.19 2.17 2.22 2.29 2.37 2.31 2.36 2.44 2.53 2.44 2.49 2.58 2.67 2.54 2.60 2.69 2.78 2.64 2.70 2.79 2.89
AMPS 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.8 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 223 239 243 248 252 270 274 280 286 308 312 319 326 350 355 363 367 394 400 409 411 441 448 458
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
MBh 35.7 36.4 38.1 40.7 34.9 35.6 37.2 39.7 34.1 34.7 36.4 38.8 33.2 33.9 35.5 37.8 31.6 32.2 33.7 35.9 29.2 29.8 31.2 33.3
S/T 0.960.920.830.680.990.960.860.701.000.980.890.721.00 1.00 0.920.741.001.000.950.771.001.000.960.78
DeltaT25252420262524212525242125 25 24212324242122222219
1238 KW 2.042.092.162.232.212.262.332.412.352.412.492.572.48 2.54 2.622.712.592.652.742.832.682.742.842.94
AMPS 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.8 11.0 11.4 11.8 11.4 11.7 12.1 12.5
HI PR 227 244 248 253 257 276 280 286 292 314 318 325 332 357 362 370 374 402 408 417 419 450 457 467
LO PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
MBh 34.7 35.3 37.0 39.5 33.9 34.5 36.2 38.6 33.1 33.7 35.3 37.7 32.3 32.9 34.4 36.7 30.6 31.2 32.7 34.9 28.4 28.9 30.3 32.3
S/T 0.910.880.800.650.950.910.820.670.970.940.850.691.00 0.97 0.870.711.001.000.910.731.001.000.910.74
DeltaT26262521272625222726252227 27 25222626252124242320
85 1100 KW 2.032.072.142.212.192.242.312.392.332.382.472.552.46 2.51 2.602.692.572.622.712.812.662.722.812.91
AMPS 8.1 8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 10.0 10.3 10.1 10.3 10.6 11.0 10.7 10.9 11.3 11.7 11.3 11.6 12.0 12.4
HI PR 225 242 245 251 254 273 277 283 289 311 315 322 329 354 359 367 370 398 404 413 415 446 452 462
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
MBh 32.0 32.6 34.2 36.5 31.3 31.9 33.4 35.6 30.5 31.1 32.6 34.8 29.8 30.3 31.8 33.9 28.3 28.8 30.2 32.2 26.2 26.7 28.0 29.8
S/T 0.880.850.770.620.910.880.800.650.940.900.820.660.97 0.93 0.840.681.000.970.870.711.000.980.880.71
Delta T 26.93 26 25 22 27 27 25 22 27 27 25 22 27 27 26 22 27 27 25 22 25 25 24 20
963 KW 2.01 2.05 2.12 2.19 2.17 2.22 2.29 2.37 2.31 2.36 2.44 2.53 2.44 2.49 2.58 2.67 2.54 2.60 2.69 2.78 2.64 2.70 2.79 2.89
AMPS 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.8 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 223 239 243 248 252 270 274 280 286 308 312 319 326 350 355 363 367 394 400 409 411 441 448 458
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
*Entering Indoor DryBulb Temperature NOTE: Shaded area is AHRI Rating Conditions

17
PERFORMANCE DATA DSX160601A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160601A* / CA*F4961*6A* + TXV / MBE2000**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5° - 7°F @ the Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 41.8 43.3 47.5 - 40.8 42.3 46.3 - 39.8 41.3 45.2 - 38.9 40.3 44.1 - 36.9 38.3 41.9 - 34.2 35.5 38.8 -
S/T 0.75 0.62 0.43 - 0.78 0.65 0.45 - 0.80 0.66 0.46 - 0.82 0.69 0.47 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
1575 KW 2.61 2.67 2.76 - 2.83 2.89 2.99 - 3.02 3.09 3.19 - 3.19 3.26 3.37 - 3.33 3.41 3.52 - 3.45 3.53 3.66 -
AMPS 10.1 10.3 10.7 - 10.9 11.2 11.6 - 11.9 12.2 12.6 - 12.7 13.0 13.5 - 14.9 15.2 15.8 - 15.7 16.1 16.7 -
HI PR 231 248 252 - 253 272 276 - 297 319 323 - 338 363 368 - 380 409 415 - 439 472 479 -
LO PR 120 124 136 - 124 128 140 - 128 132 144 - 132 136 148 - 134 139 151 - 138 142 155 -
MBh 40.6 42.0 46.1 - 39.6 41.1 45.0 - 38.7 40.1 43.9 - 37.7 39.1 42.9 - 35.9 37.2 40.7 - 33.2 34.4 37.7 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
Delta T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
70 1400 KW 2.59 2.65 2.74 - 2.80 2.87 2.97 - 2.99 3.06 3.17 - 3.16 3.23 3.34 - 3.30 3.38 3.49 - 3.42 3.50 3.62 -
AMPS 10.0 10.2 10.6 - 10.8 11.1 11.5 - 11.8 12.1 12.5 - 12.6 12.9 13.4 - 14.7 15.1 15.6 - 15.6 15.9 16.5 -
HI PR 228 246 249 - 251 270 274 - 294 316 320 - 335 360 365 - 376 405 410 - 435 468 474 -
LO PR 119 123 134 - 123 127 138 - 127 131 143 - 130 134 147 - 133 137 150 - 136 141 153 -
MBh 37.4 38.8 42.5 - 36.6 37.9 41.5 - 35.7 37.0 40.5 - 34.8 36.1 39.6 - 33.1 34.3 37.6 - 30.7 31.8 34.8 -
S/T 0.69 0.57 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
1225 KW 2.57 2.63 2.72 - 2.78 2.84 2.94 - 2.97 3.03 3.14 - 3.13 3.20 3.31 - 3.27 3.35 3.46 - 3.39 3.47 3.59 -
AMPS 9.9 10.1 10.5 - 10.7 11.0 11.4 - 11.7 12.0 12.4 - 12.5 12.8 13.2 - 14.6 15.0 15.5 - 15.4 15.8 16.3 -
HI PR 226 243 247 - 248 267 271 - 291 313 317 - 331 356 361 - 373 401 406 - 431 463 469 -
LO PR 118 122 133 - 122 125 137 - 126 130 142 - 129 133 145 - 132 136 148 - 135 139 152 -
MBh 42.5 43.8 47.4 50.8 41.5 42.7 46.3 49.6 40.5 41.7 45.2 48.5 39.5 40.7 44.1 47.3 37.6 38.7 41.9 44.9 34.8 35.8 38.8 41.6
S/T 0.850.760.580.370.880.790.600.380.900.810.610.390.93 0.83 0.63 0.41 0.97 0.87 0.66 0.42 0.98 0.87 0.66 0.43
DeltaT21191611212016112120161122 20 16 11 21 20 16 11 20 18 15 10
1575 KW 2.61 2.67 2.76 2.86 2.83 2.89 2.99 3.10 3.02 3.09 3.19 3.31 3.19 3.26 3.37 3.49 3.33 3.41 3.52 3.65 3.45 3.53 3.66 3.79
AMPS 10.1 10.3 10.7 11.1 10.9 11.2 11.6 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 14.9 15.2 15.8 16.4 15.7 16.1 16.7 17.3
HI PR 231 248 252 257 253 272 276 282 297 319 323 331 338 363 368 377 380 409 415 424 439 472 479 490
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 139 151 161 138 142 155 165
MBh 41.3 42.5 46.0 49.3 40.3 41.5 44.9 48.2 39.3 40.5 43.8 47.1 38.4 39.5 42.8 45.9 36.5 37.5 40.6 43.6 33.8 34.8 37.6 40.4
S/T 0.810.730.550.350.840.750.570.370.860.770.580.380.89 0.80 0.60 0.39 0.92 0.83 0.63 0.40 0.93 0.83 0.63 0.41
DeltaT22201711222017122221171222 21 17 12 22 20 17 12 21 19 16 11
75 1400 KW 2.59 2.65 2.74 2.83 2.80 2.87 2.97 3.07 2.99 3.06 3.17 3.28 3.16 3.23 3.34 3.46 3.30 3.38 3.49 3.62 3.42 3.50 3.62 3.75
AMPS 10.0 10.2 10.6 11.0 10.8 11.1 11.5 11.9 11.8 12.1 12.5 13.0 12.6 12.9 13.4 13.9 14.7 15.1 15.6 16.2 15.6 15.9 16.5 17.1
HI PR 228 246 249 255 251 270 274 280 294 316 320 327 335 360 365 373 376 405 410 419 435 468 474 485
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 141 153 163
MBh 38.1 39.2 42.4 45.5 37.2 38.3 41.5 44.5 36.3 37.4 40.5 43.4 35.4 36.5 39.5 42.4 33.7 34.6 37.5 40.3 31.2 32.1 34.7 37.3
S/T 0.780.700.530.340.810.720.550.350.830.740.560.360.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
DeltaT22211712232117122321171223 21 17 12 22 21 17 12 21 19 16 11
1225 KW 2.57 2.63 2.72 2.81 2.78 2.84 2.94 3.04 2.97 3.03 3.14 3.25 3.13 3.20 3.31 3.43 3.27 3.35 3.46 3.58 3.39 3.47 3.59 3.72
AMPS 9.9 10.1 10.5 10.9 10.7 11.0 11.4 11.8 11.7 12.0 12.4 12.8 12.5 12.8 13.2 13.7 14.6 15.0 15.5 16.1 15.4 15.8 16.3 17.0
HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 373 401 406 415 431 463 469 480
LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
*Entering IndoorDry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

18
PERFORMANCE DATA DSX160601A*-LOW STAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160601A* / CA*F4961*6A* + TXV / MBE2000**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5° - 7°F @ the Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 43.3 44.2 47.2 50.5 42.2 43.2 46.1 49.3 41.2 42.1 45.0 48.1 40.2 41.1 43.9 47.0 38.2 39.1 41.7 44.6 35.4 36.2 38.7 41.3
S/T 0.930.870.710.530.970.910.740.551.000.930.760.571.00 0.96 0.780.581.001.000.810.611.001.000.820.61
DeltaT24232016242320162423201623 23 20162223201621211815
1575 KW 2.612.672.762.862.832.892.993.103.023.093.193.313.19 3.26 3.373.493.333.413.523.653.453.533.663.79
AMPS 10.1 10.3 10.7 11.1 10.9 11.2 11.6 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 14.9 15.2 15.8 16.4 15.7 16.1 16.7 17.3
HI PR 231 248 252 257 253 272 276 282 297 319 323 331 338 363 368 377 380 409 415 424 439 472 479 490
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 139 151 161 138 142 155 165
MBh 42.0 42.9 45.8 49.0 41.0 41.9 44.8 47.9 40.0 40.9 43.7 46.7 39.1 39.9 42.6 45.6 37.1 37.9 40.5 43.3 34.4 35.1 37.5 40.1
S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.53 0.95 0.89 0.72 0.54 0.98 0.92 0.74 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58
DeltaT25242016252421172524211725 24 21 17 24 24 21 16 23 22 19 15
80 1400 KW 2.59 2.65 2.74 2.83 2.80 2.87 2.97 3.07 2.99 3.06 3.17 3.28 3.16 3.23 3.34 3.46 3.30 3.38 3.49 3.62 3.42 3.50 3.62 3.75
AMPS 10.0 10.2 10.6 11.0 10.8 11.1 11.5 11.9 11.8 12.1 12.5 13.0 12.6 12.9 13.4 13.9 14.7 15.1 15.6 16.2 15.6 15.9 16.5 17.1
HI PR 228 246 249 255 251 270 274 280 294 316 320 327 335 360 365 373 376 405 410 419 435 468 474 485
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 141 153 163
MBh 38.8 39.6 42.3 45.2 37.9 38.7 41.3 44.2 37.0 37.8 40.3 43.1 36.1 36.8 39.4 42.1 34.3 35.0 37.4 40.0 31.7 32.4 34.6 37.0
S/T 0.860.800.650.490.890.830.680.510.910.850.700.520.94 0.88 0.720.540.980.920.750.560.980.920.750.56
DeltaT25242117252421172524211725 24 21172524211723222016
1225 KW 2.572.632.722.812.782.842.943.042.973.033.143.253.13 3.20 3.313.433.273.353.463.583.393.473.593.72
AMPS 9.9 10.1 10.5 10.9 10.7 11.0 11.4 11.8 11.7 12.0 12.4 12.8 12.5 12.8 13.2 13.7 14.6 15.0 15.5 16.1 15.4 15.8 16.3 17.0
HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 373 401 406 415 431 463 469 480
LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
MBh 44.0 44.9 47.0 50.1 43.0 43.8 45.9 49.0 42.0 42.8 44.8 47.8 40.9 41.7 43.7 46.6 38.9 39.6 41.5 44.3 36.0 36.7 38.5 41.0
S/T 0.980.940.850.691.000.980.880.721.001.000.900.731.00 1.00 0.930.761.001.000.970.791.001.000.980.79
DeltaT25252320252524202425242024 24 24212323232021212219
1575 KW 2.612.672.762.862.832.892.993.103.023.093.193.313.19 3.26 3.373.493.333.413.523.653.453.533.663.79
AMPS 10.1 10.3 10.7 11.1 10.9 11.2 11.6 12.0 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 14.9 15.2 15.8 16.4 15.7 16.1 16.7 17.3
HI PR 231 248 252 257 253 272 276 282 297 319 323 331 338 363 368 377 380 409 415 424 439 472 479 490
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 139 151 161 138 142 155 165
MBh 42.7 43.6 45.6 48.7 41.7 42.5 44.6 47.5 40.7 41.5 43.5 46.4 39.7 40.5 42.4 45.3 37.8 38.5 40.3 43.0 35.0 35.7 37.3 39.8
S/T 0.930.900.810.660.970.930.840.680.990.960.860.701.00 0.99 0.890.721.001.000.920.751.001.000.930.76
DeltaT26262421262625212726252126 26 25212525242123232320
85 1400 KW 2.592.652.742.832.802.872.973.072.993.063.173.283.16 3.23 3.343.463.303.383.493.623.423.503.623.75
AMPS 10.0 10.2 10.6 11.0 10.8 11.1 11.5 11.9 11.8 12.1 12.5 13.0 12.6 12.9 13.4 13.9 14.7 15.1 15.6 16.2 15.6 15.9 16.5 17.1
HI PR 228 246 249 255 251 270 274 280 294 316 320 327 335 360 365 373 376 405 410 419 435 468 474 485
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 141 153 163
MBh 39.4 40.2 42.1 44.9 38.5 39.3 41.1 43.9 37.6 38.3 40.1 42.8 36.7 37.4 39.2 41.8 34.8 35.5 37.2 39.7 32.3 32.9 34.5 36.8
S/T 0.900.870.780.640.930.900.810.660.960.920.830.680.99 0.95 0.860.701.000.990.890.721.001.000.900.73
Delta T 26.61 26 25 21 27 26 25 22 27 27 25 22 27 27 25 22 26 26 25 22 24 25 23 20
1225 KW 2.572.632.722.812.782.842.943.042.973.033.143.253.13 3.20 3.313.433.273.353.463.583.393.473.593.72
AMPS 9.9 10.1 10.5 10.9 10.7 11.0 11.4 11.8 11.7 12.0 12.4 12.8 12.5 12.8 13.2 13.7 14.6 15.0 15.5 16.1 15.4 15.8 16.3 17.0
HI PR 226 243 247 252 248 267 271 277 291 313 317 324 331 356 361 369 373 401 406 415 431 463 469 480
LO PR 118 122 133 142 122 125 137 146 126 130 142 151 129 133 145 155 132 136 148 158 135 139 152 162
*Entering Indoor DryBulb Temperature NOTE: Shaded area is AHRI Rating Conditions

19
COOLINGPERFORMANCEDATA DSX160241A*-HIGHSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160241A* / CA*F3636C6** + TXV / MBE1200**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5°F @ Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -
S/T 0.76 0.63 0.44 - 0.78 0.66 0.45 - 0.80 0.67 0.47 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
900 KW 1.50 1.53 1.58 - 1.62 1.65 1.71 - 1.72 1.76 1.82 - 1.81 1.86 1.92 - 1.89 1.94 2.00 - 1.96 2.01 2.07 -
AMPS 5.9 6.0 6.2 - 6.4 6.5 6.7 - 6.9 7.1 7.3 - 7.4 7.5 7.8 - 7.8 8.0 8.3 - 8.3 8.5 8.7 -
HI PR 237 255 258 - 268 288 292 - 304 327 332 - 347 373 378 - 390 419 425 - 437 470 476 -
LO PR 122 125 137 - 125 129 141 - 129 134 146 - 133 137 150 - 136 140 153 - 139 143 156 -
MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
Delta T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
70 800 KW 1.49 1.52 1.57 - 1.61 1.64 1.69 - 1.71 1.75 1.80 - 1.80 1.84 1.90 - 1.88 1.92 1.98 - 1.94 1.99 2.06 -
AMPS 5.9 6.0 6.2 - 6.3 6.5 6.7 - 6.8 7.0 7.2 - 7.3 7.5 7.7 - 7.8 7.9 8.2 - 8.2 8.4 8.7 -
HI PR 234 252 256 - 265 285 289 - 301 324 329 - 343 369 374 - 386 415 421 - 432 465 471 -
LO PR 120 124 136 - 124 128 140 - 128 132 144 - 132 136 148 - 134 138 151 - 138 142 155 -
MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
700 KW 1.48 1.51 1.56 - 1.59 1.63 1.68 - 1.69 1.73 1.79 - 1.78 1.82 1.89 - 1.86 1.90 1.97 - 1.93 1.97 2.04 -
AMPS 5.8 5.9 6.1 - 6.3 6.4 6.6 - 6.8 6.9 7.2 - 7.2 7.4 7.6 - 7.7 7.9 8.1 - 8.1 8.3 8.6 -
HI PR 232 249 253 - 262 282 286 - 298 321 325 - 340 365 370 - 382 411 417 - 428 460 467 -
LO PR 119 123 134 - 123 127 138 - 127 131 143 - 130 134 147 - 133 137 150 - 136 140 153 -
MBh 23.9 24.6 26.7 28.6 23.4 24.1 26.0 27.9 22.8 23.5 25.4 27.3 22.2 22.9 24.8 26.6 21.1 21.8 23.6 25.3 19.6 20.2 21.8 23.4
S/T 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.91 0.82 0.62 0.40 0.94 0.84 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.88 0.67 0.43
DeltaT21191611212016112120161121 20 16 11 21 19 16 11 20 18 15 10
900 KW 1.50 1.53 1.58 1.63 1.62 1.65 1.71 1.77 1.72 1.76 1.82 1.88 1.81 1.86 1.92 1.98 1.89 1.94 2.00 2.07 1.96 2.01 2.07 2.15
AMPS5.96.06.26.56.46.56.77.06.97.17.37.67.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.7 9.1
HI PR 237 255 258 264 268 288 292 298 304 327 332 339 347 373 378 386 390 419 425 435 437 470 476 487
LO PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.2 24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7
S/T 0.82 0.73 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.93 0.84 0.63 0.41 0.94 0.84 0.64 0.41
DeltaT22201711222017122220171222 21 17 12 22 20 17 11 21 19 16 11
75 800 KW 1.49 1.52 1.57 1.62 1.61 1.64 1.69 1.75 1.71 1.75 1.80 1.87 1.80 1.84 1.90 1.97 1.88 1.92 1.98 2.05 1.94 1.99 2.06 2.13
AMPS5.96.06.26.46.36.56.76.96.87.07.27.57.3 7.5 7.7 8.0 7.8 7.9 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 234 252 256 261 265 285 289 295 301 324 329 336 343 369 374 382 386 415 421 430 432 465 471 482
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.5 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0
S/T 0.79 0.71 0.54 0.34 0.82 0.73 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40
DeltaT22211712232117122321171223 21 17 12 22 21 17 12 21 19 16 11
700 KW 1.48 1.51 1.56 1.61 1.59 1.63 1.68 1.74 1.69 1.73 1.79 1.85 1.78 1.82 1.89 1.95 1.86 1.90 1.97 2.04 1.93 1.97 2.04 2.11
AMPS5.85.96.16.36.36.46.66.86.86.97.27.47.2 7.4 7.6 7.9 7.7 7.9 8.1 8.4 8.1 8.3 8.6 8.9
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 382 411 417 426 428 460 467 477
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions

20
COOLINGPERFORMANCEDATA DSX160241A*-HIGHSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSX160241A* / CA*F3636C6** + TXV / MBE1200**-1B*, Design Subcooling @ AHRI 95°F Conditions, 5°F @ Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 24.3 24.9 26.6 28.4 23.8 24.3 26.0 27.7 23.2 23.7 25.3 27.1 22.6 23.1 24.7 26.4 21.5 22.0 23.5 25.1 19.9 20.4 21.8 23.3
S/T 0.940.890.720.541.000.920.750.561.000.940.770.571.00 1.00 0.79 0.591.001.000.820.611.001.000.830.62
DeltaT23222016242320162423201623 24 20 162222201620211815
900 KW 1.501.531.581.631.621.651.711.771.721.761.821.881.81 1.86 1.92 1.981.891.942.002.071.962.012.072.15
AMPS5.96.06.26.56.46.56.77.06.97.17.37.67.4 7.5 7.8 8.17.88.08.38.68.38.58.79.1
HI PR 237 255 258 264 268 288 292 298 304 327 332 339 347 373 378 386 390 419 425 435 437 470 476 487
LO PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
MBh 23.6 24.1 25.8 27.6 23.1 23.6 25.2 26.9 22.5 23.0 24.6 26.3 22.0 22.5 24.0 25.7 20.9 21.3 22.8 24.4 19.3 19.8 21.1 22.6
S/T 0.900.840.690.510.930.880.710.530.960.900.730.550.99 0.93 0.75 0.56 1.00 0.96 0.78 0.58 1.00 0.97 0.79 0.59
DeltaT24232016252421162524211625 24 21 17 24 24 21 16 22 22 19 15
80 800 KW 1.491.521.571.621.611.641.691.751.711.751.801.871.80 1.84 1.90 1.97 1.88 1.92 1.98 2.05 1.94 1.99 2.06 2.13
AMPS5.96.06.26.46.36.56.76.96.87.07.27.57.3 7.5 7.7 8.0 7.8 7.9 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 234 252 256 261 265 285 289 295 301 324 329 336 343 369 374 382 386 415 421 430 432 465 471 482
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
MBh 21.8 22.3 23.8 25.5 21.3 21.8 23.3 24.9 20.8 21.3 22.7 24.3 20.3 20.7 22.2 23.7 19.3 19.7 21.0 22.5 17.9 18.2 19.5 20.8
S/T 0.870.810.660.500.900.840.690.510.920.870.700.530.95 0.89 0.73 0.540.990.930.750.561.000.930.760.57
DeltaT25242117252421172524211725 24 21 172524211723221916
700 KW 1.481.511.561.611.591.631.681.741.691.731.791.851.78 1.82 1.89 1.951.861.901.972.041.931.972.042.11
AMPS5.85.96.16.36.36.46.66.86.86.97.27.47.2 7.4 7.6 7.97.77.98.18.48.18.38.68.9
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 382 411 417 426 428 460 467 477
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
MBh 24.8 25.2 26.4 28.2 24.2 24.7 25.8 27.6 23.6 24.1 25.2 26.9 23.0 23.5 24.6 26.2 21.9 22.3 23.4 24.9 20.3 20.7 21.6 23.1
S/T 0.990.960.860.701.000.990.890.721.001.000.920.741.00 1.00 0.95 0.771.001.000.980.801.001.000.990.80
DeltaT25252320252524202425242024 24 24 212223232021212219
900 KW 1.501.531.581.631.621.651.711.771.721.761.821.881.81 1.86 1.92 1.981.891.942.002.071.962.012.072.15
AMPS5.96.06.26.56.46.56.77.06.97.17.37.67.4 7.5 7.8 8.17.88.08.38.68.38.58.79.1
HI PR 237 255 258 264 268 288 292 298 304 327 332 339 347 373 378 386 390 419 425 435 437 470 476 487
LO PR 122 125 137 146 125 129 141 150 129 134 146 155 133 137 150 159 136 140 153 163 139 143 156 167
MBh 24.0 24.5 25.7 27.4 23.5 23.9 25.1 26.8 22.9 23.4 24.5 26.1 22.4 22.8 23.9 25.5 21.2 21.7 22.7 24.2 19.7 20.1 21.0 22.4
S/T 0.940.910.820.670.980.940.850.691.000.970.870.711.00 1.00 0.90 0.731.001.000.940.761.001.000.940.77
DeltaT26262421262625212626252126 26 25 212425242123232320
85 800 KW 1.491.521.571.621.611.641.691.751.711.751.801.871.80 1.84 1.90 1.971.881.921.982.051.941.992.062.13
AMPS5.96.06.26.46.36.56.76.96.87.07.27.57.3 7.5 7.7 8.07.87.98.28.58.28.48.79.0
HI PR 234 252 256 261 265 285 289 295 301 324 329 336 343 369 374 382 386 415 421 430 432 465 471 482
LO PR 120 124 136 144 124 128 140 149 128 132 144 154 132 136 148 158 134 138 151 161 138 142 155 165
MBh 22.2 22.6 23.7 25.3 21.7 22.1 23.1 24.7 21.2 21.6 22.6 24.1 20.6 21.0 22.0 23.5 19.6 20.0 20.9 22.3 18.2 18.5 19.4 20.7
S/T 0.910.880.790.640.940.910.820.670.970.930.840.681.00 0.96 0.87 0.711.001.000.900.731.001.000.910.74
Delta T 26.53 26 25 21 27 26 25 22 27 26 25 22 27 27 25 22 26 26 25 21 24 24 23 20
700 KW 1.481.511.561.611.591.631.681.741.691.731.791.851.78 1.82 1.89 1.951.861.901.972.041.931.972.042.11
AMPS5.85.96.16.36.36.46.66.86.86.97.27.47.2 7.4 7.6 7.97.77.98.18.48.18.38.68.9
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 382 411 417 426 428 460 467 477
LO PR 119 123 134 143 123 127 138 147 127 131 143 152 130 134 147 156 133 137 150 159 136 140 153 163
*Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions
