Goodmans GPS219PLLR User manual

IMPORTANT SAFEGUARDS
PRE FITTED MAINS PLUGS
WARNING:
For your convenience a mains plug has been fitted to this appliance. For your safety please
observe the following information.
1. Should the fuse in the plug fail, remove the plug from the wall socket and replace the fuse with
a 3 Amp ASTAapproved to BS 1362 fuse.
2. Never use the plug without the fuse cover fitted. Replacement fuse covers are available from
your dealer or most electrical retail outlets.
3. If the mains plug is cut off the cable, rewire the replacement plug in accordance with
instruction given in this manual.
4. CAUTION: Under no circumstances should the discarded plug be inserted mains socket. To
prevent a shock hazard carefully dispose of the discarded plug. Do not leave the plug lying
around where children might see it.
To prevent fire or shock hazard do not expose this unit to rain or moisture.
CAUTION: DANGEROUS VOLTAGES EXIST INSIDE THIS UNIT, DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL. DISCONNECT FROM MAINS SUPPLY
WHEN NOT IN USE.
PLUG WIRING DETAILS The wires in this mains lead are coloured in
accordance with the following wiring codes:
Blue................................................. Neutral
Brown................................................... Live
The wires in this mains lead must be
connected to the terminals in the plugs as
follows:
Blue Wire..................................... N or Black
Brown Wire..................................... Lor Red
Only a 3 Amp fuse should be fitted in the plug
ora5Ampfuse at the distribution board.
This symbol means that this unit is double insulated.
An earth connection is not required.
HELPLINE PHONE NUMBER 0870 873 0080
WARNING: UNDER NO CIRCUMSTANCES MUST THE LIVE OR NEUTRAL WIRES BE
CONNECTED TO THE EARTH TERMINAL IN A3-PIN MAINS PLUG.
FUSE
EL
NBROWN
CORD
GRIP
BLUE
Instruction Manual
For improvement purposes, specification and design are subject to change without notice.
Goodmans Product Information Helpline 0870 873 0080
www. goodmans.co.uk
GPS219PLLR
STEREO RADIO CASSETTE RECORDER
COMPACT DISC PLAYER

IMPORTANT NOTES
Your hearing is very important to you and to us so please take care when operating
this equipment. The following guidelines are provided for your information.
Over time your hearing will adapt to continuous loud sounds and will give the
impression that the volume has in fact been reduced. What seems normal to
you may in fact be harmful. To guard against this
set the volume at a low level.
Slowly increase the level until you can hear comfortably and clearly and without
distortion.
Damage to your hearing is accumulative and is irreversible.
Any ringing or discomfort in the ears indicates that the volume is too loud.
Remember listening for prolonged period of time at high volume levels will
harm your hearing.
The following list of typical sound levels may assist you in recognizing just how
loud you have set the volume level.
30dB Quiet library, soft whisper.
40 Living room, fridge freezer bedroom away from traffic.
50 Normal conversation, quiet office, light traffic.
60 Electric sewing machine.
70 Vacuum cleaner, hair dryer, noisy restaurant.
80dB Average city traffic, alarm clock buzzer at 1 Metre, food mixer.
90 Motorcycle, heavy goods vehicle, petrol lawn mower.
100 Pneumatic drill, chain saw, garbage truck,
120 Rock band concert, thunderclap, fast train passing by.
ESTABLISH A SAFE SOUND LEVEL
BEFORE YOUR HEARING
ADAPTS
Once you have established a comfortable listening level, DO NOT INCREASE
THE SOUND LEVEL FURTHER.
DECIBEL
THE FOLLOWING NOISE CAN BE HARMFUL UNDER CONSTANT EXPOSURE





Level dB Example
discotec/night-club.
140 Gunshot, jet plane taking off.
180 Rocket Launching pad.
THRESHOLD OF PAIN
CAUTION
CLASS 1 LASER PRODUCT
Use of Controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
LASER SAFETY
This unit employs a laser, only qualified service personnel should attempt repair.
SOME DO'S AND DONT'S ON THE SAFE USE OF EQUIPMENT
Above all
WARNING:
This equipment has been designed and manufactured to meet European safety standards but
like any electrical equipment, care must be taken if you are to obtain the best results and safety is
to be assured.
Do read the operating instructions before you attempt to use the equipment.
Do ensure that all electrical connections (Including the mains plug, extension leads and
interconnections between pieces of equipment) are properly made in accordance with the
manufacturer's instructions. Switch off and withdraw the mains plug when making or changing
connections.
Do consult your dealer if you are ever in doubt of the installation, operating, or safety of your
equipment.
Don't continue to operate the equipment if you are in any doubt about it working normally, or if it is
damaged in any way- switch off, withdraw the mains plug and consult your dealer.
Don't remove any fixed covers as this may expose dangerous voltages.
Don't leave equipment switched on when it is unattended unless it is specifically stated that it is
designed for unattended operation or has a standby mode. Switch off using the switch on the
equipment and made sure that your family knows how to do this. Special arrangements may need
to be made for infirm or handicapped people.
Don't listen to headphones at high volume, as such use can permanently damage your hearing.
Don't obstruct the ventilation of the equiment, for example with curtains or soft furnishings.
Overheating will cause damage and shorten the life of the equipment.
Don't allow electrical equipment to be exposed to rain or moisture.
Never let anyone, especially children, push anything into holes, slots or any other opening as
this could result in a fatal electric shock.
Never guess or take chances with electrical equipment of any kind.
It is better to be safe than sorry!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE, DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE, DO NOT OPEN THE CABINET, REFER
SERVICING TO QUALIFIED PERSONNEL ONLY.
CAUTION
CLEANING: Always disconnect unit from mains supply before attempting to clean it. Use soft
cloth moistened with soapy water, wipe gently. Do not use solvents or abrasive
materials.
DANGER:
CAUTION:
INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCK FAILED OR DEFEATED. AVOID DIRECT
EXPOSURE TO BEAM.
HAZARDOUS LASER RADIATION WHEN OPEN AND
INTERLOCK DEFEATED.

Power Sources ................................................. 1
Player Maintenance............................................ 2
........... 3
Program play operation......................................7
Repeat play operation.........................................8
Random play operation........................................9
Cassettes..........................................................10
Recording from MIC/ ........................... 11
Disc Cleaning, Power failure.................
Location of Controls........................................... 4
Radio operation................................................. 5
Listening to a compact disc.................................. 6
Radio/ CD
Remote Control.................................................12
Product Specifications...................................... 13
TABLE OF CONTENTS
WARNING
SAFETY PRECAUTIONS
1. As the laser beam used in this compact
disc player is harmful to the eyes, do not
attempt to disassemble the casing.
2. Stop operation immediately if any liquid or
solid object should fall into the cabinet.
Unplug the unit and have it checked by
qualified personnel.
3. Do not touch the lens or poke at it. If you do,
you may damage the lens and the player
may not operate properly.
4. Do not put anything in the safety slot. If you
do, the laser diode will be ON when the lid
is still opened.
5. This unit employs a laser. The use of
controls or adjustments or performance of
procedures other then those specified
herein may result in exposure to
hazardous radiation.
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified
personnel only.
Player Operation
1. POWER SOURCES
2. PLAYER MAINTENANCE
CLEANING THE LENS
If the lens in the CD pick-up is dirty, dusty,
etc, it could degrade the sound or prevent
disc play. Open the disc holder and clean
the lens as shown.
Use a blower (available from camera
stores) to blow dust off the lens.
If there are fingerprints, etc., on the
lens, gently wipe clean with a cotton
swab.
h
h
CASSETTE DECK MAINTENANCE
When the heads, capstan and pinch roller
become dirty, this may result in muffled,
distorted or reduced sound during play back
and may even result in tape jams.
Clean the tape head with a
.
head cleaning
tape available from all good audio stores
AC MAINS OPERATION
1. Remove the AC cord which is packed
inside the box.
2. Connect the cord to the AC input
socket.
3. Connect the 3 pin mains plug to an AC
mains socket.
BATTERY OPERATION
1. Insert 8 LR14 (C Size) batteries (not
supplied) into the battery compartment
observing the correct polarity as
indicated.
2. Ensure compartment cover is securely
fitted.
3. Product will only function from
batteries once AC cord is removed
from the unit.
4. When replacing flat batteries, ensure
all batteries are replaced at the same
time with the same type.
5. If the product is not to be used for an
extended period of time the batteries
should be removed to prevent any
possible damage to the product.

Cleaning the Disc
1. To handle a disc use only one of the two
methods illustrated.
Do not touch the rainbow-colored
side.
2. To wipe a disc, use only a soft cloth. Do
not use petroleum products or thinner
which will damage the disc. The disc
should always be wiped in a straight line
from the center to the edge. It should
never be wiped in a circular motion.
3. Never place the disc on other equipment
or near any heat source. Avoid positions
where the disc would be subjected to
direct sunlight for long periods.
NOTE:
3. DISC CLEANING, POWER FAILURE
1. Electronic products should never be
subjected to extreme temperatures nor
high humidity to ensure good performance
and a long life-time. The player should not
be placed in bathing areas, or around
stoves and radiators, etc. Always leave
sufficient space around the unit for
ventilation.
2. If necessary, only clean the cabinet of the
unit with a soft dampened piece of cloth.
(be sure the AC power cord is unplugged
from the outlet) Never use a polish or a
strong detergent for cleaning since this
can damage the finish of the cabinet.
Maintenance and care
4. LOCATION OF CONTROLS
LOCATION OF CONTROLS
1. PHONES SOCKET
2. VOLUME CONTROL
3. TAPE BUTTON
4. STANDBY INDICATOR
5. FOLDING HANDLE
6. CD DOOR
7. CD STOP BUTTON
8. CD PLAY/PAUSE BUTTON
9. CD REPEAT/RADIO PRESET BUTTON
10. TUNING/ ( & )
11. ON/OFF BUTTON
12. RADIO BUTTON
13. CD BUTTON
SKIP/SEARCH CONTROL
PROGRAM/RADIO PRESET STORE
AERIAL
COMPARTMENT (ON REAR)
14. BASS BOOST SWITCH
15. CASSETTE PAUSE BUTTON
16. CASSETTE STOP/EJECT BUTTON
17. CASSETTE FAST FORWARD BUTTON
18. CD DOOR OPEN SWITCH
19. CASSETTE REWIND BUTTON
20. CASSETTE PLAY BUTTON
21. CASSETTE RECORD BUTTON
22. CD RANDOM BUTTON
23. CD BUTTON
24. RADIO BAND BUTTON
25. SPEAKERS
26. CASSETTE DOOR
27. DISPLAY
28. REMOTE SENSOR
29. FM TELESCOPIC
30. BATTERY COMPARTMENT
31. FM STEREO/MONO SELECTOR
32. AC SOCKET
REMOTE CONTROL
1. MUTE BUTTON
2. CD BUTTON
3. CD PROGRAM/RADIO PRESET STORE BUTTON
4. VOLUME DOWN BUTTON
5. CD PLAY/PAUSE BUTTON
6. CD BACKWARD SKIP/SEARCH / RADIO TUNING
DOWN BUTTON
7. CD STOP BUTTON
8. BATTERY
9. POWER BUTTON
10. RADIO BUTTON
11. BAND BUTTON
12. CD REPEAT/RADIO PRESET BUTTON
13. TAPE BUTTON
14. VOLUME UP BUTTON
15. CD FORWARD SKIP/SEARCH /
RADIO TUNING UP BUTTON
1
2
3
5
6
7
9
10
11 12
13
15
14
4
8
1 2 345678 910
11 12
13
14
15
16
17
18
19
20
21 22
23
24
25 26 27 28 25
30 31 3229

1. Press the Radio Band Button to select
MW or FM band, and
.
2. Press the Prog/Store Button, " "
will flash in the display.
3. While the " " is flashing, Press the
Radio Preset Button to choose a
memory position. (Example: Press this
button 3 times, and the Number 3
Preset station will be selected.)
4. Press the Program/Store Button again
to confirm. The station is stored into
that preset memory position.
Steps 2-4 should be done
within 5 seconds or the
display will time out.
5. Repeat steps 1 to 4 to store other
stations in memory.
6. Each memory position can store 2
stations, one for an MW, the other for
FM.
NOTE:
select a station
using the instructions given opposite
5. RADIO OPERATION PRESETTING STATIONS
UP TO 10 FM AND 10 MW STATIONS CAN BE STORED INTO THE PRESET
MEMORIES. (THEY WILL REMAIN IN MEMORY AS LONG AS THE BATTERIES ARE
INSTALLED, OR AC POWER CORD IS CONNECTED.)
1. Press the Radio button after the ON/OFF
button has been pressed.
2. Press the Radio Band Button to select
the desired wave band.
3. Tune to desired station by
.
5. When listening to an FM station in stereo,
and there is a large amount of hiss, slide
the FM Stereo/Mono selector switch to
the Mono
6. Adjust the Volume Control to your
listening preference.
7. To turn off the radio, press the power
button to turn the unit to the Standby
mode.
4. To search for a station quickly (automatic
tuning), hold the
until the frequency
starts to change rapidly, then
release and the unit will stop search at
the next receivable station.
twisting the
Tuning/Skip/Search Control clockwise
or anti-clockwise
position to improve reception.
To return to stereo slide the switch back
to the Stereo position.
Tuning/Skip/Search
Control shown on the
display

This set is designed to play only compact
discs bearing this identification logo
(logo must say DIGITAL AUDIO).
1. Press the Power button to turn on the unit
and then press the CD button
2. Press the CD Door Open button to open
the CD Door.
3. Insert a CD with the LABEL side facing
UP, close the CD Door by gently pushing
it down.
4. The display will show 2 zeros " ", and
after the disc has been read the total
number of tracks (songs) and the total
play time of the disc. (If the disc is upside
down or damaged, the Display will show
2 zeros " ", and then " " will be
shown).
.
6. LISTENING TO A COMPACT DISC
1. Press the Radio button to select the radio.
2. Press the Radio Band Button to select the
desired wave band.
3. Press the Radio Preset Button
repeatedly to select the required station.
(Example: Press this button 3 times to
select the Number 3 Preset station, and
so on).
4. To turn off the radio, press the Power
button to turn the unit to Standby.
PLAYING A COMPACT DISC
5. To start playback, press the CD
Play/Pause Button. The first track
number " " will appear in the Display,
and the disc will start playing. The
elapsed time will be shown in the display
also.
6. Adjust the Volume Control to your taste.
For extra bass press the Bass Boost
switch.
7. To pause playback, press the
Play/Pause Button, the elapsed time will
flash to remind you that you are in pause
mode.
8. To resume playback, press the
Play/Pause Button again. The elapsed
time will be steady on (not flashing).
9. To stop playback, press the CD Stop
Button.
TO LISTEN TO PRESET MEMORY
STATIONS

SKIPPING TRACKS (SEARCH)
1.
. The Display will show the track
number.
2.
3. Twist and hold the
to search forward or backwards
at high speed to search for a section of a
track. When the section is found release
the control and normal playback will
resume.
Twist the Skip/Search/Tuning Control
anti-clcokwise once or repeatedly to
select the next or one of the subsequent
tracks
Twist the
twice or more quickly to select one of the
previous tracks.
Skip/Search/Tuning Control
Skip/Search/Tuning
Control
7. PROGRAM PLAY OPERATION
PROGRAMMED (MEMORY) PLAYBACK
(up to 20 tracks can be programmed)
4. Press the Program Button. The Display
will show " ".
5. Repeat steps 3 and 4 until all the
desired tracks are programmed.
7. All songs will be played in the order you
programmed.
8. The Display will show the track number
being played, and the " " indicator
will show (but not flashing) in the
display during programmed play.
9. When all the songs have finished
playing, the set will stop. " "
disappears from the display.
Programming can only be done
when the CD is in the stop mode.
The programmed memory will be
cleared if the CD power is turned off.
6.
NOTE:
NOTE:
Press the CD Play/Pause button to
commence playback after programming.
8. REPEAT PLAY OPERATION
To repeat the SAME track over and over
again, do the following:
1. Press the Repeat Button once during
playback or in stop mode.
2. The " " icon will flash in the display.
The song currently playing will play over
and ove
3. To stop the repeat function, press the
Repeat Button twice until the " "
icon clears from the display.
r, .until STOP is pressed
REPEAT ONE TRACK
x2
1. When the CD is stopped, press the
Program Button.
2. The Display will show " " and
"".
3. Use the
until the desired track is shown in the
display.
Skip/Search/Tuning Control
REPEAT
x1
REPEAT

REPEAT ALL TRACKS
To repeat ALL TRACKS on a disc and
play them again and again.
1. Press the Repeat Button twice during
playback .
2. The " " icon will show steadily (not
flashing) in the display. All the songs on
the CD will be played in order and then
start all over again.
3. To stop the repeat function, press the
Repeat Button once until the " "
icon removed from the display.
10. CASSETTES
CASSETTE TAPE SELECTION
The quality and condition of the cassette tapes you use will have a direct effect on the
performance of this set.
Low quality tapes tend to break and stretch and a broken tape can easily become
entangled in the drive mechanism, causing major damage. Stretched tapes will run at
uneven speeds and will distort anything recorded on them.
Use only well-known brands of tapes.
Use of C-120 (120 minutes) cassette is not recommended. The extreme thinness of
this tape may result in breakage or other failures.
This set is not designed for CrO2, Fe-Cr or METAL tape use. Therefore, be sure to
use named brand normal cassette tapes.
h
h
h
TO PLAY A CASSETTE TAPE
AUTOMATIC LEVEL CONTROL (ALC)
This product utilizes the latest Automatic
Level Control circuitry, therefore, it is not
necessary to adjust the Volume Control
when recording. This circuit automatically
records at the correct level and prevents
over loading.
NOTE: While recording you may adjust
the Volume Control as desired
without affecting the recording
operation.
Press the CD Random button in CD stop
mode or during CD playback.
Press this button once again during
Random playback to exit and resume
Normal CD playback.
9. RANDOM PLAY OPERATION
REPEAT
x2
x1
1. Open the Cassette Door by pressing the
Cassette Stop/Eject Button
2. Insert cassette tape into
. Make sure the full reel
is on the right and the exposed part of the
tape faces upward, make sure the tape
inside is not slack or loosely wound. If it is,
insert a pencil into the reel and turn until
the tape is wound up.
3. Close the Cassette Door.
4. Press the Tape button.
5. Press the Cassette Play Button.
: If the Play button pops up,
.
6. Adjust the Volume Control to your
listening preference.
7. To stop the tape, press the Cassette
Stop/Eject Button.
8. To remove the cassette, press the
Cassette Stop/Eject Button again and
the Cassette Door will open.
Unload the cassette tape, and
re-insert into cassette compartment to
play the other side of the cassette tape.
NOTE
if a tape is
already playing press this button twice, to
stop playback and then open the
Cassette Door.
tracks on the
inside of the door
turn
the tape over or rewind the tape
turn it over
REPEAT

11. RECORDING FROM RADIO/MICROPHONE/CD
RECORDING FROM RADIO
RECORDING FROM THE BUILT-IN
MICROPHONE
1. Load the cassette tape into the
Cassette Door (full reel on the right ).
2. Load the compact disc and close the CD
Door.
3. Press CD button.
4. Press the Cassette Pause button.
5. Press the Cassette Record button for
record stand by.
When pressing the Cassette
Record Button, the Cassette
Play Button will automatically
go down (If the buttons do not
go down, reverse the tape or
check record prevention tab).
6. Start the CD playing by pressing the CD
Play/Pause button.
NOTE:
RECORDING FROM A CD
1. Load a blank cassette tape into the
Cassette door (full reel or spool on right
side).
2. Press TAPE button.
3. Press the Cassette Record button and
Cassette Play button at the same time.
Both buttons should remain in their
down positions when released.
4. When you talk in front of the set your
voice will be recorded. You are now
recording using the Built-in Condenser
Microphone and the recording process
will automatically stop at the end of the
tape and shut itself off.
5. To stop the recording manually, press
the Cassette Stop/Eject button.
6. To hear what you recorded, press the
Cassette Rewind button and then the
Cassette Play button.
1. Follow the instructions to
.
2. Load a blank cassette tape with full spool
the door.
3. Locate the portion of the tape where the
recording is to begin by using the Rewind
or Fast Forward buttons or start at the
beginning of the tape.
4. Press the Cassette Record Button and
Cassette Play button simultaneously.
Both buttons should remain in their
depressed positions when released.
5. The recording process will automatically
stop at the end of the tape.
6. To stop the recording manually, press the
Cassette Stop/Eject Button.
When you want to play the cassette
tape after recording, press the TAPE button,
press Cassette Rewind Button, and then
press Cassette Play Button. Adjust the
Volume Control to your taste.
NOTE:
select the
required station
on the right into the guides on the inside
of

7. Press (and release) the Cassette Pause
button when you wish to start recording.
8. Press the Cassette Stop/Eject button to
stop the recording.
9. The recording will stop when the tape
has reached the end and the Record
and Play buttons will pop up.
10. To hear what you recorded, press TAPE
button, press Rewind and then the Play
button.
12. REMOTE CONTROL
By using the remote controller, you can
operate the system in almost the same
way as with the controls of the main unit.
MUTE BUTTON
To mute the sound press the MUTE
Button on remote controller. Press the
MUTE Button
REMOTE CONTROL RANGE
Use the remote control within an angle of
30 at the left and right horizontally and
over distances up to about 3 meters.
o
again to restored the sound.
1. Open the battery compartment cover.
2. Install 2pcs UM-4 (size AAA) batteries
into the battery Compartment matching
the polarity as shown in the battery
compartment.
3. Close the battery compartment lid.
Always remove batteries if the
remote controller is not going to
be used for a month or more.
Batteries left in the unit may
leak and cause damage.
NOTE:
INSERTING BATTERIES
REMOTE OPERATION
13. PRODUCT SPECIFICATIONS
Net Weight
Dimension
Power consumption
Power requirements
Output level
Speakers Impedance
Frequency range
Receiving bands
No. of channels
Wow and flutter
Frequency response
D/A conversion
Approx. 3.20Kg (not including batteries)
Approx. 446.6(L)X246.2(W)X170.2(H) mm
22W
AC 230V
DC 8* "C" size (or equivalents) batteries
Earphone: 20mW (32 )
2 channels (stereo)
4 5W*2
Below measurable limits
20-20,000Hz (+1/-3 dB)
1-bit DAC 8 times oversampling
AUDIO
RADIO
GENERAL
System
Cross-interleave Reed-solomon code
material: GaAIAs
Compact disc digital audio system
Error correction
Properties
Laser diode
PICK-UP
Wavelength: =780nm
Emission Duration: continuous
Laser output: <44.6 W
MW 522-1620 KHz
FM 87.5 -108.0 MHz
MW/FM
