Gorenje K6N30IX Guide

Combined and gas built-in cooking hob
MT IE GB Instructions for use, installation,
and connection

444650
Combined and gas built-in hob is intended for
use in households.
Our products are packed in environment-friendly materials
which can be recycled, disposed of, or destroyed without
imposing any burden on the environment.
Instructions for use are intended for the user. They
describe the appliance and its operation. The instructions
apply to various types of appliances and may therefore
include description of functions that may not be available
on your appliance.
These instructions are only valid of the country symbol
is indicated on the appliance. If there is NO county
symbol in the appliance, technical instructions should be
observed for adapting the appliance to comply with the
requirements and regulations for use in your country.
The appliance must be connected in compliance with the
instructions attached to it, as well as in compliance with
relevant regulations and standards. The connection may
only be performed by a qualified person.
The rating plate indicating the basic information on the
appliance is attached to the lower side of the hob.
Instructions for use
Instructions for
connection
Rating plate
Dear customer!
2
COMBINED AND GAS BUILT-IN COOKING HOB

444650
IMPORTANT - READ BEFORE USING THE APPLIANCE......................................... 4
Safety percautions........................................................................................................................4
Warnings............................................................................................................................................5
APPLIANCE DESCRIPTION ...........................................................................................7
Control knob....................................................................................................................................8
COOKING ZONES ............................................................................................................ 9
Before using the appliance for the first time...................................................................9
Important warnings......................................................................................................................9
Cookware ..........................................................................................................................................9
Energy saving................................................................................................................................ 10
Important warnings.................................................................................................................... 10
Cookware ..........................................................................................................................................11
OPERATING THE ELECTRIC COOKING ZONES ...................................................... 12
OPERATING THE GAS BURNERS................................................................................ 13
Ignition and operation of the burners .............................................................................. 13
CLEANING AND MAINTENANCE................................................................................14
Hotplates......................................................................................................................................... 14
Gas cooking zones ......................................................................................................................15
SPECIAL WARNINGS AND FAULT REPORTING......................................................16
Important ........................................................................................................................................ 16
INSTALLATION ................................................................................................................ 17
Important warnings.....................................................................................................................17
Kitchen worktop cuto dimensions................................................................................... 18
Installation procedure ............................................................................................................... 18
CONNECTING THE APPLIANCE TO THE POWER MAINS....................................20
Important warnings...................................................................................................................20
Connection diagram .................................................................................................................20
CONNECTING THE COOKING HOB TO THE GAS SUPPLY .................................. 22
Important warnings................................................................................................................... 22
Connection .................................................................................................................................... 22
Adaptation to a dierent type of gas .............................................................................. 23
Adjustment elements ............................................................................................................... 24
NOZZLE TABLE ............................................................................................................. 25
TECHNICAL CHARACTERISTICS ............................................................................... 26
Rating plate................................................................................................................................... 26
TABLE OF CONTENTS
3

444650
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• WARNING: Ensure that the appliance is switched o
before replacing the lamp to avoid the possibility of
electric shock.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements. Children less than 8 years of age shall
be kept away unless continuously supervised.
• WARNING: Danger of fire: do not store items on the
cooking surfaces
• CAUTION: The cooking process has to be supervised.
A short term cooking process has to be supervised
continuously.
• WARNING: Unattended cooking on a hob with fat or oil
can be dangerous and may result in fire. NEVER try to
extinguish a fire with water, but switch o the appliance
and then cover flame e.g. with a lid or a fire blanket.
• Do not use steam cleaners or high pressure cleaners to
clean the appliance as this may result in an electric shock.
• Means for disconnection must be incorporated in the
fixed wiring in accordance with the wiring rules.
• The appliance is not intended to be controlled with
external timers or special control systems.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard (only for appliances
supplied with connection cord) .
4
IMPORTANT - READ BEFORE USING
THE APPLIANCE
Safety percautions

444650
• The appliance may only be connected by an expert authorized by the gas distribution
company or an authorized service center. All relevant legislation and local gas
distributor's technical conditions for connection to the gas mains should be complied
with. Important notes on connection are provided in the chapter »Instructions for
connection.«
• Unauthorized service and repair can result in risk of explosion, electric shock, or short
circuit and consequently personal injury and damage to the appliance. Such tasks may
only be carried out by an authorized expert.
• Before installing and connecting the appliance, make sure the local connection
conditions and characteristics (gas type and pressure) are compatible with the
appliance set-up.
• The set-up of the appliance is specified on the rating plate.
• The appliance is not connected to a flue or a ventilation opening. The appliance
should be installed and connected in compliance with the relevant regulations on
connection. Heat, moisture, and combustion by-products are released during the use
of the cooking appliance in the room where it is installed. Make sure your kitchen
is adequately ventilated, especially during the use of appliance. Open all natural
ventilation openings or install a mechanical ventilation device (a mechanical kitchen
hood).
• The vertical distance between the appliance and the kitchen hood must be at least 650
mm or at least the distance specified in the instructions for installation of the kitchen
hood.
• The appliance is intended solely for cooking. Do not use it for any other purpose, e.g.
for room heating. Do not place empty cookware on the cooking zones.
• If another electrical appliance is connected to a AC power socket near the appliance,
make sure the power cord does not come into contact with hot cooking zones.
• Do not store temperature-sensitive items underneath the appliance, such as cleaners or
detergents, spray cans etc.
• Pay attention to correct installation of burner parts.
• If you smell gas in the room, immediately close the main inlet valve on the gas cylinder
or the gas grid, extinguish any fire (including cigarettes), ventilate the room, do not
switch on any electrical devices, and call a natural gas expert.
• Also close the main inlet valve if you do not intend to use the burners for a longer
period of time (e.g. before leaving on vacation).
• In case of prolonged use of cast iron plates, the area of the plate and the edge of the
cooking zone may discolour. Servicea in such case is not covered by the warranty.
• WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by
the manufacturer of the appliance in the instructions
for use as suitable or hob guards incorporated in the
appliance. The use of inappropriate guards can cause
accidents.
5
Warnings

444650
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead it shall be handed over to
the applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of thisproduct. For more detailed
information about recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the product.
6

444650
(equipment - depending on the model)
Upper side of a combined cooker with gas cooking zones
Type PVK4...
1. Cooking zone rear left
2. Cooking zone front left
3. Control knobs
4. Cooking zone rear right
5. Cooking zone front right
Upper side of a combined cooker with gas and electric cooking zones
Type KVK4...
7
APPLIANCE DESCRIPTION

444650
(depending on the model)
Electric
1- 6 power levels
1- 9 power levels
Gas
gas valve is closed
maximum power
minimum power
8
Control knob

444650
A) Electric cooking zones
After you receive your appliance, please wipe the entire
cooking hob, including the cooking zones, with a damp
cloth.
Turn on the cooking zones for 3 to 5 minutes and select the
maximum power level; some fumes may be discharged from
the hob. This way, the protective cover on the cooking hob
will reach its maximum solidness.
• Do not turn on a cooking zone without a pan over it, and
never use the cooking hob for room heating!
• Make sure the cooking zones and pan bottom are clean
and dry, and that sucient heat transmission is enabled
between them, in order to prevent any damage to the
heating surface.
• Any fat or oil left on the cooking ones may ignite.
Therefore, be careful when using fat and oil to prepare food
(e.g. French fries).
• Do not place a damp pan or a steam-covered lid on the
cooking zones, as moisture is detrimental to them.
• Do not leave a hot pan to cool down on the cooking zones,
because moisture will be generated under it, causing
corrosion.
Tips for using the cookware
Use high-quality cookware with a flat and stable bottom.
• Transmission of heat is best when the pan bottom and
the cooking zone are of the same diameter, and the pan is
placed on the middle of the cooking zone.
• When using a tempered glass (Pyrex) or porcelain
cookware, please follow the cookware manufacturer’s
instructions.
• When using a pressure cooker, do not leave it unattended
until the desired pressure is reached. The cooking zone
should initially be set to the maximum power level; as the
pressure rises, use the sensors to decrease the power
level according to the pressure cooker manufacturer’s
instructions.
• Make sure there is always enough water, either in a pressure
cooker or in any other piece of cookware, as using an
empty pan on the cooking hob will result in overheating
which will damage both the pan and the cooking zone.
• Tempered glass (Pyrex) cookware with a specially brushed
bottom is suitable for use on cooking hobs if it fits the
Before using the
appliance for the first
time
Important warnings
Cookware
9
COOKING ZONES

444650
diameter of the cooking zone. Cookware with larger
diameter may break due to thermal stress.
• When using any special or unconventional cookware, follow
the cookware manufacturer’s instructions.
• Pan bottom diameters should match the diameter of the
cooking zone. If the pan is too small, some heat is wasted;
furthermore, using a too small pan can damage the
cooking zone.
• Whenever possible given the cooking process, use a lid.
• The pan should be appropriately sized given the quantity
of food prepared. Preparing a small quantity of food in a
large pan will cause a waste of energy.
• Dishes that take a long time to cook should be prepared in
a pressure cooker.
• Various vegetables, potatoes, etc., can be cooked in a small
quantity of water; however, the lid should be closed tightly.
When the water is brought to boil, reduce the power level
to a setting that maintains a temperature just above boiling
point.
B) Gas cooking zones
• If you wish to quickly fry some food, set the gas burner to
the maximum power initially and reduce the power as your
continue.
• In all models, the cooker burners are fitted with
thermoelectric safety devices. If the burner flame is
extinguished (due to boiling over, draft etc.), gas supply
will be shut o automatically. Any chance of gas leaking
into the room is eliminated.
• Gas burner cover should always be placed very carefully on
the burner crown. Make sure the slots on the burner crown
are never obstructed.
1Burner crown cover
2Burner crown with the support for the burner cover
3Thermo-element
4 Spark plug
5Nozzle
Energy saving
Important warnings
1
2
3
4
5
10

444650
• Correctly selected cookware will enable optimum
cooking time and gas consumption. Pan diameter is the
most important parameter.
• Flames that reach over the edge of a pan that is too
small, can damage the cookware; furthermore, gas
consumption is higher in such cases.
• For combustion, the gas also needs air. If a pan is too
large, air supply to the burner is insucient; as a result,
combustion eect is lesser.
Grid extension (only available with some models)
Use the extension when using a pan of a smaller diameter.
Place the extension on the grid above the auxiliary burner.
Burner type Pan diameter
Large (3.0kW) 220-260 mm
Normal(1.9kW) 160-200 mm
Auxiliary (1.0kW) 120-140 mm
Double burner (3.5kW) 220-260 mm
Cookware
11

444650
• Turn on the cooking zone using the knobs installed on
the control panel.
• The symbol next to each knob indicates which cooking
zone is operated by it.
• Cooking zone power level can be set continuously (1-9)
or stepwise (1-6).
• The step knobs can be rotated in both directions. With
continuous knobs, the power level is increased as you
rotate them in the clockwise direction, and reduced as
you turn them in the anticlockwise direction.
• The cooking zone may be turned o three to five
minutes before the end of cooking in order to make
use of the residual heat and save some energy (the
following table lists some examples for using individual
power levels).
SE
00 Cooking zone turned o; using the remaining
heat
1 1-2 Maintaining the temperature and reheating of
smaller quantities of food (minimum power)
2 3-4 Further cooking
3 5-6 Further cooking of larger quantities, further
frying of larger pieces
47 Frying, preparing roux
58 Deep frying
69 Bringing to boil, browning, frying
Rapid cooking zones (only available in some models)
dier from the conventional cooking zones by their
maximum power which allows them to heat up faster.
These cooking zones are indicated by a red dot in the
middle; after a while, due to repeated use and cleaning,
this dot may disappear.
12
OPERATING THE ELECTRIC COOKING ZONES

444650
Models with two gas burners:
• Operate the gas burners using the knobs on the hob.
Power levels are indicated on the knobs by large and small
flame symbols (see section Appliance description).
• Rotate the knob through the large flame position ( )
to the small flame position ( ) and back. Operation interval
lies between the two flame symbols.
• Gas burners can be ignited using the electric spar plug built
into each gas burner (only available with some models).
Before rotating the knob, it should first be depressed.
Single-handed ignition
• In order to ignite the gas burner, press the selected burner
control knob and rotate it to the maximum power (flame)
position. An electric spark will be generated automatically,
igniting the releasing gas.
• If the electric ignition should not work due to a power
failure or damp spark plugs, the gas can also be ignited
using a match or a gas lighter. After igniting the gas, keep
the control knob pressed for another ten seconds, until the
flame settles.
• The flame can then be set between the maximum and
minimum level. Any setting between ( ) and ( ) is not
recommended, as the flame is not stable in this interval and
may be extinguished.
If the burner hasn’t ignited after the knob has been
depressed for fifteen seconds, close the burner and
wait at least one minute. Then, repeat the ignition
process.
If the burner flame is extinguished (for any reason),
close the burner and wait at least one minute before
attempting to re-ignite it.
• To extinguish the flame and close the burner gas supply,
rotate the control knob to the right, to the ‘OFF’ position
().
Ignition and operation
of the burners
13
OPERATING THE GAS BURNERS

444650
Clean the appliance using warm water, liquid detergent,
and a soft cloth.
Do not use any abrasive or sharp utensils or other objects.
Burnt or dried food residues should be moistened using a
damp cloth and softened with appropriate detergent.
Stainless steel parts should be cleaned using special-
purpose detergents. Use a dry, highly-absorbent cloth to
apply a thin layer of detergent on a dry and cool surface,
and rub gently in the direction of surface treatment
pattern. Use a damp cloth and a detergent to clean
stubborn stains; then, use a dry cloth to achieve to polish
the surface until glossy. Do not use the same (stainless
steel) detergents to clean aluminum parts.
1Burner crown cover
2Burner crown
3 Thermo-element (only with protected burners, available
only in some models)
4Ignition plug
• Use warm water with some dishwashing detergent to
clean the area around the cooking rings (or hotplates).
Before doing so, use a sponge to soften any stubborn
residues.
• All dirty cooking zones should be cleaned thoroughly
immediately after use. If the cooking zones are less
stained, it suces to wipe them with a damp cloth
soaked in water and some detergent. If the hotplate
is heavily soiled, use a steel sponge (wire scrubber)
soaked with detergent. After cleaning, the cooking
zones should always be wiped dry.
• Salt-containing liquids, dishes that have boiled over, or
moisture, can damage the cooking zones. Therefore,
always wipe the cooking zones clean and dry.
• To condition the cooking zones, occasionally use
some sewing machine oil, or conventional products
for cleaning and care, available in the market. Never
use butter, bacon / lard, or similar substance (risk of
corrosion). If the cooking zone is slightly warm, the
detergent will penetrate the pores more quickly.
• Hotplate rings are made of stainless steel; due to
thermal load during cooking, they may discolor slightly
1
2
3
4
Hotplates
14
CLEANING AND MAINTENANCE

444650
to yellow. This phenomenon is a result of physical
processes. Yellow spots can be restored by conventional
metal cleaning detergents.
Do not use aggressive utensils for cleaning the dishes, as
these will scratch the rings.
To clean the grid, cooking hob surface, and parts of the
burner, use hot water with some dishwashing detergent.
Clean the thermo-element and the spark plug with a soft
brush. These parts must be kept impeccably clean, as only
then will they operate correctly. Clean the crown and the
burner cover. Be particularly careful to keep all exit slots
on the crown clean and unobstructed. After cleaning,
dry all parts thoroughly and replace or reassemble them
correctly. Parts that are placed askew will make lighting
the burners more dicult.
Warning: Burner covers are coated in black enamel.
Due to high temperatures, discoloration is unavoidable;
however, this will not aect the operation of the burners.
Gas cooking zones
15

444650
During the warranty period, only a service center authorized by the manufacturer may
carry out any repairs.
Before making any repairs, make sure the appliance is disconnected from the power mains
either by removing the fuse or by disconnecting the power plug from the wall outlet.
Unauthorized tampering with and repairs of the kitchen range (cooking hob) can result in
electric shock or short circuit; hence, do not attempt to perform any repairs by yourselves.
Leave such tasks to an expert or an authorized service unit.
In case of minor faults or problems with the appliance operation, check the following
instructions to see whether you can eliminate the causes by yourselves.
A visit by a service technician during the warranty period
will be charged if the appliance is not functioning because
of improper use. Store these instructions in a place where
they are always readily accessible; if pas the appliance
on to another person, the instructions should also be
included.
Following is some advice on rectifying some common
problems.
Important
What happened...? Possible cause What to do?
The burners will not burn
The flame is uneven /
unstable
Flame is uneven due to a
wrong gas power setting.
Have an expert check he gas
pipeline!
The flame from the burners
suddenly changes
Wrongly assembled parts of
the kitchen hob
Assemble the burner
correctly.
Burner ignition takes more
time
Wrongly assembled parts of
the kitchen hob
Assemble the burner
correctly.
The flame is extinguished
shortly after ignition
Knob pressed too short or
to weakly.
Keep the knob depressed
for a longer period of time.
Before releasing it, pres it
harder.
The grid has discolored in
the burner area?
This is a commonplace
phenomenon resulting from
high temperature
Clean the grid with a metal
care detergent.
Electric power supply in
general is interrupted?
The fuse may be blown. Check the fuse in the fuse
box and replace it if it is
blown.
Electric ignition of the
burners no longer works?
There are food or detergent
residues between the spark
plug and the burner.
Open and carefully clean the
opening between the spark
plug and the burner.
16
SPECIAL WARNINGS AND FAULT REPORTING

444650
If the problem persists despite observing the instructions
above, call an authorized service technician. Elimination of
any errors or warranty claims that resulted from improper
connection or use of the appliance is not covered by our
warranty. In such cases, the costs of repair are borne by the
user.
• Installation of the appliance into a kitchen worktop and its connection to the power
mains may only be performed by an adequately qualified technician.
• Veneer or other finish of the piece of kitchen furniture into which the hob is to be built
in should be treated with heat resistant glue (100°C); otherwise, the worktop finish may
be discolored or deformed.
• Cooking hob is dimensioned to be built into the worktop over a piece of kitchen
furniture, with a width of 600 mm or more.
• After installation, the front two fastening elements should be freely accessible from
below.
• The kitchen furniture element underneath the hob should not be fitted with a drawer.
If the kitchen furniture element as a horizontal partition wall, it should be installed no
less than 10 centimeters from the lower surface of the worktop. The space between the
partition wall and the hob must be empty; no objects should be placed into that gap.
• Hanging, or wall-mounted kitchen elements should be installed high enough not to
interfere with the work process.
• The distance between the cooking hob and the kitchen hood should be no less than
indicated in the instructions for kitchen hood installation. The minimum distance is 650
mm.
• The distance between the appliance edge and the adjacent tall kitchen furniture
element should amount to no less than 100 mm.
• Use of massive wood decoration plates or boards on the worktops behind the cooking
hob is permitted, if the minimum distance remains the same as indicated in the
installation drawings.
• Minimum distance between the built-in cooking hob and the rear wall is indicated on
the installation drawing.
• Cooking hobs can be installed into worktops that are 30 to 50 mm thick.
Important warnings
If the burner cover looks
unappealing...
Regular dirt Clean the burner covers with
a metal care detergent.
17
INSTALLATION

444650
Type KVK4.., PVK4...
• Only type EVP4.., EVP3.., EVP2.., ovens fitted with a
cooling fan may be installed underneath this cooking
hob.
• Before installing an oven, the rear wall of the kitchen
furniture element should be removed in the area of the
cooking hob cutout. Furthermore, a gap of at least 6
mm should be left at the front side.
• The worktop should be installed completely horizontally.
• The cuto surfaces should be appropriately protected.
• Attach the fastening elements (4) with the supplied
screws (4) to the front and rear wall of the cooking hob
and the worktop cuto.
• Connect the cooking hob to the power mains and gas
supply (see instructions for connecting a cooking hob
on a power network and gas supply).
• For screwing down the fixing clip it is not allowed to use
screws longer than 6,5 mm.
Installation procedure
min 40
558-560
min 600488-490
min 40
60
min 50
R10
580
510
106-109
18
Kitchen worktop cuto
dimensions

444650
Type KVK4.., PVK4..
• Attach the supplied adhesive seal on the lower edge of
the cooking hob (do not glue the gasket over the front
support bracket).
19

444650
• The appliance may only be connected by an authorized skilled technician.
• Electric system protection should comply with all relevant regulations.
• The connection clips can be accessed when the connection clip covers are opened /
removed.
• Before connecting the appliance, make sure the voltage indicated on the rating plate is
consistent with the voltage in your home circuit.
• The rating plate with basic information is attached on the lower side of the hob.
• The electric circuit should also include an omnipolar switch that will separate the
appliance from the mains, if required, with at least 3 mm of distance between contacts.
Suitable devices include fuses, current protection switches, etc.
• The connection should be selected according to the installation possibilities with
regard to current and fuses.
• Given the protection from the risk of fire, appliances of this type may be installed in
a worktop next to a piece of kitchen furniture that is taller than the appliance (when
installed); however, in this case, a kitchen furniture element must be installed on the
other side, adjacent to the appliance.
• The current conducting and isolated parts must be protected from any possibility of
direct contact.
WARNING!
• Before any intervention, disconnect the appliance from the power mains. Connect the
appliance in compliance with the electric connections diagram supplied; make sure the
relevant network voltage is observed! The ground wire (PE) should be connected to
the clip indicated by the earthing symbol.
• The mains cable should be fed through the fastening clip which protects it from being
accidentally pulled out.
• After connecting the appliance, turn on all cooking zones / heaters for approximately
three minutes to make sure they are operating correctly.
Important warnings
‘’ The appliances are suitable for photovoltaic electrical
power under the condition that electrical voltage will
be 220VAC - 240VAC with semi tonic frequency 50Hz
in order the appliance to operate properly (alternative
a generator can be used with the same technical
characteristic).’’
• Incorrect connection may destroy parts of the appliance,
making the warranty void.
• Before connecting the appliance, make sure the voltage
indicated on the rating plate is consistent with the
voltage in your home network. Connection voltage
(230 V through N) should be checked by a qualified
technician using a corresponding measuring device!
Connection diagram
20
CONNECTING THE APPLIANCE TO
THE POWER MAINS
