Gorenje Simplicity MO235SYW User manual

WWW.GORENJE.COM
MO235SYW
MO235SYB

We sincerely thank you for your purchase. We believe you
will soon find ample evidence that you can really rely on
our products. To make the use of the appliance easier, we
attach these comprehensive instruction manual.
The instructions should aid you in getting familiar with
your new appliance. Please, read them carefully before
using the appliance for the first time.
In any case, please make sure the appliance was supplied
to you undamaged. Should you identify and transport
damage, contact your sales representative or the regional
warehouse from where the product was delivered. You
will find the telephone number on the receipt or delivery
report.
We wish you a lot of pleasure with your new household
appliance.
The appliance for household use for heating
food and beverages using electromagnetic
energy, for indoor use only.
Carefully read the instructions and save them for future
reference.
These instructions are intended for the user.
They describe the cooker and how to use it. They also
apply to dierent types of appliances, therefore you may
find some descriptions of functions that may not apply to
your appliance.
We reserve the right to any changes and errors in the
instructions for use.
DEAR CUSTOMER
EN
INSTRUCTIONS FOR
USE
MICROWAVE OVEN
64

65
Never touch the surfaces of heating
or cooking appliances. They will
become hot during operation. Keep
children at a safe distance. There is a
risk of burning!
Microwave energy & High voltage!
Do not remove the cover.
WARNING! The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age shall be kept away unless continuously supervised.
Children should be supervised to ensure that they do not
play with the appliance.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and maintenance shall
not be made by children unless they are older than 8 and
supervised.
Keep the appliance and its cord out of reach of children
less than 8 years.
• WARNING: When the appliance is operated in the
combination mode, children should only use the oven
under adult supervision due to the temperatures
generated; (Only for the model with grill function)
IMPORTANT SAFETY INSTRUCTIONS

66
• WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person;
• WARNING: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave
energy;
• WARNING: liquids and other foods must not be heated
in sealed containers since they are liable to explode.
• Children should be supervised to ensure that they do
not play with the appliance.
• Don't remove oven's feet, do not block air events of the
oven.
• Only use utensils that are suitable for use in microwave
ovens.
• When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition;
• If smoke is observed, switch o or unplug the appliance
and keep the door closed in order to stifle any flames;
• Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container;
• The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns;
• Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended;

67
• When cleaning surfaces of door, door seal, cavity of the
oven, use only mild, nonabrasive soaps, or detergents
applied with a sponge or soft cloth.
• The oven should be cleaned regularly and any food
deposits removed;
• Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
aect the life of the appliance and possibly result in a
hazardous situation;
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• Do not let the cord hang over the edge of the table or
worktop.
• Never connect this appliance to an external timer
switch or remote control system in order to avoid a
hazardous situation.
• Never replace the light bulb inside the oven. It must
always be replaced by Gorenje service.
• Do not clean the appliance with steam cleaners, high-
pressure cleaners, sharp objects, abrasive cleaning
agents, and abrasive sponges and stain removers.

68
Listed below are, as with all appliances, certain rules to
follow and safeguards to assure top performance from this
oven:
1. Always have the glass tray, roller arms, coupling and
roller track in place when operating the oven.
2. Do not use the oven for any reason other than food
preparation, such as for drying clothes, paper, or any
other nonfood items, or for sterilizing purposes.
3. Do not operate the oven when empty. This could
damage the oven.
4. Do not use the oven cavity for any type of storage,
such a papers, cookbooks, etc.
5. Do not cook any food surrounded by a membrane,such
as egg yolks, potatoes, chicken livers, etc without first
being pierced several times with a fork.
6. Do not insert any object into the openings on the outer
case.
7. Do not at any time remove parts from the oven such as
the feet, coupling, screws, etc.
8. Do not cook food directly on the glass tray. Place food
in/on proper cooking utensil before placing in the oven.
IMPORTANT - COOKWARE NOT TO USE IN YOUR
MICROWAVE OVEN
– Do not use metal pans or dishes with metal handles.
– Do not use anything with metal trim.
– Do not use paper covered wire twist-ties on plastic
bags.
– Do not use melamine dishes as they contain a
material which will absorb microwave energy. This
may cause the dishes to crack or char and will slow
down the cooking speed.
– Do not use Centura Tableware. The glaze is not
suitable for microwave use. Corelle Livingware
closed handle cups should not be used.
– Do not cook in a container with a restricted opening,
such as a pop bottle or sealed oil bottle, as they
may explode if heated in a microwave oven.
– Do not use conventional meat or candy
thermometers.
– There are the thermometers available specifically for
microwave cooking. These may be used.
9. Microwave utensils should be used only in accordance
with manufacturer's instructions.
10. Do not attempt to deep-fry foods in this oven.
11. Please remember that a microwave oven only heats
the liquid in a container rather than the container itself.
SAFETY INSTRUCTIONS
FOR GENERAL USE

69
Therefore, even though the lid of a container is not
hot to the touch when removed from the oven, please
remember that the food/liquid inside will be releasing
the same amount of steam and/or spitting when the lid
is removed as in conventional cooking.
12. Always test the temperature of cooked food yourself
especially if you are heating or cooking food/liquid for
babies. It is advisable never to consume food/liquid
straight from the oven but allow it to stand for a few
minutes and stir food/liquid to distribute heat evenly.
13. Food containing a mixture of fat and water,
e.g.stock,should stand for 30-60 seconds in the oven
after it has been turned o. This is to allow the mixture
to settle and to prevent bubbling when a spoon is
placed in the food/liquid or a stock cube is added.
14. When preparing/cooking food/liquid and remember
that there are certain foods, e.g. Christmas puddings,
jam and mincemeat, which heat up very quickly. When
heating or cooking foods with a high fat or sugar
content do not use plastic containers.
15. Cooking utensil may become hot because of heat
transferred from the heated food. This is especially true
if plastic wrap has been covering the top and handles
of the utensil. Potholders may be needed to handle the
utensil.
16. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend microwave
oven if paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from bags before placing
bag in oven.
c) If materials inside the oven should ignite, keep oven
door closed, turn the oven o at the wall switch, or
shut o power at the fuse or circuit breaker panel.

1. Door Safety Lock System
2. Oven Window
3. Roller Ring
4. Glass Tray
5. Control Panel
6. Wave guide (please do not remove the mica
plate covering the wave guide)
Grill rack (Only be used for grill or for
combination function and be placed on glass
tray
CONTROL PANEL
DISPLAY
(Cooking time, power, action indicators, and clock time
are displayed.)
TIME
FUNCTION BUTTON SIMPLICITY
START | STOP
(Press once to start a cooking program. Press
once to temporarily stop cooking. It is also
used for setting child lock.)
BUTTON FOR DOOR OPENING
70

71
INSTRUCTIONS FOR USE
The oven is fitted with a digital clock. When the oven is
in the standby mode, the clock can be set in the 24-hour
mode by pressing the CLOCK key.
For example: Suppose you want to set the oven clock time
to 8:30.
1. In standby mode, turn the function knob to the
CLOCK position.
2. Press and keys to set the time to 8:30.
3. Press button START | STOP once to confirm the hour
setting.
This function allows you to program a cooking program
to start at a later time.
For example: Suppose the present time is 9:00, and you
want the oven to start a 5 minutes gill cooking program at
10:30.
1. Turn the function button to DELAY START.
2. Press and keys to set the time to 10:30.
3. Turn the function button to GRILL program in
counter-clockwise direction.
4. Press the or directly to set the cooking time
5:00.
5. Press START | STOP to start.
NOTE:
When it is time to 10:30, the desired cooking program
starts automatically.
This function is used to prevent unsupervised operation
of the oven by little children. The CHILD LOCK indicator
will show up on display screen, and the oven can not be
operated while the CHILD LOCK is set.
To set the CHILD LOCK: In standby mode of the oven,
press button START | STOP and hold the button for 3
seconds, a beep sounds and lock indicator lights.
To cancel the CHILD LOCK: Press and hold the button
START | STOP for 3 seconds until lock indicator on display
turns o.
1. CLOCK
2. DELAY START
3. CHILD LOCK

72
V Put in a glass of water – 200ml – and turn the function
button to SELF CLEAN function. Press button START |
STOP to start.After 8 minutes remove the glass and wipe
the oven with dry cloth.
To shorten or extend the operating time, select the
appropriate function (microwave, grill…) and before
confirmation adjust the time by pressing or .
The Simplicity knob is used to set the desired function
(cooking, defrost, grill, etc.). Icons on the button represent
a typical food for this function, but are also applicable
to other, similar types of food. On the next page, the
table shows in detail the meaning and usage of individual
functions and pre-set times of each function. These can of
course be customized.
The function knob is also used to STOP or CANCEL the
selected function – just turn it to the start position »0«.
Tips for using the oven
Press the and keys simultaneously. The display
will turn o and the microwave is in Eco mode which
minimizes power usage.
To cancel the Eco mode and turn on the display again,
press any other button or open or close the door.
4. SELF CLEAN
FUNCTION
5. TIME ADJUSTMENT
6. SIMPLICITY KNOB
USAGE
7. ECO MODE – POWER
SAVING

73
Symbol Function Meaning Quantity Default time set Hint
Microwave 100% Cup of water
/ coffee /milk
/ tea
1 cup -
200ml 2 min 20 sec
For hotter drink or
bigger cup increase
time.
Microwave 100%
Pop-corn 1 bag -
100g 3 min 30 sec For bigger bag increase time.
Microwave 50%
Vegetable
300g –
carrots
(sliced)
4 min
Microwave 30%
Defrost Bread
0,5kg 20 min Decrease time for smaller pieces.
Grill 85%
Fish Fish 500g 25 min
Turn fi sh after 12,5min,
when signal beeps and
press again START |
PAUSE.
Microwave 30% +
grill 70% Pizza Pizza 350g 11 min
Microwave 40% +
grill 60%
Meat steak Meat steak
500g 35 min
For crispier steak on
both sides press
START/PAUSE button
5 minutes before end,
turn the steak and then
press START/PAUSE
again.
Microwave 10%
Staywarm 10 min
Clock Clock
Delay start Delay start
Microwave 100%
Self - clean 1 cup -
200ml 5 min

1. Turn the oven o and remove the power plug from
the wall socket before cleaning.
2. Keep the inside of the oven clean. When food
splatters of spilled liquids adhere to oven walls,wipe
with a damp cloth. The use of harsh detergent or
abrasives is not recommended.
3. The outside oven surface should be cleaned with
a damp colth. To prevent damage to the operating
parts inside the oven, water should not be allowed to
seep into the ventilation openings.
4. Do not allow the Control Panel to become wet. Clean
with a soft, damp cloth, Do not use detergents,
abrasives or spray-on cleaners on the control Panel.
5. If steam accumulates inside or around the outside
of the oven door, wipe with a soft cloth.This may
occur when the microwave oven is operated under
high humidity conditions and in no way indicates
malfunction of the unit.
6. It is occasionally necessary to remove the glass tray
for cleaning. Wash the tray in warm sudsy water or in
a dishwasher.
7. The roller ring and oven cavity floor should be
cleaned regularly to avoid excessive noise. Simply
wipe the bottom surface of the oven with mild
detergent, water or window cleaner and dry. The
roller ring may be washed in mild sudsy water or dish
washer. Cooking vapours collect during repeated use
but in no way aect the bottom surface or roller ring
wheels. When removing the roller ring from cavity
floor for cleaning, be sure to replace it in the proper
position.
8. Remove odors from your oven by combining a cup of
water with the juice and skin of one lemon in a deep
microwaveable bowl. Microwave for 5 minutes, wipe
thoroughly and dry with a soft cloth.
Do not throw away the appliance with the normal
household waste at the end of its life, but hand it in at an
ocial collection point for recycling. By doing this, you
help to preserve the environment.
ENVIRONMENT
74
CARE OF YOUR MICROWAVE OVEN

75
1. Make sure all the packing materials are removed from
the inside of the door.
2. Inspect the oven after unpacking for any visual damage
such as:
– Misaligned Door
– Damaged Door
– Dents or Holes in Door Window and Screen
– Dents in Cavity
If any of the above are visible, DO NOT use the oven.
3. This Microwave Oven weighs 15,5 kg and must be
placed on a horizontal surface strong enough to
support this weight.
4. The oven must be placed away from high temperature
and steam.
5. DO NOT place anything on top of the oven.
6. Keep the oven at least 20 cm away from both sidewalls
and 30 cm away from rear wall to ensure the correct
ventilation.
7. DO NOT remove the turn -table drive shaft.
8. As with any appliance, close supervision is necessary
when used by children.
9. Make sure that the AC outlet is easily accessible so
that the plug can be removed quickly in an emergency.
Otherwise, it should be possible to disconnect the
device using a switch from the circuit. In this case, the
existing provisions of the electrical safety standards are
considered.
The product has to be correctly installed on earthed
socket with a single-phase AC (230 V/50 Hz).
WARNING! THIS APPLIANCE MUST BE EARTHED!
10. This oven requires 1.4 KVA for its input consultation
with service engineer is suggested when installing the
oven.
CAUTION: This oven is protected internally by a 250V, 10
Amp Fuse.
INSTALLATION
MOUNTING THE MICROWAVE OVEN

76
Power consumption................................... 220-240V~50Hz, 1400W
Output power ...................................................................................... 900W
Grill heater......................................................................................1200W
Operating Frequency.................................................................2450MHz
Outside Dimensions....... 510mm(W) x 303mm(H) x 375mm(D)
Oven Capacity.................................................................................. 23 litres
Uncrated Weight ..............................................................Approx. 15,5 kg
Noise level.............................................................................Lc < 58 dB (A)
This appliance is marked according to the European
directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE).
This guideline is the frame of a European-wide
validity of return and recycling on Waste Electrical
and Electronic Equipment.
Microwave oven may cause interference to your radio, TV,
or similar equipment. When interference occurs, it may be
eliminated or reduced by the following procedures.
a) Clean the door and sealing surface of the oven.
b) Place the radio, TV, etc. as far away from your
microwave oven as possible.
c) Use a properly installed antenna for your radio, TV,
etc. to get a strong signal reception.
SPECIFICATIONS
MOUNTING
DIMENSIONS
RADIO INTERFERENCE
WE RESERVE THE RIGHT TO MAKE ANY CHANGES
THAT DO NOT AFFECT THE FUNCTIONALITY OF THE
APPLIANCE.

77
1. If the oven will not perform at all, the information
on the display does not appear or the display
disappeared:
a) Check to ensure that the oven is plugged in securely.
If it is not, remove the plug from the outlet, wait 10
seconds and plug it in again securely.
b) Check the premises for a blown circuit fuse or a
tripped main circuit breaker. If these seem to be
operating properly, test the outlet with another
appliance.
2. If the microwave power will not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely closed
to engage the safety interlocks. Otherwise, the
microwave energy will not flow into the oven.
If none of the above rectify the situation, then
contact the nearest authorized service agent.
The appliance for household use for heating food and
beverages using electromagnetic energy, for indoor use
only.
If you need information or if you have a problem, please
contact the Gorenje Customer Care Centre in your country
(you find its phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in your
country, go to your local Gorenje dealer or contact the
Service department of Gorenje domestic appliances.
Eventual mismatches in colour shades between dierent
appliances or components within a single design line may
occur due to various factors, such as dierent angles
under which the appliances are observed, dierent
coloured backgrounds, materials, and room illumination.
For personal use only!
Additional recommendations for cooking with
microwave and useful advices can be found on web
side:
http://www.gorenje.com
WISHES YOU A LOT OF PLEASURE WHILE USING YOUR
APPLIANCE
BEFORE YOU CALL FOR SERVICE
GUARANTEE & SERVICE

MO235SYW MO235SYB (03-20)
